UDM 35/40 Digital Panel Meter
Programming Guide

UDM 35/40 PANEL METER USER MANUAL
1
Index
Description 2
Programming Fundamentals 3
Access to Programming Mode/Password Protection 4
Programming 5-18
Inputs 5-6
Temperature Compensation 6-7
Display Configuration 7
Scaling the Inputs 8
Decimal Point Position 9
Display Span Configuration 9
Linearization 11-12
Alarm Set Point Configuration 12-16
Digital Filtering 16-17
Analog Output/Retransmission of Display Value 17-18
Serial Port Output 18
Fahrenheit/Celsius Conversion 19
External Command Function 20
UDMSoft User Guide 21

UDM 35/40 PANEL METER USER MANUAL
2
UDM Description
The UDM 35/40 series is a universal Digital Panel Meter that has been
developed to meet the most advanced application requirements. The UDM 35
offers:
• Quick assembly and maintenance using plug & play modules
• Quick & easy parameter programming and parameter cloning to
other UDMs by means of UDMSoft or PC HyperTerminal
• Powerful variable control by means of up to four (4) alarm outputs
• Alarms can be up-down functions with automatic reset, up-down
with manual reset, and down alarm with disable function at power-
up.
The UDM 40 offers the same features as the UDM 35, with the following
additional benefits:
• Display color adaptable to Green, Red and Amber
• Management of non-linear signals using the available 16-point
linearization capability
• “Alarm status at a glance” using a sequence of display colors that
can be programmed by the user

UDM 35/40 PANEL METER USER MANUAL
3
UDM 35/40 Programming Fundamentals
There are no jumpers to consider when programming the UDM 35/40. The
programming mode allows the user to define all of the instrument’s parameters.
Shown below are a description and the UDMxx display symbol for each basic
parameter grouping:
• Password for access to programming
• Input Probe Selection / Signal Range (current, voltage,
temperature, resistance)
• Cold Junction Compensation
• Display Selection (diSP)
• Display Color (CoLr)
• Scaling of Input Value
• Input Signal Linearization
• Alarm Set-Point (SP1 – SP4)
• Digital Filtering
• Analog Output Scaling
• Serial Port Configuration
• External Command from Input Contact

UDM 35/40 PANEL METER USER MANUAL
4
Access to Programming Mode
Press and hold for 2 seconds. Display will indicate (password).
Within 2 seconds, four zeros “0000” will be displayed as follow:
This is your prompt to enter your password. Each individual digit is selected from
left to right by toggling the key. Changing the value of each digit is
accomplished using the and arrows. When completed, press to
confirm this step. If the password you entered is not correct, you will not be
allowed access to program. Factory default password is set to “0000”.
Note: Choice of a password value is significant. Values from “0000” to “4999”
protect direct access to both set points and all other parameters. A password
value from “5000” to “9000” allow direct access to alarm set points only.
Negotiating the Programming Menu
After password is verified, you are in the Programming Mode. After
approximately 20 seconds, the unit will revert to RUN mode if no further entry is
made. Movement across the flow chart (see product carton instruction sheet for
BD35 and BD40) to a specific parameter heading is accomplished using the
and arrow keys. Pressing the UP key tabs from left-to-right across the flow
chart. Pressing the key tabs from right-to-left. Upon reaching the desired
parameter to configure, press . The display will indicate the current setting for
the first sub-parameter in this group. Each successive will scroll through the
remaining sub-parameters. To change a setting, press the or keys when a
value of a sub-parameter is displayed, followed by to confirm the change and
advance to the next sub-parameter.

UDM 35/40 PANEL METER USER MANUAL
5
Programming the Input Modules
Press and hold for 2 seconds. Display will indicate PASS (password). Within
2 seconds, four zeros “0000” will be displayed. This is your prompt to enter your
password. If zero “0000” is your password, simply press to confirm. You
have approximately 20 seconds to begin programming before the unit reverts
back to run mode. (To enter a unique password, see Access to Programming
Mode, above.)
Input Selection
Press the key once to advance to Input
When the TRX module is installed, you must first indicate probe choice:
TRX input modules offer three Probe (Prob) choices: thermocouple* (tc),
RTD (rtd), plus resistive (rES). Use or keys to make selection.
Press . Use keys to select Range (r1, r2, r3, r4, r5, r6) according
to table below and on instruction sheet. Press .

