Infinity™ 18
38TDB (60 Hz)
Two-Speed Air Conditioner
with Puron
®
Refrigerant
Sizes 024, 036, 037, 048, and 060
Copyright 2004 Carrier Corporation Form 38TDB-6PD
The Model 38TDB Infinity™ Air
Conditioner incorporates innovative
two-speed compressor technology with
Puron® refrigerant, providing quiet,
efficient cooling performance. Built into
these units are features most desired by
homeowners today, including SEER
ratings up to 18.0 when matched with a
VARIABLE SPEED indoor Carrier
product. All models are listed with UL
(U.S. and Canada), ARI and CEC. The
38TDB exceeds the Energy Star®
requirements for energy efficiency.
FEATURES/BENEFITS
Electrical Range —
All units are
offered in 208/230v single phase. Sim-
plified field-stripped lead wire connec-
tions facilitate ease of installation.
Range of Sizes —
Available in 5
nominal sizes: 024, 036, 037, 048, and
060 to meet the needs of residential
applications.
Carrier’s Infinity™ Controls
—
These industry-leading controls, when
installed with Carrier’s Ideal Humidity™
variable-speed furnaces or fan coils,
provide the homeowner with:
–unparalleled control of temperature,
humidity, indoor air quality, and zoning
–unprecedented ease of use
–simple operation through on-screen,
text-based service reminders
–worry-free equipment malfunction alert
on the two-speed outdoor section
Optional remote access through telephone
or Internet is also available when
combined with a remote connectivity kit.
WeatherArmor™ III System
is a
three component system—The casing
steel is galvanized and coated with a
layer of zinc phosphate. A modified
polyester powder coating is then applied
and baked on, providing each unit with a
hard, smooth finish that will last for
many years.
All screws on the cabinet exterior are
SermaGuard™ coated for a long lasting,
2
Model number nomenclature
38TDB 036 3 0 1
18 SEER
2-Speed Air Conditioner Packaging
Nominal Capacity
024
—
24,000 Btuh
036 — 36,000 Btuh
037 — 37,000 Btuh
048 — 48,000 Btuh
060 — 60,000 Btuh
Series
Electrical
3 — 208/230-1
rust-resistant, quality appearance.
The coil is protected by an enhanced
WeatherArmor™ heavy duty inlet grille.
Constructed of a coated steel wire grid
and with spacing of 3/8 in., the guard
helps to protect the coil from inclement
weather, vandalism and incidental
damage. It provides protection while
not restricting airflow and maintain-
ing ease of coil inspection and
cleaning.
Unit Design —
The coil incorporates
copper tubing and enhanced, aluminum
fins for optimum heat transfer. Hot con-
denser air and sound are discharged ver-
tically and away from adjacent patio
areas and foliage. Polymer spacers raise
the coil in a heat pump style basepan for
easy removal of water, dirt, and debris.
An electronic ECM condenser fan
(037 only) motor provides multi-speed
operation and enhanced low-speed effi-
ciencies and sound levels.
Auto-reset high- and low-pressure
switches continuously monitor system
operation.
A compressor crankcase heater, ener-
gized during the compressor off cycle,
helps to provide reliable starting.
Application Versatility —
This unit
can be combined with a wide variety of
evaporator coils and fan coils to provide
quiet, dependable comfort. Unit can be
installed on a roof or at ground level on a
slab.
External Service Valves —
Both
service valves are brass, back seating type
with sweat connections. Valves are exter-
nally located so refrigerant connections
can be made quickly and easily. Each
valve has a service port for ease of check-
ing operating refrigerant pressures.
Easy Serviceability —
Removal of
access panel and control box cover
provides easy access to all electrical con-
trols and compressor. Removal of top
provides access to fan motor and coil.
A self-diagnostic indicator on the
electronic control board informs the ser-
vice technician of the failed component.
Compressor Protection —
The com-
pressor is protected with internal over-
loads. An internal pressure relief valve
provides high-pressure protection to the
refrigerant system.
Standard Features —
An electronic
control eliminates excessive wiring. A
compressor sound hood and discharge
muffler provide improved sound levels
as well as sound quality.
Important —
When selecting an
indoor blower section to be installed
with the two-speed unit, variable speed
indoor blower technology is recom-
mended. Some 5-speed tap PSC motor
products can be applied but detailed
engineering of the total system static
pressure is required. Very few 4-speed
tap PSC indoor motor products can be
installed with the two-speed unit. It is
important to match CFM for high-speed
capacity and low-speed capacity as
stated in the combination rating tables.
To derive all the benefits of improved
room humidity and temperature control,
lower noise levels, and maximum
energy savings, it is recommended that
you use variable speed indoor blower
technologies. See product data digest for
CFM requirements for low-speed capac-
ity and high-speed capacity operation.
If your CFM is higher than the
required CFM for low-speed capacity
operation, you may have little latent heat
removal, resulting in lower comfort lev-
els in high humidity climates. If your
climate is hot with little to no humidity,
this mode of operation may be desired.
Compressor Start Assist —
Capaci-
tor and relay.
Expansion Valve —
This unit must
be installed with a Puron-refrigerant
TXV on the indoor coil. The FV4 indoor
fan coils and the CK5P indoor furnace
coils come factory equipped with a bi-
flow balance port Puron-refrigerant
TXV. When installed in this application,
no further change is required. If any
other indoor fan coil or furnace coil is
used, an accessory bi-flow, balance port
TXV must be installed. See accessory
list in this publication for correct part
number. A Puron refrigerant, hard shut
off, balance port TXV is shipped only
with the 037 size for field installation.
Limited Warranty —
Five-year
limited warranty on all parts and a ten-
year limited warranty on the compressor
parts. Refer to warranty certificate for
specific details.
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
1
0
U
N
I
T
A
R
Y
A
I
R
C
O
N
D
I
T
I
O
N
I
N
G
E
Q
U
I
P
M
E
N
T
REGISTERED QUALITY SYSTEM
CERTIFICATION APPLIES
ONLY WHEN THE
COMPLETE SYSTEM
IS LISTED WITH ARI.
As an ENERGY STAR
®
Partner, Carrier
Corporation has determined that this
product meets the ENERGY STAR
®
guidelines for energy efficiency.
*
*Refer to the combination ratings in the Product Data Digest for system combinations meeting ENERGY STAR®efficiency standards.
3
Physical data
NOTE:
See unit installation instructions for proper installation.
* Tube sizes are for runs up to 50 ft horizontal and/or 20 ft vertical differential. Standard long line–up to 175 ft.
†High speed
Accessories
* When applied with Carrier’s IdealHumidity™series 58MVP, 58CV(A,X) and FE Indoor Models.
‡‡Must be installed in Dual-Fuel Infinity system applications.
UNIT SIZE - SERIES 024-30 036-30 037-30 048-30 060-31
OPERATING WEIGHT (Lb)
171 228 276 266 311
REFRIGERANT
Puron®(R-410A)
Cooling Control
TXV
Charge (Lb)
6.0 8.9 12.3 11.5 13.1
CONDENSER FAN
Propeller Type, Direct Drive
Air Discharge
Vertical
Air Qty (CFM)
1500 2500 2750†3000 3100
Motor HP
1/15 1/8 1/5 1/5 1/5
Motor RPM
825 825 840†825 825
CONDENSER COIL
Copper Tube, Aluminum Plate Fin
Face Area (Sq Ft)
10.8 18.2 18.2 18.2 18.2
Fins per in.
25 25 20 20 20
Rows
11222
Circuits
2/1 3/1 4/1 5/1 5/1
VALVE CONNECT. (In. ID)
Sweat
Vapor
5/8 3/4 7/8 7/8 7/8
Liquid
3/8
REFRIG TUBES* (In. OD)
Vapor
5/8 3/4 7/8 7/8 1-1/8
Liquid
3/8
LONG LINE REFRIGERANT TUBES (In. OD)
Vapor
3/4 7/8 7/8 7/8 1-1/8
Liquid
3/8
ORDERING NO. DESCRIPTION
KAACF0801MED
Coastal Filter —Sizes 024-060
KSASF0101AAA
Support Feet (4)
KSATX0201PUR
Bi-flow Balance Port TXV (Hard Shut Off)-Size 024
KSATX0301PUR
Bi-flow Balance Port TXV (Hard Shut Off)-Size 036
KSATX0401PUR
Bi-flow Balance Port TXV (Hard Shut Off)-Size 048
KSATX0501PUR
Bi-flow Balance Port TXV (Hard Shut Off)-Size 060
THERMOSTAT DESCRIPTION
TSTATCCPRH01-B
Carrier Thermidistat™Control —Non-Programmable/Programmable Thermostat with Humidity Control
(For use in Dual Fuel, AC, HP, and 2S applications. Includes Outdoor Air Temperature Sensor.)
TSTATCCP2S01-B
Carrier Thermostat, Auto Changeover, 7-Day Programmable, °F/°C, 2-Stage Heat/2-Stage Cool in AC
Mode, 3-Stage Heat/2-Stage Cool in HP mode
TSTATCCN2S01-B
Carrier Thermostat, Auto Changeover, Non-Programmable, °F/°C, 2-Stage Heat/2-Stage Cool in AC
Mode, 3-Stage Heat/2-Stage Cool in HP mode
TSTATXXSEN01-B
Outdoor Temperature Sensor
TSTATXXNBP01
Backplate for Non-Programmable Thermostat
TSTATXXPBP01
Backplate for Programmable Thermostat
TSTATXXCNV10
Thermostat Conversion Kit (4 to 5 Wire) —10 Pack
INFINITY™* CONTROLS DESCRIPTION
SYSTXCCUID01
Infinity Control Deluxe 7-Day Programmable (Wall-mounted system control.)
SYSTXCCUIZ01
Infinity Control Deluxe Zoning 7-Day Programmable (Wall-mounted control for a multi-zone system.)
SYSTXCC4ZC01
Infinity 4-Zone Damper Control Module (Wall-mounted control for a four-zone system.)
SYSTXCCSMS01
Infinity Smart Sensor (Optional wall control used to monitor temperature and/or fan control in an
individual zone.)
SYSTXCCRRS01
Infinity Remote Room Sensor (Monitors temperature in an individual zone.)
SYSTXCCSAM01
Infinity System Access Module (Hardware for wireless access and control via phone or internet.)
SYSTXCCNIM01‡‡
Infinity Network Interface Module (Connects Heat Recovery and Energy Recovery Ventilators or older two-
speed outdoor models to system.)
SYSTXXXBPU01
Decorative Back Plate for Infinity Control (Decorative wall plate.)
Z
O
N
I
N
G
4
Accessory Description and Usage (Listed Alphabetically)
1.
Coastal Filter
A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from salt damage without restricting airflow.
Usage Guideline:
Suggested in geographic areas where salt damage could occur.
2.
Outdoor Air Temperature Sensor
A device that allows the temperature at a remote location (outdoors) to be displayed at the thermostat.
Usage Guideline:
Suggested in all Carrier programmable thermostats.
3.
Support Feet
Four stick-on plastic feet that raise the unit 4 in. above the mounting pad. This allows sand, dirt, and other debris to be flushed from the unit base, minimizing
corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
4.
Thermostatic Expansion Valve (TXV)
A modulating, flow-control valve that meters refrigerant liquid flow rate into the evaporator in response to the superheat of the refrigerant gas leaving the evap-
orator. Kit includes valve, adapter tubes, and external equalizer tube.
NOTE:
Furnace coils and variable-speed fan coils designed for Puron refrigerant are factory supplied with balanced-port Puron-refrigerant TXV.
Usage Guideline:
A balanced-port TXV specifically designed for Puron refrigerant is required for all installations.
* Permissible limits of the voltage range at which unit will operate sat-
isfactorily.
†If wire is applied at ambient greater than 30°C (86°F), consult Table
310-16 of the NEC (ANSI/NFPA 70). The ampacity of nonmetallic-
sheathed cable (NM), trade name ROMEX, shall be that of 60°C
(140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-26. If
other than uncoated (non-plated), 60 or 75°C (140 or 167°F) insula-
tion, copper wire (solid wire for 10 AWG and smaller, stranded wire
for larger than 10 AWG) is used, consult applicable tables of the NEC
(ANSI/NFPA 70).
‡Length shown is as measured 1 way along wire path between unit
and service panel for voltage drop not to exceed 2%.
** Time-delay fuse.
FLA
—Full Load Amps
LRA
—Locked Rotor Amps
MCA
—Minimum Circuit Amps
RLA
—Rated Load Amps
NOTES:
1. Control circuit is 24-v on all units and requires external
power source.
2. Copper wire must be used from service disconnect to unit.
3. All motors and compressors contain internal overload pro-
tection.
CHARGING SUBCOOLING* (TXV-TYPE EXPANSION DEVICE)
*Charge in high speed only.
A-WEIGHTED SOUND POWER (dBA)
*Sound levels at high and low speeds are equivalent.
NOTE: Tested in accordance with ARI standard 270.95. (Not listed with ARI.)
