S ERVICE M ANUAL
ECLIPSE
THIS PUBLICATION COVERS THE FOLLOWING MODELS:
RV
Universal Eclipse
Eclipse XL
Universal Eclipse w/ Battery
Eclipse w/ Windsmart Electronics
Eclipse w/ Direct Response Electronics
The information contained in the
publication applies to all models listed.
Details and procedures unique to a
specific model are labeled appropriately.
TABLE OF CONTENTS
Product Overview..........................................................................................................................1
Canopy Replacement....................................................................................................................2
For Universal Eclipse..............................................................................................................................2
For Eclipse XL ........................................................................................................................................4
Installing the Tractioners.........................................................................................................................6
Motor Replacement.......................................................................................................................7
Replacing the Motor - Awning Extended ................................................................................................7
Replacing the Motor –Awning Closed.....................................................................................................9
Idler/Spring Replacement...........................................................................................................11
Replacing the Gas Shock ...........................................................................................................12
Replacing the Arm Rollers..........................................................................................................13
Diagnostics..................................................................................................................................14
Standard Electrical................................................................................................................................15
Auto Retract Systems...........................................................................................................................18
Common Test Procedures....................................................................................................................21
Wiring Diagram - Single Switch Prior to July 2010...............................................................................23
Wiring Diagram - Single Switch - July 2010 and on..............................................................................23
Wiring Diagram - Multiple Switch Prior to July 2010.............................................................................24
Wiring Diagram - Multiple Switch After July 2010.................................................................................24
Wiring Diagram - WindSmart................................................................................................................25
Wiring Diagram - Direct Response prior to July 2010...........................................................................26
Wiring Diagram - Direct Response After July 2010..............................................................................28
Wiring Diagram - Direct Response w/ Pre Wired Harness...................................................................30
Standard Service Procedures ....................................................................................................32
Programming the Remote Receiver .....................................................................................................32
Operational Notes:............................................................................................................................32
Battery Replacement............................................................................................................................33
Charging the Battery.........................................................................................................................33
Standard Maintenance................................................................................................................34
Part Number Listing....................................................................................................................35
Part Number/Serial Number Location...................................................................................................35
Arms Part Number Configuration..........................................................................................................35
Roller Part Number Configuration.........................................................................................................35
Illustrated Parts List..............................................................................................................................36
Arms..................................................................................................................................................36
Electronics.........................................................................................................................................38
052547-301r7 Printed in USA September, 2010

PROPRIETARY STATEMENT
The Eclipse Patio Awning is a product of Carefree of Colorado, located in Broomfield, Colorado, USA. The
information contained in or disclosed in this document is considered proprietary to Carefree of Colorado.
Every effort has been made to ensure that the information presented in the document is accurate and
complete. However, Carefree of Colorado assumes no liability for errors or for any damages that result
from the use of this document.
The information contained in this manual pertains to the current configuration of the models listed on the
title page. Earlier model configurations may differ from the information given. Carefree of Colorado
reserves the right to cancel, change, alter or add any parts and assemblies, described in this manual,
without prior notice.
Carefree of Colorado agrees to allow the reproduction of this document for use with Carefree of Colorado
products only. Any other reproduction or translation of this document in whole or part is strictly prohibited
without prior written approval from Carefree of Colorado.
SAFETY INFORMATION
WARNING
AWARNING INDICATES A POTENTIALLY HAZARDOUS SITUATION WHICH,IF NOT AVOIDED,COULD RESULT IN
DEATH OR SERIOUS INJURY AND/OR MAJOR PROPERTY DAMAGE.
CAUTION
ACAUTION INDICATES A POTENTIALLY HAZARDOUS SITUATION THAT MAY CAUSE MINOR TO MODERATE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.IT MAY ALSO BE USED TO ALERT AGAINST UNSAFE PRACTICES.
NOTE: A note indicates further information about a product, part, or step.
Tip: A tip provides helpful suggestions.
Safety Notes:
Always disconnect battery or power source before working on or around the electrical system.
Always wear appropriate safety equipment (i.e. goggles).
Always use appropriate lifting devices and/or helpers when lifting or holding heavy objects.
When using fasteners, use care to not over tighten. Soft materials such as fiberglass and aluminum
can be "stripped out" and lose the ability to grip and hold.
Reference Publications located @ www.carefreeofcolorado.com:
052547-001 Eclipse Arms and Canopy After Market Installation Manual
052547-021 Eclipse Arms and Canopy OEM Installation Manual
052547-031 Eclipse Arms and Canopy OEM Installation Manual - Winnebago
052547-101 Eclipse Arms Upgrade for One-Touch
052568-201 Eclipse Owner's Manual
052547-211 Eclipse Owner's Manual - Winnebago
052547-301 Eclipse Service Manual
052987-002 WindSmart Installation & Operation Manual
052526-001 Direct Response Installation Manual
Carefree of Colorado 2145 W. 6
th
Avenue Broomfield, CO 80020
aScott Fetzer company www.carefreeofcolorado.com

Carefree of Colorado Service Manual ECLIPSE
052547-301r7 1
PRODUCT OVERVIEW
The Eclipse Patio Awning uses unique “scissor” style arms that do not require vertical ground support. The
arms provide easy to use pitch adjustment—simply push together the pins on the arms, snap into the hole
set desired, and the pitch is set! The pitch can be left in any position and the Eclipse will roll up completely!
When the awning is rolled back out, it rolls out to the pitch setting previously set.
The awning rollbar and arms are made from light weight, no-rust aluminum. The awning fabric is offered in
either heavy weight vinyl or the Sunbrella® fabric, one of the most durable, strongest, weather-resistant
and fade resistant fabrics on the market.
Two auto-retract systems are used for the hardwired Eclipse awning, WindSmart (discontinued) and Direct
Response. The system may be installed as part of the original motorized awning installation or as an upgrade to
an existing motorized awning. An auto-retract system offer unique features not available with standard electronics:
Full-Extend – Press and release the control to extend, the awning extends completely. It is not
necessary to hold the button when opening.
Full-Retract – Press and release the control to retract, the awning retracts completely. It is not. It is not
necessary to hold the button when closing.
Auto-Retract – The awning can be set to automatically close when windy conditions occur.
Remote Control – The operator can conveniently operate the awning from any location with a wireless
remote control.
Eclipse Patio Awning Specifications:
ECLIPSE UNIVERSAL ECLIPSE XL
Maximum Extension: 8 foot 9 foot
Length: 12 - 21 feet 12 - 21 feet
Drop @ Min. Pitch: approximately 12 inches approximately 13.5 inches
Drop @ Max Pitch: approximately 40 inches approximately 45 inches
Extend Actuation: Gas Shock Gas Shock
Retract Actuation: Motorized roll up Motorized roll up w/ supplemental spring tension
Position Control: Motorized roll out/in
Power Requirements: 12VDC (operating range 10VDC to 14VDC) 1
Circuit Rating: 15 amp
Power Source: Motor and controls are routed and hardwired into the vehicle’s 12V system
OR 14.4V NiCD Battery (rechargeable) (discontinued)
Battery Charger: Input: 10VDC to 18VDC Time to Charge 2: 2 Hours
Emergency Retract: Electrical override system (external power source)
Eclipse Patio Awning Options:
Alumaguard Awning Wrap 3WindSmart Auto-Retract System 4 (discontinued)
Uniguard Awning Wrap 312V Direct Response Auto-Retract System 4
SunBlocker Remote Control
5
NOTES:
1. Installation with optional SunBlocker shade requires a minimum power source of 12VDC (operating range
12VDC to 14VDC)
2. Charge time is approximate requirement for a fully discharged battery to be fully charged.
3. Selected at time of initial order.
4. Windsmart and Direct Response Installations are not available with the Universal AM Eclipse w/ Battery
5. Remote Control available with auto-retract installations only

