Canon iPF6100 - imagePROGRAF Color Inkjet Printer User manual

Mar 7 2011
Service Manual
iPF6000 series

Application
This manual has been issued by Canon Inc. for qualified persons to learn technical theory, installation, maintenance, and repair
of products. This manual covers all localities where the products are sold. For this reason, there may be information in this
manual that does not apply to your locality.
Corrections
This manual may contain technical inaccuracies or typographical errors due to improvements or changes in products. When
changes occur in applicable products or in the contents of this manual, Canon will release technical information as the need
arises. In the event of major changes in the contents of this manual over a long or short period, Canon will issue a new edition
of this manual.
The following paragraph does not apply to any countries where such provisions are inconsistent with local law.
Trademarks
The product names and company names used in this manual are the registered trademarks of the individual companies.
Copyright
This manual is copyrighted with all rights reserved. Under the copyright laws, this manual may not be copied, reproduced or
translated into another language, in whole or in part, without the written consent of Canon Inc.
COPYRIGHT © 2001 CANON INC.
Printed in Japan
Caution
Use of this manual should be strictly supervised to avoid disclosure of confidential information.

Introduction
Symbols Used
This documentation uses the following symbols to indicate special information:
Symbol Description
Indicates an item of a non-specific nature, possibly classified as Note, Caution, or Warning.
Indicates an item requiring care to avoid electric shocks.
Indicates an item requiring care to avoid combustion (fire).
Indicates an item prohibiting disassembly to avoid electric shocks or problems.
Indicates an item requiring disconnection of the power plug from the electric outlet.
Indicates an item intended to provide notes assisting the understanding of the topic in question.
Indicates an item of reference assisting the understanding of the topic in question.
Provides a description of a service mode.
Provides a description of the nature of an error indication.
Memo
REF.

Introduction
The following rules apply throughout this Service Manual:
1. Each chapter contains sections explaining the purpose of specific functions and the relationship between electrical and mechanical systems with refer-
ence to the timing of operation.
In the diagrams, represents the path of mechanical drive; where a signal name accompanies the symbol , the arrow indicates the
direction of the electric signal.
The expression "turn on the power" means flipping on the power switch, closing the front door, and closing the delivery unit door, which results in
supplying the machine with power.
2. In the digital circuits, '1'is used to indicate that the voltage level of a given signal is "High", while '0' is used to indicate "Low".(The voltage value, how-
ever, differs from circuit to circuit.) In addition, the asterisk (*) as in "DRMD*" indicates that the DRMD signal goes on when '0'.
In practically all cases, the internal mechanisms of a microprocessor cannot be checked in the field. Therefore, the operations of the microprocessors
used in the machines are not discussed: they are explained in terms of from sensors to the input of the DC controller PCB and from the output of the
DC controller PCB to the loads.
The descriptions in this Service Manual are subject to change without notice for product improvement or other purposes, and major changes will be com-
municated in the form of Service Information bulletins.
All service persons are expected to have a good understanding of the contents of this Service Manual and all relevant Service Information bulletins and be
able to identify and isolate faults in the machine."

