24ACA3
Comfortt13 Series Air Conditioner
with PuronrRefrigerant
1---1/2 To 5 Nominal Tons (Size 18 To 60)
Product Data
the environmentally sound refrigerant
Carrier’s Air Conditioners with Puron rrefrigerant provide a
collection of features unmatched by any other family of equipment.
The 24ACA has been designed utilizing Carrier’s Puron
refrigerant. The environmentally sound refrigerant allows you to
make a responsible decision in the protection of the earth’s ozone
layer.
As an Energy StarrPartner, Carrier Corporation has determined
that this product meets the Energy Starrguidelines for energy
efficiency. Refer to the combination ratings in the Product Data for
system combinations that meet Energy Starrguidelines.
INDUSTRY LEADING FEATURES /
BENEFITS
Efficiency
S13 -- 15 SEER/11 -- 12 EER
SMicrotube Technologytrefrigeration system
SIndoor air quality accessories available
Sound
SSound level as low as 74 dBA
SCompressor sound blanket
Comfort
SSystem supports ThermidistattControl or standard
thermostat
Diagnostics
STechAssisttwith 6--step diagnostics at--a--glance
Reliability
SPuronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime servce cost.
SFront--seating service valves
SScroll compressor
SInternal pressure--relief valve
SInternal thermal overload
SLow--pressure switch
SHigh--pressure switch
SFilter drier
SBalanced refrigeration system for maximum reliability
Durability
WeatherArmortprotection package:
SSolid, durable sheet metal construction
SSteel louver coil guard
SBaked--on, complete coverage, powder paint
SColor matched cabinet screws
Applications
SLong line -- up to 250 ft. total equivalent length, up to
200 feet condenser above evaporator, or up to 80 ft.
evaporator above condenser (See Long Line Guideline
for more information.)
SLow ambient (down to --20_F) with accessory kit
Warranty
Single Phase
S10--year limited compressor warranty
S5--year limited parts warranty
3--Phase
S5--year limited compressor warranty
S1--year limited parts warranty

2
MODEL NUMBER NOMENCLATURE
123 4 5 6 78
N
91011 12 13
N N A A A/N N N A/N A/N A/N N N
24A C A 3 36A00 3 0
Product
Series
Product
Family Tier Major Series SEER Cooling
Capacity
Variations Open Open Voltage Minor
Series
0, 1, 2...
24=AC A=RES
AC C=Comfort A=Puron
3=13
SEER
(Nominal)
A=Stan-
dard
0=Not
Defined
0=Not
Defined
3=208/230---1
5=208/230---3
6=460---3
As an Energy Star®Partner, Carrier
Corporation has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.
Refer to the combination ratings in
Product Data for system combinations that
meet Energy Star guidelines.
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
STANDARD FEATURES
Feature 18 24 30 36 42 48 60
Puron Refrigerant X X X X X X X
Upt to 15 SEER X X X X X X X
Scroll Compressor X X X X X X X
Louvered Coil Guard X X X X X X X
Field ---Installed Filter Drier X X X X X X X
Front---Seating Service Valves X X X X X X X
Internal Pressure---Relief Valve X X X X X X X
Internal Thermal Overload X X X X X X X
Long Line capability X X X X X X X
Low Ambient capability with Kit X X X X X X X
L o w --- P r e s s u r e S w i t c h X X X X X X X
H i g h --- P r e s s u r e S w i t c h X X X X X X X
Compressor Sound Blanket X X X X X X X
TechAssistt Diagnostics At--- a---Glance
(Single---Phase Only) X X X X X X X
24ACA3

3
PHYSICAL DATA
UNIT SIZE SERIES 18---30 24---30 30---30,50 36---30,50,60 42---30,50,60 48 ---30,50,60 60---30,50,60
Operating Weight (lb) 135 135 149 166 210 236 261
Shipping Weight (lb) 156 156 171 189 238 264 295
Compressor Type Scroll
REFRIGERANT Puron®(R--- 410A)
Control TXV (Puron®Hard Shutoff)
Charge (lb) 4.25 4.35 4.75 5.25 6.2 8.35 8.75
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 1880 2200 2200 2950 3170 3365 4050
Motor HP 1/12 1/10 1/10 1/4 1/5 1/4 1/5
Motor RPM 1100 1100 1100 1100 1100 1100 825
COND COIL
Face Area (Sq. ft.) 9.85 9.85 11.49 14.77 17.25 21.56 25.15
Fins per In. 20 20 25 25 25 25 25
Rows 1 1 1 1 1 1 1
Circuits 3 3 3 3 4 5 5
VALVECONNECT.(In.ID)
Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8
REFRIGERANT TUBES* (In. OD)
Vapor (0---80 Ft. Tube Length) 5/8 5/8 3/4 3/4 7/8 7/8 1 --- 1 / 8
Liquid (0---250 Ft. Tube Length) 3/8
* For tubing sets between 80 and 200 ft. horizontal or 20 ft. vertical differential, consult the Longline Guideline.
Note: See unit Installation Instruction for proper installation.
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
PURON 1--STAGE AIR CONDITIONER APPLICATIONS
LONG LINE APPLICATION: An application is considered ”long
line” when the total equivalent tubing length exceeds 80 ft or when
there is more than 20 ft. vertical separation between indoor and
outdoor units. These applications require additional accessories and
system modifications for reliable system operation. The maximum
allowable total equivalent length is 250Ft. The maximum vertical
separation is 200 Ft when outdoor unit is above indoor unit, and 80
ft. when the outdoor unit is below the indoor unit. Refer to
Accessory Usage Guideline for required accessories. See Long
Line Application Guideline for required piping and system
modifications. Also, refer to the table below for the acceptable
vapor tube diameters based on the total length to minimize the
cooling capacity loss.
UNIT
NOMINAL
SIZE
(BTUH)
ACCEPTABLE
LIQUID LINE
DIAMETERS
(IN. OD)
ACCEPTABLE
VAPOR LINE
DIAMETERS
(IN. OD)
COOLING CAPACITY LOSS (%)
TOTAL EQUIVALENT LINE LENGTH (FT..)
Standard Application Long Line Application Requires Accessories
25 50 80 80+ 100 125 150 175 200 225 250
18000
1Stage
Puron AC
3/8 1/2 12334678910 12
5/8 00111122333
24000
1Stage
Puron AC
3/8
5/8 01112334456
3/4 00000111112
7/8 00000000001
30000
1Stage
Puron AC
3/8
5/8 12333456789
3/4 00111122233
7/8 00000111111
36000
1Stage
Puron AC
3/8
5/8 1244567910 11 13
3/4 00111223344
7/8 00000111122
42000
1Stage
Puron AC
3/8
3/4 01222344566
7/8 00111122233
11/8 00000000001
48000
1Stage
Puron AC
3/8
3/4 01223455678
7/8 00111222334
11/8 00000000111
60000
1Stage
Puron AC
3/8
3/4 1244567910 11 12
7/8 01222344556
11/8 00001111112
Standard Length = 80 ft. or less total equivalvent length
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guideline
Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit. See
Long Line Application Guideline.
24ACA3

4
ACCESSORIES
ORDER NUMBER DESCRIPTION 18---30 24--- 30 30--- 30 30---50 36--- 30 36--- 50 36---60 42--- 30 42--- 50 42---60 48--- 30 48--- 50 48---60 60--- 30 60--- 50 60---60
KAACH1201AAA CRANKCASE HTR X X X X X X
KAACH1301AAA CRANKCASE HTR X X X
KAACH1401AAA CRANKCASE HTR XXXXXX
KAACH1501AAA CRANKCASE HTR X
KSACY0101AAA CYCLE
PROTECTOR XXXXXXXXXXXXXXXX
KAAFT0101AAA FREEZE
THERMOSTAT XXXXXXXXXXXXXXXX
KSAHS1701AAA HARD START
(CAP / RELAY) X X X X X X X
KSALA0301410 LOW AMBIENT PSW XXXXXXXXXXXXXXXX
HC32GE234 MOTOR FAN BALL
BEARING 230V X
HC34GE239 MOTOR FAN BALL
BEARING 230V XXX
HC38GE228 MOTOR FAN BALL
BEARING 230V X X
HC40GE226 MOTOR FAN BALL
BEARING 230V X X
HC40GE228 MOTOR FAN BALL
BEARING 230V X X X X
KSALA0601AAA MOTORMASTER
230V X X X X X X X X X X X X
HC40GE466 MOTOR FAN BALL
BEARING 460V X
HC38GE462 MOTOR FAN BALL
BEARING 460V X
HC40GE467 MOTOR FAN BALL
BEARING 460V X X
KSALA0701AAA MOTORMASTER
460V X X X X
KAALS0201LLS SOLENOID VALVE XXXXXXXXXXXXXXXX
KAACS0201PTC STARTASSISTPTC X X X X X X X
KSASF0101AAA SUPPORT FEET XXXXXXXXXXXXXXXX
KAATD0101TDR TIME DELAY RELAY XXXXXXXXXXXXXXXX
KSATX0201PUR TXV PURON HSO X X X X
KSATX0301PUR TXV PURON HSO XXXXXX
KSATX0401PUR TXV PURON HSO XXX
KSATX0501PUR TXV PURON HSO X X X
KAAWS0101AAA WINTER START XXXXXXXXXXXXXXXX
x = Accessory
THERMOSTAT / SUBBASE
PKG.
DESCRIPTION
TSTATCCPRH01---B Thermidistat Control --- Programmable / Non---Programmable Thermostat with Humidity control
TSTATCCPAC01---B T h e r m o s t a t --- A u t o C h a n g e o v e r, 7 --- D a y P r o g r a m m a b l e , _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCNAC01--- C T h e r m o s t a t --- A u t o C h a n g e o v e r, N o n --- P r o g r a m m a b l e , _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCBAC01--- B Builder’s Thermostat --- Manual Changeover, Non---Programmable, _F/_C , 1 --- S t a g e H e a t , 1 --- S t a g e C o o l
TSTATCCSEN01---B Outdoor Air Temperature Sensor
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXNBP01 Backplate for Non--- Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat
TSTATXXCNV10 Thermostat Conversion Kit (4 to 5 wires) --- 10 Pack
24ACA3

