Capetti Elettronica WineCapKey WSD12T-EX Series User manual

WSD12T-EXn
User Manual
Strain gauge and/or Load cell/Temperature

WSD12T-EXn
User Manual
PAGE 2/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
General warnings.
•The following information must be read and understood before proceeding with the installation, commissioning and maintenance of
the devices described in this document.
•ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger.
•ATTENTION! Explosion hazard. In case of batteries substitution, make sure that the type is compatible and complies with the
specifications indicated by the manufacturer.
•In case of batteries substitution, DO NOT disconnect the flat cable which connect the electronic boards without removing batteries
before
•ALWAYS substitute all the batteries, also in case of one single battery exhausted.
•If the device is powered by a fixed network, make sure you have disconnected the power supply before carrying out any type of
intervention. Failure to comply with this indication can cause damage to people and/or property.
•Follow the manufacturer's suggested warm-up time ( time required to obtain a reliable measurement ) of the transducer.
•Follow the manufacturer's suggested electric wiring of the transducer to measure ( ground shields at a single point, cable length and
section ); voltage measures on distances exceed 15/20 meters are subjected to electromagnetic disturbances. 0÷25mA inputs have a
f ( EMC ).
•Avoid passage in cavities with power or high voltage cables.
•The protection and safety measures and the warranty provided by the Manufacturer with the equipment may be compromised if it’s
used in a manner that does not comply with this user manual.
•This equipment complies with CE regulations.
•Modifications or tampering not expressly approved by the Manufacturer could void the user's authorization to operate the equipment.
•This equipment must be installed by qualified personnel and in accordance with national regulations and/or related local requirements.
•Make sure that the object is properly fixed to supports/infrastructures capable of withstanding this load. Make sure proper methods
and materials are used when fixing the equipment to a wall.
•Only personnel expressly authorized by the manufacturer can open the container. There are no user serviceable parts inside.

WSD12T-EXn
User Manual
PAGE 3/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
1. Description.
The WSD12T-EXn is a datalogger with 4 input channels to acquire, strain gauges/load cells inputs and outdoor temperature value, with storage
functionality of samples acquired.
2. Order code nomenclature.
WSD12T-EX1
•1 CH temperature
•120Ω–4,950µV/V - ½ bridge 3 CH full scale strain gauge - 2.5µV/V resolution
WSD12T-EX2
•1 CH temperature
•120Ω–4,950µV/V - ¼ bridge 3 CH full scale strain gauge - 2.5µV/V resolution
WSD12T-EX3
•1 CH temperature
•350Ω–4,950µV/V - ½ bridge 3 CH full scale strain gauge - 2.5µV/V resolution
WSD12T-EX4
•1 CH temperature
•350Ω–4,950µV/V - ¼ bridge 3 CH full scale strain gauge - 2.5µV/V resolution
WSD12T-EX5
•1 CH temperature
•4,950µV/V - full bridge 3 CH full scale strain gauge or load cell - 2.5µV/V
resolution
WSD12T-EX6
•1 CH temperature
•2,480µV/V - full bridge 3 CH full scale strain gauge or load cell - 1.2µV/V
resolution
Picture 1 - Product image