UNIT
SIZE HIGH
024
14
036
15
037
11
048
12
060
16
UNIT
SIZE
STANDARD
RATING*
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
024
72 44.4 59.9 58.3 62.0 55.2 51.5 42.9
036
72 52.4 63.4 59.3 64.0 55.2 52.0 44.9
037
74 51.4 61.9 62.3 68.5 55.7 51.5 44.9
048
75 53.9 60.9 61.8 71.5 60.7 54.0 46.9
060
76 54.4 59.9 59.3 62.0 60.7 55.5 47.9
Electrical data
UNIT
SIZE-
SERIES V/PH
OPER VOLTS* COMPR
FAN
FLA MCA
MIN
WIRE
SIZE†
60°C/75°C
MAX
LENGTH
(Ft)‡
60°C/75°C
MAX FUSE** OR
CKT BKR
AMPSMax Min LRA RLA
024-30
036-30
037-30
048-30
060-31
208/230-1 253 187
64.0 10.6 0.5 13.8 14/14 57/55 20
166.0 14.1 0.8 18.4 14/14 43/41 30
66.0 14.1 0.5 18.1 14/14 44/42 30
96.0 19.9 1.1 26.0 10/10 77/73 40
130.0 26.3 1.1 34.0 8/10 91/56 50
5
Dimensions
21/2
"
19/16
"
AIR DISCHARGE
43/16
"
3/8IN. DIA.
LIQUID LINE
CONN
13/4
"
FIELD POWER SUPPLY CONN
7/8IN. DIA HOLE WITH
11/8IN. DIA KNOCKOUT
AND
13/8IN. DIA KNOCKOUT
10 1/2
"
F
G
A
FIELD CONTROL SUPPLY
CONN 7/8IN. DIA HOLE
AIR DISCHARGE
AIR
DISCHARGE
AIR IN
AIR IN
AIR IN
HDIA VAPOR LINE CONN
3/8IN. DIA TIEDOWN
KNOCKOUTS (2)
PLACES IN BASEPAN B
11/4
"
M
ACCESS
PANEL
L
K
C
D
E
C
L
1. Allow 30 in. clearance to service side of unit, 48 in. above unit, 6 in.
on one side, 12 in. on remaining side, and 24 in. between units for proper airflow.
Minimum outdoor operating ambient in cooling mode is 55°F max 1252.
3. Series designation is the 13th position of the unit model number.
4. Center of gravity .
NOTES:
83/16
N
°F.
DIMENSIONS (IN.)
UNIT
SIZE SERIES
UNIT DIMENSIONS
MINIMUM
MOUNTING PAD
DIMENSIONS
ABCDEFGHKLMN
024 030 33-13/16 22-1/2 27-1/2 2-13/16 6-15/16 21-1/2 27-7/8 5/8 11 14 12-1/2 2-3/8 20 x 27
036 030 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 3/4 17 19-3/4 17-1/4 2-15/16 26 x 32
037 030 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 16-3/4 19-1/2 17 2-15/16 26 x 32
048 030 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 16-3/4 19-1/2 17 2-15/16 26 x 32
060 031 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 16-1/2 19 16-3/4 2-15/16 26 x 32
A02207
6
Combination ratings
*
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
024-30
*FV4BNF003 735 440 24,000 12,000 15.00 11.70
CC5A/CD5AA024 885 475 23,600 11,400 12.25 10.05
CC5A/CD5AA030 900 520 24,000 11,400 12.35 10.15
CC5A/CD5AA036 900 475 24,000 11,600 12.50 10.35
CC5A/CD5AW024 885 475 23,600 11,400 12.25 10.05
CC5A/CD5AW030 900 475 24,000 11,400 12.40 10.15
CC5A/CD5AW036 900 475 24,000 11,600 12.50 10.35
CE3AA024 885 475 23,800 11,400 12.35 10.10
CE3AA030 900 475 24,000 11,400 12.50 10.20
CE3AA036 900 475 24,000 11,600 12.50 10.25
CF5AA024 885 475 23,800 11,400 12.35 10.10
CF5AA036 900 475 24,000 11,600 12.50 10.30
CK3BA024 900 475 24,000 11,600 12.50 10.15
CK3BA030 900 475 24,000 11,600 12.50 10.20
CK3BA036 900 475 24,000 11,800 13.00 10.55
CK5A/CK5BA024 900 475 24,000 11,600 12.50 10.15
CK5A/CK5BA030 900 475 24,000 11,600 12.50 10.20
CK5A/CK5BA036 900 475 24,000 11,800 13.00 10.55
CK5A/CK5BT036 900 475 24,000 11,800 13.00 10.55
CK5A/CK5BW024 900 475 24,000 11,600 12.50 10.15
CK5A/CK5BW030 900 475 24,000 11,600 12.50 10.20
CK5A/CK5BW036 900 475 24,000 11,800 13.00 10.55
CK5PA024 900 475 24,000 11,600 12.50 10.15
CK5PA030 900 475 24,000 11,600 12.50 10.20
CK5PA036 900 475 24,000 11,800 13.00 10.55
CK5PT036 900 475 24,000 11,800 13.00 10.55
CK5PW024 900 475 24,000 11,600 12.50 10.15
CK5PW030 900 475 24,000 11,600 12.50 10.20
CK5PW036 900 475 24,000 11,800 13.00 10.55
FE4ANF002 735 440 24,000 11,800 14.85 11.50
FE4ANF003 735 440 24,000 12,000 15.00 11.70
FK4DNF001 735 440 24,000 11,800 14.50 11.40
FV4BNF002 735 440 24,000 11,800 14.85 11.50
40FKB/FK4DNF002 735 440 24,000 11,800 14.85 11.50
40FKB/FK4DNF003 735 440 24,000 12,000 15.00 11.70
COILS + 58CV(A,X)070-12 VARIABLE-SPEED FURNACE
CC5A/CD5AA024 700 525 23,000 11,800 14.00 11.00
CC5A/CD5AA030 700 525 23,400 11,800 14.00 11.25
CC5A/CD5AA036 700 525 24,000 12,000 14.50 11.50
CC5A/CD5AW024 700 525 23,200 11,800 14.00 11.10
CC5A/CD5AW030 700 525 23,400 11,800 14.00 11.25
CE3AA024 700 525 23,400 11,800 14.00 11.10
CE3AA030 700 525 23,800 12,000 14.50 11.30
CE3AA036 700 525 24,000 12,000 14.50 11.40
CK3BA024 700 525 23,600 12,000 14.50 11.30
CK3BA030 700 525 23,800 12,000 14.50 11.40
CK3BA036 700 525 24,000 12,000 14.50 11.55
CK5A/CK5BA024 700 525 24,000 12,000 14.50 11.45
CK5A/CK5BA030 700 525 24,000 12,000 14.50 11.50
CK5A/CK5BA036 700 525 24,000 12,000 14.50 11.55
CK5A/CK5BT036 700 525 24,000 12,000 14.50 11.55
CK5A/CK5BW024 700 525 24,000 12,000 14.50 11.45
CK5A/CK5BW030 700 525 24,000 12,000 14.50 11.50
CK5PA024 700 525 24,000 12,000 14.50 11.45
CK5PA030 700 525 24,000 12,000 14.50 11.50
CK5PA036 700 525 24,000 12,000 14.50 11.55
CK5PT036 700 525 24,000 12,000 14.50 11.55
CK5PW024 700 525 24,000 12,000 14.50 11.45
CK5PW030 700 525 24,000 12,000 14.50 11.50
COILS + 58CV(A,X)090-16 VARIABLE-SPEED FURNACE
CC5A/CD5AA024 700 525 23,200 11,800 14.00 11.10
CC5A/CD5AA030 700 525 23,600 11,800 14.50 11.30
CC5A/CD5AA036 700 525 24,000 12,000 14.50 11.60
CC5A/CD5AW024 700 525 23,200 11,800 14.00 11.15
CC5A/CD5AW030 700 525 23,600 11,800 14.50 11.30
CC5A/CD5AW036 700 525 24,000 12,000 14.50 11.60
CE3AA024 700 525 23,400 11,800 14.00 11.15
CE3AA030 700 525 23,800 12,000 14.50 11.40
CE3AA036 700 525 24,000 12,000 14.50 11.50
CK3BA024 700 525 23,600 12,000 14.50 11.40
CK3BA030 700 525 23,800 12,000 14.50 11.45
CK3BA036 700 525 24,000 12,000 15.00 11.65
CK5A/CK5BA024 700 525 24,000 12,000 14.50 11.50
CK5A/CK5BA030 700 525 24,000 12,000 14.50 11.55
CK5A/CK5BA036 700 525 24,000 12,000 15.00 11.65
CK5A/CK5BT036 700 525 24,000 12,000 15.00 11.65
CK5A/CK5BW024 700 525 24,000 12,000 14.50 11.55
CK5A/CK5BW030 700 525 24,000 12,000 14.50 11.60
CK5A/CK5BW036 700 525 24,000 12,000 15.00 11.65
CK5PA024 700 525 24,000 12,000 14.50 11.50
CK5PA030 700 525 24,000 12,000 14.50 11.55
CK5PA036 700 525 24,000 12,000 15.00 11.65
CK5PT036 700 525 24,000 12,000 15.00 11.65
See notes on pg.18.
7
024-30
CK5PW024 700 525 24,000 12,000 14.50 11.55
CK5PW030 700 525 24,000 12,000 14.50 11.60
CK5PW036 700 525 24,000 12,000 15.00 11.65
COILS + 58MVP040-14 VARIABLE-SPEED FURNACE
CC5A/CD5AW036 700 525 24,000 12,000 14.50 11.45
CE3AA024 700 525 23,200 11,800 14.00 10.95
CE3AA030 700 525 23,600 11,800 14.50 11.20
CE3AA036 700 525 23,800 12,000 14.50 11.30
CK5A/CK5BW036 700 525 24,000 12,000 14.50 11.45
CK5PW036 700 525 24,000 12,000 14.50 11.45
COILS + 58MVP060-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA024 700 525 22,800 11,600 14.00 10.95
CC5A/CD5AA030 700 525 23,200 11,800 14.00 11.15
CC5A/CD5AA036 700 525 24,000 12,000 14.50 11.45
CC5A/CD5AW024 700 525 23,000 11,600 14.00 11.00
CC5A/CD5AW030 700 525 23,200 11,800 14.00 11.15
CC5A/CD5AW036 700 525 24,000 12,000 14.50 11.45
CE3AA024 700 525 23,200 11,800 14.00 11.00
CE3AA030 700 525 23,400 11,800 14.50 11.20
CE3AA036 700 525 23,800 12,000 14.50 11.35
CK3BA024 700 525 23,400 12,000 14.50 11.25
CK3BA030 700 525 23,600 12,000 14.50 11.30
CK3BA036 700 525 24,000 12,000 14.50 11.45
CK5A/CK5BA024 700 525 23,400 11,800 14.00 11.10
CK5A/CK5BA030 700 525 23,600 12,000 14.50 11.20
CK5A/CK5BA036 700 525 24,000 12,000 14.50 11.50
CK5A/CK5BT036 700 525 24,000 12,000 14.50 11.50
CK5A/CK5BW024 700 525 23,400 11,800 14.00 11.15
CK5A/CK5BW030 700 525 23,600 12,000 14.50 11.25
CK5A/CK5BW036 700 525 24,000 12,000 14.50 11.50
CK5PA024 700 525 23,400 11,800 14.00 11.10
CK5PA030 700 525 23,600 12,000 14.50 11.20
CK5PA036 700 525 24,000 12,000 14.50 11.50
CK5PT036 700 525 24,000 12,000 14.50 11.50
CK5PW024 700 525 23,400 11,800 14.00 11.15
CK5PW030 700 525 23,600 12,000 14.50 11.25
CK5PW036 700 525 24,000 12,000 14.50 11.50
COILS + 58MVP080-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 700 525 24,000 12,000 14.50 11.40
CC5A/CD5AW024 700 525 23,000 11,800 14.00 11.00
CC5A/CD5AW030 700 525 23,400 11,800 14.00 11.15
CC5A/CD5AW036 700 525 24,000 12,000 14.50 11.40
CE3AA024 700 525 23,200 11,800 14.00 11.00
CE3AA030 700 525 23,600 11,800 14.50 11.20
CE3AA036 700 525 23,800 12,000 14.50 11.30
CK3BA024 700 525 23,400 12,000 14.50 11.20
CK3BA030 700 525 23,600 12,000 14.50 11.30
CK3BA036 700 525 24,000 12,000 14.50 11.45
CK5A/CK5BA036 700 525 24,000 12,000 14.50 11.45
CK5A/CK5BT036 700 525 24,000 12,000 14.50 11.45
CK5A/CK5BW024 700 525 23,400 11,800 14.00 11.10
CK5A/CK5BW030 700 525 23,600 12,000 14.50 11.25
CK5A/CK5BW036 700 525 24,000 12,000 14.50 11.45
CK5PA036 700 525 24,000 12,000 14.50 11.45
CK5PT036 700 525 24,000 12,000 14.50 11.45
CK5PW024 700 525 23,400 11,800 14.00 11.10
CK5PW030 700 525 23,600 12,000 14.50 11.25
CK5PW036 700 525 24,000 12,000 14.50 11.45
036-30
*FV4BNB006 1100 660 36,000 18,000 16.50 12.25
CC5A/CD5AA036 1300 720 34,800 17,400 13.50 10.50
CC5A/CD5AA042 1300 720 34,800 17,400 13.50 10.50
CC5A/CD5AC048 1280 720 34,400 17,200 13.00 10.40
CC5A/CD5AW036 1300 720 34,800 17,400 13.50 10.50
CC5A/CD5AW042 1280 720 34,400 17,200 13.50 10.45
CC5A/CD5AW048 1300 720 34,800 17,400 13.50 10.50
CD5AA048 1300 720 34,800 17,400 13.50 10.55
CE3AA036 1280 720 34,200 17,200 13.00 10.40
CE3AA042 1300 720 35,000 17,400 13.50 10.55
CE3AA048 1300 720 35,200 17,400 13.50 10.60
CF5AA036 1280 720 34,600 17,400 13.50 10.45
CF5AA048 1300 720 35,000 17,400 13.50 10.55
CK3BA036 1300 720 34,800 17,600 13.50 10.50
CK3BA042 1300 720 34,800 17,600 13.50 10.50
CK3BA048 1300 720 35,000 17,600 13.50 10.55
CK5A/CK5BA036 1300 720 34,800 17,600 13.50 10.50
CK5A/CK5BA042 1300 720 34,800 17,600 13.50 10.50
CK5A/CK5BA048 1300 720 35,000 17,600 13.50 10.60
CK5A/CK5BE042 1300 720 35,000 17,600 13.50 10.60
CK5A/CK5BT036 1300 720 34,800 17,600 13.50 10.50
CK5A/CK5BT042 1300 720 34,800 17,600 13.50 10.50
CK5A/CK5BT048 1300 720 35,000 17,600 13.50 10.60
CK5A/CK5BW036 1300 720 35,000 17,800 13.00 10.45
CK5A/CK5BW048 1300 720 35,000 17,600 13.50 10.60
CK5PA036 1300 720 34,800 17,600 13.50 10.50
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
Combination ratings (cont.)
