Canon imageRUNNER ADVANCE C3325i User manual

S
Se er rv vi ic ce e G Gu ui id de e

imageRUNNER ADVANCE C3300 Series Service Guide
Published by
Canon U.S.A., Inc.
One Canon Park
Melville, NY 11747-3336
1-800-OK-CANON
E-Mail: [e-mail]
Canon U.S.A. Homepage: http://www.usa.canon.com
Canon U.S.A. Internet e-Support Center Web site: http://www.support.cusa.canon.com
Canon U.S.A. ISG Central Web site: http://www.isgcentral.cusa.canon.com
Canon Network Access (CNA) Web site: http://www.cna.cusa.canon.com
Distributed in the United States by Canon U.S.A., Inc.
IMPORTANT
THIS SERVICE GUIDE INCLUDES THE INFORMATION RELATING TO THE imageRUNNER
ADVANCE C3330i/C3325i.
SPECIFICATIONS AND OTHER INFORMATION CONTAINED HEREIN MAY VARY SLIGHTLY FROM
ACTUAL DEVICE VALUES OR THOSE FOUND IN ADVERTISING AND OTHER PRINTED MATTER.
USE OF THIS SERVICE GUIDE SHOULD BE STRICTLY SUPERVISED TO AVOID DISCLOSURE OF
CONFIDENTIAL INFORMATION.
ALL PRICES LISTED ARE SUBJECT TO CHANGE WITHOUT NOTICE.
PART NUMBERS LISTED MAY BE CHANGED WITHOUT NOTICE TO REFLECT ENGINEERING
REVISIONS.
REVISION HISTORY
Revision
Date
Sections
Details
— May 2015 All
Release of the imageRUNNER ADVANCE C3300 Series Service
Guide.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page i

imageRUNNER ADVANCE C3300 Series Service Guide
COPYRIGHTS AND TRADEMARKS
This Service Guide is the property of Canon U.S.A., Inc.
© Canon U.S.A., Inc. 2015. All rights reserved.
Canon, imageRUNNER, and Always Ask for Canon Genuine Toner, Parts & Supplies are registered trademarks of
Canon Inc. imageWARE is a registered trademark of Canon U.S.A., Inc.
All other company names and product names may be trademarks or registered trademarks of their respective
owners, and are hereby acknowledged.
LEGAL NOTICES
The information contained in this Service Guide constitutes confidential information of Canon U.S.A., Inc.
Pursuant to the authorized Service Agreement with Canon U.S.A., Inc., this Service Guide is solely for reference
purposes and may be used only by an authorized Service Provider of Canon U.S.A., Inc. No part of this Service
Guide may be reproduced or transmitted in any form by any means, electronic or mechanical, for any purpose
without the prior written consent of Canon U.S.A., Inc., except as expressly permitted herein.
Pursuant to the authorized Service Agreement with Canon U.S.A., Inc., the Service Provider agrees to indemnify
Canon U.S.A., Inc. and to hold it harmless from and against any and all claims arising out of Service Provider’s
possession, use, or misuse of this Service Guide.
As an authorized Canon dealership for the imageRUNNER ADVANCE C3300 Series, you agree that the
imageRUNNER ADVANCE C3300 Series and its related hardware/software accessories will not be exported from
the United States except in strict accordance with the Export Administration Regulations of the U.S. Department of
Commerce and other U.S. laws and regulations controlling exports from the United States.
Canon U.S.A., Inc. from time to time updates this online Service Guide and may modify the information and/or
specifications contained in it at any time without notice. Additionally, all prices and availability dates listed herein are
subject to change without notice. The latest version is available online at the ISG Central and e-Support Web sites
noted above. Please make certain that you are using the latest version. Specimens of Web pages included herein
are for illustration purposes only.
DISCLAIMER
NEITHER CANON NOR ITS SUPPLIERS NOR ANY AUTHORIZED SERVICE PROVIDER SHALL BE LIABLE FOR
PERSONAL INJURY OR PROPERTY DAMAGE (UNLESS CAUSED SOLELY AND DIRECTLY BY THE
NEGLIGENCE OF CANON OR ANY AUTHORIZED SERVICE PROVIDER), LOSS OF REVENUE OR PROFIT,
FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, EXPENDITURES FOR SUBSTITUTE EQUIPMENT OR
SERVICES, LOSS OR CORRUPTION OF DATA, INCLUDING, WITHOUT LIMITATION, DATA STORED ON THE
PRODUCT’S OPTIONAL HARD DISK DRIVE, STORAGE CHARGES OR OTHER SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE PRODUCT,
REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED AND EVEN IF CANON OR ITS
SUPPLIERS OR ANY AUTHORIZED SERVICE PROVIDER HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST CANON OR ITS SUPPLIERS OR ANY
AUTHORIZED SERVICE PROVIDER BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE
PRODUCT CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, THE PURCHASER
ASSUMES ALL RISKS AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PERSONS AND THE PROPERTY
OF THE PURCHASER OR OTHERS ARISING OUT OF THE POSSESSION, USE, MISUSE, OR INABILITY TO
USE THE PRODUCT NOT CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON OR ANY
AUTHORIZED SERVICE PROVIDER.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page ii