WSD12T-EXn
User Manual
PAGE 4/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
3. Device pre-set and use mode.
a. Wireless Mode:
In this use mode, the datalogger records and transmits each measure sampled to the linked gateway. Typically, the monitoring system is
configured in factory, so, if the device is already associated to the system gateway is in STANDBY mode ( refer to Picture 4 - Status table –
Wireless mode ). In this case, it is necessary to start it with the TEST command ( refer to Picture 3 –Wireless devices user interface ). After this
operation, the datalogger reactivates, resumes measure activity, and performs the connection to the gateway or to a repeater WR12.
Connection The onboard LED shows the radio signal quality for 2 minutes ( refer to Picture 4 - Status table –Wireless mode ).
Otherwise, in case the device is in FACTORY RESET mode ( refer to refer to Picture 4 - Status table –Wireless mode ), that means it's ready
for connecting to an existing system, in order to associate it using the ENROL command, Refer to the “WineCap System - User Manual R30”
software manual. It is necessary to use the WineCapManager software on the PC connected to the gateway that will be linked with the
device.
b. USB Logger Mode:
For this operation mode, the dataloggers works in stand-alone, recording data in its internal memory and without any wireless connection.
This is not the factory setup so, to select it, the connection with the PC and the WineCapManager running on it is necessary to modify the
device 's operation mode. The device must be set in STAND-ALONE (refer to 7 - Stand-alone USB datalogger installation.) mode and the
sample time must be configured; automatically, the device 's clock is aligned with the PC's clock, in order to assure the temporal reference
of the sample.
Sampling operations start may be selected disconnecting the USB cable or giving the proper command with the magnetic key ( refer to 7 -
Stand-alone USB datalogger installation. ). More details on device 's connection/disconnection through the USB cable are available on the
WineCap System - User Manual R30 manual.
c. On field transition from USB to Wireless datalogger:
This transition is practicable in field, during the sampling period, using the wireless network association command. When the association is
done, the datalogger becomes a wireless datalogger and, besides sending new measures to the gateway, starts a download process towards
the same gateway of the measures acquired during the stand-alone period ( refer to Picture 5 - Status table - ).
4. Wireless device user interface.
The user interface consists of a “virtual” button that can be activated using the WineCapKey and of a two-colours led.
To give a command, user must approach the WineCapKey to the device’s sensible area and keep it in that position.; the following picture
( Picture 2 - WineCapKey positioning ) shows device’s sensible points.
LED
WineCapKey
Picture 2 - WineCapKey positioning

WSD12T-EXn
User Manual
PAGE 5/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
The following COMMAND table describes the available commands:
WIRELESS DEVICES USER INTERFACE
Flash count
Command
Description
1 flash
STATUS
Shows the device STATUS. As answer the led perform a flash sequence as
reported in the STATUS table. If the device is performing the TEST ( refer to
TEST command ) this command stops it.
2 flashes
TEST
Enter in TEST mode and transmits status and measurements every 5 seconds.
If the device is in STANDBY mode or it is out of radio range, this command
forces the connection procedure to the WSN and the return to the operative
mode. The TEST stops after 120 seconds. During TEST, the led continuously
shows the STATUS to monitor the received radio signal quality.
CAUTION: Measures acquired during TEST phase are NOT saved.
3 flashes
ENROL
Association to the network: must be used when the device has not yet been
included in a network, starts the entry and association procedure to the
gateway ( refer to “WineCap System - User Manual R30” ).
4 flashes
+ 4 flashes
STANDBY
Temporary device deactivation: the device is stopped. The sampling process
and the radio are/is. turned off losing the connection to the network. To
reactivate, a TEST command is necessary. The STANDBY command must be
given twice to confirm it: at the first sequence the led flashes alternating RED
and GREEN lights, waiting for the second confirm sequence within 15
seconds. At the command execution the led flashes as the STANDBY status
( refer to “Picture 4 - Status table –Wireless mode” ).
5 flashes
+ 5 flashes
FACTORY RESET
The device performs the memory deleting procedure and goes in STOP
status. All samples, configuration and wireless network data associated are
LOST. To reactivate the device a new association and configuration
procedure is necessary ( ENROL command ). Also in this case, the FACTORY
RESET command must be given twice to confirm it. At the command
execution the led flashes as the “PROBE/DATALOGGER NOT ASSOCIATED”
status ( refer to “Picture 4 - Status table –Wireless mode” ).
5 flashes
+ 3 flashes
LOGGER
NO WSN
As the previous command but performs only the WSN deleting procedure
and disassociate from the gateway. The device enters in LOGGER STAND
ALONE mode: data are kept, and the sampling activity CONTINUES with
previous setup. Command must be given with 2 sequences: 5 flashes and
then 3 flashes. At the command execution wait for the device reboot. At the
STATUS command, “LOGGER” will be the answer ( refer to “Picture 5 - Status
table - Stand-alone mode” ). A new association ( ENROL command ) is
possible to a new gateway.
Picture 3 –Wireless devices user interface
5. Device enrolment.
Not necessary if performed in factory before delivery.
Enrol the device to the wireless network referring to the “WineCap System - User Manual R30” . In case the device is already enrolled but in
STANDBY status, a TEST command must be issued (refer to Picture 3 – ) .
6. Installation procedure.
After installing the gateway in appropriate place in charge, ( refer to “WineCap System - User Manual R30 ”), be sure that the device is enrolled
to the gateway and activated.
Head for the installation point. On the way, to check the quality of the radio coverage, use the "Field Measurer" function.
This function is activated issuing the TEST (refer to Picture 3 –) command: position the WineCapKey in the spot indicated in Picture 2 -
WineCapKey positioning and wait for two AMBER flashes, then remove the WineCapKey from device. The "Field Measurer" function lasts
enabled for two minutes.
To issue commands to the device, place the WineCapKey where indicated.
Once the WineCapKey , is detected, the led periodically emits AMBER flashes with a 2 second cadence.