Contents
Contents
Chapter 1 PRODUCT DESCRIPTION
1.1 Product Overview .......................................................................................................................................1- 1
1.1.1 Product Overview....................................................................................................................................................1- 1
1.1.2 Product Overview....................................................................................................................................................1- 2
1.1.3 Product Overview....................................................................................................................................................1- 3
1.1.4 Product Overview....................................................................................................................................................1- 4
1.1.5 Product Overview....................................................................................................................................................1- 5
1.2 Features .....................................................................................................................................................1- 6
1.2.1 Features ..................................................................................................................................................................1- 6
1.2.2 Features ..................................................................................................................................................................1- 6
1.2.3 Features ..................................................................................................................................................................1- 6
1.2.4 Features ..................................................................................................................................................................1- 7
1.2.5 Features ..................................................................................................................................................................1- 7
1.2.6 Features ..................................................................................................................................................................1- 7
1.2.7 Printhead.................................................................................................................................................................1- 8
1.2.8 Ink Tank...................................................................................................................................................................1- 8
1.2.9 Ink Tank...................................................................................................................................................................1- 9
1.2.10 Cutter...................................................................................................................................................................1- 10
1.2.11 Roll Feed Unit......................................................................................................................................................1- 10
1.2.12 Stand ...................................................................................................................................................................1- 11
1.2.13 Hard Disk Drive....................................................................................................................................................1- 11
1.2.14 Hard Disk Drive....................................................................................................................................................1- 11
1.2.15 IEEE1394 (FireWire) Board.................................................................................................................................1- 12
1.2.16 Consumables.......................................................................................................................................................1- 13
1.2.17 Consumables.......................................................................................................................................................1- 14
1.2.18 Consumables.......................................................................................................................................................1- 15
1.2.19 Consumables.......................................................................................................................................................1- 16
1.3 Product Specifications..............................................................................................................................1- 17
1.3.1 Product Specifications...........................................................................................................................................1- 17
1.3.2 Product Specifications...........................................................................................................................................1- 18
1.3.3 Product Specifications...........................................................................................................................................1- 20
1.3.4 Product Specifications...........................................................................................................................................1- 22
1.3.5 Product Specifications...........................................................................................................................................1- 24
1.3.6 Product Specifications...........................................................................................................................................1- 26
1.4 Detailed Specifications .............................................................................................................................1- 28
1.4.1 Print Speed and Direction......................................................................................................................................1- 28
1.4.2 Interface Specifications .........................................................................................................................................1- 34
1.4.3 Interface Specifications .........................................................................................................................................1- 35
1.4.4 Interface Specifications .........................................................................................................................................1- 36
1.5 Names and Functions of Components .....................................................................................................1- 37
1.5.1 Front......................................................................................................................................................................1- 37
1.5.2 Front......................................................................................................................................................................1- 38
1.5.3 Rear.......................................................................................................................................................................1- 39
1.5.4 Rear.......................................................................................................................................................................1- 39
1.5.5 Top Cover (Inside).................................................................................................................................................1- 40
1.5.6 Top Cover (Inside).................................................................................................................................................1- 40
1.5.7 Manual Loading Area ............................................................................................................................................1- 41
1.5.8 Manual Loading Area ............................................................................................................................................1- 42
1.5.9 Roll Feed Unit Cover (Inside)................................................................................................................................1- 43
1.5.10 Roll Feed Unit Cover (Inside) ..............................................................................................................................1- 43

Contents
1.5.11 Carriage ...............................................................................................................................................................1- 44
1.5.12 Inside....................................................................................................................................................................1- 45
1.5.13 Inside....................................................................................................................................................................1- 46
1.6 Basic Operation........................................................................................................................................1- 47
1.6.1 Operation Panel.....................................................................................................................................................1- 47
1.6.2 Operation Panel.....................................................................................................................................................1- 49
1.6.3 Main Menu.............................................................................................................................................................1- 50
1.6.4 Display...................................................................................................................................................................1- 70
1.6.5 Main Menu.............................................................................................................................................................1- 71
1.6.6 Main Menu.............................................................................................................................................................1- 91
1.6.7 Menu....................................................................................................................................................................1- 111
1.6.8 Menu....................................................................................................................................................................1- 127
1.7 Safety and Precautions ..........................................................................................................................1- 144
1.7.1 Safety Precautions...............................................................................................................................................1- 144
1.7.1.1 Moving Parts........................................................................................................................................................................1- 144
1.7.1.2 Adhesion of Ink .................................................................................................................................................................... 1- 144
1.7.1.3 Electric Parts........................................................................................................................................................................1- 146
1.7.1.4 Electric Parts........................................................................................................................................................................1- 146
1.7.2 Other Precautions................................................................................................................................................1- 147
1.7.2.1 Printhead.............................................................................................................................................................................. 1- 147
1.7.2.2 Printhead.............................................................................................................................................................................. 1- 148
1.7.2.3 Ink Tank ...............................................................................................................................................................................1- 149
1.7.2.4 Handling the Printer............................................................................................................................................................. 1- 149
1.7.2.5 Handling the Printer............................................................................................................................................................. 1- 152
1.7.3 Precautions When Servicing Printer....................................................................................................................1- 154
1.7.3.1 Notes on the Data Stored in the Printer............................................................................................................................... 1- 154
1.7.3.2 Confirming the Firmware Version ........................................................................................................................................ 1- 154
1.7.3.3 Precautions against Static Electricity...................................................................................................................................1- 154
1.7.3.4 Precautions for Disassembly/Reassembly........................................................................................................................... 1- 154
1.7.3.5 Self-diagnostic Feature........................................................................................................................................................ 1- 154
1.7.3.6 Disposing of the Lithium Battery ..........................................................................................................................................1- 154
Chapter 2 TECHNICAL REFERENCE
2.1 Basic Operation Outline .............................................................................................................................2- 1
2.1.1 Printer Diagram........................................................................................................................................................2- 1
2.1.2 Printer Diagram........................................................................................................................................................2- 2
2.1.3 Printer Diagram........................................................................................................................................................2- 3
2.1.4 Printer Diagram........................................................................................................................................................2- 4
2.1.5 Printer Diagram........................................................................................................................................................2- 5
2.1.6 Printer Diagram........................................................................................................................................................2- 6
2.1.7 Print Signal Sequence .............................................................................................................................................2- 7
2.1.8 Print Signal Sequence .............................................................................................................................................2- 8
2.1.9 Print Signal Sequence .............................................................................................................................................2- 9
2.1.10 Print Driving..........................................................................................................................................................2- 10
2.1.11 Print Driving..........................................................................................................................................................2- 12
2.1.12 Print Driving..........................................................................................................................................................2- 14
2.2 Firmware ..................................................................................................................................................2- 16
2.2.1 Operation Sequence at Power-on..........................................................................................................................2- 16
2.2.2 Operation Sequence at Power-off..........................................................................................................................2- 17
2.2.3 Print Control...........................................................................................................................................................2- 18
2.2.4 Print Position Adjustment Function........................................................................................................................2- 24
2.2.5 Head Management ................................................................................................................................................2- 24
2.2.6 Printhead Overheating Protection Control.............................................................................................................2- 24
2.2.7 Pause between Pages...........................................................................................................................................2- 24
2.2.8 White Raster Skip..................................................................................................................................................2- 24
2.2.9 Sleep Mode............................................................................................................................................................2- 24

