Operator’s Manual
Model 59 Wire Prefeed
&Dereeler
Production Wire Processing Equipment
Website: www.carpentermfg.com • Email: wire@carpentermfg.com

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 2
Table of Contents
Introduction ...................................................................................................................3
Important Notice............................................................................................................4
Safety Notice .................................................................................................................5
Applications and Machine Specifications...................................................................6
Section 1–Assembling the Model 59 .........................................................................7
Section 2–Material Setup..........................................................................................12
Loading Material onto the Dereeler Axel Assembly...................................................12
Loading Material into the Model 59............................................................................13
Section 3–Machine Setup and Operation................................................................18
Section 4–Maintenance Procedures........................................................................19
Feed Belt Change......................................................................................................19
Section 5–Recommended Spare Parts and Optional Accessories.......................20
Input Roller Guide Assembly.....................................................................................20
Prefeed Stop Interface...............................................................................................21
Section 6–Warranty...................................................................................................22

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 3
Introduction
Thank you for choosing Carpenter Mfg. Co., Inc. for your wire processing equipment
needs. For over 60 years Carpenter has been a leader in wire processing technology
and service. As an independently-owned, third generation company our philosophy has
always been to provide the customer with both quality products and outstanding service.
We look forward to a long, healthy relationship with you and our company.
The Model 59 Wire Prefeed & Dereelercan process a wide range of material, as
referenced on the following pages. These processing specifications are based upon the
most commonly manufactured materials. Special applications may arise with materials
that are within the specification limits of the machine but are very difficult or
unsuccessful to process. Likewise, materials that exceed the specified limits of the
machine may sometimes be processed successfully. Because there are many
variables involved in wire processing, we strongly recommend a free material
evaluation, to be completed at our factory (http://carpentermfg.com/wire-evaluation/). A
demonstration from a Carpenter representative is also recommended to ensure the
ultimate success of your material processing application.
This operating manual explains how to operate the Model 59 Wire Prefeed & Dereeler.
To ensure the best performance of your machine, read this manual carefully until you
familiarize yourself thoroughly with its operation and features. After you have read
through the manual, keep it available for reference.
Use this manual as a quick and handy reference tool for clarifying any questions that
may arise. If you have any questions about this machine or service please let us know.
Our phone number is (315) 682-9176; we may also be reached by fax at (315) 682-
9160. Visit our website (www.carpentermfg.com), or contact us via email
Carefully unpack the Carpenter Model 59 Wire Prefeed & Dereeler. We recommend
that you keep the original box and packaging as it will protect the machine for future
transportation, if necessary.

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 4
Important Notice
The products in this shipment left our facility in good working condition. Their safe
delivery is the responsibility of the carrier that delivered this shipment to you. Our
stated shipping terms are F.O.B. our facility at 110 Fairgrounds Drive, Manlius, NY
13104. According to applicable laws, the responsibility for this shipment was
transferred to you as soon as the carrier accepted the goods at our warehouse. If
concealed damage is discovered after unpacking this shipment, you must submit a
damaged freight claim with the carrier. Carpenter Mfg. Co., Inc. cannot submit your
claim for you. In order for you to collect for concealed damage, the carrier must be
notified with 5 days of the date you receive this shipment. You must leave the damaged
items and packing material as is (i.e. return all merchandise and all packing material to
the shipping container) until the claim has been inspected by the carrier. It is also
important to note that the carrier will not accept a claim if the goods have been moved
from the point of the carriers’ delivery to another street address. If you have any
questions or problems, please give us a call at (315) 682-9176, or email us at

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 5
Safety Notice
CAUTION
The Model 59 is equipped with a polycarbonate safety
guard. The safety guard contains a safety interlock
switch. The machine will not operate unless the safety
guard is installed and in the closed position.
**IMPORTANT**
Do not attempt to defeat the function or purpose of the
safety interlock switch. Serious injury to the operator’s
eyes, fingers or other body parts may result from attempts
to operate this equipment with the safety guard in the
raised position.

