COOLER FANS AWC160400/AWC280700/AWC360900/AWC421000/AWC481200
INSTRUCTION MANUAL
1. Make sure there is a clear, unobstructed path in front of the evaporative cooler to provide maximum airflow.
2. If the evaporative cooler is positioned on a raised platform, ensure the platform is stable, well constructed, and will not allow the evaporative cooler to tip
over and that it allows for the full weight of theof the evaporative cooler including a tank full of water . The cooler must be level and in the upright position. The
casters also be locked to prevent the evaporative cooler from moving.
3. If placed near a wall or other obstruction, position the evaporative cooler a minimum of 3 feet (0.9 meters) from the wall or obstruction with evaporation media
facing the wall. This allows the unrestricted flow of warm air to the cool Comfort evaporative media side of the evaporative cooler. When using multiple
evaporative coolers in close proximity, be sure to aim each evaporative cooler so the air flows complement each other to achieve maximum cooling capacity.
PLACEMOMENT
Once the tank is full of water , moving the pump switch to the“ON” position on the control panel with turn on the pump . When initially turning on the pump , the
level in the water tank will drop suddenly and restart the flow of supply water . This is a normal condition , as the evaporative media requires a large amount of
water for proper wetting.
New cool Comfort evaporative media will require an initial 'breaking-in' period. This period is required for the media to begin readily absorbing water. It may
require to a week to achieve maximum efficiency.
It is important to ensure that the water flow to the evaporative media is properly adjusted when first starting the water flow in the evaporative cooler. Increasing
the flow using the water adjustment valve makes this adjustment. Proper water adjustment should leave the evaporative media saturated with water, but not
flooded.
Evaporative media should appear wet.
When turning the evaporative cooler off at the end of the day or week, the pump should be turned off about 15 minutes before the fan to allow the Kuul evaporative
media to dry.
STARTING THE PUMP AND ADJUSTING THE WATER FLOW
Start the fan by turning the fan switch to the desired speed on the control panel. Before starting, make sure casters in locked position.
The user interface includes touch sensitive buttons for operation of the AWC360900. The user interface also includes status indicator LEDs and a 7-segment
display status of the evaporative cooler.
1. Power
The green Power LED is illuminated when the evaporative cooler is plugged in.
2. Water level
The red water level is illuminated when the float switch detects a low water level and the pump is not turning on. This LED flashes if the pump is running during
a low water occurrence to indicate that more water needs to be added in order to continue running the pump.
3. Timer
The controller features five pre-programmed modes which control the fan/pump sequence for a pre-defined period. Each touch of the program button cycles through
the five modes; 1HR, 2HR, 4HR, 8HR, and TIMER OFF. During the program run, the user can adjust the maximum fan speed with the up/down buttons. When the
program is active, the Timer LED will be on and, for five seconds, the user will be shown which program (1H,2H,4H,OR 8H)is active.
4. Pump
Pess the pump button once to power on and again to power off. The green Pump LED is illuminated when the pump is enabled. The LED flashes slowly if continously
held and the timer is disabled.
STARTING THE CaOiOrL EVAPORATIVE COOLER
