Carrier 30MP Installation manual

3
30 0M MP P M Mu ul lt ti i- -c ch hi il ll le er r
I
In ns st ta al ll la at ti io on n a an nd d S St ta ar rt t- -u up p G Gu ui id de e
CARRIER CORPORATION ©2018
A member of the United Technologies Corporation family · Stock symbol UTX · Catalog No. 11-808-566-01 · 2/28/2018

Verify that you have the most current version of this document from
www.hvacpartners.com
or your local Carrier
office.
Important changes are listed in
Document revision history
at the end of this document.
CARRIER CORPORATION ©2018. All rights reserved throughout the world. i-Vu is a registered trademark of Carrier
Corporation. All other trademarks are the property of their respective owners.

Contents
30MP Multi-chiller overview and specifications........................................................................................................ 1
What is the 30MP Multi-chiller application? ....................................................................................................1
Controller specifications ......................................................................................................................................2
Safety considerations...........................................................................................................................................3
Installing the controller ............................................................................................................................................... 4
Mounting the controller .......................................................................................................................................4
Wiring the controller for power...........................................................................................................................5
To wire for power................................................................................................................................... 5
Addressing the controller ....................................................................................................................................5
Wiring for communications.................................................................................................................................6
Wiring specifications for BACnet MS/TP and ARC156........................................................................ 6
To wire the controller to the BACnet network ...................................................................................... 6
Wiring inputs and outputs ...................................................................................................................................7
Inputs and outputs table ...................................................................................................................... 7
Input wiring specifications .................................................................................................................... 8
Inputs ..................................................................................................................................................... 8
Binary outputs ....................................................................................................................................... 9
Analog outputs ...................................................................................................................................... 9
To wire inputs and outputs .................................................................................................................10
Wiring sensors to the controller ...................................................................................................................... 12
Wiring specifications ...........................................................................................................................12
To wire the leaving chilled water header temperature sensor to the controller..............................12
To wire an outdoor air temperature sensor to the controller ...........................................................13
To wire the Relative Humidity sensor to the controller .....................................................................14
Wiring an Equipment Touch to the controller ............................................................................................... 15
Wiring equipment to outputs........................................................................................................................... 16
Wiring specifications ...........................................................................................................................16
Wiring diagram legend ........................................................................................................................16
30MP Multi-chiller wiring diagram .....................................................................................................17
Start-up.......................................................................................................................................................................18
Configure the chiller system ............................................................................................................................ 18
Sequence of Operation .............................................................................................................................................22
Scheduling .......................................................................................................................................................... 22
Demand limiting ................................................................................................................................................ 23
OA reset............................................................................................................................................................... 24
RH cooling reset................................................................................................................................................. 24
Power failure recovery ...................................................................................................................................... 24
Cool enable......................................................................................................................................................... 24
Rotation method................................................................................................................................................ 25
Analog setpoint input........................................................................................................................................ 25
Condenser water temp control ........................................................................................................................ 25
30MP UPC Open Linkage ................................................................................................................................. 26
Troubleshooting .........................................................................................................................................................27
LED's .................................................................................................................................................................... 27
Serial number..................................................................................................................................................... 28
To replace the controller's battery .................................................................................................................. 28
Compliance ................................................................................................................................................................29
FCC Compliance................................................................................................................................................. 29
CE Compliance ................................................................................................................................................... 29
BACnet Compliance........................................................................................................................................... 29
Appendix A: 30MP Multi-chiller wire list ..................................................................................................................30

Contents
Appendix B: Device Address Binding ......................................................................................................................31
Appendix C: 30MP Multi-chiller Points/Properties ................................................................................................32
Status................................................................................................................................................................... 32
Unit Configuration.............................................................................................................................................. 33
Setpoints ............................................................................................................................................................. 35
Alarm Configuration .......................................................................................................................................... 36
Service Configuration........................................................................................................................................ 37
Maintenance....................................................................................................................................................... 40
Alarms ................................................................................................................................................................. 43
Linkage................................................................................................................................................................ 44
I/O Points............................................................................................................................................................ 45
Appendix D: Touchscreen settings ..........................................................................................................................47
30MP Multi-chiller System Touch navigation screens................................................................................. 47
30MP Multi-chiller's Equipment Touch navigation screens ........................................................................ 50
30MP Multi-chiller Start-up Wizard................................................................................................................. 54
30MP Multi-chiller Chiller Linkage Source Address..................................................................................... 55
UPC Open's Equipment Touch navigation screens....................................................................................... 56
Document revision history ........................................................................................................................................59