5
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW---AMBIENT
COOLING APPLICATIONS
(Below 55°F)
REQUIRED FOR
LONG LINE
APPLICATIONS*
(Over 80 ft.)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within 2 miles)
Ball Bearing Fan Motor Yes{No No
Compressor Start Assist Capacitor and Relay Yes Yes No
Crankcase Heater Yes Yes No
Evaporator Freeze Thermostat Yes No No
Liquid---Line Solenoid Valve No See Long Line
Application Guideline No
Motor Master®Control or
L o w --- a m b i e n t P r e s s u r e S w i t c h Yes No No
Thermostatic Expansion Valve (TXV)
Hard Shutoff Yes Yes Yes
Support Feet Recommended No Recommended
Winter Start Control Yes No No
* For tubing line sets between 80 and 200 ft. and/or 20 ft. vertical differential (250 ft. Total Equivalent Length), refer to Residential Split---System Long Line
Application Guideline.
{Required for Low---Ambient Controller (full modulation MotorMasterrControl only).
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when using MotorMasterr
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor motor
at each start up.
Usage Guideline:
Required for single--phase scroll compressors in the
following applications:
Long line
Low--ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles. Improves
compressor lubrication on restart and minimizes the chance of
liquid slugging.
Usage Guideline:
Required in Low--ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
5. Cycle Protector
The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay after
power to the compressor has been interrupted for any reason,
including power outage, protector control trip, thermostat jiggling,
or normal cycling.
6. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when Low--ambient kit has been added.
7. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in order
to maintain head pressure within normal operating limits. The
control will maintain working head pressure at low--ambient
temperatures down to 0_F when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch must be used when
cooling operation is at outdoor temperatures below
55_F (12.8_C) to a minimum of 0_F (--17.8_C).
Suggested for all commercial applications.
8. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C), it
maintains condensing temperature at 100_F±10_F (37.8_C±
-- 1 2 _C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
24ACA3

6
Accessory Description and Usage (Listed Alphabetically) (Cont)
9. Outdoor Air Temperature Sensor
Designed for use with Carrier Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary
heat lock out.
Usage Guideline:
Suggested for all Carrier thermostats listed in this
publication.
10. Support Feet
Four stick--on plastic feet that raise the unit 4 in. above the
mounting pad. This allows sand, dirt, and other debris to be
flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
11. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube. Hard
shutoff types are available.
NOTE: When using a hard shutoff TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Accessory required to meet ARI rating and system
reliability, where indoor not equipped.
Hard shutoff TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
12. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
Accessory required to meet ARI rating, where indoor
not equipped.
13. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
24ACA3

7
ELECTRICAL DATA
UNIT SIZE
--- V O L T A G E ,
SERIES
V/PH
OPER
VOLTS* COMPR FAN
MCA
MIN
WIRE
SIZE{
MIN
WIRE
SIZE{
MAX
LENGTH
(FT)}
MAX
LENGTH
(FT)}
MAX
FUSE**
or CKT
BRK
AMPS
MAX MIN. LRA RLA FLA 60°C75°C60°C75°C
18 --- 30
208---230 ---1 253 197
48.0 9.0 0.5 11.7 14 14 67 64 15
24 --- 30 58.3 13.5 0.75 17.6 14 14 45 43 25
30 --- 30 64.0 12.8 0.75 16.8 14 14 47 45 25
36 --- 30 77.0 14.1 1.4 19.0 12 12 66 63 30
42 --- 30 112.0 17.9 1.1 23.5 12 12 53 51 40
48 --- 30 109.0 19.9 1.4 26.2 10 10 76 73 40
60 --- 30 134.0 26.4 1.2 34.2 8 8 91 86 50
30 --- 50
208/230---3 253 197
58.0 10.1 0.8 13.4 14 14 68 65 20
36 --- 50 71.0 9.2 1.4 12.9 14 14 70 67 20
42 --- 50 88.0 13.5 1.2 18.1 12 12 80 76 30
48 --- 50 83.1 13.6 1.2 18.2 12 12 79 76 30
60 --- 50 110.0 17.7 1.2 23.3 12 12 62 59 40
36 --- 60
460---3 506 414
38.0 5.6 0.7 7.8 14 14 233 222 15
42 --- 60 44.0 6.0 0.5 8.0 14 14 227 216 15
48 --- 60 41.0 6.1 0.6 8.2 14 14 222 211 15
60 --- 60 52.0 7.8 0.6 10.3 14 14 177 168 15
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30˚C(86˚F), consult table 310---16 of the NEC (ANSI/NFPA 70). The ampacity of non---metallic---sheathed cable
(NM), trade name ROMEX, shall be that of 60˚C (140˚F) conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If other than uncoated (no---plated), 60_
or 75˚C (140_or 167˚C) insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables
of the NEC (ANSI/NFPA 70).
}Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit. All
motors/compressors contain internal overload protection.
A--WEIGHTED SOUND POWER (DBA)
UNIT SIZE --- VOLTAGE, SERIES STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
18---30 74 50.0 61.5 64.5 66.5 64.0 61.0 54.5
24---30 74 55.5 63.5 67.0 70.0 66.0 63.5 57.0
30---30
30---50 74 52.5 63.0 68.5 70.0 66.5 62.5 56.5
36---30
36---50
36---60
74 57.0 65.0 67.5 69.5 67.5 65.0 60.0
42---30
42---50
42---60
74 55.0 64.0 68.0 68.5 64.5 60.0 54.0
48---30
48---50
48---60
74 52.5 62.5 65.5 69.0 63.5 60.5 56.0
60---30
60---50
60---60
74 54.0 59.0 65.5 67.5 63.5 60.0 55.5
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE ---VOLTAGE, SERIES REQUIRED SUBCOOLING (_F)
18---30 8
24---30 13
36---30
36---50
36---60
16
36---30
36---50
36---60
16
42---30
42---50
42---60
10
48---30
48---50
48---60
17
60---30
60---50
60---60
11
24ACA324ACA3

8
DIMENSIONS
24ACA3

9
COMBINATION RATINGS
U N I T S I Z E ---
SERIES,
VOLTAGE
INDOOR MODEL TOTAL CAP.
BTUH
FACTORY
SUPPLIED
ENHANCEMENT
SEER
EER FURNACE MODEL
STANDARD
RATING TDR†
18---30
*CAP**1814A** 17,500 TXV 13.00 11.00
CAP**1814A** 17,200 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CAP**2414A** 17,700 TXV 13.00 11.00
CAP**2414A** 17,500 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CAP**2417A** 17,700 TXV 13.00 11.00
CAP**2417A** 17,500 TDR&TXV 14.50 11.70 58MVB060---14
CAP**2417A** 17,600 TDR&TXV 14.50 11.70 58CV(A,X)090---16
CNPV*1814A** 17,400 TXV 13.00 11.00
CNPV*1814A** 17,200 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CNPV*2414A** 17,500 TXV 13.00 11.00
CNPV*2414A** 17,300 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CNPV*2417A** 17,500 TXV 13.00 11.00
CNPV*2417A** 17,300 TDR&TXV 14.50 11.70 58MVB060---14
CNPV*2417A** 17,400 TDR&TXV 14.50 11.70 58CV(A,X)090---16
CNPH*2417A** 17,500 TXV 13.00 11.00
CNPH*2417A** 17,300 TDR&TXV 14.50 11.70 58MVB040---14
CNPH*2417A** 17,300 TDR&TXV 14.50 11.70 58MVB060---14
CNPH*2417A** 17,400 TDR&TXV 14.50 11.70 58MVB080---14
CNPH*2417A** 17,300 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CNPH*2417A** 17,400 TDR&TXV 14.50 11.70 58CV(A,X)090---16
CNPF*2418A** 17,500 TXV 13.00 11.00
CSPH*2412A** 17,000 TXV 13.00 11.00
CSPH*2412A** 16,700 TDR&TXV 14.50 11.70 58MVB040---14
CSPH*2412A** 16,700 TDR&TXV 14.50 11.70 58MVB060---14
CSPH*2412A** 16,700 TDR&TXV 14.50 11.70 58MVB080---14
CSPH*2412A** 16,600 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CSPH*2412A** 16,700 TDR&TXV 14.50 11.70 58CV(A,X)090---16
FY4ANF018 17,400 TDR&TXV 13.00 11.00
FY4ANF024 17,500 TDR&TXV 13.00 11.00
FX4CNF018 17,600 TDR&TXV 14.50 11.70
FX4CNF024 17,900 TDR&TXV 14.50 11.70
FE4ANF002 17,800 TDR&TXV 15.00 12.00
FF1ENP018 17,400 TDR&TXV 13.00 11.00
FF1ENP024 17,600 TDR&TXV 13.20 11.00
FV4BNF002 17,800 TDR&TXV 15.00 12.00
24---30
*CAP**2414A** 23,000 TXV 13.00 11
CAP**2414A** 22,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CAP**2417A** 22,800 TXV 13.00 11.00
CAP**2417A** 22,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**2417A** 22,600 TDR&TXV 14.50 11.70 58CV(A,X)090---16
CAP**3014A** 23,000 TXV 13.00 11.00
CAP**3014A** 22,800 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CAP**3017A** 23,000 TXV 13.00 11.00
CAP**3017A** 22,800 TDR&TXV 14.50 11.70 58MVB060---14
CAP**3017A** 22,800 TDR&TXV 14.50 11.70 58CV(A,X)090---16
CNPV*2414A** 22,600 TXV 13.00 11.00
CNPV*2414A** 22,400 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPV*2417A** 22,600 TXV 13.00 11.00
CNPV*2417A** 22,400 TDR&TXV 14.00 11.50 58MVB060---14
CNPV*2417A** 22,400 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CNPV*3014A** 22,800 TXV 13.00 11.00
CNPV*3014A** 22,600 TDR&TXV 14.00 11.15 58CV(A,X)070---12
CNPV*3017A** 22,800 TXV 13.00 11.00
CNPV*3017A** 22,600 TDR&TXV 14.50 11.70 58MVB060---14
CNPV*3017A** 22,600 TDR&TXV 14.50 11.70 58CV(A,X)090---16
See notes on pg. 14
24ACA3

