Gemini Select 38AP Commercial Condensing Units
• 25 to 130 Tons
• Digital compressor technology
• HFC Puron®refrigerant (R-410A)
• Reduced operating costs
• Quiet operation
• Reliable operation
• Freeze protection operating down to -20oF
• ASHRAE 90.1 compliant
• ETL listed
• Easy to start and operate
1-800-CARRIER www.carrier.com
© Carrier Corporation 2012
Cat. no. 04-811-50023
Manufacturer reserves the right to discontinue, or change at any time,
specifications or designs, without notice and without incurring obligations.
Gemini®Select 38AP
Commercial Condensing Units
The Future of the World Depends on Our Ability…
to Sustain it.
As the world’s leader in high technology
heating, air-conditioning and refrigeration
solutions, we believe that market leadership
requires environmental leadership. Carrier
sets industry standards for environmentally
sound business practices and a commitment
to sustainability across its products, services and operations.
We demonstrate this commitment by creating environmentally
responsible solutions that consume less energy and incorporate
innovations that improve the world – indoors and out.
A Legacy of Training
Willis H. Carrier began training members of
the heating, ventilation, air conditioning and
refrigeration industry in 1905. Carrier continues
to promote technical expertise in the industry
with the expansion of its sustainable solutions
curriculum and has recently been named a U.S.
Green Building Council Education Provider (USGBC EP).
To earn this status, Carrier’s course materials were reviewed
by a panel of USBGC peers and deemed to provide the high
level of quality required for training Leadership in Energy and
Environmental Design (LEED®) professionals. The courses and
workshops supporting LEED-Accredited Professional and Green
Associates credential maintenance are administered through
Carrier University.

Leave it to Carrier to design condensing units in ways you’ll notice at
the initial purchase, through installation, and for years afterward. Our
Gemini®Select commercial condensing units install quickly and easily
to save you time and money. And the savings will continue to mount
with lower operating costs due to the Gemini Select condensing unit’s
superior full- and part-load performance.
Available in 25 to 130 tons, the 38AP condensing units come in two
refrigerant circuits: 38APS single refrigerant circuit Gemini Select
condensing unit and 38APD dual refrigerant circuit Gemini Select
condensing unit, both models with HFC Puron®refrigerant (R-410A),
scroll compressors, and Novation®microchannel condenser coils to
provide excellent part-load performance in a compact package, while
exceeding ASHRAE 90.1 minimum energy efficiency requirements.
With non-ozone depleting refrigerant, simple installation, superior
efficiency and powerful controls, these units are ideal for both
replacement and new construction projects.
Environmental Leadership
All of the energy-efficient 38AP condensing units, from 25 to 130
tons, use Puron refrigerant and can be incorporated into Leadership
in Energy and Environmental Design (LEED®) Green Building Rating
System projects.
Affordability/Installability
Gemini Select commercial condensing units feature a compact
footprint design. These condensing units provide a cost effective
solution for both new system installations as well as drop in outdoor
unit replacement in the 25 to 130 ton range.
Efficiency
Along with cost efficiency in purchase and installation, Gemini Select
commercial condensing units are also more affordable to operate.
They are highly efficient, with full-load energy efficiency ratios (EER)
up to 11.5 and integrated part-load value (IPLV) ratings as high as
16.2. The key to Gemini Select commercial condensing unit’s great
operating performance is the use of highly efficient rotary scroll
compressors. These compressors use patented sealing techniques,
allowing for high volumetric efficiency and low frictional losses. They
are maintenance-free and protected by an auto-adaptive control that
minimizes wear.
Building Load Matching
Excellent temperature control and building load matching is achieved
with the digital compressor. The digital compressor provides
incremental unloading and reduced compressor cycling ultimately
providing exceptional building load match and higher compressor
reliability than standard scroll cycling.
The Right Level of Control
Carrier’s commercial ComfortLink control system makes it easy to
monitor and control each Gemini Select commercial condensing unit.
The ComfortLink system with Energy Management Module provides
functions such as demand limit, percent capacity, and supply air
temperature reset capabilities. These features provide added control
for reducing energy usage and Building Management System (BMS)
input control.
The Gemini Select condensing units offer several display options,
including the Scrolling Marquee (standard display), Touch Pilot™,
and Navigator handheld controller. These act as windows to the unit’s
operation and greatly reduce start-up time. An easy-to-follow menu
structure makes it simple to find the required information for start-up
and service.
®
The Touch Pilot display provides an easy to use touch screen user
interface. It provides access to configuration, maintenance, service,
setpoint, time schedule, alarm history and status data.
The scrolling marquee’s large light-emitting diode (LED) display is easy
to read in any lighting condition. Even gloved hands can easily access
large control buttons. An optional accessory on all Gemini Select
condensing units, the Navigator controller by Carrier is an exclusive
remote handheld diagnostic unit which provides expanded information
on virtually every aspect of operation, helping technicians to quickly
diagnose problems and even prevent them from occurring. All Gemini
Select condensing units are also ready to be used with the Carrier
Comfort Network®(CCN) control system. Additionally, 38AP units
can communicate BACnet®, MODBUS®, or LON®using an accessory
translator card or can be controlled with 4-20 mA input (BMS) signal
with the Energy Management Module.
For all your comfort needs, Carrier has the right level of control.
BACnet is a registered trademark of ASHRAE. Modbus is a registered trademark of Schneider Automation, Inc.
LON is a registered trademark of Echelon Corporation.
Selection Guide
Model 38APS (R-410A) 025 027 030 040 050 065
Capacity (tons) 24.0 26.6 31.1 39.8 48.1 59.6
Full Load Efficiency (EER) 11.0 10.9 10.8 11.5 10.8 11.1
Part Load Efficiency (IPLV) 14.4 14.7 14.3 16.2 15.0 15.1
Length (in.) 89 89 89 93 93 111
Width (in.) 41 41 41 89 89 89
Height (in.) 61 74 74 73 73 73
Operating Weight (lbs.) 1077 1240 1246 1968 1977 2561
Model 38APD (R-410A) 025 027 030 040 050 060 070 080 090 100 115 130
Capacity (tons) 24.0 26.6 31.1 39.2 50.0 58.3 67.3 78.0 87.4 96.0 110.4 125.1
Full Load Efficiency (EER) 11.0 10.9 10.8 11.5 11.1 11.0 11.0 11.1 11.3 11.1 11.1 11.1
Part Load Efficiency (IPLV) 13.1 14.0 12.8 15.3 14.9 14.5 15.7 15.6 15.3 15.0 15.2 15.2
Length (in.) 89 89 89 93 93 93 111 152 152 152 192 192
Width (in.) 41 41 41 89 89 89 89 89 89 89 89 89
Height (in.) 61 74 74 73 73 73 73 73 73 73 73 73
Operating Weight (lbs.) 1095 1258 1264 2094 2120 2227 2450 2610 2835 2844 3211 3353
Gemini®Select 38AP
Commercial Condensing Units