See notes on pg.18.
,
,
8
Combination ratings (cont.)
036-30
CK5PA042 1300 720 34,800 17,600 13.50 10.50
CK5PA048 1300 720 35,000 17,600 13.50 10.60
CK5PE042 1300 720 35,000 17,600 13.50 10.60
CK5PT036 1300 720 34,800 17,600 13.50 10.50
CK5PT042 1300 720 34,800 17,600 13.50 10.50
CK5PT048 1300 720 35,000 17,600 13.50 10.60
CK5PW036 1300 720 35,000 17,800 13.00 10.45
CK5PW048 1300 720 35,000 17,600 13.50 10.60
FE4ANB006 1100 660 36,000 18,000 16.50 12.25
FE4ANF002 1100 660 34,200 17,800 15.00 10.95
FE4ANF003 1100 660 34,600 17,800 15.50 11.50
FE4ANF005 1100 660 36,000 18,000 16.00 11.95
FK4DNF001 1100 660 33,800 17,600 15.00 10.85
FV4BNF002 1100 660 34,200 17,800 15.00 10.95
FV4BNF003 1100 660 34,600 17,800 15.50 11.50
FV4BNF005 1100 660 36,000 18,000 16.00 11.95
40FKB/FK4DNB006 1100 660 36,000 18,000 16.50 12.25
40FKB/FK4DNF002 1100 660 34,200 17,800 15.00 10.95
40FKB/FK4DNF003 1100 660 34,600 17,800 15.50 11.50
40FKB/FK4DNF005 1100 660 36,000 18,000 16.00 11.95
COILS + 58CV(A,X)070-12 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 34,000 17,800 15.50 11.15
CE3AA036 1050 700 33,400 17,600 15.00 11.05
CK3BA036 1050 700 34,000 17,800 15.50 11.20
CK5A/CK5BA036 1050 700 34,000 17,800 15.50 11.20
CK5A/CK5BT036 1050 700 34,000 17,800 15.50 11.20
CK5PA036 1050 700 34,000 17,800 15.50 11.20
CK5PT036 1050 700 34,000 17,800 15.50 11.20
COILS + 58CV(A,X)090-16 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 34,000 17,800 15.50 11.35
CC5A/CD5AA042 1050 700 34,000 17,800 15.50 11.45
CC5A/CD5AC048 1050 700 33,800 17,800 15.50 11.35
CC5A/CD5AW036 1050 700 34,000 17,800 15.50 11.40
CD5AA048 1050 700 34,200 17,800 15.50 11.50
CE3AA036 1050 700 33,600 17,600 15.50 11.20
CE3AA042 1050 700 34,200 17,800 15.50 11.45
CE3AA048 1050 700 34,400 18,000 15.50 11.55
CK3BA036 1050 700 34,200 18,000 15.50 11.40
CK3BA042 1050 700 34,200 18,000 15.50 11.40
CK3BA048 1050 700 34,400 18,000 16.00 11.60
CK5A/CK5BA036 1050 700 34,200 18,000 15.50 11.35
CK5A/CK5BA042 1050 700 34,200 18,000 15.50 11.45
CK5A/CK5BA048 1050 700 34,400 18,000 16.00 11.55
CK5A/CK5BE042 1050 700 34,400 18,000 15.50 11.50
CK5A/CK5BT036 1050 700 34,200 18,000 15.50 11.35
CK5A/CK5BT042 1050 700 34,200 18,000 15.50 11.45
CK5A/CK5BT048 1050 700 34,400 18,000 16.00 11.55
CK5A/CK5BW036 1050 700 34,200 18,000 15.50 11.45
CK5PA036 1050 700 34,200 18,000 15.50 11.35
CK5PA042 1050 700 34,200 18,000 15.50 11.45
CK5PA048 1050 700 34,400 18,000 16.00 11.55
CK5PE042 1050 700 34,400 18,000 15.50 11.50
CK5PT036 1050 700 34,200 18,000 15.50 11.35
CK5PT042 1050 700 34,200 18,000 15.50 11.45
CK5PT048 1050 700 34,400 18,000 16.00 11.55
CK5PW036 1050 700 34,200 18,000 15.50 11.45
COILS + 58CV(A,X)110-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 34,000 17,800 15.50 11.45
CC5A/CD5AA042 1050 700 34,200 17,800 15.50 11.55
CC5A/CD5AC048 1050 700 33,800 17,800 15.50 11.45
CC5A/CD5AW036 1050 700 34,000 17,800 15.50 11.55
CC5A/CD5AW042 1050 700 34,200 17,800 15.50 11.60
CC5A/CD5AW048 1050 700 34,200 17,800 16.00 11.65
CD5AA048 1050 700 34,200 17,800 15.50 11.65
CE3AA036 1050 700 33,600 17,600 15.50 11.30
CE3AA042 1050 700 34,400 17,800 15.50 11.60
CE3AA048 1050 700 34,400 18,000 16.00 11.65
CK3BA036 1050 700 34,200 18,000 15.50 11.50
CK3BA042 1050 700 34,200 18,000 15.50 11.55
CK3BA048 1050 700 34,600 18,000 16.00 11.70
CK5A/CK5BA036 1050 700 34,200 18,000 15.50 11.45
CK5A/CK5BA042 1050 700 34,200 18,000 15.50 11.55
CK5A/CK5BA048 1050 700 34,600 18,000 16.00 11.70
CK5A/CK5BE042 1050 700 34,400 18,000 16.00 11.60
CK5A/CK5BT036 1050 700 34,200 18,000 15.50 11.45
CK5A/CK5BT042 1050 700 34,200 18,000 15.50 11.55
CK5A/CK5BT048 1050 700 34,600 18,000 16.00 11.70
CK5A/CK5BW036 1050 700 34,200 18,000 15.50 11.55
CK5A/CK5BW048 1050 700 34,600 18,000 16.00 11.75
CK5PA036 1050 700 34,200 18,000 15.50 11.45
CK5PA042 1050 700 34,200 18,000 15.50 11.55
CK5PA048 1050 700 34,600 18,000 16.00 11.70
CK5PE042 1050 700 34,400 18,000 16.00 11.60
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
See notes on pg.18.
9
Combination ratings (cont.)
036-30
CK5PT036 1050 700 34,200 18,000 15.50 11.45
CK5PT042 1050 700 34,200 18,000 15.50 11.55
CK5PT048 1050 700 34,600 18,000 16.00 11.70
CK5PW036 1050 700 34,200 18,000 15.50 11.55
CK5PW048 1050 700 34,600 18,000 16.00 11.75
COILS + 58CV(A,X)135-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 34,000 17,800 15.50 11.50
CC5A/CD5AC048 1050 700 33,800 17,800 15.50 11.40
CC5A/CD5AW036 1050 700 34,000 17,800 15.50 11.45
CC5A/CD5AW042 1050 700 34,200 17,800 15.50 11.60
CC5A/CD5AW048 1050 700 34,200 17,800 16.00 11.60
CD5AA048 1050 700 34,200 17,800 15.50 11.60
CE3AA036 1050 700 33,600 17,600 15.50 11.25
CE3AA042 1050 700 34,200 17,800 15.50 11.50
CE3AA048 1050 700 34,400 18,000 15.50 11.60
CK3BA036 1050 700 34,200 18,000 15.50 11.45
CK3BA042 1050 700 34,200 18,000 15.50 11.45
CK3BA048 1050 700 34,400 18,000 16.00 11.65
CK5A/CK5BA042 1050 700 34,200 18,000 15.50 11.50
CK5A/CK5BA048 1050 700 34,400 18,000 16.00 11.65
CK5A/CK5BT042 1050 700 34,200 18,000 15.50 11.50
CK5A/CK5BT048 1050 700 34,400 18,000 16.00 11.65
CK5A/CK5BW036 1050 700 34,200 18,000 15.50 11.50
CK5A/CK5BW048 1050 700 34,600 18,000 16.00 11.70
CK5PA042 1050 700 34,200 18,000 15.50 11.50
CK5PA048 1050 700 34,400 18,000 16.00 11.65
CK5PT042 1050 700 34,200 18,000 15.50 11.50
CK5PT048 1050 700 34,400 18,000 16.00 11.65
CK5PW036 1050 700 34,200 18,000 15.50 11.50
CK5PW048 1050 700 34,600 18,000 16.00 11.70
COILS + 58CV(A,X)155-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 34,200 17,800 15.50 11.60
CC5A/CD5AC048 1050 700 33,800 17,800 15.50 11.50
CC5A/CD5AW036 1050 700 34,200 17,800 15.50 11.55
CC5A/CD5AW042 1050 700 34,200 17,800 16.00 11.70
CC5A/CD5AW048 1050 700 34,200 17,800 16.00 11.70
CD5AA048 1050 700 34,400 17,800 16.00 11.70
CE3AA036 1050 700 33,600 17,600 15.50 11.30
CE3AA042 1050 700 34,400 17,800 15.50 11.60
CE3AA048 1050 700 34,600 18,000 16.00 11.70
CK3BA036 1050 700 34,200 18,000 15.50 11.50
CK3BA042 1050 700 34,200 18,000 16.00 11.55
CK3BA048 1050 700 34,600 18,000 16.00 11.75
CK5A/CK5BA042 1050 700 34,200 18,000 16.00 11.55
CK5A/CK5BA048 1050 700 34,600 18,000 16.00 11.75
CK5A/CK5BT042 1050 700 34,200 18,000 16.00 11.55
CK5A/CK5BT048 1050 700 34,600 18,000 16.00 11.75
CK5A/CK5BW036 1050 700 34,200 18,000 15.50 11.55
CK5A/CK5BW048 1050 700 34,600 18,000 16.00 11.80
CK5PA042 1050 700 34,200 18,000 16.00 11.55
CK5PA048 1050 700 34,600 18,000 16.00 11.75
CK5PT042 1050 700 34,200 18,000 16.00 11.55
CK5PT048 1050 700 34,600 18,000 16.00 11.75
CK5PW036 1050 700 34,200 18,000 15.50 11.55
CK5PW048 1050 700 34,600 18,000 16.00 11.80
COILS + 58MVP040-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 33,600 17,800 15.50 11.10
CC5A/CD5AC048 1050 700 33,200 17,600 15.00 11.00
CC5A/CD5AW036 1050 700 33,600 17,800 15.50 11.05
CC5A/CD5AW042 1050 700 33,000 17,600 15.00 11.00
CC5A/CD5AW048 1050 700 33,800 17,800 15.50 11.15
CD5AA048 1050 700 33,800 17,800 15.50 11.15
CE3AA036 1050 700 33,200 17,600 15.00 10.90
CE3AA042 1050 700 33,800 17,800 15.50 11.10
CE3AA048 1050 700 34,000 17,800 15.50 11.20
CK3BA042 1050 700 33,800 17,800 15.50 11.10
CK3BA048 1050 700 34,000 18,000 15.50 11.25
CK5A/CK5BA042 1050 700 33,800 17,800 15.50 11.10
CK5A/CK5BA048 1050 700 34,000 18,000 15.50 11.20
CK5A/CK5BT042 1050 700 33,800 17,800 15.50 11.10
CK5A/CK5BT048 1050 700 34,000 18,000 15.50 11.20
CK5A/CK5BW036 1050 700 33,800 17,800 15.50 11.10
CK5A/CK5BW048 1050 700 34,000 18,000 15.50 11.30
CK5PA042 1050 700 33,800 17,800 15.50 11.10
CK5PA048 1050 700 34,000 18,000 15.50 11.20
CK5PT042 1050 700 33,800 17,800 15.50 11.10
CK5PT048 1050 700 34,000 18,000 15.50 11.25
CK5PW036 1050 700 33,800 17,800 15.50 11.10
CK5PW048 1050 700 34,000 18,000 15.50 11.30
COILS + 58MVP060-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 33,600 17,600 15.50 11.15
CC5A/CD5AA042 1050 700 33,800 17,800 15.50 11.25
CC5A/CD5AC048 1050 700 33,400 17,600 15.50 11.15
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
See notes on pg.18.
10
Combination ratings (cont.)
