Camplex CMX-FMCH003-T User manual

4K60 HDMI over Fiber Extender Set
CMX-FMCH003
User Manual and
Specifications

Video
Audio
Power
Enclosure
Interfaces
1 10GbE LAN (SFP+)
1 HDMI (Type A)
1 USB (Mini-B)
5V/2.6A DC (Locking)
TBD
Chassis Material Metal (Steel)
Chassis Color Black
Dimensions 57mm×20.6mm×87mm [Case Only]
(W×H×D)60mm×20.6mm×87mm [All Inclusive]
Weight 139g
HDMI 2.0 (DVI 1.0)
2.2
4K@60 YUV 4:4:4
4K@60 YUV 4:4:4
Resolutions
LAN (Streaming)4096×2160p@60 YUV 4:4:4
HDMI4096×2160p@60 YUV 4:4:4
LPCM (8 Channels), Bitstream, High Bit Rate Bitstream
HDMI
Input Port
Output Port
Bi-directional Port
Control I/O
Power Supply
Power Consumption
HDMI Compliance
HDCP Compliance
Input Signal Types
Output Signal Types
Maximum Input
Maximum Output
Video
Audio
Power
Enclosure
Interfaces
HDMI 2.0 (DVI 1.0)
2.2
4K@60 YUV 4:4:4
4K@60 YUV 4:4:4
HDMI
SFP+ (Streaming)
1 HDMI (Type A)
1 10GbE LAN (SFP+)
1 USB (Mini-B)
5V/2.6A DC (Locking)
TBD
Metal (Steel)
Black
57mm×20.6mm×87mm [Case Only]
60mm×20.6mm×87mm [All Inclusive]
139g
4096×2160p@60 YUV 4:4:4
4096×2160p@60 YUV 4:4:4
LPCM (8 Channels), Bitstream, High Bit Rate Bitstream
HDMI
Chassis Material
Chassis Color
Dimensions
(W×H×D)
Weight
Input Port
Output Port
Bi-directional Port
Control I/O
Power Supply
Power Consumption
HDMI Compliance
HDCP Compliance
Input Signal Types
Output Signal Types
Maximum Input
Maximum Output
Resolutions
4K60 HDMI over Fiber Extender Set
RX
SPECIFICATIONS
TX
CMX-FMCH003

4K60 HDMI over Fiber Extender Set
CMX-FMCH003
1x UHD HDMI over Fiber Transmitter
1x UHD HDMI over Fiber Receiver
2x 5V/2.6A DC Power Adapter
2x Shockproof Feet (Set of 4)
A/V Extension Without RF Interference
Long Distance Data and Video Transmission
Household Entertainment, Lecture Halls, Meeting Rooms and Classrooms
Point to Point Secure Video Conference
HDMI source equipment such as a media player, video game console, PC or set-top box
Compatible fiber-based receiver
IEEE 802.3ae compatible SFP+ fiber module supporting a dual-optical fiber connection style,
such as LC, or a pre-terminated crossover dual-optial fiber cable
The Camplex CMX-FMCH003 extender set is designed for high quality 4K AV
extension over Single Mode or Multimode fiber (SFP+ dependent) with very minimum
latency. The compact size of the units allows for greater flexibility during installation.
Supports all HDMI 2.0 formats including multichannel PCM, Dolby True HD and DTS
HD master audio.
APPLICATIONS
INTRODUCTION
PACKAGE CONTENTS
SYSTEM REQUIREMENTS
NOTE: SFP Modules Sold Separately
Point-To-Point Extension of Audio, Video, and Control Signals
Supports a Full Range of Formats Including 4K60 RGB/4:4:4, HDR10, 3D and Broadcast-
Friendly 4K60 10-Bit 4:2:2
Extension Up To 30km (SFP+ Module Dependent)
Supports Single Mode or Multimode Fiber (SFP+ Module Dependent)
Supports Pass-Through of 10/12-Bit HDR Sources
Signal Transmission Interfaces With 10-Gigabit Ethernet Switches Via XFI
(IEEE 802.3ae) Compatible 10-Gigabit Ethernet Connector
FEATURES

