Carrier 30XW User manual

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 1 OF 56
Touch Pilot Control
30XAXW chillers
BACNET OPTION
User Guide
For Software Release ECG-SR-20M47050

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 2 OF 56
REVISIONS HISTORY
REV DATE DESCRIPTION DONE BY
Original 14 November 2014 Original Julien DUPRE
Rev A 18 November 2014 Leak_v and leak_v_2 were set as BV object type instead
of AV object type Julien DUPRE
Rev B 9 December 2014
Touch Pilot setup settings updated
OPC-server troubleshooting added
Update BACnet objet list with object description
Monika
BURCZYK/ Julien
DUPRE
Rev C 29 April 2015 Update Version part number
Replace TL_SUCT_B object by TL_DGT_B object Julien DUPRE
Rev D 23 June 2015 Add TL_OAT (Software SR2.1) Bastien FERRAND
Rev E 11 December 2015
Update Bacnet object list.
Add 2 trendlogs (HR_PARTIAL and HR_TOTAL).
The Trendlog instances after OAT trendlog have been
modified.
Bastien FERRAND
Rev F 31 March 2016 Update Bacnet object list.
Add trendlogs (LOADFACT_cap_t).
Philippe
ROUVELLAT
Rev G 16 March 2017 Update Bacnet object list. Damien
BUATHIER

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 3 OF 56
CONTENTS
REVISIONS HISTORY...........................................................................................................2
ABOUT THIS DOCUMENT...................................................................................................5
1 INTRODUCTION.............................................................................................................6
1.1 Purpose .................................................................................................................................... 6
1.2 BACnet..................................................................................................................................... 6
1.3 Definitions, Abbreviations and Acronyms............................................................................ 6
2 HOW TO TRANSFORM A NON-BACNET CHILLER TO A BACNET CHILLER 8
2.1 Prerequisites............................................................................................................................ 8
2.2 How to mount the BACnet dongle......................................................................................... 9
2.3 How to test the dongle connection....................................................................................... 10
3 BACNET FOR 30XAXW CHILLER.............................................................................11
3.1 BACnet stack......................................................................................................................... 11
3.2 BACnet settings..................................................................................................................... 11
4 BACNET OBJECTS........................................................................................................13
4.1 BACnet chiller objects.......................................................................................................... 13
4.2 Optional properties............................................................................................................... 13
4.3 Priority assignment............................................................................................................... 14
4.4 Present Value property access............................................................................................. 14
4.5 Notification class object........................................................................................................ 14
4.6 Savings................................................................................................................................... 14
4.7 Objects list............................................................................................................................. 15
4.8 BBMD configuration ............................................................................................................ 36
5 BACNET PROTOCOL IMPLEMENTATION CONFORMANCE STATEMENT
(PICS)......................................................................................................................................37
5.1 Product Description:............................................................................................................. 37
5.2 BACnet Standardized Device Profile (Annex L): .............................................................. 37
5.3 BACnet Interoperability Building Blocks Supported (Annex K): ................................... 38
5.3.1 Data Sharing BIBBs ________________________________________________________ 38
5.3.2 Alarm / Event BIBBs _______________________________________________________ 38
5.3.3 Scheduling BIBBs__________________________________________________________ 38
5.3.4 Trending BIBBs ___________________________________________________________ 38
5.3.5 Device Management BIBBs __________________________________________________ 39
5.3.6 Network Management BIBBs _________________________________________________ 39
5.4 Segmentation Capability:..................................................................................................... 39
5.5 Standard Object Types Supported: .................................................................................... 40
5.5.1 Standard Object Types Supported: Accumulator-Object ____________________________ 40
5.5.2 Standard Object Types Supported: Analog-Input-Object ____________________________ 41
5.5.3 Standard Object Types Supported: Analog-Output-Object___________________________ 41
5.5.4 Standard Object Types Supported: Analog-Value-Object ___________________________ 42
5.5.5 Standard Object Types Supported: Averaging Object_______________________________ 42
5.5.6 Standard Object Types Supported: Binary-Input-Object ____________________________ 43
5.5.7 Standard Object Types Supported: Binary-Output-Object ___________________________ 43
5.5.8 Standard Object Types Supported: Binary-Value-Object ____________________________ 44
5.5.9 Standard Object Types Supported: Calendar-Object________________________________ 44
5.5.10 Standard Object Types Supported: Command ____________________________________ 44

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 4 OF 56
5.5.11 Standard Object Types Supported: Device-Object _________________________________ 45
5.5.12 Standard Object Types Supported: Event Enrollment Object_________________________ 45
5.5.13 Standard Object Types Supported: File__________________________________________ 45
5.5.14 Standard Object Types Supported: Group________________________________________ 45
5.5.15 Standard Object Types Supported: Loop ________________________________________ 46
5.5.16 Standard Object Types Supported: Multistate-Input-Object __________________________ 46
5.5.17 Standard Object Types Supported: Multistate-Output-Object ________________________ 47
5.5.18 Standard Object Types Supported: Multistate-Value-Object _________________________ 47
5.5.19 Standard Object Types Supported: Notification Class Object ________________________ 47
5.5.20 Standard Object Types Supported: Program______________________________________ 48
5.5.21 Standard Object Types Supported: Pulse Converter ________________________________ 48
5.5.22 Standard Object Types Supported: Schedule Object________________________________ 48
5.5.23 Standard Object Types Supported: Trendlog Object________________________________ 49
5.6 Device Address Binding: ...................................................................................................... 49
5.7 Data Link Layer Options:.................................................................................................... 49
5.8 Networking Options: ............................................................................................................ 50
5.9 Character Sets Supported:................................................................................................... 50
6 IP ADDRESS SETTINGS...............................................................................................51
6.1 Setup settings on Touch Pilot user interface ...................................................................... 51
6.2 How to modify the unit IP address...................................................................................... 52
7 BACNET IP COMMUNICATION TROUBLESHOOTING......................................54
8 BACNET OPC-SERVER TROUBLESHOOTING......................................................55
8.1 BACstac installation error................................................................................................... 55
8.2 USB dongle not recognised................................................................................................... 56
8.3 Incompatibilities.................................................................................................................... 56
8.4 BDT cannot see BACnet device........................................................................................... 56