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 6
Applications and Machine Specifications
Applications
The Model 59 is designed to dereel material before being fed into a benchtop wire
processing machine. With its powerful belt feed material transport the Model 59
eliminates the strain of pulling material from heavy spools, thus improving the accuracy
of your wire processing equipment.
Machine Specifications
Maximum Feed Speed
550 feet per minute (9.16 feet per second)
Maximum Spool Weight
110 pounds (49.90 kilograms)
Maximum Spool Diameter
28” (711.2mm)
Maximum Spool Width
14” (355.6mm)
Maximum Material Size
0.437” (11.1mm) OD, round material
Drive Motor
1/8 HP
Electrical Connection
115 VAC, 60 Hz, 2 AMP (Standard)
230 VAC, 50 Hz, 1 AMP (Optional)
Dimensions (Includes Dereeler Stand)
26” x 32” x 17” (660.4mm x 812.8mm x
431.8mm) [L x D x H]
Weight
111 pounds (50.35 kilograms)

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 7
Section 1 –Assembling the Model 59
The Model 59 is shipped partially disassembled to allow for save travel. Assembly of
the unit is very straightforward.
Follow the steps below to assemble the Model 59.
1. The PN 5269 dereeler stand assembly is shipped in its own box. Remove the
stand assembly from the shipping container. (This box may also contain [1] PN
8019 power input cord, the machine dereeler axel assembly, and any other
purchased spare parts. Remove these parts if necessary.)
2. Carefully remove the Model 59 from its shipping container and place it on a flat
surface. (If the box in Step 1 above did not include the mentioned loose items,
this box will. Remove these parts if necessary.)
3. Looking at the front of the Model 59, locate (4) PN 5429 button head screws and
(4) PN 7188 washers on the left side of the machine cabinet. Using a 3/16” hex
wrench, remove these screws and washers. Refer to Figure 1 below.

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 8
Figure 1: Mounting Holes for PN 5269 Dereeler Stand Assembly
4. Position the PN 5269 dereeler stand assembly so that the two upper and two
lower mounting plate holes line up with the holes on the machine cabinet. Using
a 3/16” hex wrench, reinstall (4) PN 5429 button head screws and (4) PN 7188
washers removed in Step 3 above. Refer to Figure 2 below.
PN 5429 Button
Head Screw (4)
and PN 7188
Washer (4)
PN 5508 Circuit
Breaker

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 9
Figure 2: PN 5269 Dereeler Stand Assembled onto Model 59
5. Position the dereeler axel assembly into the PN 5294 dereeler frame axel tube
on the top of the PN 5269 dereeler stand assembly. Line up the small hole on
the dereeler axel assembly with the small hole on the back of the PN 5294
dereeler frame axel tube. Lock into place with the PN 5303 locking pin
assembly. Refer to Figure 3 through Figure 5 below.
Figure 3: Dereeler Axel Assembly
Small Hole
for PN 5303
Locking Pin
Assembly
Mounting Holes for PN
5266 Input Roller Guide
Assembly

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 10
Figure 4: PN 5294 Dereeler Frame Axel Tube Location
PN 5294 Dereeler
Frame Axel Tube

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 11
Figure 5: Dereeler Axel Assembled
6. To allow for safe travel, the Model 59 PN 5333 accumulator pulleys are tied
together. While supporting the bottom set of PN 5333 accumulator pulleys,
carefully untie the and gently guide the PN 5333 accumulator pulleys down to the
lowest position.
PN 5294 Dereeler
Frame Axel Tube
(Back)
PN 5303 Locking
Pin Assembly