036-30
CC5A/CD5AW036 1050 700 33,800 17,800 15.50 11.20
CD5AA048 1050 700 33,800 17,800 15.50 11.30
CE3AA036 1050 700 33,200 17,600 15.00 11.05
CE3AA042 1050 700 34,000 17,800 15.50 11.30
CE3AA048 1050 700 34,200 17,800 15.50 11.35
CK3BA036 1050 700 33,800 17,800 15.50 11.20
CK3BA042 1050 700 33,800 17,800 15.50 11.25
CK3BA048 1050 700 34,200 18,000 15.50 11.40
CK5A/CK5BA036 1050 700 33,800 17,800 15.50 11.20
CK5A/CK5BA042 1050 700 33,800 17,800 15.50 11.25
CK5A/CK5BA048 1050 700 34,200 18,000 15.50 11.40
CK5A/CK5BE042 1050 700 34,200 17,800 15.50 11.30
CK5A/CK5BT036 1050 700 33,800 17,800 15.50 11.20
CK5A/CK5BT042 1050 700 33,800 17,800 15.50 11.25
CK5A/CK5BT048 1050 700 34,200 18,000 15.50 11.40
CK5A/CK5BW036 1050 700 33,800 17,800 15.50 11.25
CK5PA036 1050 700 33,800 17,800 15.50 11.20
CK5PA042 1050 700 33,800 17,800 15.50 11.25
CK5PA048 1050 700 34,200 18,000 15.50 11.40
CK5PE042 1050 700 34,200 17,800 15.50 11.30
CK5PT036 1050 700 33,800 17,800 15.50 11.20
CK5PT042 1050 700 33,800 17,800 15.50 11.25
CK5PT048 1050 700 34,200 18,000 15.50 11.40
CK5PW036 1050 700 33,800 17,800 15.50 11.25
COILS + 58MVP080-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 33,600 17,800 15.00 10.95
CC5A/CD5AA042 1050 700 33,600 17,800 15.50 11.05
CC5A/CD5AC048 1050 700 33,200 17,600 15.00 10.95
CC5A/CD5AW036 1050 700 33,600 17,800 15.50 11.00
CC5A/CD5AW042 1050 700 33,000 17,600 15.00 10.95
CC5A/CD5AW048 1050 700 33,800 17,800 15.50 11.15
CD5AA048 1050 700 33,800 17,800 15.50 11.10
CE3AA036 1050 700 33,200 17,600 15.00 10.85
CE3AA042 1050 700 33,800 17,800 15.50 11.10
CE3AA048 1050 700 34,000 17,800 15.50 11.15
CK3BA036 1050 700 33,800 17,800 15.50 11.00
CK3BA042 1050 700 33,800 17,800 15.50 11.05
CK3BA048 1050 700 34,000 18,000 15.50 11.20
CK5A/CK5BA036 1050 700 33,600 17,800 15.50 11.00
CK5A/CK5BA042 1050 700 33,800 17,800 15.50 11.05
CK5A/CK5BA048 1050 700 34,000 18,000 15.50 11.20
CK5A/CK5BE042 1050 700 34,000 18,000 15.50 11.10
CK5A/CK5BT036 1050 700 33,600 17,800 15.50 11.00
CK5A/CK5BT042 1050 700 33,800 17,800 15.50 11.05
CK5A/CK5BT048 1050 700 34,000 18,000 15.50 11.20
CK5A/CK5BW036 1050 700 33,800 17,800 15.50 11.05
CK5A/CK5BW048 1050 700 34,000 18,000 15.50 11.25
CK5PA036 1050 700 33,800 17,800 15.50 11.00
CK5PA042 1050 700 33,800 17,800 15.50 11.05
CK5PA048 1050 700 34,000 18,000 15.50 11.20
CK5PE042 1050 700 34,000 18,000 15.50 11.10
CK5PT036 1050 700 33,800 17,800 15.50 11.00
CK5PT042 1050 700 33,800 17,800 15.50 11.05
CK5PT048 1050 700 34,000 18,000 15.50 11.20
CK5PW036 1050 700 33,800 17,800 15.50 11.05
CK5PW048 1050 700 34,000 18,000 15.50 11.25
COILS + 58MVP080-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 33,600 17,800 15.50 11.15
CC5A/CD5AA042 1050 700 33,800 17,800 15.50 11.20
CC5A/CD5AC048 1050 700 33,400 17,600 15.00 11.10
CC5A/CD5AW036 1050 700 33,800 17,800 15.50 11.20
CC5A/CD5AW042 1050 700 33,200 17,600 15.50 11.10
CC5A/CD5AW048 1050 700 33,800 17,800 15.50 11.25
CD5AA048 1050 700 33,800 17,800 15.50 11.25
CE3AA036 1050 700 33,200 17,600 15.00 11.00
CE3AA042 1050 700 34,000 17,800 15.50 11.25
CE3AA048 1050 700 34,200 17,800 15.50 11.30
CK3BA036 1050 700 33,800 17,800 15.50 11.15
CK3BA042 1050 700 33,800 17,800 15.50 11.20
CK3BA048 1050 700 34,200 18,000 15.50 11.35
CK5A/CK5BA036 1050 700 33,800 17,800 15.50 11.15
CK5A/CK5BA042 1050 700 33,800 17,800 15.50 11.20
CK5A/CK5BA048 1050 700 34,200 18,000 15.50 11.35
CK5A/CK5BE042 1050 700 34,200 18,000 15.50 11.30
CK5A/CK5BT036 1050 700 33,800 17,800 15.50 11.15
CK5A/CK5BT042 1050 700 33,800 17,800 15.50 11.20
CK5A/CK5BT048 1050 700 34,200 18,000 15.50 11.35
CK5A/CK5BW036 1050 700 33,800 17,800 15.50 11.20
CK5A/CK5BW048 1050 700 34,200 18,000 15.50 11.35
CK5PA036 1050 700 33,800 17,800 15.50 11.15
CK5PA042 1050 700 33,800 17,800 15.50 11.20
CK5PA048 1050 700 34,200 18,000 15.50 11.35
CK5PE042 1050 700 34,200 18,000 15.50 11.30
CK5PT036 1050 700 33,800 17,800 15.50 11.15
CK5PT042 1050 700 33,800 17,800 15.50 11.20
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
See notes on pg.18.
11
Combination ratings (cont.)
036-30
CK5PT048 1050 700 34,200 18,000 15.50 11.35
CK5PW036 1050 700 33,800 17,800 15.50 11.20
CK5PW048 1050 700 34,200 18,000 15.50 11.35
COILS + 58MVP100-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 33,800 17,800 15.50 11.15
CC5A/CD5AA042 1050 700 33,800 17,800 15.50 11.25
CC5A/CD5AC048 1050 700 33,400 17,600 15.50 11.15
CC5A/CD5AW036 1050 700 33,800 17,800 15.50 11.20
CC5A/CD5AW042 1050 700 33,200 17,600 15.50 11.10
CC5A/CD5AW048 1050 700 33,800 17,800 15.50 11.30
CD5AA048 1050 700 34,000 17,800 15.50 11.30
CE3AA036 1050 700 33,400 17,600 15.00 11.05
CE3AA042 1050 700 34,000 17,800 15.50 11.30
CE3AA048 1050 700 34,200 17,800 15.50 11.35
CK3BA036 1050 700 33,800 17,800 15.50 11.20
CK3BA042 1050 700 34,000 17,800 15.50 11.25
CK3BA048 1050 700 34,200 18,000 15.50 11.40
CK5A/CK5BA036 1050 700 33,800 17,800 15.50 11.20
CK5A/CK5BA042 1050 700 34,000 17,800 15.50 11.25
CK5A/CK5BA048 1050 700 34,200 18,000 15.50 11.40
CK5A/CK5BE042 1050 700 34,200 18,000 15.50 11.30
CK5A/CK5BT036 1050 700 33,800 17,800 15.50 11.20
CK5A/CK5BT042 1050 700 34,000 17,800 15.50 11.25
CK5A/CK5BT048 1050 700 34,200 18,000 15.50 11.40
CK5A/CK5BW036 1050 700 34,000 17,800 15.50 11.25
CK5A/CK5BW048 1050 700 34,200 18,000 15.50 11.40
CK5PA036 1050 700 33,800 17,800 15.50 11.20
CK5PA042 1050 700 34,000 17,800 15.50 11.25
CK5PA048 1050 700 34,200 18,000 15.50 11.40
CK5PE042 1050 700 34,200 18,000 15.50 11.30
CK5PT036 1050 700 33,800 17,800 15.50 11.20
CK5PT042 1050 700 34,000 17,800 15.50 11.25
CK5PT048 1050 700 34,200 18,000 15.50 11.40
CK5PW036 1050 700 34,000 17,800 15.50 11.25
CK5PW048 1050 700 34,200 18,000 15.50 11.40
COILS + 58MVP120-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 33,800 17,600 15.50 11.25
CC5A/CD5AC048 1050 700 33,400 17,600 15.00 11.20
CC5A/CD5AW036 1050 700 33,600 17,600 15.50 11.25
CC5A/CD5AW042 1050 700 33,200 17,600 15.50 11.20
CC5A/CD5AW048 1050 700 33,800 17,800 15.50 11.35
CD5AA048 1050 700 33,800 17,800 15.50 11.35
CE3AA036 1050 700 33,200 17,600 15.00 11.05
CE3AA042 1050 700 34,000 17,800 15.50 11.30
CE3AA048 1050 700 34,000 17,800 15.50 11.35
CK3BA042 1050 700 33,800 17,800 15.50 11.30
CK3BA048 1050 700 34,200 17,800 15.50 11.45
CK5A/CK5BA042 1050 700 33,800 17,800 15.50 11.30
CK5A/CK5BA048 1050 700 34,200 17,800 15.50 11.45
CK5A/CK5BT042 1050 700 33,800 17,800 15.50 11.30
CK5A/CK5BT048 1050 700 34,200 17,800 15.50 11.45
CK5A/CK5BW036 1050 700 33,800 17,800 15.50 11.30
CK5A/CK5BW048 1050 700 34,200 17,800 15.50 11.50
CK5PA042 1050 700 33,800 17,800 15.50 11.30
CK5PA048 1050 700 34,200 17,800 15.50 11.45
CK5PT042 1050 700 33,800 17,800 15.50 11.30
CK5PT048 1050 700 34,200 17,800 15.50 11.45
CK5PW036 1050 700 33,800 17,800 15.50 11.30
CK5PW048 1050 700 34,200 17,800 15.50 11.50
037-30
*FV4BNB006 1100 660 37,000 18,000 18.00 13.15
CC5A/CD5AA036 1310 720 35,800 17,400 14.50 11.30
CC5A/CD5AA042 1310 720 35,800 17,400 14.50 11.30
CC5A/CD5AC048 1310 720 35,200 17,200 14.00 11.15
CC5A/CD5AW036 1310 720 35,800 17,400 14.50 11.30
CC5A/CD5AW042 1310 720 35,400 17,200 14.00 11.20
CC5A/CD5AW048 1310 720 35,800 17,400 14.50 11.30
CD5AA048 1310 720 35,800 17,400 14.50 11.30
CE3AA036 1310 720 35,200 17,200 14.00 11.15
CE3AA042 1310 720 36,000 17,400 14.50 11.35
CE3AA048 1310 720 36,000 17,400 14.50 11.45
CF5AA036 1310 720 35,600 17,200 14.00 11.25
CF5AA048 1310 720 36,000 17,400 14.50 11.35
CK3BA036 1310 720 35,800 17,400 14.50 11.35
CK3BA042 1310 720 35,800 17,400 14.50 11.35
CK3BA048 1310 720 36,000 17,600 14.50 11.40
CK5A/CK5BA036 1310 720 35,800 17,400 14.50 11.35
CK5A/CK5BA042 1310 720 35,800 17,400 14.50 11.35
CK5A/CK5BA048 1310 720 36,000 17,600 14.50 11.40
CK5A/CK5BE042 1310 720 36,000 17,600 14.50 11.40
CK5A/CK5BT036 1310 720 35,800 17,400 14.50 11.35
CK5A/CK5BT042 1310 720 35,800 17,400 14.50 11.35
CK5A/CK5BT048 1310 720 36,000 17,600 14.50 11.40
CK5A/CK5BW036 1310 720 35,800 17,400 14.50 11.35
CK5A/CK5BW048 1310 720 36,000 17,600 14.50 11.40
CK5PA036 1310 720 35,800 17,400 14.50 11.35
CK5PA042 1310 720 35,800 17,400 14.50 11.35
CK5PA048 1310 720 36,000 17,600 14.50 11.40
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
See notes on pg.18.
