Carel HeaterSteam 4 UR002 User manual

High Efficiency Solutions
heaterSteam 4 - UR
NO POWER
& SIGNAL
CABLES
TOGETHER
READ CAREFULLY IN THE TEXT!
Electric resistance humidifier
User manual

3
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
IMPORTANT WARNINGS:
This product is compliant with the European directives and other standards
specied on the EC declaration of conformity. The customer is responsible
for suitably verifying any use of the product that implies application of
standards relating to any special environments and/or processes (e.g.
heavy industry, medical environments, maritime environments, railway
environments, etc.) other than those specied by Carel.
The humidifiers manufactured by CAREL are advanced products, whose
operation is specified in the technical documentation supplied with the product
that can be downloaded, even prior to purchase, from the website www.carel.
com. Every product made by CAREL Industried, in relation to its advanced level of
technology, requires a qualification/ configuration / setup phse in order to best
fulfil your specific application. The lack of such phase of study, as indicated in the
manual, can cause the final product to malfunction, of which CAREL cannot be
held responsible.The client (builder, developer or installer of the final equipment)
assumes all responsibility and risk relating to the configuration of the product in
order to achieve the expected results in relation to the specific final installation
and/or equipping. In this case, subject to specific agreements, CAREL acts as a
consultant for the success of the installation / start-up / use of the machine, but
in no case does it accept liability for proper operation of the humidifier and of
the final plant, should the warnings and recommendations in this manual or in
any other technical documentation of the product not be followed. In particular,
in addition to the obligation to observe the above mentioned warnings and
recommendations for proper use of the product, we recommend paying
attention to the following warnings:
DANGER ELECTRICSHOCK: The humidifier includes live electrical parts.
Disconnect the power supply before accessing internal parts, in case of
maintenance and during installation.
DANGER WATER LEAKS:The humidifier automatically and constantly sucks
in/drains quantities of water. Malfunctions in the connections or humidifier
may cause leaks.
DANGER OF BURNS:The humidifier contains hot parts and delivers steam
at 100 °C / 212 °F.
• The product is designed exclusively to humidify rooms either directly or
through distribution systems (ducts).
• Installation, operation and maintenance must be performed by qualified
personnel, aware of the necessary precautions and able to perform the
required operations correctly.
• All operations on the product must be carried out according to the
instructions given in this manual and on the labels applied to the
product. Any uses or modifications unauthorized by the manufacturer are
considered improper. CAREL denies all responsibility for such unauthorized
uses.
• Do not attempt to open the humidifier in any way other than the ones
described in the manual.
• Follow the regulations in force in the place where the humidifier is installed.
• Keep the humidifier out of the reach of children and pets.
• Do not install and use the product near objects that can be damaged by
contact with water (or condensate). CAREL denies all responsibility for direct
or indirect damage as a result of loss of water from the humidifier.
• Do not use corrosive chemicals, aggressive solvents or detergents to clean
the internal or external parts of the humidifier, unless specifically indicated
in the user’s manual.
CAREL adopts a continuous development policy.Therefore, CAREL reserves the
right to carry out modifications and improvements to any product described
in this document without prior notice. The technical data in the manual
can undergo modifications without forewarning. The liability of CAREL in
relation to its own product is governed by CAREL general contract conditions
published on the website www.carel.com and/or by specific agreements with
clients; in particular, within the limits set by the applicable law, in no way will
CAREL, its employees or its branch offices/affiliates be responsible for any lack
of earnings or sales, loss of data and information, cost of replacement goods
or services, damage to objects or persons, work interruptions, or any direct,
indirect, accidental, patrimonial, coverage, punitive, special or consequential
damage in any way caused, be they contractual, out-of-contract, or due to
negligence or other responsibility originating from the installation, use or
inability of use of the product, even if CAREL or its branch offices/affiliates
have been warned of the possible damage.
ATTENTION
NO POWER
& SIGNAL
CABLES
TOGETHER
READ CAREFULLY IN THE TEXT!
Separate the probe cables and the digital input cables as much as possible
from the inductive load and power cables to prevent possible electro-
magnetic interference.
Never introduce power cables and signal cables (including those of electric
control board) into the same cable troughs.
The installation of the product must absolutely include the grounding
connection, using the special yellow-green terminal on the terminal block.
Do not use the neutral as grounding connection.
DISPOSAL
Fig. 1 Fig.2
Please read and keep.
With reference to European Union directive 2012/19/EU issued on 4 July 2012
and related national legislation, please note that:
1. Waste Electrical and Electronic Equipment (WEEE) cannot be disposed
of as municipal waste but must be collected separately so as to allow
subsequent recycling, treatment or disposal, as required by law;
2. users are required to take Electrical and Electronic Equipment (EEE) at end-
of-life, complete with all essential components, to the WEEE collection
centres identified by local authorities. The directive also provides for the
possibility to return the equipment to the distributor or retailer at end-of-
life if purchasing equivalent new equipment, on a one-to-one basis, or
one-to-zero for equipment less than 25 cm on their longest side;
3. this equipment may contain hazardous substances: improper use or
incorrect disposal of such may have negative effects on human health
and on the environment;
4. the symbol (crossed-out wheeled bin – Fig.1) even if, shown on the
product or on the packaging, indicates that the equipment must be
disposed of separately at end-of-life;
5. if at end-of-life the EEE contains a battery (Fig. 2), this must be removed
following the instructions provided in the user manual before disposing
of the equipment. Used batteries must be taken to appropriate waste
collection centres as required by local regulations;
6. in the event of illegal disposal of electrical and electronic waste, the
penalties are specified by local waste disposal legislation.
Warranty for materials: 2 years (from the manufacture date, excluding
consumables).
Certication: the quality and safety of CAREL products are guaranteed by
CAREL’s ISO 9001 certified design and production system, as well as
and .marking.

