These dependable split systems
match Carrier's 40RU or 39 Series
indoor-air handlers with the versatile
outdoor 38AP condensing units for a
wide selection of commercial cooling
solutions.
• Split condensing units compatible
with ASHRAE 90.1
• Chlorine-free, non-ozone depleting
Puron refrigerant (R-410A)
• Condenser coils feature the
Novation®heat exchanger with
microchannel coil technology
• 38APS single-circuit unit has up to
3 rotary scroll compressors
• 38APD unit has up to 6 rotary scroll
compressors with 2 independent
circuits
• Standard scroll compressor units
operate as low as 33% (single
circuit) or 13% (dual circuit) of
nominal capacity
• Optional digital scroll compressors
allow incremental unloading down
to 10% (single circuit) or 5% (dual
circuit) of nominal capacity for VAV
applications
• Protection against high discharge
and low suction refrigerant
pressure, and low oil pressure
Features/Benefits
The 38AP condensing unit
offers the utmost in system
configuration and control
adaptability. Its premium-
quality standard components
ensure durable, efficient, and
reliable operation.
The 38AP units offer high unit EERs
(Energy Efficiency Ratios) up to 11.6
and IPLVs (integrated part load values)
up to 16.2. These units provide great-
er efficiency than similar units in the
marketplace, which translates into
year-round operating savings.
GEMINI™ SELECT
38APS025-065,38APD025-130
Commercial Air-Cooled
Condensing Units with
PURON®Refrigerant (R-410A)
50/60 Hz
25 to 130 Nominal Tons (88 to 457 Nominal kW)
Product
Data
025 UNIT WITH
LOW SOUND OPTION
040-060 UNIT
070 UNIT
a38-7096
A38-7097
A38-7095

2
The latest safety standards for 38AP
units are certified to UL (Underwriters
Laboratories) and CSA (Canadian
Standards Association) standards, ETL
approved.
Versatility
The 38AP Series condensing units fea-
ture up to 6 compressors and 2 refrig-
erant circuits, and can be matched with
a wide variety of air-handling units.
Single circuit condensing units can op-
erate with a single air handler. Dual cir-
cuit condensing units can operate with
a single air handler or two separate air
handlers. Standard units have multiple
scroll compressors. A digital scroll op-
tion is available. This option of digital
control closely matches building loads
and allows fine incremental adjust-
ments to the variance in load.
Durable construction
All 38AP units have weatherized cabi-
nets constructed of heavy-duty galva-
nized steel prepainted with corrosion-
resistant baked enamel. Inside and out-
side surfaces are protected to ensure
long life and good appearance. The
durable, galvanized steel, prepainted
components exceed the requirements
of the 500-hour salt spray test per
ASTM (American Society for Testing
and Materials) B117.
All 38AP units have Novation®heat
exchangers with microchannel coil
technology. The microchannel heat ex-
changer (MCHX) coils provide long-
term reliability, high performance heat
transfer, and significant savings in re-
frigerant charge. E-coated MCHX is
offered as an option for harsh industri-
al or coastal conditions.
Reliability
The 38AP condensing units feature
highly reliable, hermetic scroll com-
pressors. Each 38AP unit is capable of
unloading in staging sequence of scroll
compressors. Compressors are mount-
ed on rails with vibration isolators to
provide quiet operation and reduced
component stress.
The 38AP units have single or dual
independent circuits; they provide in-
herent backup capability. Each circuit
is also protected by the following safety
features:
• Short-cycle protection
• Low superheat protection
• Loss of refrigerant charge
protection
• Reverse rotation protection
• Suction and discharge pressure
transducers
• High refrigerant pressure switch
(discharge)
• Circuit breakers or fuses for short
circuit protection of compressors
and outdoor fans
• Suction line accumulator for each
refrigerant circuit
Easier installation and service
The 38AP units are equipped with
hinged control-box access doors, con-
trol interface terminal boards, liquid
line shutoff valves, and suction line ser-
vice valves.
Table of contents
Page
Features/Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Model Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Capacity Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Options and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10,11
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-16
Selection Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-85
Typical Piping and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86-88
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89-91
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92-94
Typical Control Wiring Schematics. . . . . . . . . . . . . . . . . . . . . . . . . . . . .95-98
Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99-103
Guide Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104-106
Features/Benefits (cont)

3
Run Status
Service Test
Temperature
Pressures
Setpoints
Inputs
Outputs
Configuration
Time Clock
Operating Modes
Alarms
Alarm Status
ENTER
MODE
ESCAPE
PROPELLER FAN
AEROACOUSTIC FAN
1/3 OCTAVE BAND CENTER FREQUENCY (Hz)
SOUND POWER [dB(A)]
AEROACOUSTIC™ FAN vs. PROPELLER FAN
PENETRATES BUILDING
STRUCTURE
25 40 63 130 168 250 400 630 1080 1600 2400 4000 6300 8000
90
85
80
75
70
65
60
55
50
Run Status
Service Test
Temperatures
Pressures
Setpoints
Inputs
Outputs
Configuration
Time Clock
Operating Modes
Alarms
ENTER
ESC
MODE
Alarm Status
ComfortLink
SCROLLING MARQUEE DISPLAY
NAVIGATOR™ DISPLAY
LOW SOUND OPTION
LOW-NOISE AEROACOUSTIC FAN
AEROACOUSTIC FAN VS PROPELLER FAN
a30-2187
a30-3162
a30-3926
TUBES
FINS
MICROCHANNELS
MANIFOLD
NOVATION®HEAT EXCHANGER TECHNOLOGY
WITH MICROCHANNEL CONDENSER COILS
a38-7096
a30-3924

4
Model number nomenclature
LEGEND
*38APS units available in sizes 025-050 and 065 only.
†Digital compressor not available on size 065.
**Only available on sizes 115 and 130.
Quality Assurance
EMM — Energy Management Module
MCHX — Microchannel Heat Exchanger
a38-7200
38AP D 025 6 4 A 1 0 0 5 0
38AP – Split System Condensing Unit Packaging/Security Options
0– Std Packaging
4– Security Grilles/Hail Guards
8– Std Packaging, Bottom Skid
Controls/CommunicationsOptions
2– Scrolling Marquee
3– EMM, Scrolling Marquee
5– No Display
Ambient/Capacity Control/
Interrupt Options†
0– Std Ambient, Std Compressor,
Std Interrupt
2– Std Ambient, Digital Compressor,
Std Interrupt
3– Std Ambient, Std Compressor,
High Interrupt
5– Std Ambient, Digital Compressor,
High Interrupt
6– Low Ambient, Std Compressor,
Std Interrupt
8– Low Ambient, Digital Compressor,
Std Interrupt
9– Low Ambient, Std Compressor,
High Interrupt
C– Low Ambient, Digital Compressor,
High Interrupt
Line Length Options
1– Standard Line Length
2– Long Line Length Check Valves
Electrical Options
0– Single Point Power, Terminal Block
1– Single Point Power,
Non-Fused Disconnect
Refrigeration Circuit Options*
D– Dual Refrigeration Circuit
S– Single Refrigeration Circuit
Revision Level
A– Current Revision Level
ylppuSrewoP
1– 575-3-60
2– 380-3-60
5– 280/230-3-60
6– 460-3-60
9– 380/415-3-50
Condenser Coil/Low Sound Options
4– MCHX, No Sound Treatment
5– E-coat, MCHX, No Sound Treatment
C– MCHX, Low Sound Fan(s)
D– E-coat MCHX, Low Sound Fan(s)
H– MCHX, Low Sound Fan(s), Compressor Blankets
J– E-coat MCHX, Low Sound Fan(s), Compressor Blankets
Nominal Capacity – Tons(kW)
D– Bottom Skid, Security Grilles/Hail Guards
J– Bottom Skid, Top Crate, Bag
N– Bottom Skid, Top Crate, Bag,
Security Grilles/Hail Guards
025 – 25 (88)
050 – 50 (176) 090 – 90 (317)
027 – 27 (95)
060 – 60 (211) 100 – 100 (352)
030– 30 (106) 070 – 70 (246)
040 – 40 (141) 080– 80 (281)
065 – 65 (229) 115 – 115 (404)
130– 130 (457)
2– Dual Point Power,
XL, Terminal Block**

