Canon DR-X10C - imageFORMULA - Document Scanner User manual

SERVICE
MANUAL
imageFORMULA
DR-X10C
COPYRIGHT 2008 CANON INC. CANON imageFORMULA DR-X10C Rev. 0 PRINTED IN U.S.A.
January 1, 2008
Rev. 0

COPYRIGHT ©CANON ELECTRONICS INC. 2008
Use of this manual should be
strictly supervised to avoid
disclosure of confidential
information.

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
PREFACE
Quality Assurance Cente
r
Canon Electronics Inc.
This Service Manual describes necessary basic information for field service and maintenance for
maintaining the product quality and functions of this machine.
Contents
Chapter 1: General description
Product specifications, name of parts, operation method
Chapter 2: Functions and operation
Description of operation of machine system and electrical system by function
Chapter 3: Disassembly and reassembly
Disassembly method, reassembly method
Chapter 4: Installation and maintenance
Installation method, maintenance method
Chapter 5: Troubleshooting
Error display and troubleshooting
Appendix: General diagram etc.
Information in this manual is subject to change. Notification of such changes will be given in Service
Information Bulletins.
Thoroughly read the information contained in this Service Manual and the Service Information Bulletins
to gain a correct and deeper understanding of the machine. This is one way of fostering response for
ensuring prolonged quality and function, and for investigating the cause of trouble during troubleshooting.

CONTENTS
COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
CHAPTER 1
GENERAL DESCRIPTION
I. PRODUCT SPECIFICATIONS................1-1
1. Features..............................................1-1
2. Specifications......................................1-2
3. Precautions.........................................1-7
II. NAME OF PARTS....................................1-8
1. Front Side ...........................................1-8
2. Rear Side............................................1-9
3. Control Panel......................................1-9
III. USER OPERATION...............................1-10
1. Preparation of Trays..........................1-10
2. Feeding Methods..............................1-12
3. Job Function .....................................1-13
4. CapturePerfect3.0.............................1-14
5. Document Jam Processing...............1-16
CHAPTER 2
FUNCTIONS & OPERATION
I. OUTLINE.................................................2-1
1. Basic Configuration.............................2-1
2. Roller Arrangement.............................2-2
3. Motor Drive .........................................2-3
4. List of Sensors....................................2-4
5. Electrical Circuits ................................2-5
6. Timing Chart........................................2-6
II. READING SYSTEM.................................2-7
1. Outline.................................................2-7
2. Image Reading....................................2-8
3. Shading...............................................2-9
4. Dust-free Function ............................ 2-11
5. Frame Detection Unit........................2-13
III. FEED SYSTEM .....................................2-14
1. Outline...............................................2-14
2. Pickup Tray Elevation .......................2-15
3. Pickup Unit........................................2-16
4. Staple Detection................................2-18
5. Ultrasonic Double Feed Detection....2-19
6. Jam Detection...................................2-19
IV. CONTROL SYSTEM..............................2-20
1. Control PCB......................................2-20
2. Drive System Block Diagram............2-22
3. Image Processing Control.................2-23
V. POWER SUPPLY ..................................2-25
1. Power Supply....................................2-25
VI. OPTION.................................................2-27
1 Imprinter............................................2-27
2. Patchcode Decoder ..........................2-28
3. Barcode Module................................2-28
VII. ELECTRICAL PARTS LAYOUT.............2-29
1. Motor, Clutch, Fan.............................2-29
2. PCB...................................................2-31
VIII. PARTS LAYOUT ON EACH PCB..........2-33
1. Control PCB.....................................2-33
2. Main Drive PCB ................................2-35
3. Main Motor PCB................................2-36
4. Power Supply PCB ...........................2-37
CHAPTER 3
DISASSEMBLY &
REASSEMBLY
I. REPLACED BY USERS ..........................3-1
1. Pickup Roller.......................................3-1
2. Feed Roller..........................................3-1
3. Retard Roller.......................................3-2
II. EXTERNAL COVERS..............................3-3
1. Rear Cover..........................................3-3
2. Right Cover.........................................3-3
3. Left Cover............................................3-5
4. Top Cover............................................3-6
5. Pickup Tray Unit..................................3-6
6. Pickup Document Guide.....................3-7
7. Tray Guide ..........................................3-9
8. Lower Front Cover ............................3-10
9. Eject Tray Unit...................................3-10
10. Eject Document Guide.....................3-11