5
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
Content
1. INTRODUCTION AND INSTALLATION 7
1.1 HeaterSteam (UR*).....................................................................................................................................7
1.2 Dimensions and weights.......................................................................................................................7
1.3 When opening the packaging...........................................................................................................7
1.4 Positioning......................................................................................................................................................7
1.5 Wall mounting..............................................................................................................................................7
1.6 Removing the front panel.....................................................................................................................8
1.7 Mounting the front panel .....................................................................................................................8
1.8 Material supplied with the appliance............................................................................................9
1.9 Technical data plate..................................................................................................................................9
1.10 Water circuit...................................................................................................................................................9
1.11 Layout of models UR002 – UR0013..............................................................................................10
1.12 Layout of models UR020 – UR0080..............................................................................................11
2. HYDRAULICCONNECTIONS 12
2.1 Supply water .............................................................................................................................................14
2.2 Drain water..................................................................................................................................................14
3. STEAM DISTRIBUTION 15
3.1 CAREL steam nozzles (SDPOEM00**)..........................................................................................15
3.2 CAREL linear distributors for air ducts or AHUs (DP***DR0) ........................................15
3.3 CAREL blowers for room installation (VSDU0A*, VRDXL*)............................................16
3.4 Steam transport pipe............................................................................................................................16
3.5 Condensate drain pipe........................................................................................................................16
3.6 Outlet pressure limits............................................................................................................................17
4. ELECTRICAL CONNECTIONS 18
4.1 Wiring provisions.....................................................................................................................................18
4.2 Power cable connection.....................................................................................................................18
4.3 Control board.............................................................................................................................................19
4.4 Operating and control principles .................................................................................................20
4.5 Steam production control signals ..............................................................................................21
4.6 Control with humidity probes.........................................................................................................22
4.7 Control with temperature probes.................................................................................................23
4.8 Alarm contact ............................................................................................................................................24
4.9 Unit status contact / maintenance pre-alert..........................................................................25
4.10 Production request analogue output.........................................................................................25
4.11 Final checks.................................................................................................................................................25
5. PREPARING FOR OPERATION 25
5.1 Preliminary checks..................................................................................................................................25
6. STARTUP AND USER INTERFACE 26
6.1 Start-up..........................................................................................................................................................26
6.2 Activation sequence ...........................................................................................................................26
6.3 Shutdown.....................................................................................................................................................26
6.4 Graphic terminal ......................................................................................................................................26
6.5 Keypad ...........................................................................................................................................................27
6.6 Display............................................................................................................................................................27
6.7 Display graphic area 2 – Probes/Request.................................................................................27
6.8 Display graphic area 3 - Notification center............................................................................27
6.9 Display graphic area 4 - Unit status..............................................................................................28
6.10 Display graphic area 5 - Quick access.........................................................................................28
6.11 Display graphic area 6 - Unit status icons.................................................................................28
6.12 Main menu ..................................................................................................................................................29
6.13 Complete programming menu tree ...........................................................................................30
6.14 Alarms.............................................................................................................................................................32
7. USER MENU AND UNIT CONFIGURATION 33
7.1 Main menu ..................................................................................................................................................33
7.2 Menu E. Settings - a. Control..........................................................................................................33
7.3 Menu E. Settings - b. Functions.....................................................................................................35
7.4 Menu E. Settings - c. Configuration...........................................................................................37
7.5 E.Settings – d.Master/Slave ..............................................................................................................41
7.6 E.Settings – e.Backup ...........................................................................................................................41
7.7 E.Settings – f.Manual mode...............................................................................................................41
7.8 E.Settings – g.Initialisation ................................................................................................................42
7.9 E. Settings - h. Supervision ...............................................................................................................43
7.10 E. Settings - i. Logout..........................................................................................................................43
8. MASTER/SLAVE SYSTEM 44
8.1 Description of the Master/Slave system....................................................................................44
8.2 Network switch for Master/Slave connection.......................................................................44
8.3 Type of Master/Slave system installation..................................................................................44
8.4 Master/Slave system configuration..............................................................................................45
9. WEBSERVER 47
9.1 Integrated web server..........................................................................................................................47
9.2 Connecting to the integrated web server...............................................................................47
9.3 Description of the web server function....................................................................................47
10. HARDWARE BACKUP 48
11. SUPERVISOR NETWORK 49
11.1 Supervisor network protocols and configuration...............................................................49
11.2 Table of supervisor variables ...........................................................................................................49
12. WIRELESS PROBES, INSTALLATION AND CONFIGURA
TION 57
12.1 Type of installation and wireless probe electrical connections ...............................57
12.2 Wireless probe installation.................................................................................................................57
13. ALARM TABLE 58
14. SPARE PARTSAND MAINTENANCE 60
14.1 Maintenance...............................................................................................................................................63
14.2 Maintenance operations.....................................................................................................................63
14.3 Maintenance frequency......................................................................................................................63
14.4 Maintenance of the cylinder-boiler .............................................................................................64
14.5 Feed/drain tempering solenoid valve........................................................................................65
14.6 Fill tank ...........................................................................................................................................................66
14.7 Replacing the parts ................................................................................................................................66
14.8 Mechanical discharge of water in the cylinder.....................................................................67
15. WIRING DIAGRAMS68
15.1 Wiring diagram UR002-UR004 single-phase 208 V / 230 V .................................................
- version U...................................................................................................................................................68
15.2 Wiring diagram UR002-UR004 single-phase 230 V - version 0....................................69
15.3 Wiring diagram UR006 single-phase 208 V / 230 V - version U...................................70
15.4 Wiring diagram UR006 single-phase 230 V - version 0....................................................71
15.5 Wiring diagram UR006-UR010-UR013 three-phase (208-230-400-................................
460-575 V) - version U...........................................................................................................................72
15.6 Wiring diagram UR006-UR010-UR013 three-phase ................................................................
(230-400-460 V) - version 0................................................................................................................73
15.7 Wiring diagram UR020 three-phase (208-230-400-460-575 V) - ....................................
version U
Wiring diagram UR027 three-phase (400-460-575 V) - .........................................................
version U ......................................................................................................................................................74
15.8 Wiring diagram UR020-UR027 three-phase (230-400-460 V) - ........................................
version 0 .......................................................................................................................................................75
15.9 Wiring diagram UR027 three-phase (230 V) - version U.................................................76
15.10 Wiring diagram UR040 three-phase (400-460-575 V) - version U
Wiring diagram UR053 three-phase (575 V) - version U.................................................77
15.11 Wiring diagram UR040-UR053 three-phase (400-460 V) - ..................................................
version 0........................................................................................................................................................78
15.12 Wiring diagram UR053 three-phase (400-460 V) - version U.......................................79
15.13 Wiring diagram UR060 three-phase (575 V) - version U.................................................80
15.14 Wiring diagram UR060 (400-460 V) - version U....................................................................81
15.15 Wiring diagram UR060-UR080 three-phase (400-460 V) - ..................................................
version 0 .......................................................................................................................................................82
15.16 Wiring diagram UR080 three-phase (400-460-575 V) - .........................................................
version U.......................................................................................................................................................83
16. GENERAL FEATURESAND MODELS84
16.1 heaterSteam models and electrical features..........................................................................84
16.2 Electrical connection of boiler heaters ......................................................................................85
16.3 Technical features....................................................................................................................................86
16.4 Steam transport pipe models..........................................................................................................86
16.5 Steam nozzle models............................................................................................................................86
16.6 Linear nozzle models and typical installations......................................................................87

