OCTA-LITE FANS
8LEC SERIES
6-16’ Models
INSTALLATION
MANUAL
Custom Designed
Reduced Maintenance
STOL Technology
Patent pending

2 Canarm Octa-Lite 8LEC Series
IMPORTANT
!
READ AND SAVE THESE INSTRUCTIONS.
A printable, electronic version is available online at canarm.com.
Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read and understand the installation, operating and maintenance
instructions thoroughly before installing or servicing this equipment.
Une installation, un réglage, une modication, un service ou d’entretien peuvent causer des
dommages matériels, des blessures ou la mort. Lire et comprendre les instructions d’installation,
d’exploitation et d’entretien avant d’installer ou de réparer ce matériel.
To Reduce the Risk of Fire, Electric Shock, or Injury to Persons, Observe the Following:
Installation work and electrical wiring must be done by qualied person(s)
in accordance with all applicable codes and standards, including re-rated
construction. Failure to comply could result in personal injury, electric shock,
death, re and/or property damage.
Before attempting installation, servicing or cleaning unit, switch power off at the service panel and lock the
service disconnecting means to prevent power from being switched on accidentally.
Pour réduire le risque d’incendie, de choc électrique ou de blessures, observer les points suivants:
Les travaux d’installation et le câblage électrique doivent être effectués par une personne qualiée (s) en
conformité avec tous les codes et normes applicables, y compris la construction coupe-feu. Le non-respect
peut entraîner des blessures corporelles, de choc électrique, la mort, un incendie et / ou des dommages
matériels.
Avant d’entreprendre l’installation, l’entretien ou un nettoyage, coupez l’alimentation électrique
au panneau de service et bloquez les dispositifs de sectionnement pour éviter une mise en marche
accidentelle.
WARNING/AVERTISSEMENT
!
!
Single phase (115V or 230V) fans are shipped with a 115V
plug. Contact Canarm for 230V/1P wiring instructions.

Canarm Octa-Lite 8LEC Series 3
The installation must be in accordance with the requirements specied in this installation manual and with any
additional requirements set forth by the national electric code (NEC), ANSI/NFPA 70-1999, and all local codes.
Failure to comply with these codes could result in personal injury or property damage.
L’installation doit être en conformité avec les exigences spéciées dans le présent manuel d’installation et
avec des exigences supplémentaires prévues par le code électrique national (NEC), ANSI / NFPA 70-1999,
et tous les codes locaux. Le non respect de ces codes peut entraîner des blessures ou des dommages
matériels.
The installation of this fan requires the use of power tools. Follow the safety procedures found in the owner’s
manual of these tools and do not use them for purposes other than those intended by the manufacturer.
L’installation de ce ventilateur nécessite l’utilisation d’outils électriques. Suivez les consignes de sécurité
gurant dans le manuel du propriétaire de ces outils et ne pas les utiliser à des ns autres que celles prévues
par le fabricant.
This unit has an unguarded impeller. Do not use in locations readily accessible to people or animals.
Cet appareil possède une roue sans surveillance. Ne pas utiliser dans des endroits facilement accessibles
pour les personnes ou les animaux.
Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
The limited warranty does not cover equipment damage or failure that is caused by improper installation.
Utiliser cet appareil uniquement de la manière prévue par le fabricant. Si vous avez des questions,
contactez le fabricant. La garantie limitée ne couvre pas les dommages à l’équipement ou de l’échec qui
est causé par une mauvaise installation.
CAUTION/ATTENTION
!
IMPORTANT
!
This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