ECLIPSE Service Manual Carefree of Colorado
CANOPY REPLACEMENT
FOR UNIVERSAL ECLIPSE
Feeder Feeder
Trim Polycord
1” From Fabric
Trim Polycord
1” From Fabric
1-Piece Fabric 2-Piece Fabric
Idler
Motor
E0052
Roller Assembly
Align Slots
End Cap
#10 x 5/8 Screw (qty: 4)
End Cap
Align Slots Detail A
Detail B
Upper Bracket
(After Market Installations)
Alumaguard Uniguard
Detail C
Detail D
Figure 1. Canopy Replacement - Universal Eclipse.
1. Remove the canopy retaining screws in the awning rail.
2. Extend the awning out completely.
3. Set the awning to the maximum pitch.
4. Remove the screws that attach the end caps to the roll bar and save.
5. While holding the roll bar up, pull the roll bar out of the end cap of the motor head.
CAUTION
DO NOT ALLOW THE ROLL BAR TO DROP TOWARD THE GROUND.THE TWISTING MOTION CAN CAUSE SERIOUS
DAMAGE TO THE IDLER ARM.
6. Support the roll bar; pull the roll bar out of the end cap of the idler head.
7. Allow the fabric and roll bar to hang down on the side of the RV. Use care not to scratch the side of the RV.
8. Mark the slots that the current fabric is in then remove any fabric retaining screws in the roll bar and
slide the roll bar off the fabric.
9. Determine the type of canopy replacement:
If replacing a full fabric canopy or canopy with Alumaguard or canopy with Uniguard: For arms using
an upper mounting bracket, it will be necessary to remove the upper bracket from one side. After
removing the bracket brace the arm using scaffolding or similar support.
CAUTION
THE LOWER MOUNTING SCREWS FOR ARMS USING THE UPPER BRACKET MAY NOT BE MOUNTED INTO STRUCTURAL
MEMBERS OF THE COACH WALL.FAILURE TO SUPPORT THE ARM CAN RESULT IN DAMAGE TO THE COACH WALL.
For canopy only replacement for units with Alumaguard: The fabric is crimped into the aluminum slat.
Use a large flat screw driver or similar tool to spread open the crimp on both sides of the fabric.
For canopy only replacement for units with Uniguard: Remove the retaining screws from both sides
of the Uniguard.
2 052547-301r7

Carefree of Colorado Service Manual ECLIPSE
10. Slide the fabric out of the awning rail.
11. Clean and deburr the roll bar slots and awning rail/Alumaguard/Uniguard as required. If not
previously done, spread open the awning rail track to facilitate inserting the new fabric.
Tip: Lightly spraying the slots with a dry silicone lubricant will help the fabric slide into the slot without
staining the material.
12. Unfold the replacement fabric then slide the new fabric into the awning rail/Alumaguard/Uniguard.
Center the fabric and install any fabric retaining screws removed previously. Allow the fabric to hang
down the side of the coach.
For Alumaguard installations: Use a pair of side cutters or similar tool and crimp the aluminum.
Use care to not bend or distort the aluminum slats.
NOTE: While the awning fabric is fairly robust, care must be taken not to snag it on the awning rail.
13. Position the fabric feeders on the roll bar. Be sure to use the same slots as the old canopy.
14. Slide the rollbar on to the new fabric. Center the fabric and install any fabric retaining screws
removed previously.
15. Remove the feeders.
16. If removed, install the upper mounting bracket.
17. Lift and align the roller assembly with the end cap on the motorized arm assembly. Rotate the end cap
until the slot in the cap aligns with the empty slot in the roller assembly, and then press the roller
assembly fully into the cap. The end cap must seat squarely over the end of the roller assembly when
complete.
NOTE: The roller assembly must be oriented with the fabric going over the roller toward the
coach wall.
18. Secure the end cap to the roll bar using two #10 square-drive screws.
19. Repeat steps 17 and 18 to attach the idler arm assembly to the roll bar.
20. Visually check that the fabric is squarely mounted. Adjust as required.
21. Roll the awning in and out several times to make sure that the fabric is square on the rollbar.
22. Secure the canopy to the awning rail using one, #6 x 3/8" hex head screw at both sides of the awning.
Fabric Alumaguard
1"
#6 x 3/8
Screw
Polyrod
E0014
Fabric
1"
#6 x 3/8
Screw #6 x 3/8
Screw
Awning Rail
Awning RailAwning Rail Polyrod
Uniguard
Soft Connect
Figure 2. Securing the Fabric.
22.1. For vinyl awnings, place screw through awning rail, polyrod and canopy approximately 1” in from
the end of the fabric.
22.2. For Uniguard awnings, place screw through awning rail, polyrod and the soft connect material
approximately 1" in from the end of the fabric.
22.3. For Alumaguard awnings, place screw on the outer edge of the Alumaguard (not through the
Alumaguard).
For Alumaguard installations, go to "Installing the Alumaguard Tractioners" on page 6.
052547-301r7 3