12
037-30
CK5PE042 1310 720 36,000 17,600 14.50 11.40
CK5PT036 1310 720 35,800 17,400 14.50 11.35
CK5PT042 1310 720 35,800 17,400 14.50 11.35
CK5PT048 1310 720 36,000 17,600 14.50 11.40
CK5PW036 1310 720 35,800 17,400 14.50 11.35
CK5PW048 1310 720 36,000 17,600 14.50 11.40
FE4ANB006 1100 660 37,000 18,000 18.00 13.15
FE4ANF002 1100 660 35,200 17,600 16.50 11.75
FE4ANF003 1100 660 35,600 17,800 17.00 12.35
FE4ANF005 1100 660 37,000 18,000 17.50 12.85
FK4DNF001 1100 660 34,600 17,600 16.00 11.60
FV4BNF002 1100 660 35,200 17,600 16.50 11.75
FV4BNF003 1100 660 35,600 17,800 17.00 12.35
FV4BNF005 1100 660 37,000 18,000 17.50 12.85
40FKB/FK4DNB006 1100 660 37,000 18,000 18.00 13.15
40FKB/FK4DNF002 1100 660 35,200 17,600 16.50 11.75
40FKB/FK4DNF003 1100 660 35,600 17,800 17.00 12.35
40FKB/FK4DNF005 1100 660 37,000 18,000 17.50 12.85
COILS + 58CV(A,X)070-12 VARIABLE-SPEED FURNACE
CE3AA036 1050 700 34,400 17,600 16.50 11.75
CK3BA036 1050 700 35,000 17,800 16.50 11.95
CK5A/CK5BA036 1050 700 35,000 17,800 16.50 11.90
CK5A/CK5BT036 1050 700 35,000 17,800 16.50 11.90
CK5PA036 1050 700 35,000 17,800 16.50 11.90
CK5PT036 1050 700 35,000 17,800 16.50 11.90
COILS + 58CV(A,X)090-16 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 35,000 17,800 16.50 12.10
CC5A/CD5AA042 1050 700 35,000 17,800 17.00 12.20
CC5A/CD5AC048 1050 700 34,600 17,600 16.50 12.10
CC5A/CD5AW036 1050 700 35,000 17,800 17.00 12.20
CD5AA048 1050 700 35,200 17,800 17.00 12.30
CE3AA036 1050 700 34,600 17,600 16.50 11.95
CE3AA042 1050 700 35,200 17,800 17.00 12.25
CE3AA048 1050 700 35,400 17,800 17.00 12.30
CK3BA036 1050 700 35,200 17,800 17.00 12.15
CK3BA042 1050 700 35,200 17,800 17.00 12.20
CK3BA048 1050 700 35,400 18,000 17.00 12.40
CK5A/CK5BA036 1050 700 35,200 17,800 17.00 12.15
CK5A/CK5BA042 1050 700 35,200 17,800 17.00 12.20
CK5A/CK5BA048 1050 700 35,400 18,000 17.00 12.35
CK5A/CK5BE042 1050 700 35,400 18,000 17.00 12.30
CK5A/CK5BT036 1050 700 35,200 17,800 17.00 12.15
CK5A/CK5BT042 1050 700 35,200 17,800 17.00 12.20
CK5A/CK5BT048 1050 700 35,400 18,000 17.00 12.35
CK5A/CK5BW036 1050 700 35,200 17,800 17.00 12.20
CK5PA036 1050 700 35,200 17,800 17.00 12.15
CK5PA042 1050 700 35,200 17,800 17.00 12.20
CK5PA048 1050 700 35,400 18,000 17.00 12.35
CK5PE042 1050 700 35,400 18,000 17.00 12.30
CK5PT036 1050 700 35,200 17,800 17.00 12.15
CK5PT042 1050 700 35,200 17,800 17.00 12.20
CK5PT048 1050 700 35,400 18,000 17.00 12.35
CK5PW036 1050 700 35,200 17,800 17.00 12.20
COILS + 58CV(A,X)110-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 35,000 17,800 16.50 12.20
CC5A/CD5AA042 1050 700 35,000 17,800 17.00 12.30
CC5A/CD5AC048 1050 700 34,600 17,600 16.50 12.25
CC5A/CD5AW036 1050 700 35,000 17,800 17.00 12.30
CC5A/CD5AW042 1050 700 35,200 17,800 17.00 12.40
CC5A/CD5AW048 1050 700 35,200 17,800 17.00 12.45
CD5AA048 1050 700 35,200 17,800 17.00 12.45
CE3AA036 1050 700 34,600 17,600 16.50 12.05
CE3AA042 1050 700 35,200 17,800 17.00 12.35
CE3AA048 1050 700 36,000 18,000 17.00 12.60
CK3BA036 1050 700 35,200 17,800 17.00 12.25
CK3BA042 1050 700 35,200 17,800 17.00 12.30
CK3BA048 1050 700 35,400 18,000 17.00 12.50
CK5A/CK5BA036 1050 700 35,200 17,800 17.00 12.25
CK5A/CK5BA042 1050 700 35,200 17,800 17.00 12.30
CK5A/CK5BA048 1050 700 35,400 18,000 17.00 12.50
CK5A/CK5BE042 1050 700 35,400 18,000 17.00 12.40
CK5A/CK5BT036 1050 700 35,200 17,800 17.00 12.25
CK5A/CK5BT042 1050 700 35,200 17,800 17.00 12.30
CK5A/CK5BT048 1050 700 35,400 18,000 17.00 12.50
CK5A/CK5BW036 1050 700 35,200 17,800 17.00 12.30
CK5A/CK5BW048 1050 700 35,600 18,000 17.00 12.55
CK5PA036 1050 700 35,200 17,800 17.00 12.25
CK5PA042 1050 700 35,200 17,800 17.00 12.30
CK5PA048 1050 700 35,400 18,000 17.00 12.50
CK5PE042 1050 700 35,400 18,000 17.00 12.40
CK5PT036 1050 700 35,200 17,800 17.00 12.25
CK5PT042 1050 700 35,200 17,800 17.00 12.30
CK5PT048 1050 700 35,400 18,000 17.00 12.50
CK5PW036 1050 700 35,200 17,800 17.00 12.30
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
See notes on pg.18.
Combination ratings (cont.)
13
037-30
CK5PW048 1050 700 35,600 18,000 17.00 12.55
COILS + 58CV(A,X)135-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 35,000 17,800 17.00 12.25
CC5A/CD5AC048 1050 700 34,600 17,600 16.50 12.20
CC5A/CD5AW036 1050 700 35,000 17,800 17.00 12.25
CC5A/CD5AW042 1050 700 35,200 17,800 17.00 12.40
CC5A/CD5AW048 1050 700 35,200 17,800 17.00 12.40
CD5AA048 1050 700 35,200 17,800 17.00 12.40
CE3AA036 1050 700 34,600 17,600 16.50 12.00
CE3AA042 1050 700 35,200 17,800 17.00 12.30
CE3AA048 1050 700 35,400 17,800 17.00 12.40
CK3BA036 1050 700 35,200 17,800 17.00 12.20
CK3BA042 1050 700 35,200 17,800 17.00 12.25
CK3BA048 1050 700 35,400 18,000 17.00 12.45
CK5A/CK5BA042 1050 700 35,200 17,800 17.00 12.25
CK5A/CK5BA048 1050 700 35,400 18,000 17.00 12.45
CK5A/CK5BT042 1050 700 35,200 17,800 17.00 12.25
CK5A/CK5BT048 1050 700 35,400 18,000 17.00 12.45
CK5A/CK5BW036 1050 700 35,200 17,800 17.00 12.25
CK5A/CK5BW048 1050 700 35,600 18,000 17.00 12.50
CK5PA042 1050 700 35,200 17,800 17.00 12.25
CK5PA048 1050 700 35,400 18,000 17.00 12.45
CK5PT042 1050 700 35,200 17,800 17.00 12.25
CK5PT048 1050 700 35,400 18,000 17.00 12.45
CK5PW036 1050 700 35,200 17,800 17.00 12.25
CK5PW048 1050 700 35,600 18,000 17.00 12.50
COILS + 58CV(A,X)155-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 35,000 17,800 17.00 12.35
CC5A/CD5AC048 1050 700 34,800 17,600 17.00 12.30
CC5A/CD5AW036 1050 700 35,000 17,800 17.00 12.35
CC5A/CD5AW042 1050 700 35,200 17,800 17.00 12.50
CC5A/CD5AW048 1050 700 35,200 17,800 17.00 12.50
CD5AA048 1050 700 35,200 17,800 17.00 12.50
CE3AA036 1050 700 34,600 17,600 16.50 12.05
CE3AA042 1050 700 35,400 17,800 17.00 12.40
CE3AA048 1050 700 35,400 17,800 17.00 12.50
CK3BA036 1050 700 35,200 17,800 17.00 12.30
CK3BA042 1050 700 35,200 17,800 17.00 12.35
CK3BA048 1050 700 35,600 18,000 17.00 12.60
CK5A/CK5BA042 1050 700 35,200 17,800 17.00 12.35
CK5A/CK5BA048 1050 700 35,600 18,000 17.00 12.55
CK5A/CK5BT042 1050 700 35,200 17,800 17.00 12.35
CK5A/CK5BT048 1050 700 35,600 18,000 17.00 12.55
CK5A/CK5BW036 1050 700 35,200 17,800 17.00 12.35
CK5A/CK5BW048 1050 700 35,600 18,000 17.00 12.60
CK5PA042 1050 700 35,200 17,800 17.00 12.35
CK5PA048 1050 700 35,600 18,000 17.00 12.55
CK5PT042 1050 700 35,200 17,800 17.00 12.35
CK5PT048 1050 700 35,600 18,000 17.00 12.55
CK5PW036 1050 700 35,200 17,800 17.00 12.35
CK5PW048 1050 700 35,600 18,000 17.00 12.60
COILS + 58MVP040-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 34,600 17,600 16.50 11.80
CC5A/CD5AC048 1050 700 34,200 17,600 16.50 11.75
CC5A/CD5AW036 1050 700 34,600 17,600 16.50 11.80
CC5A/CD5AW042 1050 700 34,000 17,400 16.50 11.70
CC5A/CD5AW048 1050 700 34,800 17,600 16.50 11.90
CD5AA048 1050 700 34,800 17,600 16.50 11.90
CE3AA036 1050 700 34,000 17,400 16.00 11.60
CE3AA042 1050 700 34,800 17,600 16.70 11.85
CE3AA048 1050 700 35,000 17,800 16.50 11.90
CK3BA042 1050 700 34,800 17,800 16.50 11.80
CK3BA048 1050 700 35,000 17,800 16.50 12.00
CK5A/CK5BA042 1050 700 34,800 17,800 16.50 11.80
CK5A/CK5BA048 1050 700 35,000 17,800 16.50 11.95
CK5A/CK5BT042 1050 700 34,800 17,800 16.50 11.80
CK5A/CK5BT048 1050 700 35,000 17,800 16.50 11.95
CK5A/CK5BW036 1050 700 34,800 17,800 16.50 11.80
CK5A/CK5BW048 1050 700 35,000 17,800 16.50 12.05
CK5PA042 1050 700 34,800 17,800 16.50 11.80
CK5PA048 1050 700 35,000 17,800 16.50 11.95
CK5PT042 1050 700 34,800 17,800 16.50 11.80
CK5PT048 1050 700 35,000 17,800 16.50 11.95
CK5PW036 1050 700 34,800 17,800 16.50 11.80
CK5PW048 1050 700 35,000 17,800 16.50 12.05
COILS + 58MVP060-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 34,600 17,600 16.50 11.90
CC5A/CD5AA042 1050 700 34,600 17,600 16.50 12.00
CC5A/CD5AC048 1050 700 34,400 17,600 16.50 11.90
CC5A/CD5AW036 1050 700 34,600 17,600 16.50 11.95
CD5AA048 1050 700 34,800 17,600 16.50 12.10
CE3AA036 1050 700 34,200 17,400 16.50 11.75
CE3AA042 1050 700 34,800 17,600 16.50 12.05
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
Combination ratings (cont.)
See notes on pg.18.