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53380012-01 Printed in U.S.A. Form 38AP-7SI Pg 1 7-11 Replaces: 38AP-6SI
Installation Instructions
CONTENTS
Page
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-37
Step 1 — Inspect Shipment . . . . . . . . . . . . . . . . . . . . . . 1
Step 2 — Rig and Place Unit . . . . . . . . . . . . . . . . . . . . . 1
 DOMESTIC UNITS
 EXPORT UNITS
 PLACING UNITS
Step 3 — Make Refrigerant Piping
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
 SIZE REFRIGERANT LINES
 LIQUID LINE SOLENOID VALVE
 THERMOSTATIC EXPANSION VALVES
 LIQUID LINE FILTER DRIER
 LONG LINE APPLICATIONS
 HOT GAS BYPASS
 FINAL CONNECTION AND LEAK TEST
 EVACUATION AND DEHYDRATION
Step 4 — Make Electrical Connections . . . . . . . . . . 28
 POWER SUPPLY
 POWER WIRING
 CONTROL POWER
 FIELD CONTROL WIRING
Step 5 — Install Accessories . . . . . . . . . . . . . . . . . . . . 37
 LOW-AMBIENT OPERATION
 MISCELLANEOUS ACCESSORIES
SAFETY CONSIDERATIONS
Installing, starting up, and servicing this equipment can be
hazardous due to system pressures, electrical components, and
equipment location (roofs, elevated structures, etc.).
Only trained, qualified installers and service mechanics
should install, start up, and service this equipment.
Untrained personnel can perform basic maintenance func-
tions, such as cleaning coils. All other operations should be
performed by trained service personnel.
When working on the equipment, observe precautions in the
literature, and on tags, stickers, and labels attached to the
equipment and any other safety precautions that may apply.
 Follow all safety codes.
 Wear safety glasses and work gloves.
 Use care in handling, rigging, and setting bulky
equipment.
INSTALLATION
Step 1 — Inspect Shipment — Inspect unit for dam-
age upon arrival. If damage is found, immediately file a claim
with the shipping company. Verify proper unit delivery by
checking unit nameplate data and the model number nomen-
clature shown in Fig. 1. See Tables 1-4 for unit physical data.
Step 2 — Rig and Place Unit — All units are de-
signed for overhead rigging, and it is important that this meth-
od be used. Lifting holes are provided in the frame base rails. It
is recommended to use shackles in the lifting holes (see rigging
label on the unit and Fig. 2 and 3 for rigging weights and center
of gravity). All panels must be in place when rigging.
Use spreader bars or frame to keep the cables, chains, and
straps clear of the unit sides. Leave standard coil protection
packaging in place during rigging to provide protection to
coils. Remove and discard all coil protection after rigging ca-
bles are detached.
WARNING
Open all remote disconnects before servicing this equip-
ment. Failure to do so could result in personal injury from
electric shock.
CAUTION
Puron refrigerant (R-410A) systems operate at higher pres-
sures than standard R-22 systems. Do not use R-22 service
equipment or components on Puron refrigerant equipment.
If service equipment is not rated for Puron refrigerant,
equipment damage or personal injury may result.
IMPORTANT: To maintain unit stability while lifting,
use 4 cables, chains or straps of equal length. Attach one
end of each cable to shackle attachment point and the
other end of each cable to the overhead rigging point.
CAUTION
All panels must be in place when rigging. Failure to com-
ply could result in equipment damage.
CAUTION
For unit sizes 025 to 060 when handling with a forklift,
handle only through fork pocket holes. Failure to follow
this caution could result in equipment damage or personal
injury.
CAUTION
For unit sizes 065 to 130, do not forklift the unit unless unit
is attached to a skid designed for forklifting. Failure to fol-
low this caution could result in equipment damage or per-
sonal injury.
GEMINI™ SELECT
38APS025-065, 38APD025-130
Air-Cooled Condensing Units with PURON®Refrigerant (R-410A)
50/60 Hz

2
DOMESTIC UNITS  Standard 38AP unit packaging con-
sists of coil protection only. Skids are not provided. If overhead
rigging is not available at the jobsite, place the unit on a skid or
pad before dragging or rolling. When rolling, use a minimum
of 3 rollers. When dragging, pull the pad or skid. Do not apply
force to the unit. When in final position, raise from above to lift
unit off the pad or skid.
EXPORT UNITS  All export units are mounted on skids
with vertical coil protection. Leave the unit on the skid until it
is in final position. While on the skid, the unit can be rolled or
skidded. Apply force to the skid, not to the unit. Use a mini-
mum of 3 rollers when rolling. When in final position, raise
from above to remove the skid.
PLACING UNITS  When considering location of the unit,
be sure to consult National Electrical Code (NEC, U.S.A.) and
local code requirements. Allow sufficient space for airflow,
wiring, piping, and service. The placement area must be level
and strong enough to support the operating weight of the unit.
(See Fig. 2.) When unit is in proper location, use of mounting
holes in base rails is recommended for securing unit to
supporting structure. For mounting unit on vibration isolators,
4 x 24 in. perimeter support ASTM C channels between unit
and the isolators are recommended with a minimum of 4 chan-
nels per unit. Fasteners for mounting unit are field supplied.
See Fig. 4.
Refer to Fig. 5-9 for airflow clearances. Recommended
minimum clearances are 6 ft (1829 mm) for unrestricted air-
flow and service on sides of unit, 4 ft (1219 mm) on ends, and
unrestricted clear air space above the unit. Provide ample space
to connect liquid and suction lines to indoor unit. For multiple
units, allow 10 ft (3048 mm) separation between airflow
surfaces. If walls surround the unit, wall height should not ex-
ceed the top of the unit fan discharge. Installation in a pit is not
recommended.
Refer to Fig. 10 for outdoor fan and compressor layout.
Refer to Fig. 11 and 12 for unit piping installation. See
Table 5 for refrigerant specialties part numbers.
IMPORTANT: Be sure to mount unit level to ensure
proper oil return to compressors.
38AP D 025 6 4 A 1 0 0 5 0
38AP – Split System Condensing Unit Packaging/Security Options
0– Std Packaging
4– Security Grilles/Hail Guards
8– Std Packaging, Bottom Skid
Controls/CommunicationsOptions
2– Scrolling Marquee
3– EMM, Scrolling Marquee
5– No Display
Ambient/Capacity Control/
Interrupt Options†
0– Std Ambient, Std Compressor,
Std Interrupt
2– Std Ambient, Digital Compressor,
Std Interrupt
3– Std Ambient, Std Compressor,
High Interrupt
5– Std Ambient, Digital Compressor,
High Interrupt
6– Low Ambient, Std Compressor,
Std Interrupt
8– Low Ambient, Digital Compressor,
Std Interrupt
9– Low Ambient, Std Compressor,
High Interrupt
C– Low Ambient, Digital Compressor,
High Interrupt
Line Length Options
1– Standard Line Length
2– Long Line Length Check Valves
Electrical Options
0– Single Point Power, Terminal Block
1– Single Point Power,
Non-Fused Disconnect
Refrigeration Circuit Options*
D– Dual Refrigeration Circuit
S– Single Refrigeration Circuit
Revision Level
A– Current Revision Level
ylppuSrewoP
1– 575-3-60
2– 380-3-60
5– 280/230-3-60
6– 460-3-60
9– 380/415-3-50
Condenser Coil/Low Sound Options
4– MCHX, No Sound Treatment
5– E-coat, MCHX, No Sound Treatment
C– MCHX, Low Sound Fan(s)
D– E-coat MCHX, Low Sound Fan(s)
H– MCHX, Low Sound Fan(s), Compressor Blankets
J– E-coat MCHX, Low Sound Fan(s), Compressor Blankets
Nominal Capacity – Tons(kW)
D– Bottom Skid, Security Grilles/Hail Guards
J– Bottom Skid, Top Crate, Bag
N
– Bottom Skid, Top Crate, Bag,
Security Grilles/Hail Guards
025 – 25 (88)
050 – 50 (176) 090 – 90 (317)
027 – 27 (95)
060 – 60 (211) 100 – 100 (352)
030– 30 (106) 070 – 70 (246)
040 – 40 (141) 080– 80 (281)
065 – 65 (229) 115 – 115 (404)
130– 130 (457)
2– Dual Point Power,
XL, Terminal Block**
LEGEND
*38APS units available in sizes 025-065 only.
†Digital compressor not available on size 065.
**Only available on sizes 115 and 130.
EMM — Energy Management Module
MCHX — Microchannel Heat Exchanger
Fig. 1 — Model Number Nomenclature
a38-7200