5
38AP UNIT CAPACITY RATINGS
LEGEND NOTES:
1. Unit performance is rated in accordance with ARI (Air Conditioning
and Refrigeration Institute) Standard 365.
2. Ratings are based on 45 F (7.2 C) saturated suction temperature
and 95 F (35 C) outside-air temperature, and include suction line
losses.
UNIT SIZE
CAPACITY
NOMINAL TONS
(60 Hz)
CAPACITY
NOMINAL kW
(60 Hz)
CAPACITY
NOMINAL TONS
(50 Hz)
CAPACITY
NOMINAL kW
(50 Hz)
EER
(60 Hz)
EER
(50 Hz)
IPLV
(60 Hz)
IPLV
(50 Hz)
38APS025 24.0 84.3 19.9 69.9 11.0 11.6 14.4 15.5
38APD025 24.0 84.3 19.9 69.9 11.0 11.6 13.1 14.1
38APS027 26.6 93.4 22.1 77.6 10.9 11.5 14.7 15.7
38APD027 26.6 93.4 22.1 77.6 10.9 11.5 14.0 14.7
38APS030 31.1 109.2 25.8 90.6 10.8 11.4 14.3 15.2
38APD030 31.1 109.2 25.8 90.6 10.8 11.4 12.8 13.6
38APS040 39.8 139.8 33.0 115.9 11.6 12.1 16.2 17.4
38APD040 39.2 137.7 32.5 114.1 11.5 12.0 15.3 16.4
38APS050 48.1 168.9 39.9 140.1 11.1 11.7 15.0 15.9
38APD050 50.0 175.6 41.5 145.7 10.8 11.3 14.9 15.9
38APD060 58.3 204.7 48.4 170.0 11.1 11.7 14.5 15.5
38APS065 59.6 209.6 49.4 173.7 11.0 11.6 15.1 16.1
38APD070 67.3 236.4 55.9 196.3 11.0 11.4 15.7 16.7
38APD080 78.0 273.9 64.7 227.2 11.1 11.5 15.6 16.6
38APD090 87.4 306.9 72.5 254.6 11.3 11.8 15.3 16.4
38APD100 96.0 337.2 79.7 279.9 11.1 11.6 15.0 16.0
38APD115 110.4 388.3 91.6 322.1 11.2 11.7 15.2 16.2
38APD130 125.1 440.0 103.8 365.0 11.0 11.5 15.2 16.2
EER — Energy Efficiency Ratio
IPLV — Integrated Part Load Value
Capacity ratings

6
38AP025-050 UNITS — ENGLISH
LEGEND
*Typical operating charge with 25 ft of interconnecting piping. Operating charge is
approximate for maximum system capacity. Unit is factory supplied with nitrogen
holding charge. Refrigerant charge for dual circuit units is the total for both
circuits.
†Maximum vertical separation between evaporator coil and condensing unit if con-
densing unit is below the evaporator.
NOTE: Refer to Loading Sequences tables in Application Data section on page 99
or contact Application Engineering for detailed capacity step data.
38AP UNIT SIZE 025 027 030 040 050
NOMINAL CAPACITY, 50/60 Hz (tons) 21/25 23/27 25/30 33/40 42/50
CIRCUIT Dual Single Dual Single Dual Single Dual Single Dual Single
OPERATING WEIGHTS (lb)
Standard 1095 1077 1258 1240 1264 1246 2094 1968 2120 1977
With Low Sound Option 1131 1113 1294 1276 1300 1282 2148 2022 2174 2031
APPROXIMATE REFRIGERANT CHARGE,
TYPICAL (lb)*
28 24 30 26 30 26 52 40 52 40
NITROGEN SHIPPING CHARGE 15 psig
COMPRESSOR
hp (Qty) (CKT A/CKT B)
11 (2) 11 (2) 13 (2) 13 (2) 15 (2) 15 (2) 10 (2)/
8.5 (2)
13 (3) 11 (2)/
13 (2)
13 (3)
CAPACITY STEPS
Standard 222222 4 3 4 3
Digital Option 22 22 22 22 22 22 44 33 44 33
CRANKCASE HEATER (W) (each compressor) 90 (60 Hz), 75 (50 Hz)
CONDENSER FANS
Standard Propeller Type - Direct Drive
Quantity 222222 3 3 3 3
RPM 1140 (60 Hz), 950 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 3300 3300 3300 3300 3300 3300 4200 4200 4200 4200
Total Watts (50 Hz) 2750 2750 2750 2750 2750 2750 3500 3500 3500 3500
Low Noise Plastic Type - Direct Drive
Quantity 222222 3 3 3 3
RPM 850 (60 Hz), 700 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 2750 2750 2750 2750 2750 2750 3500 3500 3500 3500
Total Watts (50 Hz) 2300 2300 2300 2300 2300 2300 2900 2900 2900 2900
CONDENSER COIL MCHX Type
No. Coils per Circuit 111111 1 2 1 2
sq ft 27.1 27.1 33.9 33.9 33.9 33.9 67.8 67.8 67.8 67.8
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 210 F
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 13/815/813/815/813/815/815/8/ 15/821/815/8/ 15/821/8
Liquid Line 5/85/85/85/85/87/85/8/ 5/87/85/8/ 5/87/8
MAXIMUM HEIGHT FOR 3° F SUBCOOLING (ft)† 75 75 75 75 75 75 75 75 75 75
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 50/50 100 50/50 100 50/50 100 54/46 100 48/52 100
MINIMUM UNIT CAPACITY (%) 50 50 50 50 50 50 23 33 23 33
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female
Physical data

