Canon FY8-13FW-000DADF-A1 User manual

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
REVSION 0
DEC. 1998 FY8-13FW-000
DADF-A1

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
IMPORTANT
THIS DOCUMENTATION IS PUBLISHED BY CANON INC., JAPAN,TO SERVE AS A SOURCE
OF REFERENCE FOR WORK INTHE FIELD.
SPECIFICATIONS AND OTHER INFORMATION CONTAINED HEREIN MAY VARY SLIGHTLY
FROM ACTUAL MACHINE VALUES OR THOSE FOUND IN ADVERTISING AND OTHER
PRINTED MATTER.
ANYQUESTIONSREGARDINGINFORMATION CONTAINEDHEREINSHOULD BE DIRECTED
TO THE COPIER SERVICE DEPARTMENT OFTHE SALES COMPANY.
THISDOCUMENTATION ISINTENDED FORALL SALESAREAS,AND MAY CONTAIN INFOR-
MATION NOT APPLICABLETO CERTAIN AREAS.
COPYRIGHT © 1998 CANON INC.
Printed in Japan
Imprimé au Japon
Use of this manual should be strictly su-
pervised to avoid disclosure of confidential
information.
Prepared by
OFFICE IMAGING PRODUCTSTECHNICAL SUPPORT DEPARTMENT 1
OFFICE IMAGING PRODUCTSTECHNICAL SUPPORT DIVISION
CANON INC.
5-1, Hakusan, 7-chome,Toride-City, Ibaraki-Pref., 302-8501, Japan

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
i
INTRODUCTION
This Service Manual provides information needed to service the DADF in the field. This Service
Manual consists of the following chapters:
Chapter 1 “General Description” introduces the DADF’s features and specifications, and
shows how to operate it.
Chapter 2 “BasicOperation”introduces theADAF’s mechanicaland electricalsystems; italso
explains the principles used in these systems and the timing at which they are
operated with reference to the ADAF’s electrical circuitry.
Chapter 3 “Mechanical System” explains the ADAF’s mechanical construction and how its
parts may be disassembled/assembled and adjusted.
Chapter 4 “Maintenance and Servicing” provides tables of periodically replaced parts and
consumables/durables and scheduled servicing charts.
Chapter 5 “Troubleshooting” provides tables of maintenance/inspection, standards/
adjustments,andproblem identification(image fault/malfunction).
Appendix contains a general timing chart and general circuit diagrams.
The descriptions in this Service Manual are subject to change without notice for product
improvement or other purposes, and major changes will be communicated in the form of Service
Informationbulletins.
All service persons are expected to have a good understanding of the contents of this Service
Manual and all relevant Service Information bulletins, and be able to identify and isolate faults in the
machine.

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
iii
CONTENTS
CHAPTER 1 GENERAL DESCRIPTION
I. FEATURES ................................1-1
II. SPECIFICATIONS......................1-2
A. DADF-A1 ...............................1-2
III. NAMES OF PARTS ....................1-4
A. External View.........................1-4
B. Cross Section ........................1-4
IV. OPERATION...............................1-5
A. Original Set Indicator .............1-5
B. Warning and Actions..............1-5
C. Routine Maintenance by the
User.......................................1-6
CHAPTER 2 BASIC OPERATION
I. BASIC CONSTRUCTION...........2-1
A. Outline of the Electrical Circuitry.
...............................................2-1
B. Communication with the Copier
...............................................2-2
C. Inputs to the DADF Controller
PCB.......................................2-3
D. Outputs to the DADF Controller
PCB.......................................2-5
II. BASIC OPERATION...................2-6
A. Outline ...................................2-6
B. Operation...............................2-7
C. Detecting Originals ..............2-12
D. Picking Up Originals............2-17
E. Reversal ..............................2-25
F. Reduced Page Composition
.............................................2-27
G. Delivery ...............................2-34
H. Stamping Function...............2-40
I. Controlling the Pick-Up Motor
.............................................2-43
J. Controlling the Belt Motor
.............................................2-45
K. Detecting Original Jams
.............................................2-47
L. Improper Placement of
Originals ..............................2-50
III. POWRE SUPPLY.....................2-53
A. Outline .................................2-53