Contents
2.2.10 Hard Disk Drive....................................................................................................................................................2- 24
2.3 Printer Mechanical System.......................................................................................................................2- 26
2.3.1 Outline...................................................................................................................................................................2- 26
2.3.1.1 Outline.................................................................................................................................................................................... 2- 26
2.3.2 Ink Passage...........................................................................................................................................................2- 27
2.3.2.1 Ink Passage ........................................................................................................................................................................... 2- 27
2.3.2.2 Ink Tank Unit.......................................................................................................................................................................... 2- 29
2.3.2.3 Carriage Unit.......................................................................................................................................................................... 2- 33
2.3.2.4 Printhead................................................................................................................................................................................ 2- 37
2.3.2.5 Purge Unit.............................................................................................................................................................................. 2- 38
2.3.2.6 Maintenance Cartridge...........................................................................................................................................................2- 42
2.3.2.7 Air Flow..................................................................................................................................................................................2- 44
2.3.3 Paper Path.............................................................................................................................................................2- 45
2.3.3.1 Outline.................................................................................................................................................................................... 2- 45
2.3.3.2 Paper Path.............................................................................................................................................................................2- 46
2.3.3.3 Cutter Unit.............................................................................................................................................................................. 2- 56
2.4 Printer Electrical System...........................................................................................................................2- 58
2.4.1 Outline...................................................................................................................................................................2- 58
2.4.1.1 Overview................................................................................................................................................................................2- 58
2.4.1.2 Overview................................................................................................................................................................................2- 60
2.4.1.3 Overview................................................................................................................................................................................2- 62
2.4.1.4 Overview................................................................................................................................................................................2- 64
2.4.1.5 Overview................................................................................................................................................................................2- 66
2.4.2 Main Controller......................................................................................................................................................2- 68
2.4.2.1 Main controller PCB components ..........................................................................................................................................2- 68
2.4.2.2 Main controller PCB components ..........................................................................................................................................2- 69
2.4.2.3 Main controller PCB components ..........................................................................................................................................2- 71
2.4.2.4 Main controller PCB components ..........................................................................................................................................2- 72
2.4.2.5 Main controller PCB components ..........................................................................................................................................2- 74
2.4.2.6 Main controller PCB components ..........................................................................................................................................2- 75
2.4.2.7 HDD expansion PCB components.........................................................................................................................................2- 77
2.4.3 Carriage Relay PCB..............................................................................................................................................2- 77
2.4.3.1 Carriage PCB components....................................................................................................................................................2- 77
2.4.4 Motor Driver...........................................................................................................................................................2- 78
2.4.4.1 Roll feed unit PCB components.............................................................................................................................................2- 78
2.4.5 Maintenance Cartridge Relay PCB........................................................................................................................2- 78
2.4.5.1 Maintenance cartridge relay PCB components......................................................................................................................2- 78
2.4.6 Power Supply ........................................................................................................................................................2- 79
2.4.6.1 Power supply block diagram..................................................................................................................................................2- 79
2.5 Detection Functions with Sensors ............................................................................................................2- 80
2.5.1 Sensors for covers.................................................................................................................................................2- 80
2.5.2 Ink passage system...............................................................................................................................................2- 81
2.5.3 Ink passage system...............................................................................................................................................2- 83
2.5.4 Ink passage system...............................................................................................................................................2- 85
2.5.5 Ink passage system...............................................................................................................................................2- 87
2.5.6 Carriage system ....................................................................................................................................................2- 89
2.5.7 Paper path system.................................................................................................................................................2- 91
2.5.8 Paper path system.................................................................................................................................................2- 93
2.5.9 Others....................................................................................................................................................................2- 95
Chapter 3 INSTALLATION
3.1 Installation ..................................................................................................................................................3- 1
3.1.1 Making Pre-Checks.................................................................................................................................................3- 1
3.1.1.1 Making Pre-Checks.................................................................................................................................................................. 3- 1
3.1.2 Unpacking and Installation ......................................................................................................................................3- 1
3.1.2.1 Unpacking and Installation....................................................................................................................................................... 3- 1
3.1.2.2 Installing the Stand ................................................................................................................................................................ 3- 10
3.1.3 Checking the Images/Operations..........................................................................................................................3- 19