7
38AP060-130 UNITS — ENGLISH
LEGEND
*Typical operating charge with 25 ft of interconnecting piping. Operating charge is
approximate for maximum system capacity. Unit is factory supplied with nitrogen
holding charge. Refrigerant charge for dual circuit units is the total for both
circuits.
†Maximum vertical separation between evaporator coil and condensing unit if con-
densing unit is below the evaporator.
NOTE: Refer to Loading Sequences tables in Application Data section on page 99
or contact Application Engineering for detailed capacity step data.
38AP UNIT SIZE 060 065 070 080 090 100 115 130
NOMINAL CAPACITY, 50/60 Hz (tons) 50/60 54/65 58/70 67/80 75/90 83/100 96/115 108/130
CIRCUIT Dual Single Dual Dual Dual Dual Dual Dual
OPERATING WEIGHTS (lb)
Standard 2227 2561 2450 2610 2835 2844 3211 3353
With Low Sound Option 2299 2633 2522 2700 2943 2952 3319 3461
APPROXIMATE REFRIGERANT CHARGE,
TYPICAL (lb)*
60 65 70 78 96 100 115 130
NITROGEN SHIPPING CHARGE 15 psig
COMPRESSOR
hp (Qty) (CKT A/CKT B)
13 (2)/15 (2) 20 (3) 15 (2)/11 (3) 15 (2)/15 (3) 13 (3)/15 (3) 15 (3)/15 (3) 15 (3)/20 (3) 15 (3)/25 (3)
CAPACITY STEPS
Standard 43556666
Digital Option 44—555566666666
CRANKCASE HEATER (W) (each compressor) 90 (60 Hz), 75 (50 Hz)
CONDENSER FANS
Standard Propeller Type - Direct Drive
Quantity 44456678
RPM 1140 (60 Hz), 950 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 6200 6000 6000 7500 9000 9000 10,500 12,000
Total Watts (50 Hz) 5150 5000 5000 6250 7500 7500 8750 10,000
Low Noise Plastic Type - Direct Drive
Quantity 44456678
RPM 850 (60 Hz), 700 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 5200 5000 5000 6250 7500 7500 8750 10,000
Total Watts (50 Hz) 4300 4150 4150 5200 6250 6250 7292 8333
CONDENSER COIL MCHX Type
No. Coils per Circuit 1 3 2 2 to 3 3 3 3 to 4 3 to 5
sq ft 67.8 99.6 99.6 124.5 149.4 149.4 174.3 199.2
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 210 F
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 15/8/ 15/821/821/8/ 15/821/8/ 15/821/8/ 21/821/8/ 21/821/8/ 25/821/8/ 25/8
Liquid Line 5/8/ 7/87/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 11/8
MAXIMUM HEIGHT FOR 3° F SUBCOOLING (ft)† 75 75 75 75 75 75 75 75
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 46/54 100 47/53 40/60 46/54 50/50 44/56 38/62
MINIMUM UNIT CAPACITY (%) 23 33 24 20 15 17 15 13
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female

8
38AP025-050 UNITS — SI
LEGEND
*Typical operating charge with 7.62 m of interconnecting piping. Operating charge
is approximate for maximum system capacity. Unit is factory supplied with nitro-
gen holding charge. Refrigerant charge for dual circuit units is the total for both
circuits.
†Maximum vertical separation between evaporator coil and condensing unit if con-
densing unit is below the evaporator.
NOTE: Refer to Loading Sequences tables in Application Data section on page 99
or contact Application Engineering for detailed capacity step data.
38AP UNIT SIZES 025 027 030 040 050
NOMINAL CAPACITY 50/60 Hz (kW) 73/88 79/95 88/105 117/141 146/176
CIRCUIT Dual Single Dual Single Dual Single Dual Single Dual Single
OPERATING WEIGHTS (kg)
Standard 497 489 571 562 573 565 950 893 961 897
With Low Sound Option 513 505 587 579 590 582 974 917 986 921
APPROXIMATE REFRIGERANT CHARGE,
TYPICAL (kg)*
13 11 14 12 14 12 24 18 24 18
NITROGEN SHIPPING CHARGE 1.03 bar
COMPRESSOR
kW (Qty) (CKT A/CKT B)
8.2 (2) 8.2 (2) 9.7 (2) 9.7 (2) 11.2 (2) 11.2 (2) 7.5 (2)/
6.3 (2)
9.7 (3) 8.2 (2)/
9.7 (2)
9.7 (3)
CAPACITY STEPS
Standard 222222 4 3 4 3
Digital Option 22 22 22 22 22 22 44 33 44 33
CRANKCASE HEATER (W) (each compressor) 90 (60 Hz), 75 (50 Hz)
CONDENSER FANS
Standard Propeller Type - Direct Drive
Quantity 222222 3 3 3 3
r/s 19 (60 Hz), 16 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 3300 3300 3300 3300 3300 3300 4200 4200 4200 4200
Total Watts (50 Hz) 2750 2750 2750 2750 2750 2750 3500 3500 3500 3500
Low Noise Plastic Type - Direct Drive
Quantity 222222 3 3 3 3
r/s 14 (60 Hz), 12 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 2750 2750 2750 2750 2750 2750 3500 3500 3500 3500
Total Watts (50 Hz) 2300 2300 2300 2300 2300 2300 2900 2900 2900 2900
CONDENSER COIL MCHX Type
No. Coils per Circuit 111111 1 212
sq m 2.5 2.5 3.1 3.1 3.1 3.1 6.3 6.3 6.3 6.3
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 99 C
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 13/8/ 13/815/813/8/ 13/815/813/8/ 13/815/815/8/ 15/821/815/8/ 15/821/8
Liquid Line 5/8/ 5/85/85/8/ 5/85/85/8/ 5/87/85/8/ 5/87/85/8/ 5/87/8
MAXIMUM HEIGHT FOR 1.7° C
SUBCOOLING (m)†
23 23 23 23 23 23 23 23 23 23
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 50/50 100 50/50 100 50/50 100 54/46 100 48/52 100
MINIMUM UNIT CAPACITY (%) 50 50 50 50 50 50 23 33 23 33
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female
Physical data (cont)

9
38AP060-130 UNITS — SI
LEGEND
*Typical operating charge with 7.62 m of interconnecting piping. Operating charge
is approximate for maximum system capacity. Unit is factory supplied with nitro-
gen holding charge. Refrigerant charge for dual circuit units is the total for both
circuits.
†Maximum vertical separation between evaporator coil and condensing unit if con-
densing unit is below the evaporator.
NOTE: Refer to Loading Sequences tables in Application Data section on page 99
or contact Application Engineering for detailed capacity step data.
38AP UNIT SIZES 060 065 070 080 090 100 115 130
NOMINAL CAPACITY 50/60 Hz (kW) 176/211 190/228 205/246 234/281 264/316 293/351 337/404 381/457
CIRCUIT Dual Single Dual Dual Dual Dual Dual Dual
OPERATING WEIGHTS (kg)
Standard 1010 1162 1111 1184 1286 1290 1456 1521
With Low Sound Option 1043 1194 1144 1225 1335 1339 1505 1570
APPROXIMATE REFRIGERANT CHARGE,
TYPICAL (kg)*
27 29 32 35 44 45 52 59
NITROGEN SHIPPING CHARGE 1.03 bar
COMPRESSOR
kW (Qty) (CKT A/CKT B)
9.7 (2)/
11.2 (2)
15.0 (3) 11.2 (2)/
8.2 (3)
11.2 (2)/
11.2 (3)
9.7 (3)/
11.2 (3)
11.2 (3)/
11.2 (3)
11.2 (3)/
15.0 (3)
11.2 (3)/
18.6 (3)
CAPACITY STEPS
Standard 43556666
Digital Option 44—555566666666
CRANKCASE HEATER (W) (each compressor) 90
CONDENSER FANS
Standard Propeller Type - Direct Drive
Quantity 44456678
r/s 19 (60 Hz), 16 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 6200 6000 6000 7500 9000 9000 10,500 12,.000
Total Watts (50 Hz) 5150 5000 5000 6250 7500 7500 8750 10,000
Low Noise Plastic Type - Direct Drive
Quantity 44456678
r/s 14 (60 Hz), 12 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 5200 5000 5000 6250 7500 7500 8750 10,000
Total Watts (50 Hz) 4300 4150 4150 5200 6250 6250 7292 8333
CONDENSER COIL MCHX Type
No. Coils per Circuit 1 3 2 2 to 3 3 3 3 to 4 3 to 5
sq m 6.3 6.9 9.3 11.6 13.9 13.9 16.2 18.5
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 99 C
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 15/8/ 15/825/821/8/ 15/821/8/ 15/821/8/ 21/821/8/ 21/821/8/ 25/821/8/ 25/8
Liquid Line 5/8/ 7/87/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/8
MAXIMUM HEIGHT FOR 1.7° C
SUBCOOLING (m)†
23 23 23 23 23 23 23 23
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 46/54 100 47/53 40/60 46/54 50/50 44/56 38/62
MINIMUM UNIT CAPACITY (%) 23 33 24 20 15 17 15 13
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female