10
COMBINATION RATINGS CONTINUED
U N I T S I Z E ---
SERIES,
VOLTAGE
INDOOR MODEL TOTAL CAP.
BTUH
FACTORY
SUPPLIED
ENHANCEMENT
SEER
EER FURNACE MODEL
STANDARD
RATING TDR†
24---30
CNPH*2417A** 22,600 TXV 13.00 11.00
CNPH*2417A** 22,400 TDR&TXV 14.00 11.50 58MVB040---14
CNPH*2417A** 22,400 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPH*3017A** 22,800 TXV 13.00 11.00
CNPH*3017A** 22,600 TDR&TXV 14.50 11.70 58MVB040---14
CNPH*3017A** 22,600 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CNPF*2418A** 22,600 TXV 13.00 11.00
CSPH*2412A** 22,000 TXV 13.00 11.00
CSPH*2412A** 21,800 TDR&TXV 14.00 11.50 58MVB040---14
CSPH*2412A** 21,800 TDR&TXV 14.00 11.50 58MVB060---14
CSPH*2412A** 21,800 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CSPH*2412A** 21,800 TDR&TXV 14.50 11.70 58CV(A,X)090---16
CSPH*2412A** 21,800 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CSPH*2412A** 21,800 TDR&TXV 14.00 11.50 58CV(A,X)135---22
CSPH*3012A** 22,000 TXV 13.00 11.00
CSPH*3012A** 22,000 TDR&TXV 14.50 11.70 58MVB040---14
CSPH*3012A** 21,800 TDR&TXV 14.50 11.70 58MVB060---14
CSPH*3012A** 22,000 TDR&TXV 14.50 11.70 58MVB080---14
CSPH*3012A** 21,800 TDR&TXV 14.50 11.70 58MVB080---20
CSPH*3012A** 22,000 TDR&TXV 14.50 11.70 58MVB100---20
CSPH*3012A** 21,800 TDR&TXV 14.50 11.70 58MVB120---20
CSPH*3012A** 21,800 TDR&TXV 14.50 11.70 58CV(A,X)070---12
CSPH*3012A** 22,000 TDR&TXV 14.50 11.70 58CV(A,X)090---16
CSPH*3012A** 22,000 TDR&TXV 14.50 11.70 58CV(A,X)110---20
CSPH*3012A** 22,000 TDR&TXV 14.50 11.70 58CV(A,X)135---22
CSPH*3012A** 22,000 TDR&TXV 14.50 11.70 58CV(A,X)155---22
FY4ANF024 22,600 TDR&TXV 13.00 11.00
FY4ANF030 22,800 TDR&TXV 13.20 11.00
FX4CNF024 23,000 TDR&TXV 14.00 11.50
FX4CNF030 23,200 TDR&TXV 14.00 11.50
FE4ANF002 23,000 TDR&TXV 14.50 11.70
FE4ANF003 23,000 TDR&TXV 14.50 11.70
FF1ENP024 22,600 TDR&TXV 13.00 11.00
FF1ENP030 22,600 TDR&TXV 13.00 11.00
FV4BNF002 23,000 TDR&TXV 14.50 11.70
FV4BNF003 23,000 TDR&TXV 15.00 12.00
30---30
30---50
*CAP**3014A** 28,000 TXV 13.00 11
CAP**3014A** 27,600 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CAP**3017A** 28,000 TXV 13.00 11.00
CAP**3017A** 27,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**3017A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CAP**3614A** 28,000 TXV 13.00 11.00
CAP**3614A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CAP**3617A** 28,000 TXV 13.00 11.00
CAP**3617A** 27,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**3617A** 27,800 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CAP**3621A** 28,000 TXV 13.00 11.00
See notes on pg. 14
24ACA3

11
COMBINATION RATINGS CONTINUED
U N I T S I Z E ---
SERIES,
VOLTAGE
INDOOR MODEL TOTAL CAP.
BTUH
FACTORY
SUPPLIED
ENHANCEMENT
SEER
EER FURNACE MODEL
STANDARD
RATING TDR†
30---30
30---50
CAP**3621A** 27,800 TDR&TXV 14.00 11.50 58MVB080---14
CAP**3621A** 27,800 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CNPV*3014A** 27,800 TXV 13.00 11.00
CNPV*3014A** 27,400 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CNPV*3017A** 27,800 TXV 13.00 11.00
CNPV*3017A** 27,400 TDR&TXV 14.00 11.50 58MVB060---14
CNPV*3017A** 27,400 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CNPV*3617A** 27,800 TXV 13.00 11.00
CNPV*3617A** 27,400 TDR&TXV 14.00 11.50 58MVB060---14
CNPV*3617A** 27,400 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CNPV*3621A** 27,800 TXV 13.00 11.00
CNPV*3621A** 27,400 TDR&TXV 14.00 11.50 58MVB080---14
CNPV*3621A** 27,600 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CNPH*3017A** 27,800 TXV 13.00 11.00
CNPH*3017A** 27,400 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*3017A** 27,400 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPH*3617A** 27,800 TXV 13.00 11.00
CNPH*3617A** 27,400 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*3617A** 27,400 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPF*3618A** 27,800 TXV 13.00 11.00
CSPH*3012A** 27,000 TXV 13.00 11.00
CSPH*3012A** 26,800 TDR&TXV 13.50 11.20 58MVB040---14
CSPH*3012A** 26,800 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CSPH*3612A** 27,400 TXV 13.20 11.00
CSPH*3612A** 27,200 TDR&TXV 14.00 11.50 58MVB040---14
CSPH*3612A** 27,200 TDR&TXV 14.00 11.50 58CV(A,X)070---12
FY4ANF030 27,600 TDR&TXV 13.00 11.00
FY4ANF036 27,800 TDR&TXV 13.00 11.00
FX4CNF030 28,000 TDR&TXV 13.50 11.20
FX4CN(B,F)036 28,200 TDR&TXV 14.00 11.50
FE4ANF002 27,800 TDR&TXV 14.00 11.50
FE4ANF003 28,000 TDR&TXV 14.50 11.70
FE4ANF005 28,800 TDR&TXV 15.00 12.00
FF1ENP030 27,400 TDR&TXV 13.00 11.00
FF1ENP036 28,000 TDR&TXV 13.20 11.00
FV4BNF002 27,800 TDR&TXV 14.00 11.50
FV4BNF003 28,000 TDR&TXV 14.50 11.70
FV4BNF005 28,800 TDR&TXV 15.00 12.00
36---30
36---50
36---60
*CAP**3617A** 34,000 TXV 13.00 11.00
CAP**3614A** 33,000 TXV 13.00 11.00
CAP**3614A** 33,000 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CAP**3617A** 33,600 TDR&TXV 14.00 11.50 58MVB060---14
CAP**3617A** 33,600 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CAP**3621A** 34,000 TXV 13.00 11.00
CAP**3621A** 33,600 TDR&TXV 13.50 11.20 58MVB080---14
CAP**3621A** 33,800 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CAP**4221A** 34,000 TXV 13.00 11.00
CAP**4221A** 33,800 TDR&TXV 14.00 11.50 58MVB080---14
CAP**4221A** 34,000 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CAP**4224A** 34,000 TXV 13.00 11.00
CAP**4224A** 33,800 TDR&TXV 14.00 11.50 58MVB040---14
CAP**4224A** 34,000 TDR&TXV 14.50 11.70 58CV(A,X)135---22
CNPV*3617A** 33,800 TXV 13.00 11.00
CNPV*3617A** 33,200 TDR&TXV 13.50 11.20 58MVB060---14
CNPV*3617A** 33,400 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CNPV*3621A** 33,800 TXV 13.00 11.00
CNPV*3621A** 33,600 TDR&TXV 13.00 11.00 58MVB080---14
See notes on pg. 14
24ACA3