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 5 OF 56
ABOUT THIS DOCUMENT
PURPOSE
This document aims to provide an overview on the BACnet option for 30XA/XW chillers
with the Touch Pilot control.
Document Name Document ID Publication Date
30XA/XW Touch Pilot Control:
BACnet User Guide
ECG-UG-14-002 March 2016
REFERENCES
The following list includes all documents that may be the source of reference for material
discussed in this publication.
No. Reference
1. 30XA/XW IOM Control
2. 30XA/XW IOM Machine
3. 30XA/XW Service Guide
4. ASHRAE standard: BACnet; ANSI/ASHRAE Standard 135-2008
CONVENTIONS
The following symbols are used to highlight important information in this document.
Symbol Description
ADVICE
This symbol is used to provide useful information.
CAUTION
This symbol is used to indicate potentially hazardous situations and conditions.
IMPORTANT
This symbol is used to present information relevant to the topic.
This document is the property of Carrier Corporation and is delivered on the express
condition that it is not to be disclosed, reproduced in whole or in part, or used for
manufacture by anyone other than Carrier Corporation without its written consent, and
that no right is granted to disclose or so use any information contained in said document.

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 6 OF 56
Back to Beginning of Chapter – Table of Contents
1 INTRODUCTION
1.1 Purpose
This guide describes the BACnet option for 30XA/XW chillers. It is intended for Building
Management System (BMS) engineers inside or outside the Carrier Corporation.
IMPORTANT
Some parameters can be configured only by Carrier service.
1.2 BACnet
BACnet is a data communication protocol for building automation and control networks.
It is an ISO global standard recognised in more than 30 countries across the world.
BACnet makes it possible to expand and upgrade controls using technology from different
vendors.
BACnet is based on a client-server model and BACnet messages are referred to as
"service requests". The client machine ("user interface") sends the request to the server
machine ("field device") that reports the result. For example, when the "ReadProperty"
service request is sent, the server machine locates the requested property of the
requested object and sends its reading back to the client.
1.3 Definitions, Abbreviations and Acronyms
Acronym/
Abbreviation Definition
BMS
Building Management System
It is a computer-
based control system installed in buildings. BMS
controls and monitors t
he building’s mechanical and electrical
equipment such as ventilation, lighting, power systems
, fire systems
and security systems. BMS consists of software and hardware.
BACnet/IP
Building Automation and Controls Network
Open
Protocol for the controlled exchange of data between two or
more intelligent control devices or BMS. BACnet is used over IP.
BBMD
BACnet Broadcast Management Device
Broadcast management is accomplished by defining the capabilities of
the new device.
BIBBS
BACnet Interoperability Building Blocks
BIBBS are combined to build the BACnet functional requirements for a
specific device.
COV
Change Of Value
A COV notification is sent any time the object's value changes by an
amount specified as a default pa
rameter, or in the subscription
request. Devices wishing to receive the notice of change need to
"subscribe" to the COV by sending a subscription request to the device
from which a COV notification is desired.

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 7 OF 56
Back to Beginning of Chapter – Table of Contents
Additional information: BACnet/IP
BACnet/IP network is a collection of one or more IP subnetworks (IP domains)
that are assigned to a single BACnet network number.
BACnet devices are defined on the network as a collection of objects, each of which has
a set of properties defined. Two types of BACnet objects can be distinguished, i.e.
analogue and binary objects.
The most frequently referenced property for ANALOGUE /BINARY OBJECT is PRESENT VALUE,
which typically means data derived from a sensor or physical device. Other properties
associated with an object may include fault status, reliability, object name, minimum
and maximum limits, etc.
BACnet stack is an application layer that may function both as a server and a client.
The stack is the transport layer providing the following capabilities:
•The generation of limited alarm and event notifications and the ability to direct them
to recipients.
•The tracking acknowledgments of alarms from human operators.
•The adjustment of alarm parameters.
•The read/write property multiple services.
•Optional properties as COV, Intrinsic Reporting properties, Commandable properties
on some objects.
Term Definition
Device Controller/user interface or PC. The BACnet device contains a
collection of information about the device, i.e. objects and properties.
Network type Physical communication method, e.g. BACnet/IP.
Objects Information point (i.e. temperature reading, flow setpoint or
equipment schedule). The BACnet object defines certain device
information such as the device object identifier or instance number.
Every object has a collection of properties that define the object.
Note: The BACnet device object instance number must be unique
across the entire BACnet network.
Properties Information point. Properties convey information about a BACnet
object. Properties may be defined as read-only or read/write
properties.
Service Request for information or modifications (read a temperature, change
a flow setpoint, edit an equipment schedule, send an alarm). Services
defined in the BACnet network are used to take an action on objects
or properties (read-only or read/write).