10
LEGEND *Digital compressors provide incremental unloading from full capacity
down to a minimum value. Not available on size 065 unit.
NOTES:
1. Std Interrupt - SCCR (short circuit current rating) (5K)
2. High Interrupt - SCCR 460-v and 380/415-v (65K), 208/230-v
(65K), 575-v (25K)
Factory-installed options
Novation®heat exchanger technology microchan-
nel coil (aluminum fin/aluminum tube) condenser is
available for optimum durability. Novation heat exchangers
with microchannel coil technology are offered coated or
uncoated to match coil protection to site conditions. The
Carrier Electronic Catalog (E-Cat) can be used to deter-
mine whether or not corrosion protection is recommended
for particular applications in coastal/marine environments.
Following the input of the requested data, the E-Cat pro-
gram output will advise the appropriate coil to be used.
Other factors described in "Selection Guide: Environmental
Corrosion Protection, Novation Heat Exchanger with Mi-
crochannel Coil Technology" catalog number 04-581042-
01 must also be considered to determine if corrosion pro-
tection is required.
Low sound fans provide a specially designed system of
fan propellers and stacks that reduce sound without reduc-
ing unit performance. The factory-installed fan option is
compatible with the Motormaster®V option. Low sound
fans are also available as field-installed accessory
Compressor sound blankets reduce unit sound levels
by providing an acoustic blanket on each compressor.
Compressor blankets are also available as field-installed ac-
cessory.
Security grilles/hail guards consist of louvered, sheet
metal panels which securely fasten to the unit and provide
condenser coil protection against hail and physical dam-
age. Security grilles/hail guards are also available as field-
installed accessories.
Long line length check valves are required for liquid
line installation on all linear line length applications
of more than 100 ft (30.5 m). For any 025-030 size
dual-circuit unit application where evaporator is located
higher than the condensing unit, check valves are required
for linear line length above 55 ft (16.8 m). The check valve
option prevents charge migration to compressor. Check
valves are also available as field-installed accessories.
Digital compressor control allows incremental unload-
ing for a closer match to building load. Refer to Loading
Sequences tables in Application Data section on page 99.
Digital compressor option not available on unit size 065.
High short circuit current rating interrupt provides a
short circuit current rating protection for the unit up to
65,000 A on 460-v, 380/415-v, and 208/230-v units or
25,000 A on 575-v units.
Motormaster®V low-ambient control provides con-
trol of outdoor-fan motor operation to maintain head pres-
sure at low outdoor ambient temperatures down to 20 F
( 29 C) for 50 and 60 Hz units. Only one factory-installed
low ambient temperature kit per unit is required. This
option also requires field-installed wind baffles. The
Motormaster V low-ambient control is also available as a
field-installed accessory.
Dual point power connection option is provided with
terminal blocks for size 115 and 130 units.
Non-fused disconnect includes factory-installed non-
fused disconnect capability for power and control located
at the unit.
ComfortLink™ controls with scrolling marquee
display module is used for accessing condensing unit
ITEM FACTORY-INSTALLED OPTION FIELD-INSTALLED ACCESSORY
Condenser Coil/Low Sound Options
E-Coated MCHX X
Low Sound Fan(s) XX
Compressor Blankets XX
Vibration isolation Pads X
Line Length Options
Long Line Length Check Valve XX
Ambient/Capacity Control/Interrupt Options
Digital Compressor*X
High Short Circuit Current Rating Interrupt X
Motormaster V Low Ambient Control XX
Electrical Options
Dual Point Power X
Non-Fused Disconnect X
Controls/Communications Options
Navigator™ Display X
Remote Enhanced Display X
Touch Pilot™ Display X
ComfortLink™ Controls with Scrolling Marquee Display Module X
EMM XX
BACnet Translator Control X
LON Translator Control X
Packaging/Security Options
Bottom Skid X
Top Crate, Bag X
Security Grilles/Hail Guards XX
Wind Baffles X
E-Coated — Epoxy Coating Applied to Entire Coil Assembly
EMM — Energy Management Module
LON — Local Operating Network
MCHX — Microchannel Heat Exchanger
–
–
Options and accessories

11
information, reading sensor values, and testing the con-
densing unit. The scrolling marquee display is a 4-key,
4-character, 16-segment LED (light-emitting diode) display.
Eleven mode LEDs are located on the display as well as an
Alarm Status LED. The display shows all of the
ComfortLink control codes (with 60-character expandable
clear language), plus set points, time of day, temperatures,
pressures, and superheat. Additional information can be
displayed all at once with the accessory Navigator™
display. If scrolling marquee display is not used, the Navi-
gator or alternate means of of display will be required for
comissioning and servicing of the unit.
Packaging options include bottom skid with standard
coil protection and bottom skid, top crate with bag. Stan-
dard coil protection is also included on all unit packaging.
Energy management module (EMM) provides energy
management capabilities to minimize condensing unit
energy consumption. The EMM is also available as a field-
installed accessory.
Field-installed accessories
Vibration isolation pads reduce vibration transmission
from the compressor through the floor and into the condi-
tioned space. The neoprene isolator pads measure 1/4in.
thick (24 in. x 3 in.).
Long line length check valves are required for liquid
line installation on all linear line length applications
of more than 100 ft (30.5 m). For any 025-030 size dual-
circuit unit application where evaporator is located higher
than the condensing unit, check valves are required for lin-
ear line length above 55 ft (16.8 m). The check valve op-
tion prevents charge migration to compressor. Check
valves are also available as a factory-installed option.
Motormaster®V low-ambient control provides con-
trol of outdoor-fan motor operation to maintain head pres-
sure at low outdoor ambient temperatures down to 20 F
( 29 C) for 50 and 60 Hz units. Only one field-installed
low ambient temperature kit per unit is required. This ac-
cessory also requires field-installed wind baffles. The
Motormaster V low-ambient control is also available as a
factory-installed option.
Navigator™ display module provides a portable, hand
held display module for convenient access to unit status,
operation, configuration and troubleshooting diagnostics
capability. The 4-line, 80-character LCD (liquid crystal
display) display provides clear language information in
English, French, Spanish or Portuguese. The weatherproof
enclosure and industrial grade extension cord make the
Navigator module ideally suited for outdoor applications.
Magnets located on the back of the module allow
attachment of any sheet metal component for hands free
operation. Navigator display, or alternate means of dis-
play, is required if scrolling marquee is not provided with
unit.
Energy management module provides energy
management capabilities to minimize condensing unit
energy consumption. The EMM is also available as a
factory-installed option.
BACnet* translator control provides an interface be-
tween the unit and a BACnet Local Area Network (LAN,
i.e., MS/TP EIA-485).
LON (local operating network) translator control
provides an interface between the unit and a local operat-
ing network (i.e., LonWorks†FT-10A ANSI/EIA-709.1).
Remote enhanced display accessory kit contains a
remotely mounted 40-character per line, 16-line display
panel for unit diagnostics.
Touch Pilot™ display is a cost-effective, touch-screen,
remote-mount device that can be used in lieu of the remote
enhanced display.
Compressor sound blankets reduce unit sound levels
by providing an acoustic blanket on each compressor.
Compressor blankets are also available as factory-installed
option.
Security grilles/hail guards consist of louvered, sheet
metal panels which securely fasten to the unit and provide
condenser coil protection against hail and physical dam-
age. Security grilles/hail guards are also available as a
factory-installed option.
Low sound fans provide a specially designed system of
fan propellers and stacks that reduce sound without reduc-
ing unit performance. The field-installed fan accessory is
compatible with the Motormaster V option. Low sound
fans are also available as factory-installed option.
Wind baffles facilitate operation down to –20 F (–29 C)
when used in conjunction with low ambient temperature
head pressure control.
–
–
*Sponsored by ASHRAE (American Society of Heating, Refrigerating
and Air Conditioning Engineers).
†Registered trademark of Echelon Corporation.