7
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
1. INTRODUCTION AND INSTALLATION
1.1 HeaterSteam (UR*)
Range of isothermal electric heater humidifiers for steam production
control and distribution, fitted with graphic display.
Available models (identified by means of the code on the label, packaging
and on the technical data plate):
• UR002, UR004, UR006, UR010, UR013 with steam production capacity
up to 13 kg/h (28,66 lb/h), water connections under the base of the
humidifier;
• UR020, UR027, UR040, UR053, UR060, UR080 with steam production
capacity from 20 to 80 kg/h (from 44.09 to 176.37 lb/h), water
connections next to the humidifier.
1.2 Dimensions and weights
Models UR002..UR013 Models UR020...UR080
BA
C
BA
C
Fig. 1.a
UR002…13 UR020…40 UR053…80
Size
mm (in)
A 365 (14.37) 690 (27.16) 876 (34.48)
B 275 (10.82) 445 (17.51) 445 (17.51)
C 712 (28.03) 888 (34.96) 888 (34.96)
Tab. 1.a
UR002…13 UR020…40 UR053…80
Weights
kg (lb)
packaged 31(68.3) 73(160.9) 98(216.0)
empty 26(57.3) 63(138.8) 87(191.8)
installed* 35(77.1) 97(213.8) 155(341.7)
Tab. 1.b
* in operating conditions, filled with water.
1.3 When opening the packaging
• check the integrity of the humidifier upon delivery and notify to the
carrier immediately, in writing, any damage that can be attributed to
improper or careless transport;
• move the humidifier to the installation site before removing it from the
packaging, grasping the neck from beneath;
• open the cardboard box, remove the protective material and remove
the humidifier, keeping it upright at all times.
1.4 Positioning
• the unit is designed for wall mounting, suitable to support the weight
under operating conditions (see par. “Wall mounting”). The models
UR020*... UR080 * can be floor installed;
• to ensure proper distribution of steam, place the humidifier next to the
steam distribution point;
• position the humidifier vertically, use a spirit level to ensure the base is
perpendicular; observe the minimum clearances (see Fig. 1.b) to allow
space for maintenance.
Caution: during operation, the external metal panels heat up, and
the back leaning against the wall can reach temperatures above 60 °C
(140 °F).
Models UR002..UR013 Models UR020...UR080
≥200
(7.9”)
≥200 (7.9”)
≥200
(7.9”)
≥400 (15.7”)
≥700
(27.6”)
<0,5° ≥500
(19.7”)
≥1000 (39.3”)
≥300
(11.8”)
≥700
(27.6”)
Fig. 1.b
1.5 Wall mounting
Mount the humidifier on the wall using the support bracket pre-attached
to the humidifier, using the screws kit supplied (for mounting dimensions
see draws below).
Instructions for fastening:
1. unscrew the wall bracket from the one attached to the humidifier;
2. secure the bracket to the wall (see Fig. 1.c), checking with a spirit level
the horizontal position; if the unit is mounted on a masonry wall, you
can use the plastic anchor plugs (Ø 8 mm, Ø 0.31in) and the screws
(Ø 5 mm x L= 50 mm, Ø 0.19 in x L= 1.97 in) supplied;
3. hang the humidifier on the bracket using the profile on the upper
edge of the unit’s rear (Fig. 1.d).
4. lock the humidifier to the wall by means of the hole / holes found /
on the lower part of the rear panel of the machine (Fig. 1.d).
61
(2.39)
201
(7.92)
235,5
(9.27)
285,5
(11.24)
93
(3.67)
230
(9.06)
416
(16.38)
230
(9.06)
30
(1.18)
731
(28.80) 127
(4.99)
169
(6.67)
32
(1.25) 137 (5.39)
445
(17.52)
122,5
(4.82)
122,5
(4.82)
130
(5.13)
728
(28.66)
30
(1.18)
400
(15.75) 145 (5.71)
145
(5.71)
22,5
(0.89)
22,5
(0.89)
588 (23.15)
365 (14.37)
75 (2.96)
9(0.36)
41 (1.59)
162
(6.38) 106 (4.17)
49 (1.91)49 (1.91)
67
(2.64)
67
(2.64) 67
(2.64)
67
(2.64)
UR053...080
UR020...040
UR002...013
486 (19.13)
59.5 (2.34)
Fig. 1.c
Fig. 1.d

8
ENG
“heaterSteam”+0300087EN - rel. 1.4 - 22.01.2021
1.6 Removing the front panel
Models UR002…UR013:
1
2
3
4
Fig. 1.e
1. turn the oval plate with the CAREL logo until the ground screw head
can be seen;
2. loosen the screw with a screwdriver;
3. grab the sides of the panel, lift it about 20 mm (0.79 in), and detach it
from the protruding edges of the humidifier;
4. remove the panel by pulling it forward;
5. remove the protective film.
Models UR020...UR080:
1
3
2
4
Fig. 1.f
1. remove the screws on the top of the humidifier using a screwdriver;
2. grab the panel by lifting it from the top about 20 mm (0.79 in);
3. remove the panel by pulling it forward;
4. remove the protective film (on all external surfaces of the humidifier).
1.7 Mounting the front panel
Models UR002…UR013:
2
1
3
4
Fig. 1.g
1. turn the red oval plate with the CAREL logo so that the fastening hole
below is visible;
2. slide the panel on the frame (keeping it slightly raised and tilted) until
it stops on the rear edges;
3. fasten the ground screw using a screwdriver, ensuring its tightening;
4. turn the red oval plate with the CAREL logo so that the fastening hole
below is no longer visible;
Models UR020...UR080:
2
Fig. 1.h
1. slide the panel on the base, keeping it slightly tilted;
2. put it in vertical position and tighten the screws on the top cover
with a screwdriver.
Caution: in models UR020...UR080 open the electrical
compartment of the humidifier using the slotted lock.
Fig. 1.i

9
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
1.8 Material supplied with the appliance
Once the packaging opened and the front panel removed, check
if there is a:
Fig. 1.j Fig. 1.k
screws and anchor
kit for wall mounting
only for models UR020...UR080: Code
FWHDCV0003 non-return valve with
connection tube
1.9 Technical data plate
Humidifiers can be identified by means of the technical plate placed on
the partition wall of the electrical cabinet.
MOD.
A
Vac
Hz
PH
kW
kg/h
IP
Date
Part No.
IP
Date
Part No.
Serial No.
Rev.
MADE IN ....
CAREL INDUSTRIES
Via dell'Industria, 11, 35020 Brugine
(Padova) Italy
Fig. 1.l
Note: tampering, removal, lack of the identification plate or other
does not allow the safe identification of the product and will
make any installation or maintenance operation to be performed difficult.
1.10 Water circuit
Models UR002 – UR013
31 2
5
4
7
8
6
9
10
16
13
17
12
11
19
18
15
14
Fig. 1.m
Models UR020 – UR080
16
1
5
7
12
19
17
14
13
9
18
6
Fig. 1.n
1 Anti-foaming sensor 11 Drain tube tempering (*)
2 Overfill diaphragm 12 Drain valve tempering (*)
3 Fill diaphragm 13 Inlet valve
4 Feed tank 14 Drain pump
5Electrodes for conductivity meas-
urement 15 Anti-adhesive film (**)
6 Equaliser pipe 16 Overtemperature sensors (PTC)
7 Feed pipe 17 Heaters
8 Fill-up pipe 18 Water temperature sensor (NTC)
(**)
9 Level sensor 19 Thermal insulation
10 Overflow pipe/drain
(*) for the units equipped with it
(**) for full option modules only