12
COMBINATION RATINGS CONTINUED
U N I T S I Z E ---
SERIES,
VOLTAGE
INDOOR MODEL TOTAL CAP.
BTUH
FACTORY
SUPPLIED
ENHANCEMENT
SEER
EER FURNACE MODEL
STANDARD
RATING TDR†
36---30
36---50
36---60
CNPV*3621A** 33,800 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CNPV*4221A** 34,000 TXV 13.00 11.00
CNPV*4221A** 34,200 TDR&TXV 14.00 11.50 58MVB080---14
CNPV*4221A** 34,600 TDR&TXV 14.50 11.70 58CV(A,X)110---20
CNPH*3617A** 33,800 TXV 13.00 11.00
CNPH*3617A** 33,200 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*3617A** 33,200 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CNPH*4221A** 34,000 TXV 13.00 11.00
CNPH*4221A** 34,200 TDR&TXV 14.00 11.50 58MVB040---14
CNPH*4221A** 34,400 TDR&TXV 14.00 11.50 58MVB060---14
CNPH*4221A** 34,200 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CNPF*3618A** 33,800 TXV 13.00 11.00
CSPH*3612A** 33,600 TXV 13.00 11.00
CSPH*3612A** 33,200 TDR&TXV 14.00 11.50 58MVB040---14
CSPH*3612A** 33,200 TDR&TXV 14.00 11.50 58CV(A,X)070---12
CSPH*4212A** 33,800 TXV 13.20 11.20
CSPH*4212A** 33,800 TDR&TXV 13.50 11.20 58MVB040---14
CSPH*4212A** 34,000 TDR&TXV 13.50 11.20 58CV(A,X)070---12
FY4ANF036 33,800 TDR&TXV 13.00 11.00
FY4ANF042 34,400 TDR&TXV 13.00 11.00
FX4CN(B,F)036 34,400 TDR&TXV 14.00 11.50
FX4CN(B,F)042 34,800 TDR&TXV 14.00 11.50
FE4ANF002 33,600 TDR&TXV 14.00 11.50
FE4ANF003 34,000 TDR&TXV 14.50 11.70
FE4ANF005 35,000 TDR&TXV 15.00 12.00
FE4ANB006 35,400 TDR&TXV 15.00 12.00
FF1ENP036 33,800 TDR&TXV 13.00 11.00
FV4BNF002 33,600 TDR&TXV 14.00 11.50
FV4BNF003 34,000 TDR&TXV 14.50 11.70
FV4BNF005 35,000 TDR&TXV 15.00 12.00
FV4BNB006 35,400 TDR&TXV 15.00 12.00
42---30
42---50
42---60
*CAP**4221A** 41,000 TXV 13.00 11.00
CAP**4221A** 40,000 TDR&TXV 13.50 11.20 58MVB080---14
CAP**4221A** 40,500 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CAP**4224A** 41,000 TXV 13.00 11.00
CAP**4224A** 40,000 TDR&TXV 13.50 11.20 58MVB040---14
CAP**4224A** 40,500 TDR&TXV 14.00 11.50 58CV(A,X)135---22
CAP**4817A** 40,000 TXV 13.20 11.00
CAP**4817A** 40,000 TDR&TXV 14.00 11.50 58MVB060---14
CAP**4817A** 40,000 TDR&TXV 14.00 11.50 58CV(A,X)090---16
CAP**4821A** 41,500 TXV 13.20 11.00
CAP**4821A** 40,500 TDR&TXV 13.50 11.20 58MVB080---14
CAP**4821A** 41,000 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CAP**4824A** 41,500 TXV 13.20 11.00
CAP**4824A** 41,000 TDR&TXV 13.50 11.20 58MVB040---14
CAP**4824A** 41,000 TDR&TXV 14.50 11.70 58CV(A,X)135---22
CNPV*4221A** 41,000 TXV 13.00 11.00
CNPV*4221A** 40,000 TDR&TXV 13.50 11.20 58MVB080---14
CNPV*4221A** 40,000 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CNPV*4821A** 40,500 TXV 13.20 11.00
CNPV*4821A** 40,500 TDR&TXV 13.50 11.20 58MVB080---14
CNPV*4821A** 41,000 TDR&TXV 14.00 11.50 58CV(A,X)110---20
CNPV*4824A** 41,500 TXV 13.20 11.00
CNPV*4824A** 41,000 TDR&TXV 13.50 11.20 58MVB040---14
CNPV*4824A** 40,500 TDR&TXV 14.50 11.70 58CV(A,X)135---22
CNPH*4221A** 41,000 TXV 13.00 11.00
CNPH*4221A** 40,000 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*4221A** 40,500 TDR&TXV 13.50 11.20 58CV(A,X)070---12
See notes on pg. 14
24ACA3

13
COMBINATION RATINGS CONTINUED
U N I T S I Z E ---
SERIES,
VOLTAGE
INDOOR MODEL TOTAL CAP.
BTUH
FACTORY
SUPPLIED
ENHANCEMENT
SEER
EER FURNACE MODEL
STANDARD
RATING TDR†
42---30
42---50
42---60
CNPH*4821A** 41,500 TXV 13.20 11.00
CNPH*4821A** 40,500 TDR&TXV 13.50 11.20 58MVB040---14
CNPH*4821A** 41,000 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CNPF*4818A** 41,500 TXV 13.20 11.00
CSPH*4212A** 40,500 TXV 13.20 11.00
CSPH*4212A** 40,000 TDR&TXV 13.50 11.20 58MVB040---14
CSPH*4212A** 40,000 TDR&TXV 13.50 11.20 58CV(A,X)070---12
CSPH*4812A** 41,000 TXV 13.20 11.00
CSPH*4812A** 40,000 TDR&TXV 13.50 11.20 58MVB040---14
CSPH*4812A** 40,000 TDR&TXV 13.50 11.20 58CV(A,X)070---12
FY4ANF042 41,000 TDR&TXV 13.00 11.00
FY4ANF048 42,000 TDR&TXV 13.20 11.00
FX4CN(B,F)042 41,500 TDR&TXV 13.50 11.20
FX4CN(B,F)048 42,500 TDR&TXV 14.00 11.50
FE4ANF003 40,500 TDR&TXV 14.00 11.50
FE4ANF005 42,000 TDR&TXV 14.50 11.70
FE4ANB006 42,500 TDR&TXV 15.00 12.00
FV4BNF003 40,500 TDR&TXV 14.00 11.50
FV4BNF005 41,500 TDR&TXV 14.50 11.70
FV4BNB006 42,500 TDR&TXV 15.00 12.00
48---30
48---50
48---60
*CAP**4821A** 46,000 TXV 13.00 11.00
CAP**4817A** 45,500 TXV 13.00 11.00
CAP**4817A** 45,500 TDR&TXV 13.50 11.20 58CV(A,X)090---16
CAP**4821A** 45,000 TDR&TXV 13.20 11.00 58MVB080---20
CAP**4821A** 45,000 TDR&TXV 13.65 11.40 58MVB100---20
CAP**4821A** 45,000 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CAP**4824A** 46,000 TXV 13.00 11.00
CAP**4824A** 45,000 TDR&TXV 13.50 11.20 58MVB120---20
CAP**4824A** 45,500 TDR&TXV 13.50 11.20 58CV(A,X)135---22
CAP**6021A** 47,000 TXV 13.20 11.00
CAP**6021A** 46,000 TDR&TXV 13.50 11.20 58MVB080---20
CAP**6021A** 47,500 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CAP**6024A** 47,000 TXV 13.20 11.00
CAP**6024A** 46,000 TDR&TXV 14.00 11.50 58MVB120---20
CAP**6024A** 46,500 TDR&TXV 14.00 11.50 58CV(A,X)135---22
CNPV*4221A** 44,500 TXV 13.00 10.95
CNPV*4221A** 44,500 TDR&TXV 13.20 11.00 58MVB080---20
CNPV*4221A** 44,500 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CNPV*4821A** 46,000 TXV 13.00 11.00
CNPV*4821A** 45,000 TDR&TXV 13.20 11.00 58MVB080---20
CNPV*4821A** 45,000 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CNPV*4824A** 46,000 TXV 13.00 11.00
CNPV*4824A** 45,500 TDR&TXV 13.50 11.20 58MVB120---20
CNPV*4824A** 45,500 TDR&TXV 13.50 11.20 58CV(A,X)135---22
CNPV*6024A** 47,000 TXV 13.20 11.00
CNPV*6024A** 46,000 TDR&TXV 13.50 11.20 58MVB120---20
CNPV*6024A** 46,000 TDR&TXV 14.00 11.50 58CV(A,X)135---22
CNPH*4821A** 46,000 TXV 13.00 11.00
CNPH*4821A** 45,000 TDR&TXV 13.20 11.00 58MVB080---20
CNPH*4821A** 45,000 TDR&TXV 13.50 11.20 58MVB100---20
CNPH*4821A** 45,000 TDR&TXV 13.50 11.20 58CV(A,X)090---16
CNPH*4821A** 45,500 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CNPH*6024A** 47,000 TXV 13.20 11.00
CNPH*6024A** 46,000 TDR&TXV 13.50 11.20 58MVB080---20
CNPH*6024A** 46,000 TDR&TXV 13.50 11.20 58MVB100---20
CNPH*6024A** 46,000 TDR&TXV 13.50 11.20 58CV(A,X)090---16
CNPH*6024A** 46,000 TDR&TXV 13.50 11.20 58CV(A,X)110---20
CNPF*4818A** 45,000 TXV 13.00 11.00
See notes on pg. 14
24ACA3