ECLIPSE Service Manual Carefree of Colorado
FOR ECLIPSE XL
This procedure applies to the XL Model only. The idler incorporates a roll bar spring to supplement the
closing power of the motor. In the closed position, the spring has no winds; the number of winds increase
as the awning extends. It will be necessary to remove the spring temporarily to change the canopy.
Roller
Assembly
Align Empty Slots
End Cap
#10 x 5/8 Screw (qty: 4)
End Cap
E0052a
Detail A
Feeder Feeder
Trim Polycord
1” From Fabric
Trim Polycord
1” From Fabric
1-Piece Fabric 2-Piece Fabric
Idler
Motor
Detail B
Upper Bracket
(After Market Installations)
Alumaguard Uniguard
Detail
C
Detail D
Figure 3. Canopy Replacement - Eclipse XL.
1. Remove the canopy retaining screws in the awning rail.
2. Follow the instructions for "Removing the Spring" on page 11.
3. Remove the screws that attach the motor head end cap to the roll bar and save.
4. While supporting the roll bar, pull the roll bar out of the end cap of the motor head. It may be necessary
to slide the canopy in the awning rail about 2"-3" for the roll bar to clear the end cap.
CAUTION
THE ARM IS UNDER TENSION FROM THE GAS SHOCK.WHEN THE ROLLBAR IS DISENGAGED FROM THE END CAP,
THE ARM WILL EXTEND FROM THE GAS SHOCK TENSION.USE EXTREME CARE AND HOLD THE ARM AND LET IT
EXTEND.IT WILL BE NECESSARY TO HAVE AT LEAST ONE OTHER PERSON HOLDING THE MOTOR ARM.
5. Allow the fabric and roll bar to hang down on the side of the coach.
6. Mark the slots that the current fabric is in then remove any fabric retaining screws and slide the roll bar
off the fabric.
7. Determine the type of canopy replacement:
If replacing a full fabric canopy or canopy with Alumaguard or canopy with Uniguard: For arms using
an upper mounting bracket, it will be necessary to remove the upper bracket from one side. After
removing the bracket brace the arm using scaffolding or similar support.
CAUTION
THE LOWER MOUNTING SCREWS FOR ARMS USING THE UPPER BRACKET MAY NOT BE MOUNTED INTO STRUCTURAL
MEMBERS OF THE COACH WALL.FAILURE TO SUPPORT THE ARM CAN RESULT IN DAMAGE TO THE COACH WALL.
For canopy only replacement for units with Alumaguard: The fabric is crimped into the aluminum slat.
Use a large flat screw driver or similar tool to spread open the crimp on both sides of the fabric.
For canopy only replacement for units with Uniguard: Remove the retaining screws from both sides
of the Uniguard.
4 052547-301r7

Carefree of Colorado Service Manual ECLIPSE
052547-301r7 5
8. Slide the fabric out of the awning rail/Alumaguard/Uniguard.
9. Clean and deburr the roll bar slots and awning rail/Alumaguard/Uniguard as required. If not previously
done, spread open the awning rail track to facilitate inserting the new fabric.
Tip: Lightly spraying the slots with a dry silicone lubricant will help the fabric slide into the slot without
staining the material.
10. Unfold the replacement fabric then slide the new fabric into the awning rail/Alumaguard/Uniguard.
Center the fabric and install any fabric retaining screws removed previously. Allow the fabric to hang
down the side of the coach.
For Alumaguard installations: Use a pair of side cutters or similar tool and crimp the aluminum. Use
care to not bend or distort the aluminum slats.
NOTE: While the awning fabric is fairly robust, care must be taken not to snag it on the awning rail.
11. If removed, install the upper mounting bracket.
12. Position the fabric feeders on the roll bar. Be sure to use the same slots as the old canopy.
13. Slide the rollbar onto the new fabric. Center the fabric and install any fabric retaining screws
removed previously.
14. Remove the feeders.
15. Lift and align the roller assembly with the end cap on the motorized arm assembly. Rotate the end cap
until the slot in the cap aligns with the empty slot in the roller assembly, and then press the roller
assembly fully into the cap. The end cap must seat squarely over the end of the roller assembly when
complete.
NOTE: On early units, a spider bracket was inside the end cap to hold the rollbar in position with
the drive shaft. The newer end caps no longer require the use of the spider.
16. Secure the end cap to the roll bar using two #10 square-drive screws.
17. Insert the idler assembly spring into the roll bar then rotate the end cap until the slot in the cap aligns
with the empty slot in the roll bar. Press the end cap fully on to the rollbar and secure using two #10
square drive screws.
18. With the awning open, it is necessary to add winds to the spring. To add winds, firmly grasp the
mounting frame and rotate over the top and away from the coach. To hold the frame, use vice grips.
NOTE: One complete revolution equals one wind. One wind must be added for every 11 inches
that the awning is open. With the awning fully extended, total number of winds equals 10.
19. (Refer to Figure 8 on page 11) Place the idler assembly in position over the mounting bolt. Ensure that
the spacer-washers are all accounted for.
NOTE: It will be necessary to collapse and hold the arm to match the roller position.
20. Secure using the washer and lock nut removed previously. The nut should be tightened until snug
but the idler head should be able to swivel by hand.
21. Attach the rear cover to the motor assembly using the large screw removed previously.
22. Attach the front cover using the small screws removed previously.
23. Visually check that the fabric is squarely mounted without any wrinkles. Adjust as required.
24. Roll the awning in and out several times to make sure that the fabric rolls squarely onto the rollbar.

ECLIPSE Service Manual Carefree of Colorado
25. Secure the canopy to the awning rail using one, #6 x 3/8" hex head screw at both sides of the awning.
Fabric Alumaguard
1"
#6 x 3/8
Screw
Polyrod
E0014
Fabric
1"
#6 x 3/8
Screw #6 x 3/8
Screw
Awning Rail
Awning RailAwning Rail Polyrod
Uniguard
Soft Connect
Figure 4. Securing the Fabric.
25.1. For vinyl awnings, place screw through awning rail, polyrod and canopy approximately 1” in from
the end of the fabric.
25.2. For Uniguard awnings, place screw through awning rail, polyrod and the soft connect material
approximately 1" in from the end of the fabric.
25.3. For Alumaguard awnings, place screw on the outer edge of the Alumaguard (not through the
Alumaguard).
INSTALLING THE TRACTIONERS
The tractioners are used with the alumaguard metal fabric wrap and uniguard with vinyl fabrics.
1/4" Gap
A
A
View A-A
(Uniguard w/ Vinyl Fabric)
Position Tractioner under
Alumaguard/Uniguard
Keeper
E0058
1/4" Gap
Alumaguard or
Uniguard
View A-A
(Alumaguard)
Place Screw Between
Slots on Roller
Place Screw Between
Slots on Roller
Figure 5. Installing the Alumaguard Tractioner.
1. Partially extend the awning until the Alumaguard/Uniguard is extended with the edge on the roll bar as shown.
2. Unlock the keeper and wrap the tractioner around the roller tube.
3. Position the tractioner under the Alumaguard/Uniguard with a 1/4” gap between the metal wrap and
tractioner. Lock the keeper.
4. Repeat for the other end of the rollbar.
5. Extend the awning to verify that the tractioners are lifting the metal wrap up and over the roller assembly.
6. To secure the tractioner, drill a 1/8” hole through the tractioner and rollbar; roughly center the hole
between two slots of the rollbar.
7. Secure with one (1) #10 square drive screw.
IMPORTANT NOTE: Over time and use, the awning fabric may stretch. When this occurs the
position of the tractioner relative to the metal wrap may change. It may be necessary to remove the
screw and adjust the position of the tractioners (both sides). It will be necessary to drill new holes
(step 6) before securing with the screw.
6 052547-301r7

