C&T Solution VIO-110R/MX100 User manual

VIO-100/MX100 Series
VIO-200/MX100 Series
Industrial Touch Monitors

VIO-100(200)/MX100 lUser’s Manual
Table of Contents
Prefaces …………………………………………………….……………………………………………. 04
Revision …………………………………………………………………………………………..……………….……….. 04
Disclaimer ………………………………………………………..…….…….………………………….……………….. 04
Copyright Notice …………………………………….…………………….…………………………………………… 04
Trademarks Acknowledgment …………..………………………………………………………...................04
Environmental Protection Announcement …………………………….………………….……………….. 04
Safety Precautions ………………………………………….……………………………….…………….………….. 05
Technical Support and Assistance …………………………………….…………….…………….…………….06
Conventions Used in this Manual ………………………………………………………………….….………..06
Package Contents …………………………………………………………………………………………….…………07
Ordering Information …………………………………….……………………………………….……….………… 08
Optional Accessory …………...……………………………………..................................................... 09
Chapter 1 Product Introductions ………………………………………………………..… 09
1.1 Overview ……………………….………………………………..………….…………………………..11
1.1.1 VIO-110R(C)/MX100 ………….…………..…………….……….…..……………....... 12
1.1.2 VIO-112R(C)/MX100 | VIO-212R(C)/MX100 ………..……..……………....... 13
1.1.3 VIO-115R(C)/MX100 | VIO-215R(C)/MX100 …………..…..……………....... 14
1.1.4 VIO-W115R(C)/MX100 | VIO-W215R(C)/MX100 …………………....... 15
1.1.5 VIO-117R(C)/MX100 | VIO-217R(C)/MX100 ……………….……………....... 16
1.1.6 VIO-119R(C)/MX100 | VIO-219R(C)/MX100 ……..………..……………....... 17
1.1.7 VIO-W121R(C)/MX100 | VIO-W221R(C)/MX100 ……………………….......18
1.2 System I/O ……………………………..……………………..………………………………………… 19
1.2.1 Rear ………………….…………...............................…………………………………… 19
1.2.2 Side (Right) ………….……………….……………………………………………………..... 19
1.2.3 Top ……………………..………………………………….…………..……….………………... 20
1.3 Mechanical Dimension …………………………..…………………………..………….………. 21
1.3.1 VIO-110R(C)/MX100 ………….…………..…………….……….…..……………....... 21
1.3.2 VIO-112R(C)/MX100 ………….……………………………………....……………....... 21
1.3.3 VIO-212R(C)/MX100 ………….………………………………..……..……………....... 22
1.3.4 VIO-115R(C)/MX100 ………….……………..……………..................................22
1.3.5 VIO-215R(C)/MX100 ………….……………………………..………..……………....... 23
1.3.6 VIO-W115R(C)/MX100 …….………………………………………….…..………....... 23
1.3.7 VIO-W215R(C)/MX100 …….…………………………………………….………......... 24
1.3.8 VIO-117R(C)/MX100 ………………………………..….……………..……………....... 24
1.3.9 VIO-217R(C)/MX100 …………………………………………………..……………....... 25
1.3.10 VIO-119R(C)/MX100 ………………………………………….……..……………....... 25
1.3.11 VIO-219R(C)/MX100 ………….……………………………………..……………....... 26
1.3.12 VIO-W121R(C)/MX100 ……………………………………………..……………....... 26
1.3.13 VIO-W221R(C)/MX100 …………………..………………………………………....... 27
Chapter 2 Front Panel Controls ……………………………………………………………. 28
2.1 Users Controls ………………………………………….…..…………………..…….……………....29
2.1.1 Power Button ………………………….……………………………………..………………29
2.1.2 LED ……………………………………………………………..………………………..……….. 29
2.1.3 MENU / Enter Button ……………….………………………………………………..…. 29
2.1.4 Increase Button …………………………..……………………………………………..…. 29
2.1.5 Decrease Button ……………….………………………………………………………..….29
2.1.6 AUTO / Exit Button ……………………………………………………………………..….29
2