10
!
2
28
29
6
4
5
3
8
11
9
A
BC
25
24
13
12
10
26
21
20
18
17
19
27
1
30
7
14
16
15
30
22
23
ENG
“heaterSteam”+0300087EN - rel. 1.4 - 22.01.2021
1.11 Layout of models UR002 – UR0013
Fig. 1.o
Key:
1 Solid state relay (SSR) 20 Level sensor
A Green LED: normal operation
B Yellow LED: fill
C Red LED: minimum level
2 Motor protector (THP)
3 Fuse carrier (F1, F2)
4 Contactor
5 Transformer
6 Electronic controller 21 Fastening strap
7 Power cable terminal block 22 Heater
8 Pump fuse (F3) 23 Drain pump
9 RF interference suppressor (where envisaged) 24 Fill valve
10 Power cable gland 25 Drain tempering valve (where envisaged)
11 Fan control board 26 Feedwater tank
12 Auxiliary cable glands 27 SSR thermal protector (Klixon)
13 Cooling fan 28 X1-X2 (prepared for ventilated steam distributors connections)
14 ON/OFF switch 29 X3-X4 (prepared for external drain tempering valve) - where envisaged
15 Drain 30 Drain pump relay
16 Display
17 NTC probe socket
18 Boiler
19 Warning label

11
30
3
2
4
6
5
8
9
10
11
29
712
13
15
14
1
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
1.12 Layout of models UR020 – UR0080
Fig. 1.p
Key:
1 Display 20 Drain tempering valve (where envisaged)
2 SSR thermal protector (Klixon) 21 Drain tempering inlet (where envisaged)
3 Cooling fan 22 Level sensor
4 Solid state relay (SSR) 23 Boiler
5 Heater fuses (where envisaged) 24 Drain pipe
6 Contactor 25 Heater
7 Motor protector (THP) 26 Boiler thermal protector (Klixon)
8 NTC probe socket 27 Foam detection sensor
9 Transformer 28 Water fill
10 Control board 29 Drain pump relay
11 Fuse carrier (F1, F2, F3) 30 X3-X4 (prepared for external drain tempering valve) - where envisaged
12 Power cable terminal block
13 RF interference suppressor (where envisaged)
14 Power cable inlet
15 ON/OFF switch
16 Drain pump
17 Drain collection tank (∅19 mm)
18 Drain
19 Fill valve

12
ENG
“heaterSteam”+0300087EN - rel. 1.4 - 22.01.2021
2. HYDRAULIC CONNECTIONS
Important: before making the water connections disconnect the
humidifier from the power supply.
Models UR002..UR013 Models UR020...UR080
1
1
3
3
4
4 7
5
6
6
2
2
4
5
Fig. 2.a
WATER CONNECTIONS:
Important: for the Australian market and to meet Watermark
requirements, a Watermark approved double check valve must be
installed on the humidifier feedwater line when connected to the potable
water supply network. If, on the other hand, the humidifier is supplied
with water from a Carel reverse osmosis system connected to the potable
water supply network, the double check valve must be installed on the
inlet to the reverse osmosis system.
1. install a manual valve upstream (to cut off the water supply);
2. connect the humidifier to the water supply. For UR002...UR013 models,
use a flexible pipe 3/4’’G connection. For UR020...UR080 models
connect the flexible pipe with the non-return valve (supplied - code
FWHDCV0003), to avoid the water inside the humidifier making
contact with the one in the mains;
3. install a mechanical filter to retain any solid impurities (connect
downstream with respect to the tap.
4. connect a section of pipe for draining (resistant to temperatures of
100 ° C (212 ° F)) and with a minimum internal diameter of 40 mm
(1.6 in) for models UR002-UR013 and 50 mm (2 in), for models UR020
UR080; for drain tempering versions, water temperature will be 60 °C
(140 °F), with temperature is max 25 °C guaranteed;
5. provide a funnel to ensure continuity interruption in the drain piping;
6. connect a P-trap to prevent the return of odours;
7. for models UR020...UR080: connect a drain pipe from the tank to
the bottom of the humidifier (this can run into the funnel used for
draining).
8. for drain tempering versions, water temperature will be 60°C (140°F)
with temperature is max 25°C (77°F) guaranteed.
Caution:
• once the installation is complete, flush the supply pipe for about
30 minutes by carrying water directly in the drain and without
introducing it into the humidifier. This will eliminate any waste or
processing residues that could clog the inlet valve and/or cause foam
when boiling water;
• the drain pipe must run vertically downwards at least 30 cm (figure 2.a)
to prevent the return of steam.
Set up for water connections:
Models UR002..UR013 Models UR020...UR080
B
A
A
D
B
C
Fig. 2.b Fig. 2.c
Key:
A Supply water inlet (also drain tempering inlet for UR002-UR013)
B Drain water outlet
C bottom tank drain water outlet (only for models UR020-UR080)
D Drain tempering inlet

13
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
Water connection heights:
Drain / Fill
Models UR002…UR013 (view from below):
Fig. 2.d
mm (in)
D75 (2.95) E62 (2.44)
D’ 126 (4,96) E' 116 (4.57)
Water fill Water fill Water drain Water drain
Models UR020…UR080 (left side view):
L’
K
L
L”
I’
I
I”
J
Fig. 2.e
mm (in)
l50 (1.96) L' 230 (9.0)
l' 120 (4.72) L” 54 (2.1)
l" 20 (0.78) J132(5.2)
L122 (4.8) K571(22.5)
Water fill Water fill Water drain Water drain
Steam exhaust and condensate drain
Models UR002…UR013 (top view):
A1
A2
A3
Fig. 2.f
size mm (in) Models UR002-UR013
F 126.7 (5)
F' 224 (8.8)
G 137.9 (5.4)
G' 21.7 (0.85)
A1 Steam outlet
A2 Juncture for the steam distributor condensate drain pipe
A3 Fan head power cable passageway (ancillary)
Models UR020…UR080 (top view):
B1
B2
PP
Fig. 2.g
size mm (in) Models UR020...UR040 Models UR053-UR080
M 172 (2.0) 172 (6.8)
M' 31 (1.2) 52 (2.0)
N 273 (10.7) 260 (10.2)
N' --- 190 (7.4)
N" 46 (1.8) 52 (2.0)
P 60 (2.4) 60 (2.4)
B1 Set up for steam distributor condensate drain pipe
B2 Steam outlet