3
Table 1 — 38AP025-050 Unit Physical Data — English
LEGEND
*Typical operating charge with 25 ft of interconnecting piping. Operating
charge is approximate for maximum system capacity. Unit is factory supplied
with nitrogen holding charge. Refrigerant charge for dual circuit units is the
total for both circuits.
†Maximum vertical separation between evaporator coil and condensing unit if
condensing unit is below the evaporator.
38AP UNIT SIZE 025 027 030 040 050
NOMINAL CAPACITY, 50/60 Hz (tons) 21/25 23/27 25/30 33/40 42/50
CIRCUIT Dual Single Dual Single Dual Single Dual Single Dual Single
OPERATING WEIGHTS (lb)
Standard 1095 1077 1258 1240 1264 1246 2094 1968 2120 1977
With Low Sound Option 1131 1113 1294 1276 1300 1282 2148 2022 2174 2031
REFRIGERANT CHARGE (lb)
Total*
Circuit A/Circuit B
24
12/12
24
24/—
26
13/13
26
26/—
28
14/14
29
29/—
38
21/17
39
39/—
48
22/26
48
48/—
NITROGEN SHIPPING CHARGE 15 psig
COMPRESSOR
hp (Qty) (CKT A/CKT B)
11 (1)/
11 (1) 11 (2) 13 (1)/ 13 (1) 13 (2) 15 (1)/ 15 (1) 15 (2) 10 (2)/ 8.5 (2) 13 (3) 11 (2)/ 13 (2) 15 (3)
CAPACITY STEPS
Standard 2 2 2 2 2 2 4 3 4 3
Digital Option 22 22 22 22 22 22 36 27 36 27
CRANKCASE HEATER (W) (each compressor) 90 (60 Hz), 75 (50 Hz)
CONDENSER FANS
Standard Propeller Type, Axial, Vertical Discharge
Quantity 2 2 2 2 2 2 3 3 3 3
RPM 1140 (60 Hz), 950 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 3300 3300 3300 3300 3300 3300 4200 4200 4200 4200
Total Watts (50 Hz) 1997 1997 1997 1997 1997 1997 2541 2541 2541 2541
Low Noise Plastic Type, Axial, Vertical Discharge
Quantity 2 2 2 2 2 2 3 3 3 3
RPM 850 (60 Hz), 700 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 2750 2750 2750 2750 2750 2750 3500 3500 3500 3500
Total Watts (50 Hz) 1664 1664 1664 1664 1664 1664 2118 2118 2118 2118
CONDENSER COIL MCHX Type
No. Coils per Circuit 1 1 1 1 1 1 1 2 1 2
sq ft 27.1 27.1 33.9 33.9 33.9 33.9 67.8 67.8 67.8 67.8
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 210 F
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 13/8/ 13/815/813/8/ 13/815/813/8/ 13/815/815/8/ 15/821/815/8/ 15/821/8
Liquid Line 5/8/ 5/85/85/8/ 5/85/85/8/ 5/87/85/8/ 5/87/85/8/ 5/87/8
MAXIMUM HEIGHT FOR 3° F SUBCOOLING
(ft)†
75 75 75 75 75 75 75 75 75 75
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 50/50 100 50/50 100 50/50 100 54/46 100 48/52 100
MINIMUM UNIT CAPACITY (%)
Standard Compressor 50 50 50 50 50 50 27 33 23 33
Digital Compressor 17 17 17 17 17 17 13 16 11 16
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female

4
Table 2 — 38AP060-130 Unit Physical Data — English
LEGEND
*Typical operating charge with 25 ft of interconnecting piping. Operating
charge is approximate for maximum system capacity. Unit is factory supplied
with nitrogen holding charge. Refrigerant charge for dual circuit units is the
total for both circuits.
†Maximum vertical separation between evaporator coil and condensing unit if
condensing unit is below the evaporator.
38AP UNIT SIZE 060 065 070 080 090 100 115 130
NOMINAL CAPACITY, 50/60 Hz (tons) 50/60 54/65 58/70 67/80 75/90 83/100 96/115 108/130
CIRCUIT Dual Single Dual Dual Dual Dual Dual Dual
OPERATING WEIGHTS (lb)
Standard 2227 2561 2450 2610 2835 2844 3211 3353
With Low Sound Option 2299 2633 2522 2700 2943 2952 3319 3461
REFRIGERANT CHARGE (lb)
Total*
Circuit A/Circuit B
56
27/29
55
—/55
62
29/33
75
29/46
85
39/46
92
46/46
101
46/55
117
46/71
NITROGEN SHIPPING CHARGE 15 psig
COMPRESSOR
hp (Qty) (CKT A/CKT B)
13 (2)/15 (2) 20 (3) 15 (2)/11 (3) 15 (2)/15 (3) 13 (3)/15 (3) 15 (3)/15 (3) 15 (3)/20 (3) 15 (3)/25 (3)
CAPACITY STEPS
Standard 43556666
Digital Option 36 — 45 45 54 54 54 54
CRANKCASE HEATER (W) (each compressor) 90 (60 Hz), 75 (50 Hz)
CONDENSER FANS
Standard Propeller Type, Axial, Vertical Discharge
Quantity 44456678
RPM 1140 (60 Hz), 950 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 6200 6000 6000 7500 9000 9000 10,500 12,000
Total Watts (50 Hz) 3751 3630 3630 4538 5445 5445 6353 7260
Low Noise Plastic Type, Axial, Vertical Discharge
Quantity 44456678
RPM 850 (60 Hz), 700 (50 Hz)
Diameter (in.) 30
Total Watts (60 Hz) 5200 5000 5000 6250 7500 7500 8750 10,000
Total Watts (50 Hz) 3146 3025 3025 3781 4538 4538 5294 6050
CONDENSER COIL MCHX Type
No. Coils per Circuit 1 3 2 2 to 3 3 3 3 to 4 3 to 5
sq ft 67.8 99.6 99.6 124.5 149.4 149.4 174.3 199.2
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 210 F
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 15/8/ 15/825/815/8 / 21/815/8 / 21/821/8/ 21/821/8/ 21/821/8/ 25/821/8/ 25/8
Liquid Line 5/8/ 5/87/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 11/8
MAXIMUM HEIGHT FOR 3° F SUBCOOLING
(ft)†
75 75 75 75 75 75 75 75
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 46/54 100 47/53 40/60 46/54 50/50 44/56 38/62
MINIMUM UNIT CAPACITY (%)
Standard Compressor 23 33 24 20 15 17 14 13
Digital Compressor 11 — 11 9 7 8 7 6
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female

