Carrier AQUASNAP 30RA010-055 Operation manual

Copyright 2009 Carrier Corporation Form 30RA-5PD
The AquaSnap chiller is an effective all-
in-one package that is easy to install
and easy to own. AquaSnap chillers
cost less to purchase and install, and
operate quietly and efficiently. Value-
added features include:
• Scroll compression
• Low profile construction
• Quiet AeroAcoustic™ fan system
• Easy to use ComfortLink™ controls
• Integrated hydronic pump package
• Accessory fluid storage tank
Features/Benefits
Carrier’s superior chiller
design provides savings at
initial purchase, at installa-
tion, and for years afterward.
Costs less right from the start
Only Carrier’s AquaSnap chillers fea-
ture a compact, all-in-one package de-
sign that installs quickly and easily on
the ground or the rooftop. The option-
al pump and hydronic components are
already built in; this costs less than buy-
ing and installing the components indi-
vidually. The chiller’s fully integrated
and pre-assembled hydronic system in-
stalls in minutes. No other chiller in
this class installs so easily and inexpen-
sively. The preassembled and integrat-
ed hydronic module utilizes top-quality
components and pumps to ensure
years of reliable operation. Use of the
optional fluid storage tank reduces in-
stallation costs and ensures sufficient
fluid volume is available for close-cou-
pled and process cooling applications.
The AquaSnap unit’s high efficiency
keeps costs down.
AQUASNAP®
30RA010-055
Air-Cooled Chillers
10 to 55 Nominal Tons
(25 to 200 kW)
Product
Data

2
AquaSnap®chillers make
noise in the marketplace, not
the workplace.
The AquaSnap chiller’s AeroAcous-
tic™ fan is almost twice as quiet as the
competition’s per cfm, which makes
AquaSnap chillers ideal for sound-
sensitive environments. When lower
ambient temperatures allow part-load
operation or during scheduled night-
time operation, the units operate with
fewer fans and become even quieter.
AquaSnap chillers are quiet during the
day and even quieter at night.
The fan is mounted to an extremely
rigid tower, which further reduces
vibrations and noise by preventing
them from being amplified through the
unit’s casing.
The savings will continue to
mount
Besides costing less to buy and install,
AquaSnap chillers are also more af-
fordable to operate. They are very effi-
cient air-cooled models, with full-load
EER (Energy Efficiency Ratio) up to
10.1. AquaSnap chillers use ultraquiet,
high-efficiency scroll compressors, op-
erated in tandem for greater efficiency
at partial loads.
Proven reliability that’s built in
Thousands of AquaSnap chillers are
already in service around the world.
This field-proven design is backed by a
12-month warranty that includes the
hydronic system. The compressors are
maintenance-free and protected by an
auto-adaptive control that minimizes
compressor wear. Unit sizes 035 and
up have two independent refrigerant
circuits. Year-round operation is
standard, from –20 F (–29 C) (with
optional cooler heater and low ambient
control) to 125 F (52 C).
ComfortLinkTM controls speak
your language
The ComfortLink controls communi-
cate in plain English, making it as easy
as possible to monitor and control
each AquaSnap chiller while accurately
maintaining fluid temperatures. The
large scrolling marquee display acts as
a window into the unit’s operation,
providing easy-to-read information
about chiller performance and over
15 diagnostic functions. Carrier 30
Series chillers’ ComfortLink controls
provide features such as chilled water
temperature reset, demand limiting,
compressor wear minimization and
protection, temperature and pressure
displays and diagnostic functions.
These controls result in higher chiller
reliability, simplified training and more
productive service calls with corre-
spondingly lower operational and
maintenance costs.
Carrier’s exclusive handheld
Navigator™ display provides conve-
nience and powerful information in the
palm of your hand. The Navigator
display helps technicians to quickly
diagnose problems and even prevent
them from occurring.
All AquaSnap units are ready to
be used with the Carrier Comfort
Network®(CCN) system.
AquaSnap units minimize the
impact on your roofline, as
well as your bottom line
The AquaSnap chiller’s low profile —
all models are just 4'-4" (1321 mm)
high — means it will not stand out if in-
stalled on the roof. The other dimen-
sions are equally compact. The inte-
grated hydronics and the chilled fluid
storage tank’s placement under the
chiller further minimize the footprint,
allowing easy installation almost any-
where.
Features/Benefits (cont)

3
Table of contents
Page
Features/Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Model Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ARI Capacity Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
Options and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8,9
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-18
Selection Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-25
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26,27
Typical Piping and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28,29
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30-32
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33,34
Typical Control Wiring Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35-37
Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38-43
Guide Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44-48
Run Status
Service Test
Temperature
Pressures
Setpoints
Inputs
Outputs
Configuration
Time Clock
Operating Modes
Alarms
Alarm Status
ENTER
MODE
ESCAPE
PROPELLER FAN
AEROACOUSTIC FAN
1/3 OCTAVE BAND CENTER FREQUENCY (Hz)
SOUND POWER [dB(A)]
AEROACOUSTIC™ FAN vs. PROPELLER FAN
PENETRATES BUILDING
STRUCTURE
25 40 63 130 168 250 400 630 1080 1600 2400 4000 6300 8000
90
85
80
75
70
65
60
55
50
Run Status
Service Tes t
Temperatures
Pressures
Setpoints
Inputs
Outputs
Configuration
Time Clock
Operating Modes
Alarms
ENTER
ESC
MODE
Alarm Status
ComfortLink
SCROLLING MARQUEE DISPLAY
NAVIGATOR™ DISPLAY MODULE
OPTIONAL HYDRONIC PACKAGE
LOW-NOISE AEROACOUSTIC FAN
WITH NIGHTTIME LOW SOUND
AEROACOUSTIC FAN VS PROPELLER FAN

