CARLO GAVAZZI SCTL55 User manual

SCTL55
Smart Configurator
for IO-Link devices
ENITDEFRESDAZH
Instruction manual
Betriebsanleitung
Manual de instrucciones
Manuale d’istruzione
Manuel d’instructions
Brugervejledning
UAB Carlo Gavazzi Industri Kaunas Raudondvario pl. 101 Kaunas LT-47184 Lithuania
使用手册

2
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
Table of contents
1. Introduction................................................................................................... 3
1.1 Validity of documentation.........................................................................................3
1.2 Who should use this documentation...........................................................................3
1.3 Safety information ...................................................................................................3
1.4 Service and warranty ..............................................................................................3
2. Structure ....................................................................................................... 4
3. Description .................................................................................................... 5
3.1 Contents of the box .................................................................................................5
4. Features ........................................................................................................ 6
4.1 General .................................................................................................................6
4.2 IO-Link interface......................................................................................................6
4.3 IODD file administration...........................................................................................6
4.4 Configuration file administration ...............................................................................6
4.5 Button function ........................................................................................................6
4.6 Electrical ratings......................................................................................................6
4.7 Battery info.............................................................................................................6
4.8 LED function ...........................................................................................................7
4.9 Environmental.........................................................................................................7
4.10 Approval and markings .........................................................................................8
4.11 Accessories ..........................................................................................................8
5. Unboxing ...................................................................................................... 8
5.1 Switch ON your SCTL55..........................................................................................8
5.2 Screen gestures.......................................................................................................8
6. Software ....................................................................................................... 9
6.1 Example of inductive sensor connected ......................................................................12
6.2 Example of capacitive sensor connected ....................................................................17

3
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
1. Introduction
This manual is a reference guide for Carlo Gavazzi Smart Configurator. It describes how to set up and use the product
for its intended use.
1.1 Validity of documentation
This manual is valid only for SCTL55 and until any new documentation is published. It describes the function and operation
of the product for its intended use.
1.2 Who should use this documentation
This manual contains all the information you need for commissioning and operating the SCTL55 and must be read and
completely understood by specialized personnel dealing with Configurator.
We highly recommend that you read the manual carefully before starting to use the SCTL55. Save the manual for future
use. The installation manual is intended for qualified technical personnel.
1.3 Safety information
Hospitals, electronic implants
and pacemakers
Do not use or place device near any medical device.
Anyone who is fitted with an electronic implant or pacemaker must hold the device
on the opposite side as a precaution when the device is on.
Radio Interference
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area can cause harmful interference, in
which case the user will be required to correct the interference at his own expense.
Fire hazard Do not leave your device near heat sources such as radiators or cookers.
Do not leave your device charging near flammable materials as there is a risk of fire.
Contact with liquid Do not expose the device to liquid or touch it with wet hands. Any damage caused
by liquid may be irreparable.
Batteries
The device contains Li-ion batteries. Do not disassemble the device. Do not destroy
the batteries. Never use battery that have been damaged. Leave batteries away from
magnetic objects as the latter might cause a short circuit (between the positive and
negative terminals of the batteries) and destroy battery and device. As a general
rule, you shoud not expose the batteries to very high or low temperatures, (below
0°C or above 45°C).
Shock and impact
Handle and use your device with the utmost care. Protect your device. Shocks and
impacts may damage it. Part of the device is made of glass and might break if the
device is dropped or is subject to severe impact. Do not touch the display with sharp
objects.
Maintenance Cleaning: dry cloth only.
Do not disassemble device.
General Protection provided by the equipment may be impaired if used in a manner not
specified by the manufacturer
1.4 Service and warranty
Not everybody is authorized to open the Smart Configurator. This operation is reserved exclusively for CARLO GAVAZZI
technical service personnel. Tampering of the SCTL55 by unauthorized personnel voids the warranty.