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 8 OF 56
Back to Beginning of Chapter – Table of Contents
2 HOW TO TRANSFORM A NON-BACNET CHILLER TO A
BACNET CHILLER
2.1 Prerequisites
The BACnet option requires the installation of the BACnet dongle. The BACnet dongle can
be mounted during manufacturing or on site.
It is strongly recommended to disconnect the main power supply before any work.
Disconnect the power supply to the chiller Touch Pilot control.
CAUTION
The power supply must be switched off before any work is begun.
Only personnel qualified in accordance with IEC 60364 recommendations (International
Electrotechnical Commission) and trained to install the BACnet option may have access to
electrical components.
The chiller controller includes electronic components that may generate or be
damaged by electromagnetic interference, e.g. Electrostatic Discharge (ESD).
ADVICE
Use an antistatic wrist strap (ESD wrist strap) when handling electrical
components. The ESD wrist strap prevents the build-up of static electricity
which may result in electrostatic discharge.
If you do not have access to an ESD wrist strap on site, please take into consideration
the following recommendations in order to reduce the risk of ESD:
Zero Potential Make sure you are at Zero Potential by touching an unpainted metal
surface of the electrical box.
Clothes Do not to wear any clothes that conduct a lot of Electrical Charge, e.g.
a wool sweater.
Accessories Remove all jewellery to reduce the risk of ESD.
Weather Electrical storms can increase the ESD risk; unless absolutely
necessary, do not to work on the chiller controller during an electrical
storm.

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 9 OF 56
Back to Beginning of Chapter – Table of Contents
2.2 How to mount the BACnet dongle
In order to mount the BACnet dongle, perform the following steps:
Step Action
1. Disconnect the chiller Touch Pilot control power supply.
2. Open its metal cover with a Torx T10 screwdriver.
3. Remove the metal cover.

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 10 OF 56
Back to Beginning of Chapter – Table of Contents
4. Insert the BACnet dongle into the connector.
5. Mount the plastic holder to attach the dongle to the board.
6. Close the box and power up the Touch Pilot.
2.3 How to test the dongle connection
To verify that the dongle is correctly inserted and detected by the equipment, perform
the following steps:
Step Action
1. Power up the controller.
2. Check Inputs Status in the Main menu.
The BACnet dongle status must be set to Yes.
ADVICE
If the BACnet dongle status is NO, check again if the dongle is correctly inserted.

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 11 OF 56
Back to Beginning of Chapter – Table of Contents
3 BACNET FOR 30XAXW CHILLER
The 30XAXW chiller supports the BACnet protocol as BACnet B-AAC equipment (BACnet
Advanced Application Controller).
3.1 BACnet stack
The BACnet stack includes the following options:
•COV (Change of Value), Intrinsic Reporting and Commandable properties.
•The generation of alarm notifications sent to a set of predefined recipients.
•Tracking acknowledgments of alarms raised by human operators.
•The adjustment of alarm parameters.
•Read Property Multiple services.
•Write Property Multiple services.
IMPORTANT
This option can be installed during manufacturing or on site.
3.2 BACnet settings
The BACnet option can be enabled/disabled on the Touch Pilot user interface. In order to
modify BACnet parameters, the user must be logged in at service access level.
IMPORTANT
BACnet settings can be modified only by Carrier service.
In order to enable/disable the BACnet
option, navigate to the Configuration
menu and select BACnet Parameters.
After a power up, if the BACnet dongle is detected and BACnet is enabled (BACNET ENABLE),
the chiller objects will be created (see also section 4).
Metric and imperial units are supported. By default, BACnet data is given in metric units
(METRIC UNIT =YES).

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 12 OF 56
Back to Beginning of Chapter – Table of Contents
The BACnet Parameters menu allows the user to modify the BACnet network (NETWORK)
or the device object instance (IDENTIFIER).
The default instance has been chosen to let users easily recognize the chiller on a BACnet
network. By default, the device object instance is 1600001, where the first two digits
identify the BACnet CARRIER vendor (16).
CAUTION
Identifier must be unique on the BACnet network. If more than one Carrier
chiller is connected to the BACnet network, the parameter must be modified.
BACnet Parameters
Name Status Default Displayed text
bacena dsable/enable enable BACnet Enable
bacunit no/yes yes Metric Unit
network 1 to 9999 1601 Network
ident 0 to 9999999 1600001 Identifier
bbmd 0-2* 0 BACnet device management
NOTE: Changing any of these parameters will trigger a reboot of the board (after about 1 min).
* 0 = No BBMD
1 = FD (Foreign Device)
2 = BBMD
IMPORTANT
Changing IP address from the SETUP menu will require a manual reboot or
power cycle of the Touch Pilot controller in order to re-build the BACnet stack
(see also section 6).