5
Table 3 — 38AP025-050 Unit Physical Data — SI
LEGEND
*Typical operating charge with 7.62 m of interconnecting piping. Operating
charge is approximate for maximum system capacity. Unit is factory supplied
with nitrogen holding charge. Refrigerant charge for dual circuit units is the
total for both circuits.
†Maximum vertical separation between evaporator coil and condensing unit if
condensing unit is below the evaporator.
38AP UNIT SIZES 025 027 030 040 050
NOMINAL CAPACITY 50/60 Hz (kW) 73/88 79/95 88/105 117/141 146/176
CIRCUIT Dual Single Dual Single Dual Single Dual Single Dual Single
OPERATING WEIGHTS (kg)
Standard 497 489 571 562 573 565 950 893 961 897
With Low Sound Option 513 505 587 579 590 582 974 917 986 921
REFRIGERANT CHARGE (kg)
Total*
Circuit A/Circuit B
12
6/6
11
11/—
12
6/6
12
12/—
14
7/7
13
13/—
18
10/8
18
18/—
22
10/12
22
22/—
NITROGEN SHIPPING CHARGE 1.03 bar
COMPRESSOR
kW (Qty) (CKT A/CKT B)
8.2 (1)/
8.2 (1) 8.2 (2) 9.7 (1)/ 9.7 (1) 9.7 (2) 11.2 (1)/ 11.2 (1) 11.2 (2) 7.5 (2)/ 6.3 (2) 9.7 (3) 8.2 (2)/ 9.7 (2) 11.2 (3)
CAPACITY STEPS
Standard 2 2 2 2 2 2 4 3 4 3
Digital Option 22 22 22 22 22 22 36 27 36 27
CRANKCASE HEATER (W) (each compressor) 90 (60 Hz), 75 (50 Hz)
CONDENSER FANS
Standard Propeller Type, Axial, Vertical Discharge
Quantity 2 2 2 2 2 2 3 3 3 3
r/s 19 (60 Hz), 16 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 3300 3300 3300 3300 3300 3300 4200 4200 4200 4200
Total Watts (50 Hz) 1997 1997 1997 1997 1997 1997 2541 2541 2541 2541
Low Noise Plastic Type, Axial, Vertical Discharge
Quantity 2 2 2 2 2 2 3 3 3 3
r/s 14 (60 Hz), 12 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 2750 2750 2750 2750 2750 2750 3500 3500 3500 3500
Total Watts (50 Hz) 1664 1664 1664 1664 1664 1664 2118 2118 2118 2118
CONDENSER COIL MCHX Type
No. Coils per Circuit 1 1 1 1 1 1 1 212
sq m 2.5 2.5 3.1 3.1 3.1 3.1 6.3 6.3 6.3 6.3
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 99 C
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 13/8/ 13/815/813/8/ 13/815/813/8/ 13/815/815/8/ 15/821/815/8/ 15/821/8
Liquid Line 5/8/ 5/85/85/8/ 5/85/85/8/ 5/87/85/8/ 5/87/85/8/ 5/87/8
MAXIMUM HEIGHT FOR 1.7° C
SUBCOOLING (m)†
23 23 23 23 23 23 23 23 23 23
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 50/50 100 50/50 100 50/50 100 54/46 100 48/52 100
MINIMUM UNIT CAPACITY (%)
Standard Compressor 50 50 50 50 50 50 27 33 23 33
Digital Compressor 17 17 17 17 17 17 13 16 11 16
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female

6
Table 4 — 38AP060-130 Unit Physical Data — SI
LEGEND
*Typical operating charge with 7.62 m of interconnecting piping. Operating
charge is approximate for maximum system capacity. Unit is factory supplied
with nitrogen holding charge. Refrigerant charge for dual circuit units is the
total for both circuits.
†Maximum vertical separation between evaporator coil and condensing unit if
condensing unit is below the evaporator.
38AP UNIT SIZES 060 065 070 080 090 100 115 130
NOMINAL CAPACITY 50/60 Hz (kW) 176/211 190/228 205/246 234/281 264/316 293/351 337/404 381/457
CIRCUIT Dual Single Dual Dual Dual Dual Dual Dual
OPERATING WEIGHTS (kg)
Standard 1010 1162 1111 1184 1286 1290 1456 1521
With Low Sound Option 1043 1194 1144 1225 1335 1339 1505 1570
REFRIGERANT CHARGE (kg)
Total*
Circuit A/Circuit B
25
12/13
25
—/25
28
13/15
34
13/21
39
18/21
42
21/21
46
21/25
53
21/32
NITROGEN SHIPPING CHARGE 1.03 bar
COMPRESSOR
kW (Qty) (CKT A/CKT B)
9.7 (2)/
11.2 (2)
15.0 (3) 11.2 (2)/
8.2 (3)
11.2 (2)/
11.2 (3)
9.7 (3)/
11.2 (3)
11.2 (3)/
11.2 (3)
11.2 (3)/
15.0 (3)
11.2 (3)/
18.6 (3)
CAPACITY STEPS
Standard 43556666
Digital Option 36 — 45 45 54 54 54 54
CRANKCASE HEATER (W) (each compressor) 90
CONDENSER FANS
Standard Propeller Type, Axial, Vertical Discharge
Quantity 44456678
r/s 19 (60 Hz), 16 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 6200 6000 6000 7500 9000 9000 10,500 12,.000
Total Watts (50 Hz) 3751 3630 3630 4538 5445 5445 6353 7260
Low Noise Plastic Type, Axial, Vertical Discharge
Quantity 44456678
r/s 14 (60 Hz), 12 (50 Hz)
Diameter (mm) 762
Total Watts (60 Hz) 5200 5000 5000 6250 7500 7500 8750 10,000
Total Watts (50 Hz) 3146 3025 3025 3781 4538 4538 5294 6050
CONDENSER COIL MCHX Type
No. Coils per Circuit 1 3 2 2 to 3 3 3 3 to 4 3 to 5
sq m 6.3 6.9 9.3 11.6 13.9 13.9 16.2 18.5
TEMPERATURE RELIEF Fusible Plug on Liquid Lines of Each Circuit - 99 C
CONNECTIONS (in.) ODF (CKT A/CKT B)
Suction Line 15/8/ 15/825/815/8 / 21/815/8 / 21/821/8/ 21/821/8/ 21/821/8/ 25/821/8/ 25/8
Liquid Line 5/8/ 5/87/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 7/87/8/ 11/8
MAXIMUM HEIGHT FOR 1.7° C
SUBCOOLING (m)†
23 23 23 23 23 23 23 23
CAPACITY PER CIRCUIT (%) (CKT A/CKT B) 46/54 100 47/53 40/60 46/54 50/50 44/56 38/62
MINIMUM UNIT CAPACITY (%)
Standard Compressor 23 33 24 20 15 17 14 13
Digital Compressor 11 — 11 9 7 8 7 6
MCHX — Microchannel Heat Exchanger
ODF — Outside Diameter, Female