4
ARI* capacity ratings
LEGEND
* Air Conditioning and Refrigeration Institute.
NOTE: Based on ARI-550/590 standard rating conditions. Ratings are for
standard chillers only. Ratings do not include options.
UNIT
30RA
CAPACITY COMPRESSOR
POWER INPUT
(kW)
FAN
POWER
(kW)
TOTAL
POWER
(kW)
FULL LOAD IPLV COOLER FLOW
RATE
COOLER
WATER
PRESSURE
DROP
Tons kW EER COP EER COP GPM L/s Ft wg kPa
010 9.6 33.7 9.7 1.9 11.7 9.8 2.9 12.9 3.8 22.9 1.4 5.6 16.7
015 13.7 48.1 14.8 1.9 16.8 9.8 2.9 12.8 3.7 33.0 2.1 6.8 20.3
018 15.9 55.9 18.0 1.9 20.0 9.6 2.8 13.4 3.9 38.2 2.4 7.5 22.4
022 21.1 74.2 23.4 1.7 25.2 10.0 2.9 14.1 4.1 50.6 3.2 9.7 29.0
025 23.8 83.6 27.9 1.7 29.7 9.6 2.8 13.9 4.1 57.1 3.6 10.7 32.0
030 27.2 95.6 31.7 1.7 33.5 9.8 2.9 14.0 4.1 65.3 4.1 12.6 37.7
035 34.8 122.3 37.8 3.6 41.5 10.1 2.9 14.5 4.2 83.4 5.3 7.7 23.0
040 37.7 132.5 42.8 3.6 46.6 9.7 2.8 13.6 4.0 90.6 5.7 8.2 24.5
045 43.1 151.5 47.5 3.4 51.1 10.1 3.0 15.2 4.4 103.4 6.5 11.2 33.5
050 47.4 166.6 55.8 3.4 59.4 9.6 2.8 14.1 4.1 113.8 7.2 12.1 36.2
055 54.3 190.8 63.4 3.4 67.0 9.7 2.8 14.1 4.1 130.4 8.2 14.3 42.7
COP — Coefficient of Performance
EER — Energy Efficiency Ratio
IPLV — Integrated Part Load Value
Model number nomenclature
Voltage
1–575-3-60
2–380-3-60
4–230-3-60
5–208/230-3-60
6–460-3-60
Compressor Start Option
N– Standard Across-the-Line Start Packaging
1 – Standard Domestic (Coil Cover and
Bottom Skid)
3–Standard Export with Coil Cover,
Top and Bottom Skid & Shipping Bag
4–Full Export Crate
5–Option #1 with Factory-Installed Coil Grilles
7–Option #3with Factory-Installed Coil Grilles
8–Option #4 with Factory-Installed Coil Grilles
30 R A N 0 1 0 – – – 6 1 1 – –
38RA – Air-Cooled AquaSnap Chiller
Unit Sizes
010 025
040 055
015 030
018
045
022 035
050
Chilled Fluid Pump Options
––No pump installed
A–Single Pump, 1.5 HP
B–Single Pump, 2 HP
C – Single Pump, 2 HP High Head
D–Single Pump, 3HP
E–Single Pump, 5 HP
F–Dual Pump, 1.5 HP
G–Dual Pump, 2 HP
H–Dual Pump, 2 HP High Head
J–Dual Pump, 3HP
K–Dual Pump, 5 HP
Factory-Installed Options(FIOP)
Series– 1
Display, Energy Management, GFI Option
––Standard Scrolling Marquee (SM) Display
E–SM + EMM
S–SM + EMM + GFI Convenience Outlet
(120 Volt, 4 Amp) [1,4,5,6 VoltagesOnly)
Condenser Coil Options
––Standard Copper Tube/Aluminum Fin
C– Copper Tube/Copper Fin, Copper Tube Sheet/Mylar
Coil Separator
E–Copper Tube/Aluminum Fin with E-Coat
F–Copper Tube/Copper Fin, Copper Tube Sheet,
Mylar Separator with E-Coat
K– Copper Tube/Aluminum Fin Precoated
AQUASNAP®CHILLER MODEL NUMBER DESIGNATION
LEGEND
EMM — Energy Management Module
GFI — Ground Fault Interrupting
Quality Assurance
Certified to ISO 9001: 2000
a30-4595