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 13 OF 56
Back to Beginning of Chapter – Table of Contents
4 BACNET OBJECTS
4.1 BACnet chiller objects
The 30XAXW chiller contains up to 700 BACnet objects. These objects are of
ANALOG_VALUE (AV) or BINARY_VALUE (BV) type.
There is one Notification Class object for alarm reporting and one Device object.
Some AV and BV objects support options such as COV, Intrinsic Reporting, Commandable
properties (e.g. the Present_Value of an analog-output object). These objects are
predefined and cannot be deleted. At the same time, new objects cannot be added.
Objects names consist of the menu name (table name) and the point name.
For example:
Menu name (table name) Point name Object name
GENCONF off_on_d GENCONF_off_on_d
General Configuration Unit Off to On Delay Unit Off to On Delay
4.2 Optional properties
Change of Value is an event that occurs when a measured or calculated analogue value
changes by a predefined amount.
For the CHANGE OFVALUE option (COV) the increment value can be configured.
Intrinsic reporting is the detection and reporting of an alarm or event, based on
algorithm defined as part of the object type specification.
For the INTRINSIC REPORTING option (IR) the alarm configuration and the configuration of
the equipment to be notified are required. Otherwise, the option will not be active.
The Commandable option reflects the state of the output.
Objects with the COMMANDABLE option are named with the _wr suffix.
For example: GENUNIT_CTRL_PNT_wr (GENUNIT – General Parameters, Control Point).

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 14 OF 56
Back to Beginning of Chapter – Table of Contents
4.3 Priority assignment
Commanding entities have their priority level assigned. The BACnet priority level
corresponds to the CCN override level.
If the Local Operating Type is set to Network, then it is possible to control the unit from
the BACnet writing these objects:
The highest priority value of the commandable object will be copied to the present
value of the object using the same name with the _rd suffix
(e.g., GENUNIT_CTRL_PNT_wr highest priority value copied to
GENUNIT_CTRL_PNT_rd present value).
If the Local Operating Type is set to Local or Remote, then the Priority value won’t be
applied and the value determined by the controller will be applied:
The present value of the object name with the _rd suffix will still reflect the
current software value (e.g., GENUNIT_CTRL_PNT_rd).
The BACnet priority level corresponds to the CCN override level (1:1). If this BACnet
priority level is removed, the first non-NULL value in Priority_array property will be
applied to the corresponding CCN point (CCN "Auto" command will be applied first). *
When the CCN override level is applied from the CCN, the CCN override level will be
the BACnet priority level.
BACnet priority level 16 (the lowest) has no CCN equivalent and does not correspond
to the CCN override. This priority level should not be used.
*The Priority_Array consists of an array of commanded values in order of decreasing priority. The first value
in the array corresponds to priority 1 (highest prority), the second value corresponds to priority 2, etc. The
sixteenth value corresponds to priority 16 (lowest prority).
4.4 Present Value property access
Writing AV and BV "Present Value" is authorized by the BACnet protocol for all objects.
However, the Present value regarding the access object parameters (read-only or
read/write) may or may not be authorised by the chiller application.
If the "present value" property with an access parameter equal to RO is written, then the
present value will be overwritten by the chiller application with the previous value.
Objects with "present value" in read-only access are all objects used for chiller
configuration and status.
Objects with "present value" in read/write access are objects used for setpoint
configuration, i.e. objects with names with the SETPOINT_ prefix (e.g., SETPOINT_csp1)
and Commandable objects with the _wr suffix (e.g., GENUNIT_CTRL_PNT_wr).
4.5 Notification class object
The notification class object can notify up to 5 BACnet devices. These devices are listed
in the Recipient List property.
IMPORTANT
You must enter the IP address of the device to notify (see also section 6).
Device Name and instance are not yet supported.
4.6 Savings
COV increment property, Intrinsic Reporting properties, Priority values, Notification class
and Trend log properties are saved in files and restored automatically on power-up.

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 15 OF 56
Back to Beginning of Chapter – Table of Contents
4.7 Objects list
The BACnet objects list includes the list of all objects names with respect to the following
parameters:
AV Analogue Value
BV Binary Value
TL TREND_LOG
COV Change Of Value
IR Intrinsic Reporting (Alarming)
CMD Commandable
RO Read-Only Present Value (PV)
RW Read/Write Present Value (PV)
For BMS, the more often used objects are objects with names starting with GENUNIT, TEMP,
PRESSURES, RUNTIMES and SETPOINT prefixes.
Object Name
Type Instance Option COVInc PV Access
Description
GENCONF_lead_cir AV 1 0 RO Cir Priority Sequence
GENCONF_seq_typ BV 1 0 RO Staged Loading Sequence
GENCONF_ramp_sel BV 2 0 RO Ramp Loading Select
GENCONF_off_on_d AV 2 0 RO Unit Off to On Delay
GENCONF_nh_start AV 3 0 RO Night Mode Start Hour
GENCONF_nh_end AV 4 0 RO Night Mode End Hour
GENCONF_nh_limit AV 5 0 RO Night Capacity Limit
GENCONF_bas_menu AV 6 0 RO Basic Menu Configuration
GENCONF_lim_sel AV 7 0 RO Demand Limit Type Select
GENCONF_lim_mx AV 8 0 RO mA For 100% Demand Limit
GENCONF_lim_ze AV 9 0 RO mA For 0% Demand Limit
GENCONF_curr_sel BV 3 0 RO Current Limit Select
GENCONF_curr_ful AV 10 0 RO CurrentLimit at 100%
GENCONF_free_dt AV 11 0 RO Free Cooling Delta T Th
GENCONF_fc_tmout AV 12 0 RO Full Load Timeout
GENCONF_ice_cnfg BV 4 0 RO Ice Mode Enable
GENCONF_al_rever BV 5 0 RO Reverse Alarms Relay
PUMPCONF_hpumpseq AV 13 0 RO Condenser Pumps Sequence
PUMPCONF_cpumpseq AV 14 0 RO Cooler Pumps Sequence
PUMPCONF_pump_del AV 15 0 RO Pump Auto Rotation Delay
PUMPCONF_pump_per BV 6 0 RO Pump Sticking Protection
PUMPCONF_pump_sby BV 7 0 RO Stop Pump During Standby
PUMPCONF_pump_loc BV 8 0 RO Flow Checked If Pump Off
PUMPCONF_stopheat BV 9 0 RO Cooler Pump Off In Heat
PUMPCONF_stopcool BV 10 0 RO Cond Pump Off In Cool
RESETCFG_cr_sel AV 16 0 RO Cooling Reset Select
RESETCFG_hr_sel AV 17 0 RO Heating Reset Select
RESETCFG_oat_crno AV 18 0 RO OAT No Reset Value
RESETCFG_oat_crfu AV 19 0 RO OAT Full Reset Value
RESETCFG_dt_cr_no AV 20 0 RO Delta T No Reset Value
RESETCFG_dt_cr_fu AV 21 0 RO Delta T Full Reset Value
RESETCFG_v_cr_no AV 22 0 RO Current No Reset Value