Carefree of Colorado Service Manual ECLIPSE
MOTOR REPLACEMENT CAUTION
ALWAYS DISCONNECT THE BATTERY OR POWER SOURCE BEFORE WORKING WITH ANY ELECTRICAL COMPONENTS.
Two methods are used for replacing the Eclipse motor. 1) Replacing the motor if the awning is extended
(fully or partially) and 2) Replacing the motor if the awning is fully closed.
REPLACING THE MOTOR -AWNING EXTENDED
1
1
Spacers
(qty: 11)
3/8-16 x 6 Bolt
Front Cover
Rear Cover
Motor - Red Wire
Cable - Red Wire
Motor Head
Motor - Black Wire
Cable - Black Wire
1Wire color from the cable
may deviate on some models.
NOTE:
Standard Color
Red
Black
Deviation Color
Yellow
Brown
3/8-16 Lock Nut
#10 x 5/8 Screw
(qty: 2)
E0049
Figure 6. Motor Replacement - Awning Extended.
1. For convenience, lower the awning to the maximum pitch setting.
2. On the motorized side, remove the two square drive screws attaching the end cap to the roll bar then
separate the roll bar from the end cap. It will be necessary to hold the roll bar and both arms in
position.
CAUTION
THE ARMS ARE UNDER TENSION FROM THE GAS SHOCK.WHEN THE ROLL BAR IS SEPERATED,BOTH ARMS WILL
EXTEND.USE EXTREME CARE AND HOLD THE ARMS IN POSITION.IT WILL BE NECESSARY TO HAVE AT LEAST ONE
OTHER PERSON HOLDING THE IDLER ARM.
3. Hold on to the motor arm and allow it to extend to its maximum position.
4. Hold on to the idler arm and roll bar and allow the arm to extend to its maximum position while allowing
the fabric to unroll from the roll bar.
CAUTION
FOR XL AWNINGS: THE IDLER HEAD HAS A ROLL BAR SPRING INCORPORATED TO SUPPLEMENT THE CLOSING
POWER OF THE MOTOR.IN THE CLOSED POSITION,THE SPRING HAS NO WINDS;THE WINDS INCREASE AS THE
AWNING IS OPENED.WHEN THE ARM IS FREED THE ARM WILL OPEN/CLOSE UNTIL THE SPRING WIND TENSION
(CLOSE)EQUALS THE GAS SHOCK TENSION (OPEN). ALLOW THE ARM TO COME TO REST AT THE EQUALIZATION
POINT.DURING ASSEMBLY COLLAPSE AND HOLD THE MOTOR ARM TO MATCH THE XL IDLER ARM POSITION.
5. Use a ladder or other device support the roll bar.
CAUTION
DO NOT ALLOW THE ROLL BAR TO DROP TOWARD THE GROUND.THE TWISTING MOTION CAN CAUSE SERIOUS
DAMAGE TO THE IDLER ARM.
6. On the right hand arm remove the front cover by removing the six (6) smaller screws from the back of
the motor head. Save cover and screws.
052547-301r7 7

ECLIPSE Service Manual Carefree of Colorado
8 052547-301r7
7. Disconnect the motor and cable wires from inside the rear cover. Carefully note the location of each
wire.
8. Remove the rear cover by removing the one (1) large screw from the back of the motor head. Save
cover and screw.
9. Loosen and remove the 3/8-16 lock nut from the mounting bolt. Make note of the number and order of
the spacer-washers between the arm mounting block and the motor head.
Tip: When the nut is removed, the bolt will slide out of the arm mounting block inside the arm channel.
Placing tape on the head of the mounting bolt and the spacers will prevent them from falling out when
the nut and motor are removed.
10. Remove the motor assembly. The motor assembly consists of the motor, mounting frame, gears, shaft
and roller end cap.
11. Place the new motor assembly in position over the mounting bolt. Ensure that the spacer-washers
are all accounted for.
12. Secure using the washer and lock nut removed previously. The nut should be tightened until snug
but the motor head should be able to swivel by hand.
13. Attach the rear cover to the motor assembly using the large screw removed previously.
14. Attach the motor and cable wires to the terminals inside the rear cover.
NOTE: FOR XL AWNINGS: Before attaching the roll bar to the end cap, collapse and hold the motor
arm to match the idler arm position. Ensure that the fabric is rolled up evenly on the roll bar.
15. Align the roll bar with the end cap on the motorized arm assembly. Rotate the end cap until the slot
in the cap aligns with the empty slot in the roller assembly, and then press the roller assembly fully into
the cap. The end cap must seat squarely over the end of the roller assembly when complete.
NOTE: On early units, a spider gear inside the end cap is used to hold the rollbar in position
with the drive shaft. The replacement end cap no longer requires the use of the spider.
16. Secure the end cap to the roller assembly using two #10 x 5/8 square-drive screws.
17. Restore power and test operation. If the awning moves in the wrong direction (i.e. extends when
retract is pushed) reverse only the two motor wires in the rear cover.
18. Attach the front cover using the small screws removed previously.