14
037-30
CE3AA048 1050 700 35,000 17,600 16.50 12.10
CK3BA036 1050 700 34,800 17,600 16.50 11.95
CK3BA042 1050 700 34,800 17,800 16.50 12.00
CK3BA048 1050 700 35,000 17,800 17.00 12.15
CK5A/CK5BA036 1050 700 34,800 17,800 16.50 11.90
CK5A/CK5BA042 1050 700 34,800 17,800 16.50 12.00
CK5A/CK5BA048 1050 700 35,000 17,800 17.00 12.15
CK5A/CK5BE042 1050 700 35,000 17,800 16.50 12.05
CK5A/CK5BT036 1050 700 34,800 17,800 16.50 11.90
CK5A/CK5BT042 1050 700 34,800 17,800 16.50 12.00
CK5A/CK5BT048 1050 700 35,000 17,800 17.00 12.15
CK5A/CK5BW036 1050 700 34,800 17,800 16.50 12.00
CK5PA036 1050 700 34,800 17,800 16.50 11.90
CK5PA042 1050 700 34,800 17,800 16.50 12.00
CK5PA048 1050 700 35,200 17,800 17.00 12.15
CK5PE042 1050 700 35,000 17,800 16.50 12.05
CK5PT036 1050 700 34,800 17,600 16.50 11.90
CK5PT042 1050 700 34,800 17,800 16.50 12.00
CK5PT048 1050 700 35,200 17,800 17.00 12.15
CK5PW036 1050 700 34,800 17,600 16.50 11.95
COILS + 58MVP080-14 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 34,400 17,600 16.50 11.70
CC5A/CD5AA042 1050 700 34,600 17,600 16.50 11.75
CC5A/CD5AC048 1050 700 34,200 17,600 16.50 11.70
CC5A/CD5AW036 1050 700 34,600 17,600 16.50 11.75
CC5A/CD5AW042 1050 700 34,000 17,400 16.50 11.65
CC5A/CD5AW048 1050 700 34,600 17,600 16.50 11.90
CD5AA048 1050 700 34,800 17,600 16.50 11.90
CE3AA036 1050 700 34,000 17,400 16.00 11.55
CE3AA042 1050 700 34,800 17,600 16.50 11.80
CE3AA048 1050 700 34,800 17,800 16.50 11.85
CK3BA036 1050 700 34,600 17,800 16.50 11.70
CK3BA042 1050 700 34,600 17,800 16.50 11.75
CK3BA048 1050 700 35,000 17,800 16.50 11.95
CK5A/CK5BA036 1050 700 34,600 17,800 16.50 11.70
CK5A/CK5BA042 1050 700 34,600 17,800 16.50 11.75
CK5A/CK5BA048 1050 700 35,000 17,800 16.50 11.95
CK5A/CK5BE042 1050 700 35,000 17,800 16.50 11.85
CK5A/CK5BT036 1050 700 34,600 17,800 16.50 11.70
CK5A/CK5BT042 1050 700 34,600 17,800 16.50 11.75
CK5A/CK5BT048 1050 700 35,000 17,800 16.50 11.95
CK5A/CK5BW036 1050 700 34,600 17,800 16.50 11.75
CK5A/CK5BW048 1050 700 35,000 17,800 16.50 12.00
CK5PA036 1050 700 34,600 17,800 16.50 11.70
CK5PA042 1050 700 34,600 17,800 16.50 11.75
CK5PA048 1050 700 35,000 17,800 16.50 11.95
CK5PE042 1050 700 35,000 17,800 16.50 11.85
CK5PT036 1050 700 34,600 17,800 16.50 11.70
CK5PT042 1050 700 34,600 17,800 16.50 11.75
CK5PT048 1050 700 35,000 17,800 16.50 11.95
CK5PW036 1050 700 34,600 17,800 16.50 11.75
CK5PW048 1050 700 35,000 17,800 16.50 12.00
COILS + 58MVP080-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 34,600 17,600 16.50 11.85
CC5A/CD5AA042 1050 700 34,600 17,600 16.50 11.95
CC5A/CD5AC048 1050 700 34,200 17,600 16.50 11.85
CC5A/CD5AW036 1050 700 34,600 17,600 16.50 11.90
CC5A/CD5AW042 1050 700 34,200 17,600 16.50 11.80
CC5A/CD5AW048 1050 700 34,800 17,600 16.50 12.00
CD5AA048 1050 700 34,800 17,600 16.50 12.00
CE3AA036 1050 700 34,200 17,400 16.00 11.70
CE3AA042 1050 700 34,800 17,600 16.50 12.00
CE3AA048 1050 700 35,000 17,800 16.50 12.05
CK3BA036 1050 700 34,800 17,800 16.50 11.90
CK3BA042 1050 700 34,800 17,800 16.50 11.95
CK3BA048 1050 700 35,000 17,800 17.00 12.10
CK5A/CK5BA036 1050 700 34,800 17,800 16.50 11.90
CK5A/CK5BA042 1050 700 34,800 17,800 16.50 11.95
CK5A/CK5BA048 1050 700 35,000 17,800 16.50 12.10
CK5A/CK5BE042 1050 700 35,000 17,800 16.50 12.05
CK5A/CK5BT036 1050 700 34,800 17,800 16.50 11.90
CK5A/CK5BT042 1050 700 34,800 17,800 16.50 11.95
CK5A/CK5BT048 1050 700 35,000 17,800 16.50 12.10
CK5A/CK5BW036 1050 700 34,800 17,800 16.50 11.95
CK5A/CK5BW048 1050 700 35,200 17,800 17.00 12.10
CK5PA036 1050 700 34,800 17,800 16.50 11.90
CK5PA042 1050 700 34,800 17,800 16.50 11.95
CK5PA048 1050 700 35,200 17,800 16.50 12.10
CK5PE042 1050 700 35,000 17,800 16.50 12.05
CK5PT036 1050 700 34,800 17,800 16.50 11.90
CK5PT042 1050 700 34,800 17,800 16.50 11.95
CK5PT048 1050 700 35,200 17,800 16.50 12.10
CK5PW036 1050 700 34,800 17,800 16.50 11.95
CK5PW048 1050 700 35,200 17,800 17.00 12.10
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
Combination ratings (cont.)
See notes on pg.18.
15
037-30
COILS + 58MVP100-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 34,600 17,600 16.50 11.90
CC5A/CD5AA042 1050 700 34,800 17,600 16.50 12.00
CC5A/CD5AC048 1050 700 34,400 17,600 16.50 11.90
CC5A/CD5AW036 1050 700 34,800 17,600 16.50 11.95
CC5A/CD5AW042 1050 700 34,200 17,600 16.50 11.85
CC5A/CD5AW048 1050 700 34,800 17,800 16.50 12.10
CD5AA048 1050 700 34,800 17,800 16.50 12.10
CE3AA036 1050 700 34,200 17,400 16.50 11.75
CE3AA042 1050 700 35,000 17,800 16.50 12.05
CE3AA048 1050 700 35,200 17,800 16.50 12.10
CK3BA036 1050 700 34,800 17,800 16.50 11.95
CK3BA042 1050 700 34,800 17,800 16.50 12.00
CK3BA048 1050 700 35,200 17,800 17.00 12.15
CK5A/CK5BA036 1050 700 34,800 17,800 16.50 11.95
CK5A/CK5BA042 1050 700 34,800 17,800 16.50 12.00
CK5A/CK5BA048 1050 700 35,200 17,800 17.00 12.15
CK5A/CK5BE042 1050 700 35,200 17,800 16.50 12.05
CK5A/CK5BT036 1050 700 34,800 17,800 16.50 11.95
CK5A/CK5BT042 1050 700 34,800 17,800 16.50 12.00
CK5A/CK5BT048 1050 700 35,200 17,800 17.00 12.15
CK5A/CK5BW036 1050 700 34,800 17,800 16.50 12.00
CK5A/CK5BW048 1050 700 35,200 17,800 17.00 12.20
CK5PA036 1050 700 34,800 17,800 16.50 11.95
CK5PA042 1050 700 34,800 17,800 16.50 12.00
CK5PA048 1050 700 35,200 17,800 17.00 12.15
CK5PE042 1050 700 35,000 17,800 16.50 12.10
CK5PT036 1050 700 34,800 17,800 16.50 11.95
CK5PT042 1050 700 34,800 17,800 16.50 12.00
CK5PT048 1050 700 35,200 17,800 17.00 12.15
CK5PW036 1050 700 34,800 17,800 16.50 12.00
CK5PW048 1050 700 35,200 17,800 17.00 12.20
COILS + 58MVP120-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA042 1050 700 34,600 17,600 16.50 12.05
CC5A/CD5AC048 1050 700 34,200 17,400 16.50 11.95
CC5A/CD5AW036 1050 700 34,600 17,600 16.50 12.00
CC5A/CD5AW042 1050 700 34,200 17,400 16.50 11.95
CC5A/CD5AW048 1050 700 34,800 17,600 16.50 12.15
CD5AA048 1050 700 34,800 17,600 16.50 12.15
CE3AA036 1050 700 34,200 17,400 16.50 11.80
CE3AA042 1050 700 34,800 17,600 16.50 12.05
CE3AA048 1050 700 35,000 17,600 16.50 12.15
CK3BA042 1050 700 34,800 17,600 16.50 12.00
CK3BA048 1050 700 35,000 17,800 17.00 12.20
CK5A/CK5BA042 1050 700 34,800 17,600 16.50 12.05
CK5A/CK5BA048 1050 700 35,000 17,800 17.00 12.20
CK5A/CK5BT042 1050 700 34,800 17,600 16.50 12.05
CK5A/CK5BT048 1050 700 35,000 17,800 17.00 12.20
CK5A/CK5BW036 1050 700 34,800 17,600 16.50 12.05
CK5A/CK5BW048 1050 700 35,200 17,800 17.00 12.25
CK5PA042 1050 700 34,800 17,600 16.50 12.05
CK5PA048 1050 700 35,200 17,800 17.00 12.20
CK5PT042 1050 700 34,800 17,600 16.50 12.05
CK5PT048 1050 700 35,200 17,800 17.00 12.20
CK5PW036 1050 700 34,800 17,600 16.50 12.05
CK5PW048 1050 700 35,200 17,800 17.00 12.25
048-30
*FV4BNB006 1470 880 47,500 26,000 15.00 11.55
CC5A/CD5AA060 1700 985 45,500 26,000 13.00 10.30
CC5A/CD5AA060 1700 985 45,500 26,000 13.00 10.30
CC5A/CD5AC048 1665 985 44,500 25,800 12.50 10.15
CC5A/CD5AW048 1700 985 45,500 26,000 13.00 10.30
CC5A/CD5AW060 1740 985 46,500 26,000 13.00 10.50
CD5AA048 1700 985 45,500 26,000 13.00 10.30
CE3AA048 1700 985 45,500 26,000 13.00 10.30
CE3AA060 1740 985 46,500 26,000 13.00 10.50
CK3BA048 1700 985 45,500 26,000 13.00 10.30
CK3BA060 1740 985 46,500 26,000 13.00 10.50
CK5A/CK5BA048 1700 985 45,500 26,000 13.00 10.30
CK5A/CK5BA060 1740 985 46,500 26,000 13.00 10.50
CK5A/CK5BT048 1700 985 45,500 26,000 13.00 10.30
CK5A/CK5BT060 1740 985 46,500 26,000 13.00 10.50
CK5A/CK5BW048 1700 985 45,500 26,000 13.00 10.30
CK5A/CK5BX060 1750 985 47,500 26,000 13.45 10.60
CK5PA048 1700 985 45,500 26,000 13.00 10.30
CK5PA060 1740 985 46,500 26,000 13.00 10.50
CK5PT048 1700 985 45,500 26,000 13.00 10.30
CK5PT060 1740 985 46,500 26,000 13.00 10.50
CK5PW048 1700 985 45,500 26,000 13.00 10.30
CK5PX060 1750 985 47,500 26,000 13.45 10.60
FE4ANB006 1470 880 47,500 26,000 15.00 11.55
FE4ANF005 1470 880 47,000 26,000 15.00 11.15
FV4BNF005 1470 880 47,000 26,000 15.00 11.15
40FKB/FK4DNB006 1470 880 47,500 26,000 15.00 11.55
40FKB/FK4DNF005 1470 880 47,000 26,000 15.00 11.15
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
Combination ratings (cont.)
See notes on pg.18.
16
048-30
COILS + 58CV(A,X)090-16 VARIABLE-SPEED FURNACE
CC5A/CD5AC048 1400 875 43,500 25,800 14.50 10.60
CD5AA048 1400 875 44,500 26,000 14.50 10.80
CE3AA048 1400 875 44,500 26,000 14.50 10.75
CK3BA048 1400 875 44,500 26,000 14.50 10.80
CK5A/CK5BA048 1400 875 44,500 26,000 14.50 10.80
CK5A/CK5BT048 1400 875 44,500 26,000 14.50 10.80
CK5PA048 1400 875 44,500 26,000 14.50 10.80
CK5PT048 1400 875 44,500 26,000 14.50 10.80
COILS + 58CV(A,X)110-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1400 875 44,500 26,000 14.50 11.05
CC5A/CD5AC048 1400 875 44,000 25,800 14.50 10.85
CC5A/CD5AW048 1400 875 44,500 26,000 14.50 11.05
CD5AA048 1400 875 44,500 26,000 14.50 11.00
CE3AA048 1400 875 44,500 26,000 14.50 10.95
CE3AA060 1400 875 46,000 26,000 15.00 11.30
CK3BA048 1400 875 44,500 26,000 14.50 11.05
CK3BA060 1400 875 46,000 26,000 15.00 11.35
CK5A/CK5BA048 1400 875 44,500 26,000 14.50 11.00
CK5A/CK5BA060 1400 875 46,000 26,000 15.00 11.35
CK5A/CK5BT048 1400 875 44,500 26,000 14.50 11.00
CK5A/CK5BT060 1400 875 46,000 26,000 15.00 11.35
CK5A/CK5BW048 1400 875 45,000 26,000 14.50 11.10
CK5A/CK5BX060 1400 875 46,000 26,000 15.00 11.45
CK5PA048 1400 875 44,500 26,000 14.50 11.00
CK5PA060 1400 875 46,000 26,000 15.00 11.35
CK5PT048 1400 875 44,500 26,000 14.50 11.00
CK5PT060 1400 875 46,000 26,000 15.00 11.35
CK5PW048 1400 875 45,000 26,000 14.50 11.10
CK5PX060 1400 875 46,000 26,000 15.00 11.45
COILS + 58CV(A,X)135-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1400 875 44,500 26,000 14.50 11.00
CC5A/CD5AC048 1400 875 44,000 25,800 14.50 10.80
CC5A/CD5AW048 1400 875 44,500 26,000 14.80 11.00
CC5A/CD5AW060 1400 875 46,000 26,000 15.00 11.30
CD5AA048 1400 875 44,500 26,000 14.50 10.95
CE3AA048 1400 875 44,500 26,000 14.50 10.90
CE3AA060 1400 875 46,000 26,000 15.00 11.25
CK3BA048 1400 875 44,500 26,000 14.50 11.00
CK3BA060 1400 875 46,000 26,000 15.00 11.30
CK5A/CK5BA048 1400 875 44,500 26,000 14.50 10.95
CK5A/CK5BA060 1400 875 46,000 26,000 15.00 11.30
CK5A/CK5BT048 1400 875 44,500 26,000 14.50 10.95
CK5A/CK5BT060 1400 875 46,000 26,000 15.00 11.30
CK5A/CK5BW048 1400 875 45,000 26,000 14.50 11.05
CK5A/CK5BX060 1400 875 46,000 26,000 15.00 11.40
CK5PA048 1400 875 44,500 26,000 14.50 10.95
CK5PA060 1400 875 46,000 26,000 15.00 11.30
CK5PT048 1400 875 44,500 26,000 14.50 10.95
CK5PT060 1400 875 46,000 26,000 15.00 11.30
CK5PW048 1400 875 45,000 26,000 14.50 11.05
CK5PX060 1400 875 46,000 26,000 15.00 11.40
COILS + 58CV(A,X)155-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1400 875 44,500 26,000 14.50 11.10
CC5A/CD5AC048 1400 875 44,000 25,800 14.50 10.85
CC5A/CD5AW048 1400 875 44,500 26,000 14.50 11.10
CC5A/CD5AW060 1400 875 46,000 26,000 15.00 11.35
CD5AA048 1400 875 44,500 26,000 14.50 11.05
CE3AA048 1400 875 44,500 26,000 14.50 11.00
CE3AA060 1400 875 46,000 26,000 15.00 11.35
CK3BA048 1400 875 45,000 26,000 15.00 11.10
CK3BA060 1400 875 46,000 26,000 15.00 11.35
CK5A/CK5BA048 1400 875 45,000 26,000 15.00 11.05
CK5A/CK5BA060 1400 875 46,000 26,000 15.00 11.40
CK5A/CK5BT048 1400 875 45,000 26,000 15.00 11.05
CK5A/CK5BT060 1400 875 46,000 26,000 15.00 11.40
CK5A/CK5BW048 1400 875 45,000 26,000 15.00 11.15
CK5A/CK5BX060 1400 875 46,500 26,000 15.00 11.50
CK5PA048 1400 875 45,000 26,000 15.00 11.05
CK5PA060 1400 875 46,000 26,000 15.00 11.35
CK5PT048 1400 875 45,000 26,000 15.00 11.05
CK5PT060 1400 875 46,000 26,000 15.00 11.40
CK5PW048 1400 875 45,000 26,000 15.00 11.15
CK5PX060 1400 875 46,500 26,000 15.00 11.50
COILS + 58MVP080-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1400 875 44,000 25,800 14.00 10.60
CC5A/CD5AC048 1400 875 43,000 25,600 13.50 10.40
CC5A/CD5AW048 1400 875 44,000 25,800 14.00 10.55
CD5AA048 1400 875 44,000 25,800 14.00 10.55
CD5PX060 1400 875 46,000 26,000 14.50 10.90
CE3AA048 1400 875 44,500 26,000 14.00 10.55
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
Combination ratings (cont.)