UDM 35/40 PANEL METER USER MANUAL
6
LSX and HSX input modules offer True RMS (trnS) or DC measurement
(dC). Use keys to make selection. Press .
Press keys to select Input signal integration time value (intt).
If all zeros “0000” is selected, “Auto” will be displayed and the value will be
automatically calculated from 100ms – 999.9 ms. Press to confirm.
Press to advance to next program step sequence.
Cold Junction Compensation (CJC) Temperature Compensation
Available only when TRX input module is installed.
TRX module with Thermocouple (tC) requires configuration of Cold
Junction Compensation (CJC). Press key to advance to CJC Then
to enter.

UDM 35/40 PANEL METER USER MANUAL
7
Press key to select Auto (Auto). Press to confirm. . Press to
advance to next program step sequence.
Manual compensation should only be used in special applications. Consult
factory.
Configuring the Display (diSP) UDM35 only
UDM 35 (BD35) base unit displays may be configured as 3 ½ digit (1999)
or 3 digit + dummy zero (9990). When “diSP” is displayed, press .
Then press keys to make selection. Press to confirm. Press
to advance to next program step sequence.
Selection of Display Color (CoLr) UDM40 only
UDM40 (BD40) base unit offers three display colors. When “CoLr” is
visible on the display, press .
Use keys to select RED (rEd), Orange (orAn) or Green (GrEn).
Press to confirm. Press to advance to next program step sequence.

UDM 35/40 PANEL METER USER MANUAL
8
Scaling the Inputs
When is displayed, access is available for configuring the
electrical input range, the decimal point position and display span as
follows:
Electrical Input Range (HiE and LoE)
Allows the operator to define an electrical input range different from the
standard range setup at the “inP” programming step. As example, a UDM
with a full-scale 20mA (19.99mA) setting, it is possible to select an
electrical input range from 4.00mA (Lo.E) to 19.99mA (Hi.E) by
proceeding as follows:
When is displayed, press . “LoE” will appear.
Using the key, toggle to select a digit, then press the or key to
choose the desired value. Using the key, repeat as necessary until all
digits have proper values. Press .
“HiE” will now appear.
Using the same procedure as above, toggle through the digits using the
key and choose the desired values with the or key. Press to
confirm and advance to the next parameter, Decimal Point Position.

UDM 35/40 PANEL METER USER MANUAL
9
Decimal Point Position (dP)
The decimal point position is relative to the Display Value, which will be
discussed next.
When “dP” is displayed, press . Using the and keys, select the
decimal point position and press to confirm and advance to next step,
“Lod” and “Hid”, the display span parameters.
Display Span (Lod and Hid)
Allows the user to define the actual display span (in engineering units)
corresponding to the previously defined electrical input range (HiE and
LoE). The “Lod” value represents the minimum displayed value; “Hid”
represents the maximum displayed value.
When “Lod” appears, press key to toggle to proper digit. Use the
and keys to select desired value. Repeat procedure until all digits
have been set, press to confirm and advance to the next step, “Hid”.
Repeat the same procedure to select and confirm the “Hid” values. Press
to confirm. Press to advance to the next program step sequence.

UDM 35/40 PANEL METER USER MANUAL
10
Linearization
Introduction
When is displayed, a signal from a non-linear transducer-sensor
may be modified by setting the input (in. 01 – in. 16) and output (ou. 01 –
ou.16) linearization points so that the accuracy of the displayed value is
maximized. This programming step is available when using the UDM40
and LSX/HSX input modules only. On the illustration below, the nominal
output characteristics of an analog inductive proximity sensor is 4-20mA.
Note the non-linear curve. The nominal characteristics need to be divided
into a number of segments. In this example, we can divide the curve into
9 segments (9 segments + 1) corresponding to the vertical axis. The
menu must be activated and the number of linearization points
set (10 in this example). Then the input/output coordinates must be
determined and entered into the program. In this example, going from
right to left on drawing, Input 1 (shown on drawing as “1.0”; displayed as
“in.01”) = 4. Output 1 (displayed as “ou.01) = 1.0. Likewise “in.02” (shown
on drawing as 0.9) =4.5, ou.02=0.9……Fast-forward to “in.09”=12,
ou.09=0.2, and “in.10”=20, “ou.10=0.1.
It is important to note that the first and last linearization points must
correspond to those points defined in the scale menu . In this
example: “in.01”= LoE, “ou.01”=Lo.d, “in.10”=HiE, “ou.10”=Hi.d.
Inputs are noted on the “X” axis and the analog current values along the
“Y” axis. Input 1.0 has a value of 4. The second input, 0.9, has a value of
4.5, etc.