VIO-100(200)/MX100 lUser’s Manual
3
2.2 OSD Operation ……………………………………………….…….……….…….………............. 30
2.2.1 Luminance ……………………………………………………………….………………..…. 30
2.2.2 Picture ……………………………………………………………………..………………..…. 31
2.2.3 Color …………………………………………………………………………..……………..…. 31
2.2.4 OSD Settings …………………………………………………….………………………..…. 31
2.2.5 Setup ……………………………………………………………………..…………………..….32
Chapter 3 System Setup …………………………..……………………………… 33
3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and
unscrewing ..……………………………………………………………………………………….…... 34
3.2 Connecting MX100 monitor module with VIO display module ………………… 34

VIO-100(200)/MX100 lUser’s Manual
4
Revision
Disclaimer
All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T
Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading.
The information in this document is subject to change without notice and does not represent a
commitment on the part of C&T Solution Inc.
C&T Solution Inc. disclaims all warranties, express or implied, including, without limitation, those of
merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must
take full responsibility for the application of the product.
Copyright Notice
All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,
without the prior written permission of C&T Solutions Inc. Copyright © 2015 C&T Solutions Inc.
Trademarks Acknowledgment
Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.
Windows® is registered trademark of Microsoft Corporation.
AMI is trademark of American Megatrend Inc.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation
All other products and trademarks mentioned in this manual are trademarks of their respective owners.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution
and ensure environment protection.
Prefaces
Revision
Description
Date
1.0
Manual Released
2016/10/06
Preface

VIO-100(200)/MX100 lUser’s Manual
5
Safety Precautions
Before installing and using the equipment, please read the following precautions:
Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
The power outlet shall be installed near the equipment and shall be easily accessible.
Turn off the system power and disconnect the power cord from its source before making any
installation. Be sure both the system and the external devices are turned OFF. Sudden surge
of power could ruin sensitive components. Make sure the equipment is properly grounded.
When the power is connected, never open the equipment. The equipment should be opened
only by qualified service personnel.
Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
Avoid the dusty, humidity and temperature extremes.
Do not place heavy objects on the equipment.
If the equipment is not used for long time, disconnect it from the power to avoid being
damaged by transient over-voltage.
The storage temperature shall be above -20°C and below 70°C.
The computer is provided with a battery-powered real-time clock circuit. There is a danger of
explosion if incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer.
If one of the following situation arises, get the equipment checked be service personnel:
•The power cord or plug is damaged.
•Liquid has penetrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well or it cannot work according the user’s manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Preface

VIO-100(200)/MX100 lUser’s Manual
6
Technical Support and Assistance
1. Visit the C&T Solution Inc website at www.candtsolution.com where you can find the latest
information about the product.
2. Contact your distributor, our technical support team or sales representative for technical support if
you need additional assistance. Please have following information ready before you call:
Model name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Conventions Used in this Manual
Preface
This indication alerts operators to an operation that, if not strictly observed,
may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly observed,
may result in safety hazards to personnel or damage to equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE

VIO-100(200)/MX100 lUser’s Manual
7
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
Preface
VIO
-110/MX100
Item Description Q’ty
1
VIO
-110/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
6
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-112/MX100
Item Description Q’ty
1
VIO
-112/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
10
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-115/MX100
Item Description Q’ty
1
VIO
-115/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
10
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-W115/MX100
Item Description Q’ty
1
VIO
-W115/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
8
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-119/MX100
Item Description Q’ty
1
VIO
-119/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
14
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-W121/MX100
Item Description Q’ty
1
VIO
-W121/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
12
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-117/MX100
Item Description Q’ty
1
VIO
-117/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
10
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-212/MX100
Item Description Q’ty
1
VIO
-212/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
10
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1

VIO-100(200)/MX100 lUser’s Manual
8
Preface
VIO
-215/MX100
Item Description Q’ty
1
VIO
-215/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
10
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-W215/MX100
Item Description Q’ty
1
VIO
-W215/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
8
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-217/MX100
Item Description Q’ty
1
VIO
-217/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
10
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-219/MX100
Item Description Q’ty
1
VIO
-219/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
14
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
VIO
-W221/MX100
Item Description Q’ty
1
VIO
-W221/MX100 Series Touch
Monitor
1
2
Panel Mount Kit
12
3
USB Cable
1
4
VGA Cable
1
5
Screw Pack
1
Ordering Information
Model No. Product Description
VIO-110R/MX100 10.4" SVGA Resistive Touch Monitor with 2x 5W Speaker
VIO-110C/MX100 10.4" SVGA Capacitive Touch Monitor with 2x 5W Speaker
VIO-112R/MX100 12.1" XGA Resistive Touch Monitor with 2x 5W Speaker
VIO-112C/MX100 12.1" XGA Capacitive Touch Monitor with 2x 5W Speaker
VIO-115R/MX100 15" XGA Resistive Touch Monitor with 2x 10W Speaker
VIO-115C/MX100 15" XGA Capacitive Touch Monitor with 2x 10W Speaker