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 12
Section 2 –Material Setup
Loading Material onto the Dereeler Axel Assembly
Follow the steps below to load a material spool onto the dereeler axel assembly. Refer
to Figure 6 below to aid in parts identification.
1. Using the PN 5415 handle, loosen and remove the outer PN 5398 dereeler shaft
collar and PN 5426 reel side assembly from the dereeler axel assembly.
2. Slide the material spool onto the rod, ensuring the material spool opening fits
onto the PN 5426 reel side assembly that remains on the dereeler axel
assembly.
3. Reinstall the outer PN 5398 dereeler shaft collar and PN 5426 reel side assembly
removed in Step 1 above. Both material spool openings must fit snugly onto the
(2) PN 5426 reel side assemblies.
4. Refer to Figure 7 below to view a material spool correctly loaded onto the
dereeler axel assembly.
Figure 6: Parts Identification
PN 5269
Dereeler Stand
Assembly
PN 5415 Handle
PN 5426 Reel
Side Assembly (2)
PN 5398 Dereeler
Shaft Collar
PN 5342 Dereeler
Axel
PN 5588 Guard
Assembly
PN 8449 Drive
Adjusting Knob
PN 5406 Speed
Control Knob
PN 5549 Cam
(Upper)
PN 5333
Accumulator
Pulley (8)
PN 5262
Extension Arm
PN 5549 Cam
(Lower)
PN 5524 Weight
Cap and PN
3733 Cap Screw
PN 5522 Pulley
Weight

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 13
Figure 7: Material Spool Correctly Loaded onto Dereeler Axel Assembly
Loading Material into the Model 59
Follow the steps below to load material into the Model 59. Refer to Figure 6 above to
aid in parts identification.
1. Manually pull approximately twenty-five (25) feet of material from the material
spool. Open the upper and lower PN 5549 cams that cover the PN 5333
accumulator pulleys.
2. Thread the material around the PN 5333 accumulator pulleys. Refer to Figure 8
through Figure 10 below for three material routing options.
a. The Model 59 is supplied with (1) PN 5522 1.25-pound pulley weight,
attached to the lower (4) PN 5333 accumulator pulleys. This weight is
designed to aid in processing solid conductor, rigid multi-conductor, or
large AWG stranded wire. Due to the rigid construction of these types of
materials it may be necessary to use only one set of the PN 5333
accumulator pulleys (i.e. threading material around only once [refer to
Figure 10 below]).
b. The Model 59 allows for an optional PN 5521 2.5-pound pulley weight.
This is for use when processing the heaviest, most-rigid material
appropriate for the Model 59.

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 14
c. To process smaller AWG wire, it may be necessary to remove the PN
5522 1.25-pound pulley weight to avoid stretching the wire during the
dereeling process. To remove the PN 5522 1.25-pound pulley weight,
loosen the PN 3733 cap screw and remove the PN 5524 weight cap.
Remove the PN 5522 1.25-pound pulley weight and reinstall the PN 5524
weight cap and PN 3733 cap screw, tightening accordingly.
Figure 8: Option 1, Material Routing for Non-Rigid Wire and Tubing

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 15
Figure 9: Option 2, Material Routing for Semi-Rigid Wire and Tubing
Figure 10: Option 3, Material Routing for Semi-Rigid Wire and Tubing
3. After routing the material according to the appropriate option for the application,
close the upper and lower PN 5549 cams to secure the material in place.

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 16
4. With the PN 5333 accumulator pulleys threaded and the upper and lower PN
5549 cams closed, remove the PN 5588 guard assembly by loosening the PN
5584 captive screw. Refer to Figure 11 below.
Figure 11: Removing the PN 5588 Guard Assembly
5. Using the PN 8449 drive adjusting knob (shown in Figure 11 above), adjust the
PN 8447 feed belt pair open wide enough so the material may be placed
between each belt.
6. Using the PN 8449 drive adjusting knob, adjust the PN 8447 feed belt pair closed
until both feed belts firmly contact the material.
7. Replace the PN 5588 guard assembly removed in Step 4 above. When
replacing the PN 5588 guard assembly, line up the assembly’s two dowel pins
with the holes on the machine cabinet. Refer to Figure 12 below.
PN 5584
Captive Screw
PN 8449 Drive
Adjusting Knob
PN 8447 Feed
Belt Pair

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 17
Figure 12: Reinstalling the PN 5588 Guard Assembly
Dowel Pins (2) to
Line up with Machine
Cabinet Holes