UDM 35/40 PANEL METER USER MANUAL
11
Navigating & Programming within the Linearization Menu
As appears, press followed by and keys to choose to
ignore or enable linearization . Press to confirm your choice
and advance to next step. If you chose YES, you will be prompted to
enter the number of Linearization Points, using the escape
button to select the position, and the up /down buttons to select
the numerical value, from 01-16. Press enter to confirm and advance.
Next, the correlation between the inputs and outputs must be defined in
the program.
“In.01” will be displayed. Press to toggle through the positions, and
use the and keys to select the value. Press to confirm and
advance. “Ou.01” will display next. Again, using the escape key ,
toggle to the appropriate position. Use the and keys to select the
value. Press enter to confirm and advance. Repeat this procedure for
each set of Inputs and Outputs, up through a maximum of 16. Press the
enter key to confirm. Press to advance to the next program step
sequence.
Alarm Set-point Programming
Up to 4 alarm set-points may be configured. You may configure each set
point using the following parameters, in order, as shown below:
Minimum set-point limit
Maximum set-point limit
Set-point setting

UDM 35/40 PANEL METER USER MANUAL
12
Hysteresis selection
Off-Delay Value (0-255s)
On-Delay Value (0-255s)
Relay Selection (normally energized or de-energized)
Alarm Type (off, down, up, up with latch, down with latch)
Color of display during alarm (red, orange, green, none)
If “none” is selected, basic display color remains.

UDM 35/40 PANEL METER USER MANUAL
13
Navigating through this program sequence
Minimum Set-Point
The lowest value, below which, it is not possible to program a set-point.
When is first displayed, you have reached the Set-point program
sequence. Press to enter program. The first parameter, Minimum Set-point
Limit, will be displayed. To skip this step and advance to the next
parameter, press the enter key . Otherwise, press the escape key to
select the proper numerical position to enter a value. Press the up/down arrow
keys to select the numerical value for each position. When completed,
press enter to confirm and advance to next programming sequence.
Maximum Set-Point
The highest value, above which, it is not possible to program a set-point.
Maximum Set-Point Limit . Using the same procedure as above,
press the escape key to toggle to the appropriate position. Then use the
up/down arrows to select the appropriate value for each position. Press
to confirm your choice and advance to the next programming step.
Set-Point
The actual value that must be reached to trigger an output.
When is displayed, press the key to toggle to the desired numerical
position. Use the keys to select the appropriate value for each position.
Press to confirm and advance to the next parameter in the program
sequence.

UDM 35/40 PANEL METER USER MANUAL
14
Hysteresis
The point at which an active alarm output must revert to for the alarm output to
turn off. Example: If an “up” alarm set point is “10.5”, and you want to have the
alarm reset at “10.3”, then the Hysteresis value to set in the program must be
“.2”, not 10.3. You need not be concerned about whether that value is to be in a
positive or negative direction. That is automatically configured when you select
the Down Alarm or Up Alarm.
When Hysteresis is displayed, use the key to toggle to the desired
numerical position. Using the keys, select the value for each position.
Then press to confirm and advance to the next step.
Off Delay
When Off Delay is displayed you may opt to choose a value of 0-255
seconds. Use the key to toggle to the desired position and select the correct
value with the keys. Press enter to confirm and advance to the next step.
On Delay
When On Delay is displayed, you may opt to choose a value of 0-
255 seconds by using the same procedure as Off Delay.
Relay Configuration
The set point alarm relay may be configured as “Normally Energized or Normally
De-Energized”. When is displayed, press either or key to make
your choice. Press to confirm and advance to the next step.
The configuration of Alarm type allows for selection of “OFF” or disabled, “DOWN
alarm”, “DOWN alarm with disable at power on”, “UP alarm”, “UP alarm w/latch”,
“DOWN alarm w/latch”. When the displays shows use the
keys to make your choice. Press to confirm and advance to the next step in
the sequence.