VIO-100(200)/MX100 lUser’s Manual
9
Preface
Optional Accessories
Model No. Product Description
1
-E09A06002
Adapter AC/DC 12V 5A 60W with 3pin Terminal Block Plug 5.0mm Pitch
SFICBL022
Power Cord, 3
-pin US Type, 180cm
1
-TPCD00002
Power Cord, European Type, 180cm
1
-TPCD00001
Power Cord, 3
-pin UK Type, 180cm
Model No. Product Description
VIO-W115R/MX100 15.6" 16:9 FHD Resistive Touch Monitor with 2x 10W Speaker
VIO-W115C/MX100 15.6" 16:9 FHD Capacitive Touch Monitor with 2x 10W Speaker
VIO-117R/MX100 17" SXGA Resistive Touch Monitor with 2x 10W Speaker
VIO-117C/MX100 17" SXGA Capacitive Touch Monitor with 2x 10W Speaker
VIO-119R/MX100 19" SXGA Resistive Touch Monitor with 2x 10W Speaker
VIO-119C/MX100 19" SXGA Capacitive Touch Monitor with 2x 10W Speaker
VIO-W121R/MX100 21.5" 16:9 FHD Resistive Touch Monitor with 2x 10W Speaker
VIO-W121C/MX100 21.5 " 16:9 FHD Capacitive Touch Monitor with 2x 10W Speaker
VIO-212R/MX100 12.1" XGA Resistive Touch Thin Frame Monitor with 2x 5W Speaker
VIO-212C/MX100 12.1" XGA Capacitive Touch Thin Frame Monitor with 2x 5W Speaker
VIO-215R/MX100 15" XGA Resistive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-215C/MX100 15" XGA Capacitive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-W215R/MX100 15.6" 16:9 FHD Resistive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-W215C/MX100 15.6" 16:9 FHD Capacitive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-217R/MX100 17" SXGA Resistive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-217C/MX100 17" SXGA Capacitive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-219R/MX100 19" SXGA Resistive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-219C/MX100 19" SXGA Capacitive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-W221R/MX100 21.5" 16:9 FHD Resistive Touch Thin Frame Monitor with 2x 10W Speaker
VIO-W121C/MX100 21.5 " 16:9 FHD Capacitive Touch Thin Frame Monitor with 2x 10W Speaker

Chapter 1
Product Introductions

VIO-100(200)/MX100 lUser’s Manual
11
1.1 Overview
The VIO-100/MX100 and VIO-200/MX100 series touch monitor provide a wide selection of display sizes
are available from 10.4” to 21.5” with a format aspect of 4:3 and 16:9, and selected touch type. Featuring
with flat surface, IP 65 dust/waterproof front panel, and aluminum die-casting front frame with rugged
body structure, it is rugged and reliable for industrial environment. It also supports Multi-Mode Display
Module (MDM) technology which allows to configure, upgrade and maintain easily.
The VIO-100/MX100 and VIO-200/MX100 series supports both digital and analog signal input via three
types of display interface: VGA, DVI-D and DisplayPort. Touch screen can be connected with USB or COM
port. It also has multi-language OSD function for adjusting the view options of display. In addition,
supporting wide range power input from 9 to 48VDC and high reliability even operating in temperature
extremes.
Featuring with completely cable-less designed and high functional, VIO-100/MX100 and VIO-200/MX100
series are ruggedized display systems that can operate in harsh environments and easy to install and
maintain. A build in over voltage protection (OVP), over current protection and reverse protection DC
power input makes VIO-100/MX100 and VIO-200/MX100 series are safety system for all industrial
applications.
Chapter 1: Product Introductions