Contents
3.1.3.1 Checking the Image and Operation.......................................................................................................................................3- 19
3.2 Transporting the Printer............................................................................................................................3- 20
3.2.1 Transporting the Printer.........................................................................................................................................3- 20
3.2.1.1 Transporting the Printer ......................................................................................................................................................... 3- 20
3.2.1.2 Transporting the Printer ......................................................................................................................................................... 3- 22
3.2.2 Reinstalling the Printer...........................................................................................................................................3- 24
3.2.2.1 Reinstalling the Printer...........................................................................................................................................................3- 24
Chapter 4 DISASSEMBLY/REASSEMBLY
4.1 Service Parts..............................................................................................................................................4- 1
4.1.1 Service Parts............................................................................................................................................................4- 1
4.2 Disassembly/Reassembly ..........................................................................................................................4- 2
4.2.1 Disassembly/Reassembly........................................................................................................................................4- 2
4.3 Points to Note on Disassembly and Reassembly.......................................................................................4- 2
4.3.1 Note: Items that should never be disassembled......................................................................................................4- 2
4.3.2 Moving the carriage manually..................................................................................................................................4- 2
4.3.3 Units requiring draining of ink ..................................................................................................................................4- 2
4.3.4 External Covers .......................................................................................................................................................4- 4
4.3.5 Driving Unit ............................................................................................................................................................4- 17
4.3.6 Cutter.....................................................................................................................................................................4- 18
4.3.7 Cutter.....................................................................................................................................................................4- 21
4.3.8 Carriage Unit..........................................................................................................................................................4- 24
4.3.9 Carriage Unit..........................................................................................................................................................4- 32
4.3.10 Feeder Unit ..........................................................................................................................................................4- 40
4.3.11 Feeder Unit ..........................................................................................................................................................4- 43
4.3.12 Roll Feed Unit ......................................................................................................................................................4- 46
4.3.13 Purge Unit............................................................................................................................................................4- 49
4.3.14 Waste Ink Collection Unit.....................................................................................................................................4- 52
4.3.15 Ink Tank Unit........................................................................................................................................................4- 56
4.3.16 Ink Tank Unit........................................................................................................................................................4- 59
4.3.17 Head Management Sensor..................................................................................................................................4- 62
4.3.18 Multi Sensor.........................................................................................................................................................4- 62
4.3.19 Multi Sensor.........................................................................................................................................................4- 63
4.3.20 PCBs....................................................................................................................................................................4- 64
4.3.21 PCBs....................................................................................................................................................................4- 67
4.3.22 PCBs....................................................................................................................................................................4- 72
4.3.23 Opening the Cap/Moving the Wiper Unit..............................................................................................................4- 77
4.3.24 Opening the Cap/Moving the Wiper Unit..............................................................................................................4- 79
4.3.25 Opening/Closing the Ink Supply Valve.................................................................................................................4- 81
4.3.26 Draining the Ink....................................................................................................................................................4- 82
4.4 Applying the Grease.................................................................................................................................4- 83
4.4.1 Applying the Grease ..............................................................................................................................................4- 83
4.5 Adjustment and Setup Items ....................................................................................................................4- 87
4.5.1 Adjustment Item List ..............................................................................................................................................4- 87
4.5.2 Adjustment Item List ..............................................................................................................................................4- 87
4.5.3 Procedure after Replacing the Carriage Unit or Multi Sensor................................................................................4- 87
4.5.4 Procedure after Replacing the Carriage Unit or Multi Sensor................................................................................4- 90
4.5.5 Procedure after Replacing the Head Management Sensor...................................................................................4- 93
Chapter 5 MAINTENANCE
5.1 Periodic Replacement Parts.......................................................................................................................5- 1
5.1.1 Periodic Replacement Parts ....................................................................................................................................5- 1
5.2 Consumable Parts......................................................................................................................................5- 1
5.2.1 Consumable Parts ...................................................................................................................................................5- 1