5
ENGLISH
SI
LEGEND
TXV — Thermostatic Expansion Valve
*Flow switch and strainer are standard on all units, with or without hydronic package.
UNIT 30RA 010 015 018 022 025 030 035 040 045 050 055
REFRIGERANT TYPE R-22, TXV Controlled System
Refrigerant Charge (lb) Ckt A/Ckt B 16/— 24/— 31/— 40/— 45/— 55/— 44/30 45/30 44/44 45/45 55/55
COMPRESSORS Scroll, Hermetic
Quantity 11222233444
Speed (Rpm) 3500
(Qty) Ckt A (1) SM125 (1) SM185 (2) SM110 (1) SM115,
(1) SM160 (2) SM160 (2) SM185 (1) SM115, (1) SM160 (2) SM160 (1) SM125, (1) SM160 (2) SM160 (2) SM185
(Qty) Ckt B ——————(1)SM185(1)SM185 (1) SM125,
(1) SM160 (2) SM160 (2) SM185
Oil Charge (Compressor/Pt) SM110/5.7, SM115/6.7, SM125/6.7, SM160/7.0, SM185/11.6
No. Capacity Steps
Standard 11222233444
Optional (Maximum) 22333344555
Minimum Capacity Step (%)
Standard 100 100 50 41 50 50 25 32 22 25 25
Optional 69 79 32 27 38 39 16 24 15 19 20
COOLER Welded, Direct-Expansion Plate Heat Exchanger
Net Fluid Volume (gal) 1.12 1.61 1.86 2.41 2.84 3.40 6.30 7.00 6.55 7.44 8.56
Maximum Refrigerant Pressure (psig) 450 450 450 450 450 450 450 450 450 450 450
Maximum Water Side Pressure
Without Pump(s) (psig) 150 150 150 150 150 150 150 150 150 150 150
Maximum Water Side Pressure
With Pump(s) (psig) 150 150 150 150 150 150 150 150 150 150 150
WATER CONNECTIONS (in.)
Inlet and Outlet, FPT 2222222
1/221/221/221/221/2
Drain (NPT) 1/21/21/21/21/21/21/21/21/21/21/2
CONDENSER FANS
Standard Low Noise Type
Fan Speed (Rpm) Standard/Low Noise 1140/570 1140/570 1140/570 —/850 —/850 —/850 —/850 —/850 —/850 —/850 —/850
No. Blades...Diameter (in.) Ckt A/Ckt B 15...30/— 15...30/— 15...30/— 11...30/— 11...30/— 11...30/— 11...30/
11...30
11...30/
11...30
11...30/
11...30
11...30/
11...30
11...30/
11...30
No. Fans...Total kW 1...1.8 1...1.8 1...1.8 2...2.0 2...2.0 2...2.0 2...2.0 (A),
1...1.8 (B)
2...2.0 (A),
1...1.8 (B) 4...4.0 4...4.0 4...4.0
Total Airflow (Cfm) 10,500 10,500 10,500 13,600 13,600 14,500 21,000 21,000 27,300 27,300 29,000
CONDENSER COILS
Quantity...No. Rows 1...2 1...3 1...3 1...3 1...3 1...3 2...3 2...3 2...3 2...3 2...3
Total Face Area (sq ft) 23 23 23 32 32 40 55 55 64 64 80
HYDRONIC MODULE (Optional)* Pump(s), Strainer with Blowdown Valve, Expansion Tank, Pressure Taps, Drain and Vent Plugs, Flow Switch, and Balance Valve
Pump Single or Dual, Centrifugal Monocell Pump(s), 3500 Rpm
Expansion Tank Volume (gal)
Total/Acceptance 5.0/2.9 10.0/5.5
UNIT 30RA 010 015 018 022 025 030 035 040 045 050 055
REFRIGERANT TYPE R-22, TXV Controlled System
Refrigerant Charge (kg) Ckt A/Ckt B 7.3/— 10.9/— 14.1/— 18.2/— 20.5/— 22.7/— 20.0/13.6 20.4/13.6 20.0/20.0 20.4/20.4 25.0/25.0
COMPRESSORS Scroll, Hermetic
Quantity 11222233444
Speed (r/s) 58.3
(Qty) Ckt A (1) SM125 (1) SM185 (2) SM110 (1) SM115,
(1) SM160 (2) SM160 (2) SM185 (1) SM115, (1) SM160 (2) SM160 (1) SM125, (1) SM160 (2) SM160 (2) SM185
(Qty) Ckt B ——————(1)SM185(1)SM185 (1) SM125,
(1) SM160 (2) SM160 (2) SM185
Oil Charge (Compressor/Pt) SM110/5.7, SM115/6.7, SM125/6.7, SM160/7.0, SM185/11.6
No. Capacity Steps
Standard 11222233444
Optional (Maximum) 22333344555
Minimum Capacity Step (%)
Standard 100 100 50 42 50 50 25 32 22 25 25
Optional 69 79 32 27 38 39 16 24 15 19 20
COOLER Welded, Direct-Expansion Plate Heat Exchanger
Net Fluid Volume (L) 4.22 6.08 7.03 9.12 10.75 12.84 23.84 26.49 24.79 28.12 32.34
Maximum Refrigerant Pressure (kPa) 3103 3103 3103 3103 3103 3103 3103 3103 3103 3103 3103
Maximum Water Side Pressure
Without Pump(s) (kPa) 1034 1034 1034 1034 1034 1034 1034 1034 1034 1034 1034
Maximum Water Side Pressure
With Pump(s) (kPa) 1034 1034 1034 1034 1034 1034 1034 1034 1034 1034 1034
WATER CONNECTIONS (mm)
Inlet and Outlet, FPT 50.8 50.8 50.8 50.8 50.8 50.8 63.5 63.5 63.5 63.5 63.5
Drain (NPT) 12.7 12.7 12.7 12.7 12.7 12.7 12.7 12.7 12.7 12.7 12.7
CONDENSER FANS
Standard Low Noise Type
Fan Speed (r/s) Standard/Low Noise 19/9.5 19/9.5 19/9.5 —/14.2 —/14.2 —/14.2 —/14.2 —/14.2 —/14.2 —/14.2 —/14.2
No. Blades...Diameter (mm) Ckt A/Ckt B 15...762/— 15...762/— 15...762/— 11...762/— 11...762/— 11...762/— 11...762/
11...762
11...762/
11...762
11...762/
11...762
11...762/
11...762
11...762/
11...762
No. Fans...Total kW 1...1.8 1...1.8 1...1.8 2...2.0 2...2.0 2...2.0 2...2.0 (A),
1...1.8 (B)
2...2.0 (A),
1...1.8 (B) 4...4.0 4...4.0 4...4.0
Total Airflow (L/s) 4,955 4,955 4,955 6,419 6,419 6,843 9,595 9,595 12,884 12,884 13,687
CONDENSER COILS
Quantity...No. Rows 1...2 1...3 1...3 1...3 1...3 1...3 2...3 2...3 2...3 2...3 2...3
Total Face Area (sq m) 2.14 2.14 2.14 2.97 2.97 3.72 5.11 5.11 5.95 5.95 7.43
HYDRONIC MODULE (Optional)* Pump(s), Strainer with Blowdown Valve, Expansion Tank, Pressure Taps, Drain and Vent Plugs, Flow Switch, and Balance Valve
Pump Single or Dual, Centrifugal Monocell Pump(s), 58.3 r/s
Expansion Tank Volume (L)
Total/Acceptance 18.9/11.0 37.9/20.8
Physical data

