Carlin EZ-Temp 90000B User manual

Microprocessor
TemperatureControls
EZ-Temp
TM
Instruction Manual
70 Maple Street East Longmeadow, MA 01028
Ph 413-525-7700 Fx 413-525-8306
Carlin Combustion Technology, Inc.
Te c h s u p p o r t 800-989-2275 carlincombustion.com
©Copyright 2008 — Carlin Combustion Technology, Inc.
Installer/servicer — Except where specifically stated otherwise,
this manual must be used only by a qualified service technician.
Read and follow all instructions in this manual and in the appliance
manual. Failure to comply with this or other requirements in this
manual could result in severe personal injury, death or substantial
property damage.
This symbol calls out a hazard that could cause severe personal
injury, death or substantial property damage if the instructions
given are not followed.
Wiring: Refer to EZ-Temp data sheet for wiring information.
Verify ratings: Verify the ratings of the control meet the require-
ments of the appliance as specified in the appliance instructions.
Refer to the EZ-Temp control data sheet for required electrical
supply and load ratings. Verify that the controls, wiring and instal-
lation comply with all applicable codes.
Electrical shock hazard: Disconnect power to appliance when
wiring or servicing any electrical component.
Scald hazard: Water hotter than 130°F can cause serious burns or
death. Follow water heating appliance manufacturer’s guidelines
when installing temperature limit controls - DO NOT install a control
that can be set at a higher temperature than specified. Also verify
that the installation includes all water temperature regulating
means needed to ensure the safety of building occupants, in
compliance with all applicable codes.
Verify operation: Test the controls/appliance to verify the appliance
operates as specified in the appliance manual before leaving the
installation.
E-Clamp Style with red sensor retainer plug

EZ-Temp Microprocessor Temperature Control — Instruction manual
– 2 – Carlin part number MNEZT Rev. 12/08/2008
Configurations
Carlin EZ-Temp components are available in the following configurations, allowing use
with existing wells in addition to EZ-Temp wells.
Surface-mount sensors are also available.
• Control kits
EZ-Temp controls mount to a standard 4x4 J-box or can be panel mounted.
Control kits include the control and sensor(s) (item 2) plus hardware needed
for mounting to an existing well (items 10 and 11). To obtain an EZ-Temp well
and hardware, obtain an EZ-Temp well kit, below.
• Well kits
EZ-Temp wells are available in the sizes shown below. Well kits include a
well (item 1), rubber sensor retainer (item 3), retainer washer (item 4), jam
nut (item 5), and J-box lock washer (item 8).
• Sensor Kits
Sensor kits include only the sensor (item 2). Sensors are available in single
and dual configurations (two sensors in the same assembly). For controls
that use multiple sensors, obtain separate sensor kits or a sensor kit and a
dual sensor.
Install sensor(s)
To install a new immersion well:
1. Turn off power to the appliance and close isolation valves.
2. Follow appliance instructions to drain the appliance so water line is below
the insertion tapping.
3. Remove existing well and sensor. Apply a small amount of pipe dope to the
new well and secure in tapping.
4. Insert EZ-Temp sensor into well and secure sensor in place as described in
the following.
5. Refill appliance with water, following appliance manual procedures.
When routing sensor wires, avoid sharp edges and use strain
relief bushings at penetrations to prevent movement or electrical
shorting of the sensor. Sensor wires are not low voltage, and must
be routed in conduit.
Configuration A: Sensor and well only
1. Insert the sensor into well (1) until the sensor (2) tip bottoms in the well
socket.
2. EZ-Temp well: Slide the rubber retainer (3) over the sensor wires until it
firmly contacts the sensor casing. Slide the retainer washer (4) and the jam
nut (5) over the wires. Thread the jam nut into the well until snug.
3. Existing well: Press the sensor retainer plug (11) into the well until it securely
holds the sensor wires, to prevent movement of the sensor.
Configuration B: Sensor, EZ-Temp well and J-box
1. Insert the sensor into well (1) until the sensor (2) tip bottoms in the well
socket.
2. Slide the rubber retainer (3) over the sensor wires until it firmly contacts the
sensor casing. Slide the retainer washer (4) over the wires.
3. Slide the lock washer (8), J-box (7), and jam nut (4) over the wires.
4. Thread the jam nut into the well and tighten to secure the J-box and sensor
in place.
Configuration C: Sensor, EZ-Temp well and J-box
1. Insert the sensor into well (1) until the sensor (2) tip botoms in the well
socket.
2. Slide the J-box (7) over the wires and secure the J-box in place by snapping
the retainer ring (10) onto the well shoulder.
3. Press the sensor retainer plug (11) into the well until it securely holds the
sensor wires, to prevent movement of the sensor.
Mount the control
1. Insert sensor wire terminals into the labelled openings on the back of the
control. Press into place firmly.
2. Attach the control to the 4x4 J-box or panel mount, as desired.
Wire the control
1. Control wiring (including sensor wires) must be routed through conduit
or electrical enclosures. Follow all applicable codes and the appliance
manual.
2. Follow the burner and appliance wiring diagrams to connect the control(s)
into the appliance limit circuit.
3. For specific applications, contact your Carlin supplier for further informa-
tion.
Set the control
1. Follow the appliance manual to set the correct limit temperature for the
appliance. To adjust the EZ-Temp control:
• Insertascrewdriverintothesettingslotandrotateuntiltheindicatorpoints
to the desired temperature.
2. Test the operation of the appliance and the new limit control(s) to verify
correct operation.
3. NOTE: EZ-Temp controls have a subtractive differential — control contacts
trigger when the temperature setting is reached. Contacts reset after tem-
perature drops below setpoint minus the differential amount.