See notes on pg.18.
17
048-30
CE3AA060 1400 875 45,500 26,000 14.50 10.85
CK3BA048 1400 875 44,000 26,000 14.00 10.60
CK3BA060 1400 875 45,500 26,000 14.50 10.80
CK5A/CK5BA048 1400 875 44,000 26,000 14.00 10.55
CK5A/CK5BA060 1400 875 45,500 26,000 14.50 10.80
CK5A/CK5BT048 1400 875 44,000 26,000 14.00 10.55
CK5A/CK5BT060 1400 875 45,500 26,000 14.50 10.80
CK5A/CK5BW048 1400 875 44,000 26,000 14.00 10.65
CK5A/CK5BX060 1400 875 46,000 26,000 14.50 10.95
CK5PA048 1400 875 44,000 26,000 14.00 10.55
CK5PA060 1400 875 45,500 26,000 14.50 10.80
CK5PT048 1400 875 44,000 26,000 14.00 10.55
CK5PT060 1400 875 45,500 26,000 14.50 10.80
CK5PW048 1400 875 44,000 26,000 14.00 10.65
CK5PX060 1400 875 46,000 26,000 14.50 10.95
COILS + 58MVP100-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1400 875 44,000 25,800 14.00 10.65
CC5A/CD5AC048 1400 875 43,500 25,600 14.00 10.45
CC5A/CD5AW048 1400 875 44,000 25,800 14.00 10.65
CD5AA048 1400 875 44,000 25,800 14.00 10.60
CD5PX060 1400 875 46,000 26,000 14.50 10.95
CE3AA048 1400 875 44,500 26,000 14.00 10.65
CE3AA060 1400 875 45,500 26,000 14.50 10.90
CK3BA048 1400 875 44,500 26,000 14.00 10.65
CK3BA060 1400 875 45,500 26,000 14.50 10.90
CK5A/CK5BA048 1400 875 44,500 26,000 14.00 10.65
CK5A/CK5BA060 1400 875 45,500 26,000 14.50 10.90
CK5A/CK5BT048 1400 875 44,500 26,000 14.00 10.65
CK5A/CK5BT060 1400 875 45,500 26,000 14.50 10.90
CK5A/CK5BW048 1400 875 44,500 26,000 14.00 10.70
CK5A/CK5BX060 1400 875 46,000 26,000 14.50 11.00
CK5PA048 1400 875 44,500 26,000 14.00 10.65
CK5PA060 1400 875 45,500 26,000 14.50 10.90
CK5PT048 1400 875 44,500 26,000 14.00 10.65
CK5PT060 1400 875 45,500 26,000 14.50 10.90
CK5PW048 1400 875 44,500 26,000 14.00 10.70
CK5PX060 1400 875 46,000 26,000 14.50 11.00
COILS + 58MVP120-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1400 875 44,000 25,800 14.00 10.70
CC5A/CD5AC048 1400 875 43,500 25,400 14.00 10.50
CC5A/CD5AW048 1400 875 44,000 25,800 14.00 10.65
CD5AA048 1400 875 44,000 25,800 14.00 10.65
CD5PX060 1400 875 46,000 26,000 14.50 11.00
CE3AA048 1400 875 44,500 26,000 14.00 10.65
CE3AA060 1400 875 45,500 26,000 14.50 10.95
CK3BA048 1400 875 44,000 26,000 14.00 10.70
CK3BA060 1400 875 45,500 26,000 14.50 10.95
CK5A/CK5BA048 1400 875 44,000 26,000 14.00 10.65
CK5A/CK5BA060 1400 875 45,500 26,000 14.50 10.95
CK5A/CK5BT048 1400 875 44,000 26,000 14.00 10.65
CK5A/CK5BT060 1400 875 45,500 26,000 14.50 10.95
CK5A/CK5BW048 1400 875 44,500 26,000 14.00 10.75
CK5A/CK5BX060 1400 875 46,000 26,000 14.50 11.05
CK5PA048 1400 875 44,000 26,000 14.00 10.65
CK5PA060 1400 875 45,500 26,000 14.50 10.95
CK5PT048 1400 875 44,000 26,000 14.00 10.65
CK5PT060 1400 875 45,500 26,000 14.50 10.95
CK5PW048 1400 875 44,500 26,000 14.00 10.75
CK5PX060 1400 875 46,000 26,000 14.50 11.05
060-31
*FV4BNB006 1835 1100 60,000 30,000 15.00 10.55
CC5A/CD5AA060 2250 1185 58,000 28,400 13.00 9.95
CC5A/CD5AW060 2175 1185 59,500 28,800 13.00 9.95
CE3AA060 2250 1185 60,000 29,200 13.00 10.00
CK3BA060 2175 1185 58,500 29,000 13.00 9.80
CK5A/CK5BA060 2175 1185 58,500 29,000 13.00 9.85
CK5A/CK5BT060 2175 1185 58,500 29,000 13.00 9.80
CK5A/CK5BX060 2250 1185 60,000 29,400 13.20 10.00
CK5PA060 2175 1185 58,500 29,000 13.00 9.85
CK5PT060 2175 1185 58,500 29,000 13.00 9.85
CK5PX060 2250 1185 60,000 29,400 13.20 10.00
FE4ANB006 1835 1100 60,000 30,000 15.00 10.55
40FKB/FK4DNB006 1835 1100 60,000 30,000 15.00 10.55
COILS + 58CV(A,X)110-22 VARIABLE-SPEED FURNACE
CE3AA060 1750 1050 58,500 29,200 14.50 10.45
CK3BA060 1750 1050 58,000 29,400 14.50 10.40
CK5A/CK5BA060 1750 1050 58,000 29,400 14.50 10.40
CK5A/CK5BT060 1750 1050 58,000 29,400 14.50 10.40
CK5A/CK5BX060 1750 1050 59,000 29,600 15.00 10.55
CK5PA060 1750 1050 58,000 29,400 14.50 10.40
CK5PT060 1750 1050 58,000 29,400 14.50 10.40
CK5PX060 1750 1050 59,000 29,600 15.00 10.55
COILS + 58CV(A,X)135-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 58,000 29,200 14.50 10.30
CC5A/CD5AW060 1750 1050 58,000 29,200 14.50 10.40
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
Combination ratings (cont.)
See notes on pg.18.
18
060-31
CE3AA060 1750 1050 58,500 29,200 14.50 10.40
CK3BA060 1750 1050 58,000 29,400 14.50 10.35
CK5A/CK5BA060 1750 1050 58,000 29,400 14.50 10.40
CK5A/CK5BT060 1750 1050 58,000 29,400 14.50 10.40
CK5A/CK5BX060 1750 1050 59,000 29,600 15.00 10.50
CK5PA060 1750 1050 58,000 29,400 14.50 10.40
CK5PT060 1750 1050 58,000 29,400 14.50 10.40
CK5PX060 1750 1050 59,000 29,600 15.00 10.50
COILS + 58CV(A,X)155-22 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 58,000 29,200 14.50 10.40
CC5A/CD5AW060 1750 1050 58,000 29,200 14.50 10.45
CE3AA060 1750 1050 58,500 29,200 14.50 10.50
CK3BA060 1750 1050 58,000 29,400 14.50 10.45
CK5A/CK5BA060 1750 1050 58,000 29,400 14.50 10.45
CK5A/CK5BT060 1750 1050 58,000 29,400 14.50 10.45
CK5A/CK5BX060 1750 1050 59,500 29,600 15.00 10.60
CK5PA060 1750 1050 58,000 29,400 14.50 10.45
CK5PT060 1750 1050 58,000 29,400 14.50 10.45
CK5PX060 1750 1050 59,500 29,600 15.00 10.60
COILS + 58MVP080-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 55,500 28,200 13.50 9.45
CD5PX060 1750 1050 58,000 29,200 14.00 9.75
CE3AA060 1750 1050 57,500 29,000 14.00 9.75
CK3BA060 1750 1050 57,000 29,000 14.00 9.70
CK5A/CK5BA060 1750 1050 57,000 29,000 14.00 9.70
CK5A/CK5BT060 1750 1050 57,000 29,000 14.00 9.70
CK5A/CK5BX060 1750 1050 58,000 29,200 14.00 9.80
CK5PA060 1750 1050 57,000 29,000 14.00 9.70
CK5PT060 1750 1050 57,000 29,000 14.00 9.70
CK5PX060 1750 1050 58,000 29,200 14.00 9.80
COILS + 58MVP100-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 55,500 28,200 13.50 9.55
CD5PX060 1750 1050 58,000 29,200 14.00 9.85
CE3AA060 1750 1050 57,500 29,000 14.00 9.85
CK3BA060 1750 1050 57,000 29,000 14.00 9.80
CK5A/CK5BA060 1750 1050 57,000 29,000 14.00 9.85
CK5A/CK5BT060 1750 1050 57,000 29,000 14.00 9.85
CK5A/CK5BX060 1750 1050 58,500 29,400 14.00 9.95
CK5PA060 1750 1050 57,000 29,000 14.00 9.85
CK5PT060 1750 1050 57,000 29,000 14.00 9.85
CK5PX060 1750 1050 58,500 29,400 14.00 9.95
COILS + 58MVP120-20 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 55,500 28,200 13.50 9.65
CD5PX060 1750 1050 58,000 29,200 14.00 9.95
CE3AA060 1750 1050 57,500 29,000 14.00 9.95
CK3BA060 1750 1050 57,000 29,000 14.00 9.90
CK5A/CK5BA060 1750 1050 57,000 29,000 14.00 9.90
CK5A/CK5BT060 1750 1050 57,000 29,000 14.00 9.90
CK5A/CK5BX060 1750 1050 58,500 29,200 14.00 10.05
CK5PA060 1750 1050 57,000 29,000 14.00 9.90
CK5PT060 1750 1050 57,000 29,000 14.00 9.90
CK5PX060 1750 1050 58,500 29,200 14.00 10.05
UNIT
SIZE
INDOOR
SECTION
INDOOR AIR CFM TOTAL CAPACITY BTUH
SEER EERHigh Low High Low
Combination ratings (cont.)
* Tested combination.
EER —Energy Efficiency Ratio
SEER —Seasonal Energy Efficiency Ratio
NOTES: 1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for
other combinations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Application of capillary tube coils is not recommended.
