Carefree ASCENT User manual

052553-301 Printed in USA June, 2008
SERVICE MANUAL
ASCENT
RV
SLIDE-OUT COVER
THIS MANUAL CONTAINS INFORMATION FOR: ASCENT
ASCENT XL
These instructions apply to all models listed. Details and procedures unique to a specific
model are labeled appropriately
Table of Contents

PROPRIETARY STATEMENT
The Ascent series of Slide-Out Room Covers is a product of Carefree of Colorado, located in Broomfield,
Colorado, USA. The information contained in or disclosed in this document is considered proprietary to
Carefree of Colorado. Every effort has been made to ensure that the information presented in the
document is accurate and complete. However, Carefree of Colorado assumes no liability for errors or for
any damages that result from the use of this document.
The information contained in this manual pertains to the current configuration of the models listed on the
title page. Earlier model configurations may differ from the information given. Carefree of Colorado
reserves the right to cancel, change, alter or add any parts and assemblies, described in this manual,
without prior notice.
Carefree of Colorado agrees to allow the reproduction of this document for use with Carefree of Colorado
products only. Any other reproduction or translation of this document in whole or part is strictly prohibited
without prior written approval from Carefree of Colorado.
SAFETY INFORMATION
WARNING
AWARNING INDICATES A POTENTIALLY HAZARDOUS SITUATION WHICH,IF NOT AVOIDED,COULD RESULT IN
DEATH OR SERIOUS INJURY AND/OR MAJOR PROPERTY DAMAGE.
CAUTION
ACAUTION INDICATES A POTENTIALLY HAZARDOUS SITUATION THAT MAY CAUSE MINOR TO MODERATE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.IT MAY ALSO BE USED TO ALERT AGAINST UNSAFE PRACTICES.
NOTE: A note indicates further information about a product, part, or step.
Tip: A tip provides helpful suggestions.
Safety Notes:
•Always disconnect battery or power source before working on or around the electrical system.
•Always wear appropriate safety equipment (i.e. goggles).
•Always use appropriate lifting devices and/or helpers when lifting or holding heavy objects.
•When using fasteners, use care to not over tighten. Soft materials such as fiberglass and aluminum
can be "stripped out" and lose the ability to grip and hold.
Reference Publications located @ www.carefreeofcolorado.com:
052553-001 Ascent Installation Manual
052557-301 Ascent Service Manual
Carefree of Colorado 2145 W. 6
th
Avenue Broomfield, CO 80020
aScott Fetzer company 303-469-3324 ♦www.carefreeofcolorado.com
Table of Contents

Carefree of Colorado Service Manual ASCENT
052553-301 1
TABLE OF CONTENTS
Product Overview.......................................................................................................................... 2
The Front Cover - All Models........................................................................................................ 3
Canopy Replacement - All Models............................................................................................... 4
Removing the Fabric and Roller Tube ....................................................................................................4
Installing the Fabric and Roller Tube......................................................................................................5
Spring/Roll Bar Replacement ....................................................................................................... 6
Removing the Roller Tube Assembly .....................................................................................................6
Replacing the Spring Assembly..............................................................................................................7
Assembling the XL Roller Tube Assembly..............................................................................................8
Installing the Roller Tube Assembly .......................................................................................................8
Standard Maintenance ................................................................................................................ 10
Fabric Care...........................................................................................................................................10
Mildew ...............................................................................................................................................10
Pooling ..............................................................................................................................................10
Hardware Maintenance.........................................................................................................................10
Part Number Listing .................................................................................................................... 11
Part Number Configuration ...................................................................................................................11
Part Number/Serial Number Location...................................................................................................11
Illustrated Parts List ..............................................................................................................................12