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
iv
CHAPTER 3 MECHANICAL SYSTEM
CHAPTER 4 MAINTENANCE AND SERVICING
I. BASIC CONSTRUCITON...........3-1
A. External Covers .....................3-1
B. Switches ................................3-3
C. Adjusting the DADF Height
...............................................3-5
II. DRIVE SYSTEM ........................3-6
A. Removing the Pick-Up
Motor Unit ..............................3-6
B. Removing the Feeder Motor Unit
...............................................3-6
C. Belt Motor ..............................3-7
D. Removing the Clutch Unit
...............................................3-9
E. Delivery Motor .....................3-10
III. FEEDING SYSTEM..................3-11
A. Pick-Up Roller .....................3-11
B. Removing the Separation
Belt Unit...............................3-12
C. Feeding Roller Unit .............3-12
D. Registration Roller...............3-14
E. Delivery/Resersing Roller
.............................................3-16
F. Delivery Roller Unit
(bottom Pick-up Mode).........3-20
G. Delviery Roller Unit
(top Pick-up Mode)...............3-20
H. Reversing Guide..................3-22
I. Stopper Plate Solenoid........3-24
J. Positioning the Paper Retaining
Plate Solenoid (SL2) ...........3-24
K. Positioning the Paper Deflecting
Solenoid (SL3).....................3-26
L. Stamp Solenoid ...................3-26
M. Feeding Belt ........................3-28
IV. CLEANING ...............................3-30
A. Belt Assembly......................3-30
B. Sensors ...............................3-30
C. Separation Flapper..............3-33
D. Separation Guide.................3-33
V. FEEDING .................................3-34
A. Pick-Up Drive Assembly......3-34
B. Right Delivery Drive
Assembly.............................3-34
I. PERIODICALLY REPLACED
PARTS........................................4-1
II. CONSUMABLES AND
DURABLES................................4-1
III. SCHEDULED SERVICING
CHART.......................................4-2

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
v
CHAPTER 5 TROUBLESHOOTING
APPENDIX
I. STANDARDS AND
ADJUSTMENTS ........................5-1
A. Mechanical System ...............5-1
B. Electrical System .................5-17
II. TROUBLESHOOTING..............5-20
A. Troubleshooting
Malfunctions ........................5-20
III. ARRAIGMENT OF THE ELECTRI-
CAL PARTS..............................5-24
A. Motors, Solenoids, and
Sensors ...............................5-24
B. PCB.....................................5-26
IV. VARIABLE RESISTORS, LIGHT-
EMITTING DIODES, AND CHECK
PINS BY PCB...........................5-27
A. DADF Controller PCB..........5-27
B. Indicator PCB ......................5-29
C. DIP Switch Functions ..........5-30
V. SELF DIAGNOSIS....................5-32
A. DADF Self Diagnosis ..........5-32
A. GENERAL TIMING CHART ...... A-1
B. NAMES AND ABBREVIATIONS OF
SIGNALS................................... A-4
C. DADF-A1 GENERAL CIRCUIT
DIAGRAM.................................. A-5
D. DADF CONTROLLER CIRCUIT
DIAGRAM.................................. A-6
E. DISPLAY BOARD.................... A-13
F. SPECIAL TOOLS..................... A-14
G. SOLVENTS AND OILS............ A-15

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 1
GENERAL DESCRIPTION
I. FEATURES .................................1-1
II. SPECIFICATIONS.......................1-2
A. DADF-A1 ...................................1-2
III. NAMES OF PARTS.....................1-4
A. External View.............................1-4
B. Cross Section ............................1-4
IV. OPERATION................................1-5
A. Original Set Indicator .................1-5
B. Warnings and Actions ................1-5
C. Routine Maintenance
by the User.................................1-6

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-1
CHAPTER 1 GENERAL DESCRIPITON
I. FEATURES
1. Two Types of Pick-Up Mode
Top pick-up: Pick-up starts with the top page.
Bottom pick-up: Pick-up starts with the bottom page.
2. Stamp Marking
The machine can mark originals with a stamp to indicate that they have been processed for fax
transmission.
3. Original Size Identification
The machine can identify the size of an original in terms of its length (feeding direction) and
width for communication to its host copier.