30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
1
What is the 30MP Multi-chiller application?
The 30MP Multi-chiller is a special purpose application used to control from two to eight 30MP chillers as a single
large chiller, which is operated from the AppController. Each 30MP chiller must be equipped with the 30MP UPC
Open interface. The 30MP Multi-chiller application operates each individual chiller in the most efficient manner by
staging the machines independently. As a system, it reduces the Kw/ton energy consumption at part load
operating conditions. The 30MP Multi-chiller application can run in 100% stand-alone mode or communicate to an
i-Vu® Control System.
30MP Multi-chiller overview and specifications

30MP Multi-chiller overview and specifications
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
2
Controller specifications
Power 24 Vac ±10%, 50–60 Hz
20 VA power consumption
26 Vdc (25 V min, 30 V max)
Single Class 2 source only, 100 VA or less
BACnet Port For communication with the controller network using BACnet ARC156 (156 kbps)
or BACnet MS/TP (9600 bps – 76.8 kbps)
Rnet port Supports 1 Equipment Touch per Rnet
NOTE
Equipment Touch requires 24 Vac and cannot be powered by Rnet's 12
Vdc. For more details, see the Equipment Touch Installation and Setup Guide.
Local Access port For system start-up and troubleshooting using Field Assistant or an Equipment
Touch device
Inputs 6 inputs configurable for thermistor or dry contact. 1 and 2 are also configurable
for 0–5 Vdc sensors.
NOTE
7 and 8 are unused.
Input resolution 10 bit A/D
Analog outputs 3 analog outputs, 0–10 Vdc (5 mA max)
Binary outputs 5 binary outputs, dry relay contacts rated at 1 A max. @ 24 Vac/Vdc. Configured
normally open
Output resolution 8 bit A/D, using filtered PWM
Real time clock Battery-backed real time clock keeps track of time in the event of a power failure
Battery 10-year Lithium CR2032 battery retains the following data for a maximum of
10,000 hours during power outages: control programs, editable properties,
schedules, and trends.
Protection Incoming power and network connections are protected by non-replaceable
internal solid-state polyswitches that reset themselves when the condition that
causes a fault returns to normal.
The power, network, input, and output connections are also protected against
transient excess voltage/surge events lasting no more than 10 msec.
Status indicators LEDs indicate status of communications, running, errors, and power.
Environmental operating
range
0 to 130°F (-18 to 54°C), 0 to 90% relative humidity, non-condensing
Storage temperature range -24 to 140°F (-30 to 60°C), 0 to 90% relative humidity, non-condensing
Physical Rugged GE C2950HF Cycoloy plastic

30MP Multi-chiller overview and specifications
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
3
Overall dimensions A:
B:
5-5/8 in. (14.3 cm)
5-1/8 in. (13 cm)
Mounting dimensions C:
D:
E:
5-1/4 in. (13.3 cm)
2-9/16 in. (6.5 cm)
3/16 in. (.5 cm)
Panel depth 2 in. (5.1 cm)
Weight 0.44 lbs. (0.20 kg)
BACnet support Conforms to the BACnet Advanced Application Controller (B-AAC) Standard Device
Profile as defined in ANSI/ASHRAE Standard 135-2012 (BACnet) Annex L,
Protocol Revision 9
Listed by UL-916 (PAZX), cUL-916 (PAZX7), FCC Part 15-Subpart B-Class A, CE
Safety considerations
WARNING
Disconnect electrical power to the controller before wiring it. Failure to follow this warning could
cause electrical shock, personal injury, or damage to the controller.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
4
1 Mount the controller (page 4).
2 Wire the controller for power (page 5).
3 Set the controller's address (page 5).
4 Wire the controller to the BACnet MS/TP or BACnet ARC156 network (page 6).
5 Wire inputs and outputs (page 7).
6 Wire sensors to the controller (page 12).
7 Wire equipment to outputs (page 16).
Mounting the controller
WARNING
When you handle the controller:
•Do not contaminate the printed circuit board with fingerprints, moisture, or any foreign material.
•Do not touch components or leads.
•Handle the board by its edges.
•Isolate from high voltage or electrostatic discharge.
•Ensure that you are properly grounded.
Screw the controller into an enclosed panel using the mounting slots on the coverplate. Leave about 2 in. (5 cm)
on each side of the controller for wiring. Mounting hole dimensions 5 9/16" (14.1 cm) between mounting slot
center lines.
Installing the controller