Contents
5.2.2 Consumable Parts...................................................................................................................................................5- 2
5.2.3 Consumable Parts...................................................................................................................................................5- 3
5.2.4 Consumable Parts...................................................................................................................................................5- 4
5.3 Periodic Maintenance.................................................................................................................................5- 5
5.3.1 Periodic Maintenance..............................................................................................................................................5- 5
5.3.2 Periodic Maintenance..............................................................................................................................................5- 8
5.3.3 Periodic Maintenance............................................................................................................................................5- 11
Chapter 6 TROUBLESHOOTING
6.1 Troubleshooting..........................................................................................................................................6- 1
6.1.1 Outline.....................................................................................................................................................................6- 1
6.1.1.1 Outline of Troubleshooting....................................................................................................................................................... 6- 1
6.1.2 Troubleshooting When Warnings Occur..................................................................................................................6- 1
6.1.2.1 Ink Lvl: Chk XX (1000,1001,1002,1003,1004,1005,1006,1008,1009,100A,100B,100C)......................................................... 6- 1
6.1.2.2 MTCart Full Soon (1100) .........................................................................................................................................................6- 1
6.1.2.3 Mist Full Soon (1101)...............................................................................................................................................................6- 1
6.1.2.4 GARO W12xx: xx stands for digits (1221,1222,1223,1225,1231,1232,1233,1234,1235) .......................................................6- 1
6.1.2.5 Feed Limit... (100F)..................................................................................................................................................................6- 2
6.1.2.6 Check printed document.(1010)...............................................................................................................................................6- 2
6.1.3 Troubleshooting When Errors Occur.......................................................................................................................6- 2
6.1.3.1 01800500-1012/01800500-1013 Defective printhead nozzle.................................................................................................. 6- 2
6.1.3.2 03010000-200C/03010000-2017/03010000-2018/03016000-2010 Multi sensor error............................................................6- 2
6.1.3.3 03010000-200D Cut sheet end cannot be detected ................................................................................................................6- 2
6.1.3.4 03010000-2820/03010000-2821/03010000-2822/03010000-2823/03130031-2F32/03010000-2F33 Adjustment error.........6- 3
6.1.3.5 03010000-2E1F/03060000-2E14/03061000-2E15/03060000-2E16/03060200-2E03/03060200-2E0B/03060A00-2E00/
03060A00-2E01/03860002-2E0A Path mismatch error................................................................................................................. 6- 3
6.1.3.6 03010000-2E25/03010000-2E27 Paper feed/delivery jam error .............................................................................................6- 3
6.1.3.7 03030000-2E21 IEEE1394 error..............................................................................................................................................6- 4
6.1.3.8 03060A00-2E0E Roll media unit uninstallation........................................................................................................................ 6- 4
6.1.3.9 03060A00-2E1B Roll media end error.....................................................................................................................................6- 4
6.1.3.10 03130031-291B Lift home position error................................................................................................................................ 6- 4
6.1.3.11 03130031-291D Supr cam sensor error................................................................................................................................. 6- 5
6.1.3.12 03130031-2E23 Cutter unit breakdown ................................................................................................................................. 6- 5
6.1.3.13 03130031-2F13 A/D Converter external trigger output stopped ............................................................................................6- 5
6.1.3.14 03130031-2F14 ASIC Register cannot be written................................................................................................................. 6- 5
6.1.3.15 03130031-2F16 Mist fan error................................................................................................................................................6- 5
6.1.3.16 03130031-2F17 Suction fan error..........................................................................................................................................6- 6
6.1.3.17 03130031-2F20/03130031-2F28/03130031-2F22/03130031-2F23 Defective sensor in purge unit......................................6- 6
6.1.3.18 03130031-2F24 Cutter drive time-out error............................................................................................................................ 6- 6
6.1.3.19 03130031-2F25 Carriage home position error....................................................................................................................... 6- 6
6.1.3.20 03130031-2F26/03130031-2F27 Carriage motor error..........................................................................................................6- 7
6.1.3.21 03130031-2F2A Feed roller home position error ...................................................................................................................6- 7
6.1.3.22 03130031-2F2D The cassette cannot work...........................................................................................................................6- 7
6.1.3.23 03130031-2F2E Roll drive time-out error...............................................................................................................................6- 7
6.1.3.24 03130031-2F3A Valve open/close error ................................................................................................................................ 6- 8
6.1.3.25 03180003-2E22 MIT error...................................................................................................................................................... 6- 8
6.1.3.26 03180101-2E17 Cassette uninstallation ................................................................................................................................6- 8
6.1.3.27 03800200-2802/03800400-2803/03800300-2801/03800201-280A/03800401-280B/03800301-2809/03800200-2804/
03800202-2807 Printhead error.....................................................................................................................................................6- 8
6.1.3.28 03810101-2501/03810102-2502/03810103-2503/03810104-2500/03810105-2508/03810106-2506/03810107-250A/
03810108-250C/03810109-250B/03810112-2504/03810113-2505/03810115-2509 No ink error................................................. 6- 9
6.1.3.29 03830101-2521/03830104-2520/03830102-2522/03830103-2523/03830112-2524/03830113-2525/03830106-2526/
03830105-2528/03830115-2529/03830107-252A/03830109-252B/03830108-252C Ink tank is not installed.(This error occurs when
the ink tank is replaced.) ................................................................................................................................................................6- 9
6.1.3.30 03830201-2541/03800204-2540/03830202-2542/03830203-2543/03830212-2544/03830213-2545/03830206-2546/
03830205-2548/03830215-2549/03830207-254A/03830209-254B/03830208-254C Invalid ink tank ID.......................................6-9
6.1.3.31 03830301-2561/03830304-2560/03830302-2562/03830303-2563/03830312-2564/03830313-2565/03830306-2566/
03830305-2568/03830305-2568/03830315-2569/03830307-256A/03830309-256B/03830308-256C Ink tank EEPROM error... 6- 9
6.1.3.32 03841001-2819/03841201-2816/03841201-2817/03841101-2818/01841001-281B Maintenance cartridge error................6- 9
6.1.3.33 03861001-2405/03861001-2406 Borderless printing error..................................................................................................6- 10