ASCENT Service Manual Carefree of Colorado
2 052553-301
PRODUCT OVERVIEW
¾Stylized to blend smoothly with the coach wall;
¾Simplified installation, deflector mounts directly to room and aligns with the top of the room flange;
¾Improved pitch provides for rain run off;
¾Hinged cover provides easy access for cleaning and service while providing a closed, finished
appearance;
¾Weather slat eliminates billowing. When the room is closed, no fabric is exposed;
¾Available in standard and XL versions.
5.5”
3.6”
4.63”
Width = Box Length + 8” (approx.)
Dimensions are approximate, actual dimensions may vary based on the slide-out configuration and if optional mounting brackets are used.
as029
Slat
Cover
Roller Tube
Chassis
Figure 1. General Dimensions.
Standard 42" - 196"
AVAILABLE LENGTHS:
(measured box length) XL 197" - 384"
AVAILABLE EXTENSION: Up to 42"
Pitch: 5° @ 42" extension (pitch increases as extension decreases)
FABRIC TENSION One spring for standard widths; Two springs for XL models
COLOR: Hardware: White, Black, Pewter, Champagne and Satin
Fabric: Woven Acrylic, Polyweave and Vinyl (refer to sales literature for available colors)
Standard Base Weight @ 42" Box Length = 22.2 lbs; for every 12" increase, add 3.6 lbs WEIGHT:
XL Base Weight @ 197" Box Length = 75.2 lbs; for every 12" increase, add 3.6 lbs
Weight calculation is approximate. Actual weight may vary based on type of canopy fabric and specific installation details
Table of Contents

Carefree of Colorado Service Manual ASCENT
052553-301 3
THE FRONT COVER -ALL MODELS
To Open the Cover
Cover
as010
DETAIL A
#10 x 1 1/2 SHCS
Screw (qty: 2)
Figure 2. Opening the Front Cover.
1. Open the room approximately 3" - 4". This will relieve the fabric tension against the front cover.
2. Remove the two retaining screws from the end caps (one on each side). Save the screws.
3. Rotate the cover down. The cover can hang down for cleaning and service.
4. (Detail A) If necessary to remove the cover, hold the cover perpendicular to the deflector then lift and
unhook the cover from the back of the case.
To Install the Cover
5. Hold the cover perpendicular to the deflector, lift and hook the cover onto the back of the case.
6. Rotate the cover up and secure using two (2) #10 x 1 1/2 socket head cap screws. .
NOTE: There will be a small gap between the cover and end cap. DO NOT attempt to close the
cap by over tightening the screw, maximum torque is 30 in-lbs.
Table of Contents

ASCENT Service Manual Carefree of Colorado
4 052553-301
CANOPY REPLACEMENT -ALL MODELS
#10 Fender Washer
#10 x 3/8 Spindle Tab
Retaining Screw
Spring Lock Pin
as024
Spindle Tab
(ref)
DETAIL A
DETAIL D
DETAIL B
Loosen the 2
End Cap Screws
Approximately 1”
Slide End Cap Out
After Loosening
Screws
Slat
Roller Tube & Fabric
Remove and Save
Lower Screws
Rotate one End Plate
Down to Expose Fabric Slot
6” Approx.
DETAIL C
Spindle Tab
Hem on Bottom
View of RH Spindle
Clearly Mark the RH End of Roller Tube
#10 x 2 Fabric Retaining Screw
Pull Down and Hold Polycord
While Placing Retaining Screw
Gray Polycord
Screw Position
#8 x 2 Screw
Fabric
Spindle and Bearing Assy (ref)
Figure 3. Replacing the Fabric.
REMOVING THE FABRIC AND ROLLER TUBE
1. Open the room approximately 3"-4".
2. Open the front cover. Refer to page 3.
CAUTION
THE SPRINGS ARE WOUND AND UNDER TENSION.THE SPRING LOCKING PINS MUST BE INSERTED BEFORE
CONTINUING OTHERWISE THE ROLLER TUBE CAN SPIN OUT OF CONTROL AND CAUSE PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
3. (Detail A) On the right end of the roller tube, insert a spring locking pin through the roller bearing and
spindle; it may be necessary to twist the roller to align the holes. The locking pin is a 3/16 x 1 1/4 cotter
pin or equivalent. Place tape over the head of the pin to avoid the pin coming out.
IMPORTANT NOTE: The XL model has two springs. A second spring locking pin must also
be inserted through the LH bearing and spindle and taped in place before continuing.
4. On the slat assembly, remove the lower screws that secure the fabric and slat. It is not necessary to remove
the upper screws. On one end of the slat, swivel the end plate out of the way to clear the lower slot of the slat.
Table of Contents

