CANchecked MFD28 User manual

!
!
!
!
Version v0.2d www.canchecked.de
Quickstart Guide
MFD28
Provided accessories
- Plug A, Plug B
- Precrimped cables
- Four fastening screws
- MicroSD card (installed)
- MicroSD adapter to SD
- Diffuse display foil
- 2x 1K1 pullup resistor (for NTC)
- additional pins for own crimps
More information
More information on the display and
other products and accessories you
can find online at:
www.canchecked.de
www.canchecked.de/mfd28/
Plug A:
Molex 43025-0800
Plug B:
Molex 43025-1000
Crimp:
43020-0001
PLUG
A
A1
A2
A3
A4
A5
A6
A7
A8
* future
GND
5V
AIN4
AIN3
12V
GND
AIN2
AIN1
Application
PLUG
B
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
RX2*
CANH
CANL
SHIFT
RX
TX2*
*
5V
GND
TX

!
!
!
!
Version v0.2d www.canchecked.de
Installation
When installing the display, you need to pay attention to a neat cabling. The power
cable needs to be fused with 5A. Connect ground to A1 and 12V to A5.
The measurements for the mounting hole and the screw holes can be found in the
upper drawing.
In addition, only the can bus cables (high/low) needs to be connected.
Implementation
After the start-up, the splash screen appears and after 5 seconds or tap on the screen
you will get forwarded to the first view.
The ten predefined views give you a rough guidance of what is possible to display.
By a tap on the screen, you can stop the display and you will see the following view:
Touch areas on the screen
1) Setup current widgets
2) Menu for setup
3) View back (current view -1)
4) View forward (current view
+1)
5) Backlight adjustment
6) Back to dataview
Optional accessories:
1) Shift light
2) Haldex control
3) Serial adapter for some special ECUs (e.g. VEMS)
4) Car specific bezels (replace the four fastening screws)
On questions regarding accessories or functionality please get in contact with us via
our homepage (
www.canchecked.de
) or via email (
[email protected]
).
1
2
1
6
3
4
5