CHAPTER 1 GENERAL DESCRIPITON
1-2
COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
Item
Original pick-up
Original placement 1
Original placement 2
Original pick-up
Original type
Original size
Original tray
Delivery tray
Original processing
mode
Original size
identification
Residual original
detection
Continuous feeding
Size mix
Communication with
copier
Power supply
Maximum power
consumption
Weight
Dimensions (mm)
Serial No.
Operating conditions
Temperature Humidity
II. SPECIFICATIONS
A. DADF-A1
Specifications
Circulating, auto duplexing pick-up method
Face up
Center reference
Top pick-up
Bottom pick-up
Sheet (50 to 105 g/m2), single-sided sheet,
double-sided sheet
A5/STMT to A3/279×432 mm (11"×17")
If small size, 50 sheets, 5.5 mm high max.
(A5, B5, B5R, A4, A4R, STMT, LTR, LTRR)
If large size, 25 sheets (B4, A3, LGL,
279×432 mm (11"×17")
If small size, 50 sheets (A5, B5, B5R, A4,
A4R, STMT, LTR, LTRR)
If large size, 25 sheets (B4, A3, LGL,
279×432 mm (11"×17")
Single-sided, double-sided, reduce image
composition
Length (feeding direction) and width
Possible in conjunction with the host copier.
Possible
Possible
Possible
IPC 2
24 VDC (from the host copier)
170 W or less
14.1 kg (approx.)
684 (W) × 527 (D) × 161 (H)
AB ZLZ xxxxx
INCH/A ZNE xxxxx
A ZNF xxxxx
INCH/AB ZNG xxxxx
Same as the host copier.
Remarks
See p.2-17.
No extra length original.
Paper of 80 g/m2or less.
Paper of 80 g/m2or less.
Paper of 80 g/m2or less.
Paper of 80 g/m2or less.
For fax processing only.
Of the same width only.
For fax processing only.
Not including the
delivery tray.
Not including the
delivery tray.
Table 1-201
The above specifications are subject to change for product improvement.

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-3
CHAPTER 1 GENERAL DESCRIPITON
Note:
The following must not be used as originals:
• A transparency or paper with an opacity of 80% or less.
• A carbon-backed sheet.
• A sheet with paste-ups or binding.
• A sheet with a cut-off, hole, or tear.
• A sheet with a clip or glue.
• A sheet with curling, wrinkling, or creasing.
Caution:
Do not feed the same original more than 30 times to protect against damage.

CHAPTER 1 GENERAL DESCRIPITON
1-4
COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
III. NAMES OF PARTS
A. External View
[1] [2] [3] [4] [5] [6] [7] [8]
Figure 1-301
[1] Upper cover
[2] Side guide
[3] Re-circulating guide
[4] Original Set indicator
[5] Original tray
[6] Sub tray
[7] Body cover
[8] Original delivery tray
B. Cross Section
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10]
[16] [15] [14] [13] [12] [11]
Figure 1-302
[1] Delivery/reversing roller
[2] Paper deflecting plate
[3] Feeding roller
[4] Separation belt
[5] Separation flapper
[6] Pre-separation guide
[7] Delivery/pick-up roller
[8] Paper retaining plate
[9] Pick-up roller
[10] Delivery roller
[11] Feeding belt link roller
[12] Retaining rolls
[13] Feeding belt
[14] Paper stopper plate
[15] Feeding belt drive roller
[16] Registration roller

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-5
CHAPTER 1 GENERAL DESCRIPITON
IV. OPERATION
A. Original Set Indicator
The Original Set indicator turns on when
an original is placed on the original tray, and
flashes when an original jams.
A4/B5 A3/B4
Figure 1-401
Operation
1) If the original is B5R or larger or is A5 in
feeding length, open the original sub tray.
2) Set the side guide to suit the size of the
original.
Reference:
The side guide lock must be removed if
thewidthof theoriginalis largerthan 297
mm (A4/A3). For details, see 3. “Side
Guide Lock” on p. 3-3.
3) Place the originals with the first page on
top.
4) As needed, set the appropriate copying
mode on the copier.
5) Press the copier’s Copy Start key.
B. Warnings and Actions
If the Original Set indicator flashes while
an original is being fed, suspect a jam and
performthefollowing:
1) Remove the originals from the original
tray.
2) Openthe upper cover,and remove thejam.
Then, open the DADF to reset the
warning. (If any original is on the
copyboard glass, remove it.)
Caution:
If the jam is in the copier, the copier will
run jam recovery mode and will
automatically set the originals. Do not
open the DADF to reset.
3) Set the originals in correct order, and set
the stack in the DADF.

CHAPTER 1 GENERAL DESCRIPITON
1-6
COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
C. Routine Maintenance by the User
Instruct the user to clean the following at least once a week:
1. Copyboard Glass
Wipe it with a cloth moistened with water or alcohol; then, dry-wipe it.
2. Feeding Belt
Wipe it with water or alcohol.
3. Other Parts
Clean all other parts of the DADF (if soiled) using a solution of mild detergent; then, dry-wipe
them to remove any residue.
4. Feeding Belt and Feeding Roller
Execute cleaning mode in the copier’s user mode.
5. Stamp
If markings start to be fuzzy, replace the stamp using tweezers.
Stamp Tweezers
Figure 1-402
Caution:
Do not touch the stamp face. If your skin has come into contact with its ink, be sure to wash it
withwaterimmediately.