6
UNIT WEIGHTS
STD UNITS
SINGLE PUMP UNITS
30RA
SIZE
POUNDS — ALUMINUM 30RA
SIZE
POUNDS — COPPER
ABCD Total
Weight ABCD Total Weight
010 182 210 255 299 946 010 194 231 274 326 1025
015 197 245 291 335 1068 015 216 280 321 382 1199
018 206 268 377 358 1209 018 220 303 411 404 1338
022 336 451 381 355 1523 022 364 521 418 410 1713
025 350 464 395 380 1589 025 380 532 432 436 1780
030 378 518 409 400 1705 030 409 606 441 474 1930
035 748 642 604 850 2844 035 854 721 691 958 3224
040 763 653 616 882 2914 040 869 731 702 992 3294
045 860 709 746 903 3218 045 965 790 833 1011 3599
050 876 721 770 946 3313 050 978 805 859 1051 3693
055 977 753 831 954 3515 055 1096 857 931 1082 3966
30RA
SIZE
KILOGRAMS — ALUMINUM 30RA
SIZE
KILOGRAMS — COPPER
ABCD Total
Weight ABCD Total Weight
010 83 95 116 136 430 010 88 105 124 148 465
015 89 111 132 152 484 015 98 127 146 173 544
018 93 122 171 162 548 018 100 137 186 183 606
022 152 205 173 161 691 022 165 236 190 186 777
025 159 210 179 172 720 025 172 241 196 198 807
030 171 235 186 181 773 030 186 275 200 215 876
035 339 291 274 386 1290 035 387 327 313 435 1462
040 346 296 279 400 1321 040 394 332 318 450 1494
045 390 322 338 410 1460 045 438 358 378 459 1633
050 397 327 349 429 1502 050 444 365 390 477 1676
055 443 342 377 433 1595 055 497 389 422 491 1799
30RA
SIZE
POUNDS — ALUMINUM 30RA
SIZE
POUNDS — COPPER
ABCD Total
Weight ABCD Total Weight
010 209 241 293 343 1086 010 221 262 312 370 1165
015 223 277 329 379 1208 015 242 312 359 426 1339
018 230 299 421 399 1349 018 244 334 455 445 1478
022 367 492 416 388 1663 022 395 562 453 443 1853
025 381 505 430 413 1729 025 411 573 467 469 1920
030 409 561 443 433 1845 030 440 649 475 507 2070
035 801 687 646 910 3044 035 907 766 733 1018 3424
040 815 698 658 943 3114 040 921 776 744 1053 3494
045 913 753 792 959 3418 045 1018 834 879 1067 3799
050 929 765 816 1003 3513 050 1031 849 905 1108 3893
055 1033 796 878 1008 3715 055 1152 900 978 1136 4166
30RA
SIZE
KILOGRAMS — ALUMINUM 30RA
SIZE
KILOGRAMS — COPPER
ABCD Total
Weight ABCD Total Weight
010 95 109 133 156 493 010 108 129 152 181 570
015 101 126 149 172 548 015 117 151 174 206 648
018 104 136 191 181 612 018 117 161 218 215 711
022 166 224 189 176 755 022 187 268 215 211 881
025 173 229 195 187 784 025 194 272 221 224 911
030 185 254 201 196 836 030 208 308 224 241 981
035 363 311 293 413 1380 035 422 356 341 474 1593
040 370 316 298 427 1411 040 429 361 346 490 1626
045 414 342 359 435 1550 045 473 387 408 496 1764
050 421 347 370 455 1593 050 479 394 421 514 1808
055 468 361 398 458 1685 055 533 417 453 527 1930
Physical data (cont)
CONTROL
BOX END
B
C
A
D
a30-4596

