CapstanAG SwathPRO User manual

TM
320700-005 Rev. H | Revised 08/2023 | ©2023 Capstan Ag Systems, Inc.
SwathPRO™
For AirTractor
Instructions for
Continued Airworthiness

ii 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.
This page intentionally left blank

2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 iii
Introduction
Revisions and Amendments
All ICA changes will be submitted to the FAA for review and acceptance by the Aircraft Certication O󰀩ce
and the Aircraft Evaluation Group prior to issuance to the eld. Revisions to this ICA may not be distributed
without prior FAA acceptance. Once an ICA revision is accepted by the FAA, it shall be distributed to all
registered owners by either U.S. mail, internet, or email at the election of the STC holder. For questions or
assistance regarding these Instructions for Continued Airworthiness, contact:
Capstan Ag Systems, Inc.
4225 SW Kirklawn Ave.
Topeka, KS 66609
Toll-free number: [phone] | Fax: [phone]
CapstanAG.com | CapstanAG.ca
[email protected]
Change Log
Revision Pages Description Date
A All Initial Release of the Instructions for Continued Airworthiness of the
SwathPRO™ system
11/15/2021
B 37–44 Clarication and additions to Section 6: System Operation in accordance
with FAA STC direction 6/21/2022
C 75–96 Clarications and addition of Wiring Schematics into Section 8:
Schematics. Fixed part number error in Power and Sensors Schematic 7/22/2022
D 77 Addition of Ag-Nav Servo/Control Valve Harness 10/22/2022
E 80–81 Removed part number 320015-096 and x shuto󰀨 kit schematic 11/18/2022
F 36, 38, 75
80
Added procedure for inputting number of nozzles into CapView.
Updated Wiring Schematic
12/28/2022
G 80
83
Updated Wiring Schematic
Corrected verbiage in Table 9
3/3/2023
H 39
80
82
Main power note added
Updated wiring schematic
Removed Nav Spray Map information
8/22/2023

Change Log
iv 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.
This page intentionally left blank

2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 v
Introduction
Contents
References...................................................................................................................................................ix
AcronymList..................................................................................................................................................x
Section 1: Introduction.................................................................................................................11
This Manual................................................................................................................................................12
ApplicableAircraft Models...........................................................................................................................12
Modication for SwathPRO™......................................................................................................................13
Required and Special Tools.........................................................................................................................13
Section 2: Safety.................................................................................................................................15
Signal Words..............................................................................................................................................16
Emergency Safety.......................................................................................................................................16
Personal Protective Equipment...................................................................................................................16
Pressurized Fluid Lines...............................................................................................................................16
Chemical Safety..........................................................................................................................................16
Section 3: Warranty.........................................................................................................................17
Limited Warranty.........................................................................................................................................18
What does the Limited Warranty cover?...............................................................................................18
What is the period of coverage?...........................................................................................................19
How do you get service?.......................................................................................................................19
How does state law relate to this Limited Warranty?............................................................................19
Section 4:Airworthiness Limitations............................................................................21
Section 5: Installation....................................................................................................................23
Before Installation of the CapstanAG™ System..........................................................................................24
Install the SwathPRO™ Booms...................................................................................................................24
Post-install Checklist...................................................................................................................................25
System Dry Tests........................................................................................................................................25
Boom Dry Test......................................................................................................................................25
Key Fob Boom Dry Test.......................................................................................................................26
System Wet Test...................................................................................................................................................27
Key Fob Boom Wet Test.......................................................................................................................27
Remove the SwathPRO Booms..................................................................................................................29