4 Canarm Octa-Lite 8LEC Series
Mini-Eppler Blades (patent pending)
8LEC Control and Power Assembly (patent pending)
MODEL DESCRIPTION WIDTH (X) LENGTH (Y) HEIGHT (Z) SHIPPING WEIGHT
8L06EC 6’ / 1.8M Fan 8” (203 mm) 36” (914 mm) 9” (229 mm) 22 lbs. (10 kg)
8L08EC 8’ / 2.4M Fan 8” (203 mm) 48” (1219 mm) 9” (229 mm) 27 lbs. (12 kg)
8L10EC 10’ / 3.0M Fan 8” (203 mm) 60” (1524 mm) 9” (229 mm) 33 lbs. (15 kg)
8L12EC 12’ / 3.6M Fan 8” (203 mm) 72” (1829 mm) 9” (229 mm) 38 lbs (17 kg)
8L14EC 14’ / 4.3M Fan 8” (203 mm) 84” (2134 mm) 9” (229 mm) 43 lbs. (20 kg)
8L16EC 16’ / 4.9M Fan 8” (203 mm) 96” (2438 mm) 9” (229 mm) 48 lbs (22 kg)
MODEL DESCRIPTION LENGTH WIDTH HEIGHT SHIPPING WEIGHT
8LEC Control & Power Assembly 30.5” (775mm) 33.0” (838mm) 30.5” (775mm) 140 lbs (64kg)
CONTENTS
1 Fan Diagram ..................................................................................................................................6
2 Important Information ...................................................................................................................7
3 Mounting Considerations .............................................................................................................8
4 Preparing the Work Site ................................................................................................................9
5 Mounting Method 1: I-Beam ......................................................................................................10
Mounting Method 2: Angle Iron ...........................................................................................11-15
Mounting Method 3: Purlins ...................................................................................................16-17
Mounting Method 4: Upper Truss ..........................................................................................18-19
6 Hanging the Fan .....................................................................................................................20-21
7 Installing Guy Wires .................................................................................................................22-23
8 Installing Blades ......................................................................................................................24-27
9 Electrical ..................................................................................................................................28-32
10 Troubleshooting ......................................................................................................................33-35
11 User Servicing Instructions ......................................................................................................36-37

Canarm Octa-Lite 8LEC Series 5
WHAT’S IN THE BOX
Prior to installation, verify that you have received all fan contents included with your system by
checking them against the packing list. Materials not included in the fan contents (e.g., Grade 5
hardware, etc.) are the responsibility of the installer. Notify your product representative or Canarm of
any discrepancy or missing kit contents prior to installing unit.
Extension Tube (x1)
Wingtip (x8) Blade (x8)
Motor & Chassis (x1)
Wingtip (x8)
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
AA
BB
CC
DD
SHEET
1
OF
1
DRAWN
CHECKED
QA
MFG
APPROV ED
sales 5/15/2019
DWG NO
19.05.15 IOM Page 5.p ng
TITLE
SIZE
D
SCALE
REV
3/4
Upper Yoke (x2)Blade Boomerang
Bracket (x8)
Boomerand Bracket (x8)
1
1
2
2
3
3
4
4
AA
BB
CC
DD
TBP Upper Yoke
DRAWN DATE:
19.04.10
DRAWN BY:
TH
PART NUMBER:
6001-S
REV:
_001
THIS DRAWING IS THE EXCLUSIVE PROPERTY OF SKYBLADE FA N COMPANY AND CANNOT BE REPRODUCED OR
DISCLOSED TO ANY TH IRD PARTY WITHOUT THE AUTHO RIZATION OF SKYBLADE FAN CO MPANY
MATERIAL:
1/5" Steel, RAL# 9006
ALL DIMENSION ARE IN INCHES
UNLESS OTHERWISE STATED
PKT 1 - Current PKT 2 - Current PKT 3 - Current
5Gripple Fasteners
4 15’ Guy Wires
1 5’ Safety Cable
Gripple Packet
Reference Controller Brochure for additional hardware.
8Soc Cap 5/16-18 x 5/8
8Soc Cap 5/16-18 x 3/4
16 Zinc Split Lock Washer 5/16
8BTN Cap Screw 10-32 X 3/8
Hardware Packet 2
(Blade Assembly)
4 Bolt - GR5 1/2” -13x 2 1/2”
4 Bolt - GR5 1/2-13x3-1/2”
16 Zinc Flat washer 1/2”
8Nylock Nut - GRC 1/2-13”
Hardware Packet 1
(Mounting Assembly)
1 Bolt - GR5 1/2”-13x3-1/2”
1 Bolt - GR5 1/2” - 13 x 2 1/2”
3 Zinc Flat Washer 1/2”
3 Nylock Nut - GRC 1/2”-13
2 Soc Cap 5/16”-18 x 3/4
2 Soc Cap 5/16”- 18 x 5/8
3Zinc Split Lock Washer M8
1 BTN Cap Screw 10-32 X 3/8
Hardware Packet 3
(Extra Hardware)