12
Dimensions
38AP UNITS, SIZES 025-030
a38-7101
P
4.62
117.4[]
1.50 38.1[] 1.50 38.1[]
SEE NOTE #4
TYP.
1.00 25.4[]
SEE NOTE #4
TYP.
1.00 25.4
[]
11.81 300.0[]
8.52
216.4
[]
9.52
241.8[]
40.34 1024.5[]
Y
X
H
SEE NOTE #6
15.31 388.9[]
36 [914] MIN.
42 [1067]
MIN.
36 [914] MIN.
48 [1219]
MIN.
FIELD POWER ENTRY SEE NOTE #3
7/8 22.4
[]
RADIUS 20 [508]
CONTROL BOX
HINGED ACCESS
21.06 534.9[]
24.56 623.8[]
88.24 2241.3[]
TOP VIEW
CG
SERVICE
CLEARANCE
BORDER
(NOT TO SCALE)
COIL SIDE SEE NOTE #5
PANEL SIDE
SEE NOTE #5
AIR FLOW
COIL AREA
RIGHT SIDE
VIEW
COIL SIDE
SEE NOTE #5
SEE NOTE'S #1,2
FRONT VIEW
AIR FLOW
FIELD CONTROL WIRING CONNECTIONS
LOW SOUND FAN STACK (PICTORIALLY ONLY)
CONTROL BOX
HINGED ACCESS
CIRCUIT A
LIQUID CONNECTION
CIRCUIT A
SUCTION CONNECTION
CIRCUIT B
SUCTION CONNECTION
CIRCUIT B
LIQUID CONNECTION
SERVICE
ACCESS
COMPRESSOR
ACCESS
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
POWER ENTRY,
in. (mm)
SERVICE VALVE
CONNECTIONS, in. (mm)
X Y H P Suction Liquid
Standard
38APS025 1077 (489) 17.8 (452) 36.9 (937) 61.0 (1549) 24.9 (632) 15/8(41) 5/8(16)
38APD025 1095 (497) 17.8 (452) 37.0 (940) 13/8(35) 5/8(16)
38APS027 1240 (563) 18.2 (462) 37.6 (955)
73.1 (1857) 36.9 (937)
15/8(41) 5/8(16)
38APD027 1258 (571) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
38APS030 1246 (565) 18.2 (462) 37.5 (953) 15/8(41) 7/8(22)
38APD030 1264 (573) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
Low Sound
38APS025 1113 (505) 17.8 (452) 36.9 (937) 66.5 (1689) 24.9 (632) 15/8(41) 5/8(16)
38APD025 1131 (513) 17.8 (452) 37.0 (940) 13/8(35) 5/8(16)
38APS027 1276 (579) 18.2 (462) 37.6 (955)
78.6 (1996) 36.9 (937)
15/8(41) 5/8(16)
38APD027 1294 (587) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
38APS030 1282 (582) 18.2 (462) 37.5 (953) 15/8(41) 7/8(22)
38APD030 1300 (590) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief. 3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring. Actual hole size
required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil End - 42 in. (1067) from solid surface. Panel Side - 48 in. (1219) per NEC (National Electrical Code).
6. Unit height (dimension H) for the low sound fan option includes the fan stack. 7. Installation in a pit is not recommended. 8. Unit can be handled using the fork truck lift pockets. 9. Dimensions shown in inches (mm).
10. Weight does not include unit refrigerant
charge.

13
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE
CONNECTIONS, in. (mm)
X Y H Suction Liquid
Standard
38APS040 1968 (893) 35.0 (869) 44.0 (1118)
73.0 (1854)
21/8(54) 7/8(22)
38APD040 2094 (950) 33.7 (856) 44.1 (1120) 15/8(41) 5/8(16)
38APS050 1977 (897) 34.9 (886) 44.0 (1118) 21/8(54) 7/8(22)
38APD050 2120 (961) 33.4 (848) 44.1 (1120) 15/8(41) 5/8(16) 38APD060 2227 (1010) 34.4 (874) 44.1 (1120) 15/8(41) 5/8(16)
Low Sound
38APS040 2022 (917) 35.0 (869) 44.0 (1118)
78.5 (1994)
21/8(54) 7/8(22)
38APD040 2148 (974) 33.7 (856) 44.1 (1120) 15/8(41) 5/8(16)
38APS050 2031 (921) 34.9 (886) 44.0 (1118) 21/8(54) 7/8(22)
38APD050 2174 (986) 33.4 (848) 44.1 (1120) 15/8(41) 5/8(16) 38APD060 2299 (1043) 34.4 (874) 44.1 (1120) 15/8(41) 5/8(16)
38AP UNITS, SIZES 040-060
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief.
3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring. Actual
hole size required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil End - 72 in. (1829) from solid surface. Panel Side - 48 in. (1219) per NEC (National Electrical Code).
6. Unit height (dimension H) for the low sound fan option includes the fan stack. 7. Installation in a pit is not recommended. 8. Unit can be handled using the fork truck lift pockets. 9. Dimensions shown in inches (mm).
10. Sizes 040 and 050 units have 3 condenser fans. Size 060 units have 4 condenser
fans.
11. Weight does not include unit refrigerant charge.
a38-7102

14
Dimensions (cont)
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE CONNECTIONS,
in. (mm)
SERVICE VALVE LOCATIONS
CIRCUIT B ONLY,
in. (mm)
Suction Liquid Suction
X Y H Circuit A Circuit B S1 S2
Standard 38APS065 2561 (1162) 36.2 (920) 43.6 (1107) 73.0 (1854) — 25/8(67) 7/8(22) 9.26 (235.2) 20.81 (528.61)
38APD070 2450 (1111) 50.9 (1293) 40.6 (1031) 73.0 (1854) 21/8(54) 15/8(41) 7/8(22) 12.85 (326.4) 14.04 (356.6)
Low Sound 38APS065 2387 (1083) 35.1 (892) 34.5 (876) 78.5 (1994) — 25/8(67) 7/8(22) 9.26 (235.2) 20.81 (528.61)
38APD070 2522 (1144) 50.9 (1293) 40.6 (1031) 78.5 (1994) 21/8(54) 15/8(41) 7/8(22) 12.85 (326.4) 14.04 (356.6)
38AP UNITS, SIZES 065,070
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief. 3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring.
Actual hole size required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil, Panel and Rear Side - 72 in. (1829) from solid surface.
6. Unit height (dimension H) for the low sound fan option includes the fan stack. 7. Installation in a pit is not recommended. 8. Unit can be handled using crane. Refer to service installation instructions. 9. Dimensions shown in inches (mm).
10. Weight does not include unit refrigerant charge.