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
11. Operation Panel.............................. 3-12
III. BASE UNIT-1 (ELECTRICAL SYSTEM)
.......................................................... 3-13
1. Control PCB...................................... 3-13
2. Power Supply PCB........................... 3-14
3. Main Motor........................................ 3-15
4. Main Motor PCB............................... 3-16
5. Exhaust Fan ..................................... 3-17
6. Tray Detection PCB.......................... 3-17
7. Tray Drive Unit.................................. 3-18
8. Pickup Tray Motor ............................ 3-19
9. Separation Motor.............................. 3-19
10. Ultrasonic Drive PCB ...................... 3-20
11. Eject Unit......................................... 3-21
12. Eject Motor...................................... 3-21
13. Eject PCB........................................ 3-22
14. Platen Motor (Lower) ...................... 3-22
IV. BASE UNIT-2 (FEED SYSTEM) ........... 3-24
1. Entrance Lower Guide Unit.............. 3-24
2. Platen Roller (Lower)........................ 3-24
3. Registration Roller............................ 3-25
4. Reading Roller (Front)...................... 3-26
5. Reading Roller (Center) ................... 3-27
6. Reading Roller (Rear) ...................... 3-28
7. U-Turn Roller A................................. 3-28
8. U-Turn Roller B................................. 3-29
9. Eject Roller....................................... 3-30
10. Belt (Right)...................................... 3-30
11. Belt (Left)......................................... 3-31
V. BASE UNIT-3 (READING SYSTEM) .... 3-32
1. Reading Unit (Lower) ....................... 3-32
2. Reading PCB.................................... 3-33
3. Shading Motor.................................. 3-35
4. CIS Unit............................................ 3-36
5. Reading Holder ................................ 3-38
6. Blower............................................... 3-38
7. Frame Detection Unit ....................... 3-39
VI. UPPER UNIT-1 (EXTERNAL COVERS)
.......................................................... 3-40
1. Entrance Upper Unit......................... 3-40
2. Pickup Roller Cover.......................... 3-40
3. Upper Front Cover............................ 3-41
4. Entire Upper Unit.............................. 3-42
VII. UPPER UNIT-2 (ELECTRICAL SYSTEM)
.......................................................... 3-46
1. Main Drive PCB................................ 3-46
2. Staple PCB....................................... 3-47
3. Ultrasonic Sensor PCB..................... 3-48
4. Pickup Unit Motor............................. 3-49
5. Platen Motor..................................... 3-50
VIII. UPPER UNIT-3 (FEED SYSTEM)......... 3-51
1. Platen Roller..................................... 3-51
2. Registration Roller...........................3--51
3. Reading Roller (Front)...................... 3-52
4. Reading Roller (Center) ................... 3-53
5. Reading Roller (Rear)....................... 3-53
6. U-Turn Rollers .................................. 3-54
7. Eject Roller....................................... 3-55
8. Pickup Unit ....................................... 3-55
9. Reverse Roller.................................. 3-56
10. Roller Holder ................................... 3-56
IX. UPPER UNIT-4 (READING SYSTEM).. 3-58
1. Reading Unit..................................... 3-58
2. Reading PCB.................................... 3-59
3. Blower............................................... 3-60
4. Reading Holder................................. 3-61
X. OPTION................................................. 3-62
1. Post-Imprinter................................... 3-62
2. Pre-Imprinter..................................... 3-64
CHAPTER 4
INSTALLATION &
MAINTENANCE
I. INSTALLATION ....................................... 4-1
1. Choosing Location.............................. 4-1
2. UnpackingAnd Installation................. 4-2
3. Pre-imprinter Installation Procedure... 4-9
4. Post-imprinter Installation Procedure
........................................................ 4-12