7
UNIT WEIGHTS (cont)
DUAL PUMP UNITS
PUMP IMPELLER SIZES
30RA
SIZE
POUNDS — ALUMINUM 30RA
SIZE
POUNDS — COPPER
ABCD Total
Weight ABCD Total Weight
010 226 262 316 372 1176 010 238 283 335 399 1255
015 238 299 353 408 1298 015 257 334 383 455 1429
018 244 320 448 427 1439 018 258 355 482 473 1568
022 385 521 437 410 1753 022 413 591 474 465 1943
025 399 533 451 436 1819 025 429 601 488 492 2010
030 427 590 462 456 1935 030 458 678 494 530 2160
035 825 707 666 936 3134 035 931 786 753 1044 3514
040 840 717 678 969 3204 040 946 795 764 1079 3584
045 938 773 813 984 3508 045 1043 854 900 1092 3889
050 953 784 837 1029 3603 050 1055 868 926 1134 3983
055 1057 816 899 1033 3805 055 1176 920 999 1161 4256
30RA
SIZE
KILOGRAMS — ALUMINUM 30RA
SIZE
KILOGRAMS — COPPER
ABCD Total
Weight ABCD Total Weight
010 103 119 144 169 535 010 108 129 152 181 570
015 108 135 160 185 588 015 117 151 174 206 648
018 110 146 203 194 653 018 117 161 218 215 711
022 174 237 198 186 795 022 187 268 215 211 881
025 181 241 204 198 824 025 194 272 221 224 911
030 193 268 210 207 878 030 208 308 224 241 981
035 374 320 302 425 1421 035 422 356 341 474 1593
040 381 325 307 440 1453 040 429 361 346 490 1626
045 425 351 368 447 1591 045 473 387 408 496 1764
050 432 356 380 466 1634 050 479 394 421 514 1808
055 479 370 408 469 1726 055 533 417 453 527 1930
CONTROL
BOX END
B
C
A
D
PUMP OPTION PUMP DIAMETER (in.)
A,F 3/4AAB 4.25
B,G 11/4AAB 3.88
C,H 3/4AAB 4.75
D,J 11/4AAB 4.50
E,K 11/2AAB 4.63

8
LEGEND
Factory-installed options
Hydronic pump package — This option adds circulat-
ing pumps, complete with controls, contactor, and insu-
lated expansion tank. Available in single or dual (lead/lag
controlled) cooler pump versions, with total dynamic head
external to the chiller from approximately 15 to 75 feet.
Low ambient protection package — Cooler heaters
provide protection from cooler freeze-up to –20 F (–29 C).
Includes low ambient protection for optional hydronic
package, when provided.
Energy management module — This module provides
energy management capabilities to minimize chiller energy
consumption. Several features are provided with this mod-
ule including leaving fluid temperature reset, cooling set
point reset or demand limit control from a 4 to 20 mA sig-
nal, 2-point demand limit control (from 0 to 100%) acti-
vated by a remote contact closure, and discrete input for
“Ice Done” indication for ice storage system interface.
GFI convenience outlet — The factory installed con-
venience outlet includes 4-amp GFI (ground fault inter-
rupter) receptacle with independent fuse protection.
Convenience outlet is 115-v female receptacle.
Low-ambient Motormaster® V control — This option
permits operation of the 30RA units down to –20 F
(–29 C) outdoor ambient temperature. The control is also
available as a field-installed accessory. Also requires
field-installed wind baffles, minimum load control, and the
liquid line solenoid accessory.
Non-fused disconnect — This option provides non-
fused disconnect capability for power and control located
at the unit.
Minimum load control — This option allows additional
capacity reduction for unit operation below the minimum
step of unloading (down to 15% of the minimum unit
capacity, depending on unit size). Minimum load control is
also available as a field-installed accessory.
Condenser coil options — These options are available
to match coil construction to the site conditions for the best
durability. Refer to the Environmental Corrosion Protec-
tion white paper for more information.
Security grilles — One-in. by four-in. coated wire grille
protects condenser coil from damage.
Medium temperature brine — This option permits
supply liquid temperatures to be set from 15 F (–9.4 C) to
40 F (4.4 C). Refrigeration circuit components, such as the
expansion device, are modified at the factory to adjust for
lower refrigerant flow rates. The use of this option also
requires the addition of the Motormaster V low ambient
control, field-installed wind baffles or accessory wind baffle
kit, minimum load control, and the accessory liquid line
solenoid.
ITEM FACTORY-INSTALLED
OPTION
FIELD-INSTALLED
ACCESSORY
Hydronic Pump Package X
Enviro-Shield™ System Condenser Coil Protection Options X
Copper Fins X
Aluminum Fins, E-coat X
Copper Fins, E-coat X
Aluminum Fins, Pre-coated X
Medium Temperature Brine, 15 F to 40 F LBT X
Non-Fused Disconnect X
Low-Ambient Protection Package (Cooler Heater) X
Motormaster® V Low-Ambient Control XX
Minimum Load Control XX
Security Grilles XX
Hail Guards X
Navigator™ Hand Held Display X
Control Display Access Door X
Remote Enhanced Display X
Chillervisor System Manager III Multi-Unit Control X
GFI Convenience Outlet XX
Energy Management Module (EMM) XX
Vibration Isolation X
Chilled Water Storage Tank X
Touch Pilot™ Display X
LON Translator Control X
BACnet™ Modbus Translator Control X
Liquid Line Solenoid Kit X
Wind Baffle Kit X
GFI —Ground Fault Interrupter
LBT—Leaving Brine Temperature
Options and accessories

