Canon MF4010 Series Setup guide

1
ENG
2
3
4
Table of Contents
Index How to Use This Guide
TOP
Back Previous Next
Please read this guide before operating this product.
After you finish reading this guide, store it in a safe place
for future reference.
Advanced Guide
Series
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix

1
2
3
4
TOP
Back Previous Next
i
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Manuals for the Machine
●Machine Set-Up
●Software Installation
●Basic Features
●Maintenance
Starter Guide
●Basic Features
●Maintenance
●Machine Settings
●Specifications
Basic Guide
●Advanced Features
●System Monitor
●Troubleshooting Advanced Guide
(This Document)
●Scanning Features
Scanner Driver Guide
Indicates the manual is supplied in PDF format in the accompanying CD-ROM.
●To view the manual in PDF format, Adobe Reader/Adobe Acrobat Reader is required. If Adobe Reader/
Adobe Acrobat Reader is not installed on your system, please download it from the Adobe Systems
Incorporated website.
●Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions.
However, as we are constantly improving our products, if you need an exact specification, please contact
Canon.
●The machine illustration on the cover may differ slightly from your machine.
CD-ROM
CD-ROM
CD-ROM
CD-ROM

1
2
3
4
TOP
Back Previous Next
ii
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Legal Notices
Trademarks
Canon and the Canon logo are trademarks of Canon Inc.
All other product and brand names are registered trademarks, trademarks or service marks of their respective owners.
Copyright
Copyright © 2007 by Canon Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual, or otherwise, without the prior written permission of Canon Inc.
Disclaimers
The information in this document is subject to change without notice.
CANON INC. MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, EITHER EXPRESS OR IMPLIED, EXCEPT AS
PROVIDED HEREIN, INCLUDING WITHOUT LIMITATION, THEREOF, WARRANTIES AS TO MARKETABILITY, MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE OF USE OR NON-INFRINGEMENT. CANON INC. SHALL NOT BE LIABLE FOR ANY DIRECT,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM THE USE OF THIS
MATERIAL.

1
2
3
4
TOP
Back Previous Next
Table of Contents
Index iii
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Things You Can Do
Select a scan mode depending
on the type of image
Image Quality
→Basic Guide
Adjust the density level of
scanned images
Density
→Basic Guide
Enlarge or reduce copied
images
Zoom Ratio
→Basic Guide
ABC
ABC
ABC
ABC
AA
Sort copies by page order
Collate Copy
→p. 1-2
Copy two documents on one
sheet
2 on 1 Combination
→p. 1-3
Print a document from a PC
Printing
→Online Help
DDDD
DDDD
DDDD
DDDD
4
CCCC
CCCC
CCCC
CCCC
3
BBBB
BBBB
BBBB
BBBB
2
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1
ABC
ABC
ABC
ABC
1
DEF
DEF
DEF
DEF
2
DEF
DEF
DEF
DEF
2
ABC
ABC
ABC
ABC
1
ABC
ABC
ABC
ABC
1
D
E
F
D
EF
Specify detailed scanning
options to suit various images
Scanning
→Scanner Driver Guide
ABC
ABC
ABC
ABC

1
2
3
4
TOP
Back Previous Next
iv
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Table of Contents
Manuals for the Machine ................................................................................i
Legal Notices................................................................................................ ii
Things You Can Do ..................................................................................... iii
How to Use This Guide.................................................................................vi
Using the Top Page ...............................................................................vi
Using the Chapter Topic List................................................................. vii
1 Advanced Copy Features.............................................................................................. 1-1
Advanced Copy Features .......................................................................... 1-2
Collate Copy........................................................................................ 1-2
2 on 1 Combination ............................................................................. 1-3
Canceling Copy Jobs................................................................................. 1-4
Canceling a Job While Scanning ........................................................ 1-4
Canceling a Job While Printing ........................................................... 1-4

1
2
3
4
TOP
Back Previous Next
v
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
2 System Monitor .............................................................................................................. 2-1
Checking Job and Machine Status ............................................................ 2-2
Checking Print Status.......................................................................... 2-2
Checking Print and Scan Counts ........................................................ 2-2
3 Troubleshooting............................................................................................................. 3-1
General Problems...................................................................................... 3-2
Paper Feeding Problems........................................................................... 3-4
Copying Problems ..................................................................................... 3-5
Printing Problems ...................................................................................... 3-6
4 Appendix......................................................................................................................... 4-1
Glossary .................................................................................................... 4-2
Index.......................................................................................................... 4-3

1
2
3
4
TOP
Back Previous Next
vi
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
How to Use This Guide
■Using the Top Page
1
ENG
2
3
4
Table of Contents
Index How to Use This Guide
TOP
Back Previous Next
Please read this guide before operating this product.
After you finish reading this guide, store it in a safe place
for future reference.
Advanced Guide
Series
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Displays the previous or next page.
Returns to the last page opened.
Returns to the top page.
Displays the “How to Use This Guide” page.
Quick links to the list of things you can do, topics
for each chapter, table of contents, and the index.