WSD12T-EXn
User Manual
PAGE 6/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
For each flash, a different command is associated; to confirm the command the WineCapKey must be removed from the sensible area
immediately after the number of flashes corresponding at the desired command. The TEST corresponds to the second pulse and activate the
"Field Measurer" function.
The device will give back the radio signal quality through led flashes:
WIRELESS MODE STATUS Table
FLASH COUNT –WIRELESS MODE
STATUS/RADIO SIGNAL QUALITY
5 green flashes
ACTIVE - Radio signal: Excellent
4 green flashes
ACTIVE - Radio signal: Good
3 green flashes
ACTIVE - Radio signal: Fair
2 amber flashes
ACTIVE - Radio signal: Sufficient
1 red flash
ACTIVE - Radio signal: Insufficient
1 red flash 2” long
OUT OF RANGE
Network searching
2 red flashes 2” long
STANDBY
Radio off - No Logging
Short-long-short red
flashes series
FACTORY RESET
Device not enrolled –No logging
Picture 4 - Status table –Wireless mode
Optimize reception selecting the best position: small movements can help.
If the signal is absent or insufficient at the install point, a repeater WR12 should be put between ( refer to “WineCap System - User Manual
R30 ”). The repeater WR12 itself must be in a position where the signal level is at least sufficient.
The network will reconfigure itself automatically; the signal will be good again when the device synchronizes with the repeater WR12 .
The wireless communication will not be reconfigured until completely lost by the device. Because of this, in some cases it could be necessary
to force the operation. In such cases, put the device in STANDBY mode, then run the TEST again ( refer to “WineCap System - User Manual
R30 ”).
NOTE: The display equipped datalogger (WD04T) is recommended, to verify the signal quality during devices installation.
7. Stand-alone USB datalogger installation.
Install the datalogger in appropriate place.
If the sampling process has not yet been activated, you can start it through the WineCapKey .
Bring it closer to the sensitive point, wait for 2 flashes ( TEST ) (refer to Picture 3 –) and remove. The datalogger begins sampling according to
your settings through your PC.
Through the WineCapKey is possible to ask for the status, bring it close to the datalogger for 1 flash ( STATUS ) and remove it.
STAND-ALONE DEVICE - STATUS TABLE Table
FLASH COUNT –STAND ALONE MODE
STATUS
1 green flash 2 seconds long
ACTIVE
2 red flashes 2 seconds long
STANDBY
Sequence of red flashes: short,
2 seconds long, short
FACTORY RESET
INVALID datalogger clock!
PC connection required.
Picture 5 - Status table - Stand-alone mode

WSD12T-EXn
User Manual
PAGE 7/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
8. Shutting off/Reactivating the device.
If the device is shut off and left unused for a long time, you can issue the STANDBY command (refer to Picture 3 –) . It corresponds to the
command number 4 and must be issued twice to confirm the operation.
Position the WineCapKey in the spot indicated in ( Picture 2 - WineCapKey positioning ), and wait for four AMBER flashes, then remove the
WineCapKey from device. Verify that the device asks for confirmation of STANDBY command with alternate GREEN/RED flashing, then position
again the WineCapKey and wait for four flashes again. The device will confirm the STANDBY status lighting the RED led for 2 seconds twice. To
reactivate the device the TEST command must be issued.