Carefree of Colorado Service Manual ECLIPSE
REPLACING THE MOTOR –AWNING CLOSED
This procedure will require replacing the front and rear motor covers in addition to the motor assembly.
1
1
Motor - Red Wire
Cable - Red Wire
Motor Head
Motor - Black Wire
Cable - Black Wire
1Wire color from the cable
may deviate on some models.
NOTE:
Standard Color
Red
Black
Deviation Color
Yellow
Brown
Spacers
(qty: 11)
3/8-16 x 6 Bolt
Front Cover
Rear Cover
3/8-16 Lock Nut
#10 x 5/8 Screw
(qty: 2)
E0049a
Motor (ref)
Motor Attach
Bolts & Nuts
Rear Cover
(ref)
Front Cover
(ref)
Figure 7. Motor Replacement - Awning Closed.
1. Place a large flat blade screwdriver or similar tool in the seam between the front and rear covers. Using
a twisting and prying motion, break the covers off. It may be necessary to use a hammer and lightly tap
the screwdriver into the plastic to establish a starting point.
Tip: Start at the bottom and work around the seam until the covers are off.
2. Disconnect the motor and cable wires from inside the rear cover. Carefully note the location of each wire.
3. Firmly hold the motor and idler arms up while removing the three (3) motor attach bolts and nuts.
4. Remove the motor from the motor mounting frame.
CAUTION
THE ARMS ARE UNDER TENSION FROM THE GAS SHOCKS.WHEN THE MOTOR IS DISENGAGED FROM THE GEARS,
THE ROLL BAR WILL BE ABLE TO FREE SPIN AND BOTH ARMS WILL EXTEND FROM THE GAS SHOCK TENSION.USE
EXTREME CARE AND HOLD THE ARMS IN POSITION.IT WILL BE NECESSARY TO HAVE AT LEAST ONE OTHER
PERSON HOLDING THE IDLER ARM.
5. While holding on to the arms and roll bar allow the awning to extend to the maximum position; the fabric
will unroll from the roll bar.
CAUTION
FOR XL AWNINGS: THE IDLER HEAD HAS A ROLL BAR SPRING INCORPORATED TO SUPPLEMENT THE CLOSING
POWER OF THE MOTOR.IN THE CLOSED POSITION,THE SPRING HAS NO WINDS;THE WINDS INCREASE AS THE
AWNING IS OPENED.WHEN THE ARM IS FREED THE ARM WILL OPEN/CLOSE UNTIL THE SPRING WIND TENSION
(CLOSE)EQUALS THE GAS SHOCK TENSION (OPEN). ALLOW THE ARM TO COME TO REST AT THE EQUALIZATION
POINT.DURING ASSEMBLY COLLAPSE AND HOLD THE MOTOR ARM TO MATCH THE XL IDLER ARM POSITION.
6. On the right hand arm remove any pieces of the front and rear covers. Remove the cover's attaching
screws and save.
052547-301r7 9

ECLIPSE Service Manual Carefree of Colorado
7. Remove the two square drive screws attaching the end cap to the roll bar, separate the roll bar and end
cap. It will be necessary to hold the roll bar and motor arm. Allow the arm to extend out.
8. Use a ladder or other device support the roll bar.
CAUTION
DO NOT ALLOW THE ROLL BAR TO DROP TOWARD THE GROUND.THE TWISTING MOTION CAN CAUSE SERIOUS
DAMAGE TO THE IDLER ARM.
9. Loosen and remove the 3/8-16 lock nut from the mounting bolt. Make note of the number and order of
the spacer-washers between the arm mounting block and the motor head.
Tip: When the nut is removed, the bolt will slide out of the arm mounting block inside the arm channel.
Placing tape on the head of the mounting bolt and the spacers will prevent the bolt and the spacers
from falling out when the nut and motor are removed.
10. Remove the rest of the motor assembly. The motor assembly consists of the motor, mounting frame,
gears, shaft and roller end cap.
11. Place the new motor assembly in position over the mounting bolt. Ensure that the spacer-washers are
all accounted for.
12. Secure using the washer and lock nut removed previously. The nut should be tightened until snug but
the motor head should be able to swivel by hand.
13. Attach the rear cover to the motor assembly using the large screw removed previously.
14. Attach the motor and cable wires to the terminals inside the rear cover.
NOTE: FOR XL AWNINGS: Before attaching the roll bar to the end cap, collapse and hold the motor
arm to match the idler arm position. Ensure that the fabric is rolled up evenly on the roll bar.
15. Align the roll bar with the end cap on the motorized arm assembly. Rotate the end cap until the slot
in the cap aligns with the empty slot in the roller assembly, and then press the roller assembly fully into
the cap. The end cap must seat squarely over the end of the roller assembly when complete.
NOTE: On early units, a spider gear was inside the end cap to hold the rollbar in position with
the drive shaft. The replacement end cap no longer requires the use of the spider.
16. Secure the end cap to the roller assembly using two #10 x 5/8 square-drive screws.
17. Restore power and test operation. If the awning moves in the wrong direction (i.e. extends when retract
is pushed) reverse only the two motor wires in the rear cover.
18. Attach the front cover using the small screws removed previously.
10 052547-301r7

Carefree of Colorado Service Manual ECLIPSE
IDLER/SPRING REPLACEMENT
This procedure applies to the XL Model only. The idler incorporates a roll bar spring to supplement the closing
power of the motor. In the closed position, the spring has no winds; the winds increase as the awning extends.
Spacers
Front Cover
Rear Cover
3/8-16 Lock Nut
#10 x 5/8 Screw
(qty: 2)
3/8-16 x 6 Bolt
E0051
Subtract
Add
Mounting Frame
Tie Arms
In this Area
Detail ADetail B
Figure 8. Idler/Spring Replacement.
REMOVING THE SPRING
1. Extend the awning out approximately 10 inches. This will allow access to the attaching screws for the covers.
2. Tie the arm as shown in Detail A. Use a soft rag or similar material beneath the tie material to prevent
damaging the finish. CAUTION
THE ARM IS UNDER TENSION FROM THE GAS SHOCK.WHEN THE HEAD IS DISENGAGED FROM THE ROLL BAR,THE
ARM WILL TRY TO EXTEND FROM THE GAS SHOCK TENSION IF THE ARM IS NOT TIED AND SECURED.
3. Remove the six (6) small screws for the front cover and the one (1) large screw that attaches the rear
cover to the frame. Set covers and screws aside and save.
CAUTION
THE SPRING WILL HAVE A MINIMUM OF ONE WIND WHEN THE AWNING IS PARTIALLY OPEN.FIRMLY HOLD THE
IDLER HEAD WHILE DISASSEMBLING.WITH MINIMUM TENSION THE SPRING CAN STILL UNWIND WITH FORCE
THATCAN CAUSE PERSONAL INJURY AND/OR PROPERTY DAMAGE.
4. Loosen and remove the 3/8-16 lock nut from the mounting bolt. Make note of the number and order of
the spacer-washers between the arm mounting block and the idler head.
5. Firmly hold the idler head and pull the bolt down to free the head from the arm.
6. While firmly holding the idler mounting frame, unwind the spring. To unwind, rotate the idler mounting
frame over the top toward the coach.
7. Remove the square drive screws attaching the end cap to the roll bar and separate the end cap from roll bar.
8. Pull the idler head and spring out of the roll bar and set aside.
INSTALLING THE SPRING
9. Insert the new spring into the roll bar then rotate the end cap until the slot in the cap aligns with the empty slot
in the roll bar. Press the end cap fully on to the rollbar and secure using two #10 square drive screws.
NOTE: On early units, a spider gear was inside the end cap to hold the rollbar in position with
the drive shaft. The replacement end cap no longer requires the use of the spider.
10. With the awning partially open add one wind to the spring. To add a wind, firmly grasp the mounting
frame and rotate over the top and away from the coach. One complete revolution equals one wind.
NOTE: One wind must be added for every 11 inches that the awning is open.
11. Place the idler assembly in position over the mounting bolt. Ensure that all the spacer-washers are
accounted for.
12. Secure using the washer and lock nut removed previously. The nut should be tightened until snug but
the idler head should be able to turn by hand.
13. Reinstall the idler head covers.
052547-301r7 11