7
38APS Unit (lb)
38APD Unit (lb)
38APS Unit (kg)
38APD Unit (kg)
38APS
UNIT
SIZE
TOTAL
WEIGHT
OPERATIONAL CORNER WEIGHT
A B C D
025 1089 356 253 200 281
027 1255 396 291 240 327
030 1261 399 293 241 328
040 1998 619 616 380 382
050 2007 623 620 381 383
065 2594 885 863 418 429
38APD
UNIT
SIZE
TOTAL
WEIGHT
OPERATIONAL CORNER WEIGHT
A B C D E F
025 1107 360 258 204 285 — —
027 1273 401 296 245 331 — —
030 1279 404 297 245 333 — —
040 2124 672 671 390 390 — —
050 2150 683 684 392 391 — —
060 2257 706 705 422 423 — —
070 2494 723 620 532 620 — —
080 2665 791 679 552 643 — —
090 2901 759 750 692 700 — —
100 2910 759 750 696 705 — —
115 3288 578 582 518 514 550 546
130 3441 604 613 542 535 578 569
38APS
UNIT
SIZE
TOTAL
WEIGHT
OPERATIONAL CORNER WEIGHT
A B C D
025 494 161 115 91 127
027 569 180 132 109 148
030 572 181 133 109 149
040 906 281 280 173 173
050 910 282 281 173 174
065 1177 401 391 190 195
38APD
UNIT
SIZE
TOTAL
WEIGHT
OPERATIONAL CORNER WEIGHT
A B C D E F
025 502 163 117 93 129 — —
027 577 182 134 111 150 — —
030 580 183 135 111 151 — —
040 963 305 305 177 177 — —
050 975 310 310 178 178 — —
060 1024 320 320 192 192 — —
070 1131 328 281 241 281 — —
080 1209 359 308 250 292 — —
090 1316 344 340 314 318 — —
100 1320 344 340 316 320 — —
115 1491 262 264 235 233 250 248
130 1561 274 278 246 242 262 258
A
B C
D
COMP COMP
CONTROL
BOX
A
B C
D
COMP COMP
CONTROL BOX
COMP COMP
A
B C
D
COMP COMP
CONTROL BOX
COMP
COMP COMP COMP
F
E
TOP VIEW, SIZES 070 TO 130
TOP VIEW,
SIZES 025 TO 030 TOP VIEW, SIZES 040 TO 065
Fig. 2 — Corner Weights
a38-7232

8
2633 1194 12402733
Fig. 3 — Rigging Labels
Fig. 4 — Perimeter Support Channel
SIZES 025 TO 060 SIZES 065 TO 130
a38-7115
LEGEND
ASTM — American Society for
Testing and Materials
4 x 24 in.
ASTM “C”
CHANNEL
a38-7130
a38-7202

9
P
4.62
117.4[ ]
1.50 38.1[ ] 1.50 38.1[ ]
SEE NOTE #4 TYP. 1.00 25.4[ ]
SEE NOTE #4
TYP.
1.00 25.4[ ]
11.81 300.0[ ]
8.52
216.4[ ]
9.52
241.8[ ]
40.34 1024.5[ ]
Y
X
H
SEE NOTE #6
15.31 388.9[ ]
36 [914] MIN.
42 [1067]
MIN.
36 [914] MIN.
48 [1219]
MIN.
FIELD POWER ENTRY SEE NOTE #3
7/8 22.4[ ]
RADIUS 20 [508]
CONTROL BOX
HINGED ACCESS
21.06 534.9[ ]
24.56 623.8[ ]
88.24 2241.3[ ] TOP VIEW
CG
SERVICE
CLEARANCE
BORDER
(NOT TO SCALE)
COIL SIDE SEE NOTE #5
PANEL SIDE
SEE NOTE #5
AIR FLOW
COIL AREA
RIGHT SIDE
VIEW
COIL SIDE SEE NOTE #5
SEE NOTE'S #1,2
FRONT VIEW
AIR FLOW
FIELD CONTROL WIRING CONNECTIONS
LOW SOUND FAN STACK (PICTORIALLY ONLY)
CONTROL BOX
HINGED ACCESS
CIRCUIT A
LIQUID CONNECTION
CIRCUIT A
SUCTION CONNECTION
CIRCUIT B
SUCTION CONNECTION
CIRCUIT B
LIQUID CONNECTION
SERVICE
ACCESS
COMPRESSOR
ACCESS
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
POWER ENTRY,
in. (mm)
SERVICE VALVE
CONNECTIONS, in. (mm)
X Y H P Suction Liquid
Standard
38APS025 1077 (489) 17.8 (452) 36.9 (937) 61.0 (1549) 24.9 (632) 15/8(41) 5/8(16)
38APD025 1095 (497) 17.8 (452) 37.0 (940) 13/8(35) 5/8(16)
38APS027 1240 (563) 18.2 (462) 37.6 (955)
73.1 (1857) 36.9 (937)
15/8(41) 5/8(16)
38APD027 1258 (571) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
38APS030 1246 (565) 18.2 (462) 37.5 (953) 15/8(41) 7/8(22)
38APD030 1264 (573) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
Low Sound
38APS025 1113 (505) 17.8 (452) 36.9 (937) 66.5 (1689) 24.9 (632) 15/8(41) 5/8(16)
38APD025 1131 (513) 17.8 (452) 37.0 (940) 13/8(35) 5/8(16)
38APS027 1276 (579) 18.2 (462) 37.6 (955)
78.6 (1996) 36.9 (937)
15/8(41) 5/8(16)
38APD027 1294 (587) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
38APS030 1282 (582) 18.2 (462) 37.5 (953) 15/8(41) 7/8(22)
38APD030 1300 (590) 18.2 (462) 37.6 (955) 13/8(35) 5/8(16)
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief. 3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring. Actual hole size
required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil End - 72 in. (1829) from solid surface. Panel Side - 48 in. (1219) per NEC (National Electrical Code, U.S.A. Standard).
6. Unit height dimension for standard and low sound unit with stack fan option. 7. Installation in a pit is not recommended. 8. Unit can be handled using the fork truck lift pockets.
9. Dimensions shown in inches (mm).
a38-7101
Fig. 5 — 38AP Unit Dimensions, Sizes 025-030