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
5. Patchcode Decoder Installation
Procedure........................................4-15
II. PARTS REPLACEMENT.......................4-17
1. Periodically Replaced Parts..............4-17
2. Consumable Parts (Commercial Goods)
.........................................................4-17
3. Consumable Parts (For User)...........4-17
4. Consumable Parts (For servicing)....4-18
5. Main Parts.........................................4-20
III. MAINTENANCE.....................................4-21
1. User Maintenance.............................4-21
2. Service Maintenance ........................4-22
CHAPTER 5
TROUBLESHOOTING
I. ERROR DISPLAY....................................5-1
1. Main Body...........................................5-1
2. Computer............................................5-3
II. USER MODE...........................................5-4
1. Operations and Items .........................5-4
III. SERVICE MODE.....................................5-6
1. Outline.................................................5-6
2. Installation Procedure.........................5-8
3. Starting Up and Exiting Service Mode 5-8
4. All Adjustment.....................................5-9
5. Individual Adjustments......................5-10
6. Analog...............................................5-11
7. Firm Load..........................................5-12
8. About.................................................5-12
9. Max Document Size..........................5-13
10. Dcon Check.....................................5-13
11. Check Device ..................................5-24
12. Sleep................................................5-24
13. SCSI Transfer..................................5-25
14. Counter............................................5-25
IV. LIST OF FAILURES...............................5-27
1. Operation Failures ............................5-27
2. Images Failures ................................5-27
V. OPERATION TROUBLESHOOTING ....5-28
1. No Power Is Supplied .......................5-28
2. Scanner Is Not Recognized..............5-29
3. Scanning Does Not Start...................5-30
4. Documents Are Not Fed Properly.....5-31
5. Scanning Speed IS Slow...................5-32
VI. IMAGE TROUBLESHOOTING..............5-33
1. Completely Black, Completely White,
All Streaks........................................5-34
2. Too Dark, Too Light...........................5-34
3. Wrong Image Size.............................5-35
4. Image Skews ....................................5-35
5. Streaks on Image..............................5-36
6. Text Invisible .....................................5-36
7. Moire (A Shimmering Wavy Pattern) on
Image...............................................5-37
VII. AFTER REPLACING PARTS ................5-38
APPENDIX
I. GENERAL DIAGRAM............................. A-1
II. UPPER UNIT DIAGRAM........................ A-2

CHAPTER 1
GENERAL DESCRIPTION
COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
I. PRODUCT SPECIFICATIONS.................1-1
II. NAME OF PARTS....................................1-8 III. USER OPERATION ...............................1-10

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION 1-1
CHAPTER 1 GENERAL DESCRIPTION
I. PRODUCT SPECIFICATIONS
1. Features
1) High-speed scanning
Binary/Grayscale/Color, 200 dpi: Simplex 100 ppm, Duplex 200 ipm (A4 portrait)
Color, 300 dpi: Simplex 100 ppm, Duplex 170 ipm (A4 portrait)
2) Dust prevention
Blower: blowing the dust off
Wiper: wiping on the reading glass
Dust escape function: changing the reading position
3) Feed advancement
Separation roller control
Eject roller control
Double feed retry function
4) Image treatment by high-speed IC
5) Many other functions
Three ultrasonic sensors, Staple detection, Exchangeable background color, Moire reduction,
etc.
6) High-durability
Expected life: 18-million sheets (A4 portrait)
“Windows” is a trademark of Microsoft Corporation in the U.S. and other countries.
Other company names and product names mentioned in this document are registered trademarks or
trademarks of the respective companies.