6 Canarm Octa-Lite 8LEC Series
SERIES 8LEC 8LEC 8LEC 8LEC 8LEC 8LEC
DIAMETER 6’ / 1.8M 8’ / 2.4M 10’ / 3.0M 12’ / 3.6M 14’ / 4.3M 16’ / 4.9M
BLADES 888888
VOLTAGE
INPUT
120/1
230/1
230/3
460/3
120/1
230/1
230/3
460/3
120/1
230/1
230/3
460/3
120/1
230/1
230/3
460/3
120/1
230/1
230/3
460/3
120/1
230/1
230/3
460/3
Model Number Ordering Format: SERIES-DIAMETER-BLADES-INPUT VOLTAGE-PHASE
Sample Model Number: 8LEC-1649-823-3
NOTE: 277V power source is not accepted.
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
AA
BB
CC
DD
SHEET
1
OF
1
DRAWN
CHECKED
QA
MFG
APP ROVED
sales 5/15/2019
DWG NO
19.05.15 IOM Page 5.png
TITLE
SIZE
D
SCALE
REV
0.25 : 1
1 FAN DIAGRAM
A. Safety Cable: Used as a redundant safety feature that secures the fan to the mounting structure.
B. Upper Yoke: Secures the fan to the structure and allows the fan to hang in a vertical direction.
C. Extension Bar: Extends the fan from the ceiling to reach optimum operating height.
D. Chassis: Housing for the motor and gear reducer
E. Blade: Provides air movement.
F. Wingtip Fence: Improves air movement efciency by reducing drag.
B
E

Canarm Octa-Lite 8LEC Series 7
2 IMPORTANT INFORMATION
2.1 Canarm Safety Components
Canarm fans are designed with redundant safety features to provide protection in the unlikely event
of a catastrophic failure. Follow installation instructions carefully when installing fans.
2.2 Fan Spacing’s and Placement
A standard ceiling fan should be mounted so that the bottom of the fans hub is 33 inches below the
bottom of the beam which it is mounted. Fan blades should be mounted between 10’ and 50’ above
the oor with optimum height between 20’-30’. If desired, extension bars are available to lower the fan
if needed. Avoid mounting fans directly below lights or skylights to avoid a strobe effect caused by
the moving blades.
When mounting a fan in an area where objects may be lifted or moved into the path of the fan,
Canarm recommends marking or painting hash lines on the oor to alert personnel of the above
movement of the fan.
The area within 15% of the diameter when the fan is at rest is considered “close clearance”. It is
extremely dangerous to mount the fans within “close clearance” of any object or path of object. We
strongly recommend not mounting the fan closer than 15% of its diameter to any object or its path. If
this is an issue, mounting extension bars and smaller fans are available from Canarm.
2.3 Fire Suppression Systems and Fan Placement
If installing Fans in a location where re sprinklers are in place, do not interfere with their correct
operation. Fans should be located in the center of each sprinkler quadrant and no less than 3 feet
below the sprinkler. Review all codes applicable to sprinkler systems prior to installation; it is the
customer’s responsibility to see that the installation is completed to code and that it is correct.
2.4 Shielded Motor Cable
To minimize electromagnetic interference and stray voltage, Canarm recommends the use of
shielded input voltage cable. This shielded system reduces the likelihood of broadcasting and
receiving electronic noise which can interfere with radio and other sensitive equipment. This shielded
motor cable and the controller cable must be run in separate conduit at least 6 inches apart.
Electrical interference and stray voltages are the liability of the installer and are not covered by
Canarm under warranty.
2.5 Check Compliance with Federal, State, and Local Codes
Check all relevant codes to make sure product certications, product listings, and building regulations
are met. Code compliance is the responsibility of the installer.

8 Canarm Octa-Lite 8LEC Series
3 MOUNTING CONSIDERATIONS
3.1 General Mounting
Each type of mounting system requires a specic mounting bracket. Most are available from Canarm.
Check with the contractor, building owner, or architect to ensure the structure is sound and will
support the weight of the fan before beginning installation. Canarm provides guidelines for mounting
fans; however, it is the sole responsibility of the building owner and installer to ensure the safety of the
mounting system, that the building structure is sound, and the installation complies with all federal,
state, and local codes.
3.2 Weight
A Standard 1.35-horsepower, 8LEC Series, 16 foot, 8-blade fan and mounting assembly weighs about
250 pounds. In inverted-blade applications designed to blow air upward, there is an additional
downward force of about 80 pounds due to fan thrust. We recommend applying a safety factor of 2
times the stated hanging weight of the fan when determining the capabilities of the building structure.
3.3 Safety Cable
A Canarm fan should never be run without proper installation of Safety Cables. These are supplied
with every fan. You must install safety cable for warranty to be in effect.
3.4 Guy Wires
While in operation a fan can sway due to minor imbalance or because of wind. Since the mounting
system is capable of swiveling, it will not stop fan movement, so it is important that the guy wires be
installed properly. Proper installation includes the angle and tension of the guy wires. See page 22-23
for more information.
3.5 Universal Mounting Hardware
We recommend mounting the fan to a horizontal structural beam, however, this is not always possible
in buildings with pitched roof construction. For this reason, our universal mounting system is designed
to allow the fan to hang in a level position perpendicular to the ground by rotating the upper yoke 90
degrees.
When cutting or drilling into a wall or ceiling, take care not to damage electrical wiring or other utilities.
Lorsque vous coupez ou percez un mur ou un plafond, prenez garde à ne pas endommager les ls
électriques ou d’autres services publics.
Select a location that is free from obstructions that may interfere with the fan’s operation.
Choisissez un emplacement qui est libre de tout obstacle pouvant interférer avec le fonctionnement
du ventilateur.
CAUTION/ATTENTION
!