VIO-100(200)/MX100 lUser’s Manual
12
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 10.4” (4:3)
•Max. Resolution: 800 x 600 (SVGA)
•Brightness (cd/m2): 400
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.264 (H) x 0.264 (V)
•Viewing Angle (H-V): 160 / 130
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire: VIO-110R/MX100 Only
•Projected Capacitive: VIO-110C/MX100 Only
I/O
•VGA Input: 1x VGA Input
•DVI-D Input: 1x DVI-D Input
•DisplayPort Input: 1x DisplayPort Input
•USB 2.0 Input: 1x USB 2.0 Input
•COM Port Input: 1x COM Port Input
•Audio Input: 1x Audio Input
Other Features
•Internal Speaker: AMP 5W + 5W
•OSD:
- LCD On/Off, Auto, Menu, Up and Down
- Multi-language
Power
•Power Supply Voltage: 9-48VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~95% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•Dimension: 300 (W) x 238.5 (D) x 64.7 (H)mm
•Weight: TBC
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
1.1.1 VIO-110R(C)/MX100
Key Features
•10.4” TFT SVGA 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch
•1x VGA, 1x DVI-D, 1x DisplayPort, 1x USB 2.0, 1x COM, 1x Audio
•9 to 48VDC wide range power input
•-10°C to 60°C extended operating temperature
•Designed with Aluminum Die-Casting Front Frame
•IP65 Compliant Front Panel
•Two 5W Internal Speakers Built-in
•Multi-language OSD built-in

VIO-100(200)/MX100 lUser’s Manual
13
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 12.1” (4:3)
•Max. Resolution: 1024 x 768 (XGA)
•Brightness (cd/m2): 500
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.24 (H) x 0.24 (V)
•Viewing Angle (H-V): 160 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire:
VIO-112R/MX100 and VIO-212R/MX100 Only
•Projected Capacitive:
VIO-112C/MX100 and VIO-212C/MX100 Only
I/O
•VGA Input: 1x VGA Input
•DVI-D Input: 1x DVI-D Input
•DisplayPort Input: 1x DisplayPort Input
•USB 2.0 Input: 1x USB 2.0 Input
•COM Port Input: 1x COM Port Input
•Audio Input: 1x Audio Input
Other Features
•Internal Speaker: AMP 5W + 5W
•OSD:
- LCD On/Off, Auto, Menu, Up and Down
- Multi-language
Power
•Power Supply Voltage: 9-48VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~95% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•Dimension:
- VIO-112R(C)/MX100
338 (W) x 262 (D) x 61.7 (H)mm
- VIO-212R(C)/MX100
319 (W) x 257 (D) x 61.7 (H)mm
•Weight: TBC
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
1.1.2 VIO-112R(C)/MX100 | VIO-212R(C)/MX100
Key Features
•12.1” TFT XGA 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch
•1x VGA, 1x DVI-D, 1x DisplayPort, 1x USB 2.0, 1x COM, 1x Audio
•9 to 48VDC wide range power input
•-10°C to 60°C extended operating temperature
•Designed with Aluminum Die-Casting Front Frame
•IP65 Compliant Front Panel
•Two 5W Internal Speakers Built-in
•Multi-language OSD built-in

VIO-100(200)/MX100 lUser’s Manual
14
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 15” (4:3)
•Max. Resolution: 1024 x 768 (XGA)
•Brightness (cd/m2): 350
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.297 (H) x 0.297 (V)
•Viewing Angle (H-V): 170 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire:
VIO-115R/MX100 and VIO-215R/MX100 Only
•Projected Capacitive:
VIO-115C/MX100 and VIO-215C/MX100 Only
I/O
•VGA Input: 1x VGA Input
•DVI-D Input: 1x DVI-D Input
•DisplayPort Input: 1x DisplayPort Input
•USB 2.0 Input: 1x USB 2.0 Input
•COM Port Input: 1x COM Port Input
•Audio Input: 1x Audio Input
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD:
- LCD On/Off, Auto, Menu, Up and Down
- Multi-language
Power
•Power Supply Voltage: 9-48VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 65°C
•Relative Humidity: 10%~95% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•Dimension:
- VIO-115R(C)/MX100
397 (W) x 306 (D) x 64.7 (H)mm
- VIO-215R(C)/MX100
377 (W) x 301 (D) x 64.7 (H)mm
•Weight: TBC
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
1.1.3 VIO-115R(C)/MX100 | VIO-215R(C)/MX100
Key Features
•15” TFT XGA 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch
•1x VGA, 1x DVI-D, 1x DisplayPort, 1x USB 2.0, 1x COM, 1x Audio
•9 to 48VDC wide range power input
•-10°C to 60°C extended operating temperature
•Designed with Aluminum Die-Casting Front Frame
•IP65 Compliant Front Panel
•Two 10W Internal Speakers Built-in
•Multi-language OSD built-in