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
5
Wiring the controller for power
WARNING
Do not apply line voltage (mains voltage) to the controller's ports and terminals.
CAUTIONS
•The controller is powered by a Class 2 power source. Take appropriate isolation measures when mounting it
in a control panel where non-Class 2 circuits are present.
•Carrier controllers can share a power supply as long as you:
•Maintain the same polarity.
○Use the power supply only for Carrier controllers.
To wire for power
1 Remove power from the power supply.
2 Pull the screw terminal connector from the controller's power terminals labeled
Gnd
and
Hot
.
3 Connect the transformer wires to the screw terminal connector.
NOTE
If using a grounded transformer, connect the ungrounded lead to the
Hot
terminal to avoid damaging
the transformer.
4 Apply power to the power supply.
5 Measure the voltage at the controller’s power input terminals to verify that the voltage is within the operating
range of 21.6–26.4 Vac.
6 Insert the screw terminal connector into the controller's power terminals.
7 Verify that the
Power
LED is on and the
Run
LED is blinking.
Addressing the controller
You must give the controller an address that is unique on the network. You can address the controller before or
after you wire it for power.
1 If the controller has been wired for power, pull the screw terminal connector from the controller power
terminals labeled
Gnd
and
Hot
. The controller reads the address each time you apply power to it.
2 Using the rotary switches, set the controller address. Set the
Tens
(
10's
) switch to the tens digit of the
address, and set the
Ones
(
1's
) switch to the ones digit.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
6
EXAMPLE
If the controller’s address is 25, point the arrow on the
Tens
(
10's
) switch to 2 and the arrow on
the
Ones
(
1's
) switch to 5.
10's
1's
1
3
4
5
2
7
8
9
6
0
1
3
4
5
2
7
8
9
6
0
CAUTION
The factory default setting is
00
and must be changed to successfully install your controller.
Wiring for communications
The controller communicates using BACnet on the following types of network segments:
•MS/TP communicating at 9600 bps, 19.2 kbps, 38.4 kbps, or 76.8 kbps
•ARC156 communicating at 156 kbps
NOTE
For more networking details, see the Open Controller Network Wiring Installation Guide.
Wiring specifications for BACnet MS/TP and ARC156
Cable: 22 AWG or 24 AWG, low-capacitance, twisted, stranded, shielded copper wire
Maximum length: 2000 feet (610 meters)
WARNING
Do not apply line voltage (mains voltage) to the controller's ports and terminals.
To wire the controller to the BACnet network
1 Pull the screw terminal connector from the controller's power terminals labeled
24 Vac
and
Gnd
(
Return
).
2 Check the communications wiring for shorts and grounds.
3 Connect the communications wiring to the controller’s screw terminals labeled
Net +
,
Net -
, and
Shield
.
NOTE
Use the same polarity throughout the network segment.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
7
4 Set the communication type and baud rate.
For...
Set Communications
Selection jumper to...
Set DIP switches 1 and 2 to...
Set DIP switches 3 and 4 to...
MS/TP
BACnet MS/TP
The appropriate baud rate. See the
MS/TP Baud
diagram on the
controller.
Off/Off
ARC156
BACnet ARC156
N/A. Baud rate will be 156 kbps
regardless of the DIP switch
settings.
Off/Off
NOTE
Use the same baud rate for all controllers on the network segment.
5 Wire the controllers on a BACnet MS/TP or BACnet ARC156 network segment in a daisy-chain configuration.
6 If the controller is at either end of a network segment, connect a BT485 to the controller.
7 Insert the power screw terminal connector into the controller's power terminals.
8 Verify communication with the network by viewing a Module Status report in the i-Vu® interface.
Wiring inputs and outputs
WARNING
Do not apply line voltage (mains voltage) to the controller's ports and terminals.
See Appendix A (page 30) to print a blank wire list.
Inputs and outputs table
I/O
Type
I/O
Terminal
Gnd
Terminal
Point Name/
Function
Hardware/
Signal
Jumper
Position of
Pins
RH Sensor
AI
IN-1
2 - Gnd
RH sensor
0-5 Vdc
IN-1
Bottom
AI Setpoint
AI
IN-2
4 - Gnd
External AI Chilled Water Setpoint
0-5 Vdc
IN-2
Bottom
OAT Sensor
AI
IN-3
6 - Gnd
Outdoor Air Temperature
10K Thermistor
N/A
Leaving Chilled
Water Header
Temp
AI
IN-4
8 - Gnd
Leaving Chilled Water Header Temperature
5K Thermistor
N/A
Ext Demand
Limit
B1
IN-5
1 - Gnd
External Demand Limit Input
Dry Contact
N/A