14
COMBINATION RATINGS CONTINUED
U N I T S I Z E ---
SERIES,
VOLTAGE
INDOOR MODEL TOTAL CAP.
BTUH
FACTORY
SUPPLIED
ENHANCEMENT
SEER
EER FURNACE MODEL
STANDARD
RATING TDR†
48---30
48---50
48---60
CSPH*4812A** 45,500 TXV 13.00 11.00
CSPH*4812A** 44,500 TDR&TXV 13.20 11.00 58MVB080---20
CSPH*4812A** 44,500 TDR&TXV 13.50 11.20 58CV(A,X)090---16
CSPH*6012A** 46,000 TXV 13.20 11.00
CSPH*6012A** 45,000 TDR&TXV 13.50 11.20 58MVB080---20
CSPH*6012A** 45,000 TDR&TXV 13.50 11.20 58CV(A,X)090---16
FX4CN(B,F)048 47,000 TDR&TXV 13.50 11.20
FX4CN(B,F)060 47,500 TDR&TXV 14.00 11.50
FE4ANF005 46,500 TDR&TXV 14.00 11.50
FE4ANB006 47,000 TDR&TXV 14.50 11.70
FV4BNF005 46,500 TDR&TXV 14.00 11.50
FV4BNB006 47,000 TDR&TXV 14.50 11.70
FY4ANF048 46,000 TDR&TXV 13.00 11.00
FY4ANB060 46,500 TDR&TXV 13.20 11.00
60---30
60---50
60---60
*CAP**6024A** 57,500 TXV 13.00 11.00
CAP**6021A** 56,500 TXV 13.00 11.00
CAP**6021A** 56,000 TDR&TXV 13.20 11.00 58CV(A,X)110---20
CAP**6024A** 56,500 TDR&TXV 13.20 11.00 58CV(A,X)135---22
CAP**6024A** 56,500 TDR&TXV 13.50 11.20 58CV(A,X)155---22
CNPV*6024A** 57,000 TXV 13.00 11.00
CNPV*6024A** 56,000 TDR&TXV 13.50 11.00 58CV(A,X)135---22
CNPV*6024A** 56,500 TDR&TXV 13.50 11.20 58CV(A,X)155---22
CNPH*6024A** 56,000 TXV 13.00 11.00
CNPH*6024A** 56,000 TDR&TXV 13.50 11.20 58CV(A,X)135---22
CNPH*6024A** 56,500 TDR&TXV 13.50 11.20 58CV(A,X)155---22
CSPH*6012A** 56,500 TXV 13.00 11.00
CSPH*6012A** 55,500 TDR&TXV 13.20 11.00 58CV(A,X)110---20
CSPH*6012A** 55,500 TDR&TXV 13.50 11.20 58CV(A,X)135---22
CSPH*6012A** 55,500 TDR&TXV 13.50 11.20 58CV(A,X)155---22
FX4CN(B,F)060 58,000 TDR&TXV 13.20 11.00
FE4ANB006 57,000 TDR&TXV 13.50 11.20
FV4BNB006 57,000 TDR&TXV 13.50 11.20
FY4ANB060 56,500 TDR&TXV 13.00 11.00
* Tested combination .
{In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use
either the accessory Time---Delay Relay, KAATD0101TDR, or a furnace equipped with TDR. Most Carrier furnaces are equipped with TDR.
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other
combinations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are significantly affected.
EER — Energy Efficiency Ratio
SEER — Seasonal Energy Efficiency Ratio
TDR — T i m e --- D e l a y R e l a y
TXV — Thermostatic Expansion Valve
24ACA3

15
DETAILED COOLING CAPACITIES{{
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
System
KW**
Capacity
MBtuh† Total
System
KW**
Capacity
MBtuh† Total
System
KW**
Capacity
MBtuh† Total
System
KW**
Capacity
MBtuh† Total
System
KW**
Capacity
MBtuh† Total
System
KW**
Total Sens
‡Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
24ACA318A30 Outdoor Section With CAP**1814A** Indoor Section
525
72 20.46 10.76 1.21 19.55 10.41 1.36 18.59 10.05 1.53 17.62 9.69 1.71 16.57 9.30 1.91 15.40 8.88 2.13
67 18.79 13.26 1.22 17.95 12.90 1.37 17.05 12.52 1.53 16.12 12.14 1.72 15.13 11.74 1.92 14.03 11.30 2.13
62 17.27 15.73 1.22 16.49 15.36 1.37 15.68 14.97 1.54 14.83 14.55 1.72 14.00 14.00 1.92 13.15 13.15 2.13
57 16.78 16.78 1.23 16.15 16.15 1.37 15.48 15.48 1.54 14.77 14.77 1.72 14.00 14.00 1.92 13.15 13.15 2.13
600
72 20.79 11.28 1.24 19.83 10.92 1.39 18.83 10.55 1.56 17.83 10.19 1.74 16.76 9.80 1.94 15.55 9.37 2.16
67 19.11 14.10 1.25 18.23 13.73 1.40 17.30 13.36 1.56 16.35 12.97 1.74 15.33 12.57 1.94 14.20 12.12 2.16
62 17.66 16.88 1.25 16.87 16.49 1.40 16.06 16.06 1.56 15.32 15.32 1.75 14.51 14.51 1.94 13.61 13.61 2.16
57 17.46 17.46 1.25 16.79 16.79 1.40 16.07 16.07 1.56 15.32 15.32 1.75 14.51 14.51 1.94 13.61 13.61 2.16
675
72 21.03 11.77 1.27 20.02 11.40 1.42 18.99 11.03 1.58 17.97 10.67 1.77 16.88 10.28 1.97 15.65 9.85 2.18
67 19.33 14.90 1.27 18.43 14.54 1.42 17.48 14.15 1.59 16.51 13.77 1.77 15.48 13.35 1.97 14.33 12.89 2.19
62 18.01 17.91 1.28 17.30 17.30 1.43 16.54 16.54 1.59 15.76 15.76 1.77 14.92 14.92 1.97 13.97 13.97 2.19
57 18.01 18.01 1.28 17.30 17.30 1.43 16.55 16.55 1.59 15.76 15.76 1.77 14.92 14.92 1.97 13.97 13.97 2.19
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor
Model Capacity Power Furnace Model
*CAP**1814A** 1.00 1.00
CAP**2414A** 1.01 1.01
CAP**2417A** 1.01 1.01
CNPF*2418A** 1.00 1.00
CNPH*2417A** 1.00 1.00
CNPV*1814A** 0.99 0.99
CNPV*2414A** 1.00 1.00
CNPV*2417A** 1.00 1.00
CSPH*2412A** 0.97 0.97
FE4ANF002 1.02 0.93
FF1ENP018 0.99 0.99
FF1ENP024 1.01 1.01
FV4BNF002 1.02 0.93
FX4CNF018 1.01 0.95
FX4CNF024 1.02 0.96
FY4ANF018 0.99 0.99
FY4ANF024 1.00 1.00
Cooling Indoor
Model Capacity Power Furnace Model
CAP**1814A** 0.98 0.92 58CV(A,X)070---12
CAP**2414A** 1.00 0.94 58CV(A,X)070---12
CNPH*2417A** 0.99 0.93 58CV(A,X)070---12
CNPV*1814A** 0.98 0.92 58CV(A,X)070---12
CNPV*2414A** 0.99 0.93 58CV(A,X)070---12
CSPH*2412A** 0.95 0.89 58CV(A,X)070 ---12
CAP**2417A** 1.01 0.95 58CV(A,X)090---16
CNPH*2417A** 0.99 0.93 58CV(A,X)090---16
CNPV*2417A** 0.99 0.93 58CV(A,X)090---16
CSPH*2412A** 0.95 0.90 58CV(A,X)090 ---16
CNPH*2417A** 0.99 0.93 58MVB040 ---14
CSPH*2412A** 0.95 0.90 58MVB040---14
CAP**2417A** 1.00 0.94 58MVB060---14
CNPH*2417A** 0.99 0.93 58MVB060 ---14
CNPV*2417A** 0.99 0.93 58MVB060 ---14
CSPH*2412A** 0.95 0.90 58MVB060---14
CNPH*2417A** 0.99 0.93 58MVB080 ---14
CSPH*2412A** 0.95 0.90 58MVB080---14
See notes on pg. 21
24ACA3