VIO-100(200)/MX100 lUser’s Manual
15
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 15.6” (16:9)
•Max. Resolution: 1920 x 1080 (Full HD)
•Brightness (cd/m2): 400
•Contrast Ratio: 700 : 1
•LCD Color: 16.7M
•Pixel Pitch (mm): 0.17925 (H) x 0.17925 (V)
•Viewing Angle (H-V): 160 / 140
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire:
VIO-115R/MX100 and VIO-W215R/MX100 Only
•Projected Capacitive:
VIO-W115C/MX100 and VIO-W215C/MX100 Only
I/O
•VGA Input: 1x VGA Input
•DVI-D Input: 1x DVI-D Input
•DisplayPort Input: 1x DisplayPort Input
•USB 2.0 Input: 1x USB 2.0 Input
•COM Port Input: 1x COM Port Input
•Audio Input: 1x Audio Input
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD:
- LCD On/Off, Auto, Menu, Up and Down
- Multi-language
Power
•Power Supply Voltage: 9-48VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 70°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~95% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•Dimension:
- VIO-W115R(C)/MX100
432 (W) x 261 (D) x 70.7 (H)mm
- VIO-W215R(C)/MX100
398 (W) x 247 (D) x 70.7 (H)mm
•Weight: TBC
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
1.1.4 VIO-W115R(C)/MX100 | VIO-W215R(C)/MX100
Key Features
•15.6” Full HD 16:9 LCD with Resistive 5-wire / Projected Capacitive Touch
•1x VGA, 1x DVI-D, 1x DisplayPort, 1x USB 2.0, 1x COM, 1x Audio
•9 to 48VDC wide range power input
•-10°C to 70°C extended operating temperature
•Designed with Aluminum Die-Casting Front Frame
•IP65 Compliant Front Panel
•Two 10W Internal Speakers Built-in
•Multi-language OSD built-in

VIO-100(200)/MX100 lUser’s Manual
16
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 17” (4:3)
•Max. Resolution: 1280 x 1024 (SXGA)
•Brightness (cd/m2): 350
•Contrast Ratio: 800 : 1
•LCD Color: 16.7M
•Pixel Pitch (mm): 0.264 (H) x 0.264 (V)
•Viewing Angle (H-V): 170 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire:
VIO-117R/MX100 and VIO-217R/MX100 Only
•Projected Capacitive:
VIO-117C/MX100 and VIO-217C/MX100 Only
I/O
•VGA Input: 1x VGA Input
•DVI-D Input: 1x DVI-D Input
•DisplayPort Input: 1x DisplayPort Input
•USB 2.0 Input: 1x USB 2.0 Input
•COM Port Input: 1x COM Port Input
•Audio Input: 1x Audio Input
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD:
- LCD On/Off, Auto, Menu, Up and Down
- Multi-language
Power
•Power Supply Voltage: 9-48VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~95% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•Dimension:
- VIO-117R(C)/MX100
431.5 (W) x 344 (D) x 70.5 (H)mm
- VIO-217R(C)/MX100
407.5 (W) x 339 (D) x 70.5 (H)mm
•Weight: TBC
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
1.1.5 VIO-117R(C)/MX100 | VIO-217R(C)/MX100
Key Features
•17” TFT SXGA 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch
•1x VGA, 1x DVI-D, 1x DisplayPort, 1x USB 2.0, 1x COM, 1x Audio
•9 to 48VDC wide range power input
•-10°C to 60°C extended operating temperature
•Designed with Aluminum Die-Casting Front Frame
•IP65 Compliant Front Panel
•Two 10W Internal Speakers Built-in
•Multi-language OSD built-in