10
Y
X
SEE NOTE #4 TYP. 1.00 25.4[ ]
38.07 967.0[ ]
41.13 1044.7[ ]
SEE NOTE #4
TYP.
1.00 25.4[ ]
1.50 38.1[ ]
1.50 38.1[ ]
46.88 1190.8[ ]
49.94 1268.5[ ]
RADIUS 20 [508]
CONTROL BOX
HINGED ACCESS
FIELD POWER ENTRY SEE NOTE #3
7/8 22.4[ ]
8.84
224.5[ ]
9.65
245.1[ ]
27.98
710.7[ ]
4.63
117.6[ ]
H
SEE NOTE #6
42 [1067]
MIN.
42 [1067] MIN.
48 [1219] MIN.
48 [1219]
MIN.
92.13 2340.0[ ]
FRONT VIEW (DUAL CIRCUIT) RIGHT SIDE
VIEW
CONTROL BOX
HINGED ACCESS
CIRCUIT A
COMPRESSOR
ACCESS
CIRCUIT B
COMPRESSOR
ACCESS
COIL AREA
COIL AREA
AIR FLOW
AIR FLOW
FRONT VIEW (SINGLE CIRCUIT)
COMPRESSOR
ACCESS
CG
TOP VIEW
SERVICE CLEARANCE BORDER (NOT TO SCALE)
COIL SIDE SEE NOTE #5
PANEL SIDE SEE NOTE #5
COIL SIDE SEE NOTE #5
PANEL SIDE
SEE NOTE #5
NOTE: 3 OR 4 FANS
AIR FLOW LOW SOUND FAN STACK
(PICTORIALLY ONLY)
SEE NOTE'S #1,2
LIQUID CONNECTION
SUCTION CONNECTION
SUCTION CONNECTION
LIQUID CONNECTION
REAR VIEW
SERVICE
ACCESS
FIELD
CONTROL
WIRING
CONNECTIONS
88.24
[2241.3]
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE
CONNECTIONS, in. (mm)
X Y H Suction Liquid
Standard
38APS040 1968 (893) 35.0 (869) 44.0 (1118)
73.0 (1854)
21/8(54) 7/8(22)
38APD040 2094 (950) 33.7 (856) 44.1 (1120) 15/8(41) 5/8(16)
38APS050 1977 (897) 34.9 (886) 44.0 (1118) 21/8(54) 7/8(22)
38APD050 2120 (961) 33.4 (848) 44.1 (1120) 15/8(41) 5/8(16) 38APD060 2227 (1010) 34.4 (874) 44.1 (1120) 15/8(41) 5/8(16)
Low Sound
38APS040 2022 (917) 35.0 (869) 44.0 (1118)
78.5 (1994)
21/8(54) 7/8(22)
38APD040 2148 (974) 33.7 (856) 44.1 (1120) 15/8(41) 5/8(16)
38APS050 2031 (921) 34.9 (886) 44.0 (1118) 21/8(54) 7/8(22)
38APD050 2174 (986) 33.4 (848) 44.1 (1120) 15/8(41) 5/8(16) 38APD060 2299 (1043) 34.4 (874) 44.1 (1120) 15/8(41) 5/8(16)
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief. 3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring.
Actual hole size required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil End - 72 in. (1829) from solid surface. Panel Side - 48 in. (1219) per NEC (National Electrical Code, U.S.A. Standard).
6. Unit height dimension for standard and low sound unit with stack fan option. 7. Installation in a pit is not recommended. 8. Unit can be handled using the fork truck lift pockets. 9. Dimensions shown in inches (mm).
10. Sizes 040 and 050 units have 3 condenser fans. Size 060 units have 4 con-
denser fans.
a38-7224
Fig. 6 — 38AP Unit Dimensions, Sizes 040-060

11
Fig. 7 — 38AP unit Dimensions, Sizes 065 and 070
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief. 3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring.
Actual hole size required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil, Panel and Rear Side - 72 in. (1829) from solid surface.
6. Unit height (dimension H) for the low sound fan option includes the fan stack. 7. Installation in a pit is not recommended. 8. Unit can be handled using crane. Refer to service installation instructions. 9. Dimensions shown in inches (mm).
10. Weight does not include unit refrigerant charge.
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE CONNECTIONS,
in. (mm)
SERVICE VALVE LOCATIONS
CIRCUIT B ONLY,
in. (mm)
Suction Liquid Suction
X Y H Circuit A Circuit B S1 S2
Standard 38APS065 2561 (1162) 36.2 (920) 43.6 (1107) 73.0 (1854) — 25/8(67) 7/8(22) 9.26 (235.2) 20.81 (528.61)
38APD070 2450 (1111) 50.9 (1293) 40.6 (1031) 73.0 (1854) 21/8(54) 15/8(41) 7/8(22) 12.85 (326.4) 14.04 (356.6)
Low Sound 38APS065 2633 (1194) 36.2 (920) 43.6 (1107) 78.5 (1994) — 25/8(67) 7/8(22) 9.26 (235.2) 20.81 (528.61)
38APD070 2522 (1144) 50.9 (1293) 40.6 (1031) 78.5 (1994) 21/8(54) 15/8(41) 7/8(22) 12.85 (326.4) 14.04 (356.6)

12
a38-7104
Fig. 8 — 38AP Unit Dimensions, Sizes 080-100
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE CONNECTIONS,
in. (mm)
Suction Liquid
X Y H Circuit A Circuit B
Standard
38APD080 2610 (1184) 67.6 (1716) 40.2 (1020)
73.0 (1854)
21/8(54) 15/8(41) 7/8(22)
38APD090 2835 (1286) 72.4 (1839) 43.3 (1099) 21/8(54) 7/8(22) 38APD100 2844 (1290) 72.6 (1844) 43.3 (1099) 21/8(54) 7/8(22)
Low Sound
38APD080 2700 (1225) 67.6 (1716) 40.2 (1020)
78.5 (1994)
21/8(54) 15/8(41) 7/8(22)
38APD090 2943 (1335) 72.4 (1839) 43.3 (1099) 21/8(54) 7/8(22) 38APD100 2952 (1339) 72.6 (1844) 43.3 (1099) 21/8(54) 7/8(22)
NOTES:
1. Be sure to use a wet rag to remove all valve cores before brazing field piping. 2. Do not cap or otherwise obstruct the liquid line temperature relief.
3. A 7/8in. (22.4 mm) diameter hole is provided for locating field power wiring.
Actual hole size required depends on field wire sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil, Panel and Rear Side - 72 in. (1829) from solid surface.
6. Unit height (dimension H) for the low sound fan option includes the fan stack. 7. Installation in a pit is not recommended. 8. Unit can be handled using crane. Refer to service installation instructions. 9. Dimensions shown in inches (mm).
10. Size 080 units have 5 condenser fans. Sizes 090 and 100 units have 6 con-
denser fans.
11. Weight does not include unit refrigerant charge.