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 18
Section 3 –Machine Setup and Operation
1. Plug the female end of the power cord into the power entry module, located on
the left side of the machine. Plug the male end into a proper electrical outlet.
Turn the power switch, located on the top of the machine cabinet, to the ON
position; this will illuminate the power indicator light.
2. Feed the end of the material into the processing machine. Refer to the
processing machine operating instructions for information on how to correctly
load material into the machine.
3. When the processing machine is properly loaded with material, adjust the PN
5262 extension arm (shown in Figure 6 above) up or down until the material is
level with the processing machine.
4. Adjust belt pressure with the PN 8449 drive adjusting knob. The adjustments
read MORE and LESS. The goal of this adjustment is to achieve enough
pressure so the material does not slip. Too much pressure will result in
premature belt wear.
5. The PN 5406 speed control knob is located on the top of the machine cabinet.
The goal of this adjustment is to achieve an even flow of movement of the lower
PN 5333 accumulator pulleys in an up-and-down motion that is consistent with
the speed of the processing machine.
a. Proper speed adjustment is crucial to trouble-free operation. If the speed
is set too fast, there is a potential for material overrun.
6. When the Model 59 is ready for operation and all above settings are adjusted
accordingly, the operator may begin processing material. If necessary, refer to
the processing machine operating instructions for information on how to correctly
process material.
7. If the PN 5508 circuit breaker, located on the left side of the machine cabinet
(shown in Figure 1 above), trips, wait 10-15 minutes before resetting. To reset,
simply push the white button back into the housing.

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 19
Section 4 –Maintenance Procedures
Feed Belt Change
Follow the steps below to change the PN 8447 feed belt pair. Refer to Figure 13 below
for a diagram of the feed belt change process.
1. Power off the Model 59 and unplug the power cord.
2. Using the PN 8449 drive adjusting knob, separate the PN 8447 feed belt pair.
3. Remove (12) PN 5451 cap screws, (12) PN 8525 washers, and (8) PN 8514 belt
guides.
4. Remove the PN 8447 feed belt pair.
5. To install a new PN 8447 feed belt pair, reverse the above steps.
Figure 13: Model 59 PN 8447 Feed Belt Change

Carpenter Model 59 Wire Prefeed & Dereeler
Carpenter Model 59 Wire Prefeed & Dereeler • Phone: (315) 682-9176 • Fax: (315) 682-9160
Website: www.carpentermfg.com • Email: wire@carpentermfg.com
Revised 09/27/2021 Page 20
Section 5 –Recommended Spare Parts and Optional
Accessories
The below items are recommended spare parts for the Model 59.
Quantity Per Machine
Carpenter Part Number
Description
1
8447
Feed Belt Pair
The below items are optional accessories for the Model 59.
Carpenter Part Number
Description
5266
Input Roller Guide Assembly
5521
2.5-Pound Pulley Weight
8989
Prefeed Stop Interface Cable
Input Roller Guide Assembly
If the material spool is not mounted to the PN 5269 dereeler stand assembly as outlined
in “Section 1 –Assembling the Model 59”, use of the optional PN 5266 input roller guide
assembly may be necessary. If material is pulled from a wire rack or from a floor-mount
dereeler, the PN 5266 input roller guide assembly helps ensure material feeds correctly
into the Model 59.
Follow the steps below to install the PN 5266 input roller guide assembly onto the PN
5269 dereeler stand assembly. Refer to Figure 14 below for a properly assembled PN
5266 input roller guide assembly.
1. Remove the (2) PN 2509 cap screws and (2) PN 6510 washers included with the
PN 5266 input roller guide assembly.
2. Line up the mounting holes on the PN 5266 input roller guide assembly with the
mounting holes on the Model 59 cabinet. Refer to Figure 2 above.
3. Using a 3/16” hex wrench, install the PN 5266 input roller guide assembly with
the included (2) PN 2509 cap screws and (2) PN 6510 washers.
Table of contents
Other Carpenter MFG Tools manuals