9
Field-installed accessories
Minimum load control — This option allows additional
capacity reduction for unit operation below the minimum
step of unloading (down to 15% of the minimum unit
capacity). Minimum load control is also available as a
factory-installed option.
Control display access door — This option provides
easy access to the unit control module through a
see-through door without having to open the control box
panels.
Navigator™ display module — Provides a portable,
hand held display module for convenient access to unit
status, operation, configuration and troubleshooting diag-
nostics capability. The 4-line, 80-character LCD display
provides clear language information in English, French,
Spanish or Portuguese. The weatherproof enclosure and
industrial grade extension cord makes the Navigator ideally
suited for outdoor applications. Magnets located on the
back of the module allow attachment of any sheet metal
component for hands free operation.
Remote enhanced display — This accessory kit con-
tains a remotely mounted 40-character per line, 16-line
display panel for unit diagnostics.
Chillervisor System Manager III multi-unit control
—This accessory allows sequencing of between 2 and
8 chillers in parallel or 2 chillers in series. Pump control is
also provided.
Hail guards — Sheet metal hood provides protection
against hail and flying debris damage.
Security grilles — One-in. x 4-in. coated wire grille pro-
tects condenser coil from damage.
Low ambient Motormaster®V head pressure con-
trol — Permits starting and operating down to –20 F
(–29 C) outside ambient temperature. This control is also
available as a factory-installed option. Requires field-
installed wind baffles, minimum load control, and acces-
sory liquid line solenoid.
Liquid line solenoid kit — The kit provides a liquid line
solenoid valve (per refrigerant circuit) which causes a
complete liquid line shutoff when the chiller is shut down.
This accessory is required when the medium temperature
brine option or the Motormaster V are used.
Wind baffle kit — This kit provides a factory designed
wind baffle for applications requiring protection. Field-
installed wind baffles are required when the Motormaster V
is used.
Energy management module — This module provides
energy management capabilities to minimize chiller energy
consumption. Several features are provided with this mod-
ule including leaving fluid temperature reset, cooling set
point reset or demand limit control from a 4 to 20 mA
signal; 2-point demand limit control (from 0 to 100%)
activated by a remote contact closure; and discrete input
for “Ice Done” indication for ice storage system interface.
GFI convenience outlet — The field-installed conve-
nience outlet includes 4-amp GFI (Ground Fault Inter-
rupter) receptacle with independent fuse protection.
Convenience outlet is 115-v female receptacle.
Chilled water storage tank — Provides additional loop
volume for improved temperature control and chilled water
loop stability. Will provide up to 6 gallons per ton. Heater
supplied (additional 230-1-60 field power supply required)
to protect to –20 F (–29 C).
Vibration isolation — The field-installed 1/4-in. neo-
prene isolator pads (24-in. x 3-in.) reduce vibration trans-
mission from the compressor through the floor and into
the conditioned space.
BACnet translator control — The control provides an
interface between the chiller and a BACnet Local Area
Network (LAN, i.e., MS/TP EIA-485).
LON translator control — The control provides an
interface between the chiller and a Local Operating Net-
work (LON, i.e., LonWorks FT-10A ANSI/EIA-709.1).
Touch Pilot™ display — The display, when used as an
accessory, is a cost-effective, touch-screen, remote-mount
device that can be used in lieu of the remote enhanced
display.
CONDENSER COIL CORROSION PROTECTION OPTIONS
LEGEND
*See page 42 for further description, also see “Environmental Corrosion Protection” white paper for more information (Publication 04-581006-01).
ENVIRO-SHIELD™
OPTION*
ENVIRONMENT
Standard Mild
Coastal
Moderate
Coastal
Severe
Coastal Industrial Combined Industrial/Coastal
AL Fins (Standard Coils) X
CU Fins XX
AL Fins, E-coat XX X
CU Fins, E-coat X
AL Fins, Precoated X
AL — Aluminum
CU — Copper

10
Dimensions — 30RA010,015,018
a30-4597
NOTES:
1. Unit must have clearances for airflow as follows:
TOP — Do not restrict in any way COIL SIDE — 3 1/2 ft [1067 mm] from solid surface OTHER SIDE AND ENDS — 3 ft [914 mm] from solid surface (for service access)
2. Coil side clearance with accessory hail guard
installed is 3 ft [914 mm] to outside edge of hail guard top panel.
3. Coil side clearance for multiple chiller installation is
6 ft [1981 mm].
4. Flow switch and strainer are factory installed in
entering fluid piping.
5. Dimensions in [ ] are in mm.