16
DETAILED COOLING CAPACITIES{{ (CONT.)
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens‡ To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ACA324A30 Outdoor Section With CAP**2414A** Indoor Section
700
72 27.11 14.29 1.61 25.97 13.86 1.81 24.75 13.40 2.03 23.47 12.92 2.28 22.09 12.41 2.55 20.55 11.85 2.84
67 24.89 17.62 1.61 23.81 17.16 1.81 22.66 16.68 2.03 21.45 16.19 2.28 20.15 15.66 2.55 18.73 15.09 2.85
62 22.86 20.91 1.61 21.86 20.44 1.81 20.81 19.93 2.04 19.72 19.39 2.28 18.65 18.65 2.56 17.57 17.57 2.86
57 22.24 22.24 1.61 21.43 21.43 1.82 20.56 20.56 2.04 19.64 19.64 2.28 18.65 18.65 2.56 17.57 17.57 2.86
800
72 27.54 14.98 1.64 26.35 14.54 1.84 25.08 14.08 2.06 23.76 13.60 2.31 22.34 13.09 2.58 20.75 12.52 2.88
67 25.31 18.74 1.64 24.19 18.29 1.85 23.00 17.81 2.07 21.75 17.31 2.31 20.42 16.77 2.59 18.96 16.19 2.88
62 23.37 22.46 1.65 22.36 21.95 1.85 21.35 21.35 2.07 20.38 20.38 2.32 19.33 19.33 2.59 18.18 18.18 2.89
57 23.14 23.14 1.65 22.28 22.28 1.85 21.36 21.36 2.07 20.38 20.38 2.32 19.33 19.33 2.59 18.18 18.18 2.89
900
72 27.83 15.64 1.68 26.61 15.19 1.88 25.31 14.72 2.10 23.96 14.25 2.34 22.50 13.73 2.61 20.87 13.16 2.91
67 25.61 19.83 1.68 24.46 19.37 1.88 23.25 18.88 2.10 21.97 18.37 2.35 20.61 17.83 2.62 19.12 17.24 2.92
62 23.85 23.85 1.68 22.96 22.96 1.88 22.00 22.00 2.10 20.98 20.98 2.35 19.87 19.87 2.62 18.66 18.66 2.92
57 23.87 23.87 1.68 22.97 22.97 1.88 22.00 22.00 2.10 20.98 20.98 2.35 19.87 19.87 2.62 18.66 18.66 2.92
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor
Model
Capacity Power Furnace Model
*CAP**2414A** 1.00 1.00
CAP**2417A** 0.99 0.99
CAP**3014A** 1.00 1.00
CAP**3017A** 1.00 1.00
CNPF*2418A** 0.98 0.98
CNPH*2417A** 0.98 0.98
CNPH*3017A** 0.99 0.99
CNPV*2414A** 0.98 0.98
CNPV*2417A** 0.98 0.98
CNPV*3014A** 0.99 0.99
CNPV*3017A** 0.99 0.99
CSPH*2412A** 0.96 0.96
CSPH*3012A** 0.96 0.96
FE4ANF002 1.00 0.94
FE4ANF003 1.00 0.94
FF1ENP024 0.98 0.98
FF1ENP030 0.98 0.98
FV4BNF002 1.00 0.94
FV4BNF003 1.00 0.92
FX4CNF024 1.00 0.96
FX4CNF030 1.01 0.96
FY4ANF024 0.98 0.98
FY4ANF030 0.99 0.99
Cooling Indoor
Model
Capacity Power Furnace Model
CAP**2414A** 0.98 0.94 58CV(A,X)070---12
CAP**3014A** 0.99 0.95 58CV(A,X)070---12
CNPH*2417A** 0.97 0.93 58CV(A,X)070 ---12
CNPH*3017A** 0.98 0.92 58CV(A,X)070 ---12
CNPV*2414A** 0.97 0.93 58CV(A,X)070 ---12
CNPV*3014A** 0.98 0.97 58CV(A,X)070 ---12
CSPH*2412A** 0.95 0.91 58CV(A,X)070---12
CSPH*3012A** 0.95 0.89 58CV(A,X)070---12
CAP**2417A** 0.98 0.92 58CV(A,X)090---16
CAP**3017A** 0.99 0.93 58CV(A,X)090---16
CNPV*2417A** 0.97 0.93 58CV(A,X)090 ---16
CNPV*3017A** 0.98 0.92 58CV(A,X)090 ---16
CSPH*2412A** 0.95 0.89 58CV(A,X)090---16
CSPH*3012A** 0.96 0.90 58CV(A,X)090---16
CSPH*2412A** 0.95 0.91 58CV(A,X)110---20
CSPH*3012A** 0.96 0.90 58CV(A,X)110---20
CSPH*2412A** 0.95 0.91 58CV(A,X)135---22
CSPH*3012A** 0.96 0.90 58CV(A,X)135---22
CSPH*3012A** 0.96 0.90 58CV(A,X)155---22
CNPH*2417A** 0.97 0.93 58MVB040---14
CNPH*3017A** 0.98 0.92 58MVB040---14
CSPH*2412A** 0.95 0.91 58MVB040---14
CSPH*3012A** 0.96 0.90 58MVB040---14
CAP**2417A** 0.98 0.94 58MVB060---14
CAP**3017A** 0.99 0.93 58MVB060---14
CNPV*2417A** 0.97 0.93 58MVB060---14
CNPV*3017A** 0.98 0.92 58MVB060---14
CSPH*2412A** 0.95 0.91 58MVB060---14
CSPH*3012A** 0.95 0.89 58MVB060---14
CSPH*3012A** 0.96 0.90 58MVB080---14
CSPH*3012A** 0.95 0.89 58MVB080---20
CSPH*3012A** 0.96 0.90 58MVB100---20
CSPH*3012A** 0.95 0.89 58MVB120---20
See notes on pg. 21
24ACA3

17
DETAILED COOLING CAPACITIES{{ (CONT.)
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ACA330A30 Outdoor Section With CAP**3014A** Indoor Section
875
72 33.13 17.60 2.01 31.70 17.06 2.23 30.20 16.49 2.47 28.59 15.90 2.75 26.87 15.27 3.06 25.01 14.60 3.38
67 30.12 21.64 2.01 28.78 21.09 2.23 27.37 20.50 2.48 25.87 19.89 2.76 24.27 19.25 3.07 22.59 18.58 3.42
62 27.50 25.68 2.01 26.29 25.09 2.23 25.03 24.47 2.48 23.75 23.75 2.77 22.56 22.56 3.08 21.27 21.27 3.43
57 26.93 26.93 2.01 25.94 25.94 2.24 24.89 24.89 2.48 23.76 23.76 2.77 22.56 22.56 3.08 21.27 21.27 3.43
1000
72 33.69 18.46 2.05 32.21 17.92 2.27 30.64 17.34 2.52 28.98 16.74 2.80 27.20 16.10 3.11 25.32 15.44 3.45
67 30.64 23.04 2.05 29.26 22.48 2.27 27.80 21.89 2.52 26.25 21.27 2.80 24.61 20.61 3.12 22.87 19.92 3.46
62 28.16 27.55 2.06 26.95 26.95 2.28 25.86 25.86 2.53 24.67 24.67 2.81 23.39 23.39 3.12 22.02 22.02 3.47
57 28.03 28.03 2.06 26.98 26.98 2.28 25.86 25.86 2.53 24.67 24.67 2.81 23.39 23.39 3.12 22.02 22.02 3.47
1125
72 34.09 19.27 2.10 32.57 18.72 2.32 30.96 18.14 2.56 29.26 17.54 2.84 27.43 16.89 3.15 25.50 16.22 3.49
67 31.03 24.36 2.10 29.61 23.80 2.32 28.12 23.20 2.57 26.54 22.57 2.85 24.86 21.90 3.16 23.10 21.19 3.50
62 28.94 28.94 2.10 27.83 27.83 2.32 26.66 26.66 2.57 25.40 25.40 2.85 24.06 24.06 3.16 22.61 22.61 3.48
57 28.94 28.94 2.10 27.83 27.83 2.32 26.66 26.66 2.57 25.41 25.41 2.85 24.06 24.06 3.16 22.62 22.62 3.51
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor
Model Capacity Power Furnace Model
*CAP**3014A** 1.00 1.00
CAP**3017A** 1.00 1.00
CAP**3614A** 1.00 1.00
CAP**3617A** 1.00 1.00
CAP**3621A** 1.00 1.00
CNPF*3618A** 0.99 0.99
CNPH*3017A** 0.99 0.99
CNPH*3617A** 0.99 0.99
CNPV*3014A** 0.99 0.99
CNPV*3017A** 0.99 0.99
CNPV*3617A** 0.99 0.99
CNPV*3621A** 0.99 0.99
CSPH*3012A** 0.96 0.96
CSPH*3612A** 0.98 0.98
FE4ANF002 0.99 0.95
FE4ANF003 1.00 0.94
FE4ANF005 1.03 0.94
FF1ENP030 0.98 0.98
FF1ENP036 1.00 1.00
FV4BNF002 0.99 0.95
FV4BNF003 1.00 0.94
FV4BNF005 1.03 0.94
FX4CN(B,F)036 1.01 0.96
FX4CNF030 1.00 0.98
FY4ANF030 0.99 0.99
FY4ANF036 0.99 0.99
Cooling Indoor
Model Capacity Power Furnace Model
CAP**3014A** 0.99 0.97 58CV(A,X)070---12
CAP**3614A** 0.99 0.94 58CV(A,X)070---12
CNPH*3017A** 0.98 0.94 58CV(A,X)070 ---12
CNPH*3617A** 0.98 0.94 58CV(A,X)070 ---12
CNPV*3014A** 0.98 0.96 58CV(A,X)070 ---12
CSPH*3012A** 0.96 0.92 58CV(A,X)070---12
CSPH*3612A** 0.97 0.93 58CV(A,X)070---12
CAP**3017A** 0.99 0.94 58CV(A,X)090---16
CAP**3617A** 0.99 0.95 58CV(A,X)090---16
CNPV*3017A** 0.98 0.94 58CV(A,X)090 ---16
CNPV*3617A** 0.98 0.94 58CV(A,X)090 ---16
CAP**3621A** 0.99 0.95 58CV(A,X)110---20
CNPV*3621A** 0.99 0.94 58CV(A,X)110 ---20
CNPH*3017A** 0.98 0.96 58MVB040---14
CNPH*3617A** 0.98 0.96 58MVB040---14
CSPH*3012A** 0.96 0.94 58MVB040---14
CSPH*3612A** 0.97 0.93 58MVB040---14
CAP**3017A** 0.99 0.94 58MVB060---14
CAP**3617A** 0.99 0.94 58MVB060---14
CNPV*3017A** 0.98 0.94 58MVB060---14
CNPV*3617A** 0.98 0.94 58MVB060---14
CAP**3621A** 0.99 0.95 58MVB080---14
CNPV*3621A** 0.98 0.94 58MVB080---14
See notes on pg. 21
24ACA3