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 16 OF 56
Back to Beginning of Chapter – Table of Contents
Object Name
Type Instance Option COVInc PV Access
Description
RESETCFG_v_cr_fu AV 23 0 RO Current Full Reset Value
RESETCFG_spacr_no AV 24 0 RO Space T No Reset Value
RESETCFG_spacr_fu AV 25 0 RO Space T Full Reset Value
RESETCFG_cr_deg AV 26 0 RO Cooling Reset Deg. Value
RESETCFG_oat_hrno AV 27 0 RO OAT No Reset Value
RESETCFG_oat_hrfu AV 28 0 RO OAT Full Reset Value
RESETCFG_dt_hr_no AV 29 0 RO Delta T No Reset Value
RESETCFG_dt_hr_fu AV 30 0 RO Delta T Full Reset Value
RESETCFG_v_hr_no AV 31 0 RO Current No Reset Value
RESETCFG_v_hr_fu AV 32 0 RO Current Full Reset Value
RESETCFG_spahr_no AV 33 0 RO Space T No Reset Value
RESETCFG_spahr_fu AV 34 0 RO Space T Full Reset Value
RESETCFG_hr_deg AV 35 0 RO Heating Reset Deg. Value
RESETCFG_heat_th AV 36 0 RO Heating OAT threshold
RESETCFG_both_sel BV 11 0 RO HSM Both Command Select
RESETCFG_auto_sel BV 12 0 RO Auto Changeover Select
GENUNIT_CTRL_TYP AV 37 COV 1 RO Local=0 Net.=1 Remote=2
GENUNIT_STATUS AV 38 0 RO Run Status
GENUNIT_CHIL_S_S_rd BV 13 COV 1 RO Net.: Cmd Start/Stop
GENUNIT_CHIL_OCC_rd BV 14 COV 1 RO Net.: Cmd Occupied
GENUNIT_min_left AV 39 0 RO Minutes Left for Start
GENUNIT_HEATCOOL AV 40 0 RO Heat/Cool status
GENUNIT_HC_SEL_rd AV 41 COV 1 RO Heat/Cool Select
GENUNIT_SP_SEL_rd AV 42 COV 1 RO Setpoint Select
GENUNIT_SP_OCC_rd BV 15 COV 1 RO Setpoint Occupied?
GENUNIT_CAP_T AV 43 COV 100 RO Percent Total Capacity
GENUNIT_TOT_CURR AV 44 0 RO Actual Chiller Current
GENUNIT_CURR_LIM_rd AV 45 0 RO Chiller Current Limit
GENUNIT_sp AV 46 COV 100 RO Current Setpoint
GENUNIT_CTRL_PNT_rd AV 47 COV 100 RO Control Point
GENUNIT_EMSTOP_rd BV 16 0 RO Emergency Stop
GENUNIT_DEM_LIM_rd AV 48 COV 100 RO Active Demand Limit Val
TEMP_COOL_EWT AV 49 COV 36 RO Cooler Entering Fluid
TEMP_COOL_LWT AV 50 COV 36 RO Cooler Leaving Fluid
TEMP_COND_EWT AV 51 COV 36 RO Condenser Entering Fluid
TEMP_COND_LWT AV 52 COV 36 RO Condenser Leaving Fluid
TEMP_SCT_A AV 53 COV 36 RO Saturated Cond Tmp cir A
TEMP_SST_A AV 54 COV 36 RO Saturated Suction Temp A
TEMP_SUCT_A AV 55 COV 36 RO Compressor Suction Tmp A
TEMP_DGT_A AV 56 COV 36 RO Discharge Gas Temp cir A
TEMP_CP_TMP_A AV 57 COV 36 RO Motor Temperature cir A
TEMP_SCT_B AV 58 COV 36 RO Saturated Cond Tmp cir B
TEMP_SST_B AV 59 COV 36 RO Saturated Suction Temp B
TEMP_SUCT_B AV 60 COV 36 RO Compressor Suction Tmp B
TEMP_DGT_B AV 61 COV 36 RO Discharge Gas Temp cir B