15
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE CONNECTIONS,
in. (mm)
Suction Liquid
X Y H Circuit A Circuit B
Standard
38APD080 2610 (1184) 67.6 (1716) 40.2 (1020)
73.0 (1854)
21/8(54) 15/8(41) 7/8(22)
38APD090 2835 (1286) 72.4 (1839) 43.3 (1099) 21/8(54) 7/8(22) 38APD100 2844 (1290) 72.6 (1844) 43.3 (1099) 21/8(54) 7/8(22)
Low Sound
38APD080 2700 (1225) 67.6 (1716) 40.2 (1020)
78.5 (1994)
21/8(54) 15/8(41) 7/8(22)
38APD090 2943 (1335) 72.4 (1839) 43.3 (1099) 21/8(54) 7/8(22) 38APD100 2952 (1339) 72.6 (1844) 43.3 (1099) 21/8(54) 7/8(22)
38AP UNITS, SIZES 080-100
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief. 3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring.
Actual hole size required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil, Panel and Rear Side - 72 in. (1829) from solid surface.
6. Unit height (dimension H) for the low sound fan option includes the fan stack. 7. Installation in a pit is not recommended. 8. Unit can be handled using crane. Refer to service installation instructions. 9. Dimensions shown in inches (mm).
10. Size 080 units have 5 condenser fans. Sizes 090 and 100 units have 6 con-
denser fans.
11. Weight does not include unit refrigerant charge.
a38-7104

16
Dimensions (cont)
20.81 528.4[]
L1
9.26
235.1[]
L2 12.25
311.2[]
12.85
326.4[]
14.02 356.2[]
28.44 722.3[]
1.50 38.1[]
1.50 38.1[]
SEE NOTE #4
TYP.
1.50 38.1[]
SEE NOTE #4 TYP. 1.50 38.1[]
191.34 4860.0[]
H
4.00 101.6[]
34.99
888.7[]
88.25 2241.4[]
FIELD POWER ENTRY SEE NOTE #3
7/8 22.4[]
RADIUS 24 [610]
CONTROL BOX HINGED DOOR
15.61
396.4[]
4.78
121.3[]
X
Y
CONTROL BOX
HINGED ACCESS
FRONT VIEW
TOP VIEW
LOW SOUND FAN STACK (PICTORIALLY ONLY)
AIR FLOW
AIR FLOW
AIR FLOW
AIR FLOW
CG
RIGHT SIDE
VIEW
CIRCUIT B LIQUID CONNECTION
CIRCUIT B SUCTION CONNECTION
CIRCUIT A
LIQUID
CONNECTION
CIRCUIT A
SUCTION
CONNECTION
SERVICE CLEARANCE BORDER (NOT TO SCALE)
REAR SIDE SEE NOTE #5
PANEL SIDE
SEE NOTE #5
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE CONNECTIONS,
in. (mm)
SERVICE VALVE LOCATIONS
CIRCUIT B ONLY,
in. (mm)
Suction Liquid Liquid
X Y H Circuit A Circuit B L1 L2
Standard 38APD115 3211 (1457) 71.1 (1806) 44.4 (1128) 73.0 (1854) 21/8(54) 25/8(67) 7/8(22) 28.48 (723) 12.25 (311)
38APD130 3353 (1521) 70.9 (1801) 44.6 (1133) 21/8(54) 25/8(67) 7/8(22) 28.36 (720) 11.97 (304)
Low Sound 38APD115 3319 (1506) 71.1 (1806) 44.4 (1128) 78.5 (1994) 21/8(54) 25/8(67) 7/8(22) 28.48 (723) 12.25 (311)
38APD130 3461 (1570) 70.9 (1801) 44.6 (1133) 21/8(54) 25/8(67) 7/8(22) 28.36 (720) 11.97 (304)
38AP UNITS, SIZES 115,130
NOTES:
1. Be sure to use a wet rag to remove all valve cores before braz-
ing field piping.
2. Do not cap or otherwise obstruct the liquid line temperature
relief.
3. A 7/8in. (22.4 mm) diameter hole is provided for locating field
power wiring. Actual hole size required depends on field wire
sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil, Panel and Rear Side - 72 in. (1829) from solid surface.
6. Unit height (dimension H) for the low sound fan option includes
the fan stack.
7. Installation in a pit is not recommended. 8. Unit can be handled using crane. Refer to service installation
instructions.
9. Dimensions shown in inches (mm).
10. Weight does not include unit refrigerant charge. 11. Size 115 units have 7 condenser fans. Size 130 units have 8
condenser fans.

17
To select a 38AP stand-alone condensing unit:
Use Carrier's Commercial Split Builder program to se-
lect a stand-alone outdoor unit from the Installation Config-
uration drop down menu and input the job requirements.
From the list presented, select a 38AP condensing
unit that is estimated to meet capacity requirements.
The 38APS single-circuit unit is offered in sizes 025-065
and the 38APD dual-circuit unit is offered in sizes 025-
130. After a 38AP unit is selected, the program will calcu-
late the condensing unit performance.
To select 38AP systems:
For systems with one 40RU fan coil unit or
39 Series air handler — Use Carrier's Commercial
Split Builder program to select a combined 38AP out-
door unit with matched 40RU indoor unit for sizes 025-
030. The AHUBuilder®selection program is available to
select 38AP outdoor units with a matching 39 Series air
handler with direct-expansion (DX) coils. The 38APS sin-
gle-circuit unit is offered in sizes 025-065 and 38APD
dual-circuit unit is offered in sizes 025-130. Enter the soft-
ware program and input the job requirements. From the
list presented, select a 38AP condensing unit that is esti-
mated to meet capacity requirements. After selecting a
38AP unit, check its performance with one or several DX
coils. From the DX coil list presented on the screen, match
the 38AP with any coil or all coils. The program calculates
the combined performance of the condensing unit and
each DX coil and presents the resulting system capacities
and operating temperatures. Matching thermostatic ex-
pansion valves and nozzles for the DX coils are automati-
cally selected and displayed.
For systems with two air handlers — Use Carrier's
AHUBuilder®selection program to select one size 025-
130 38AP outdoor unit to match with two 39 Series air
handlers with DX coils. For the first air handler, enter the
AHUBuilder selection program and input the job require-
ments. To choose a condensing unit, select the Specify
Your Own option. The program asks for condensing unit
capacities and SDT (saturated discharge temperature) at
30 F ( 1.1 C) and 50 F (10 C) SST (saturated suction tem-
perature). The SDT must first be determined by running a
standalone outdoor unit in the Commercial Split Build-
er program. The circuit capacity is listed in the Condens-
ing Unit Circuit Ratings tables on pages 23-34, 40-51, 57-
68, and 74-85. Enter the capacities from condenser circuit
A or B and SDT for circuits A and B into the AHUBuilder
program. (remember to use the correct air temperature en-
tering condenser column when locating the circuit capaci-
ties). For the second air handler, repeat the procedure to
select the second DX coil for the condenser circuit (A or B)
not used in the first selection.
–
Selection procedure