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
8
I/O
Type
I/O
Terminal
Gnd
Terminal
Point Name/
Function
Hardware/
Signal
Jumper
Position of
Pins
Remote
Occupancy
Contact
BI
IN-6
1 - Gnd
Remote Occupancy Contact
Dry Contact
N/A
Tower Fan
Speed
AO
AO-1
2 - Gnd
Tower Fan Speed Output
0-10 Vdc
N/A
Alarm Lamp
BO
BO-1
1 - Pwr
Equipment Alarm Indicator Output
Relay
N/A
Legend
AI
- Analog Input
AO
- Analog Output
BI
- Binary Input
BO
- Binary Output
*These channels are configurable.
Input wiring specifications
Input
Maximum length
Minimum gauge
Shielding
0–5 Vdc 500 feet
(152 meters)
22 AWG 100 feet
(30.4 meters) unshielded
100 - 500 feet shielded
Thermistor
Dry contact
Pulse counter TLO
500 feet
(152 meters)
22 AWG 100 feet
(30.4 meters) unshielded
100 - 500 feet shielded
Equipment Touch
device
500 feet
(152 meters)
22 AWG (7x0096) bare
copper
If shielded, Aluminum/Mylar shield
(100% coverage) with TC drain wire
Inputs
The controller has 6 inputs that accept the following signal types.
These
inputs...
Support this signal
type...
Description
All Thermistor Precon type 2 (10k Ohm at 77°F/25°C) for IN-3 (Outdoor Air Temp) and
5k Ohm at 77°F (25°C) for IN-4 (Leaving Chilled Water Header Temp)
Input voltage for all other inputs: 0.33 to 2.52 Vdc
All Dry contact A 3.3 Vdc wetting voltage detects contact position, resulting in a 0.3 mA
maximum sense current when the contacts are closed.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
9
These
inputs...
Support this signal
type...
Description
IN-1, IN-2 0–5 Vdc The input impedance of the controller is approximately 30k Ohm.
All Pulse counter Pulse counting up to 10 pulses per second.
Minimum pulse width (on or off time) required for each pulse is 50
msec.
Binary outputs
The controller has 5 binary outputs. You can connect each output to a maximum of 24 Vac/26 Vdc. Each output is
a dry contact rated at 1 A, 24 V maximum and is normally open.
To size output wiring, consider the following:
•Total loop distance from the power supply to the controller, and then to the controlled device
NOTE
Include the total distance of actual wire. For 2-conductor wires, this is twice the cable length.
•Acceptable voltage drop in the wire from the controller to the controlled device
•Resistance (Ohms) of the chosen wire gauge
•Maximum current (Amps) the controlled device requires to operate
Analog outputs
The controller has analog outputs that support voltage. The controlled device must share the same ground as the
controller and have the following input impedance:
0–10 Vdc Minimum impedance 2000 Ohms, max 5 mA
NOTE
Ohm's law: -10V/.005a = 2000 Ohms

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
10
To wire inputs and outputs
1 Pull the screw terminal connector from the controller's power terminals labeled
Gnd
and
Hot
.
2 Connect the input wiring to the screw terminals on the controller.
NOTES
○Connect the shield wire to the
GND
terminal with the ground wire.
○
IN-5
and
IN-6
share the
GND
terminal above
IN-5
.
3 Set the appropriate jumpers on the controller.
To use inputs...
For...
All Thermistor
Dry contact
Verify the
IN-5
jumper is on.
All 0–5 Vdc Set jumper
IN-2
to the 0-5 Vdc position.
CAUTION
You must change this jumper from the default
Thermistor position.
IN-1 and 2 0–5 Vdc Set jumper
IN-1
to the 0-5 Vdc position.
IN-3 - 6 Thermistor
Dry contact
Set jumpers
IN-1
to the Thermistor/Dry contact position

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
11
4 Connect the analog output wiring to the screw terminals on the controller and to the controlled device.
5 Connect the binary output wiring to the screw terminals on the controller and to the controlled device.
6 Insert the power screw terminal connector into the controller's power terminals.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
12
Wiring sensors to the controller
You can connect the following sensors:
•Leaving chilled water header temperature (required)
•Outdoor air temperature (optional)
•Relative humidity (optional)
NOTE
This document gives instructions for wiring the sensors to the controller. For mounting and wiring the
sensors, see the Carrier Sensors Installation Guide.
WARNING
Disconnect electrical power to the controller before wiring it. Failure to follow this warning could
cause electrical shock, personal injury, or damage to the controller.
CAUTIONS
•Do not run sensor or relay wires in the same conduit or raceway with Class 1 AC or DC service wiring.
•Do not abrade, cut, or nick the outer jacket of the cable.
•Do not pull or draw cable with a force that may harm the physical or electrical properties.
•Avoid splices in any control wiring.
Wiring specifications
Cable from sensor to controller: If <100 ft (30.5 meters) 22 AWG, unshielded
If >100 ft (30.5 meters) 22 AWG, shielded
Maximum length: 500 feet (152 meters)
To wire the leaving chilled water header temperature sensor to the controller
Use one of the following leaving chilled water header 5k Ohm temperature sensors with associated immersion
well:
5k Ohm thermistor
Size
Immersion Well
HH79NZ014 3 in. 10HB50106801
HH79NZ029 4 in. 10HB50106802