VIO-100(200)/MX100 lUser’s Manual
17
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 19” (4:3)
•Max. Resolution: 1280 x 1024 (SXGA)
•Brightness (cd/m2): 350
•Contrast Ratio: 800 : 1
•LCD Color: 16.7M
•Pixel Pitch (mm): 0.264 (H) x 0.264 (V)
•Viewing Angle (H-V): 170 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire:
VIO-119R/MX100 and VIO-219R/MX100 Only
•Projected Capacitive:
VIO-119C/MX100 and VIO-219C/MX100 Only
I/O
•VGA Input: 1x VGA Input
•DVI-D Input: 1x DVI-D Input
•DisplayPort Input: 1x DisplayPort Input
•USB 2.0 Input: 1x USB 2.0 Input
•COM Port Input: 1x COM Port Input
•Audio Input: 1x Audio Input
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD:
- LCD On/Off, Auto, Menu, Up and Down
- Multi-language
Power
•Power Supply Voltage: 9-48VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~95% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•Dimension:
- VIO-119R(C)/MX100
470 (W) x 380 (D) x 71 (H)mm
- VIO-219R(C)/MX100
450 (W) x 375 (D) x 71 (H)mm
•Weight: TBC
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
1.1.6 VIO-119R(C)/MX100 | VIO-219R(C)/MX100
Key Features
•19” TFT SXGA 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch
•1x VGA, 1x DVI-D, 1x DisplayPort, 1x USB 2.0, 1x COM, 1x Audio
•9 to 48VDC wide range power input
•-10°C to 60°C extended operating temperature
•Designed with Aluminum Die-Casting Front Frame
•IP65 Compliant Front Panel
•Two 10W Internal Speakers Built-in
•Multi-language OSD built-in

VIO-100(200)/MX100 lUser’s Manual
18
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 21.5” (16:9)
•Max. Resolution: 1920 x 1080 (Full HD)
•Brightness (cd/m2): 300
•Contrast Ratio: 5000 : 1
•LCD Color: 16.7M
•Pixel Pitch (mm): 0.248 (H) x 0.248 (V)
•Viewing Angle (H-V): 178 / 178
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire:
VIO-W121R/MX100 and VIO-W221R/MX100 Only
•Projected Capacitive:
VIO-W121C/MX100 and VIO-W221C/MX100 Only
I/O
•VGA Input: 1x VGA Input
•DVI-D Input: 1x DVI-D Input
•DisplayPort Input: 1x DisplayPort Input
•USB 2.0 Input: 1x USB 2.0 Input
•COM Port Input: 1x COM Port Input
•Audio Input: 1x Audio Input
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD:
- LCD On/Off, Auto, Menu, Up and Down
- Multi-language
Power
•Power Supply Voltage: 9-48VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 60°C
•Relative Humidity: 10%~95% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•Dimension:
- VIO-W121R(C)/MX100
563.5 (W) x 336 (D) x 71 (H)mm
- VIO-W221R(C)/MX100
528.5 (W) x 324 (D) x 71 (H)mm
•Weight: TBC
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
1.1.7 VIO-W121R(C)/MX100 | VIO-W221R(C)/MX100
Key Features
•21.5” TFT FHD 16:9 LCD with Resistive 5-wire / Projected Capacitive Touch
•1x VGA, 1x DVI-D, 1x DisplayPort, 1x USB 2.0, 1x COM, 1x Audio
•9 to 48VDC wide range power input
•-10°C to 60°C extended operating temperature
•Designed with Aluminum Die-Casting Front Frame
•IP65 Compliant Front Panel
•Two 10W Internal Speakers Built-in
•Multi-language OSD built-in

VIO-100(200)/MX100 lUser’s Manual
DC IN
Used to plug a DC power input with terminal
block.
DVI-D
This 24-pin port is for PC (Personal Computer)
DVI-D digital signal connection.
VGA
Use the rear panel standard 15-pin female VGA
connector to connect the monitor to the system
graphics interface.
DisplayPort
The DisplayPort connector connects to a display
device with DisplayPort interface.
COM Port for Touch Panel Connector (Resistive
Touch Only)
Use the rear panel female DB-9 touch panel
connector to connect the monitor to the system
interface.
USB for Touch Panel Connector
Use the rear panel standard USB touch panel
connector to connect the monitor to the system
interface.
Audio-in
This port connects PC audio source by the
bundled audio cable.
19
1.2 System I/O
1.2.1 Rear
Chapter 1: Product Introductions
1.2.2 Side (Right)
PC/CAR mode select switch
Used to select PC or CAR power mode
12V/24V mode select switch
Used to select 12V or 24V Car power input
voltage
DELAY TIME switch
Used to select Car power turn off delay-time
Power LED
Indicates the power status of the monitor.
Suspend LED
Indicates the suspend mode of the monitor.

VIO-100(200)/MX100 lUser’s Manual
20
1.2.3 Top
Chapter 1: Product Introductions
VESA Mounting Hole
These are mounting holes for VESA mount (75x75mm and 100x100mm)