14
ENG
“heaterSteam”+0300087EN - rel. 1.4 - 22.01.2021
2.1 Supply water
The supply water for the electric heater humidifier must not be corrosive,
must not emit bad odours, and must not contain too much lime to
avoid excessive deposits. The water, supplied from mains of drinking
water or demineralised water, must have the following characteristics:
LIMIT VALUES FOR THE HEATER HUMIDIFIER WATER
Min Max
Specific conductivity at 20°C /68°fH σ20 - µS/cm 0 1500
Total dissolved solids TDS – mg/l (1) (1)
Fixed residual at 180°C/ 356°fH TDS – mg/l (1) (1)
Hydrogen ion activity pH 6 8.5
Total hardness TH– mg/l CaCO3 0 (2) 400
Temporary hardness mg/l CaCO3 0 (3) 300
Chlorides ppm Cl = 50(4)
Iron + Manganese mg/l Fe+Mn = 0.2
Silica mg/l SIO2 = 20
Residual Chlorine mg/l Cl- = 0.2
Calcium sulphate mg/l CaSO4 = 100
Metallic impurities mg/l 0 0
Solvents, diluents, detergents, lubricants mg/l 0 0
Tab. 2.a
1. Values depending on the specific conductivity; in general: TDS ≈0,93 * σR, 20
°C; R180 ≈0,65 * σR , 20 °C;
2. Not lower than 200% the content of chloride in mg/l Cl- ;
3. Not lower than 300% the content of chloride in mg/l Cl- ;
4. It could be necessary to intervene on the drain rate to avoid a concentration
in the boiling water higher than 300 mg/l Cl-;
For particularly aggressive water (conductivity <1 µS/cm), use titanium
heaters (heaterSteam titanium model).
Important: water treatment with polyphosphates or water
softeners is allowed, guaranteeing at least 60% of the initial
hardness value and no less than 5°f.
3. STEAM DISTRIBUTION
3.1 CAREL steam nozzles (SDPOEM00**)
Compact steam distributors for small ducts or applications such as steam
baths. They can be mounted either horizontally or vertically (steam
exhaust facing upwords).
Mounting instructions (see gure):
1. drill a series of holes in the wall of the pipe, using the drilling jig of
the distributor;
2. insert the distributor;
3. fasten the flange of the distributor using 4 screws.
31,5
50 50
31,5
50
31,531,5
57,5
100
C
C
B
AA B
D
Fig. 3.a
Key:
A. steam inlet
B. condensate drain
C.
steam outlet
The hole dimensions vary depending on the distributor model:
• model SDPOEM0000: hole to be drilled manually,
up to 30 mm (1.2 in) diameter;
• model SDPOEM0012: hole diameter 12 mm (0.5 in);
• model SDPOEM0022: hole diameter 22 mm (0.9 in);
D. drilling jig
Note: if using steam hoses with an inside diameter of 30 mm (1.2 in),
remove the 22 mm (0.9 in) inlet section from the steam nozzle.
3.2 CAREL linear distributors for air ducts or
AHUs (DP***DR0)
The steam distributors for AHU or duct applications deliver steam along
their entire length in order to ensure the shortest not-wetting distance.
The distributor should be chosen based on the maximum required
capacity, the dimensions of the AHU/duct and the outlet diameter of
the humidifier it is connected to. Install far from any obstacle (curves,
ramification, section changes, grilles, filters, fans).
Minimum distance between distributor and obstacle: 1…1.5 m (3.3…4.9 ft).
Increase distance in case of:
1. increase in speed of the air in the duct;
2. turbulence decrease.
Mounting instructions (see figure):
• drill a series of holes in the wall of the pipe, using the drilling jig of the
distributor (found in the packaging of the distributor);
• insert the distributor with the steam outlet holes facing upwards;
• fasten the flange of the distributor using 4 screws.
BY
X
A
X
°2
L
5
4
3
2
1
9
6
8
Fig. 3.b
Softened water reduces maintenance requirements.
Softened water favors the concentration of dissolved salts in the water
inside the boiler, with the consequence of foam formation.
Not recommended:
1. the use of well water, industrial water or water from cooling circuits
and, in general, water which may be chemically or bacteriologically
contaminated;
2. the addition to the water of disinfectants or anticorrosion
compounds, as these may cause irritation.
Note:no relationship can be proven between water hardness and
conductivity; nonetheless, as an indication only, water with a hardness of
40°f should have a conductivity of approximately 900-1000 mS/cm a 20 °C.
2.2 Drain water
• contains the same substances dissolved in the supply water, but in
larger amounts;
• it can reach a temperature of 100 °C (212° F);
• it is not toxic and can be drained in the white waters collection
system.
3. for drain tempering versions, water temperature will be 60°C (140°F),
with temperature is max 25 °C guaranteed.
Important: completely demineralised water is aggressive. For
connection to a water system with fully demineralized water use
only installation items made of plastic resistant to chemicals (eg.
Polypropylene) or stainless steel.