Contents
vi 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.
Install Conventional (OEM) Booms..............................................................................................................30
Section 6: Operation.......................................................................................................................33
Start the CapView........................................................................................................................................34
Main Operation Screen................................................................................................................................35
Upload a Prole to the CapView..................................................................................................................36
Update Software.........................................................................................................................................37
Shut down the CapView..............................................................................................................................39
Forced Shutdown—Unresponsive CapView...............................................................................................40
CapView Will Not Turn On..........................................................................................................................41
Missing VCM Error on the CapView Display...............................................................................................42
Valves Not Operating Correctly...................................................................................................................43
Section7:Maintenance................................................................................................................45
Service the System.....................................................................................................................................46
Jump Start, Weld On, or Charge the Machine............................................................................................46
Winterize the SwathPRO™ System............................................................................................................46
Antifreeze in the Booms........................................................................................................................46
Dry out the Booms................................................................................................................................47
Recommended Guidelines for Maintenance/Service..................................................................................47
Access the SwathPRO System Components..............................................................................................48
MaintenanceServiceIntervals.....................................................................................................................49
Flush the System.........................................................................................................................................50
Baseline Evaluation Process.......................................................................................................................51
ExaminetheSystem....................................................................................................................................51
Examine Specic System Components.......................................................................................................52
Examine the Harnesses........................................................................................................................52
NozzleValves........................................................................................................................................58
Examine the CapView and Harnesses..................................................................................................62
Examine the Gateway Hub...................................................................................................................65
Examine the Power Supply...................................................................................................................65
Replacing the GPS Receiver.......................................................................................................................68
Strainers and Screens.................................................................................................................................69
Replacing the Pressure Sensor...................................................................................................................70
FactoryResetProcedure.............................................................................................................................72
Location Setup Procedure...........................................................................................................................73
Input Total Number of Valves.......................................................................................................................75

2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 vii
Introduction
Section 8: Schematics..................................................................................................................77
System Layout............................................................................................................................................78
Power and Sensors Schematic...................................................................................................................80
Controls Schematic.....................................................................................................................................81
Boom Shut-o󰀨 Kit Schematic......................................................................................................................82
Nozzle Type and Component Identication.................................................................................................84
ValveAssemblyComponents................................................................................................................84
Center ValveAssembly Components....................................................................................................85
Gateway Hub Identication..........................................................................................................................86
Gateway Hub Connector Pin Identication...........................................................................................87
PressureSensorHarness............................................................................................................................89
Gateway Boom Control Extension Harness................................................................................................90
CapView Display Harness...........................................................................................................................91
Boom Control Harness................................................................................................................................92
SWATHPRO MAIN Circuit Breaker Switch..................................................................................................92
VCM Assemblies.........................................................................................................................................93
Center VCM HarnessAssembly............................................................................................................93
VCMHarnessAssembly........................................................................................................................94
Shut-o󰀨 Harness Assembly..........................................................................................................................95
GPS-HubAdapterHarness..........................................................................................................................96
GPS Receiver.............................................................................................................................................97
Section 9: Troubleshooting.....................................................................................................99
Troubleshooting Charts.............................................................................................................................100
Interchange Components..........................................................................................................................102
Fuses........................................................................................................................................................102
Coil Assembly Test....................................................................................................................................103
CapView Battery Voltage Test..................................................................................................................104
System Load Capacity Test......................................................................................................................105
VCM Voltage Test.....................................................................................................................................106
Pressure Sensor Signal Test....................................................................................................................107
Index............................................................................................................................................................109

Contents
viii 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.
This page intentionally left blank