11
Dimensions — 30RA022,025
a30-4598
NOTES:
1. Unit must have clearances for airflow as follows:
TOP — Do not restrict in any way COIL SIDE — 3 1/2 ft [1067 mm] from solid surface OTHER SIDE AND ENDS — 3 ft [914 mm] from solid surface (for service access)
2. Coil side clearance with accessory hail guard
installed is 3 ft [914 mm] to outside edge of hail guard top panel.
3. Coil side clearance for multiple chiller installation is
6 ft [1981 mm].
4. Flow switch and strainer are factory installed in
entering fluid piping.
5. Dimensions in [ ] are in mm.

12
Dimensions — 30RA030
a30-4599
NOTES:
1. Unit must have clearances for airflow as follows:
TOP — Do not restrict in any way COIL SIDE — 3 1/2 ft [1067 mm] from solid surface OTHER SIDE AND ENDS — 3 ft [914 mm] from solid surface (for service access)
2. Coil side clearance with accessory hail guard
installed is 3 ft [914 mm] to outside edge of hail guard top panel.
3. Coil side clearance for multiple chiller installation is
6 ft [1981 mm].
4. Flow switch and strainer are factory installed in
entering fluid piping.
5. Dimensions in [ ] are in mm.

13
Dimensions — 30RA035,040
NOTES:
1. Unit must have clearances for airflow as follows:
TOP — Do not restrict in any way COIL SIDE — 3 1/2 ft [1067 mm] from solid surface OTHER SIDE AND ENDS — 3 ft [914 mm] from solid surface (for service access)
2. Coil side clearance with accessory hail guard
installed is 3 ft [914 mm] to outside edge of hail guard top panel.
3. Coil side clearance for multiple chiller installation is
6 ft [1981 mm].
4. Strainer is factory installed in entering fluid piping.
Flow switch is factory installed in the leaving fluid piping.
5. Dimensions in [ ] are in mm.

14
Dimensions — 30RA045,050
a30-4601
NOTES:
1. Unit must have clearances for airflow as follows:
TOP — Do not restrict in any way COIL SIDE — 3 1/2 ft [1067 mm] from solid surface OTHER SIDE AND ENDS — 3 ft [914 mm] from solid surface (for service access)
2. Coil side clearance with accessory hail guard
installed is 3 ft [914 mm] to outside edge of hail guard top panel.
3. Coil side clearance for multiple chiller installation is
6 ft [1981 mm].
4. Strainer is factory installed in entering fluid piping.
Flow switch is factory installed in the leaving fluid piping.
5. Dimensions in [ ] are in mm.

15
Dimensions — 30RA055
a30-4602
NOTES:
1. Unit must have clearances for airflow as follows:
TOP — Do not restrict in any way COIL SIDE — 3 1/2 ft [1067 mm] from solid surface OTHER SIDE AND ENDS — 3 ft [914 mm] from solid surface (for service access)
2. Coil side clearance with accessory hail guard
installed is 3 ft [914 mm] to outside edge of hail guard top panel.
3. Coil side clearance for multiple chiller installation is
6 ft [1981 mm].
4. Strainer is factory installed in entering fluid piping.
Flow switch is factory installed in the leaving fluid piping.
5. Dimensions in [ ] are in mm.