Carefree of Colorado Service Manual ASCENT
052553-301 5
5. (Detail B) Inside the end caps, remove the spindle tab retaining screws and washers. There is one
screw in each end cap.
6. On one end of the deflector, loosen the screws for the end cap approximately 1" and slide the end cap
out. It is not necessary to remove the screws and end cap from the deflector.
7. Lift the roller tube out of the deflector.
8. Slide the roller tube and fabric out of the slat.
9. Clearly mark the right end of the roller tube for reference then unroll the fabric from the roller tube.
10. Remove the retaining screws from the roller tube spindles and save. Remove the fabric from the roller tube.
INSTALLING THE FABRIC AND ROLLER TUBE
If replacing or repairing the roller tube, make the necessary repairs before continuing.
1. Unfold the replacement fabric.
2. (Detail C) Slide the black polycord of the fabric into the fabric slot located on the opposite side of the
spindle tabs. Orient the fabric is with the hem on the bottom (the hem will then roll against the roller
tube). Center the fabric in the roller tube.
3. (Detail C) After the fabric is centered, pull and hold the excess polycord in the bottom of the fabric slot.
Place one (1) #10 x 2 PHSD screw through the fabric slot hole and polycord. The screw must be
positioned to thread into the metal of the roller tube slot and the edge of the polycord. The screw action
will pull the polycord further into the slot hole. DO NOT OVERTIGHTEN,maximum torque 16 in-lbs.
4. After the screw is installed, trim the excess polycord.
5. After tightening the fabric in the slot from one end of the roller tube to the other end, repeat step 5 and 6
to secure the fabric.
6. Roll the fabric onto the roller tube. Note the direction of the wrap as shown in Detail B. The view is of the RH
spindle that was marked earlier. Allow approximately 6" of fabric to extend past the roller tube.
7. Lift the roller tube up and slide the fabric polyrod into the front slot of the slat. Center the fabric in the slat.
Trim any excess polycord that extends past the slat.
8. Roll up any slack material onto the roller tube.
9. Insert the roller tube into the fixed end cap. Note the orientation of the spindle tabs at the ends of the
roller tube; these must point forward (away from coach).
10. Align the RH spindle of the roller tube then push the loose end cap onto the roller tube and against the
deflector. Tighten the screws.
11. (Detail A) Inside each end cap, screw in the #10 x 3/8 thread-cutter screw and fender washer as shown.
12. (Detail D) Confirm the material is centered in the slat, then align one end plate and attach to the slat
using the #8 x 2 flat head screw. DO NOT OVER TIGHTEN,maximum torque 16 in-lbs.
NOTE: The attaching screws are offset from the center of the polyrods. Ensure that the polyrod is
positioned in the large diameter of the fabric slot. The screws thread into the extrusion and
the top of the polyrod.
Tip: Place a small wedge (such as a small flat blade screwdriver) between the top of the fabric and the slot to
hold the polyrod down to start the screw in the correct position. Use care to not damage the fabric.
13. After tightening the fabric in the slot from one end of the slat to the other end, trim any excess polyrod
that extends past the slat. Align the second end plate and attach to the slat using two (2) #8 x 2 flat
head screws. DO NOT OVER TIGHTEN,maximum torque 16 in-lbs.
CAUTION
WHEN THE PINS ARE REMOVED,THE ROLLER TUBE SPRINGS WILL QUICKLY ROLL UP ANY SLACK MATERIAL.USE CARE
THAT HANDS AND FINGERS ARE OUT OF THE WAY.
14. (Detail A) Remove the spring locking pin from the end of the roller tube assembly. The XL roller tube
has two springs. Remove the pins from both ends of the XL roller tube.
15. Close the cover. Refer to "The Front Cover" on page 3.
Table of Contents

