C&H M/MA Module Carrier AMi3000 User manual

C&H Technologies, Inc. •445 Round Rock West Drive •Round Rock, TX 78681-5012
[phone] •FAX [phone] •www.chtech.com
Software Support
•ANSI C Applications Library
•Applications Examples
•Board Detect software (DOS
Based)
•Configuration Program
•PLX Mon to provide user control
over PCI9050
Ordering Information
Description
AMi3000 M/MA Module Carrier
Part Number 11028380-0001
PCI Compliance
Complies with PCI specification 2.1
for Target Interfaces
Bi-directional FIFO for zero wait-
state operation
Configurable for memory mapped
and I/O mapped operation
Applications
•Selectable M Module interface
types in a single cPCI slot.
•Port customer interfaces from ITA
to a cPCI slot.
•cPCI ATE "glue logic".
Additional Information
This product is distributed in the
United Sates by C&H Technologies,
Inc.
Specifications:
Number of M/MA Modules
Carried:
•One (1) M or MA Module
M/MA Module Interface:
•A08/A24, D16/D32
M Module Interface Operation:
•Asynchronous to PCI Clock
Interrupts: INTA
Input/Output: Provided by M
Module
Temperature:
Operating: 0°C to 60°C
Storage: -20°C to 70°C
AMi3000
M/MA Module
Carrier
The Ami3000 M Module Carrier for
Compact PCI (cPCI) bus features a
compact high-performance PCI bus
gateway to the M Module interface.
One M Module mounting socket is
provided by this carrier.
The cPCI interface is PCI
Specification 2.1 compliant, Slave
Only. The PCI to M Module bridge
is implemented using the PCI9050
PCI Bus Target Interface Chip, by
PLX Technology, Inc.