ECLIPSE Service Manual Carefree of Colorado
REPLACING THE GAS SHOCK CAUTION
THE GAS SHOCK HAS APPROXIMATELY 85 LBS OF PRESSURE IN THE CLOSED POSITION.APRESSURIZED SHOCK
CAN OPEN RAPIDLY WHEN REMOVED OR RELEASED AND CAUSE PERSONAL INJURY AND PROPERTY DAMAGE.
1. Open the awning.
NOTE: The arm may not completely open when the shock has lost pressure or it is removed. It
may be necessary to pull the arm out and away from the vehicle to open the awning.
12 052547-301r7
2. Remove the stop bolts and save.
3. Remove the two square drive screws
attaching the end cap to the roller tube,
then separate the roller tube and end
cap. It will be necessary to hold the roll
bar and motor arm. Allow the arm to
extend out.
4. Use a scaffold or similar device to
support the roller tube.
CAUTION
DO NOT ALLOW THE ROLLER TUBE TO DROP
TOWARD THE GROUND.THE TWISTING MOTION
CAN CAUSE DAMAGE TO THE OTHER ARM.
5. Support the arm in the area shown.
6. Unscrew the shock barrel from the
clevis in the mounting channel.
Tip: Wearing a pair of rubber gloves will
aid in gripping the surfaces of the shock.
7. Unscrew the shaft from the clevis in the arm joint. Set old shock aside.
NOTE: It may be necessary to use vice grips or pliers on the old shock to unscrew the shock
from the clevis. DO NOT use vice grips or pliers on the new shock. Damage to the surface of
the shaft or damage to the barrel can cause the new shock to not work.
E0054
Loosen
Loosen
Stop
Bolts
Set Arm at
Minimum Pitch
Support and Lift in this area
Align Slots
End Cap
#10 x 5/8 Screw (qty: 2)
Figure 9. Replacing the Shock.
8. Unpack the new shock and carefully allow it to extend to its maximum length.
9. Insert the new shock between the upright struts.
10. Coat the threads of the shaft of the new shock with a non-permanent thread lock (i.e. loctite) then screw
the rod into the clevis of the arm elbow. Hand-tighten only.
11. Lift and hold the arm up in the area indicated in Figure 9. The arm should be unfolded and extended as
far as possible.
12. Coat the threads of the barrel of the new shock with a non-permanent thread lock (i.e. loctite) then
screw the barrel into the clevis in the mounting channel. Hand-tighten only. It will be necessary to grip
and hold the shaft while turning the barrel.
13. Align the roll bar with the end cap on the arm assembly. Rotate the end cap until the slot in the cap
aligns with the empty slot in the roller assembly, and then press the roller assembly fully into the cap.
The end cap must seat squarely over the end of the roller assembly when complete.
14. Secure the end cap to the roller assembly using two #10 x 5/8 square-drive screws.
15. Partially retract the awning. It may be necessary to lightly pull down on the lower arm at the mounting
channel until the rollers are past the location of the stop bolts. Always pull down from the bottom of the
arm to avoid pinching.
16. Reinstall the stop bolts removed in step 2.

Carefree of Colorado Service Manual ECLIPSE
REPLACING THE ARM ROLLERS
Use Kit number R019291-005 for white or
R019251-006 for black.
1. Open the awning completely.
2. Use a ladder or scaffold to support the roller tube.
3. Disconnect power to the awning.
4. Cut the tie bracket in half.
5. Drill out the roll rivets from the roller on both sides
of the arm. Drill only the rivet; do not drill into the
roller mount at the bottom of the channel.
Cut Tie Bracket
Drill Out Rivet
Holding Roller
(2 plcs)
E0061a
6. Spread the arm channels and hold slightly skewed.
From inside the channels, drill out the 4 rivets that
hold the tie bracket halves. Remove and discard
parts.
7. Pull out the roller from the channel. It may be
necessary to use a flat blade screwdriver or similar
tool to "pop out" the roller.
CAUTIONUSE A RAG OR SIMILAR PROTECTION
BETWEEN ANY TOOLS AND THE SURFACES OF THE ARMS.
THIS IS TO PREVENT SCRATCHING OR DAMAGING THE
SURFACE.
Drill Out and Remove
Bracket Rivets
(4 plcs)
Remove Roller
From Extrusions
E0061b
8. Assemble the new roller, standoff and rivet as
shown then insert the roller into the channel of the
extrusion. It may be useful to use a clamp or wide
mouth pair of pliers to squeeze the new roller into
the channel of the extrusion.
9. Slide the arm channels onto the rivets.
NOTE: It is not necessary to crimp or roll the new
roller rivet. When the assembly is
complete; the rivet is trapped and cannot
come out.
Roller
Standoff
Rivet
Insert Rollers
into Channel
(2 plcs)
Slide Arm
Onto Rivet
E0061c
10. Position the new tie bracket between the arm
channels.
11. Attach using four (4) each 1/4-20 x 1 truss head
screws and nylock nuts. Use the existing rivet
holes in the channels. Before tightening, make
sure that the front of the bracket is parallel with the
front face of the channels.
12. Clean the surface of the bracket then attach the
warning label to the front of the bracket.
13. Remove the roller tube supports and reconnect
power to the awning.
Tie Bracket
1/4-20 Screw
& Nut
(4 plcs)
E0061d
DANGER
Keep Hands Clear
Label
052547-301r7 13