imageRUNNER ADVANCE C3300 Series Service Guide
Contents
I. Product Overview and Configuration ---------------------------------------------------------------1
A. Overview ------------------------------------------------------------------------------------------------------------- 1
B. Features -------------------------------------------------------------------------------------------------------------- 2
C. Main Unit Box Contents ----------------------------------------------------------------------------------------- 5
D. Configuration ------------------------------------------------------------------------------------------------------- 6
II. Hardware Accessory Options------------------------------------------------------------------------ 12
A. Cassette Feeding Unit-AL1 ------------------------------------------------------------------------------------12
B. Cabinet Type-J ----------------------------------------------------------------------------------------------------12
C. FL Cassette-AX1 --------------------------------------------------------------------------------------------------12
D. FL Cassette-AY1 --------------------------------------------------------------------------------------------------12
E. Staple Finisher-U1------------------------------------------------------------------------------------------------13
F. Booklet Finisher-U1----------------------------------------------------------------------------------------------13
G. Inner Finisher-G1-------------------------------------------------------------------------------------------------13
H. Inner 2Way Tray-J1-----------------------------------------------------------------------------------------------14
I. Copy Tray-J2-------------------------------------------------------------------------------------------------------14
J. Copy Card Reader-F1 -------------------------------------------------------------------------------------------14
III. System Options------------------------------------------------------------------------------------------- 15
A. Copy and Print Options-----------------------------------------------------------------------------------------15
1. Barcode Printing Kit-D1 ------------------------------------------------------------------------------------- 15
2. Secure Watermark-B1 --------------------------------------------------------------------------------------- 15
3. PCL International Font Set-A1 ----------------------------------------------------------------------------- 15
B. Universal Send and Fax Options----------------------------------------------------------------------------16
1. Universal Send Trace & Smooth PDF Kit-A1 ---------------------------------------------------------- 16
2. Universal Send Security Feature Set-D1 ---------------------------------------------------------------- 16
3. Universal Send Digital User Signature Kit-C1 ---------------------------------------------------------- 16
4. Super G3 FAX Board-AR1 ---------------------------------------------------------------------------------- 16
5. Super G3 2nd Line Fax Board-AR1 ---------------------------------------------------------------------- 16
6. Remote Fax Kit-A1 ------------------------------------------------------------------------------------------- 16
C. Connectivity Options--------------------------------------------------------------------------------------------17
1. Web Access Software-H1 ---------------------------------------------------------------------------------- 17
2. USB Device Port-E4 ------------------------------------------------------------------------------------------ 17
D. Data Security and Wireless Options------------------------------------------------------------------------17
1. Encrypted Secure Print Software-D1 --------------------------------------------------------------------- 17
2. iR-ADV Security Kit-L1 for IEEE 2600.1 Common Criteria Certification Set (Not Available at
Launch) --------------------------------------------------------------------------------------------------------------- 17
3. HDD Data Encryption Kit-C9 ------------------------------------------------------------------------------- 17
4. Removable HDD Kit-AK1 ----------------------------------------------------------------------------------- 18
5. Document Scan Lock Kit-B1 ------------------------------------------------------------------------------- 18
E. Accessibility Options--------------------------------------------------------------------------------------------18
1. Voice Guidance Kit-F2 --------------------------------------------------------------------------------------- 18
2. Voice Operation Kit-C2 -------------------------------------------------------------------------------------- 18
3. ADF Access Handle-A1 ------------------------------------------------------------------------------------- 18
IV. Document Storage Capabilities --------------------------------------------------------------------- 19
A. Mail Box Simple---------------------------------------------------------------------------------------------------19
B. Network--------------------------------------------------------------------------------------------------------------19
C. Memory Media-----------------------------------------------------------------------------------------------------20
D. Advanced Box Client --------------------------------------------------------------------------------------------20
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page iii