WSD12T-EXn
User Manual
PAGE 8/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
9. Transducer’s connection layout.
Picture 6 - Connections layout
¼ bridge - two wires strain gauge connection.
¼ bridge - three wires strain gauge connection.
½ bridge dual strain gauge connection (advised for strain gauge connection as temperature compensation).
Full bridge strain gauge connection.
CHANNEL 4
CHANNEL 3
CHANNEL 2
CHANNEL 4
CHANNEL 3
CHANNEL 2
CHANNEL 4
CHANNEL 3
CHANNEL 2
CHANNEL 4
CHANNEL 3
CHANNEL 2

WSD12T-EXn
User Manual
PAGE 9/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
10. Technical Information.
Power supply
8.5Ah - 3.6V type “C” lithium internal battery ( BAT2 )
Battery life (*)
Up to 10years
(samples every 60 minutes and radio signal quality at least
sufficient)
Measures acquired (4 input channels)
•Temperature
•Strain gauge/Load cells
Sampling interval (*)
Selectable from one minute to 24 hours (60 minutes default)
Datalogger capacity
64,000 samples ( for each channel )
Working temperature
•Operative: -30°C÷+60°C
•Warehousing: -40°C÷+70°C
Radio frequency
ISM 868MHz
Radio coverage
Up to 6Km in line of sight
(can be extended using WR12 battery powered repeaters)
Sealing
IP65
Dimensions
90x120x50mm
Weight
350g
Case material
ABS
Mounting
Fix on 4 points
Connections
Wireless, USB
Cable external diameter
4.7mm maximum
Copper wire section
0.05÷2.5mm² / ÷ 14 AWG
Strain Gauges/Load Cells - Channels
3
Strain Gauges/Load Cells - Bridge input type
full bridge, ½ bridge, ¼ bridge (to be defined during order)
Strain Gauges/Load Cells - Bridge impedance
120Ω or 350Ω (to be defined during order)
Outdoor temperature - Transducer type
NTC10KΩ
Outdoor temperature - Measure range
-30°C÷+60°C
Outdoor temperature - Measure accuracy
•±0.5°C Range -30°C÷0°C
•±0.2°C Range 0°C÷+60°C
Outdoor temperature - Measure resolution
0.01°C
* battery life may be influenced by fieldwork conditions, sampling/measuring interval and system configuration.
** radio coverage can be extended using up to 32 WR12 repeaters (maximum 16 for each path) between the device and the gateway.

WSD12T-EXn
User Manual
PAGE 10/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
11. Mechanical dimensions.
Picture 7 - Mechanical dimensions
12. Disclaimer.
•Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica
S.r.l.
•Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica
S.r.l. will be liable for incidental or consequential damages resulting from the use of this document or the systems described in this
document.
•All Contents published or distributed by Capetti Elettronica S.r.l. are made available for general information purposes.
•It is not permitted to publish or use, in whole or in part, such contents for commercial purposes without the explicit written consent
of Capetti Elettronica S.r.l.
•The reproduction, duplication, modification, sale or resale of this material or part of it is not permitted without the explicit written
consent of Capetti Elettronica S.r.l.

WSD12T-EXn
User Manual
PAGE 11/11
WA0136_WSD12T-EXn_User Manual_R12 V6.1
www.capetti.it
13. Reference standards.
EN 61010 -1
For electromagnetic compatibility
EN 61000 - 3 - 2
EN 61000 - 3 - 3
EN 300 220 -2
EN 301 489 - 03
EN 61000 - 6 -1
This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts
the use of substances in the manufacturing of electronic devices.
The “WEEE” logo on the label indicates that this product is compliant with the "WEEE" EC Directive. This
symbol (valid only in the European Union countries) indicates that the product it is applied to, MUST
NOT be discarded with ordinary household or industrial waste, but must be sent to an authorized
reception point. The end user should contact the device provider, either the manufacturer or the reseller,
to agree a collection and disposal process, after having checked the terms and conditions of sale.
IT1902000001116
1