15
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
Key:
1. L-shaped mounting bracket (where applicable)
2. flange gasket
3. steam inlet (ØA)
4. condensate drain (ØB)
5. flange screw (see instructions sheet that comes with the distributor)
6. L = length (depending on the model of distributor, see paragraph
“Linear distributors”)
7. tilt angle (about 2 °) for condensate drain
8. diameter of the hole in the wall (ØY)
Size in mm (in)
linear distributors from CAREL
DP***D22R0 DP***D30R0 DP***D40R0
ØA 22 (0.9) 30 (1.2) 40 (1.6)
ØB 10 (0.4) 10 (0.4) 10 (0.4)
ØY 58 (2.3) 68 (2.7) 89 (3.5)
Ø 35 (1.4) 45 (1.8) 60 (2.4)
X 68 (2.7) 77 (3.0) 99 (3.9)
Tab. 3.a
Caution:
1. mount the distributor slightly tilted (at least 2°, to facilitate the
condensate discharge);
2. the L-shaped supports (see element 1 Fig. 3. b) is supplied with steam
distributors models from DP085* to DP205*. For shorter lengths the
bracket can be supplied as optional (code 18C478A088).
3.3 CAREL high-eciency linear distributors
for air ducts or AHUs (DP***RH)
CAREL high-efficiency linear distributors can be used wherever there is
the need to reduce condensate formation within the distributor itself.
All the information provided in the paragraph on linear distributors
still applies, while the dimensions and diameters corresponding to the
DP***RH distributor are shown below.
6
BY
X
A
X
°2
1
1
2
4
3
5
7
8
Fig. 3.b-1
Key:
1. “L” shaped fixing bracket (where featured)
2. flange gasket
3. steam inlet (ØA)
4. condensate drain (ØB)
5. flange screw (see the technical leaflet supplied with the distributor)
6. L = length (depending on the distributor models, see the paragraph
on“Linear distributors”)
7. slope (about 2°) for condensate drainage
8. diameter of the hole in the wall (ØY)
Dimensions in mm (in)
CAREL high-efficiency distributors
DP***D30RH DP***D40RH
ØA 30 (1.2) 40 (1.6)
ØB 10 (0.4) 10 (0.4)
ØY 68 (2.7) 89 (3.5)
Ø 45 (1.8) 60 (2.4)
Ø1 60 (2.4) 80 (3.1)
X 77 (3.0) 99 (3.9)
3.4 CAREL blowers for room installation
(VSDU0A*, VRDXL*)
Steam distributors for installation in rooms. These come with a fan
to assist steam absorption. The VSDU0A* blowers can be used on
humidifiers with flow-rates up to 18 kg/h (39.7 lb/h), i.e. models UR002…
UR013. They can be connected to the top of the humidifier, or separately
in a remote position using the fastening support VSDREM0003 (see Fig.
3.c). These distributors have a power supply inside the electrical panel (24
Vac, Terminals X1, X2).
30222190_002_R01
A
D
D
B
C
D
D
B
C
E
A
Fig. 3.c
Assembly (all dimensions in m [ft])
Ref. On top of the humidier Wall
A > 3 (9.8) > 3 (9.8)
B >1 (3.3) >1 (3.3)
C around 2.1 (6.8) around 2.1 (6.8)
D > 0.5 (1.6) > 0.5 (1.6)
E - ≤4 (13.1) Tab. 3.b
Note:
• the value of C may be lower when transiting in front of the blower is
not possible;
• see the humidification manual for details on positioning
Caution: in order to achieve proper steam distribution observe
the distances indicated in the fig. above.
For the humidifiers larger than 18 kg/h, the are ventilated steam
distributors code VRDXL00000 with 230 Vac power supply, external
power supply (maximum capacity 45 kg/h). The distributors are designed
for installation in a remote position, and require two steam hoses with a
30 mm diameter, c. Connected to a “Y” adapter (available as accessories,
contact Carel for details on the product code).
30222195_002_R01
D
D
B
C
E
A
Fig. 3.d
Assembly (all dimensions in m [ft])
Ref. Wall Ref. Wall
A >5 (16.4) D > 0.5 (1.6)
B ≥2 (6.5) E ≤4 (13.1)
C+E ≥2.1 (6.8) Tab. 3.c
Note:
• the value of C+E may be lower when transiting in front of the blower
is not possible;
• see the humidification manual for details on positioning
In this case, terminal J19.1 on the control board is used as a voltage-free
contact (normally open when there is no production - SSR OFF). This
contact has amaximum ratingof 2 A.

16
ENG
“heaterSteam”+0300087EN - rel. 1.4 - 22.01.2021
3.5 Steam transport pipe
• use CAREL flexible hoses (max 4 m long, see section“Models of steam
conducting pipes”);
• avoid the formation of pockets or traps (cause of condensate
accumulation)
• avoid choking the pipe with sharp bends or twists.
• Use metal clamps to fasten the ends of the pipe to the connections
on the humidifier and the steam distributor, so that they do not come
loose as a result of the temperature.
• avoid strains which include mechanical stress on the cylinder steam
outlet tailpiece
3.6 Condensate drain pipe
During the operation of the humidifier part of the steam can condense,
causing efficiency loss and noise (gurgling).
To drain the condensate connect to the base of the distributor a discharge
pipe with a water trap and a minimum slope of 5° (see fig.3.d).
CAREL condensate drain pipes: code 1312368AXX (ø 10mm) -
(CHOSE00516 (5/16”) for North American market) for DP* series linear
steam distributors; code 1312353APG (ø 7mm) - (CHOSE0038 (3/8”) for
North American market) for steam blowers and nozzles.
Caution: the condensate drain pipe trap must be filled with water
prior to turning on the humidifier.
Below are show some installation examples of the steam transport and
condensate drain pipes:
All the UR models
>5°
D> 200mm (8”)
>5°
R> 300mm (12”)
H ≤ 2 m (7.8”)
Fig. 3.e
Models UR002...UR013 (1), condensate drain connection with return
to ll tank:
>20°
>5°
1
D> 200mm (8”) R> 300mm (12”)
Fig. 3.f
Models UE020...UR080 (1) extend the pipe inside the humidier up to
the base tank.
>20°
>5°
1
D> 200mm (8”) R> 300mm (12”)
Fig. 3.g
All the UR models
NO
Fig. 3.h
SI
R>300mm (12”)
D> 200mm (8”)
R>300mm (12
”
NO
NO
D> 200mm (8”)
Fig. 3.i
3.7 Outlet pressure limits
The backpressure at the boiler outlet, either positive or negative, depends
both on the relative pressure in the duct/AHU and the pressure drop in
the steam pipe, due to bends or adapters, and the steam distributor.
Carel steam transport pipes have a pressure drop of around 150 Pa/m
(0.021psi) (respecting the maximum flow-rate recommended by Carel).
Carel DP* series linear distributors have a pressure drop of around 25 Pa
(0.003psi) (respecting the maximum flow-rate recommended by Carel).
Considering these values, the boiler outlet pressure must be:
boiler outlet pressure > 150 [Pa/m] * steam pipe length [metres] + 25 [Pa]
DP + pressure in duct/AHU [Pa]
Boiler outlet pressure values for heaterSteam:
UR002…R013 UR020…UR080
pressure limits at boiler outlet
Pa (PSI)
0 to 1500 (0 to
0.218)
0 to 2000 (0 to
0.290)
Note: a pressure of around -200 Pa (-0.029 psi) at the boiler outlet
corresponds to around 20 mm (0.78”) of water inside the boiler (for all
sizes).