imageRUNNER ADVANCE C3300 Series Service Guide
V. Security Features ---------------------------------------------------------------------------------------- 21
A. Device Authentication-------------------------------------------------------------------------------------------21
1. User Authentication------------------------------------------------------------------------------------------- 21
2. Department ID Management ------------------------------------------------------------------------------- 22
3. SSO-H ----------------------------------------------------------------------------------------------------------- 22
B. Data Security-------------------------------------------------------------------------------------------------------23
1. Initialize All Data/Settings Function ----------------------------------------------------------------------- 23
2. HDD Data Erase Kit ------------------------------------------------------------------------------------------ 24
3. Document Scan Lock Kit ------------------------------------------------------------------------------------ 24
4. TPM (Trusted Platform Module) --------------------------------------------------------------------------- 25
5. HDD Data Encryption Kit ------------------------------------------------------------------------------------ 26
6. Removable Hard Disk Drive Kit --------------------------------------------------------------------------- 26
7. HDD Data Erase Scheduler -------------------------------------------------------------------------------- 26
C. Document Security-----------------------------------------------------------------------------------------------27
1. PDF Visible Digital Signature ------------------------------------------------------------------------------ 27
2. Adobe LiveCycle Rights Management ES Server Integration -------------------------------------- 27
D. Network Security -------------------------------------------------------------------------------------------------28
1. IPSec ------------------------------------------------------------------------------------------------------------ 28
2. Filtering by Port Number ------------------------------------------------------------------------------------ 28
3. Wireless Security and Authentication -------------------------------------------------------------------- 28
4. Network Port and Application Access Control --------------------------------------------------------- 28
VI. Software Solutions -------------------------------------------------------------------------------------- 29
A. Document Management and Binding Software---------------------------------------------------------29
1. imageRUNNER ADVANCE Desktop --------------------------------------------------------------------- 29
2. imageRUNNER ADVANCE Quick Printing Tool ------------------------------------------------------- 29
3. imageWARE Document Server --------------------------------------------------------------------------- 29
4. imageWARE Scan Manager DS -------------------------------------------------------------------------- 30
5. eCopy PDF Pro Office --------------------------------------------------------------------------------------- 30
B. Scan Management Software ----------------------------------------------------------------------------------31
1. Workflow Composer and Connectors -------------------------------------------------------------------- 31
2. Authorized Send ----------------------------------------------------------------------------------------------- 31
3. uniFLOW (Scanning)----------------------------------------------------------------------------------------- 31
4. ADVANCE Cloud Portal ------------------------------------------------------------------------------------- 31
5. eCopy ShareScan -------------------------------------------------------------------------------------------- 31
C. Print/Output Management Software------------------------------------------------------------------------32
1. Direct Print & Scan for Mobile------------------------------------------------------------------------------ 32
2. uniFLOW -------------------------------------------------------------------------------------------------------- 32
3. AA-PRINT (Advanced Anywhere Print) ------------------------------------------------------------------ 32
4. EFI PrintMe ----------------------------------------------------------------------------------------------------- 32
D. Device Security and Management Software -------------------------------------------------------------33
1. AA-PROX (Advanced Authentication – Proximity Card) --------------------------------------------- 33
2. uniFLOW Device Security & Management ------------------------------------------------------------- 33
3. uniFLOW Serverless Secure Print ------------------------------------------------------------------------ 33
4. imageWARE Enterprise Management Console and Plug-ins -------------------------------------- 33
5. imageWARE Secure Audit Manager Express --------------------------------------------------------- 34
6. MEAP Web ----------------------------------------------------------------------------------------------------- 34
7. MDS Cloud ----------------------------------------------------------------------------------------------------- 34
E. Business Workflow Software---------------------------------------------------------------------------------35
1. Forms and Print Services for Salesforce ---------------------------------------------------------------- 35
2. Enterprise Imaging Platform-------------------------------------------------------------------------------- 35
VII. Dealer Sales/Service Authorization ---------------------------------------------------------------- 36
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page iv

imageRUNNER ADVANCE C3300 Series Service Guide
VIII. Service Training------------------------------------------------------------------------------------------ 36
A. Training Program Overview-----------------------------------------------------------------------------------36
B. Online Course Module ------------------------------------------------------------------------------------------36
C. Prerequisites-------------------------------------------------------------------------------------------------------37
D. Certification --------------------------------------------------------------------------------------------------------37
E. Who Should Attend ----------------------------------------------------------------------------------------------37
F. Online Course Training Facilities ---------------------------------------------------------------------------38
G. Course Equipment -----------------------------------------------------------------------------------------------38
H. Service Materials -------------------------------------------------------------------------------------------------38
IX. Servicing Notes------------------------------------------------------------------------------------------- 39
A. Power and Plug Requirements-------------------------------------------------------------------------------39
B. Installation Space Requirements----------------------------------------------------------------------------41
C. Estimated Installation Times----------------------------------------------------------------------------------43
D. Remote Support Services--------------------------------------------------------------------------------------44
1. imageWARE Remote ---------------------------------------------------------------------------------------- 44
2. Content Delivery System ------------------------------------------------------------------------------------ 44
E. Serviceability-------------------------------------------------------------------------------------------------------47
F. Less Maintenance Strategy -----------------------------------------------------------------------------------48
G. Device Configuration Management-------------------------------------------------------------------------49
1. DCM (Device Configuration Manager) ------------------------------------------------------------------- 49
2. Device Migration Navigator --------------------------------------------------------------------------------- 49
H. LMS (License Management System) -----------------------------------------------------------------------50
I. Content Delivery System Web Site -------------------------------------------------------------------------51
J. Recommended System Engineer Requirements-------------------------------------------------------52
K. Firmware Upgrades Using the Service Support Tool-------------------------------------------------53
L. Computer Requirements for Downloading Firmware-------------------------------------------------54
M.Hard Disk Drive Handling --------------------------------------------------------------------------------------54
N. Special Tools-------------------------------------------------------------------------------------------------------55
O. Consumables ------------------------------------------------------------------------------------------------------56
P. Consumable Parts------------------------------------------------------------------------------------------------58
Q. Periodically Replaced Parts-----------------------------------------------------------------------------------60
R. Periodic Maintenance -------------------------------------------------------------------------------------------60
S. Counters-------------------------------------------------------------------------------------------------------------62
T. MEAP Counter-----------------------------------------------------------------------------------------------------64
X. Suggested End-User Customer Service Offerings-------------------------------------------- 65
A. Monthly Copy/Print Volume-----------------------------------------------------------------------------------65
B. Limited Warranty Support -------------------------------------------------------------------------------------65
1. End-User Limited Warranty Conditions ------------------------------------------------------------------ 65
2. GPR-53 Drum Unit Limited Warranty -------------------------------------------------------------------- 65
3. Flat-Rate Program -------------------------------------------------------------------------------------------- 66
4. Warranty Parts for Repair ----------------------------------------------------------------------------------- 68
5. e-Tag ------------------------------------------------------------------------------------------------------------- 70
6. Online Limited Warranty Credit Inquiry ------------------------------------------------------------------ 72
XI. Product Technical Support Offerings ------------------------------------------------------------- 76
A. Dealer Support Requirements--------------------------------------------------------------------------------76
B. Canon USA Support Offerings -------------------------------------------------------------------------------78
1. Canon USA Technical Support Center ------------------------------------------------------------------ 78
2. Internet Support ----------------------------------------------------------------------------------------------- 80
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page v