1
2
3
4
TOP
Back Previous Next
vii
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
■Using the Chapter Topic List
1
2
3
4
TOP
Back Previous Next
1-1
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
1 Advanced Copy Features
Advanced Copy Features........................................................................ 1-2
Collate Copy ........................................................... 1-2
2 on 1 Combination ................................................ 1-3
Canceling Copy Jobs .............................................................................. 1-4
Canceling a Job While Scanning............................ 1-4
Canceling a Job While Printing............................... 1-4
Returns to the last page opened.
Displays the previous or next page.
Returns to the top page.
Table of contents for the chapter.
Quick links to the list of things you can do, topics
for each chapter, table of contents, and the index.

1
2
3
4
TOP
Back Previous Next
viii
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
The following symbols are used throughout the manuals for the machine and indicate the warnings, cautions and notes you should
keep in mind when using the machine.
WARNING
Indicates a warning that may lead to death or serious injury if not observed.
CAUTION
Explains how to avoid actions that could injure you or damage your machine.
NOTE
Explains operating restrictions and how to avoid minor difficulties.
In addition, this guide uses distinctive notations to identify keys and information in the LCD:
– The keys you press appear in square brackets: [Stop/Reset].
– Information in the LCD appears in angle brackets: <LOAD PAPER>.

1
2
3
4
TOP
Back Previous Next
1-1
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
1 Advanced Copy Features
Advanced Copy Features........................................................................ 1-2
Collate Copy ........................................................... 1-2
2 on 1 Combination ................................................ 1-3
Canceling Copy Jobs .............................................................................. 1-4
Canceling a Job While Scanning............................ 1-4
Canceling a Job While Printing............................... 1-4

1
2
3
4
TOP
Back Previous Next
1-2
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Advanced Copy Features
■Collate Copy
You can copy documents collated into sets arranged in page
order. This feature can be used with “2 on 1 Combination” (see
p. 1-3) at the same time.
1. Set the first page of the document on the
platen glass.
2. Press [COPY].
NOTE
If <AUTO COLLATE> is set to <ON> in the <COPY SETTINGS>
of the Additional Functions menu, skip step 3 and 4.
3. Press [Collate/2 on 1].
4. Use [ ] or [ ] to select <COLLATE>,
then press [OK].
5. Use the numeric keys to enter the desired
copy quantity (1 to 99).
6. Press [Start].
7. Place the next page of the document on the
platen glass, then press [Start].
Repeat this step to scan all pages. The machine prints only one
copy of each page.
8. Press [OK].
The machine prints the rest of sets of copies.
NOTE
– To cancel all settings, press [Stop/Reset].
– When scanning multiple page documents, <MEMORY FULL>
may appear in the LCD and scanning may be canceled. In this
case, the machine returns to the standby mode automatically.

1
2
3
4
TOP
Back Previous Next
1-3
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
■2 on 1 Combination
2 on 1 combination automatically reduces two documents to fit
on A4 or LTR size paper. This feature can be used with “Collate
Copy” (see p. 1-2).
1. Set the first page of the document on the
platen glass.
2. Press [COPY].
3. Press [Collate/2 on 1].
4. Use [ ] or [ ] to select <2 ON 1>, then
press [OK].
If you want to use <2 ON 1> with “Collate Copy” (see p. 1-2) at
the same time, select <COLLATE+2 ON 1>, then press [OK].
5. Use the numeric keys to enter the desired
copy quantity (1 to 99).
6. Press [Start].
7. Place the next page of the document on the
platen glass, then press [Start].
8. When scanning is complete, press [OK].
NOTE
– If you press [OK] without scanning the second document, only
the first document will be printed on the left side of the paper.
– A maximum of 4 mm margin will be produced between the two
reduced documents in 2 on 1 combination copying.
– To cancel all settings, press [Stop/Reset].
2
1
12
Originals
Copy

1
2
3
4
TOP
Back Previous Next
1-4
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Canceling Copy Jobs
Cancel an ongoing job as follows.
■Canceling a Job While Scanning
1. Press [Stop/Reset].
■Canceling a Job While Printing
1. Press [Stop/Reset].
2. Press [ ] to select <YES>.
Ex.
CANCEL COPYING?
< YES NO >

1
2
3
4
TOP
Back Next
2-1
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Previous
2 System Monitor
Checking Job and Machine Status ........................................................ 2-2
Checking Print Status ............................................. 2-2
Checking Print and Scan Counts............................ 2-2

1
2
3
4
TOP
Back Next
2-2
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Previous
Checking Job and Machine Status
System monitor enables you to check remaining memory
and check print and scan counts.
■Checking Print Status
You can check and delete the print jobs sent from a computer.
1. Press [System Monitor].
2. Use [ ] or [ ] to select <PRINT
STATUS>, then press [OK].
3. Use [ ] or [ ] to view the job list.
4. If you want to delete the print job, press [OK],
then press [ ] to select <YES>.
5. Press [Stop/Reset] to return to the standby
mode.
■Checking Print and Scan Counts
1. Press [System Monitor].
2. Use [ ] or [ ] to select <VIEW PAGE
TOTALS>, then press [OK].
3. Use [ ] or [ ] to view the print or scan
counts.
4. Press [Stop/Reset] to return to the standby
mode.