ASCENT Service Manual Carefree of Colorado
6 052553-301
SPRING/ROLL BAR REPLACEMENT
WARNING
THESE PROCEDURES DEAL DIRECTLY WITH THE PRE-WOUND SPRING TENSION IN THE ROLL BAR.FAILURE TO
EXCERCISE CARE AND/OR FAILURE TO FOLLOW THE INSTRUCTIONS CAN RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.IF THE SPRING IS PREMATURELY RELEASED,THE ROLL BAR CAN SPIN OUT OF CONTROL AND
CAUSE PERSONAL INJURY AND/OR PROPERTY DAMAGE.
NOTES:
1. Replacement roller tube assemblies are complete and include the spindles and pre-wound
spring assembly.
2. The instructions in this section are for replacing only the roller tube assembly or spring
assembly.
3. If replacing the fabric and roller tube assembly, follow the "Canopy Replacement"
instructions on page 4. Substitute the replacement roller tube for the existing roller tube.
4. If replacing the fabric and spring assembly, follow the "Canopy Replacement" instructions
on page 4. Repair the roller tube assembly following the instructions for "Replacing the
Spring Assembly" on page 7 before installing the new fabric.
5. The XL roller tube assembly is shipped in two pieces. The center splice is pre assembled in
the RH half of the roller tube. Refer to the instructions on page 7 before continuing.
REMOVING THE ROLLER TUBE ASSEMBLY
If not replacing the fabric, it is not necessary to remove the fabric from the coach. The fabric can hang down on
the side of the coach.
Refer to Figure 3 "Replacing the Fabric" on page 4.
1. Open the room approximately 3"-4".
2. Open the front cover. Refer to page 3.
CAUTION
THE SPRINGS ARE WOUND AND UNDER TENSION.THE SPRING LOCKING PINS MUST BE INSERTED BEFORE
CONTINUING OTHERWISE THE ROLLER TUBE CAN SPIN OUT OF CONTROL AND CAUSE PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
11. (Detail A) On the right end of the roller tube, insert a spring locking pin through the bearing and spindle;
it may be necessary to twist the roller to align the holes. The locking pin is a 3/16 x 1 1/4 cotter pin or
equivalent. Place tape over the head of the pin to avoid the pin coming out.
IMPORTANT NOTE: The XL model has two springs. A second spring locking pin must also
be inserted through the LH spindle and taped in place before continuing.
3. (Detail B) Inside the end caps, remove the spindle tab retaining screws and washers. There is one
screw in each end cap.
4. On the right end of the deflector, loosen the screws for the end cap approximately 1" and slide the end
cap out.
5. Lift the roller tube out of the deflector.
6. Clearly mark the right end of the roller tube for reference then unroll the fabric from the roller tube.
7. Remove the fabric retaining screws from the roller tube spindles and save.
8. Slide the roller tube off the fabric.
If replacing the roller tube assembly, go to "Installing the Roller Tube Assembly" on page 8.
If replacing the spring assembly, go to "Replacing the Spring Assembly" on page 7.
Table of Contents