13
20.81 528.4[ ]
L1
9.26
235.1[ ]
L2 12.25
311.2[ ]
12.85
326.4[ ]
14.02 356.2[ ]
28.44 722.3[ ]
1.50 38.1[ ]
1.50 38.1[ ]
SEE NOTE #4
TYP.
1.50 38.1[ ]
SEE NOTE #4 TYP. 1.50 38.1[ ]
191.34 4860.0[ ]
H
4.00 101.6[ ]
34.99
888.7[ ]
88.25 2241.4[ ]
FIELD POWER ENTRY SEE NOTE #3
7/8 22.4[ ]
RADIUS 24 [610]
CONTROL BOX HINGED DOOR
15.61
396.4[ ]
4.78
121.3[ ]
X
Y
CONTROL BOX
HINGED ACCESS
FRONT VIEW
TOP VIEW
LOW SOUND FAN STACK (PICTORIALLY ONLY)
AIR FLOW
AIR FLOW
AIR FLOW
AIR FLOW
CG
RIGHT SIDE
VIEW
CIRCUIT B LIQUID CONNECTION
CIRCUIT B SUCTION CONNECTION
CIRCUIT A
LIQUID
CONNECTION
CIRCUIT A
SUCTION
CONNECTION
SERVICE CLEARANCE BORDER (NOT TO SCALE)
REAR SIDE SEE NOTE #5
PANEL SIDE
SEE NOTE #5
UNIT STANDARD
WEIGHT, lb (kg)
CENTER OF GRAVITY,
in. (mm)
HEIGHT,
in. (mm)
SERVICE VALVE CONNECTIONS,
in. (mm)
SERVICE VALVE LOCATIONS
CIRCUIT B ONLY,
in. (mm)
Suction Liquid Liquid
X Y H Circuit A Circuit B L1 L2
Standard 38APD115 3211 (1457) 71.1 (1806) 44.4 (1128) 73.0 (1854) 21/8(54) 25/8(67) 7/8(22) 28.48 (723) 12.25 (311)
38APD130 3353 (1521) 70.9 (1801) 44.6 (1133) 21/8(54) 25/8(67) 7/8(22) 28.36 (720) 11.97 (304)
Low Sound 38APD115 3319 (1506) 71.1 (1806) 44.4 (1128) 78.5 (1994) 21/8(54) 25/8(67) 7/8(22) 28.48 (723) 12.25 (311)
38APD130 3461 (1570) 70.9 (1801) 44.6 (1133) 21/8(54) 25/8(67) 7/8(22) 28.36 (720) 11.97 (304)
Fig. 9 — 38AP Unit Dimensions, Sizes 115, 130
NOTES:
1. Be sure to use a wet rag to remove all valve cores before braz-
ing field piping.
2. Do not cap or otherwise obstruct the liquid line temperature
relief.
3. A 7/8in. (22.4 mm) diameter hole is provided for locating field
power wiring. Actual hole size required depends on field wire
sizing.
4. A 0.437 in. (11.1 mm) diameter hole is used for mounting unit. 5. Unit must have clearances as follows:
Top - Do not restrict. Coil, Panel and Rear Side - 72 in. (1829) from solid surface.
6. Size 115 units have 7 condenser fans. Size 130 units have 8
condenser fans.
7. Unit height (dimension H) for the low sound fan option includes
the fan stack.
8. Installation in a pit is not recommended. 9. Unit can be handled using crane. Refer to service installation
instructions.
10. Dimensions shown in inches (mm). 11. Weight does not include unit refrigerant charge.

14
Outdoor Fan Layout
To
p
View To
p
View To
p
View To
p
View
Sizes 025-030 Sizes 040-050 Sizes 060-070 Size 080
To
p
View To
p
View To
p
View
Sizes 090-100 Size 115 Size 130
Compressor Layout Dual Circuit
To
p
View To
p
View To
p
View
Sizes 025-030 Sizes 040-060 Sizes 070-080
To
p
View
Sizes 090-130
Compressor Layout Single Circuit
To
p
View To
p
View To
p
View
Sizes 025-030 Sizes 040-050 Size 065
CONTROL BOX
CONTROL BOX
CONTROL BOX CONTROL BOX
CONTROL BOX
OFM1
OFM2 OFM2
OFM3
OFM3
OFM4
OFM4
OFM5
OFM6
OFM2
OFM2
OFM2
OFM3
OFM3
OFM5
OFM6
OFM1
OFM1 OFM1
OFM1
CONTROL BOX
CONTROL BOX
CONTROL BOX
CONTROL BOX
A1
B1
B1
B2
A1
A2 B1
B2 A2
A1
B3
B1
B2
B3
A3
A2
A1
CONTROL BOX
CONTROL BOX
A1
A2
A1
A2
A3
CONTROL BOX
OFM4
OFM5
OFM6
OFM2
OFM3
OFM1 OFM7
OFM8
CONTROL BOX
OFM4
OFM5
OFM2
OFM3
OFM1 OFM7
OFM8
CONTROL BOX
B1
B2
B3
Fig. 10 — Outdoor Fan and Compressor Layout
a38-7213
LEGEND
A — Circuit 1 Compressor
B — Circuit 2 Compressor
OFM — Outdoor Fan

15
40RU
3FTMAXFORSHORTRISER
a38-7237
LEGEND
*Field supplied.
†If double suction riser is required for piping
system, size short riser (3 ft maximum)
according to Fig. 13.
**Field supplied. See Table 5 for refrigerant spe-
cialties part numbers.
LLSV — Liquid Line Solenoid Valve
NEC — National Electrical Code
TXV — Thermostatic Expansion Valve
Piping
Double Riser Piping (if required)
NOTES:
1. All piping must follow standard refrigerant piping techniques. Refer to Carrier System
Design Manual for details.
2. All wiring must comply with the applicable local and national codes.
3. Wiring and piping shown are general points-of-connection guides only and are not
intended for, or to include all details for, a specific installation.
4. Install field-supplied disconnect switch in accordance with all local and national electrical
codes.
5. Liquid line solenoid valves (solenoid drop control) are not required but are recommended
to prevent refrigerant migration to the compressor.
6. Factory-supplied accumulator not shown.
7. Dual-circuit piping shown. Single-circuit piping is similar but would only have one suction
line and one liquid line.
8. A field-supplied (min. 5% up to 15%) bleed port TXV is required for every application.
9. Sight glass, LLSV, and filter drier are field supplied.
10. Long line length check valves are required for liquid line installation on all linear line
length applications of more than 100 ft (30.5 m). For any 025-030 size dual-circuit unit
application where evaporator is located higher than the condensing unit, check valves
are required for linear line length above 55 ft (16.8 m).
11. Do not use soft solder.
Fig. 11 — 38AP Unit Rooftop Installation

16
a38-7099_gs
NOTES:
1. All piping must follow standard refrigerant piping techniques. Refer to Carrier System
Design Manual for details.
2. All wiring must comply with the applicable local and national codes.
3. Wiring and piping shown are general points-of-connection guides only and are not
intended for, or to include all details for, a specific installation.
4. Install field-supplied disconnect switch in accordance with all local and national electri-
cal codes.
5. Liquid line solenoid valves (solenoid drop control) are not required but are recom-
mended to prevent refrigerant migration to the compressor.
6. Factory-supplied accumulator not shown.
7. Dual-circuit piping shown. Single-circuit piping is similar but would only have one suc-
tion line and one liquid line.
8. A field-supplied (min. 5% up to 15%) bleed port TXV is required for every application.
9. Sight glass, LLSV, and filter drier are field supplied.
10. Long line length check valves are required for liquid line installation on all linear line
length applications of more than 100 ft (30.5 m). For any 025-030 size dual-circuit unit
application where evaporator is located higher than the condensing unit, check valves
are required for linear line length above 55 ft (16.8 m).
11. Do not use soft solder.
LEGEND
*Field supplied.
†Field supplied. See Table 5 for refrigerant spe-
cialties part numbers.
LLSV — Liquid Line Solenoid Valve
NEC — National Electrical Code
TXV — Thermostatic Expansion Valve
Piping
Fig. 12 — 38AP Unit Ground Level Installation