Canarm Octa-Lite 8LEC Series 9
4PREPARING THE WORK SITE
4.1 Mechanical Installation
A 24’ (7.3m) 8LEC fan (our largest model) weighs, at maximum, 310 lbs (140kg). A scissor lift, or other
suitable means for lifting and a minimum of two installation personnel, will be required.
Canarm fans can be hung from a unistrut, angle irons, or an I-beam. See installation instructions on
the following page. Do not mount the fan to single purlins, trusses, or bar joists. Consult a structural
engineer for installation methods not covered in the manual.
The fan installation area and path must be free of obstructions such as lights, cables, sprinklers, or
other building structure. We strongly recommend not mounting the fan closer than 15% of its diameter
to any object or its path.
Do not install the fan where it will be continuously subjected to high winds (ex. Under a high velocity
HVAC system). Allow a required 2x the fans diameter between the fan and the HVAC (or other air-
moving) equipment when measured from the center of the fan to the equipment.
The spacing between multiple fans should be no less than 2.5x the fans diameter when measured
from the center of the fans.
The mounting structure must be able to withstand the torque which is generated by the fan. A 20’
diameter fan generates a maximum of nearly 300 ft-lb (406.7 N-m) of torque during operation.
4.2 Electrical Installation
To reduce the risk of electrical shock, wiring should be performed by a qualied electrician. Incorrect
assembly can cause electric shock or damage the motor and controller.
The installation of a Canarm fan must comply with the National Electrical Code, ANSI/NFPA 70-1999,
and all local codes.
All unused conductors that share conduit with the AC supply feeds must be grounded on both ends.
If required, a local disconnect should be installed per NEC and all local codes.
Refer to specications on page 31 for appropriate circuit requirements.
Each fan requires dedicated branch circuit protection.
(I-Beam Adapter Kit Required)
To reduce the risk of injury to persons, install the fan so that the blade(s) is at least 10 feet (3.05 meters)
above the oor.
Pour réduire le risque de blessures, installez le ventilateur de sorte que la lame (s) est d’au moins 10
pieds (3,05 mètres) au-dessus du sol.
CAUTION/ATTENTION
!

10 Canarm Octa-Lite 8LEC Series
5 MOUNTING METHOD 1: UNI-STRUT
5.1 Select Proper Unistrut:
NOTE: Unistrut and Unistrut hardware is not included with the fan. This equipment must be eld
supplied.
(2) 1-5/8” Unistrut Channels (not provided).
If the spanning distance is greater than 8 feet, please consult a structural engineer.
Span two (2) pieces of 1-5/8” Unistrut open side facing down and space apart so there is 12-7/8” from
outside edge to outside edge.
Once the Unistrut is in place, apply liquid thread lock to the recommended bolts and use the
remaining recommended hardware to attach the mount to the Unistrut.
Follow the table below when selecting Unistrut for fan installation. PLEASE NOTE: These are
recommendations. Canarm is not liable for accidents resulting from improperly sized mounting
methods. Please consult a structural engineer.
Unistrut Span
(between
mounting
point)
Minimum
Unistrut Size
(W x H x T)
Qty. of
Unistrut
Needed
< 8’ (2.4m) 1-5/8” 2
Support Directly From Building Structure.
All mounting instructions assume that the building structure from which the fan will be
hung is of sound construction, undamaged, and capable of supporting loads of up to
650 lbs (295 kg). It is the sole responsibility of the customer to verify that the building’s
structure is adequate for fan installation. Canarm recommends consulting with a
structural engineer prior to fan installation.
Aider directement à la structure du bâtiment.
Toutes les instructions de montage supposent que la structure du bâtiment à partir de laquelle le
ventilateur sera pendu est de construction solide, en bon état, et capable de supporter des charges
de jusqu’à 650 lb (295 kg). Il est de la seule responsabilité du client de vérier que la structure du
bâtiment est sufsante pour l’installation du ventilateur. Canarm recommande de consulter un
ingénieur en structure avant d’attiser installation.
WARNING/ AVERTISSEMENT
!