imageRUNNER ADVANCE C3300 Series Service Guide
XII. Appendix---------------------------------------------------------------------------------------------------- 83
A. Specifications------------------------------------------------------------------------------------------------------83
B. Main Unit Limited Warranty -----------------------------------------------------------------------------------95
C. List of Tables-------------------------------------------------------------------------------------------------------96
D. List of Figures -----------------------------------------------------------------------------------------------------97
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page vi

imageRUNNER ADVANCE C3300 Series Service Guide
I. Product Overview and Configuration
A. Overview
The Canon imageRUNNER ADVANCE C3300 Series consists of the
imageRUNNER ADVANCE C3330i/C3325i. These models bring the following
capabilities to users in a low-volume, medium to small size, or remote office
environment:
• Speeds of up to 30 ppm (pages per minute) (LTR, Color and
Black-and-White).
• Duplexing document feeder with two-sided color and black-and-white
scanning speeds of up to 27.5 ipm (images per minute) at 300 dpi, and
100-sheet capacity.
• A 7” full-color WVGA LCD display (640 x 480 pixels), tilting control panel.
• Finishing options, such as an inner finisher, staple finisher, or booklet
finisher.
• A maximum paper size of 12” x 18” is supported. Multiple paper sources,
including an optional cassette feeding unit, can hold up to 2,300 sheets of
paper.
• Prints in 600 x 600 dpi at the engine’s rated speed.
• Standard HDD (Hard Disk Drive) Data Erase feature.
• The ability to continue printing in B&W when there is a CMY drum error.
• Inter-device link functionality enables imageRUNNER ADVANCE C3300
machines with a network connection to connect to other imageRUNNER
ADVANCE host models with an Advanced Box. This enables the
imageRUNNER ADVANCE C3300 Series machine to act as a client, and
share the Scan and Print functions from the Advanced Box of the host
imageRUNNER ADVANCE machine. Client imageRUNNER ADVANCE
C3300 Series machines can also share remote address books, send and
receive fax documents using the Remote Fax function (provided the
Remote Fax Kit is installed on the imageRUNNER ADVANCE C3300
Series device).
• RAPID Fusing Technology enables quick warm up times and first copy
output times.
• OPC drum technology improves longevity, which results in lower operating
costs and reduced downtime.
• Reduced toner soiling with new toner supply system.
• Standard Universal Send and UFR II printing.
• Standard USB memory support. Use the USB memory port to scan to or
print from a USB memory stick.
• “Less-Maintenance” design – Some customers are able to replace a few
components that require regular replacement.
• All imageRUNNER ADVANCE C3300 Series machines are EPEAT
(Electronic Product Environmental Assessment Tool) qualified.
• The ability to activate optional software products via the LMS (License
Management System). Refer to the LMS section herein for further details.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 1

imageRUNNER ADVANCE C3300 Series Service Guide
B. Features
The imageRUNNER ADVANCE C3300 Series machines offer the following
new system, performance, and environmental features:
• On-screen device maintenance videos.
• Advanced imageCHIP System Architecture – A dual CPU design for
image processing, and maintains concurrent UI and network connection
responses.
• Enhanced user authentication capabilities.
• OOXML Scan to PowerPoint and Word support with enhanced
authentication for Send.
• Quick startup and high-speed RIP.
• Energy Saver LED key and improved handling of originals.
• Remote/Auto Shutdown and Weekly Shutdown Timer support.
• Toner signal alarm (pre-toner low alarm and toner bottle count up alarm).
• Ability to detect when a new toner bottle, drum unit, and fixing unit has
been installed.
• The ability to continue printing in B&W when there is a CMY drum error.
• Faster firmware upgrade time with the Parallel Update feature.
• Ability to duplicate the same settings on one machine, and then install
these settings on multiple other machines.
• Use of a temporary data storage function by making a backup in the
Service mode.
• Use of automatic pull-in cassettes.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 2

