INCLUDES
Two 5VDC/2A Power Supplies
Two SFP Modules
Two Pair IR Blasters
Two RS232 Connectors
• Transmission Up to 3300 Feet over Single Mode
• Video Resoluons up to 4K2K@50/60Hz
• Bi‐direconal Infrared Control
• RS‐232 Transmission
• Locking Power Adapters
• CE, RoHS Cerfied
• Single Fiber Simplex Operaon
CAMPLEXBroadcastFiberSoluons
812 Kings Highway • Saugeres, NY 12477
www.camplex.com
USERMANUAL
d
CamplexCMX‐HDMI‐SFP
HDMIoverFiberSFPExtender
SFP‐BasedTransmissionSystem
FEATURES
CMX‐HDMI‐SFPTRANSMITTER
Camplex CMX-HDMI-SFP USER MANUAL Page 2
CMX‐HDMI‐SFPRECEIVER
123
312
Front
56478910
Rear
Front
Rear
56789104
4 Connect Power Supply
5 Opcal—SFP Port
6 Connect to HDMI Source
7 Connect IR Receiver Cable. Place IR Receiver Header Close to Display Device’s IR Receiver
8 Connect IR Emier Cable. Place IR Emier Header Close to Source Device’s IR Receiver
9 RS‐232
10 Factory Use Only
1 System Power LED Indicator
2 Opcal Link LED Indicator
3 HDMI Input Signal LED Indicator
4 Connect Power Supply
5 Opcal ‐SFP Port
6 Connect to HDMI Display
7 Connect IR Receiver Cable. Place IR Receiver Header Close to Display Device’s IR Receiver
8 Connect IR Emier Cable. Place IR Emier Header Close to Source Device’s IR Receiver
9 RS‐232
10 Factory Use Only
1 System Power LED Indicator
2 Opcal Link LED Indicator
3 HDMI Input Signal LED Indicator
SPECIFICATIONS
Camplex CMX-HDMI-SFP USER MANUAL Page 3
Transmission
Distance
Single Mode: 3300 feet/1000 meters
Mulmode (OM3): 1000 feet/300 meters
IR Frequency 20KHz‐60KHz
RS‐232 Baud Rate 4800‐115200bps
Power Consumpon 3W
Power Input AC100 ‐240V 50/60Hz
Dimensions Each
Unit
6.375 (w/mounng ears) x 2.7 x 0.75in /
162 x 68.58 x 19.05mm
Weight TX: 9.03 oz/256g, RX: 9.17 oz/260g
Compliance HDMI 2.0b (18Gbps), HDCP 2.2, DVI
Video Bandwidth 18Gbps
Video Resoluons
4K2K@50/60Hz(YUV4:4:4)
4K2K@30Hz
1080P@120Hz
1080P 3D@60Hz
Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 8‐bit, 10‐bit, 12‐bit
HDMI Audio
Formats
LPCM 2/5.1/7.1CH
Dolby Digital
DTS 5.1
Dolby Digital+
Dolby TrueHD
DTS‐HD Master Audio
Dolby Atmos
DTS:X
CONNECTIONDIAGRAM
Transmi
Receiver
Single Fiber
LC‐LC Connecon
Single Mode
SAFETYPRECAUTIONS
10/16/2019Rev
1. To prevent fire or shock hazard, do not expose this equipment to high humidity and/or dust. Do not use in an unprotected
outdoor installaon nor any area classified as overly damp or wet.
2. The temperature for installaon should be between 32°F to 140°F (0°C to 60°C). Avoid direct sunlight exposure or extreme
changes of temperature over a short period of me.
3. Do not disassemble the unit or place it on an unstable base.
4. Do not drop the unit and avoid heavy impact.
5. This unit should not be placed in a built‐in installaon unless proper venlaon is provided. Any openings in the enclosure
must not be blocked or covered as they protect the unit from overheang.
6. Before cleaning, unplug the unit from all connecons. Use a clean, slightly damp cloth. Do not use liquid or aerosol cleaners.
Use appropriate cleaning kits for fiber opc cables.
7. Do not overload outlets and extension cords as this could result in a fire or electric shock.
8. Enclosure entry is dangerous. Never push objects of any kind, including liquids, into this unit through openings as they may
touch dangerous voltage points or short‐out parts that could result in a fire or electric shock.
9. Do not aempt to open or service this unit yourself as opening or removing covers may expose you to dangerous voltage
and other hazards.
10. There are no user‐serviceable parts inside the unit. If the unit requires service contact your authorized dealer, or an author‐
ized repair service company.
CAMPLEXBroadcastFiberSoluons
812 Kings Highway • Saugeres, NY 12477
www.camplex.com