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 2
BASIC OPERATION
I. BASIC CONSTRUCTION ...........2-1
A. Outline of the Electrical
Circuitry......................................2-1
B. Communication with the Copier.2-2
C. Inputs to the DADF
Controller PCB...........................2-3
D. Outputs to the DADF Controller PCB
...................................................2-5
II. BASIC OPERATION....................2-6
A. Outline .......................................2-6
B. Operation ...................................2-7
C. Detecting Originals ..................2-12
D. Picking Up Originals ................2-17
E. Reversal ..................................2-25
F. Reduced Page Composition ....2-27
G. Delivery....................................2-34
H. Stamping Function...................2-40
I. Controlling the Pick-Up Motor..2-43
J. Controlling the Belt Motor ........2-45
K. Detecting Original Jams...........2-47
L. Improper Placement of
Originals ..................................2-50
III. POWRE SUPPLY......................2-53
A. Outline .....................................2-53

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
2-1
CHAPTER 2 BASIC OPERATION
I. BASIC CONSTRUCTION
A. Outline of the Electrical Circuitry
The machine’s electrical mechanisms are controlled by the DADF controller PCB. A
microprocessor (CPU) is used on the DADF controller PCB, and the microprocessor reads the input
signals from the sensors and the copier and generates signals used to drive DC loads (motors,
solenoids) at such times as programmed in advance.
Sensor
Variable
resistor
DADF controller PCB
CPU
(Q1)
ROM
(Q2)
RAM
(Q4)
Communication
IC(Q3)
24V
J2-1 J1-6
5V
5 VDC
power
supply
Power supply
circuit
Copierk
Motor
Solenoid
Clutch
Brake
Indicator
LED PCB Motor
Figure 2-101

CHAPTER 2 BASIC OPERATION
2-2
COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
B. Communication with the Copier
The operation modes selected on the copier are communicated to the machine in an IPC
communication method. Likewise, the operation states of the machine are communicated to the
copier in an IPC communication.
If an error occurs in the IPC communication, the copier’s self diagnosis function turns on to
indicate “E400” or “E712” on its control panel.
Communication
IC
Communication
IC
CPUCPU
RSOUT
RSIN
Copier DADF
Figure 2-102

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
2-3
CHAPTER 2 BASIC OPERATION
C. Inputs to the DADF Controller PCB
1. Inputs to the DADF Controller PCB (1/2)
DADF switch
MS1
MS2
S1 J203
J205
LED3
S3
S4
S5
S6
S7
J212
COM J2-3 +24V
+5V
+5V
+5V
+5V
+5V
+5V
RFC
EMPS
ENTS
CVRSW
DCTS
EJTS1
SPRS
UPCC1
-4
1-2
J5-7
J9-B10
-B9
-B12
J9-B6
J5-3
J9-A1
J9-A4
-A6
-A5
-A3
-A2
-1
-2
-B8
-B7
-B11
-8
-9
3
1
21
3
1
2
3
J207
J208
1
2
3
1
2
3
1
2
3
1
2
1
3
2
1
3
2
3
1
2
2
41
2
J3-
NO
COM
NO
Upper cover switch
Original tray
paper sensor
Registration
paper sensor
Upper cover
sensor
Pick-up roller sensor
Delivery sensor 1
Pick-up sensor
DADF controller PCB
When the RDF is open, '0'.
When the upper cover is open, '0'.
When an original blocks the sensor, '1'.
When an original blocks the sensor, '1'.
When the upper cover is open, '0'.
(The light-blocking plate is at the sensor.)
When the pick-u roller is
at the home position, '1'.
(The light-blocking plate is at the sensor.)
When an original is detected, '1'.
(The light-blocking plate is at the sensor.)
When an original is detected, '1'.
(The light-blocking plate is at the sensor.)
Figure 2-103