Carefree of Colorado Service Manual ASCENT
052553-301 7
REPLACING THE SPRING ASSEMBLY
This procedure will require two people.
DETAIL A
View of RH Spindle
#8 x 1 PHSD Screw
Spindle Attach Screw
Fabric Slot (ref)
3/8 Square Drive
as026
Figure 4. Replacing the Spring Assembly.
1. Remove the existing spring winds.
CAUTION
USE A PAIR OF GOOD QUALITY WORK GLOVES TO PROTECT THE HANDS WHILE HOLDING ONTO THE ROLL
BAR.INSULATED RUBBER GLOVES PROVIDE A SOLID GRIP.
•Firmly hold onto the roller tube.
CAUTION
THE SPRING IS WOUND AND UNDER TENSION.WHEN THE PIN IS REMOVED,THE SPINDLE WILL TURN RAPIDLY.
TO AVOID PERSONAL INJURY,KEEP HANDS AWAY FROM THE SPINDLE UNTIL THE SPRING HAS UNWOUND.
•Remove the spring locking pin and allow the spring to unwind.
2. After the spring is unwound, remove the #8 x 1 pan head square drive screw that attaches the spindle
assembly to the roller tube and save.
3. Remove the spring assembly from the roller tube and set aside.
4. Insert the new spring assembly and secure to the roller tube with the #8 x 1 screw removed previously.
Calculating the Spring Winds
The Ascent spring winds are calculated based on the box length of the slide-out. To calculate the spring
winds (room closed), measure the box length IN FEET.
Box Length Winds Required
•Less than 5' Spring Winds = 4
•5' to 16' 4" Spring Winds = Number of feet
Example: Box Length = 10' 4"; spring winds = 10.
Always round down to the nearest whole number.
(XL Models)
•16' 5" to 29' 11" Spring Winds = Number of feet divided by 2
Example: Box Length = 20' 6"; spring winds = 20 divided by 2 = 10.
Always round down to the nearest whole number.
•30' of longer Spring Winds = 15
Box Length
(in feet)
as027
Adding Spring Winds
NOTE: Have a spring lock pin available. The pin should be a solid 3/16 x 1 1/4 shaft with a flat end
such as a drill bit. If using a 3/16 cotter pin, cut the two legs flush so that the end is flat.
5. Have one person firmly hold the roller tube stationary.
6. Insert a 3/8 square drive extension with handle into the spindle. Turn the handle counter clockwise to
add spring winds. One complete rotation of the spindle equals one spring wind.
Table of Contents

ASCENT Service Manual Carefree of Colorado
8 052553-301
7. After adding the required number of spring winds, firmly
hold the ratchet handle and roller tube and insert the
spring locking pin. The pin will only go in partially until
the 3/8 drive is removed.
8. Hold the pin in place and slowly release the ratchet
handle. When there is no pressure on the handle,
remove the square drive from the spindle. Press the
pin in as far as possible then place tape over the head
of the pin to avoid the pin coming out.
After completing the spring replacement, go to "Installing the
Roller Tube Assembly" on page 8.
ASSEMBLING THE XL ROLLER TUBE ASSEMBLY
The XL roller tube assembly is shipped in two pieces. The center splice is pre assembled in the RH half of
the roller tube. It is necessary to assembly the XL roller tube before continuing.
1. Clearly mark the RH roller tube next to the
bearing and spindle.
2. On the ground, press the two roller tube
halves tightly together. The splice can
only fit one way in the tube. For
reference, the spindle tabs on the roller
tube must both point in the same direction.
3. (Detail A) Attach the left tube half to the splice using four (4) #8 x 3/4 self-drilling screws. Match the
screw pattern in the right roller tube half.
INSTALLING THE ROLLER TUBE ASSEMBLY
If the new fabric is being installed with the replacement or modified roller tube, use the installation
instructions for "Installing the Fabric and Roller Tube" on page 5.
For the referenced Details, refer to Figure 3 "Replacing the Fabric" on page 4.
If the fabric was left on the coach:
1. Slide the roller tube onto the fabric. Make sure that the right end (spring end) of the roller tube is on the
RH side of the canopy.
2. (Detail C) After the fabric is centered, hold the polycord in the bottom of the fabric slot. Place one (1)
#10 x 2 PHSD screw through the fabric slot hole and polycord. The screw must be positioned to thread
into the metal of the roller tube slot and the edge of the polycord. The screw action will pull the
polycord further into the slot hole. DO NOT OVERTIGHTEN,maximum torque 16 in-lbs.
NOTE: The attaching screws are offset from the center of the polyrods. Ensure that the polyrod is
positioned in the large diameter of the fabric slot. The screws thread into the extrusion and
the top of the polyrod.
Tip: Place a small wedge (such as a small flat blade screwdriver) between the top of the fabric and the slot to
hold the polyrod down to start the screw in the correct position. Use care to not damage the fabric.
3. After tightening the fabric in the slot from one end of the roller tube to the other end, repeat step 2 to
secure the fabric.
4. Roll the fabric onto the roller tube. Note the direction of the wrap as shown in Detail C. The view is of the RH
spindle that was marked earlier.
5. Insert the roller tube into the fixed end cap. Note the orientation of the spindle tabs at the ends of the
roller tube; these must point forward (away from coach).
6. Align the RH spindle of the roller tube then push the loose end cap onto the roller tube and against the
deflector. Tighten the screws.
Firmly Grasp the Roller Tube
3/8 Square Drive
Socket Extension
3/16 x 1 3/4 Locking Pin
Cut End Off Flat
as028
Figure 5. Adding Spring Winds.
Splice (ref)
#8 x 3/4
Self Drilling Screw
(qty: 4)
as014a
Spindle Tab
Clearly Mark the RH End of Roller Tube
Figure 6. Assembling the XL Roller Tube.
Table of Contents