17
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
4. ELECTRICAL CONNECTIONS
4.1 Wiring provisions
Models UR002-UR013
Outside, bottom view Inside, top view
3
1
1
3
Fig. 4.a Fig. 4.b
Models UR20-UR80
Outside, side view
1
3
2
Fig. 4.c
Key:
1. power supply cable inlet;
2. inlet (after removing the knock-out) for other uses;
3. probe cables inlet (after removing the knock-outs).
4.2 Power cable connection
Before making the connections, make that the unit is disconnected from
the mains power supply: move the main system switch and humidifier
switch to OFF).
Important: the humidifier ON/OFF switch disconnects power
only to the electronic controller, and not the other devices, which
therefore remain powered.
Check that the unit’s power supply voltage corresponds to the rated value
shown inside the electrical panel. Remove the front panel as explained in
chap. 1.
To enter the power and probe cables, see the follow the procedures
described below:
Models UR002-UR013
1. unscrew the screws and remove the cover (A);
2. if necessary, cut the top part of the conical cable gland (B) and insert
the power cable;
3. connect the electrical wires to the terminal block, reposition the
cover and fasten it using the screws;
To attach the probe cable:
4. remove the knock-out (C) and unscrew the screws;
5. insert the probe cable through the opening created: then fasten the
cable using the screws.
A
B
1
2
GND
L
N
3
Fig. 4.d Fig. 4.e
GND
L
N
C
4
GND
L
N
5
Fig. 4.f Fig. 4.g
Models UR020-UR080
1. identify the rubber cable gland (A) on the right side of the unit and
insert the power cable;
2. inside the electrical panel: unscrew the cable gland (B), connect the
wires to the terminal block and tighten the screws again to fasten
the cable.
GND
L1 L2 L3
B
A
Fig. 4.h
The humidifier power line must be fitted by the installer with a disconnect
switch and fuses to protect against short circuits. The table shows the
recommended sizes of the cable and fuses; nonetheless, these data are
purely indicative and, if different from local standards in force, the latter
must prevail.
Note: to avoid unwanted interference, the power cables should
be kept separate from the probe signal cables.
Important: connect the yellow-green wire to the earth terminal
(GND).

18
ENG
“heaterSteam”+0300087EN - rel. 1.4 - 22.01.2021
4.3 Control board
The control board (S) is inside of the electrical panel in the wall dividing.
The auxiliary connections (probes, remote terminal, alarm) are made by
inserting the cables form the outside into the electrical panel.
To do this, use cables gland located on the base of the unit to the plug-in
screw terminals on the control board.
UR002-UR013 UR020-UR080
S
S
Fig. 4.i
M2M9
1 2 1 123 1 2 3452121122123456
J17C
G
2 1
J17L J23 J24 J19J20J3 J16 M3 J18
2 1
J21
M8 M1 M5 M6M12
1 1234567821132 31221212
main probe
ext. regulator
GND GND
Remote
ON/OFF
limit probe
12Vdc
Control signal
Ethernet
GND
RS485 Serial
L+
L-
Alarm
relay
NO
NC
C
NO
C
Unit
status
relay
Fig. 4.j
Key:
Terminal Function Electrical specications
M1 M1.1 GND (G0)
M1.2 Controller power supply 24Vac +10%/-15% 50/60Hz
M2 M2.1 Main room probe signal
input or signal from external
controller
0/1V, 0/10V, 2/10V, 0/20mA,
4/20mA, NTC 10 kΩ a 25 °C
M2.2 GND
M2.3
Probe power supply (+G)
+12 Vdc, maximum current that
can be delivered 50 mA; Protec-
tion against short-circuits
GProbe power supply (+G) CAREL 0-10 V
M2.4 Digital input for backup/
rotation function
Maximum current output: 5 mA;
Maximum voltage with contact
open: 13 Vdc
M2.5 Limit humidity probe signal
input
0/1V, 0/10V, 2/10V, 0/20mA,
4/20mA, NTC
M2.6 GND
M2.7 GND
M2.8 Remote on/off contact
digital input
Maximum current output: 5 mA;
Maximum voltage with contact
open: 13 Vdc
M3 M3.1
Fieldbus
Tx/Rx-
M3.2 Tx/Rx+
M3.3 GND
M5 M5.1 Unit status contact (NO) 250 Vac; 2 A with resistive load;
2 A with inductive load
M5.2 Unit status contact
common
M6 M6.1 Alarm common 250 Vac; 2 A with resistive load;
2 A with inductive load
M6.2 NC alarm contact
M6.3 NO alarm contact
Terminal Function Electrical specications
M8 M8.1 Production request analo-
gue output
Output voltage range: 0-10 V
max 10 mA
M8.2 GND
M9 M9.1 Backup and rotation contact
common 250 Vac; 2 A with resistive load;
2 A with inductive load
M9.2 Backup and rotation NO
contact
M11 Ethernet port
M12 M12.1
BMS 485
Tx/Rx-
M12.2 Tx/Rx+
M12.3 GND
Earth connection
J18 pLAN/display terminal
J19 J19.1 Auxiliary/blower contact
(NO) 250 Vac; 2 A with resistive load;
2 A with inductive load
J19.2 Auxiliary/blower contact
common
USB Port (type A)
Ethernet RJ45 Port Tab. 4.c