imageRUNNER ADVANCE C3300 Series Service Guide
Table 1 - imageRUNNER ADVANCE C3300 Series Comparison
Feature imageRUNNER ADVANCE
C3330i C3325i
Print Speed (ppm) (LTR, B&W and Color)
Up to 30
Up to 25
Optimum Copy Volume (copies/prints)
Approximately 2,000 to 16,000
Scan Speed
(LTR, 300 dpi,
B&W/Color)
Simplex Approximately 55 ipm/55 ipm
Duplex Approximately 27.5 ipm/27.5 ipm
Scan Speed
(LTR, 600 dpi,
B&W/Color)
Simplex Approximately 30 ipm/30 ipm
Duplex Approximately 15 ipm/15 ipm
Automatic Document Feeder
Standard
Feeder Capacity
Up to 100 sheets (20 lb bond (80 g/m²))
Resolution Reading Up to 600 x 600 dpi
Writing Up to 1,200 x 1,200 dpi
Maximum Paper Size 12” x 18”
Maximum Paper Weight
Paper Drawer 80 lb cover (220 g/m²)
Multi-Purpose
Tray
140 lb index (256 g/m2)
Paper Capacity
Paper Drawers
Up to 640 sheets (17 lb bond (64 g/m2))
Up to 550 sheets (20 lb bond (80 g/m
2
))
Multi-Purpose
Tray
Up to 100 sheets (20 lb bond (80 g/m2))
Multiple Copies 1 to 999 sheets
Printer Memory 2 GB
Hard Disk Drive
1
Approximately 250 GB (Used Space: 215 GB)
Warm Up Time
(at a room temp. of 68°F
(20°C))2
After Power ON
3
Approximately 34 seconds
From Sleep
Mode
Approximately 10 seconds
From the Quick
Startup Settings
for Main Power
Mode
4
Approximately 7 seconds
FCOT (First Copy
Output Time)
Full Color Approximately 8.2 seconds
B&W Approximately 5.9 seconds
Power Consumption5
Maximum Approximately 1.5 kW
In the Sleep
Mode
Approximately 0.8 W
Quick Startup
Settings for Main
Power Mode is
‘Off’
Approximately 0.19 W
Quick Startup
Settings for Main
Power Mode is
‘On’
Approximately 0.45 W
Power Requirements
120V AC, 60 Hz, 7.5 A
Plug Type
NEMA 5-15P
1 The hard disk capacity is subject to change in a future release.
2 Activation time may vary, depending on the environment and conditions under which the machine is used.
3 The Quick Startup Settings for Main Power mode is set to ‘Off’.
4 Even if the Quick Startup Settings for Main Power mode is set to ‘On’, the Warm-Up time may be longer, depending on the
conditions under which the machine is used.
5 These values may differ, depending on the system and conditions of use.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 3

imageRUNNER ADVANCE C3300 Series Service Guide
Table 1 – imageRUNNER ADVANCE C3300 Series Comparison Continued
Feature
imageRUNNER ADVANCE
C3330i
C3325i
Toner Yield (at 5%
Coverage (LTR))
Black
Approximately 36,000 pages
Color (CMY)
Approximately 19,000 pages
Drum Yield (LTR)
Black6
Approximately 97,000 pages
Approximately 86,300 pages
Color (CMY)7
Approximately 82,700 pages
Approximately 72,600 pages
Copy Standard
Store
Mail Box
Simple
Standard
Advanced Box As a client only
Memory Media
Support
Standard (USB)
Print
UFR II, PCL,
and Adobe PS
(PostScript)
Standard
imagePASS
(External)
Not Available
Send
Color Universal
Send
Standard
Scan to
USB/Print from
USB
Standard
Trace &
Smooth PDF
Kit
Optional8
PDF Security
Feature Set
Optional9
PDF Digital
User Signature
Optional
Fax
Single Line Optional w/Super G3 FAX Board-AR1
2
nd
Line Optional w/Super G3 2
nd
Line Fax Board-AR1
Remote Fax Optional w/Remote Fax Kit-A1 (As client only)
Network Standard Ethernet 10/100/1000Base-TX
Remote UI Standard
Remote Operator’s Software Standard
MEAP/MEAP Web Capability Standard
AMS (Access Management System) Standard
6 Based on 25% color ratio and LTR size paper.
7 Based on 100% color ratio and LTR size paper.
8 Includes Trace & Smooth PDF format support.
9 Includes Digital Device Signature (PDF/XPS) and Encrypted PDF modes.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 4

imageRUNNER ADVANCE C3300 Series Service Guide
C. Main Unit Box Contents
Note: The box contents shown below are for reference purposes only, and
are subject to change without notice.
Table 2 – imageRUNNER ADVANCE C3300 Series Box Contents
Contents imageRUNNER ADVANCE
C3330i
C3325i
Main Unit  
Support Guide  
Quick Operation Guide  
e-Manual  
AMS Kit Software/Manual CD  
Features of AMS  
Notice for Latest Software (CS/PS)  
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 5

imageRUNNER ADVANCE C3300 Series Service Guide
D. Configuration
Note: All configurations shown are for reference purposes only, and are
subject to change without notice. Please refer to the Dealer Price List on the
ISG Central Web site for the most up-to-date item numbers.
Table 3 – Configuration
Item
Part Number10
imageRUNNER ADVANCE C3330i with the optional Cassette Feeding Unit-AL1
imageRUNNER ADVANCE C3330i11
8477B004AA
imageRUNNER ADVANCE C3325i11
8478B004AA
10 Part numbers are subject to change without notice.
11 Ships standard with one 100-sheet capacity Duplexing Automatic Document Feeder, standard UFR II, PCL, PS, and direct
printing, two 550-sheet paper cassettes, 100-sheet multipurpose tray, Color Universal Send, OOXML support (.docx, .pptx),
2 GB RAM, 250 GB HDD, 1000Base-T/100Base-TX/10Base-T, USB 2.0 connectivity, drum units, Remote Operator’s Software
Kit, Access Management System, HDD Data Erase, IP Sec, and Color Network ScanGear.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 6