Canarm Octa-Lite 8LEC Series 11
5 MOUNTING METHOD 1:UNI-STRUT
5.2 Fasten Unistrut to Roof Structure Mounting Points:
Do not install the fan from a single purlin, truss, or bar joist.
Ne pas installer le ventilateur à partir d’une seule panne, botte, ou solives.
The unistrut must be fastened to the roof structure at each end.
L’Unistrut doit être xé à la structure du toit à chaque extrémité.
Fasten the unistrut to the roof structure mounting points at each end with customer-supplied Grade 5
hardware as shown.
Fixez l’unistrut aux points de xation de la structure du toit à chaque extrémité avec le matériel de
qualité 5 fourni par le client, comme illustré.
ATTENTION: Do not tighten the hardware until the upper yoke has been mounted to the unistrut.
Grade 5 Hardware (customer supplied)
a. (4) 1/2”-13 GR 5 Bolt
b. (8) 1/2” Flat Washer
c. (4) 1/2” Nylock Nut
d. (4) 2-1/2” Square Washer
b
b
a
d
c
1
1
2
2
3
3
4
4
A A
B B
C C
D D
(PART NAME HERE)
DRAWN DATE:
XX.XX.XX
DRAWN BY:
XX
PART NUMBER:
XXXX
REV:
_001
THIS DRAWING IS THE EXCLUSIVE PROPERTY OF SKYBLADE FAN COMPANY AND CANNOT BE REPRODUCED OR
DISCLOSED TO ANY THIRD PARTY WITHOUT THE AUTHORIZATION OF SKYBLADE FAN COMPANY
MATERIAL:
XXXXXXXX
ALL DIMENSION ARE IN INCHES
UNLESS OTHERWISE STATED

12 Canarm Octa-Lite 8LEC Series
5 MOUNTING METHOD 2:ANGLE IRONS
5.3 Select Proper Angle Irons:
NOTE: Angle Irons and angle iron hardware are not included with the fan.
Follow the table below when selecting angle irons for fan installation.
Never use clamping plate or clamping shims when mounting the fan to angle irons!
Ne jamais utiliser la plaque de serrage ou des cales de serrage lors du montage du ventilateur à
cornières!
Beam clamps are only intended for I-beam installations.
Serre-poutres sont uniquement destinées aux installations de faisceaux.
WARNING/AVERTISSEMENT
!
Do not install the fan from a single purlin, truss, or bar joist.
Ne pas installer le ventilateur à partir d’une seule panne, botte, ou solives.
Unsupported angle iron spans should not exceed 12’ (3.7m).
Non pris en charge travées de fer d’angle ne doit pas dépasser 12 pi (3,7 m).
Do not install motor and hub assembly directly on angle iron.
Ne pas installer moteur et moyeu directement sur cornière.
CAUTION/ATTENTION
!
6’ (1.8m) or less
over 6’ (1.8m) - 8’ (2.4m)
over 8’ (2.4m) - 12’ (3.7m)
Thickness
Height
Width
Angle Iron Span
(between
mounting point)
Minimum Angle
Iron Dimensions
(W x H x T)
Qty. of
Angle
Irons
Needed
6’ (1.8m) or less 2.5”(6.4cm) x 2.5”(6.4cm)
x .25”(.6cm) 2
over 6’ (1.8m) -
8’ (2.4m)
3”(7.6cm)
x 3”(7.6cm)
x .25”(.6cm) 2
over 8’ (2.4m) -
12’ (3.7m)
3”(7.6cm)
x 3”(7.6cm)
x.25”(.6cm) 4*
*2 pairs of angle irons. Pairs should be placed
back to back and fastened in center (see step 2).