UDM 35/40 PANEL METER USER MANUAL
15
Configuring the Display Color for Alarm Event (UDM40/BD40 only)
When is displayed, the color of the display may be set to be RED,
ORANGE, or GREEN during the alarm event. Selecting NONE results in the
basic display color being used during alarm event. Use the keys to make
your selection and press to confirm. Press to advance to the next
program step sequence.
Digital Filtering
The digital panel meters are extremely fast to follow the trend of input signals and
to display the relevant values. Unlike in analog panel meters, which tend to filter
the input and present a more stable indication, the fluctuations in digital panel
meters can be quite fast and prevent the user from clearly reading the displayed
value. Fluctuations can also be introduced when the resolution of the displayed
value is higher than the input resolution. The use of a digital filter results in
higher stability of the displayed value.
There are two types of filter parameters.
The first is and it defines the operating range of the filter. Generally,
Fil.S represents the resolution (in digits) wanted to assign to the display. It is
suggested to set this parameter to evaluate the amplitude of the fluctuation on
the display and use this value as Fil.S. If, for example, a display value fluctuates
between 2.5 and 3.4, it means that the fluctuation is 9 digits and the Fil.S must
be set as “9”.
When is displayed, you may elect to program filter values by pressing the
key. This results in being displayed. Using the key, toggle to
the desired position and select the value to enter by using the keys. Press
to confirm and advance to the next step in the sequence.

UDM 35/40 PANEL METER USER MANUAL
16
The second filter parameter is . It represents the filtering coefficient.
The higher the value of Fil.C, the smoother the curve of the displayed value.
There is no theoretical rule to define this parameter, but it is suggested to start
with the same value of the Fil.S coefficient and then increase it until the desired
stability is reached. The digital filter affects the values retransmitted via both
serial communications and analog output.
Once is displayed, use the key to toggle to the desired position.
Use the keys to select the value to enter. Press to confirm. Press
to advance to the next program step sequence.
Analog Output Programming
Many times the displayed value must be retransmitted as an analog output. The
relationship between parameters is as follows:
Low Display Value >>>>> Low Analog Output
High Display Value >>>>> High Analog Output
To assure proper coordination and retransmission, it is important to note that the
parameters are programmed as a percentage of the analog output full scale
value (20mA or 10 Vdc) according to the TYPE selection (see below). Therefore,
to set 4mA as Lo.A, the correct value to be entered must be 20 (20% of the full
scale 20mA range). The Hi.A must be 100 (100% = 20mA). Because of this
programming technique, it is possible to set a reverse slope analog output
characteristic.

UDM 35/40 PANEL METER USER MANUAL
17
Programming example:
Retransmit a 4-20mA signal proportional to the following displayed values:
Lo.D = 0 and Hi.D = 18.
When is displayed, the Analog Output program may be addressed. Press
to enter sequence. is displayed. Press to toggle to the first
position. Use the keys to select value “0”. Press to toggle to the left to
“tens” position. Using keys, select value “2” and press enter to confirm
all choices and advance to the next program sequence.
will be displayed. Press to toggle to “hundreds” position and use
keys to select “1”. Press to toggle to each remaining position and
select “0” for each. When completed, press to confirm and advance to the
next program sequence.
will be displayed. Using the keys choose either “A” for 20mA
output full range, or “U” for 10v output. In this example, the selection would be
“A”. Press to confirm. Press to advance to the next program step
sequence.
Serial Port Output
When is displayed you may elect to configure a serial port address and
baud rate. Press . will be displayed. Using the key, toggle to the
desire position and select the proper value(s) using the keys. Press to
confirm.
When is displayed, use the keys to select the desired baud rate
indicated in kbits/sec. Press to confirm. Press to advance to the next, and
last, program step sequence.

CONVERTING CELSIUS TO FAHRENHEIT
The UDM35/40 digital panel meters use the Celsius temperature scale.
However, the displayed value can easily be scaled to indicate Fahrenheit values
by using the following guidelines:
The LoE and HiE are always expressed as Celsius values.
To display Fahrenheit values, manually convert the LoD to a Fahrenheit value
and then convert the HiD to a Fahrenheit value.
Ex:
LoE is 0
HiE is 100
Manual conversion to Fahrenheit:
LoD would be 32 (F)
HiD would be 212 (F)

UDM 35/40 PANEL METER USER MANUAL
18
External Command Function
When is displayed, the user may elect to dedicate a Command signal
(contact closure) from the input module, terminals 6 & 7, to perform one of the
following:
C1 HOLD Function
C2 Disable-Keypad
C3 Reset latch Alarms
Press to select Command sequence. Choose either C1, C2 or C3 by using
the keys to make your selection. Press to confirm.