imageRUNNER ADVANCE C3300 Series Service Guide
Table 4 – Hardware Accessories
Item
Part Number10
Cassette Feeding Unit-AL1
12
8786B002AA
Cabinet Type-J12, 13
0988C001AA
Staple Finisher-U1 (Includes the Buffer Pass Unit)14
8473B001AA
Booklet Finisher-U1 (Includes the Buffer Pass Unit)
14
8474B001AA
Inner 2Way Tray-J1
14
9611B001AA
Inner Finisher-G1
14, 15
8472B001AA
FL Cassette-AX1
16
8476B001AA
FL Cassette-AY1
17
8476B002AA
Copy Tray-J2 8815A003AA
Utility Tray-A2 3723B002AB
USB Keyboard (Cherry)
18
1266V426
Universal Keyboard Stand-A1
2212V477
Card Reader Assembly for Universal Keyboard Stand
19
2212V478
Copy Card Reader-F1
20
4784B001AA
Copy Card Reader Attachment Kit-B4 3684B004AA
Canon Card Set-A1 (1-30)
4781B001AA
Canon Card Set-A2 (31-100)
4781B002AA
Canon Card Set-A3 (101-200)
4781B003AA
Canon Card Set-A4 (201-300)
4781B004AA
Canon Card Set-A5 (301-500) 4781B005AA
Canon Card Set-A6 (501-1000)
4781B006AA
ADF Access Handle-A1 1095B001AA
Braille Label Kit-F1 7518A004AA
Copy Control Interface Kit-A1
21
3726B001AA
Convenience Stapler-B1
1727V838
10 Part numbers are subject to change without notice.
12 The Cassette Feeding Unit-AL1 and Cabinet Type-J cannot be installed at the same time.
13 The Cabinet Type-J cannot be installed with the Staple Finisher-U1 or Booklet Finisher-U1.
14 The Staple Finisher-U1, Booklet Finisher-U1, Inner Finisher-G1, and Inner 2Way Tray-J1 cannot be installed together.
15 Includes two trays as standard.
16 A replacement cassette for Paper Drawer 1.
17 A replacement cassette for Paper Drawers 2, 3, and 4.
18 When installing the USB Keyboard, it is recommended to install the Utility Tray-A2 or Universal Keyboard Stand-A1.
19 Attaches to the Universal Keyboard Stand-A1 for card reader authentication.
20 Requires the Copy Card Reader Attachment Kit-B4.
21 Cannot be installed if the Copy Card Reader-F1 is installed.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 7

imageRUNNER ADVANCE C3300 Series Service Guide
Table 5 – System Accessories
Item Box Part
Number
10
eLAN Number22
Super G3 FAX Board-AR1
8480B002AA
-
Super G3 2nd Line Fax Board-AR123
8481B002AA
-
Remote Fax Kit-A124
-
3679B005AA
Encrypted Secure Print Software-D1
-
1337B011AA
Secure Watermark-B1
-
1082B010AA
Barcode Printing Kit-D1
-
3999B004AA
Web Access Software-H1
-
2738B007AA
Removable HDD Kit-AK1
8957B001AA
-
Universal Send Trace & Smooth PDF Kit-A1
-
8581B002AA
Universal Send Security Feature Set-D125
-
3406B006AA
Universal Send Digital User Signature Kit-C126
-
1326B013AA
HDD Data Encryption Kit-C9
8956B002AA
-
USB Device Port-E4
5594B004AA
-
Document Scan Lock Kit-B1
3840B007AA
-
iR ADV Security Kit-L1 for IEEE 2600.1 Common Criteria
Certification Set
27, 28
TBD -
Voice Guidance Connection Kit for iR-ADV C3300 Series
9999B001AA
-
Voice Guidance Kit-F229, 30
3681B003AA
-
Voice Operation Kit-C229
3682B004AB
-
PCL International Font Set-A1
4821B003AA
-
Silex Wireless Bridge SX-4600WAN
8034B003AA
-
10 Part numbers are subject to change without notice.
22 The eLAN (Electronic License Access Number) is delivered via the CNA (Canon Network Access) Web site.
23 Requires the optional Super G3 FAX Board-AR1.
24 Cannot be installed with the Super G3 FAX Board-AR1.
25 Contains multiple options. Uses a single eLAN to generate multiple license keys or files for activation.
26 SSO-H settings must be enabled.
27 Not available at the time of device launch.
28 Includes the HDD Data Encryption Kit-C9. Specified configurations and settings need to be applied to the device to achieve
and maintain IEEE 2600.1 Common Criteria Certification. Cannot be used with the Super G3 2nd Line Fax Board-AR1,
Remote Fax Kit-A1, Web Access Software-H1, some MEAP applications, and imageWARE options.
29 Requires the Voice Guidance Connection Kit for iR-ADV C3300 series.
30 The Voice Guidance Kit-F2 and Voice Operation Kit-C2 cannot be installed together.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 8