4
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
2. Structure
Power
Battery status
M8 3-wire
M12
M8 4-wire
LEDs
battery
indication
LEDs
state
indication
Micro USB port
Micro SD card port
5.5”

5
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
3. Description
The SCTL55 is the Industry 4.0 portable, self-powered and user friendly smart configurator for IO-Link sensors that accesses
your sensor data and manages its parameters. There is no need for a PC and dedicated software.
Through a 5.5” HD touchscreen display and dedicated Apps you can now:
• Have access to an advanced diagnostic, showing operating hours, number of detections, operating cycles and alarms
• Verify your sensor status, including current temperature, quality of run and process data
• Easily change the operating sensor parameters to better meet the process requirements (switchpoint mode, sensing
distance, timing functions, PNP/NPN/push-pull, NO/NC). It is also possible to add favourite parameters to the
homepage and create different user profiles (observer, maintainer, specialist).
• Automatically download IODD files, through Wi-fi. As soon as you plug the sensor to one of the 3 connectors on the
top of the device, if the IODD file is not already on the device memory, it automatically connects to the download area
and shows all the data of the sensor.
Thanks to these innovations you can now manage and optimize your sensor very quickly and improve your processes and
predictive maintenance.
3.1 Contents of the box

6
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
4. Features
4.1 General
Manufacturer Carlo Gavazzi UAB Industri Kaunas
Model number SCTL55
Body Polycarbonate
Dimensions (H x L x W) 62 x 222 x 90 [mm]
Weight 600 g
Screen size 5.5”
Shipping weight
(including bag etc.) 800 g
4.2 IO-Link interface
Supply voltage 24VDC +/- 20%
Max load 80mA/Short circuit protected
SIO2 output test Led indicated SIO2 (Standard Input Output 2) logic state (pull down only)
Incorrect polarity protection Yes
Connectors to sensor Plug types: M8 3-wire, M8 4-wire, M12
IO-Link protocol support IO-link v1.1
4.3 IODD file administration
Wifi Download IODD file via Configure App
Micro SD card (not inclulded) Import IODD file from Micro SD card
4.5 Button function
Battery status Short press will indicate battery level for 5 sec.
+ (plus) Reserved for future use
- (minus)
Power button Hold for 3 sec to power on / off your Smart Configurator
Short press to switch on / off the screen
4.6 Electrical ratings
Standard charger via micro USB 5V/1A or PC USB port
4.7 Battery info
Operating time
(connected to sensor)
Full operation: > 5 hours
Screen off: > 22 hours
Standby time Device completely off: 6 months
Internal batteries 3.8V/10Ah (2x3,5Ah + 3Ah) (LI-ION)
Charge time 5V/1A standard charger via USB mini connector: <10 hours
Battery expected lifetime 60% capacity after 500 cycles
4.4 Configuration file administration
Micro SD card (not inclulded) Save and load device configuration files
Internal memory Save and load device configuration files

7
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
4.9 Environmental
Operational environment To be used in indoor applications only
IP-rating IP30
Ambient air temperature Charging: 10 to + 35°C
Operating: 0 to + 40°C
Storage temperature 0 to + 50°C
Ambient humidity range Operating: 0 to + 90% non condensing
Storage: 0 to + 90% non condensing
Transportation test EN60068-2-31
Drop test EN62368-1:2014, T.7
Pollution degree 2
4.8 LED function
Battery LEDs (green)
Flashing
When the device is connected to power, it flashes from the first LED
on the left to the other LEDs on the right and indicates that the main
battery is being charged.
Steady on
After briefly pressing the battery status button, it indicates the status
of the charge of the main battery. Each LED indicates around 20%
of the charge.
Flashing The main battery is almost discharged. Please recharge your device
Power LED (green)
Steady on The device is switched on
IO-Link LED (green)
Flashing IO-Link communication is ready, the sensor is not connected or it does
not have IO-Link communication enabled
Steady on IO-Link communication is established with the IO-Link sensor connected
Error LED (red)
Flashing Error (short circuit, data transmission error, overload)
SIO2 LED (orange)
Steady Status of the switching input output 2 of the sensor
USB LED (orange)
Steady Micro USB port is connected to a PC