19
Detailed cooling capacities*
See notes on pg. 55.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡
38TDB024-30 Outdoor Section With FV4BNF003 Indoor Section - High Speed
600
72 29.76 14.87 1.78 27.81 14.05 1.91 25.82 13.24 2.04 23.82 12.45 2.16 21.77 11.66 2.28 19.62 10.86 2.39
67 26.74 17.46 1.74 24.91 16.63 1.86 23.07 15.82 1.98 21.24 15.03 2.10 19.34 14.23 2.21 17.40 13.43 2.31
63†† 24.54 16.81 1.71 22.83 15.98 1.82 21.11 15.18 1.94 19.35 14.36 2.05 17.58 13.57 2.14 15.79 12.79 2.24
62 23.95 20.00 1.70 22.24 19.17 1.81 20.53 18.34 1.92 18.82 17.50 2.03 17.10 16.62 2.13 15.50 15.50 2.22
57 21.78 21.78 1.66 20.56 20.56 1.78 19.33 19.33 1.89 18.08 18.08 2.01 16.81 16.81 2.12 15.50 15.50 2.22
700
72 30.82 15.67 1.83 28.72 14.82 1.96 26.61 13.99 2.09 24.49 13.18 2.22 22.30 12.36 2.34 20.03 11.53 2.45
67 27.70 18.67 1.79 25.75 17.82 1.91 23.81 16.98 2.03 21.84 16.16 2.15 19.83 15.33 2.26 17.78 14.51 2.36
63†† 25.44 17.96 1.76 23.63 17.11 1.87 21.78 16.27 1.99 19.90 15.43 2.10 18.03 14.61 2.20 16.14 13.80 2.29
62 24.81 21.62 1.75 22.99 20.73 1.86 21.20 19.84 1.98 19.38 18.88 2.09 17.69 17.69 2.19 16.27 16.27 2.30
57 23.08 23.08 1.72 21.77 21.77 1.84 20.43 20.43 1.96 19.07 19.07 2.08 17.69 17.69 2.19 16.28 16.28 2.30
800
72 31.61 16.39 1.87 29.41 15.52 2.01 27.21 14.68 2.14 24.96 13.84 2.27 22.68 13.00 2.38 20.33 12.15 2.50
67 28.43 19.79 1.83 26.40 18.92 1.96 24.35 18.06 2.08 22.28 17.21 2.20 20.18 16.37 2.31 18.05 15.51 2.41
63†† 26.14 19.02 1.80 24.22 18.15 1.92 22.27 17.28 2.04 20.32 16.42 2.15 18.37 15.58 2.25 16.38 14.70 2.34
62 25.47 23.09 1.79 23.60 22.15 1.91 21.71 21.13 2.02 19.90 19.90 2.14 18.41 18.41 2.25 16.89 16.89 2.36
57 24.18 24.18 1.77 22.76 22.76 1.89 21.35 21.35 2.02 19.90 19.90 2.14 18.42 18.42 2.25 16.90 16.90 2.36
900
72 32.25 17.07 1.91 30.00 16.20 2.05 27.67 15.33 2.18 25.33 14.47 2.31 22.98 13.62 2.43 20.55 12.76 2.55
67 29.04 20.87 1.88 26.93 19.98 2.00 24.77 19.10 2.13 22.62 18.23 2.25 20.46 17.36 2.36 18.24 16.44 2.46
63†† 26.72 20.05 1.84 24.69 19.14 1.96 22.67 18.26 2.08 20.66 17.39 2.19 18.60 16.48 2.30 16.57 15.54 2.39
62 26.04 24.47 1.84 24.09 23.42 1.95 22.19 22.19 2.07 20.63 20.63 2.20 19.06 19.06 2.31 17.43 17.43 2.43
57 25.15 25.15 1.82 23.68 23.68 1.95 22.16 22.16 2.07 20.64 20.64 2.20 19.06 19.06 2.31 17.44 17.44 2.43
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed Indoor
Section Size
High Speed
Capacity Power Capacity Power
CC5A/CD5AA 024 0.98 1.12 COILS + 58CV(A,X)070-12 VARIABLE SPEED FURNACE
030 1.00 1.12 CC5A/CD5AA 024 0.96 1.02
036 1.00 1.13 030 0.98 1.02
CC5A/CD5AW 024 0.98 1.12 036 1.00 1.02
030 1.00 1.12 CC5A/CD5AW 024 0.97 1.02
036 1.00 1.13 030 0.98 1.02
CE3AA 024 0.99 1.12 CE3AA 024 0.98 1.03
030 1.00 1.13 030 0.99 1.03
036 1.00 1.14 036 1.00 1.03
CF5AA 024 0.99 1.12 CK3BA 024 0.98 1.02
036 1.00 1.13 030 0.99 1.02
CK3BA 024 1.00 1.12 036 1.00 1.01
030 1.00 1.13 CK5A/CK5BA 024 1.00 1.02
036 1.00 1.13 030 1.00 1.02
CK5A/CK5BA 024 1.00 1.12 036 1.00 1.01
030 1.00 1.13 CK5A/CK5BT 036 1.00 1.01
036 1.00 1.14 CK5A/CK5BW 024 1.00 1.02
CK5A/CK5BT 036 1.00 1.14 030 1.00 1.02
CK5A/CK5BW 024 1.00 1.12 CK5PA 024 1.00 1.02
030 1.00 1.13 030 1.00 1.02
036 1.00 1.14 036 1.00 1.01
CK5PA 024 1.00 1.12 CK5PT 036 1.00 1.01
030 1.00 1.13 CK5PW 024 1.00 1.02
036 1.00 1.14 030 1.00 1.02
CK5PT 036 1.00 1.14 COILS + 58CV(A,X)090-16 VARIABLE SPEED FURNACE
CK5PW 024 1.00 1.12 CC5A/CD5AA 024 0.97 1.02
030 1.00 1.13 030 0.98 1.02
036 1.00 1.14 036 1.00 1.01
FE4ANF 002 1.00 1.01 CC5A/CD5AW 024 0.97 1.01
003 1.00 1.00 030 0.98 1.02
FK4DNF 001 1.00 1.01 036 1.00 1.01
FV4BNF 002 1.00 1.01 CE3AA 024 0.98 1.02
003 1.00 1.00 030 0.99 1.02
40FKB/FK4DNF 002 1.00 1.01 036 1.00 1.02
003 1.00 1.00 —— —
20
Detailed cooling capacities*
See notes on pg. 55.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡Total Sens‡
38TDB024-30 Outdoor Section With FV4BNF003 Indoor Section - High Speed continued
600
72 29.76 14.87 1.78 27.81 14.05 1.91 25.82 13.24 2.04 23.82 12.45 2.16 21.77 11.66 2.28 19.62 10.86 2.39
67 26.74 17.46 1.74 24.91 16.63 1.86 23.07 15.82 1.98 21.24 15.03 2.10 19.34 14.23 2.21 17.40 13.43 2.31
63†† 24.54 16.81 1.71 22.83 15.98 1.82 21.11 15.18 1.94 19.35 14.36 2.05 17.58 13.57 2.14 15.79 12.79 2.24
62 23.95 20.00 1.70 22.24 19.17 1.81 20.53 18.34 1.92 18.82 17.50 2.03 17.10 16.62 2.13 15.50 15.50 2.22
57 21.78 21.78 1.66 20.56 20.56 1.78 19.33 19.33 1.89 18.08 18.08 2.01 16.81 16.81 2.12 15.50 15.50 2.22
700
72 30.82 15.67 1.83 28.72 14.82 1.96 26.61 13.99 2.09 24.49 13.18 2.22 22.30 12.36 2.34 20.03 11.53 2.45
67 27.70 18.67 1.79 25.75 17.82 1.91 23.81 16.98 2.03 21.84 16.16 2.15 19.83 15.33 2.26 17.78 14.51 2.36
63†† 25.44 17.96 1.76 23.63 17.11 1.87 21.78 16.27 1.99 19.90 15.43 2.10 18.03 14.61 2.20 16.14 13.80 2.29
62 24.81 21.62 1.75 22.99 20.73 1.86 21.20 19.84 1.98 19.38 18.88 2.09 17.69 17.69 2.19 16.27 16.27 2.30
57 23.08 23.08 1.72 21.77 21.77 1.84 20.43 20.43 1.96 19.07 19.07 2.08 17.69 17.69 2.19 16.28 16.28 2.30
800
72 31.61 16.39 1.87 29.41 15.52 2.01 27.21 14.68 2.14 24.96 13.84 2.27 22.68 13.00 2.38 20.33 12.15 2.50
67 28.43 19.79 1.83 26.40 18.92 1.96 24.35 18.06 2.08 22.28 17.21 2.20 20.18 16.37 2.31 18.05 15.51 2.41
63†† 26.14 19.02 1.80 24.22 18.15 1.92 22.27 17.28 2.04 20.32 16.42 2.15 18.37 15.58 2.25 16.38 14.70 2.34
62 25.47 23.09 1.79 23.60 22.15 1.91 21.71 21.13 2.02 19.90 19.90 2.14 18.41 18.41 2.25 16.89 16.89 2.36
57 24.18 24.18 1.77 22.76 22.76 1.89 21.35 21.35 2.02 19.90 19.90 2.14 18.42 18.42 2.25 16.90 16.90 2.36
900
72 32.25 17.07 1.91 30.00 16.20 2.05 27.67 15.33 2.18 25.33 14.47 2.31 22.98 13.62 2.43 20.55 12.76 2.55
67 29.04 20.87 1.88 26.93 19.98 2.00 24.77 19.10 2.13 22.62 18.23 2.25 20.46 17.36 2.36 18.24 16.44 2.46
63†† 26.72 20.05 1.84 24.69 19.14 1.96 22.67 18.26 2.08 20.66 17.39 2.19 18.60 16.48 2.30 16.57 15.54 2.39
62 26.04 24.47 1.84 24.09 23.42 1.95 22.19 22.19 2.07 20.63 20.63 2.20 19.06 19.06 2.31 17.43 17.43 2.43
57 25.15 25.15 1.82 23.68 23.68 1.95 22.16 22.16 2.07 20.64 20.64 2.20 19.06 19.06 2.31 17.44 17.44 2.43
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed Indoor
Section Size
High Speed
Capacity Power Capacity Power
CK3BA 024 0.98 1.01 CK5A/CK5BA 024 0.98 1.03
030 0.99 1.01 030 0.98 1.03
036 1.00 1.01 036 1.00 1.02
CK5A/CK5BA 024 1.00 1.02 CK5A/CK5BT 036 1.00 1.02
030 1.00 1.01 CK5A/CK5BW 024 0.98 1.03
036 1.00 1.01 030 0.98 1.02
CK5A/CK5BT 036 1.00 1.01 036 1.00 1.02
CK5A/CK5BW 024 1.00 1.01 CK5PA 024 0.98 1.03
030 1.00 1.01 030 0.98 1.03
036 1.00 1.00 036 1.00 1.02
CK5PA 024 1.00 1.02 CK5PT 036 1.00 1.02
030 1.00 1.01 CK5PW 024 0.98 1.03
036 1.00 1.01 030 0.98 1.02
CK5PT 036 1.00 1.01 036 1.00 1.02
CK5PW 024 1.00 1.01 COILS + 58MVP080-14 VARIABLE SPEED FURNACE
030 1.00 1.01 CC5A/CD5AA 036 1.00 1.03
036 1.00 1.00 CC5A/CD5AW 024 0.96 1.02
COILS + 58MVP040-14 VARIABLE SPEED FURNACE 030 0.98 1.03
CC5A/CD5AW 036 1.00 1.02 036 1.00 1.02
CE3AA 024 0.97 1.03 CE3AA 024 0.97 1.03
030 0.98 1.03 030 0.98 1.03
036 0.99 1.03 036 0.99 1.03
CK5A/CK5BW 036 1.00 1.02 CK3BA 024 0.98 1.02
CK5PW 036 1.00 1.02 030 0.98 1.02
COILS + 58MVP060-14 VARIABLE SPEED FURNACE 036 1.00 1.02
CC5A/CD5AA 024 0.95 1.02 CK5A/CK5BA 036 1.00 1.02
030 0.97 1.01 CK5A/CK5BT 036 1.00 1.02
036 1.00 1.02 CK5A/CK5BW 024 0.98 1.03
CC5A/CD5AW 024 0.96 1.02 030 0.98 1.03
030 0.97 1.01 036 1.00 1.02
036 1.00 1.02 CK5PA 036 1.00 1.02
CE3AA 024 0.97 1.03 CK5PT 036 1.00 1.02
030 0.98 1.02 CK5PW 024 0.98 1.03
036 0.99 1.02 030 0.98 1.03
CK3BA 024 0.98 1.01 036 1.00 1.02
030 0.98 1.02 —— —
036 1.00 1.02
Other manuals for 38TDB
1
This manual suits for next models
5
Table of contents
Other Carrier Air Conditioner manuals
Carrier
Carrier 30XV140-500 User manual
Carrier
Carrier 18K-24K User manual
Carrier
Carrier 42GM Manual
Carrier
Carrier 50ZP Series Assembly Instructions
Carrier
Carrier AQUASNAP JUNIOR 30RA User manual
Carrier
Carrier Omnizone 50BVC Operating instructions
Carrier
Carrier xpower blue II 42KCL109313G User manual
Carrier
Carrier 42QZA009DS-1 User manual
Carrier
Carrier 40KMC User manual
Carrier
Carrier 38MPRA Series User manual
Carrier
Carrier 38QUS012DS User manual
Carrier
Carrier 53G100HF User manual
Carrier
Carrier 50TC Series Operation manual
Carrier
Carrier WeatherMaker 50TCQD09 User manual
Carrier
Carrier ROOM AIR CONDITIONER User manual
Carrier
Carrier 42NQV009E User manual
Carrier
Carrier 24AHA4 Performance Series User manual
Carrier
Carrier 50ZP036300 User manual
Carrier
Carrier 40GXC User manual
Carrier
Carrier 42cvur018-703 User manual