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 17 OF 56
Back to Beginning of Chapter – Table of Contents
Object Name
Type Instance Option COVInc PV Access
Description
TEMP_CP_TMP_B AV 62 COV 36 RO Motor Temperature cir B
TEMP_SCT_C AV 63 COV 36 RO Saturated Cond Tmp cir C
TEMP_SST_C AV 64 COV 36 RO Saturated Suction Temp C
TEMP_SUCT_C AV 65 COV 36 RO Compressor Suction Tmp C
TEMP_DGT_C AV 66 COV 36 RO Discharge Gas Temp cir C
TEMP_CP_TMP_C AV 67 COV 36 RO Motor Temperature cir C
TEMP_SPACETMP AV 68 0 RO Optional Space Temp
TEMP_CHWSTEMP AV 69 0 RO CHWS Temperature
TEMP_CHWSHEAT AV 70 0 RO CHWS Heat Temp
TEMP_OAT AV 71 COV 36 RO External Temperature
TEMP_T_HEATER AV 72 0 RO Cooler Heater Temp
TEMP_T_HEAT_C AV 73 0 RO Circuit C Heater Temp
TEMP_ECO_TP_A AV 74 0 RO Economizer Gas Temp A
TEMP_ECO_TP_B AV 75 0 RO Economizer Gas Temp B
TEMP_ECO_TP_C AV 76 0 RO Economizer Gas Temp C
PRESSURE_DP_A AV 77 0 RO Discharge Pressure A
PRESSURE_SP_A AV 78 0 RO Main Suction Pressure A
PRESSURE_OP_A AV 79 COV 145 RO Oil Pressure A
PRESSURE_DOP_A AV 80 0 RO Oil Pressure DifferenceA
PRESSURE_ECON_P_A AV 81 COV 145 RO Economizer Pressure A
PRESSURE_DP_B AV 82 0 RO Discharge Pressure B
PRESSURE_SP_B AV 83 0 RO Main Suction Pressure B
PRESSURE_OP_B AV 84 COV 145 RO Oil Pressure B
PRESSURE_DOP_B AV 85 0 RO Oil Pressure DifferenceB
PRESSURE_ECON_P_B AV 86 COV 145 RO Economizer Pressure B
PRESSURE_DP_C AV 87 0 RO Discharge Pressure C
PRESSURE_SP_C AV 88 0 RO Main Suction Pressure C
PRESSURE_OP_C AV 89 COV 145 RO Oil Pressure C
PRESSURE_DOP_C AV 90 0 RO Oil Pressure DifferenceC
PRESSURE_ECON_P_C AV 91 COV 145 RO Economizer Pressure C
INPUTS_ONOFF_SW BV 17 0 RO Remote On/Off Switch
INPUTS_HC_SW BV 18 0 RO Remote HeatCool Switch
INPUTS_RECL_SW BV 19 0 RO Remote Reclaim Switch
INPUTS_FC_SW BV 20 0 RO Free Cooling Disable Sw
INPUTS_SETP_SW BV 21 0 RO Remote Setpoint Switch
INPUTS_LIM_SW1 BV 22 0 RO Limit Switch 1
INPUTS_LIM_SW2 BV 23 0 RO Limit Switch 2
INPUTS_OIL_L_A BV 24 0 RO Oil Level Input A
INPUTS_OIL_L_B BV 25 0 RO Oil Level Input B
INPUTS_OIL_L_C BV 26 0 RO Oil Level Input C
INPUTS_CURREN_A AV 92 0 RO Motor Current A
INPUTS_CURREN_B AV 93 0 RO Motor Current B
INPUTS_CURREN_C AV 94 0 RO Motor Current C
INPUTS_SP_RESET AV 95 0 RO Reset/Setpnt4-20mA Sgnl
INPUTS_REM_LOCK BV 27 0 RO Customer Interlock