8
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
5. Unboxing
5.1 Switch ON your SCTL55
To switch on your smart configurator, press and hold the power key button for 3 seconds.
5.2 Screen gestures
Touch: touch an item once. For example, touch to select an option
Swipe: swipe your finger on the screen vertically to scroll through a list or horizontally to
change a value
4.11 Accessories
Micro USB power adapter
(not included)
DC 5V/1A (current limited).
Only suitably rated and approved USB charger should be used with the
equipment as per the National Regulations for the country of use. Marked as
LPS (according to IEC 60950-1) or PS2 (according to IEC 62368-1).
Using any other may affect the safety of the equipment.
Contact the manufacturer if in doubt
Extension cable 0.5m M12 to 4 hooks, included
Protective holster Included
Lanyard Included
Micro USB cable Included
Quick start guide Included
4.10 Approval and markings
General reference EN62368-1
Radio ETSI EN 300 328 v2.1.1
FCC
EMC CFR 47 Parts 15.107 & 15.109
Radio CFR 47 Part 15 Subpart C
Contains FCC ID: 2AH8Q-HT17
Approvals

9
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
6. Software
Home screen
Settings
Wi-Fi switch
Store
Configure app
STEP1: settings > Wi-Fi
Select WiFi
Select settings Select to turn on the
Wi-Fi and select one of the
networks available from the
list, to connect the device to
internet. If requested, insert the
password
Time and date

10
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
STEP2:store > update
Keep your smart configurator up to date
and accept available software updates to
get new and enhanced features
Select the store
STEP3:configure app
Select the icon to start

11
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
STEP4:connect your sensor
Back to home screen
IODD file not found in the device
Press the icon to download it automatically
from internet
Sensor not connected
Sensor unrecognized
IODD file editable, wait..
Warning:
It is possible to connect only one sensor at a time

12
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
Parameterization Close Configure App and
go back to home screen
6.1 Example of inductive sensor connected
Process data
Graphic of set point
Create a user: parameterization > settings > users
Favourite parameters
Main icons
Select parameterization Select users, then to add
a user with a specific role
Select settings
Roles
Functions Observer Maintenance Specialist
Identification ✓✓✓
Observation ✓✓✓
Diagnosis ✓✓✓
Parameter Basic ✓ ✓
Advanced ✓

13
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
IODD options: parameterization > settings > IODD
Select settings Select IODD
Delete or update the
existing IODD file
Refresh the IODD
index
Project options: parameterization > save, load or write
Touch to open a saved
project
Select the project to open and
touch
Save, load or write
a project
Delete, rename or
load a project
List of projects

14
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
Switching output setup
Select + SO
Select ▼to change
Select +to change
Scroll vertically to find the
desired parameter
Process data
Select + details
Example of SO active
Example of SO active
Information:
Please scan the QR code on the right or press the link below to understand all the possible
settings via IO-Link for our inductive sensors
http://www.productselection.net/MANUALS/UK/IOL_IM.pdf
Command icons

15
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
Command icons
Touch this to activate the live mode
When the live mode is turned on, the changes are written automatically into the sensor
Touch this to read the parameters of the sensor
Touch this to write the changes into the sensor
Attention:
Remember to push after each change if mode is not
Touch this to go ahead
Touch this to go back to the previous parameter
Add a parameter to the favourite list
Scroll vertically to find the
desired parameter, for
example “So” (source)
Swipe left and press
to add it to the favourites list
Favourite selection saved

16
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
EN
Delete a favourite parameter
Touch the arrow to open
the list
Scroll vertically to find the
icon, then touch it
Touch to delete it
Use a main icon
Touch the number to change,
for example “3” of divider
Select the icon To change the value:
Touch “3” and digit via keypad
the correct value, or...
Swipe horizontally, or...
Touch + or - to change by 1, or
touch +or -to change by 10
Attention:
Remember to push after each change if mode is not

17
EN
Rev. 0 - 01/2019 | SCTL55 Smart congurator | © 2019 | CARLO GAVAZZI Industri
6.2 Example of capacitive sensor connected
Options Close Configure App and
back to home screen
Process data
Graphics of set point
Favourite parameters
Main icons
Information:
Please scan the QR code on the right or press the link below to understand all the possible
settings via IO-Link for our capacitive sensors
http://www.productselection.net/MANUALS/UK/MAN%20CA18-30%20IO-LINK%20MUL.pdf