Canarm Octa-Lite 8LEC Series 13
5 MOUNTING METHOD 2:ANGLE IRONS
5.4 Pre-Drill Angle Irons:
Drill two 9/16” (1.4cm) holes exactly 4” (10.16 cm) apart in the center of the two angle irons.
Measure the distance between the mounting points of the roof structure that the angle irons will span.
Measure the same distance on the angle irons and drill 9/16” (1.4cm) diameter holes through each
end of the angle irons. Drill holes in two angle irons if the span is 8’ (2.4m) or less. Drill holes in 4 angle
irons if span is greater than 8’ (2.4m).
5.5. Fasten Angle Irons Together (if span is longer than 8’)
If the angle iron span is 8’ (2.4m) or less, proceed to step 5.6a on the following page.
If the angle iron span is longer than 8’ (2.4m), it is necessary to use double angle irons.
Locate the center of the angle iron length. Drill 9/16” (1.4cm) diameter hole through the center of the
vertical wall of the angle iron. Drilling through a total of four angle irons.
Place two drilled angle irons back to back. Fasten the angle irons together with customer supplied
grade 5 hardware.
Align the angle irons to each other and tighten the bolts to 90 ft-lb (122 N-m) using a 3/4” socket with
torque wrench.
Proceed to step 5.6b.
Grade 5 Hardware (customer supplied)
a. (2) 1/2”-13 GR 5 Bolt
b. (4) 1/2” Flat Washer
c. (2) 1/2” Nylock Nut

14 Canarm Octa-Lite 8LEC Series
5 MOUNTING METHOD 2:ANGLE IRONS
5.6a Fasten Single Angle Iron to Roof Structure Mounting Points:
If installation requires double angle irons (i.e., span is greater than 8’(2.4m)), proceed to step 5.6b.
ATTENTION: Do not tighten the hardware until the upper yoke has been mounted to the angle irons.
Proceed to step 5.7.
Grade 5 Hardware (customer supplied):
a. (4) 1/2”-13 GR 5 Bolt
b. (8) 1/2” Flat Washer
c. (4) 2-1/2” Square Washer (see diagram)
d. (4) 1/2” Nylock Nut
2.5”
(6.4 cm)
9/16” Dia.
(1.4 cm) 2.5”
(6.4 cm)
Do not install the fan from a single purlin, truss, or bar joist.
Ne pas installer le ventilateur à partir d’une même purlin, botte, ou solives.
The angle irons must be fastened to the roof structure at each end.
Les cornières doivent être attachés à la structure de toit à chaque extrémité.
Fasten the angle irons to the roof structure mounting points at each end with customer-supplied Grade 5
hardware as shown.
Fixer les cornières aux points de xation de la structure du toit à chaque extrémité fourni par le client 5
e année du matériel comme indiqué.
CAUTION/ATTENTION
!

Canarm Octa-Lite 8LEC Series 15
5 MOUNTING METHOD 2:ANGLE IRONS
5.6b Fasten Double Angle Irons to Roof Structure Mounting Points:
ATTENTION: Do not tighten the hardware until the upper yoke has been mounted to the angle irons.
Proceed to step 5.7.
Grade 5 Hardware (customer supplied):
a. (4) 1/2”-13 GR 5 Bolt
b. (8) 1/2” Flat Washer
c. (4) 2-1/2” Square Washer (see diagram)
d. (4) 1/2” Nylock Nut
Do not install the fan from a single purlin, truss, or bar joist.
Ne pas installer le ventilateur à partir d’une même purlin, botte, ou solives.
The angle irons must be fastened to the roof structure at each end.
Les cornières doivent être attachés à la structure de toit à chaque extrémité.
Fasten the angle irons to the roof structure mounting points at each end with customer-supplied Grade 8
hardware as shown.
Fixer les cornières à la structure du toit de points de xation à chaque extrémité fourni par le client
matérielle la 8e année, comme illustré.
CAUTION/ATTENTION
!