Contents
6.1.3.34 03862000-2E09 Insufficient roll media error........................................................................................................................ 6- 10
6.1.3.35 03870001-2015 Cut error.....................................................................................................................................................6- 10
6.1.4 Troubleshooting When Service Call Errors Occur.................................................................................................6- 10
6.1.4.1 Outline....................................................................................................................................................................................6- 10
6.1.4.2 E141-4046 Recovery system rotation count reached 50,000................................................................................................6- 11
6.1.4.3 E144-4047 Supply system's count error................................................................................................................................6- 11
6.1.4.4 E146-4001 Borderless/idle ejection/mist collection count full................................................................................................ 6- 11
6.1.4.5 E194-404A Non-discharge detection count error...................................................................................................................6- 11
6.1.4.6 E196-4040/E196-4041/E196-4042/E196-4045/E196-4049 main controller PCB error .........................................................6- 11
6.1.4.7 E198-401C/E198-401D/E198-401E RTC error......................................................................................................................6- 11
6.2 Location of Connectors and Pin Arrangement .........................................................................................6- 12
6.2.1 Main controller PCB...............................................................................................................................................6- 12
6.2.2 Main controller PCB...............................................................................................................................................6- 24
6.2.3 Main controller PCB...............................................................................................................................................6- 35
6.2.4 Main controller PCB...............................................................................................................................................6- 46
6.2.5 Main controller PCB...............................................................................................................................................6- 57
6.2.6 Carriage PCB.........................................................................................................................................................6- 68
6.2.7 Power supply .........................................................................................................................................................6- 77
6.2.8 Power supply .........................................................................................................................................................6- 78
6.2.9 Roll feed unit PCB..................................................................................................................................................6- 79
6.3 Version Up................................................................................................................................................6- 80
6.3.1 Firmware Update Tool ...........................................................................................................................................6- 80
6.3.2 Firmware Update Tool ...........................................................................................................................................6- 81
6.4 Service Tools............................................................................................................................................6- 82
6.4.1 Tool List .................................................................................................................................................................6- 82
Chapter 7 SERVICE MODE
7.1 Service Mode .............................................................................................................................................7- 1
7.1.1 Service Mode Operation..........................................................................................................................................7- 1
7.1.2 Service Mode Operation..........................................................................................................................................7- 2
7.1.3 Map of the Service Mode.........................................................................................................................................7- 3
7.1.4 Map of the Service Mode.........................................................................................................................................7- 8
7.1.5 Map of the Service Mode.......................................................................................................................................7- 13
7.1.6 Map of the Service Mode.......................................................................................................................................7- 18
7.1.7 Map of the Service Mode.......................................................................................................................................7- 25
7.1.8 Details of Service Mode.........................................................................................................................................7- 32
7.1.9 Details of Service Mode.........................................................................................................................................7- 40
7.1.10 Details of Service Mode.......................................................................................................................................7- 48
7.1.11 Details of Service Mode.......................................................................................................................................7- 56
7.1.12 Details of Service Mode.......................................................................................................................................7- 71
7.1.13 Sample Printout....................................................................................................................................................7- 86
7.1.14 e-Maintenance/imageWARE Remote..................................................................................................................7- 90
7.1.15 Viewing PRINT INF............................................................................................................................................7- 100
7.1.16 Viewing PRINT INF............................................................................................................................................7- 114
7.2 Special Mode..........................................................................................................................................7- 128
7.2.1 Special Modes for Servicing ................................................................................................................................7- 128
7.2.2 Special Modes for Servicing ................................................................................................................................7- 128
Chapter 8 ERROR CODE
8.1 Outline........................................................................................................................................................8- 1
8.1.1 Outline......................................................................................................................................................................8- 1
8.1.2 Outline......................................................................................................................................................................8- 2
8.2 Warning Table............................................................................................................................................8- 3
8.2.1 Warnings..................................................................................................................................................................8- 3
8.2.2 Warnings..................................................................................................................................................................8- 4