2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 ix
Introduction
Title Part Number Description
Pilot’s Operating Handbook and FAA Approved
Airplane Flight Manual for SwathPRO™
320700-001 System operation information
SwathPRO™ Installation Manual 320700-007 System installation information
ProMaker User Guide 320700-002 Computer software manual to
make proles
Acceptable Methods, Techniques, and Practices
- Aircraft Inspection and Repair AC 43.13-1B Aircraft inspection and repair information
CapstanAg
Part Number Description AN Part Number Torque Specication
713600-012 Washer, Mil-Spec, 1/4, Cad Plated AN960C416L
713600-010 Washer, Mil-Spec, 5/16, Cad Plated AN960-516L
713501-527 Nut, Hex, Nylok, 5/16-24, Cad Plated AN365-524A 100-140 in/lbs
713501-526 Nut, Stop, Hex, Thin, 6-32, Cad Plated AN364-632A 11-13 in/lbs
713501-525 Nut, Stop, Hex, Thin, 1/4-28, Cad Plated AN364-428A 30-40 in/lbs
713501-419 Bolt, Mil-Spec 5/16-24 x 31/32, Cad Plated AN5-7A
713501-454 Bolt, Hex 10-32 x 21/32 Cad Plated AN3-5A
713501-531 Nut, Hex Elastic Stop, 10-32 Cad Plated AN365-1032A 20-25 in/lbs
713600-013 Washer, Flat, #10 Cad Plated AN960-10
713501-427 Bolt, Hex 3/8-24 x 31/32 Cad Plated AN6-7A
713501-521 Nut, Hex Elastic Stop, 3/8-24 Cad Plated AN365-624A 160-190 in/lbs
713501-014 Washer, Flat, 3/8 Cad Plated AN960-616L
713501-428 Screw, 4-40 x ¾” Cad Plated MS35206-219
713501-522 Nut, 4-40, thin, Cad Plated AN364-440A 3-4 in/lbs
713600-015 Washer, 4-40, Cad Plated AN960-4L
713501-417 Screw, 1/4-28 x 5/8" Cad Plated MS35207-280
The published torque values do not include the rotational drag of the elastic stop nuts (AN365). Standard
maintenance practice dictates that mechanics add this value to the specied torque. A random sample of new
and used AN365-4, and -5 nuts shows that the torque required to turn AN4 (1/4”) nuts varied between 15-19
in/lbs. The torque required onAN5 (5/16”) nuts varied between 18-22 in/lbs. This value must be added to the
torque value.
References
Table 1: Reference List
Table 2: AN Part Numbers and Toque Specications

References
x 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.
Acronym List
Acronym Description
FAA Federal Aviation Administration
OEM Original Equipment Manufacturer
VCM Valve Control Module
SDS Safety Data Sheet
PPE Personal Protective Equipment
DTM Deutsch Mini
DT Deutsch
RMA Return Merchandise Authorization
PWM Pulse Width Modulation
LED Light Emitting Diode
CAN Controller Area Network
CB Circuit Breaker

2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 11
Introduction
Section 1: Introduction
Topics:
• This Manual
• Applicable Aircraft Models
• Modication for SwathPRO
• Required and Special Tools

This Manual
Important: This document must be placed into the aircraft operator’s Aircraft Maintenance Manual and
incorporated into the aircraft’s scheduled maintenance program.
For any case in which the instructions in this document and the Aircraft Maintenance Manual are in conict,
the most restrictive instructions take precedence.
This manual includes maintenance and re-installation information for the SwathPRO™ system you
purchased.
Make sure that all personnel has read this manual other referenced manual(s) and thoroughly understand the
safe and correct operation, maintenance, and re-installation procedures.
The right and left sides of the system are determined by facing the direction of forward travel of the aircraft on
which the system is installed.
This manual contains important information on how to safely and correctly reinstall, operate, and maintain
the SwathPRO™ system. These instructions help keep personnel safe, reduce downtime, and increase the
reliability and life of the equipment, its components, and related systems.
Review the safety information in the manual(s) listed in the reference section of this manual. For more
information, go to References.
Follow the instructions (in this manual) and in the other referenced manual(s) for each step to make sure that
work conditions in and around the aircraft are safe.
It is important for all individuals working with chemicals to understand the potential risks, necessary safety
precautions, and proper response in the event of accidental contact. Reference the specic chemical manuals
for safety information.
Read, understand, and review the procedures in this manual and other referenced documents. Use the Safety
Data Sheets (SDS) and the required Personal Protective Equipment (PPE) for hazardous chemicals.
If you do not understand the SwathPRO™ system after reading this manual and referenced documentation,
please obtain the proper training before operating, servicing, or reinstalling the system. Proper training is
important for your own safety, as well as your co-workers’ safety, is maintained.
Applicable Aircraft Models
Refer to the STC AML for applicable aircraft models.
Introduction
12 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.