ECLIPSE Service Manual Carefree of Colorado
14 052547-301r7
DIAGNOSTICS
The following procedures are intended to aid the service technician to logically resolve operational issues
with the mechanical and standard electronics installations.
Common Operational Items
The following items are operational items that may come up as questions during normal operation. These
are also given in the operator's manual.
1. The motor has a thermal protection circuit. If the motor overheats, the circuit will shut off the motor.
Wait approximately 15 minutes, operation will return to normal. As an example, this may occur if the
awning is fully closed and retract switch pushed repeatedly, then the awning does not extend.
2. The awning seems to extend and retract slowly. The operational range is 28-35 seconds to extend or
retract. If the power supply is on the low side of the range (10V) the awning will move slower.
3. The awning may appear to move jerkily. When the fabric is rolled out, the Alumaguard or Uniguard
may "bounce" creating a wave like motion in the canopy fabric. This will create the appearance of
moving jerkily.
4. With Uniguard, the awning sticks or hangs up. When Uniguard is installed with a vinyl canopy, the vinyl
will have a tendency to "cling" to the Uniguard when not used over an extended period. Open and
close the awning in short bursts 2 or 3 times, the awning will then open normally.
Refer to the appropriate wiring diagram for the system being tested:
STANDARD ELECTRICAL
Wiring diagram – single switch page 23
Wiring diagram – multiple switch page 23
AUTO RETRACT SYSTEMS:
Wiring diagram – Windsmart page 25
Wiring diagram – Direct Response page 26
Procedures in this section: Page
STANDARD ELECTRICAL...................................................................................................................15
D01 THE AWNING OPERATES IN REVERSE OF THE SWITCH PLATE ...................................................15
D02 THE AWNING DOES NOT EXTEND AND/OR RETRACT .................................................................15
D03 ARM DOES NOT EXTEND OR DOES NOT EXTEND COMPLETELY .................................................17
AUTO RETRACT SYSTEMS................................................................................................................18
D04 THE AWNING OPERATES IN REVERSE OF THE SWITCH PLATE MARKINGS ..................................18
D05 THE AWNING DOES NOT EXTEND AND/OR RETRACT USING THE PATIO SWITCH.........................18
D06AAWNING DOES NOT AUTO-RETRACT DURING WINDY CONDITIONS -WINDSMART.....................19
D06BAWNING DOES NOT AUTO-RETRACT DURING WINDY CONDITIONS –DIRECT RESPONSE..........19
D07 AWNING DOES NOT MOVE WHEN KEY FOB BUTTONS ARE PUSHED...........................................20
COMMON TEST PROCEDURES...........................................................................................................21
CT01 TESTING A SWITCH AND HARNESS .........................................................................................21
CT02 TESTING THE CONTROL BOX .................................................................................................22
CT03 TESTING THE BATTERY AND CHARGER ..................................................................................22

Carefree of Colorado Service Manual ECLIPSE
052547-301r7 15
STANDARD ELECTRICAL
The following procedures are intended to aid the service technician to logically resolve operational issues
with the mechanical and standard electronics installations.
In the charts below, YES is a positive response to the test; NO is a negative response.
D01 THE AWNING OPERATES IN REVERSE OF THE SWITCH PLATE
This condition generally occurs during new installations or when major components have been replaced.
YES Switch mounted OK; go to test B A Confirm Switch is mounted in correct position and correctly
oriented. NO Carefully remove the switch, rotate
180 and reinstall in panel. Reconnect
harnesses and retest
YES Switch wired OK; go to test C B Confirm switch is wired correctly. Use the wiring diagram and
confirm the wires to/from the switch to the connector are
correctly placed. NO Rewire the switch according to the
wiring diagram
D02 THE AWNING DOES NOT EXTEND AND/OR RETRACT
For Multiple Switch configurations, the Power switch must be ON. YES Go to test B
A Check Installation Integrity
Use the wiring diagram and confirm that the components and
wiring are properly installed and connected NO Correct as required
YES Go to test B B Confirm Power Supply
Is vehicle battery or power source providing 10V to 14V to the
Switch (Power switch for Multiple switch installations) For
battery installations, use test procedure “CT03 Testing the
Battery” on page 22.
NO Correct as required
YES Motor is good, go to test C C Test Motor Function
1. For installations with an external plug; Disconnect plug.
2. For installations with a single switch; Remove switch plate and
disconnect the motor wires from the switch.
3. For installations with multiple switches, disconnect the
connector from the relay to the motor. If no connector, remove
the butt splices on the red and black wires from the motor. Cap
the wires to prevent shorting
4. Attach jumper leads to the emergency terminals located
on the back of the motor head.
5. Connect the other ends of the jumpers to a 12-18VDC
power source (i.e. drill battery). It may be necessary to try
then reverse the leads on the battery and try again.
6. Does the motor run?
NO Motor is defective - replace
YES Wire continuity good – reconnect the
wires disconnected in the previous
test then go to test E
D Test wire continuity between motor and wire ends.
NO Repair as required then reconnect
the wires disconnected in the
previous test.
DO2 continued on next page