1-2 COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
CHAPTER 1 GENERAL DESCRIPTION
2. Specifications
1) Appearance/Installation
No. Item Specifications
1 Type Desktop type sheet-fed scanner
2 Power supply rating 1) 100V model: 100 VAC, 50/60 Hz, 125 W
2) 120V model: 120 VAC, 60 Hz, 1.4 A
3) 200V model: 220-240 VAC, 50/60 Hz, 0.8 A
3 Power consumption 1) Operating: 125 W
2) Stand-by mode: 4.2 W (100 V/120 V), 4.5 W (200 V)
3) Power switch OFF: 0 W
4 Operating environment 10 to 32.5°C (50 to 90.5°F), 20 to 80%RH
*No condensation allowed.
5 Noise 1) Standby: 40 dB max.
2) Operating: 72 dB max.
*Sound power level
6 Dimensions
* Details to be described
later.
Tray closed: 528 (W) ×563(D) ×375 (H) mm
Tray opened: 528 (W) ×861(D) ×432 (H) mm
7 Weight 39 kg (Main body only)
8 Output interface 1) USB 2.0 (Hi-speed)
2) SCSI-3 (Ultra)
3) KOFAX board interface
*KOFAX board will be released after this machine.
9 Expected product life
(In-house information) One of the following two items, whichever comes first. 1) 5 years
2) Sheets fed: 18-millon sheets (A4 copy paper)
*There are parts needed to replace.
10 Installation By service technicians
11 Bundle software ISIS/TWAIN driver, CapturePerfect 3.0, Job Tool
12 Consumable parts
(commercial goods) 1) Exchange roller kit (Pickup/Feed/Retard rollers) *Expected life 500,000 sheets
2) Roller cleaning sheets
3) Ink cartridge
*Ink cartridge is consumable parts for Imprinter (option).
13 Option 1) Pre-imprinter
2) Post-imprinter
3) Patchcode decoder
4) Barcode module (driver's option)
Table 1-101

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION 1-3
CHAPTER 1 GENERAL DESCRIPTION
* Dimensions (unit: mm)
(861)
563
(536)
(432)
(140)
375
528
Figure 1-101

1-4 COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
CHAPTER 1 GENERAL DESCRIPTION
2) Document feed
No. Item Specifications
1 Document feed path U-turn path
1) Width 50.8 to 305 mm
*Less than 55 mm, no guarantee for
skew.
2) Length 70 to 432 mm
*Excluded long document mode.
2 Document size
3) Weight
(thickness) 1) Separation pickup 52 to 128 g/m2 (0.06 to 0.15 mm)
2) Non-separation pickup
42 to 255 g/m2 (0.05 to 0.30 mm)
3 Document limitation 1) Pressure-sensitive paper: Can be fed with limitation of
direction.
2) Carbon-backed paper: Cannot be fed.
3) Perforated paper for binder: Can be fed with limitation of
holes.
4) Curled paper: Can be fed only if curl is 8 mm or less.
5) Creased paper: Can be fed, but crease must be
straightened before being fed.
*For the staple detection, curl is 3 mm or less, and no
crease.
4 Long document mode Length: 1000 mm max.
*Thickness is 0.2 mm or less.
*Image data size is 384 MB ×80% or less.
*Feeding function is not guaranteed.
*If using the Folio together, A1-size scanning is available.
5 Document storage 1) Pickup: 500 sheets max. or 48mm height max.
(including curls)
2) Eject: 500 sheets max. or 50mm height max.
(including curls)
Resolution Binary, Grayscale, Color
100/150/200/240/300 dpi
400/600 dpi (speed priority) 661.7 mm/sec
6 Feeding speed
400/600 dpi (image priority) 165.4 mm/sec
7 Double feed detection 1) Length detection (by registration sensor)
2) Ultrasonic double feed detection (3 positions)
*Separation retry function is available, when it is detected.
8 Dust prevent function 1) Blower: The fans are installed in the reading unit.
2) Wiper: The brush is attached on the platen roller.
9 Other functions 1) Separation torque adjustment
2) Automatic eject speed control
3) Staple detection
4) Multiple document guides positioning
5) Pickup tray position adjustment
Table 1-102