18
38APD,APS025 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
38APD,APS027 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
38APD,APS030 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
LEGEND
NOTES:
1. Ratings are based on 15 F superheat and use of R-410A
refrigerant.
2. Ratings include suction line losses due to an accumulator.
3. Refer to Commercial Split Builder program for more detailed
information.
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 203.0 195.9 188.4 181.5 174.5 167.5 160.2 152.9 145.4 138.5 131.4
kW 16.7 17.7 18.8 19.8 20.9 21.9 23.0 24.1 25.2 26.2 27.3
25 TC 225.7 218.1 210.1 202.8 195.3 187.8 180.1 172.1 164.2 156.9 149.2
kW 17.0 18.1 19.2 20.2 21.3 22.4 23.5 24.7 25.8 26.8 27.9
30 TC 250.0 241.8 233.3 225.4 217.4 209.2 201.0 192.6 184.1 176.2 168.0
kW 17.2 18.4 19.6 20.6 21.7 22.8 24.0 25.1 26.3 27.4 28.5
35 TC 275.6 266.8 257.7 249.2 240.6 231.9 223.0 214.0 204.7 196.3 187.5
kW 17.5 18.6 19.9 20.9 22.0 23.2 24.3 25.5 26.8 27.8 29.0
40 TC 302.0 292.5 282.6 273.5 264.2 254.8 245.3 235.6 225.7 216.6 207.1
kW 18.1 19.2 20.5 21.6 22.8 23.8 25.0 26.2 27.5 28.6 29.8
45 TC 328.2 318.0 307.3 297.5 287.5 277.4 267.1 256.6 245.9 236.1 225.9
kW 18.1 19.2 20.5 21.6 22.8 23.8 25.0 26.2 27.5 28.6 29.8
50 TC 353.7 342.7 331.2 320.5 309.6 298.6 287.5 276.1 264.6 253.9 242.9
kW 18.4 19.6 20.9 21.9 23.0 24.2 25.4 26.6 27.8 28.9 30.1
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 232.0 225.0 217.7 210.9 204.0 197.0 190.0 182.8 175.5 168.7 161.7
kW 18.2 19.4 20.9 22.0 23.2 24.4 25.7 27.1 28.5 29.6 30.9
25 TC 256.5 248.9 241.0 233.5 226.0 218.5 210.8 202.9 195.1 187.7 180.0
kW 18.6 19.9 21.3 22.5 23.7 24.9 26.2 27.6 29.0 30.1 31.4
30 TC 282.5 274.2 265.6 257.5 249.3 241.0 232.6 224.2 215.5 207.4 199.1
kW 19.2 20.4 21.8 23.0 24.1 25.4 26.7 28.0 29.5 30.6 31.8
35 TC 309.6 300.5 291.1 282.3 273.4 264.4 255.2 245.9 236.4 227.6 218.5
kW 19.7 20.9 22.4 23.5 24.7 25.9 27.2 28.5 30.0 31.1 32.3
40 TC 336.9 327.1 316.8 307.3 297.6 287.8 277.9 267.8 257.5 248.0 238.1
kW 20.9 22.1 23.5 24.6 25.8 27.0 28.3 29.6 31.0 32.1 33.3
45 TC 364.2 353.5 342.4 332.0 318.6 310.8 300.0 289.0 277.9 267.5 256.8
kW 20.9 22.1 23.5 24.6 25.8 27.0 28.3 29.6 31.0 32.1 33.3
50 TC 391.3 379.6 367.6 356.2 344.7 333.1 321.4 309.5 297.4 286.1 274.4
kW 21.5 22.8 24.2 25.2 26.4 27.6 28.9 30.2 31.6 32.6 33.9
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 270.2 262.2 253.9 246.1 238.2 230.3 222.1 213.9 205.6 197.9 189.8
kW 21.9 23.5 25.2 26.7 28.1 29.6 31.3 33.0 34.7 36.1 37.7
25 TC 298.8 290.1 281.1 272.6 264.1 255.4 246.6 237.8 228.7 220.3 211.5
kW 22.5 24.1 25.8 27.2 28.7 30.3 31.9 33.6 35.4 36.8 38.4
30 TC 328.8 319.4 309.6 300.5 291.2 281.9 272.5 262.8 253.0 243.9 234.5
kW 23.1 24.7 26.5 27.9 29.3 30.9 32.5 34.2 36.0 37.4 39.0
35 TC 359.8 349.6 339.0 329.2 319.2 309.1 298.8 288.4 277.8 268.0 257.8
kW 23.7 25.3 27.1 28.5 30.0 31.5 33.2 34.9 36.7 38.1 39.6
40 TC 390.7 379.8 368.5 358.0 347.4 336.7 325.7 314.5 303.1 292.7 281.8
kW 25.2 26.8 28.5 29.9 31.4 32.9 34.5 36.2 38.0 39.4 41.0
45 TC 421.2 409.6 397.6 386.5 373.5 363.7 352.1 340.2 328.1 317.0 305.4
kW 25.2 26.8 28.5 29.9 31.4 32.9 34.5 36.2 38.0 39.4 41.0
50 TC 452.0 439.6 426.8 414.8 402.6 390.3 377.9 365.3 352.2 340.3 327.9
kW 26.1 27.6 29.4 30.7 32.2 33.7 35.3 36.9 38.7 40.1 41.6
kW — Compressor Power
SST — Saturated Suction Temperature Entering Condensing Unit
TC — Gross Cooling Capacity (1000 Btuh)
Performance data

19
38APD040 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
38APS040 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
38APD050 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
LEGEND
NOTES:
1. Ratings are based on 15 F superheat and use of R-410A
refrigerant.
2. Ratings include suction line losses due to an accumulator.
3. Refer to Commercial Split Builder program for more detailed
information.
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 335.7 324.3 312.4 301.3 290.3 278.9 267.5 255.8 243.6 232.8 221.4
kW 26.2 28.1 30.1 31.9 33.7 35.6 37.6 39.6 41.6 43.4 45.3
25 TC 372.4 360.1 347.2 335.4 323.4 311.1 298.6 286.2 273.1 261.4 249.0
kW 26.6 28.6 30.7 32.5 34.4 36.3 38.3 40.4 42.5 44.3 46.2
30 TC 411.2 397.9 384.0 371.1 358.4 345.3 331.9 318.0 304.1 291.5 278.2
kW 27.1 29.1 31.3 33.1 35.0 37.0 39.0 41.1 43.3 45.1 47.1
35 TC 451.9 437.5 422.8 408.8 394.9 380.7 366.4 351.6 336.8 323.0 308.7
kW 27.6 29.7 31.9 33.7 35.6 37.7 39.7 41.9 44.1 45.9 47.9
40 TC 494.0 478.6 462.8 447.5 432.2 417.3 401.5 385.9 369.6 354.8 339.3
kW 28.8 30.8 33.1 34.9 36.5 38.9 41.0 43.2 45.4 47.3 49.4
45 TC 538.1 521.2 503.7 486.9 470.9 453.8 437.0 420.1 401.4 385.6 368.7
kW 28.8 30.8 33.1 34.9 36.5 38.9 41.0 43.2 45.4 47.3 49.4
50 TC 582.3 563.9 544.3 527.5 509.4 491.1 471.6 453.6 434.5 416.7 398.3
kW 29.4 31.5 33.7 35.6 37.6 39.6 41.7 43.9 46.1 48.0 50.1
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 342.5 331.8 321.0 310.5 300.0 289.5 278.8 268.0 257.0 246.7 236.0
kW 25.9 27.7 29.8 31.4 33.2 35.0 36.9 38.9 41.0 42.6 44.5
25 TC 378.2 366.5 354.6 343.3 331.9 320.3 308.7 296.8 284.8 273.6 261.9
kW 26.6 28.4 30.5 32.2 33.9 35.7 37.6 39.6 41.7 43.4 45.2
30 TC 416.3 403.6 390.5 378.2 365.7 353.1 340.3 327.4 314.1 301.9 289.1
kW 27.3 29.2 31.3 33.0 34.7 36.5 38.4 40.4 42.5 44.2 46.0
35 TC 456.7 442.8 428.5 414.9 401.3 387.5 373.5 359.3 344.8 331.4 317.5
kW 28.2 30.1 32.1 33.8 35.5 37.4 39.3 41.3 43.4 45.0 46.9
40 TC 498.8 483.7 468.2 453.4 438.5 423.4 408.1 392.6 377.5 362.5 347.3
kW 29.1 30.9 33.0 34.7 36.4 38.3 40.2 42.2 44.3 45.9 47.8
45 TC 543.2 526.6 510.2 493.3 477.0 460.5 443.7 427.7 410.6 394.2 377.7
kW 30.1 31.9 34.0 35.7 37.4 39.2 41.1 43.1 45.2 46.9 48.7
50 TC 589.2 571.2 553.5 535.0 517.1 499.0 481.9 463.6 445.1 427.4 409.4
kW 31.1 33.0 35.1 36.7 38.4 40.2 42.2 44.2 46.2 47.9 49.7
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 433.0 418.5 403.0 389.1 375.2 361.3 347.3 331.8 314.7 302.2 287.6
kW 36.5 38.9 41.5 43.7 46.0 48.4 50.9 53.4 55.9 58.2 60.7
25 TC 478.5 463.0 446.8 431.7 417.0 401.9 385.8 370.6 353.2 339.0 323.5
kW 37.3 39.8 42.4 44.7 47.0 49.5 52.0 54.6 57.2 59.5 62.0
30 TC 526.4 509.8 492.9 476.6 460.3 444.3 426.8 410.3 393.4 377.2 360.6
kW 38.1 40.6 43.4 45.7 48.0 50.5 53.1 55.7 58.5 60.7 63.2
35 TC 578.9 560.6 541.3 524.3 506.7 488.5 469.7 450.8 432.5 414.8 396.5
kW 39.1 41.6 44.4 46.7 49.1 51.6 54.1 56.8 59.5 61.8 64.4
40 TC 632.1 612.3 591.1 572.6 553.4 534.0 514.4 493.3 472.0 453.7 433.8
kW 41.1 43.6 46.4 48.7 50.1 53.6 56.2 58.9 61.7 64.0 66.5
45 TC 686.6 665.0 642.1 622.2 600.2 580.1 556.8 534.9 513.9 492.5 471.0
kW 41.1 43.6 46.4 48.7 50.1 53.6 56.2 58.9 61.7 64.0 66.5
50 TC 740.3 717.1 693.4 670.7 648.0 624.2 600.4 578.3 553.9 531.1 507.9
kW 42.2 44.7 47.5 49.8 52.2 54.7 57.3 60.0 62.7 65.0 67.6
kW — Compressor Power
SST — Saturated Suction Temperature Entering Condensing Unit
TC — Gross Cooling Capacity (1000 Btuh)

