Carcomm CRFC-687 User manual

Installation Guide
8/12 or 10/15-Slot Desktop Charger
www.carcomm.eu © 2018 CarComm International BV Manual : P14100096 V1
8/12 or 10/15-Slot Desktop Charger Installation Guide
CarComm reserves the right to make changes to any product to improve reliability,
function, or design. CarComm does not assume any product liability arising out of,
or in connection with, the application or use of any product, circuit, or application
described herein. No license is granted, either expressly or by implication, estoppel,
or otherwise under any patent right or patent, covering or relating to any combination,
system, apparatus, machine, material, method, or process in which CarComm
products might be used. An implied license exists only for equipment, circuits,
and subsystems contained in CarComm products.
Introduction
The 8/12 or 10/15-Slot Desktop Charger Base provides power for charging up to 8,10,12 or 15 devices
depending on the model. The charging cradles hold the hand held devices and can be easily
mounted or removed of the base, by disconnecting the power cables placed in the front
of the base and clipping of the cradles.
Regulatory Information
This guide applies to the CarComm 8/12 and 10/12-Slot Desktop Chargers product range.
All CarComm devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required.
Any changes or modifications to CarComm equipment, not expressly approved by CarComm could void the
user’s authority to operate the equipment. Declared maximum operating temperature: 40 °C.
Power Supply
Use of alternative power supply will invalidate any approvals given to this unit and may be dangerous.
CE Marking and European Economic Area (EEA)
Statement of Compliance
CarComm hereby declares that this device is in compliance with all the applicable Directives, 2004/108/EC, 2006/95/EC and 2011/65/EU. A Declaration of Conformity may be obtained from
http://www.carcomm.eu/contact/.
Waste Electrical and Electronic Equipment (WEEE)
English: For EU Customers: All products at the end of their life must be returned to CarComm for recycling. For information on how to return product,
please go to: http://www.carcomm.eu/contact/.
Français: Clients de l'Union Européenne: Tous les produits en fin de cycle de vie doivent être retournés à CarComm pour recyclage. Pour de plus amples informations sur le retour de produits,
consultez : http://www.carcomm.eu/contact/.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen am Ende ihrer Lebensdauer zum Recycling an CarComm zurückgesandt werden. Informationen zur Rücksendung von Produkten
finden Sie unter http://www.carcomm.eu/contact/.
Nederlands: Voor klanten in de EU: alle producten dienen aan het einde van hun levensduur naar CarComm te worden teruggezonden voor recycling.
Raadpleeg http://www.carcomm.eu/contact/ voor meer informatie over het terugzenden van producten.
Warranty
For the complete CarComm hardware product warranty statement,
go to: http://www.carcomm.eu/warranty
Service Information
If you have a problem using the equipment, contact your facility’s Technical or Systems Support.
If there is a problem with the equipment, they will contact the Global Customer Support Center at:
http://www.carcomm.eu/contact/support/

www.carcomm.eu Manual : P14100096 V1
Connecting power:
Inserting and removing a device:
Specifications:
Eingangsleistung
Ausgangsleistung
Stromverbrauch
: 100-240V 50/60Hz, 1.2A Max.
: 2x 5.0V(8&10 Slot) / 3x 5.0V(12&15 Slot) 8000mA
: 100Watt (8&10 Slot) / 150Watt (12&15 Slot) Max.
~
Safety:
Read the manual carefully before use.
Keep the manual for future reference.
Only use the appliance and the accessories
for their intended purposes. Do not use the
appliance and the accessories for other
purposes than described in the manual.
Children should be supervised to ensure that
they do not play with the appliance.
Do not use the appliance if any part or any
accessory is damaged or defective. If a part
or an accessory is damaged or defective,
it must be replaced by the manufacturer
or an authorised repair agent.
Do not use the appliance near bathtubs,
showers, basins or other vessels containing
water.
Do not immerse or clean the appliance
in/with water or other liquids. If the appliance
is immersed in water or other liquids,
do not remove the appliance with your hands.
Immediately remove the mains plug from
the wall socket. If the appliance is immersed
in water or other liquids, do not use the
appliance again.
Before use, always check that the mains
voltage is the same as the voltage on the
rating plate of the appliance.
The appliance is not intended to be
operated by means of an external timer
or separate remote-control system.
Connect the appliance to an earthed
wall socket. If necessary, use an earthed
extension cable of a suitable diameter
(at least 3 x 1 mm2).
For additional protection, install a residual
current device (RCD) with a rated residual
operating current that does not exceed
30 mA.
Electrical safety
General safety
1. Make sure the power switch
on the back of the base is
switched off “0”.
2. A. Plug in the power cable on the back of the base.
B. Plug the power cable into the 230V power socket.
Turn on the power switch “1” (see step 1).
B
1 2
1. To insert a device, align the device with the cradle and
gently push the device into the cradle and onto the connector.
2. To remove a device from the cradle, gently pull the device till it
comes loose from the connector and slide the device out of the cradle.
A
Make sure that water cannot enter the
contact plugs of the mains cable and the
extension cable.
Always fully unwind the mains cable and
the extension cable.
Make sure that the mains cable does not
hang over the edge of a worktop and
cannot be caught accidentally or tripped
over.
Keep the mains cable away from heat,
oil and sharp edges.
Do not use the appliance if the mains
cable or the mains plug is damaged or
defective. If the mains cable or the mains
plug is damaged or defective, it must be
replaced by the manufacturer or an
authorised repair agent.
Do not pull the mains cable to disconnect
the mains plug from the mains.
Disconnect the mains plug from the mains
when the appliance is not in use for
prolonged periods of time, before
assembly or disassembly and before
cleaning and maintenance.
Always connect the desktop charger to an
electrical outlet which has a minimum
power rating of 16A.

Installation Guide
Rubber feet
www.carcomm.eu © 2019 CarComm International BV Manual : P14100096 V2
Required:
4x
4x
Installation:
Philips