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION 1-5
CHAPTER 1 GENERAL DESCRIPTION
3) Document reading *using bundle software CapturePerfect 3.0
No. Item Specifications
1 Type of sensor 3-line Contact Image Sensor (CIS)
2 Sensor pixels 600 dpi, Effective pixels 7396 ×3 lines (313 mm)
3 Light source 3-color (RGB) LED, Double-side illumination
4 Background color White or Black (User selection)
5 Image data memory size 384 MB (However, 20% of it is used for image rotation.)
6 Document frame sensor Sensor: CIS (300 dpi), Light source: LED (penetrate type)
*To use the auto-size detection and deskew.
7 Reading side Simplex/Duplex/Blank skip/Folio
8 Reading size 1) Typical: A3/A4/A4-R/A5/A5-R/A6/A6-R,
B4/B5/B5-R/B6/B6-R, LDR/LGL/LTR/LTR-R
2) Auto-size detection
3) Maximum size (305 ×432 mm)
4) User setting
5) Margin (±10 mm)
9 Output mode 1) Binary (Black and white/Error diffusion/ATE/ATE-II)
*ATE=Advanced Text Enhancement
*ATE-II is not available at 400/600 dpi.
2) Grayscale (8 bits)
3) Color (24 bits)
4) Auto image type detection
10 Output resolution 100 ×100 dpi, 150 ×150 dpi, 200 ×200 dpi, 240 ×240 dpi,
300 ×300 dpi, 400 ×400 dpi (speed priority),
600 ×600 dpi (speed priority), 400 ×400 dpi (image priority),
600 ×600 dpi (image priority)
*A4 portrait, JPEG transportation for grayscale and color
modes.
Mode
(file format) Resolution Simplex Duplex
200 dpi 100 ppm 200 ipm
300 dpi 100 ppm 200 ipm
600 dpi (speed priority) 82 ppm 82 ipm
Black and
white
(TIFF)
600 dpi (image priority) 25 ppm 50 ipm
200 dpi 100 ppm 200 ipm
300 dpi 100 ppm 200 ipm
600 dpi (speed priority) 84 ppm 84 ipm
Grayscale
(JPEG)
600 dpi (image priority) 25 ppm 50 ipm
200 dpi 100 ppm 200 ipm
300 dpi 100 ppm 170 ipm
600 dpi (speed priority) 46 ppm 46 ipm
Color
(JPEG)
600 dpi (image priority) 25 ppm 18 ipm
11 Reading speed
*The numbers above may differ depending on the com-
puter, the function settings and other conditions.
Table 1-103

1-6 COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
CHAPTER 1 GENERAL DESCRIPTION
4) Image processing/Other functions *using bundle software CapturePerfect 3.0
No. Item Specifications
1 Brightness adjustment 255 steps, back side individual setting,Auto for Black and
white mode (ABC processing)
*Not available for ATE/ATE-II
2 Contrast adjustment 7 steps, back side individual setting
3 Gamma correction Front/back side each, R/B/G/grayscale
4 Edge emphasize 5 steps
5 Color dropout Dropout/emphasize, R/G/B/custom, front/back side each
6 Moire reduction None/Hi-speed/Hi-quality
*Depend on the resolution, selectable items are different.
7 Other image processing Dots erasing, Prevent bleed-through/Remove background,
Text orientation recognition, Border removal, Punch hole
removal, Add-on, Resampling (included MultiStream), Pre-
scan, 3-D gamma (color correction), Image rotation
8 Other function Skew detection, Rapid recovery scan, Continuous manual
feed, Dust escape, Buzzer, Count only, Verify count, Auto-
matic pickup tray opening, USB interlock power switch,
Roller cleaning, Batch separation
9 Operation section Keys (Start/Stop/Functions), Display LCD (16 characters ×
2 lines)
*Function of buttons can be invalided.
10 User modes Setting by operation section of the main body.
11 Job function Save as file
12 Counter Sheets count for total scanning and replacing parts
(memorized in EEPROM on the scanner main body)
Table 1-104
The specifications above are subject to change for improvement of the product.