Modication for SwathPRO™
The SwathPRO™ system removes and replaces the factory spray booms.
The system added electronically controlled spray valves to control spray patterns.
The CapView display in the aircraft cockpit lets the pilot upload custom spray patterns and save preset
pattern proles for selection in-ight.
Spray on/o󰀨 is controlled by the use of the existing spray handle (with no changes) or rate controller, as
applicable.
The SwathPRO™ system is compatible with aftermarket rate controllers and spray nozzles.
Required and Special Tools
2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 13
Introduction
Tool Description Where Used
Torque wrench Install the SwathPRO™ Booms
5 psi water line and a camlock tting on the
end of each boom Key Fob Boom Wet Test Flush the System
Voltmeter Coil Assembly Test
CapView Battery Voltage Test
System Load Capacity Test
VCM Voltage Test
Pressure Sensor Signal Test

Introduction
14 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.
This page intentionally left blank

Safety
2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 15
Section 2: Safety
Topics:
• Signal Words
• Emergency Safety
• Personal Protective Equipment
• Pressurized Fluid Lines
• Chemical Safety

Signal Words
DANGER: Indicates an imminent hazard which, if not avoided, will result in death or serious injury.
This signal word is limited to the most extreme situations, typically for aircraft components that, for
functional purposes, cannot be guarded.
WARNING:Indicates a potential hazard which, if not avoided, could result in death or serious injury,
and includes hazards that are exposed when guards are removed. It may also be used to alert
against unsafe practices.
CAUTION: Indicates a potential hazard which, if not avoided, may result in minor or moderate injury.
It may also be used to alert against unsafe practices.
IMPORTANT: This is used to draw attention to specic information that is necessary for the operation, setup,
or service of the system.
Note: This is used for additional information that can help understand or operate the system.
Emergency Safety
Fire extinguishing systems must meet the applicable OSHA requirements, and all users of portable/ xed
re suppression equipment must know the types, limitations, and proper uses of this equipment; including
hazards involved with incipient stage reghting.
Keep emergency numbers for doctors, ambulance service, hospital, and re department near your telephone.
Know the location of re extinguishers and rst aid kits and how to use them.
Examine the re extinguisher and service the re extinguisher regularly.
Follow the recommendations on the instructions plate.
Very small res can be put out (extinguished) with a re extinguisher. Use an appropriate method to
extinguish a re (water for paper res, and chemical extinguishers for electrical or chemical res).
Personal Protective Equipment
Wear close-tting clothing and the correct personal protective equipment (PPE) for the job. Refer to the
specic chemical manufacturer documentation or other information for correct PPE.
Pressurized Fluid Lines
Do not heat by welding, soldering, or using a torch near pressurized uid lines or other ammable materials.
Pressurized lines can accidentally burst when too much heat is present.
Chemical Safety
Chemicals used in agricultural applications can be harmful to your health and/or the environment if not used
correctly. Always follow all label directions for e󰀨ective, safe, and legal use of agricultural chemicals.
Safety
16 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.

2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 17
Warranty
Section 3: Warranty
Topics:
• Limited Warranty