16 Canarm Octa-Lite 8LEC Series
5 MOUNTING METHOD 2:ANGLE IRONS
5.7 Attach Upper Yoke (to Angle Iron):
Secure the upper yoke directly to the angle irons with the Beam Clamp hardware as depicted below.
Consult the diagrams below for distances between the angle irons. Do not install the fan from a single
purlin, truss, or bar joist.
Tighten bolts to 90 ft-lb (122 N-m) using a 3/4” socket and torque wrench.
Upper Yolk Hardware (supplied):
a. (4) 1/2”-13x2-1/2” GR 5 Bolt
b. (8) 1/2” Flat Washer
c. (4) 1/2”-13 Nylock Nut
1
1
2
2
3
3
4
4
AA
BB
CC
DD
Page. 16
DRAWN DATE:
XX.XX.XX
DRAWN BY:
XX
PART NUMBER:
XXXX
REV:
_001
THIS DRAWING IS THE EXCLUSIVE PROPERTY OF SKYBLADE FAN COMPANY AND CANNOT BE REPRODUCED OR
DISCLOSED TO ANY THIRD PARTY WITHOUT THE AUTHORIZATION OF SKYBLADE FAN COMPANY
MATERIAL:
XXXXXXXX
ALL DIMENSION ARE IN INCHES
UNLESS OTHERWISE STATED
a
b
b
c
Upper Yoke Side View
Upper Yoke Top View
1
1
2
2
3
3
4
4
AA
BB
CC
DD
Page. 16
DRAWN DATE:
XX.XX.XX
DRAWN BY:
XX
PART NUMBER:
XXXX
REV:
_001
THIS DRAWING IS THE EXCLUSIVE PROPERTY OF SKYBLADE FAN COMPANY AND CANNOT BE REPRODUCED OR
DISCLOSED TO ANY THIRD PARTY WITHOUT THE AUTHORIZATION OF SKYBLADE FAN COMPANY
MATERIAL:
XXXXXXXX
ALL DIMENSION ARE IN INCHES
UNLESS OTHERWISE STATED
The angle irons should be aligned with the innermost holes of the upper yoke.
Les fers angulaires doivent être alignés avec les trous les plus à l’intérieur de la culasse supérieure.
After attaching upper yoke to the angle irons, tighten all the bolts securing the angle irons to the roof
structure to 90 ft-lb (122 N-m) using a 3/4” socket with torque wrench.
Après l’avoir xée culasse supérieure aux cornières, serrer tous les boulons de xation des cornières à la
structure du toit à 90 lb-pi (122 Nm) avec une “prise 3/4 avec une clé dynamométrique.
CAUTION/ATTENTION
!
1
1
2
2
3
3
4
4
AA
BB
CC
DD
Page. 16
DRAWN DATE:
XX.XX.XX
DRAWN BY:
XX
PART NUMBER:
XXXX
REV:
_001
THIS DRAWING IS THE EXCLUSIVE PROPERTY OF SKYBLADE FAN COMPANY AND CANNOT BE REPRODUCED OR
DISCLOSED TO ANY THIRD PARTY WITHOUT THE AUTHORIZATION OF SKYBLADE FAN COMPANY
MATERIAL:
XXXXXXXX
ALL DIMENSION ARE IN INCHES
UNLESS OTHERWISE STATED
4.00”
(10.61 cm)
8-1/4”
(20.96 cm)

Canarm Octa-Lite 8LEC Series 17
5 MOUNTING METHOD 3: I-BEAM
NOTE: Mounting to I-beams requires the purchase of the I-beam Adapter Kit in lieu of standard Upper
Yoke from Canarm.
5.8 Attach I-Beam Adapter (to I-Beam)
Measure the ange width of the I-beam you are wanting to hang the fan from. Compare the I-beam
ange width to the diagram below to determine what mounting holes you will require.
Secure the upper yoke to the I-beam with the “Clamping Plate” hardware shown below. Tighten the
bolts to 90 ft-lb, (122 N-m) using a 3/4” socket and torque wrench.
Proceed to “Hanging the Fan” on pg. 21.
Clamping Plate Hardware (purchased separately):
a. (4) 1/2”-13x2 1/2” GR 5 Bolt
b. (8) 1/2” Flat Washer
c. (4) 1/2”-13 Nylock Nut
d. (2) Clamping Plate
Install the “Clamping Shims” only if the thickness of the I-beam ange exceeds 3/8” (1cm). The
mounting holes of the shim are closer to one side than the other. Make sure this side is facing the I-beam.
Installez les cales de serrage que si l’épaisseur de la semelle de la poutre supérieure à 3/8 “(1 cm).
Les trous de xation de la cale sont plus près d’un côté que de l’autre. Assurez-vous que ce côté est
confronté à la poutre
CAUTION/ATTENTION
!
I-Beam
Flange Width
Upper Yoke
Mounting Holes
5” (12.7cm)
8-3/8” (21.2cm) inner holes
>8-3/8” (21.2cm)
9” (22.8cm) outer holes
Outer Holes
Inner Holes
a
b
c
b
d
Clamping Plate