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION 1-7
CHAPTER 1 GENERAL DESCRIPTION
3. Precautions
This section describes items that require
particular care, for example, regarding human
safety.
These precautions must be observed.
The user should be explained the items that
relate to user safety and instructed to take
appropriate actions.
1) Power OFF in emergency
If such abnormal conditions as extraordi-
nary noise, smoke, heat and odor occur,
immediately unplug the power cord.
Be careful not to get clothing (ties, long
hair, etc.) caught in the machine as it may
cause injury. Should this occur, immedi-
ately unplug the power cord. Do not insert
fingers in the feed section while moving
the rollers.
2) Power OFF on disassembling
When disassembling and assembling are
performed, unplug the power cord.
3) Prohibition of modify
This machine must not arbitrarily be
modified or remade. If it is, use may be
forcibly suspended.
To change the specifications or disas-
semble and reassemble this machine, fol-
low the instructions described in this
manual and the service information.
4) Electromagnetic wave interference
This machine complies with some stan-
dards regarding electromagnetic wave
interference, such as VCCI and FCC.
However, the user may have to take
countermeasures if the machine causes
electromagnetic wave interference.
5) “User Manual”
Read each “User Manual” thoroughly prior
to use of this machine.
6) Disposal
Follow local regulations when disposing of
the product and parts. This product is
subject to the WEEE Directive in Europe.
7) Movement
This machine weighs 39 kg. When lifting
or moving this machine, 2 persons must
hold it from both sides.
Figure 1-102

1-8 COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
CHAPTER 1 GENERAL DESCRIPTION
II. NAME OF PARTS
1. Front Side
Figure 1-201
{
1Document eject tray
{
2Document feed tray (Pickup tray ¼)
{
3Power switch
{
4Operation panel
{
5Document guide
{
6Eject paper stoppers
{
7Document eject tray extension
{
8Document guide
{
9Document guide lock lever
{
10
Document feed tray extension
Note:In this manual, the “Document feed tray” may also be mentioned as the “Pickup tray.”

COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION 1-9
CHAPTER 1 GENERAL DESCRIPTION
2. Rear Side
Figure 1-202
{
1USB connector (Type B)
{
2SCSI connector (Half pitch D-sub 50 pin)
{
3DIP switches (SCSI ID)
{
4Power connector
{
5Ventilation holes (exhaust fan)
3. Control Panel ¼
Figure 1-203
{
1Display panel
{
2Enter key
{
3keys (allow keys)
{
4Menu key
{
5Job key
{
6Count Only key
{
7Bypass Mode key
{
8New file key
{
9START key
{
10
STOP key
Note:In this manual, the “Control panel” may
also be mentioned as the “Operation
panel.”

1-10 COPYRIGHT © CANON ELECTRONICS INC. 2008 CANON DR-X10C FIRST EDITION
CHAPTER 1 GENERAL DESCRIPTION
III. USER OPERATION
This section presents an outline of the
scan operations and document jam clearing.
Refer to the “User Manual” of this ma-
chine for details. This machine includes 2
printed manuals; the “Easy Start Guide” and
the “Reference Guide.” The CD-ROM disc
contains the data of the “User Manual” in
addition to these manuals.
The machine is installed by the service
technician.
1. Preparation of Trays
Before scanning documents, prepare for
the document feed tray and document eject
tray according to the documents.
1) Document feed tray
When the power to the main body is
turned ON, the document feed tray opens
automatically and moves to the height of
the set home position.
Figure 1-301
Push the document guides from both
sides (
{
1) and adjust their positions ac-
cording to the document width (
{
2).
Figure 1-302
Note:The right and left positions can be
changed by locking the document guides.
Refer to the “User Manual” for the details.
Pull out the document feed tray extension
according to the document length.
Figure 1-303