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 18 OF 56
Back to Beginning of Chapter – Table of Contents
Object Name
Type Instance Option COVInc PV Access
Description
INPUTS_ICE_SW BV 28 0 RO Ice Done Storage Switch
INPUTS_OCC_OVSW BV 29 0 RO Occupied Override Switch
INPUTS_LIM_ANAL AV 96 0 RO Limit 4-20mA Signal
INPUTS_ELEC_BOX BV 30 0 RO Electrical Box Interlock
INPUTS_HEATR_SW BV 31 0 RO Cooler Heater Feedback
INPUTS_leak_v AV 97 0 RO Leakage detector 1 val
INPUTS_leak_2_v AV 98 0 RO Leakage detector 2 val
OUTPUTS_COMP_A BV 32 0 RO Compressor A
OUTPUTS_OIL_SL_A BV 33 0 RO Oil Solenoid Output A
OUTPUTS_SLID_1_A BV 34 0 RO Slide Valve 1 Output A
OUTPUTS_SLID_2_A BV 35 0 RO Slide Valve 2 Output A
OUTPUTS_CAPT010A AV 99 0 RO Capacity Signal Cir A
OUTPUTS_COMP_B BV 36 0 RO Compressor B
OUTPUTS_OIL_SL_B BV 37 0 RO Oil Solenoid Output B
OUTPUTS_SLID_1_B BV 38 0 RO Slide Valve 1 Output B
OUTPUTS_SLID_2_B BV 39 0 RO Slide Valve 2 Output B
OUTPUTS_CAPT010B AV 100 0 RO Capacity Signal Cir B
OUTPUTS_COMP_C BV 40 0 RO Compressor C
OUTPUTS_OIL_SL_C BV 41 0 RO Oil Solenoid Output C
OUTPUTS_SLID_1_C BV 42 0 RO Slide Valve 1 Output C
OUTPUTS_SLID_2_C BV 43 0 RO Slide Valve 2 Output C
OUTPUTS_CAPT010C AV 101 0 RO Capacity Signal Cir C
OUTPUTS_CAPT_010 AV 102 0 RO Chiller Capacity signal
OUTPUTS_ALARM BV 44 0 RO Alarm Relay Status
OUTPUTS_RUNNING BV 45 0 RO Running Relay Status
OUTPUTS_ALERT BV 46 0 RO Alert Relay State
OUTPUTS_SHUTDOWN BV 47 0 RO Shutdown Indicator State
OUTPUTS_pos_3wv AV 103 0 RO Cond 3 Way Valve Pos
OUTPUTS_COOLHEAT BV 48 0 RO Cooler Heater Command
OUTPUTS_READY BV 49 0 RO Ready or Running Status
OUTPUTS_cond_htr BV 50 0 RO Reclaim Condenser Heater
OUTPUTS_iso_cl_a BV 51 0 RO Ball Valve Close Out A
OUTPUTS_iso_op_a BV 52 0 RO Ball Valve Open Out A
OUTPUTS_iso_cl_b BV 53 0 RO Ball Valve Close Out B
OUTPUTS_iso_op_b BV 54 0 RO Ball Valve Open Out B
OUTPUTS_iso_cl_c BV 55 0 RO Ball Valve Close Out C
OUTPUTS_iso_op_c BV 56 0 RO Ball Valve Open Out C
OUTPUTS_FAN_ST_A AV 104 0 RO Fan Staging Number A
OUTPUTS_FAN_ST_B AV 105 0 RO Fan Staging Number B
OUTPUTS_FAN_ST_C AV 106 0 RO Fan Staging Number C
OUTPUTS_hd_pos_a AV 107 0 RO Head Press Act Pos A
OUTPUTS_hd_pos_b AV 108 0 RO Head Press Act Pos B
OUTPUTS_hd_pos_c AV 109 0 RO Head Press Act Pos C
OUTPUTS_OIL_HT_A BV 57 0 RO Oil Heater Output A
OUTPUTS_OIL_HT_B BV 58 0 RO Oil Heater Output B

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 19 OF 56
Back to Beginning of Chapter – Table of Contents
Object Name
Type Instance Option COVInc PV Access
Description
OUTPUTS_OIL_HT_C BV 59 0 RO Oil Heater Output C
OUTPUTS_RV_A BV 60 0 RO 4 Way Refrig Valve A
OUTPUTS_RV_B BV 61 0 RO 4 Way Refrig Valve B
OUTPUTS_iso_refa BV 62 0 RO Ball Valve Position A
OUTPUTS_iso_refb BV 63 0 RO Ball Valve Position B
OUTPUTS_iso_refc BV 64 0 RO Ball Valve Position C
OUTPUTS_ALARMOUT BV 65 0 RO Alarm Relay Status
PUMPSTAT_SET_FLOW BV 66 0 RO Cooler Flow Setpoint Out
PUMPSTAT_CPUMP_1_rd BV 67 0 RO Cooler Pump #1 Command
PUMPSTAT_CPUMP_2_rd BV 68 0 RO Cooler Pump #2 Command
PUMPSTAT_ROTCPUMP_rd BV 69 0 RO Rotate Cooler Pumps ?
PUMPSTAT_FLOW_SW BV 70 0 RO Cooler Flow Switch
PUMPSTAT_HPUMP_1_rd BV 71 0 RO Condenser Pump Command1
PUMPSTAT_HPUMP_2_rd BV 72 0 RO Condenser Pump Command2
PUMPSTAT_ROTHPUMP_rd BV 73 0 RO Rotate Condenser Pumps ?
PUMPSTAT_watpres1 AV 110 0 RO Water pres before cooler
PUMPSTAT_watpres2 AV 111 0 RO Water pres after cooler
PUMPSTAT_watpres3 AV 112 0 RO Water pres before filter
PUMPSTAT_watpres4 AV 113 0 RO Water pres after filter
PUMPSTAT_wat_flow AV 114 0 RO Water flow
PUMPSTAT_cool_pwr AV 115 0 RO Cooling power
PUMPSTAT_CONDFLOW BV 74 0 RO Condenser Flow Status
RUNTIME_HR_MACH AV 116 0 RO Machine Operating Hours
RUNTIME_st_mach AV 117 0 RO Machine Starts Number
RUNTIME_hr_cp_a AV 118 0 RO Compressor A Hours
RUNTIME_st_cp_a AV 119 0 RO Compressor A Starts
RUNTIME_hr_cp_b AV 120 0 RO Compressor B Hours
RUNTIME_st_cp_b AV 121 0 RO Compressor B Starts
RUNTIME_hr_cp_c AV 122 0 RO Compressor C Hours
RUNTIME_st_cp_c AV 123 0 RO Compressor C Starts
RUNTIME_hr_cpum1 AV 124 0 RO Cooler Pump #1 Hours
RUNTIME_hr_cpum2 AV 125 0 RO Cooler Pump #2 Hours
RUNTIME_hr_hpum1 AV 126 0 RO Condenser Pump #1 Hours
RUNTIME_hr_hpum2 AV 127 0 RO Condenser Pump #2 Hours
RUNTIME_hr_fcm_a AV 128 0 RO Free Cool A Pump Hours
RUNTIME_hr_fcm_b AV 129 0 RO Free Cool B Pump Hours
MODES_m_delay BV 75 0 RO Start Up Delay In Effect
MODES_m_2stpt BV 76 0 RO Second Setpoint In Use
MODES_m_reset BV 77 0 RO Reset In Effect
MODES_m_demlim BV 78 0 RO Demand limit Active
MODES_m_ramp BV 79 0 RO Ramp Loading Active
MODES_m_clheat BV 80 0 RO Cooler Heater Active
MODES_m_pmprot BV 81 0 RO Cooler Pump Rotation
MODES_m_pmpper BV 82 0 RO Pump Periodic Start
MODES_m_night BV 83 0 RO Night Low Noise Active