17
Table 5 — Refrigerant Specialties Part Numbers
LEGEND
*Bushing required to fit 5/8in. line.
NOTE:
1. Filter driers have been sized based upon 1 to 2 psig pressure drop clean
in accordance with AHRI Standard 710.
2. All pipe sizes are OD inches. Equivalent sizes in millimeters follow:
3. Thermostatic expansion valve (TXV) is provided with all 40RU fan coil
units. Contact your Carrier representative for appropriate TXV size.
38APS UNIT SIZE
CIRCUIT A
Tons LL Size (in.) LLSV LLSV Coil
24-v, 50/60 Hz Sight Glass Filter Drier Filter Drier Core
025 24.0 5/8EF680028 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008
027 26.7 5/8EF680028 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008
030 31.1
5/8EF680028 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008
040 39.8
5/8EF680028 EF680032 KM680005 KH680003*KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008
050 48.1 7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008
065 59.6
7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008
13/8EF680038 EF680032 KM680007*KH680012 KH680008
38APD
UNIT
SIZE
CIRCUIT A CIRCUIT B
Tons LL Size
(in.) LLSV LLSV Coil 24-v, 50/60 Hz
Sight
Glass
Filter
Drier
Filter
Drier Core Tons LL Size (in.) LLSV LLSV Coil 24-v, 50/60 Hz
Sight
Glass
Filter
Drier
Filter
Drier Core
025 12.0 1/2EF680031 EF680032 KM680004 KH680001 — 12.0 1/2EF680031 EF680032 KM680004 KH680001 —
5/8EF680028 EF680032 KM680005 KH680002 KH680008 5/8EF680028 EF680032 KM680005 KH680002 KH680008
027 13.3 1/2EF680031 EF680032 KM680004 KH680001 — 13.3 1/2EF680031 EF680032 KM680004 KH680001 —
5/8EF680028 EF680032 KM680005 KH680002 KH680008 5/8EF680028 EF680032 KM680005 KH680002 KH680008
030 15.6
1/2EF680031 EF680032 KM680004 KH680001 —
15.6
1/2EF680031 EF680032 KM680004 KH680001 —
5/8EF680028 EF680032 KM680005 KH680002 KH680008 5/8EF680028 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008 7/8EF680029 EF680032 KM680006 KH680003 KH680008
040 21.0
— — — — — —
18.2
1/2EF680028 EF680032 KM680004 KH680001 —
5/8EF680028 EF680032 KM680005 KH680002 KH680008 5/8EF680029 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008 7/8EF680029 EF680032 KM680006 KH680003 KH680008
050 23.8 5/8EF680028 EF680032 KM680005 KH680002 KH680008 26.3 5/8EF680028 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008 7/8EF680029 EF680032 KM680006 KH680003 KH680008
060 26.8
5/8EF680028 EF680032 KM680005 KH680002 KH680008
31.5
5/8EF680028 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008 7/8EF680029 EF680032 KM680006 KH680003 KH680008
— — — — — — 11/8EF680030 EF680032 KM680007 KH680004 KH680008
070 31.8
5/8EF680028 EF680032 KM680005 KH680002 KH680008
35.5
5/8EF680028 EF680032 KM680005 KH680002 KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008 7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008 11/8EF680030 EF680032 KM680007 KH680004 KH680008
080 31.3
5/8EF680028 EF680032 KM680005 KH680002 KH680008 46.7 5/8EF680028 EF680032 KM680005 KH680003*KH680008
7/8EF680029 EF680032 KM680006 KH680003 KH680008 7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008 11/8EF680030 EF680032 KM680007 KH680004 KH680008
090 40.3
5/8EF680028 EF680032 KM680005 KH680003*KH680008 47.1 — — — — — —
7/8EF680029 EF680032 KM680006 KH680003 KH680008 7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008 11/8EF680030 EF680032 KM680007 KH680004 KH680008
100 48.0 7/8EF680029 EF680032 KM680006 KH680003 KH680008 48.0 7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008 11/8EF680030 EF680032 KM680007 KH680004 KH680008
115 48.0
7/8EF680029 EF680032 KM680006 KH680003 KH680008 62.4 7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008 11/8EF680030 EF680032 KM680007 KH680004 KH680008
— — — — — — 13/8EF680038 EF680032 KM680007*KH680012 KH680008
130 48.0
7/8EF680029 EF680032 KM680006 KH680003 KH680008 77.1 7/8EF680029 EF680032 KM680006 KH680003 KH680008
11/8EF680030 EF680032 KM680007 KH680004 KH680008 11/8EF680030 EF680032 KM680007 KH680004 KH680008
— — — — — — 13/8EF680038 EF680032 KM680007*KH680012 KH680008
LL — Liquid Line
LLSV — Liquid Line Solenoid Valve
in. mm
1/212.7
5/815.9
7/822.2
11/828.6

18
Step 3 — Make Refrigerant Piping
Connections
The units have large suction lines to minimize friction loss-
es. The units also have the ability to operate at low capacity.
Because of these capabilities, use special care with suction pip-
ing and suction risers to ensure proper compressor oil return
under all operating conditions. If the evaporator is above the
condensing unit, the maximum allowable vertical separation
between the condensing unit and the evaporator is 75 ft
(22.9 m) for all units. Size suction lines in accordance with
Table 6 and Fig. 13.
SIZE REFRIGERANT LINES  Consider the length of pip-
ing required between the condensing unit and indoor unit
(evaporator), the amount of liquid lift, and compressor oil re-
turn. Suction and liquid lines should be sized in accordance
with Table 6. Double suction risers may be required if con-
densing unit is located above the evaporator to assure proper
oil return at minimum load operating conditions. See Table 6
and Fig. 13. Note the indoor unit installation instructions for
additional information.
CAUTION
Do NOT bury refrigerant piping underground. Failure to
comply could result in equipment damage.
CAUTION
The field-supplied liquid line solenoid valve must be
installed at the evaporator to avoid possible compressor
damage during unit operation if the maximum allowable
evaporator size is exceeded per Tables 7A and 7B. See
Fig. 14 (for 38APD025-130 dual-circuit units), or Fig. 15
(for 38APS025-065 single-circuit units).
Fig. 13 — Double Suction Riser Construction
LEGEND
NOTES:
1. Short riser, pipe D, is used when routing suction line to
condensing unit connection. See table at right.
2. See Table 6 for values of A, B, and C.
A — Pipe A, Suction Riser, without Trap
B — Pipe B, Suction Riser with Trap
C — Suction Line to Condensing Unit
D — Pipe D, Suction Riser Short Lift
RED. — Reducer
STR — Street
38AP
UNIT
SIZE
D PIPE DIAMETER
Dual Circuit Single Circuit
Circuit A Circuit B
in. mm in. mm in. mm
025 11/829 11/829 13/835
027 11/829 11/829 13/835
030 11/829 11/829 13/835
040 13/835 11/829 15/841
050 13/835 13/835 15/841
060 13/835 15/841 — —
065 ———— 21/854
070 15/841 15/841 — —
080 15/841 15/841 — —
090 15/841 15/841 — —
100 15/841 15/841 — —
115 15/841 25/867 — —
130 15/841 25/867 — —
a38-7132