Carefree of Colorado Service Manual ASCENT
052553-301 9
7. (Detail B) Inside each end cap, screw in the #10 x 3/8 screw and fender washer as shown.
CAUTION
WHEN THE PINS ARE REMOVED,THE ROLLER TUBE SPRINGS WILL QUICKLY ROLL UP ANY SLACK MATERIAL.USE CARE
THAT HANDS AND FINGERS ARE OUT OF THE WAY.
8. (Detail A) Remove the spring locking pin from the end of the roller tube assembly. The XL roller tube
has two springs. Remove the pins from both ends of the XL roller tube.
9. Close the cover and secure using two (2) #10 x 1 1/2 socket head cap screws. (Refer to "The Front
Cover" on page 3).
Table of Contents

ASCENT Service Manual Carefree of Colorado
10 052553-301
STANDARD MAINTENANCE
Maintaining a Carefree Ascent slide-out cover is easy. Just follow these basic steps:
•Periodically check that the fasteners are tight. Tighten if necessary.
•Keep the awning fabric clean.
FABRIC CARE
CAUTION
DO NOT USE OIL BASED CLEANERS OR ANY CAUSTIC,GRANULATED,OR ABRASIVE TYPE CLEANERS ON YOUR
CAREFREE PRODUCT.
1. One of the best ways to keep the fabric looking good and to delay the need for deep or vigorous
cleanings is to hose fabrics off on a monthly basis with clear water. This practice will help prevent dirt
from becoming deeply imbedded in the fabric. In most environments, a thorough cleaning will be
needed every two to three years.
2. When it’s time for a thorough cleaning, the fabric can be cleaned while still on the awning frame.
•For Vinyl Fabric – Use a soft brush and warm water with soap.
•For Acrylic Fabric – Use a stiff brush and warm water with soap.
3. When cleaning the fabric, it is important to observe the following:
•Always use a natural soap, never detergent.
•Water should be cold to lukewarm, never more than 100°F.
•Air-dry only. Never apply heat to the fabric.
•Always allow the fabric to dry thoroughly before rolling up the canopy.
Mildew
Mildew is a fungus growth that looks like dirt. Vinyl coated polyester fabrics are mildew resistant because
of a chemical biocide in the vinyl coating. Under ordinary conditions, mildew will not appear. However, in
areas where high temperature and humidity are common, mildew can be a problem and required the
material to be washed more frequently. Thoroughly rinse the fabric with clean water and allow to air dry
completely before rolling up the canopy.
Pooling
When water collects on the top of the fabric, this is known as "pooling". This can occur during inclement
weather or if a running air conditioner discharges over the awning. The water is dumped when the awning
is retracted. It is recommended that if water accumulates on the top; retract the room in steps (8"-12") to dump
the water. This will help prevent the fabric from stretching or distorting.
IMPORTANT NOTE: If the room must be closed during wet weather (rain), close the room in
increments (approximately 6-8"). This is to allow water to run off while the room is closing and
prevent sudden pooling.
HARDWARE MAINTENANCE
•Replace any parts that become damaged.
•Periodically check all mounting hardware, screws, lags, etc., and re-tighten when necessary.
Table of Contents