4K60 HDMI over Fiber Extender Set
CMX-FMCH003
Front Panel:
Operation Controls and Functions
Power LED: This LED will illuminate to indicate the unit is on and receiving power
System LED: This LED will illuminate to indicate that the system is stable and ready to process
audio/video streams
Video LED: This LED will illuminate to indicate that the video source is stable, and streaming is in
process
HDMI IN Port: Connect to HDMI source equipment such as a media player, game console, or set-top
box
SFP Port: Insert a standard SFP+ module and connect the appropriate optical cable to allow data
transmission to a compatible receiver
1.
2.
3.
4.
5.
NOTE: SFP Modules Sold Separately
Service (USB Mini-B) Port: Factory use only
DC 5V Port: Plug the 5V DC power adapter into this port and connect it to an AC wall outlet for power
1.
2.
Rear Panel:

4K60 HDMI over Fiber Extender Set
CMX-FMCH003
Connection Diagram:
SYS
SYS
VIDEO
VIDEO
SERVICE
HDMI IN
HDMI IN
SFP+
SFP+
DC 5V
Smart TV
Media Player
HDMI
Output
HDMI
Input
Power
Supply
Power
Supply
TX
SERVICEDC 5V
RX

Supported Resolutions (Hz)
720x400p@70/85
640x480p@60/72/75/85
720x480i@60
720x480p@60
720x576i@50
720x576p@50
800x600p@56/60/72/75/85
848x480p@60
1024x768p@60/70/75/85
1152x864p@75
1280x720p@60
1280x768p@60/75/85
1280x800p@60/75/85
1280x960p@60/85
1280x1024p@60/75/85
1360x768p@60
1366x768p@60
1400x1050p@60
1440x900p@60/75
1600x1200p@60
1680x1050p@60
1920x1080i@50/60
1920x1080p@24/25/30
1920x1080p@50/60
2560x1440p@60RB
2569x1600p@60RB
3840x2160p@24/25/30
3840x2160p@50/60 (4:2:0)
3840x2160p@24 HDR10
3840x2160p@50/60 (4:2:0) HDR10
3840x2160p@50/60
4096x2160p@24/25/30
4096x2160p@50/60 (4:2:0)
4096x2160p@50/60 (4:2:0) HDR10
4096x2160p@50/60
4K60 HDMI over Fiber Extender Set
CMX-FMCH003
Video Specifications Supported:

Cable Length:
1080p
4K30
4K60
High Speed HDMI Cable
8-bit
12-bit
(4:4:4)
8-bit
(4:4:4)
8-bit
HDMI Input
1080P 8 BIT 15M
1080P 12 BIT 10M
4K30 (4:4:4) 8 BIT 5M
4K60 (4:4:4) 8 BIT 3M
15m
10m
5m
3m
Fiber Cable
Multimode Fiber (OM3)
300M (984 Feet)
Multimode Fiber (OM4)
550M (1804 Feet)
Single Mode Fiber
30 KM (18.6 Miles)
HDMI Input / 10 GbE Output:
LPCM:
Max Channels
8 Channels
Sample Rate (kHz)
32, 44.1, 48 kHz
Bitstream:
Supported Formats
Standard & High Definition
4K60 HDMI over Fiber Extender Set
CMX-FMCH003
Audio Specifications Supported:
Cable Specifications Supported:

812 Kings Highway | Saugerties, NY 12477 | [phone] | www.camplex.com
100% Employee Owned Division of Tower Products Incorporated
4K60 HDMI over Fiber Extender Set
CMX-FMCH003
Up to 1080p@60Hz, 12-bit color
Data rates lower than 5.3Gbps or below 225MHz TMDS clock
1080p (FHD Video)
4K@24/25/30Hz & 4K@50/60Hz (4:2:0), 8-bit color
Data rates higher than 5.3Gbps or above 225MHz TMDS clock but
below 10.2Gbps
4K30 (4K UHD Video)
4K@50/60Hz (4:4:4, 8-bit)
4K@50/60Hz (4:2:0, 10-bit HDR)
Data rates higher than 10.2Gbps
4K60 (4K UHD+ Video)