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
13
The leaving chilled water header temperature sensor is required and used to measure the temperature of the
water in the common supply header leaving the chillers.
1 Strip the outer jacket from the cable for at least 4 inches (10.2 cm). Strip .25 inch (.6 cm) of insulation from
each wire.
2 Wire the sensor to the controller. See diagram below.
3 Sensor may be terminated at Input 4.
4 Apply power and verify sensor readings.
To wire an outdoor air temperature sensor to the controller
Part #33ZCSENOAT
You can use an optional outdoor air temperature (OAT) sensor to provide a reset of the chilled water setpoint
adjustment based on the OAT reset.
1 Strip the outer jacket from the cable for at least 4 inches (10.2 cm). Strip .25 inch (.6 cm) of insulation from
each wire.
2 Wire the sensor to the controller. See diagram below.
3 Sensor may be terminated at Input 3.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
14
4 Apply power and verify sensor readings.
To wire the Relative Humidity sensor to the controller
Wall and duct sensor - Part #33ZCSENSRH-02
You can use the optional relative humidity (RH) sensor to override the OAT reset in order to provide better humidity
control.
NOTE
The RH override requires that the OATsensor is installed and OAT reset function is enabled and active.
Otherwise, there is only RH sensor monitoring and alarming.
1 Strip the outer jacket from the cable for at least 4 inches (10.2 cm). Strip .25 inch (.6 cm) of insulation from
each wire.
2 Wire the sensor to the controller. See diagram below.
3 Sensor may be terminated at Input 1.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
15
4 Apply power and verify sensor readings.
Wiring an Equipment Touch to the controller
A single Equipment Touch is the only device you can wire to the controller's Rnet port. You can use a 2-conductor
cable instead of the standard 4-conductor Rnet cable and follow the instructions below.
NOTE
The Rnet communicates at a rate of 115 kbps.
For complete Equipment Touch installation instructions including wiring diagrams, see the Equipment Touch
Installation and Setup Guide.
1 Turn off the controller's power.
2 Partially cut, then bend and pull off the outer jacket of the cable. Do not nick the inner insulation.
3 Strip about .25 inch (.6 cm) of the inner insulation from each wire.
4 Wire the controller's
Rnet+
and
Rnet-
terminals to the terminals of the same name on the Equipment Touch's
connector.
NOTE
If using shielded wire, connect the shield wire and the ground wire to the
Gnd
terminal.
5 Turn on the controller's power.
6 Turn on the Equipment Touch.

Installing the controller
30MP Multi-chiller CARRIER CORPORATION ©2018
Installation and Start-up Guide All rights reserved
16
Wiring equipment to outputs
Use the following wiring specifications and diagram to wire the controller's outputs:
Prerequisites
•Each 30MP chiller must be equipped with the UPC Open.
•All 30MP chillers must be the same type, either all air-cooled or all water-cooled.
•A BACnet MS/TP bus must connect the 30MP chiller control to all 30MP UPC Open controllers. See To wire
the controller to the network (page 6).
Wiring specifications
To size output wiring, consider the following:
•Total loop distance from the power supply to the controller, and then to the controlled device
NOTE
Include the total distance of actual wire. For 2-conductor wires, this is twice the cable length.
•Acceptable voltage drop in the wire from the controller to the controlled device
•Resistance (Ohms) of the chosen wire gauge
•Maximum current (Amps) the controlled device requires to operate
Wiring diagram legend
AI setpoint
OAT sensor
Lvng Ch Wtr Hdr Temp
Gnd
Hot
REMOTE
RH sensor
RMT
n/c
N.C.
N.O.
=
=
=
=
=
=
=
=
=
=
=
Analog Input setpoint
Outdoor air temperature sensor
Leaving chilled water header temperature
Ground
24 Vac ungrounded power
Remote occupancy sensor
Relative humidity sensor
Remote occupancy
No connection
Normally closed
Normally oen