imageRUNNER ADVANCE C3300 Series Service Guide
Table 6 – Integrated and imageRUNNER ADVANCE Solutions
Item Box Part
Number
10
eLAN Number22
AA-PROX V2.6.2 Software Only31, 32
-
4164BP90AA
AA-PROX V2.6.2 NFR Software Only31, 32
-
4164BP91AA
HDD Data Erase Scheduler V3.027
-
TBD
HDD Data Erase Scheduler V3.0 NFR27, 33
-
TBD
Direct Print and Scan for Mobile V2.3 (1 License)
-
4164BM80AA
Direct Print and Scan for Mobile V2.3 NFR (1 License)34
-
4164BM81AA
Authorized Send Kit V5.4.3 (1 License)31
-
4164BJ94AC
Authorized Send Kit V5.4.3 (10 Licenses)31
-
4164BJ95AC
Authorized Send Kit V5.4.3 (100 Licenses)31
-
4164BJ96AC
Authorized Send Kit V5.4.3 (1 License NFR)31
-
4164BJ97AC
AA-PRINT for MFP V1.5 (1 License)
27, 31
-
TBD
AA-PRINT for MFP V1.5 NFR (1 License)
27, 31
-
TBD
MEAP for PaperCut V1.0.4
27
-
TBD
MEAP Web Connection Kit
-
4848B033
MEAP Web Connection Kit NFR
-
4848B039
ADVANCE Cloud Portal for Google Drive
35, 36
-
0956C001AA
Universal Login Manager – 1 Device License
37
3575B372AA
-
Universal Login Manager – 5 Device Licenses37
3575B373AA
-
Universal Login Manager – 10 Device Licenses37
3575B374AA
-
Upgrade to ULM to uniFLOW for SMB-MEAP37
3575B405AA
-
MiCard PLUS
3575B353AA
-
imageRUNNER ADVANCE Desktop V3.1.2 1L with 3 Years
Software Maintenance
- 4140B397AA
imageRUNNER ADVANCE Desktop V3.1.2 5L with 3 Years
Software Maintenance
- 4140B398AA
imageRUNNER ADVANCE Desktop V3.1.2 20L with 3 Years
Software Maintenance
- 4140B399AA
imageRUNNER ADVANCE Desktop V3.1.2 10L NFR38
-
4140B400AA
imageRUNNER ADVANCE Desktop 1L with 1 Year Software
Maintenance Extension
39
7494A752AA -
imageRUNNER ADVANCE Desktop 5L with 1 Year Software
Maintenance Extension
39
7494A689AA -
imageRUNNER ADVANCE Desktop 10L with 1 Year Software
Maintenance Extension
39
7494A868AA -
imageRUNNER ADVANCE Desktop 20L with 1 Year Software
Maintenance Extension
39
7494A751AA -
imageRUNNER ADVANCE Desktop 50L with 1 Year Software
Maintenance Extension39 7494A867AA -
10 Part numbers are subject to change without notice.
22 The eLAN (Electronic License Access Number) is delivered via the CNA (Canon Network Access) Web site.
27 Not available at the time of device launch.
31 The Jar file can only be attained via download from http://www.canon.com/fau/downloads.
32 Requires a supported RF IDeas pcProx Card Reader.
33 Dealers can purchase up to three NFR packages per showroom.
34 One NFR license per dealer showroom location.
35 A license is required to connect the machine to the ADVANCE Cloud Portal Web Service.
36 Requires the MEAP Web Connection Kit and PDF Direct Print feature.
37 Software license only.
38 Licenses expire in one (1) year.
39 Software Maintenance Extensions can be purchased and registered up to 5 years in advance.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 9