18
DETAILED COOLING CAPACITIES{{ (CONT.)
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sen s‡ To t a l Sens ‡To t a l Sens ‡
24ACA336A30 Outdoor Section With CAP**3617A** Indoor Section
1050
72 40.12 21.34 2.48 38.42 20.70 2.74 36.61 20.02 3.03 34.70 19.31 3.35 32.62 18.55 3.71 30.32 17.72 4.09
67 36.62 26.34 2.47 35.03 25.67 2.73 33.34 24.97 3.02 31.55 24.24 3.34 29.62 23.47 3.70 27.50 22.62 4.09
62 33.54 31.31 2.46 32.11 30.61 2.72 30.61 29.86 3.01 29.06 29.06 3.34 27.62 27.62 3.70 25.99 25.99 4.09
57 32.88 32.88 2.46 31.70 31.70 2.72 30.44 30.44 3.01 29.09 29.09 3.34 27.63 27.63 3.70 26.00 26.00 4.09
1200
72 40.72 22.34 2.54 38.96 21.69 2.80 37.09 21.00 3.09 35.11 20.28 3.41 32.97 19.51 3.76 30.60 18.67 4.15
67 37.19 27.96 2.53 35.54 27.28 2.79 33.80 26.58 3.08 31.96 25.85 3.40 29.98 25.06 3.76 27.81 24.20 4.15
62 34.30 33.50 2.52 32.84 32.84 2.78 31.55 31.55 3.07 30.12 30.12 3.40 28.56 28.56 3.75 26.83 26.83 4.14
57 34.15 34.15 2.52 32.89 32.89 2.78 31.55 31.55 3.07 30.12 30.12 3.40 28.56 28.56 3.75 26.83 26.83 4.14
1350
72 41.16 23.27 2.60 39.34 22.61 2.86 37.42 21.92 3.14 35.40 21.20 3.47 33.21 20.42 3.82 30.78 19.57 4.21
67 37.62 29.51 2.59 35.93 28.83 2.85 34.15 28.12 3.14 32.27 27.38 3.46 30.25 26.57 3.81 28.05 25.67 4.20
62 35.18 35.18 2.58 33.86 33.86 2.84 32.45 32.45 3.13 30.95 30.95 3.46 29.31 29.31 3.81 27.50 27.50 4.20
57 35.19 35.19 2.58 33.86 33.86 2.84 32.46 32.46 3.13 30.95 30.95 3.46 29.31 29.31 3.81 27.50 27.50 4.20
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor Model Capacity Power Furnace Model
*CAP**3617A** 1.00 1.00
CAP**3614A** 0.97 0.97
CAP**3621A** 1.00 1.00
CAP**4221A** 1.00 1.00
CAP**4224A** 1.00 1.00
CNPF*3618A** 0.99 0.99
CNPH*3617A** 0.99 0.99
CNPH*4221A** 1.00 1.00
CNPV*3617A** 0.99 0.99
CNPV*3621A** 0.99 0.99
CNPV*4221A** 1.00 1.00
CSPH*3612A** 0.99 0.99
CSPH*4212A** 0.99 0.98
FE4ANB006 1.04 0.95
FE4ANF002 0.99 0.95
FE4ANF003 1.00 0.94
FE4ANF005 1.03 0.94
FF1ENP036 0.99 0.99
FV4BNB006 1.04 0.95
FV4BNF002 0.99 0.95
FV4BNF003 1.00 0.94
FV4BNF005 1.03 0.94
FX4CN(B,F)036 1.01 0.97
FX4CN(B,F)042 1.02 0.98
FY4ANF036 0.99 0.99
FY4ANF042 1.01 1.01
Cooling Indoor Model Capacity Power Furnace Model
CAP**3614A** 0.97 0.95 58CV(A,X)070---12
CNPH*3617A** 0.98 0.96 58CV(A,X)070 ---12
CNPH*4221A** 1.01 0.96 58CV(A,X)070 ---12
CSPH*3612A** 0.98 0.93 58CV(A,X)070---12
CSPH*4212A** 1.00 0.98 58CV(A,X)070---12
CAP**3617A** 0.99 0.95 58CV(A,X)090---16
CNPV*3617A** 0.98 0.94 58CV(A,X)090 ---16
CAP**3621A** 0.99 0.95 58CV(A,X)110---20
CAP**4221A** 1.00 0.96 58CV(A,X)110---20
CNPV*3621A** 0.99 0.98 58CV(A,X)110 ---20
CNPV*4221A** 1.02 0.96 58CV(A,X)110 ---20
CAP**4224A** 1.00 0.94 58CV(A,X)135---22
CAP**4224A** 0.99 0.95 58MVB040---14
CNPH*3617A** 0.98 0.96 58MVB040---14
CNPH*4221A** 1.01 0.96 58MVB040---14
CSPH*3612A** 0.98 0.93 58MVB040---14
CSPH*4212A** 0.99 0.98 58MVB040---14
CAP**3617A** 0.99 0.95 58MVB060---14
CNPH*4221A** 1.01 0.97 58MVB060---14
CNPV*3617A** 0.98 0.96 58MVB060---14
CAP**3621A** 0.99 0.97 58MVB080---14
CAP**4221A** 0.99 0.95 58MVB080---14
CNPV*3621A** 0.99 0.99 58MVB080---14
CNPV*4221A** 1.01 0.96 58MVB080---14
See notes on pg. 21
24ACA3