18 Canarm Octa-Lite 8LEC Series
d
c
b
a
e
5 MOUNTING METHOD 4: PURLINS
NOTE: Purlin brackets and hardware are available from Canarm upon request and not included
standard.
5.9 Selecting Proper Angle Irons
Select the proper angle irons based on the requirements stated under section 5.3.
5.10 Pre-Drill Purlins
Drill four 9/16” (1.4 cm) diameter holes centered vertically along the purlin spaced apart 4.5” (11.4
cm) horizontally and 1.5” (3.8 cm) vertically. These holes should match up perfectly with those of the
purlin bracket and back plate.
5.11 Attach Brackets and Backing Plates
Purlin mounting brackets and backing plates should be attached using the provided 1/2” grade 5
bolts, washers, and nylock nuts. A washer should be placed on both sides of the plate for each bolt.
5.12 Pre-Drill Angle Iron Brackets Holes
Your angle iron should be cut to allow 1/2” (1.27 cm) clearance between the end of the angle iron
and the purlin you are mounting to. Drill one 9/16” (1.4 cm) diameter hole centered vertically exactly
1” (2.54 cm) from the edge on both ends of the vertical wall of the angle iron. Drill a second hole
exactly 3” (7.6 cm) inward from the rst hole on both ends. Repeat for the second angle iron. These
holes will be used to secure the angle iron to the purlin bracket with the provided hardware.
5.13 Pre-Drill Angle Iron Fan Mounting Holes
Measure the distance between the mounting points that each angle iron will span. Drill two 9/16” (1.4
cm) diameter holes centered on the bottom wall of each angle iron. The two holes should be spaced
5.5” (13.9 cm) apart to best match those of the upper yolk. These holes will attach the upper yolk to
the angle iron.

Canarm Octa-Lite 8LEC Series 19
5 MOUNTING METHOD 4: PURLINS
5.14 Mount Angle Iron
Attach the angle irons to the brackets using the provided 1/2” grade 5 bolts, washers, and nylock nuts.
The angle irons must be facing outward secured to the outside faces of the purlin brackets.
5.15 Attach Upper Yoke to Angle Iron
Attach the upper yolk to the angle irons using the provided 1/2” grade 5 bolts, washers, and nylock
nuts. See section 5.7 “Attach Upper Yoke (to Angle Iron)” to continue installation.
Purlin Bracket Hardware (per set, supplied):
a. (2) 1/4” Formed Steel Purlin Bracket
b. (2) 1/4” Steel Purlin Backplate
c. (16) 1/2”-13-1 3/4” GR 5 Bolt
d. (16) 1/2” Nylock Nut
e. (32) 1/2” Flat Washer
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
AA
BB
CC
DD
SHEET
1
OF
1
DRAWN
CHECKED
QA
MFG
APPROV ED
sales 6/12/2019
DWG NO
19.07.01 Purlin Assembly Page. 19
TITLE
SIZE
D
SCALE
REV
0.2 : 1
d
a
c
eb

20 Canarm Octa-Lite 8LEC Series
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
AA
BB
CC
DD
SHEET
1
OF
1
DRAWN
CHECKED
QA
MFG
APP ROVED
sales 5/15/2019
DWG NO
19.05.15 IOM Page 5.png
TITLE
SIZE
D
SCALE
REV
0.25 : 1
6 HANGING THE FAN
Before installation all set screws must be checked, and tightened where necessary, before installation.
6.1 Attach Extension Tube (to Upper Yoke):
Attach the extension tube to the upper yoke with the hardware
shown.
Before tightening the bolts, allow the fan to hang freely from the
structure to allow the fan to rest perpendicularly from the oor.
Tighten bolts to 90 ft-lb (122 N-m) using a 3/4” socket and torque
wrench.
Single Pivot Hardware (supplied):
a. (2) 1/2” - 13x 3 1/2” GR 5 Bolt
b. (4) 1/2” Flat Washer
c. (2) 1/2”-13 Nylock Nut
Cable End Detail
The safety cable is a critical safety feature of the fan and must be installed correctly.
Le câble de sécurité est une caractéristique de sécurité essentielle de la soufante qui doit être installé
correctement.
WARNING/ AVERTISSEMENT
!
6.2 Secure Upper Safety Cable:
Secure the safety cable to the I-beam or angle iron by wrapping the safety cable around it, threading
the cable through the 17/32” open hole on the top of the extension tube, and securing the ends with
the gripple fastener as shown. The cable must have as little slack as possible. Securely tighten the
gripple.
1
1
2
2
3
3
4
4
AA
BB
CC
DD
Page. 20
DRAWN DATE:
XX.XX.XX
DRAWN BY:
XX
PART NUMBER:
XXXX
REV:
_001
THIS DRAWING IS THE EXCLUSIVE PROPERTY OF SKYBLADE FAN COMPANY AND CANNOT BE REPRODUCED OR
DISCLOSED TO ANY THIRD PARTY WITHOUT THE AUTHORIZATION OF SKYBLAD E FAN COMPANY
MATERIAL:
XXXXXXXX
ALL DIMENSION ARE IN INCHES
UNLESS OTHERWISE STATED
c
b
a