Contents
8.2.3 Warnings .................................................................................................................................................................8- 5
8.3 Error Table..................................................................................................................................................8- 8
8.3.1 Error Code List ........................................................................................................................................................8- 8
8.3.2 Error Code List ......................................................................................................................................................8- 18
8.3.3 Errors.....................................................................................................................................................................8- 29
8.4 Sevice Call Table......................................................................................................................................8- 40
8.4.1 Service Call Errors.................................................................................................................................................8- 40
8.4.2 Service Call Errors.................................................................................................................................................8- 40
8.4.3 Service Call Errors.................................................................................................................................................8- 41

Contents

Chapter 1 PRODUCT DESCRIPTION

Contents
Contents
1.1 Product Overview ..........................................................................................................................................................1-1
1.1.1 Product Overview ........................................................................................................................................................................ 1-1
1.1.2 Product Overview ........................................................................................................................................................................ 1-2
1.1.3 Product Overview ........................................................................................................................................................................ 1-3
1.1.4 Product Overview ........................................................................................................................................................................ 1-4
1.1.5 Product Overview ........................................................................................................................................................................ 1-5
1.2 Features..........................................................................................................................................................................1-6
1.2.1 Features........................................................................................................................................................................................ 1-6
1.2.2 Features........................................................................................................................................................................................ 1-6
1.2.3 Features........................................................................................................................................................................................ 1-6
1.2.4 Features........................................................................................................................................................................................ 1-7
1.2.5 Features........................................................................................................................................................................................ 1-7
1.2.6 Features........................................................................................................................................................................................ 1-7
1.2.7 Printhead ...................................................................................................................................................................................... 1-8
1.2.8 Ink Tank....................................................................................................................................................................................... 1-8
1.2.9 Ink Tank....................................................................................................................................................................................... 1-9
1.2.10 Cutter........................................................................................................................................................................................ 1-10
1.2.11 Roll Feed Unit.......................................................................................................................................................................... 1-10
1.2.12 Stand ........................................................................................................................................................................................ 1-11
1.2.13 Hard Disk Drive....................................................................................................................................................................... 1-11
1.2.14 Hard Disk Drive....................................................................................................................................................................... 1-11
1.2.15 IEEE1394 (FireWire) Board.................................................................................................................................................... 1-12
1.2.16 Consumables............................................................................................................................................................................ 1-13
1.2.17 Consumables............................................................................................................................................................................ 1-14
1.2.18 Consumables............................................................................................................................................................................ 1-15
1.2.19 Consumables............................................................................................................................................................................ 1-16
1.3 Product Specifications..................................................................................................................................................1-17
1.3.1 Product Specifications ............................................................................................................................................................... 1-17
1.3.2 Product Specifications ............................................................................................................................................................... 1-18
1.3.3 Product Specifications ............................................................................................................................................................... 1-20
1.3.4 Product Specifications ............................................................................................................................................................... 1-22
1.3.5 Product Specifications ............................................................................................................................................................... 1-24
1.3.6 Product Specifications ............................................................................................................................................................... 1-26
1.4 Detailed Specifications ................................................................................................................................................1-28
1.4.1 Print Speed and Direction.......................................................................................................................................................... 1-28
1.4.2 Interface Specifications.............................................................................................................................................................. 1-34
1.4.3 Interface Specifications.............................................................................................................................................................. 1-35
1.4.4 Interface Specifications.............................................................................................................................................................. 1-36
1.5 Names and Functions of Components .........................................................................................................................1-37
1.5.1 Front........................................................................................................................................................................................... 1-37
1.5.2 Front........................................................................................................................................................................................... 1-38
1.5.3 Rear............................................................................................................................................................................................ 1-39
1.5.4 Rear............................................................................................................................................................................................ 1-39
1.5.5 Top Cover (Inside)..................................................................................................................................................................... 1-40
1.5.6 Top Cover (Inside)..................................................................................................................................................................... 1-40
1.5.7 Manual Loading Area ................................................................................................................................................................ 1-41
1.5.8 Manual Loading Area ................................................................................................................................................................ 1-42
1.5.9 Roll Feed Unit Cover (Inside).................................................................................................................................................... 1-43
1.5.10 Roll Feed Unit Cover (Inside).................................................................................................................................................. 1-43
1.5.11 Carriage.................................................................................................................................................................................... 1-44