1
2
3
4
TOP
Back Previous Next
3-1
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
3 Troubleshooting
General Problems.................................................................................... 3-2
Paper Feeding Problems......................................................................... 3-4
Copying Problems ................................................................................... 3-5
Printing Problems.................................................................................... 3-6

1
2
3
4
TOP
Back Previous Next
3-2
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
General Problems
The machine has no power.
Q Is the power cord plugged in securely?
ACheck that the power cord is securely plugged into
the machine and into the wall outlet. If the machine
is plugged into a power strip, make sure the power
strip is plugged in and turned on.
Q Is the power cord supplying power?
AUse a different power cord, or test the cord for
continuity using a voltmeter.
Q Is the main power switch turned on?
ATurn on the main power switch.
The Error indicator flashes.
Q Does the machine feed paper correctly, or is
there paper in the paper feeding tray or multi-
purpose tray?
AClear the paper jam, or load paper in the paper
feeding tray or multi-purpose tray. (For instructions
on clearing paper jam, see Chapter 8, “Clearing
Jams,” in the Basic Guide. For instructions on
loading paper, see “Set Up the Paper Trays and
Load Paper,” in the Starter Guide.)
AIf the machine has no paper jam, or paper is
loaded in the paper feeding tray or multi-purpose
tray, turn off the main power switch and wait for
more than five seconds, then turn it on in again. If
the problem is fixed, the Error indicator will turn off,
and the LCD will return to the standby mode. If the
Error indicator remains flash, turn off the main
power switch, and contact your local authorized
Canon dealer or the Canon help line.

1
2
3
4
TOP
Back Previous Next
3-3
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Nothing appears in the LCD.
Q Is the power cord plugged in securely?
ACheck that the power cord is securely plugged into
the machine and into the wall outlet. If the machine
is plugged into a power strip, make sure the power
strip is plugged in and turned on.
Q Is the main power switch turned on?
ATurn on the main power switch.
Q Is the machine in the Sleep mode?
APress [Energy Saver] to take the machine out of
the Sleep mode.

1
2
3
4
TOP
Back Previous Next
3-4
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Paper Feeding Problems
Paper does not feed properly.
Q Is the paper loaded correctly?
AMake sure the paper is correctly loaded. (See “Set
Up the Paper Trays and Load Paper,” in the Starter
Guide.)
Q Does the machine contain too many sheets?
AMake sure you load the correct quantity. (See
Chapter 3, “Print Media,” in the Basic Guide.)
Multiple sheets feed together into the machine.
Q Is the paper loaded correctly?
AMake sure the paper is correctly loaded. (See “Set
Up the Paper Trays and Load Paper,” in the Starter
Guide.)
Q Does the machine contain too many sheets?
AMake sure you load the correct quantity. (See
Chapter 3, “Print Media,” in the Basic Guide.)
Q Are different types of paper loaded in the
machine?
ALoad only one type of paper.
AMake sure you load paper that meets the
requirements for use. (See Chapter 3, “Print
Media,” in the Basic Guide.)
ALet the paper run out before refilling the machine.
Avoid mixing new stock with paper already loaded.
Repeated paper jams occur.
Q Is the correct type of paper loaded in the
machine?
AMake sure you load paper that meets the
requirements for use. (See Chapter 3, “Print
Media,” in the Basic Guide.)

1
2
3
4
TOP
Back Previous Next
3-5
Table of Contents
Index
Advanced Copy
Features
System Monitor
Troubleshooting
Appendix
Copying Problems
Cannot make copies.
Q Have you removed the sealing tape from the
toner cartridge?
AMake sure you remove the sealing tape from the
cartridge. (See “Install Toner Cartridge,” in the
Starter Guide.)
Q Is the toner cartridge installed properly?
AMake sure the toner cartridge is installed properly.
(See “Install Toner Cartridge,” in the Starter Guide.)
AMake sure the scanning platform and rear cover
are fully closed.
Q Is the document loaded correctly?
AMake sure the document is correctly loaded. (See
Chapter 2, “Document Handling,” in the Basic
Guide.)
Q Does the document meet the requirements for
the machine?
AMake sure you load documents that meet the
requirements for use. (See Chapter 2, “Document
Handling,” in the Basic Guide.)