CHAPTER 2 BASIC OPERATION
2-4
COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
Reversal sensor S8
3
1
2
J209 3
1
2
J9-A7
-A9
-A8
+5V
1
3
2
Feeder motor
clock sensor S9
1
2
3
J9-A12
-A11
-A10
+5V
Belt motor
clock sensor S10
1
2
3
J9-B5
-B4
-B3
+5V
Registration roller
clock sensor S11
1
2
3
J5-4
-5
-6
+5V
Delivery sensor 2 S12
3
1
2
J219 3
1
2
J14-4
-6
-5
+5V
1
3
2
1
2
3
4
5
6
3
2
1
Delivery motor
clock sensor
Re-circulation
sensor
Original width
detecting VR
S13
S14
J219 J14-3
-2
-1
+5V
+5V
+5V
WIDTH
RSS
ECLK
RCLK
BCLK1
FCLK
TURNS
EJTS2
J8-3
-2
-1
J101-3
-2
-1
J218 1
2
3
J8-7
-8
-9
3
2
1
Display PCB
DADF controller PCB
When an original is detected, '1'.
(When the light-blocking plate is
at the sensor.)
While the feeder motor is rotating,
alternates '1' and '0'.
While the feeder motor is rotating,
alternates '1' and '0'.
While the feeder motor is rotating,
alternates '1' and '0'.
When an original is detected, '1'.
(When the light-blocking plate is
at the sensor.)
While the delivery motor is rotating,
alternates '1' and '0'.
When the re-circulation bar is set
on the top original, '1'.
Detects the width of the original
stacked on the original tray.
2. Inputs to the DADF Controller PCB (2/2)

COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
2-5
CHAPTER 2 BASIC OPERATION
D. Outputs to the DADF Controller PCB
1. Outputs to the DADF Controller PCB (1/1)
Stopper plate solenoid When '0', the solenoid (SL1) turns on.
(The stopper plate moves down.)
SL1
J217 1
2
J5-10
-11
+24V
STPSL
2
1
Paper retaining plate
solenoid When '0', the solenoid (SL2) turns on.
(The paper retaining plate moves down.)
SL2
J216 1
2
J5-12
-13
+24V
WGTSL
2
1
Stamp solenoid When '0', the solenoid (SL4) turns on.
(The stamp puts a marking on the
original.)
SL4
J220 1
2
J14-9
-10
+24V
SMPSL
Clutch When '0', the clutch (CL1)
turns on.
CL
J13-1
-2
+24V
CL
Brake When '0', the brake (BK1)
turns on.
BK
J6-1
-2
+24V
BK
Pick-up motor See p. 2-43.
M1
J12-1
-2
Feeder motor When '0', the feeder motor (M2)
turns on.
M2
J11-1
-2
+24V
FMPWM
Belt motor
Delivery motor
See p. 2-45.
M3
J7-1
-2
When '0', the delivery motor (M5)
turns on.
M5
J14-8
-7
+24V
EMPWM
Re-circulation motor
Display PCB
LED101
LED102
When '0', the re-circulation motor (M4)
turns on.
M4
J8-5
-6
-3
-4
J102-1
-2 J101 -5
-6
-3
+5V
RSDRV
When '0', the Original Set indicator
turns on.
+5V
ORGLED
2
1
1
2
3
2
J221
J101-4
Paper deflecting plate
solenoid When '0', the solenoid (SL3) turns on.
(The paper deflecting plate operates.)
SL3
J9-B2
-B1
+24V
FLPSL1

CHAPTER 2 BASIC OPERATION
2-6
COPYRIGHT © 1998 CANON INC. CANON DADF-A1 REV.0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
II. BASIC OPERATION
A. Outline
The machine uses four motors and one clutch to pick up, feed, and deliver originals.
Thepick-upmotor (M1)servesto pickup originals. Thefeeder motor (M2)serves toreverseand
deliver originals. The belt motor (M3) moves and stops originals to and on the copyboard glass, and
delivers them. The delivery motor (M3) operates to deliver originals to the delivery tray.
The clutch (CL) is used to engage or disengage the drive of the feeder motor (M2) and the belt
motor(M3).

DADF controller PCB
Indicator
PCB
Belt motor drive signal
Feeder belt brake drive signal
Belt motor clock signal
Clutch drive signal
Feeder motor clock signal
Feeder motor drive signal
Reversal/feeder paper detection signal
Paper deflecting plate solenoid drive signal
Delivery detection signal 1 Pick-up registration signal Pick-up paper detection signal
Upper cover open/closed detection signal 2
Original tray paper signal Pick-up roller home position detection signal
Paper holding solenoid drive signal
Stopper plate solenoid drive signal
Registration roller clock signal
Last original detection signal Original set indicator ON signal
Re-circulator motor drive signal
Pick-up motor drive signal
Delivery motor clock signal
Delivery motor drive signal
Delivery detection signal 2
Stamp solenoid drive signal
S9
M2
CL SL3
S6
S7
S3
S11
SL1
S4 SL2
M1
S14
M4
S13 M5
S12
SL4
S5
S1
S8
S10
BK M3
Figure 2-201