Contents
1.5.12 Inside........................................................................................................................................................................................ 1-45
1.5.13 Inside........................................................................................................................................................................................ 1-46
1.6 Basic Operation........................................................................................................................................................... 1-47
1.6.1 Operation Panel.......................................................................................................................................................................... 1-47
1.6.2 Operation Panel.......................................................................................................................................................................... 1-49
1.6.3 Main Menu................................................................................................................................................................................. 1-50
1.6.4 Display....................................................................................................................................................................................... 1-70
1.6.5 Main Menu................................................................................................................................................................................. 1-71
1.6.6 Main Menu................................................................................................................................................................................. 1-91
1.6.7 Menu ........................................................................................................................................................................................ 1-111
1.6.8 Menu ........................................................................................................................................................................................ 1-127
1.7 Safety and Precautions .............................................................................................................................................. 1-144
1.7.1 Safety Precautions.................................................................................................................................................................... 1-144
1.7.1.1 Moving Parts...............................................................................................................................................................................................1-144
1.7.1.2 Adhesion of Ink ..........................................................................................................................................................................................1-144
1.7.1.3 Electric Parts...............................................................................................................................................................................................1-146
1.7.1.4 Electric Parts...............................................................................................................................................................................................1-146
1.7.2 Other Precautions..................................................................................................................................................................... 1-147
1.7.2.1 Printhead.....................................................................................................................................................................................................1-147
1.7.2.2 Printhead.....................................................................................................................................................................................................1-148
1.7.2.3 Ink Tank......................................................................................................................................................................................................1-149
1.7.2.4 Handling the Printer....................................................................................................................................................................................1-149
1.7.2.5 Handling the Printer....................................................................................................................................................................................1-152
1.7.3 Precautions When Servicing Printer........................................................................................................................................ 1-154
1.7.3.1 Notes on the Data Stored in the Printer ......................................................................................................................................................1-154
1.7.3.2 Confirming the Firmware Version..............................................................................................................................................................1-154
1.7.3.3 Precautions against Static Electricity..........................................................................................................................................................1-154
1.7.3.4 Precautions for Disassembly/Reassembly ..................................................................................................................................................1-154
1.7.3.5 Self-diagnostic Feature ...............................................................................................................................................................................1-154
1.7.3.6 Disposing of the Lithium Battery ...............................................................................................................................................................1-154

Chapter 1
1-1
1.1 Product Overview
1.1.1 Product Overview
0016-8093
iPF6100
This printer is capable of printing on A4- to A1-size cut sheets and its maximum print width is 24 inches. This printer is a desktop large-format printer twelve-colors
(pigment-based colors) printer that can be used to print office documents as well as handy POP and posters. An auto roll feed unit is equipped for printing on roll
media.
F-1-1
F-1-2
T-1-1
[1] Top Cover [10] Operation Panel
[2] Ink Tank Cover [11] Roll Feed Unit
[3] Cutter [12] Roll Feed Unit Cover
[4] Front Manual Feed Guide [13] Manual Feed Cover
[5] Peper Eject Slot [14] Power Connector
[6] Paper Alignment Line [15] Ethernet Connector
[7] Basket [16] USB Port
[8] Stand [17] Expansion Board Slot
[9] Output Guide [18] Carrying Handle
[1]
[2]
[13] [12]
[11]
[10]
[9]
[8]
[7]
[6]
[5]
[3]
[4]
[17]
[18]
[18]
[16]
[15]
[14]

Chapter 1
1-2
1.1.2 Product Overview
0020-1808
iPF6200
This printer is capable of printing on A4- to A1-size cut sheets and its maximum print width is 24 inches. This printer is a desktop large-format printer twelve-colors
(pigment-based colors) printer that can be used to print office documents as well as handy POP and posters. An auto roll feed unit is equipped for printing on roll
media.
F-1-3
F-1-4
T-1-2
[1] Top Cover [10] Operation Panel
[2] Ink Tank Cover [11] Roll Feed Unit
[3] Cutter [12] Roll Feed Unit Cover
[4] Front Manual Feed Guide [13] Manual Feed Cover
[5] Peper Eject Slot [14] Power Connector
[6] Paper Alignment Line [15] Ethernet Connector
[7] Basket [16] USB Port
[8] Stand [17] Carrying Handle
[9] Output Guide
[1]
[2]
[13] [12]
[11]
[10]
[9]
[8]
[7]
[6]
[5]
[3]
[4]
[17]
[17]
[16]
[15]
[14]