imageRUNNER ADVANCE C3300 Series Service Guide
Table 6 – Integrated and imageRUNNER ADVANCE Solutions Continued
Item Box Part
Number
10
eLAN Number22
Workflow Composer with MEAP Connectors V2.3 1L
(1 to 4 Licenses)
- 4165B114AA
Workflow Composer with MEAP Connectors V2.3 1L
(5 to 19 Licenses)
- 4165B115AA
Workflow Composer with MEAP Connectors V2.3 1L (20 or More
Licenses)
- 4165B116AA
Workflow Composer with MEAP Connectors V2.3 1L NFR
-
4165B117AA
imageRUNNER ADVANCE Tracker V1.5.3 1L (1 to 4 Licenses)
-
4148B533AA
imageRUNNER ADVANCE Tracker V1.5.3 1L (5 to 19 Licenses)
-
4148B534AA
imageRUNNER ADVANCE Tracker V1.5.31L (20 or More Licenses)
-
4148B535AA
imageRUNNER ADVANCE Tracker V1.5.3 1L NFR
-
4148B536AA
MEAP Connector for SharePoint Server V1.1 (1 Device)40
-
4165B036AB
Client Access License for imageWARE Document Server V2.0
5CAL
- 4143B046AB
Client Access License for imageWARE Document Server V2.0
20CAL
- 4143B047AB
Client Access License for imageWARE Document Server V2.0
100CAL
- 4143B048AB
Client Access License for imageWARE Document Server V2.0
10CAL NFR
- 4143B049AB
imageWARE Document Server V2.0E 1L with 3 Years Software
Maintenance
41
- 4143B039AB
imageWARE Document Server V2.0E 1L NFR
-
4143B045AB
imageWARE Document Server 1L with 1 Year Software
Maintenance Extension39 7494A696AA -
imageWARE Document Server V1.1 1L and DT 5L with 1 Year
Software Maintenance Extension
39
7494A766AA -
imageWARE Scan Manager DS V1.1E 1L with 3 Years Software
Maintenance
41
7494A698AB -
imageWARE Scan Manager DS V1.0/1.1 EFS 1L with 1 Year
Software Maintenance Extension39 7494A699AA -
imageWARE Scan Manager DS V1.0/1.1 EFS 5L with 1 Year
Software Maintenance Extension
39
7494A869AA -
imageWARE Scan Manager DS V1.1E 1L NFR
33
7494A700AB
-
10 Part numbers are subject to change without notice.
22 The eLAN (Electronic License Access Number) is delivered via the CNA (Canon Network Access) Web site.
33 Dealers can purchase up to three NFR packages per showroom.
39 Software Maintenance Extensions can be purchased and registered up to 5 years in advance.
40 Workflow Composer must be installed. MEAP Connector for SharePoint Server 2007/2010 does not come with software
maintenance.
41 Ships standard with three year software maintenance.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 10

imageRUNNER ADVANCE C3300 Series Service Guide
Table 7 – Supplies and Consumables
Item Part
Number
10
GPR-53 Drum Unit
8528B004AA
GPR-53 Black Toner 8524B003AA
GPR-53 Cyan Toner
8525B003AA
GPR-53 Magenta Toner
8526B003AA
GPR-53 Yellow Toner
8527B003AA
Stamp Ink Cartridge-C1
1857B001AA
Stamp Unit-B1
1858B001AA
Staple Cartridge-D242
0250A002AD
Staple-P143
1008B001AA
Staple-J144
6707A001AC
10 Part numbers are subject to change without notice.
42 Used for Booklet Finishing only in the Booklet Finisher-U1. Three cartridges per case, and 2,000 staples per cartridge.
43 Used for the Inner Finisher-G1. Two cartridges per case, and 5,000 staples per cartridge.
44 Used for corner and double stapling only in the Staple Finisher-U1 or Booklet Finisher-U1. Three cartridges per case, and
5,000 staples per cartridge.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 11

imageRUNNER ADVANCE C3300 Series Service Guide
II. Hardware Accessory Options
A. Cassette Feeding Unit-AL1
• Provides two additional paper drawers with a total capacity of up to 1,100
sheets (20 lb bond (80 g/m2)).
• Supports paper sizes up to 12” x 18” (from 14 lb bond to 80 lb cover
(52 to 220 g/m2)).
• No support for coated or tab paper, or double-feed detection.
• Cannot be installed with the Cabinet Type-J.
B. Cabinet Type-J
• Used to adjust the height of the device with the standard paper-feeding
configuration.
• Cannot be installed with the Cassette Feeding Unit-AL1.
C. FL Cassette-AX1
• A replacement cassette for Paper Drawer 1.
• Holds up to 550 sheets (20 lb bond (80 g/m2)).
• Paper weight: 14 lb bond to 80 lb cover (52 to 220 g/m2)).
D. FL Cassette-AY1
• A replacement cassette for Paper Drawers 2, 3, and 4.
• Holds up to 550 sheets (20 lb bond (80 g/m2)).
• Paper weight: 14 lb bond to 80 lb cover (52 to 220 g/m2)).
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 12

imageRUNNER ADVANCE C3300 Series Service Guide
E. Staple Finisher-U1
• Contains two trays, which hold approximately 1,000 sheets of LTR paper
each with no finishing modes set.
• Can corner or double staple approximately 50 sheets of paper
(LTR, 14 to 20 lb bond (52 to 80 g/m2)).
• Cannot be installed with the Booklet Finisher-U1, Inner Finisher-G1, or
Copy Tray-J2.
F. Booklet Finisher-U1
• Contains two trays, which hold approximately 1,000 sheets of LTR paper
each with no finishing modes set.
• Can corner or double staple approximately 50 sheets of paper
(LTR, 14 to 20 lb bond (52 to 80 g/m2)).
• Can saddle stitch up to 16 sheets (10 sets) in LTRR, LGL, 11” x 17”, and
12” x 18” paper sizes (16 to 21 lb bond (60 to 81 g/m2)).
• Cannot be installed with the Staple Finisher-U1, Inner Finisher-G1, or
Copy Tray-J2.
G. Inner Finisher-G1
• The Inner Finisher-G1 has a compact footprint and provides two trays for
corner and double stapling. The upper tray can hold up to 100 sheets of
LTR paper with no finishing modes set. The lower tray can hold up to 500
sheets of LTR paper with no finishing modes set.
• Cannot be installed with the Staple Finisher-U1, Booklet Finisher-U1, or
Inner 2Way Tray-J1.
imageRUNNER ADVANCE C3300 Series Service Guide May 2015
Page 13