ECG–UG–14-002 REVISION DATE PAGE
30XAXW
BACnet Option Rev G March 2017 20 OF 56
Back to Beginning of Chapter – Table of Contents
Object Name
Type Instance Option COVInc PV Access
Description
MODES_m_slave BV 84 0 RO Master Slave Active
MODES_m_autoc BV 85 0 RO Auto Changeover Active
MODES_m_lowEwt BV 86 0 RO Heating Low EWT Lockout
MODES_m_cpmpro BV 87 0 RO Condenser Pump Rotation
MODES_m_cpmppr BV 88 0 RO Cond Pump Periodic Start
MODES_m_ice BV 89 0 RO Ice Mode In Effect
MODES_m_defA BV 90 0 RO Defrost Active On Cir A
MODES_m_defB BV 91 0 RO Defrost Active On Cir B
MODES_m_freec BV 92 0 RO Free Cooling Active
MODES_m_recla BV 93 0 RO Reclaim Active
MODES_m_sst_a BV 94 0 RO Low Suction Circuit A
MODES_m_sst_b BV 95 0 RO Low Suction Circuit B
MODES_m_sst_c BV 96 0 RO Low Suction Circuit C
MODES_m_map_a BV 97 0 RO Map compressor Circuit A
MODES_m_map_b BV 98 0 RO Map compressor Circuit B
MODES_m_map_c BV 99 0 RO Map compressor Circuit C
MODES_m_hp_a BV 100 0 RO High Pres Override Cir A
MODES_m_hp_b BV 101 0 RO High Pres Override Cir B
MODES_m_hp_c BV 102 0 RO High Pres Override Cir C
RECLAIM_RECL_SEL_rd BV 103 0 RO Heat Reclaim Select
RECLAIM_HR_EWT AV 130 0 RO Reclaim Entering Fluid
RECLAIM_HR_LWT AV 131 0 RO Reclaim Leaving Fluid
RECLAIM_hr_v_pos AV 132 0 RO Reclaim Valve Position
RECLAIM_hrstat_a AV 133 0 RO Reclaim Status Circuit A
RECLAIM_PD_P_A AV 134 0 RO Pumpdown Pressure Cir A
RECLAIM_hr_subta AV 135 0 RO Sub Condenser Temp Cir A
RECLAIM_hr_sat_a AV 136 0 RO Pumpdown Saturated Tmp A
RECLAIM_hr_subca AV 137 0 RO Subcooling Temperature A
RECLAIM_hr_ea_a BV 104 0 RO Air Cond Entering Valv A
RECLAIM_hr_ew_a BV 105 0 RO Water Cond Enter Valve A
RECLAIM_hr_la_a BV 106 0 RO Air Cond Leaving Valve A
RECLAIM_hr_lw_a BV 107 0 RO Water Cond Leaving Val A
RECLAIM_hrstat_b AV 138 0 RO Reclaim Status Circuit B
RECLAIM_PD_P_B AV 139 0 RO Pumpdown Pressure Cir B
RECLAIM_hr_subtb AV 140 0 RO Sub Condenser Temp Cir B
RECLAIM_hr_sat_b AV 141 0 RO Pumpdown Saturated Tmp B
RECLAIM_hr_subcb AV 142 0 RO Subcooling Temperature B
RECLAIM_hr_ea_b BV 108 0 RO Air Cond Entering Valv B
RECLAIM_hr_ew_b BV 109 0 RO Water Cond Enter Valve B
RECLAIM_hr_la_b BV 110 0 RO Air Cond Leaving Valve B
RECLAIM_hr_lw_b BV 111 0 RO Water Cond Leaving Val B
FREECOOL_FC_DSBLE_rd BV 112 0 RO Free Cooling Disable?
FREECOOL_fc_delta AV 143 0 RO LWT-OAT Delta
FREECOOL_mc_pwr_a AV 144 0 RO Mechanical Cooling Power
FREECOOL_fc_pwr_a AV 145 0 RO Free Cooling Maxi Power