Limited Warranty
What does the Limited Warranty cover?
The ultimate purchaser/user (“you”), by acceptance of seller Capstan Ag Systems, Inc.’s, (“our,” “we,” or “us”)
product, assume all risk and liability of the consequences of any use or misuse by you, your employees, or
others.
All replacement components furnished under this warranty, but shipped before the failed component is
returned for evaluation, will be invoiced in the usual manner and warranty adjustments will be made after the
component claimed to be defective has been returned to and inspected and deemed defective by us at our
factory.
Upon determining that a component has failed under warranty, the repaired component or replacement
component, furnished under this warranty, will be shipped at our expense, to your location. We will credit you
an amount equal to the incoming freight you paid. We shall not be responsible for installation costs. (You shall
be responsible for all customs and brokerage fees for all international transactions.)
If the component does not prove to be defective, you shall be liable for all freight, inspection, and handling
costs. In no event will any claim for labor or incidental or consequential damages be allowed for removing or
replacing a defective product. Warranty will be denied on any component which has been subject to misuse,
abuse, accidents, or alterations, or to improper or negligent use, maintenance, storage, transportation, and
handling.
Our liability under this warranty, or for any loss or damage to the components whether the claim is based on
contract or negligence, shall not, in any case, exceed the purchase price of the components and upon the
expiration of the warranty period all such liability shall terminate. The foregoing shall constitute your exclusive
remedy and our exclusive liability.
The terms of this warranty do not in any way extend to any product which was not manufactured by us or
one of our a󰀩liates. While necessary maintenance or repairs on your CapstanAG product can be performed
by any company, we recommend that you use only authorized CapstanAG dealers. Improper or incorrectly
performed maintenance or repair voids this warranty.
The foregoing warranty is exclusive and is in lieu of all other warranties expressed or implied. We shall not be
liable for any incidental or consequential damages resulting from any breach of warranty.
Your exclusive remedy for breach of warranty shall be repair or replacement of defective component(s):
Provided, if the component(s) are incapable of being repaired or replaced, your exclusive remedy shall be
credit issued, but such credit shall not exceed the purchase price of the components.
On any claim of any kind, including negligence, our liability for any loss or damage arising out of, or from the
design, manufacture, sale, delivery, resale, installation, technical direction of installation, inspection, repair,
operation of use of any products shall in no case exceed the purchase price allocable to the components.
In no event, whether as a result of breach of contract or warranty or alleged negligence, shall we be liable for
incidental or consequential damages, including, but not limited to: personal injury, loss of prots or revenue,
loss of use of equipment or any associated equipment, cost of capital, cost of substitute equipment, facilities
or services, downtime costs, environmental damage, crop losses, or claims of customers of you for such
damages.
Warranty
18 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.

What is the period of coverage?
We warrant to you that our products are free from defects in material and workmanship in normal use and
service for a period of one year from date of purchase.
How do you get service?
Our obligation under this warranty shall be limited to the repairing or replacing at our option, the component
which our inspection discloses to be defective, free of charge, return freight paid by us, provided you: (i)
Notify us of defect within thirty (30) days of failure; (ii) Return the defective component to us, freight prepaid;
(iii) Complete the Owner Registration Form and returned it to us; and (iv) Establish that the product has been
properly installed, maintained and operated in accordance with our instructions or instructions contained in
our operations or maintenance manuals and within the limits of normal usage.
Any claim for breach of our warranty must be in writing addressed to us and must set forth the alleged defect
in su󰀩cient detail to permit its easy identication by us. All breach of warranty claims must be made within
thirty (30) days after expiration of the warranty period, which is applicable to the defective product. Any
breach of warranty claim not timely made will not be honored by us and will be of no force and e󰀨ect. Any
component that needs to be repaired or evaluated for warranty has to be authorized before return. Contact
the factory (785-232-4477) to get a Return Materials Authorization (RMA #). This helps to track the part
coming into the factory for repair or replacement.
Before returning any component to the factory, clean the component as well as possible to remove any dirt or
chemical residue. Components received at the factory that are not clean will be returned and warranty denied.
After receiving your RMA #, package the part, making sure to include the RMA #, customer’s name, your
address and phone number and description of problems or failure. If the component(s) are not returned to the
shipping address below within the thirty (30) day period, no credit will be issued for the part. Ship to:
Capstan Ag Systems, Inc.
Attn: Warranty/Repair
4225 SW Kirklawn Ave.
Topeka, KS 66609
Phone: [phone] | Fax: [phone]
Hours: 8 am to 4:30 pm CST
Once the package is received by us, we have thirty (30) days to process the warranty claim. If the warranty
claim is still open after thirty (30) days, the warranty will be accepted, and credit issued to.
How does state law relate to this Limited Warranty?
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not
apply to you.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to
state.1
1 Rev. Date 06/21/2022
2023 Capstan Ag Systems, Inc. 320700-005, Rev. H 08/23/23 19
Warranty

20 08/23/23 320700-005, Rev. H 2023 Capstan Ag Systems, Inc.
This page intentionally left blank
Warranty