Carefree of Colorado Service Manual ASCENT
052553-301 11
PART NUMBER LISTING
PART NUMBER CONFIGURATION
Example: Part Number: A C 0 7 6 C W J V 4 2
AC 076 CW JV 42
Ascent 76" Toast (acrylic) Black 42"
STYLE CODE
LENGTH (IN INCHES)
(BOX LENGTH) CANOPY COLOR CASE COLOR EXTENSION
AC = Ascent 050 - 196 VINYL
POLYWEAVE
ACRYLIC
STANDARD &
CUSTOM
BZ = Ascent XL 197 - 330
Refer to sales order information for specific
codes and colors available
Standard Fabric
Extension = 42"
PART NUMBER/SERIAL NUMBER LOCATION
Inside Front Cover
Rear Side of Slat
On Roller Tube
as025
Table of Contents

ASCENT Service Manual Carefree of Colorado
12 052553-301
ILLUSTRATED PARTS LIST
13
11
9
14
20
8
19
18
7
15
4
21
5
10
DETAIL
A
XL Chassis Assy
DETAIL
B
XL Slat Assy
22
DETAIL
C
XL Cover Assy
DETAIL
D
XL Roll Bar Assy
24
6
23 1
3
2
2
12
10
ascent501
16
17
XL Only
Table of Contents

Carefree of Colorado Service Manual ASCENT
052553-301 13
Item Part Number Description Notes
1 R001564XXX-xxx Deflector Standard
2 R001565XXX-xxx Deflector, Half XL Only
3 R001555 Spacer, Shoulder XL Only
4 R001563 Deflector Glide 24" LG
5 R001557XXX Bracket, Deflector Mount
6 R001151XXX Cover, Mounting Bracket
7 R001554WHT End Cap, LH White
R001554BLK End Cap, LH Black
8 R001556WHT End Cap, RH White
R001556BLK End Cap, RH Black
9 610700xxXXX Awning Rail
10 R001573WHT-xxx Flex Connect White
R001573BLK-xxx Flex Connect Black
11 R001566XXX-xxx Slat Assy Standard
12 R001567XXX-xxx Slat Assy XL Only 2
13 R001553WHT End Plate, Slat, LH White
R001553BLK End Plate, Slat, LH Black
14 R001558WHT End Plate, Slat, RH White
R001558BLK End Plate, Slat, RH Black
15 R001568-xxx Roller Tube Assy Standard 3
16 R001569-xxx Roller Tube Half, LH XL 4
17 R001572-xxx Roller Tube Half, RH XL 5
18 R001559 Spindle and Bearing Assy, LH Standard
19 R001561 Spring Assy, LH XL Only
20 R001560 Spring Assy, RH
21 R001570XXX-xxx Cover Assy Standard
22 R001571XXX-xxx Cover Assy XL Only 2
23 R001562 Cover Glide 24" LG
24 Canopy Only Refer to Canopy Order Form
Notes: 1. XXX = Color; xxx = Length in inches
2. Ascent XL components (items 12, 22) are shipped in two pieces and must be assembled during
installation.
3. Roller tube assy (item 15) is complete and includes roller tube, LH spindle assy (item 17) and pre-
wound RH spring assy (item 18).
4. XL LH roller tube assy (item 16a) is complete and includes roller tube half, screws and pre-wound
LH spring assy (item 19)
5. XL RH roller tube assy (item 16b) is complete and includes roller tube half, splice, screws and pre-
wound RH spring assy (item 18).
Table of Contents

ASCENT Service Manual Carefree of Colorado
14 052553-301
NOTES:
Table of Contents