ECLIPSE Service Manual Carefree of Colorado
D02 (CONT)
Test Switch Function – Single Switch Installation (this test requires a continuity tester)
The Patio Switch used in the Single Switch Installation is a center on that is internally cross-wired to short in the
center position to provide dynamic braking for the motor to prevent "drift" when the awning is stopped.
Test 1 is for Series I & II switches. Use Test 2 for Series III switches.
Observe continuity for switch in center position, extend position and retract position.
Pin: Center Extend Retract
3 N Y N
6 Y N Y
YES Test OK, all checks pass – go to step
1b
5B Y N N
1a Place one lead of tester
on pin 2B. Touch 2nd
lead to the other pins
one at a time. N = no continuity, Y = continuity NO Test failed; switch defective - replace
Pin: Center Extend Retract
3 N N Y
6 Y Y N
YES Test OK, all checks pass – Revaluate
problem, cause is not electrical
1b Place one lead of tester
on pin 5B. Touch 2nd
lead to the other pins
one at a time. N = no continuity, Y = continuity NO Test failed; switch defective - replace
Travelr019
Note:
The Series II switch terminals are not labeled.
The illustrations are labeled for identification purposes
in the procedures above.
Series I Switch
(Retract)
(Extend)
(Center)
6
5B
4
3
2B
1
Series II Switch
(Retract)
(Extend)
(Center)
(6)
(5B)
(3)
(2B)
E
Test 2 is for Series III switches. Use Test 1 for Series I & II switches.
Observe continuity for switch in center position, extend position and retract position.
Pin: Center Extend Retract
2 N N Y
4 N Y N
YES Test OK, all checks pass – go to step 2b
N = no continuity, Y = continuity
2a Place one lead of tester
on 12V pin (3). Touch
2nd lead to the other
pins one at a time. All other pins should be NO in all
switch positions
NO Test failed; switch defective - replace
Pin: Center Extend Retract
2 Y Y N
YES Test OK, all checks pass – go to step 2c
N = no continuity, Y = continuity
2b Place one lead of tester
on Ground1pin (1).
Touch 2nd lead to the
other pins one at a time. All other pins should be NO in all
switch positions
NO Test failed; switch defective - replace
Pin: Center Extend Retract
4 Y N Y
YES Test OK, all checks pass – Revaluate
problem, cause is not electrical
N = no continuity, Y = continuity
2c Place one lead of tester
on Ground2pin (5).
Touch 2nd lead to the
other pins one at a time. All other pins should be NO in all
switch positions
NO Test failed; switch defective - replace
Travelr019a
Note:
The Series III switch terminals are not labeled.
The illustration is labeled for identification purposes
in the procedures above.
(Retract)
(Extend)
(Center)
Ground
1
(1)
12V (3)
Retract (2) (5) Ground
2
(4) Extend
Series III Switch
16 052547-301r7

Carefree of Colorado Service Manual ECLIPSE
052547-301r7 17
D03 ARM DOES NOT EXTEND OR DOES NOT EXTEND COMPLETELY
YES Go to test B A Visually confirm motor is working when control switch is pressed. NO Go to test D02 – Awning Does Not
Extend and/or Retract – page 14.
YES Go to test C B Confirm that the arm channels, pivot points and contact points
are clean and clear of obstructions. NO Clean and Lubricate then retest. If
the arm still hangs up – go to test C
YES Tractioners OK - Go to test D C If the awning has Alumaguard, check that the tractioners are
installed and positioned correctly (refer to page 6). NO Reposition and attach the
tractioners according to the
directions on page 6 and retest.
YES Shock is defective – replace. See
procedure on page 12.
D 1. Open the awning. If the awning arm does not extend,
carefully pull the arm out as the fabric is unrolling.
2. Does the fabric sag when the awning is extended?
3. Inspect the shock. Is there evidence of dirt build up and oil
leaks on the rod?
4. Hand close and open the arm. Is the tension from the shock
mushy, weak or missing?
NOTE: To close the awning by hand, push the head of the
arm toward the coach. Pulling down on the head or roll bar
WILL NOT close the awning.
NO Shock extends with arm and is
solid. Shock pressure is
approximately 85 lbs. Go to test E.
E This step only applies to new Uniguard and Alumaguard installations that do not extend correctly. Check that the
centerline of the roll bar is 3/4" ± 1/4" above the centerline of the awning rail. Refer to 052547-001 Eclipse Arms
and Canopy After Market Installation Manual or 052547-021 Eclipse Arms and Canopy OEM Installation Manual
and reposition the arms as necessary.

ECLIPSE Service Manual Carefree of Colorado
18 052547-301r7
AUTO RETRACT SYSTEMS
The following procedures are intended to aid the service technician to logically resolve operational issues
with the auto-retract installation.
NOTES:
1. Refer to the appropriate wiring diagram for the system being tested:
2. In the charts below, YES is a positive response to the test; NO is a negative response.
3. After July 2010, the Direct Response system uses an On/Off switch in place of the "Mode" switch. The auto-
retract system is active when the switch is in the ON position and disabled when the switch is OFF.
4. The Extend/Retract switch is also referred to as the Patio switch.
5. Orginal switches are labeled Series I. New switch configuration is labeled Series III.
D04 THE AWNING OPERATES IN REVERSE OF THE SWITCH PLATE MARKINGS
For series I switches, the Mode switch must be in the POWER ON or AUTO-RETRACT ON positions for the key FOB
to work. For series III switches, the On/Off switch must be ON. YES Switch mounted OK; go to test B
A (Series I only) Confirm Switch is mounted in correct position
and correctly oriented.. The lens or lens caps should be on
the bottom of the switch as indicated by the shaded area. NO Carefully remove the switch, rotate
180 and reinstall in panel. Reconnect
harnesses and retest
YES Switch wired OK; go to test C B Confirm switch is wired correctly. Use the wiring diagram and
confirm the wires from the switch to the connector are
correctly placed. NO Rewire the switch according to the
wiring diagram
YES Switch and Harness OK; go to test D C Confirm Operation of EXTEND/RETRACT Switch Use test
procedure “CT01 Testing a Switch and Harness” on page 21. NO Repair or replace as recommended
in procedure and retest
YES Power and Control Box OK D Is the control box operating correctly? Use test procedure
“CT02 Testing the Control Box” on page 22. NO Repair as recommended in
procedure and retest
D05 THE AWNING DOES NOT EXTEND AND/OR RETRACT USING THE EXTEND/RETRACT SWITCH
For series I switches, the Mode switch must be in the POWER ON or AUTO-RETRACT ON positions for the key FOB
to work. For series III switches, the On/Off switch must be ON. YES Go to test B
A Confirm Power Supply Is vehicle battery or power source
providing 10V to 14V to the control box. NO Correct as required
YES Motor is good, go to test C B Test Motor Function
1. Disconnect Motor Plug from control box.
2. Attach jumper leads to the emergency terminals located
on the back of the motor head.
3. Connect the other ends of the jumpers to a 12-18VDC
power source (i.e. drill battery). It may be necessary to try
then reverse the leads on the battery and try again.
4. Does the awning move?
NO Motor is defective - replace
YES Wire continuity good – go to test D C Test wire continuity between motor and control box connector. NO Repair as required
YES Switch and harness OK; go to test E D (Series I only) Confirm Operation of MODE Switch Use test
procedure “CT01 Testing a Switch and Harness” on page 19. NO Repair or replace as recommended
in procedure and retest
YES Switch and harness OK; go to test F E Confirm Operation of EXTEND/RETRACT Switch Use test
procedure “CT01 Testing a Switch and Harness” on page 21. NO Repair or replace as recommended
in procedure and retest
YES Control box OK F Is the control box operating correctly? Use procedure “CT02
Testing the Control Box” on page 22. NO Repair as recommended in
procedure and retest