19
ENG
“heaterSteam”+0300087EN - rel. rel. 1.4 - 22.01.2021
4.4 Operating and control principles
Before describing each electrical connection on heaterSteam, below are
some fundamental aspects regarding the control of steam humidifiers.
4.4.1 Operatingprincipleof aheater humidier
HeaterSteam is an isothermal steam humidifier whose technology uses
heaters immersed in a cylinder or boiler filled with water. This may be
mains water or demineralised water. The heat generated by the heaters
increases the water temperature up to around 100°C (212°F). The use of
demineralised water ensures long cylinder and heater life, as virtually no
scale builds up. On the other hand, if using mains water, some of the
minerals dissolved in the water accumulate in the cylinder as solids
with different compositions. To prevent this from occurring, when the
water conductivity in the cylinder exceeds a certain value, some of the
water is periodically drained and replenished, thus diluting the water. In
models where featured, the drain water is mixed with mains water so
as to not exceed the maximum temperature allowed by national and
local standards in force (drain tempering function). The steam generated
has a temperature of around 100°C (212°F) and minimal positive
pressure (unpressurised steam). It is virtually free of minerals and germs.
Steam production is controlled with ON/OFF logic or with continuous
modulation from 0% to 100% of rated output, using solid state relays
(SSR); the control logic in this case is PWM (i.e. pulse width modulation)
with a programmable time base.
4.4.2 Control principles
The appliance is fitted with solid state relays (SSR), meaning steam
production is continuously adjustable based on demand, in one of the
following modes.
4.4.3 ON/OFF control
Operation is all or nothing, and is activated by an external contact; the
maximum percentage of unit production can be set.
4.4.4 Proportional to an external signal (modulating
control)
Steam production is proportional to the value of an external signal Y,
(selectable by programming one of the following standards: 0 to 1 Vdc; 0
to 10 Vdc; 2 to 10 Vdc; 0 to 20 mA; 4 to 20 mA). The maximum production
Pmax corresponds to the maximum value of the external signal Y and
will be the humidifier’s rated production. The activation hysteresis hy is
settable by the user and refers to the external signal Y.
Pmax
Steam_Pr
Pmin
OFF ON
0% hy 2xhy 100%
Y
Y= 0…1Vdc
0…10Vdc
2…10Vdc
0…20mA
4…20mA
Fig. 4.k
Key:
Steam_pr Steam production Y External signal
P0 Max production hy Activation hysteresis
Pm Min production
Note: the graph shown above applies when the pre-heating
function is disabled.
4.4.5 Autonomous control with humidity probes
Steam production is related to the % rH reading made by the relative
humidity probe and increases as the value read deviates from the set
point St. Maximum production Pmax corresponds to the case where the
humidity value, read by the probe, is BP away (proportional band) from
the set point. The activation hysteresis hy is settable by the user.
Pmax
Steam_Pr
Pmin
OFF
ON
St
hy
BP
%rH
Fig. 4.l
Key:
Steam_pr Steam production Y External signal
P0 Max production hy Activation hysteresis
Pm Min production
To check that the relative humidity measured by the transducer is within
certain preset values, two alarm thresholds can be set in autonomous
control:
• high relative humidity alarm threshold;
• low relative humidity alarm threshold.
When these thresholds are exceeded, an alarm is activated by closing the
corresponding relay contact on the main control board.
4.4.6 Autonomous control with relativehumidity
transducer and outlet limitprobe
In this case too, the controller modulates steam production based on the
% rH measured by the main relative humidity transducer, while limiting
production if the humidity measured by a second limit transducer,
located in the air duct downstream of the steam distributor, approaches
the maximum desired value. Consequently, to prevent the relative
humidity of the outlet air from exceeding a value that is considered
excessive, the control module with autonomous control and limit
transducer can be set with a high relative humidity alarm threshold.
When this threshold is exceeded, the alarm is activated by closing the
corresponding relay contact on the main control board. The limit probe
allows steam production to be modulated depending on the specific set
limit differential.
4.4.7 Application for steam baths
In applications for steam baths, in which the control probe measures
temperature rather than humidity, the same rules apply as for
autonomous control with probe.
By setting control to temperature, the humidifier will continue to produce
steam until reaching the desired set point temperature inside the steam
bath, and consequently the desired saturation of the air (fog effect).
Recommended CAREL transducer: ASET030001 or ASET030000, or NTC
probes UEKNTC0*.

20
ENG
“heaterSteam”+0300087EN - rel. 1.4 - 22.01.2021
4.5 Steam production control signals
The humidifier features solid state relays (SSR) for modulating steam
production, and consequently capacity may range from 1 to 100% of output,
depending on control requirements. The humidifier can be connected via
RS485 serial or Ethernet connection to a remote supervisor. Depending on
the type of signal used, steam production can be enabled and/or managed
in different ways (ON/OFF or modulating).
Important: the probe inputs are protected against short-circuits,
and the maximum current delivered (M2.3) is 50 mA. Despite this, it is
recommended to configure the “Control type” before connecting the
probes to the terminals.
To help users configure the unit, a screen index is shown at the top right of the
display. The screen index corresponds to the sequence in each menu in order
to reach the specific page.
Screen
index
Fig. 4.m
Steam production can be started by:
HUMIDISTAT (ON/OFF operation):
• connect terminals M2.1 and M2.2 (production request) to a humidistat;
• short-circuit terminals M2.7 – M2.8 (jumper) to enable production;
• to enable ON/OFF operation, set:
Screen index Screen description Parameter
Ea01 Control type External ON/OFF signal
Ea04 Maximum production 0-100% of rated production
M2M9 M8
1 12345678212
Fig. 4.n
_________________________________________________________
HUMIDISTAT and REMOTE CONTACT (ON/OFF operation)
• connect terminals M2.1 and M2.2 (production request) to a humidistat;
• connect inputs M2.7 – M2.8 (enable) to a remote contact (e.g.: switch,
timer,...);
• to enable ON/OFF operation, set:
Screen index Screen description Parameter
Ea01 Control type External ON/OFF signal
Ea04 Maximum production 0-100% of rated production
M2M9 M8
1 12345678212
Fig. 4.o
Steam production can be enabled and controlled by:
EXTERNAL PROPORTIONAL CONTROLLER (modulating operation)
• short-circuit terminals M2.7 – M2.8 (jumper) to enable production;
• connect terminals M2.1 and M2.2 (production request) to an external
controller;
• to enable control, set:
Screen ind. Screen desc. Parameter
Ea01 Control type proportional to external signal
Ea03 Proportional band Set: Hysteresis (0-100%)
Minimum production (0-100%)
Maximum production (0-100%)
Ec01 Main probe type Select from: 0-1V, 0-10V, 2-10V, 0-20mA,
4-20mA
OUT
REF
M2M9 M8
1 12345678212
Fig. 4.p
_________________________________________________________
EXTERNAL PROPORTIONAL CONTROLLER and REMOTE CONTACT
(modulating operation)
• connect terminals M2.1 and M2.2 (production request) to a humidistat;
• connect inputs M2.7 – M2.8 (enable) to a remote contact (e.g.: switch,
timer,...);
• to enable control, set:
Screen ind. Screen desc. Parameter
Ea01 Control type proportional to external signal
Ea03 Proportional band Set: Hysteresis (0-100%)
Minimum production (0-100%)
Maximum production (0-100%)
Ec01 Main probe type Select from: 0-1V, 0-10V, 2-10V, 0-20mA,
4-20mA
OUT
REF
M2M9 M8
1 12345678212
Fig. 4.q
_________________________________________________________
EXTERNAL PROPORTIONAL CONTROLLER and REMOTE CONTACT
(modulating operation) with LIMIT PROBE
• short-circuit terminals M2.7 – M2.8 (jumper) to enable production;
alternatively connect terminals M2.7 – M2.8 to a remote contact (e.g.:
switch, timer,...);
• connect terminals M2.1 and M2.2 (production request) to an external
controller;
• connect the active limit probe to terminals M2.5, M2.3 (+12Vdc), M2.6
(GND);
Note: when using Carel 0-10V probe, connect the probe power
supply +(G) to terminal“G”on the board rather than terminal M2.3.
• to enable control, set:
Screen ind. Screen desc. Parameter
Ea01 Control type prop. to external signal with limit probe
Ea03 Proportional band Set:
Hysteresis (0-100%)
Minimum production (0-100%)
Maximum production (0-100%)
Ea06 Limit probe Set:
Set point (0-100 %rH)
Differential (0-100%)
Ec01 Main probe type Select from: 0-1V, 0-10V, 2-10V, 0-20mA,
4-20mA
Ec02 Limit probe type Select from: 0-1V, 0-10V, 2-10V, 0-20mA,
4-20mA