20
38APS050 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
38APD060 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
38APS065 CONDENSING UNIT RATINGS, 60 Hz ENGLISH
LEGEND
NOTES:
1. Ratings are based on 15 F superheat and use of R-410A
refrigerant.
2. Ratings include suction line losses due to an accumulator.
3. Refer to Commercial Split Builder program for more detailed
information.
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 411.1 398.1 386.4 369.8 359.0 346.1 333.0 319.8 306.3 293.5 280.4
kW 33.4 35.8 38.6 40.4 42.6 45.0 47.5 50.0 52.7 54.7 57.1
25 TC 451.7 438.1 424.4 409.0 398.0 387.2 367.2 355.8 341.6 325.9 311.1
kW 35.3 37.5 40.0 42.0 44.0 46.3 48.2 50.8 53.5 55.3 57.5
30 TC 503.7 486.6 471.0 453.0 435.0 417.0 399.0 381.2 371.3 349.9 332.8
kW 59.7 61.9 40.3 42.5 44.7 46.9 49.1 51.4 54.1 40.3 42.5
35 TC 551.1 534.3 516.6 500.6 484.4 469.0 451.0 433.9 415.9 400.3 383.6
kW 36.4 38.7 41.3 43.4 45.6 47.9 50.3 52.8 55.3 57.4 59.8
40 TC 602.4 584.3 565.4 548.0 530.1 512.1 495.3 476.6 455.5 439.4 421.3
kW 37.3 39.7 42.3 44.4 46.6 48.8 51.3 53.8 56.3 58.4 60.8
45 TC 656.0 636.0 614.8 596.9 577.5 556.4 536.3 515.7 496.6 476.6 456.7
kW 38.9 41.2 43.2 45.4 49.2 49.8 52.2 54.6 57.2 59.3 61.5
50 TC 710.1 688.0 665.3 644.2 623.1 599.6 577.5 556.3 533.4 511.8 489.8
kW 39.5 41.8 44.3 46.4 48.5 50.8 53.1 55.6 58.1 60.1 62.4
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 492.7 478.8 459.7 453.8 440.6 424.6 410.4 394.7 379.9 368.0 354.2
kW 39.9 42.8 45.8 48.4 51.2 53.8 56.7 59.7 62.9 65.4 68.2
25 TC 551.7 535.5 517.9 505.1 485.4 472.8 456.4 438.7 421.5 406.7 390.6
kW 41.2 44.0 47.1 49.7 52.2 54.8 57.7 60.9 64.0 66.4 69.2
30 TC 607.4 589.8 570.0 555.1 536.5 520.8 503.6 486.0 462.4 448.6 431.0
kW 42.4 45.2 48.3 50.9 53.4 56.0 58.9 62.0 65.2 67.6 70.4
35 TC 653.4 636.1 609.0 605.5 591.5 573.3 546.6 532.6 511.7 498.2 481.0
kW 43.6 46.5 49.5 52.1 54.7 57.6 60.3 63.2 66.4 68.9 71.7
40 TC 701.2 684.4 649.2 660.0 645.0 623.4 602.6 581.2 559.3 550.1 533.3
kW 46.4 49.2 52.2 54.9 57.6 60.4 63.2 66.1 69.2 71.8 74.6
45 TC 760.6 742.3 705.5 712.8 700.1 679.5 648.7 631.8 606.0 596.1 577.8
kW 46.4 49.2 52.2 54.9 57.6 60.4 63.2 66.1 69.2 71.8 74.6
50 TC 835.2 813.2 776.2 779.4 754.4 728.7 704.3 678.9 654.7 637.2 615.3
kW 48.1 50.9 53.9 56.7 59.2 61.9 64.7 67.7 70.8 73.3 76.1
SST (F) CONDENSER ENTERING-AIR TEMPERATURE (F)
70 80 85 90 95 100 105 110 115 120 125
20 TC 509.5 492.8 476.1 459.1 442.9 426.2 409.5 392.6 375.8 359.2 342.5
kW 41.8 44.6 47.7 50.2 52.9 55.6 58.5 61.5 64.7 67.2 70.0
25 TC 564.4 546.0 527.6 509.4 490.7 472.9 454.1 436.1 417.3 399.1 380.8
kW 43.0 45.9 49.0 51.5 54.1 56.9 59.8 62.8 65.9 68.5 71.3
30 TC 622.1 602.1 582.0 561.9 542.0 521.7 502.2 481.9 461.5 441.7 421.6
kW 44.3 47.2 50.3 52.8 55.5 58.3 61.1 64.1 67.3 69.8 72.6
35 TC 683.9 662.0 639.6 618.0 596.5 574.7 552.7 530.4 507.9 486.5 464.6
kW 45.7 48.6 51.7 54.2 56.9 59.7 62.6 65.6 68.7 71.2 74.1
40 TC 748.5 724.6 700.7 676.9 652.8 628.7 605.8 581.0 557.4 533.5 509.6
kW 47.2 50.1 53.2 55.7 58.4 61.1 64.0 67.1 70.2 72.7 75.5
45 TC 818.8 792.3 765.8 738.0 714.6 685.8 660.6 634.8 604.8 580.2 553.6
kW 48.4 51.3 54.8 57.3 58.5 62.7 65.6 68.6 71.7 74.2 77.1
50 TC 882.2 854.9 826.1 801.4 771.8 747.7 719.4 691.9 661.9 636.6 609.3
kW 50.6 53.4 56.5 59.0 61.7 64.5 67.3 70.3 73.4 75.9 78.8
kW — Compressor Power
SST — Saturated Suction Temperature Entering Condensing Unit
TC — Gross Cooling Capacity (1000 Btuh)
Performance data (cont)
