Technical information

Ceramic Hob
7
C806C

Spare part list
Page 1
Model :
No. Parts code Parts names QTY Series No.
1 301500101374 Screw 12
541400000007 base cover 1 1220 0001 - 1220 0250
541410000005 base cover 1 From：1225 0001
3 541400200002 spring bracket 12
4 303203501144 single loop hob(200mm) 2
5 541400400002 Fixer for burner 12
6 303203501145 single loop hob(165mm) 2
7 G-C806C glass assembly 1
8 541300300007 Knob 4
9 303207103098 silicone ring 4
10 303207900037 silicone sealed strip 1
11 303202804183 adiabatic cotton 1 1220 0001 - 1220 0250
12 303207400068 adiabatic bracket 1
13 541600300002 Energy adjuster 4
14 303207800272 knob bracket 1
15 541600300001 Pilot lamp assembly 1
16 303207300267 Knob base 1
17 301500101200 screw assembly 1
18 303207300159 junction box 1
19 541800000021 Power cord 1
2
C806C

Exploded view
Page 2
(7)
19
16
17
18
Model : C806C

Exploded view
Step1：
remove the screw A around the base cover
Step2：
remove the wires
Step 3：
open the bracket and remove the heating element
Step 4：
remove the light cover
Step 5：
to remove the knob base,reverse the base and
remove the screws
Step 6：
to remove the Energy adjuster ,reverse the base and
remove the screws
1
32
4
screw A
screw A
screw A
screw A
Page 3
Model : C806C

1. Remove the screw A.
2. Push the top plate back and then lift it up.
3. Remove the 2 screws B.
4. Remove the 4 screws C in the terminal box and
insert the power cord at the connection.
screw A
screw B
screw C
5. Assemble the cable clamp, be aware that
the ellipse hole on cable clamp must match
the ellipse hole on.
6. Fix the top plate.
Technical data
Page 4

Technical data
Page 7