19
DETAILED COOLING CAPACITIES{{ (CONT.)
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ACA342A30 Outdoor Section With CAP**4221A** Indoor Section
1225
72 48.51 25.52 3.33 46.40 24.71 3.68 44.17 23.86 4.08 41.83 22.99 4.51 39.30 22.05 4.99 36.50 21.03 5.51
67 44.49 31.40 3.31 42.53 30.57 3.66 40.46 29.71 4.06 38.30 28.81 4.50 35.96 27.87 4.98 33.41 26.84 5.51
62 40.85 37.25 3.29 39.08 36.40 3.65 37.24 35.50 4.04 35.33 34.54 4.48 33.39 33.39 4.97 31.44 31.44 5.50
57 39.76 39.76 3.29 38.32 38.32 3.64 36.79 36.79 4.04 35.17 35.17 4.48 33.41 33.41 4.97 31.45 31.45 5.50
1400
72 49.22 26.65 3.40 47.02 25.82 3.76 44.72 24.97 4.15 42.30 24.08 4.59 39.69 23.14 5.07 36.79 22.10 5.59
67 45.18 33.25 3.38 43.15 32.40 3.74 41.00 31.53 4.13 38.76 30.63 4.57 36.37 29.68 5.05 33.74 28.63 5.58
62 41.71 39.81 3.37 39.92 38.90 3.72 38.04 38.04 4.12 36.38 36.38 4.56 34.50 34.50 5.05 32.41 32.41 5.58
57 41.28 41.28 3.37 39.74 39.74 3.72 38.11 38.11 4.12 36.38 36.38 4.56 34.50 34.50 5.05 32.41 32.41 5.58
1575
72 49.76 27.73 3.48 47.49 26.90 3.84 45.12 26.04 4.23 42.63 25.14 4.67 39.95 24.19 5.14 36.99 23.14 5.66
67 45.71 35.04 3.46 43.61 34.19 3.82 41.42 33.32 4.21 39.13 32.41 4.65 36.68 31.44 5.13 33.99 30.36 5.65
62 42.55 42.13 3.45 40.89 40.89 3.80 39.17 39.17 4.20 37.34 37.34 4.64 35.37 35.37 5.12 33.16 33.16 5.65
57 42.52 42.52 3.45 40.89 40.89 3.80 39.17 39.17 4.20 37.35 37.35 4.64 35.37 35.37 5.12 33.16 33.16 5.65
Multipliers for Determining the Performance With Other Indoor Sections
Indoor Model Capacity Power Furnace Model
*CAP**4221A** 1.00 1.00
CAP**4224A** 1.00 1.00
CAP**4817A** 0.98 0.98
CAP**4821A** 1.01 1.01
CAP**4824A** 1.01 1.01
CNPF*4818A** 1.01 1.01
CNPH*4221A** 1.00 1.00
CNPH*4821A** 1.01 1.01
CNPV*4221A** 1.00 1.00
CNPV*4821A** 0.99 0.99
CNPV*4824A** 1.01 1.01
CSPH*4212A** 0.99 0.99
CSPH*4812A** 1.00 1.00
FE4ANB006 1.04 0.95
FE4ANF003 0.99 0.94
FE4ANF005 1.02 0.96
FV4BNB006 1.04 0.95
FV4BNF003 0.99 0.94
FV4BNF005 1.01 0.95
FX4CN(B,F)042 1.01 0.99
FX4CN(B,F)048 1.04 0.99
FY4ANF042 1.00 1.00
FY4ANF048 1.02 1.02
Indoor Model Capacity Power Furnace Model
CNPH*4221A** 0.99 0.97 58CV(A,X)070---12
CNPH*4821A** 1.00 0.98 58CV(A,X)070---12
CSPH*4212A** 0.98 0.96 58CV(A,X)070---12
CSPH*4812A** 0.98 0.96 58CV(A,X)070---12
CAP**4817A** 0.98 0.93 58CV(A,X)090 ---16
CAP**4221A** 0.99 0.97 58CV(A,X)110 ---20
CAP**4821A** 1.00 0.96 58CV(A,X)110 ---20
CNPV*4221A** 0.98 0.93 58CV(A,X)110---20
CNPV*4821A** 1.00 0.96 58CV(A,X)110---20
CAP**4224A** 0.99 0.94 58CV(A,X)135 ---22
CAP**4824A** 1.00 0.94 58CV(A,X)135 ---22
CNPV*4824A** 0.99 0.93 58CV(A,X)135---22
CAP**4224A** 0.98 0.96 58MVB040---14
CAP**4824A** 1.00 0.98 58MVB040---14
CNPH*4221A** 0.98 0.96 58MVB040---14
CNPH*4821A** 0.99 0.97 58MVB040---14
CNPV*4824A** 1.00 0.98 58MVB040---14
CSPH*4212A** 0.98 0.96 58MVB040---14
CSPH*4812A** 0.98 0.96 58MVB040---14
CAP**4817A** 0.98 0.93 58MVB060---14
CAP**4221A** 0.98 0.96 58MVB080---14
CAP**4821A** 0.99 0.97 58MVB080---14
See notes on pg. 21
24ACA3

20
DETAILED COOLING CAPACITIES{{ (CONT.)
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
Capacity
MBtuh† To t a l
System
KW**
To t a l Sens
‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡To t a l Sens ‡
24ACA348A30 Outdoor Section With CAP**4821A** Indoor Section
1400
72 55.04 28.49 3.35 52.62 27.54 3.75 50.08 26.56 4.20 47.38 25.54 4.72 44.49 24.45 5.30 41.25 23.26 6.01
67 49.86 34.52 3.35 47.63 33.55 3.75 45.27 32.56 4.21 42.77 31.51 4.73 40.10 30.41 5.33 37.08 29.19 6.08
62 45.26 40.60 3.35 43.30 39.77 3.76 41.26 38.91 4.22 39.15 38.04 4.74 37.27 37.27 5.34 35.05 35.05 6.09
57 44.65 44.65 3.35 42.99 42.99 3.76 41.23 41.23 4.22 39.35 39.35 4.74 37.33 37.33 5.34 35.06 35.06 6.09
1600
72 56.06 29.65 3.42 53.54 28.69 3.82 50.89 27.69 4.27 48.09 26.65 4.79 45.09 25.55 5.36 41.76 24.34 6.06
67 50.79 36.35 3.42 48.45 35.38 3.82 46.00 34.36 4.28 43.40 33.30 4.80 40.63 32.17 5.39 37.50 30.93 6.14
62 46.36 43.45 3.42 44.40 42.66 3.83 42.52 41.92 4.17 40.77 40.77 4.81 38.63 38.63 5.40 36.19 36.19 6.15
57 46.41 46.41 3.42 44.64 44.64 3.83 42.77 42.77 4.28 40.78 40.78 4.81 38.63 38.63 5.40 36.19 36.19 6.15
1800
72 56.83 30.71 3.49 54.22 29.73 3.89 51.49 28.72 4.34 48.61 27.66 4.85 45.53 26.54 5.43 42.11 25.32 6.12
67 51.48 38.05 3.49 49.06 37.05 3.89 46.53 36.02 4.35 43.86 34.94 4.87 41.00 33.80 5.46 37.80 32.58 6.20
62 47.45 46.27 3.50 45.69 45.69 3.90 44.03 44.03 4.36 41.94 41.94 4.88 39.69 39.69 5.47 37.12 37.12 6.21
57 47.87 47.87 3.49 46.01 46.01 3.90 44.04 44.04 4.36 41.95 41.95 4.88 39.69 39.69 5.47 37.13 37.13 6.21
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor
Model Capacity Power Furnace Model
*CAP**4821A** 1.00 1.00
CAP**4817A** 0.99 0.99
CAP**4824A** 1.00 1.00
CAP**6021A** 1.02 1.02
CAP**6024A** 1.02 1.02
CNPF*4818A** 0.98 0.98
CNPH*4821A** 1.00 1.00
CNPH*6024A** 1.02 1.02
CNPV*4221A** 0.97 0.97
CNPV*4821A** 1.00 1.00
CNPV*4824A** 1.00 1.00
CNPV*6024A** 1.02 1.02
CSPH*4812A** 0.99 0.99
CSPH*6012A** 1.00 1.00
FE4ANB006 1.02 0.96
FE4ANF005 1.01 0.97
FV4BNB006 1.02 0.96
FV4BNF005 1.01 0.97
FX4CN(B,F)048 1.02 1.00
FX4CN(B,F)060 1.03 0.99
FY4ANB060 1.01 1.01
FY4ANF048 1.00 1.00
Cooling Indoor
Model Capacity Power Furnace Model
CAP**4817A** 0.99 0.97 58CV(A,X)090---16
CNPH*4821A** 0.98 0.96 58CV(A,X)090---16
CNPH*6024A** 1.00 0.98 58CV(A,X)090---16
CSPH*4812A** 0.97 0.95 58CV(A,X)090 ---16
CSPH*6012A** 0.98 0.96 58CV(A,X)090 ---16
CAP**4821A** 0.98 0.96 58CV(A,X)110 ---20
CAP**6021A** 1.03 1.01 58CV(A,X)110 ---20
CNPH*4821A** 0.99 0.97 58CV(A,X)110---20
CNPH*6024A** 1.00 0.98 58CV(A,X)110---20
CNPV*4221A** 0.97 0.95 58CV(A,X)110---20
CNPV*4821A** 0.98 0.96 58CV(A,X)110---20
CAP**4824A** 0.99 0.97 58CV(A,X)135 ---22
CAP**6024A** 1.01 0.97 58CV(A,X)135 ---22
CNPV*4824A** 0.99 0.97 58CV(A,X)135---22
CNPV*6024A** 1.00 0.96 58CV(A,X)135---22
CAP**4821A** 0.98 0.98 58MVB080---20
CAP**6021A** 1.00 0.98 58MVB080---20
CNPH*4821A** 0.98 0.98 58MVB080---20
CNPH*6024A** 1.00 0.98 58MVB080---20
CNPV*4221A** 0.97 0.97 58MVB080---20
CNPV*4821A** 0.98 0.98 58MVB080---20
CSPH*4812A** 0.97 0.97 58MVB080---20
CSPH*6012A** 0.98 0.96 58MVB080---20
CAP**4821A** 0.98 0.94 58MVB100---20
CNPH*4821A** 0.98 0.96 58MVB100---20
CNPH*6024A** 1.00 0.98 58MVB100---20
CAP**4824A** 0.98 0.96 58MVB120---20
CAP**6024A** 1.00 0.96 58MVB120---20
CNPV*4824A** 0.99 0.97 58MVB120---20
CNPV*6024A** 1.00 0.98 58MVB120---20
See notes on pg. 21
24ACA3