16
Dimensions — storage tank 30RA010-018
a30-4603

17
Dimensions — storage tank 30RA022-030
a30-4604

18
Dimensions — storage tank 30RA035-055
a30-4605

19
Carrier’s electronic catalog chiller selection program pro-
vides quick, easy selection of Carrier chillers. The program
considers specific temperature, fluid, and flow require-
ments and other factors, such as fouling and altitude
correction.
To select a 30RA chiller, use the electronic catalog or
follow one of the procedures below.
ENGLISH EXAMPLE
I Determine 30RA unit size and operating
conditions required to meet given capacity at
given conditions.
Given:
Capacity. . . . . . . . . . . . . . . . . . . . . . . . . 43 Tons
Leaving Chilled Water Temp (LCWT) . . . . . . .44 F
Cooler Water Temp Rise . . . . . . . . . . . . . . . 10° F
Condenser Entering Air Temp . . . . . . . . . . . .95 F
Fouling Factor (Cooler) . . . . . . . . . . . . . .0.00010
NOTE: For other than 10° F temperature rise, data
corrections must be made using the chiller program
in the electronic catalog.
II From Chiller Ratings table on page 26 and
pressure drop curves on page 23, determine
operating data for selected unit.
Unit . . . . . . . . . . . . . . . . 30RA-045 (single pump)
Capacity. . . . . . . . . . . . . . . . . . . . . . . .43.1 Tons
Chiller Power Input . . . . . . . . . . . . . . . . .51.1 kW
Cooler Water Flow . . . . . . . . . . . . . . . 103.3 gpm
Internal Pressure Drop. . . . . . . . . .20.5 ft of water
III Single pump selection. (See AquaSnap®
pump selection on page 20.)
Required GPM (from above) . . . . . . . . . 103.3 gpm
Chiller Pressure Drop
(from chart on page 23) . . . . . . . . . . 20.5 ft wg
Additional External System
Pressure Drop (from jobsite) . . . . . . . . . 40 ft wg
Add Chiller Pressure and External
Pressure Drop . . . . . . . . . . . . . . . . . 60.5 ft wg
Using Pump Curve on page 21
Select . . . . . . . . . . Pump E at 103.1, 60.5 ft wg
To find pump horsepower, follow the 4.63-in. im-
peller curve for pump E on page 21.
Hp: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6 bhp
Max hp = 5 hp, therefore necessary hp does not ex-
ceed pump rating.
SI EXAMPLE
I Determine unit size and operating conditions
required to meet given capacity at given
conditions.
Given:
Capacity. . . . . . . . . . . . . . . . . . . . . . . . . 160 kW
Leaving Chilled Water Temp (LCWT) . . . . . . . 6 C
Cooler Water Temp Rise . . . . . . . . . . . . . . 5.6° C
Condenser Entering Air Temp . . . . . . . . . . . 35 C
Fouling Factor (Cooler) . . . . . . . . . . . . .0.000018
NOTE: For other than 6° C temperature rise, data
corrections must be made using the chiller program
in the electronic catalog.
II From Chiller Ratings table on page 27 and
pressure drop curves on page 23, determine
operating data for selected unit.
Unit . . . . . . . . . . . . . . . . 30RA-050 (single pump)
Capacity. . . . . . . . . . . . . . . . . . . . . . . .163.4 kW
Chiller Power Input . . . . . . . . . . . . . . . . .59.0 kW
Cooler Water Flow . . . . . . . . . . . . . . . . . .7.0 L/s
Chiller Pressure Drop . . . . . . . . . . . . . . 67.0 kPa
III Pump selection. (See AquaSnap pump selec-
tion on page 20.)
Required Flow
(from above) . . . . . . . . .7.0 x 3.6 = 25.2 m3/hr
Chiller Pressure Drop
(from chart on page 23) . . . . . . . . . . . 67.0 kPa
Additional External System
Pressure Drop (from jobsite) . . . . . . . . . 176 kPa
Add Chiller Pressure and External
Pressure Drop . . . . . .243 x .1018 = 24.7 m wg
Using Pump Curve on page 21
Select . . . Pump E at 25.2 m3/hr and 24.7 m wg
To find pump horsepower, follow the 4.63-in. im-
peller curve for pump E on page 21.
Hp: . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.86 bhp
Max hp = 5 hp, therefore necessary hp does not ex-
ceed pump rating.
Selection procedure

20
AquaSnap®pump selection
Several pump sizes are available for each AquaSnap chiller
size to provide flexibility in matching water system require-
ments. A dual pump option is also available for primary/
standby operation. The Carrier E-Cat Packaged AC Chiller
Builder can be used for pump selection, or selection can be
done manually.
Proper water system design is critical; cooling loads,
water pressure drops and proper water line sizing must be
accounted for in order to ensure proper system operation.
Incorrect or incomplete analysis/design of the water loop
could lead to low water flow, loss of water temperature
control, and excessive cycling of chiller compressors.
The following are the steps for manual selection of water
pumps for the 30RA chillers.
1. Calculate the water flow rate (gpm) and the total
water pressure drop of the system external to the
30RA chiller.
2. Determine the internal pressure drop of the chiller
hydronic package based on the design flow rate (refer
to internal Pressure Drop tables on page 22). Values
given in these charts are based on units with clean
strainers and circuit setter valve wide open.
NOTE: These pressure drops are for water. If glycol is
used, correct by multiplying by the factors below.
3. If an optional storage tank is used, determine the
internal pressure drop by referencing the internal
Pressure Drop tables on page 24.
NOTE: Note that these pressure drops are for water. If gly-
col is used, correct by multiplying by the factors below.
4. Add pressure drops found in Steps 1-3. This is the
total pressure drop and total head required by the
pump.
5. Use the pump envelope charts (page 25) to deter-
mine proper pump sizing. Plot water flow rate
(Step 1) and total head (Step 4), point on the chart.
The region containing the point corresponds to the
correct pump.
NOTE: Although pump bhp increases with glycol concen-
tration, pumps and pump overloads are selected such that
glycol concentrations up to 50% will not trip pump over-
loads if run within the recommended gpm ranges.
Example: Required water flow rate for a 30RA018
chiller is 45 gpm. The pressure drop in feet for the water
system external to the chiller is 50 feet. The system does
not have an accessory storage tank. The single pump is
needed. Select the pump.
Since the flow rate and external head losses (Step 1) are
known, the internal losses in the hydronic package must be
found (Step 2). Using the pressure drop graphs (page 22)
for the 30RA018 units, the internal loss at 45 gpm is
15 feet. Since no accessory storage tank is being used
(Step 3), the pressure drop is 0 feet.
Add all losses together (Step 4). The total pressure rise
needed by the pump is 50 + 15 + 0 = 65 feet. The pump
selection becomes pump C.
% GLYCOL ETHYLENE
GLYCOL
PROPYLENE
GLYCOL
0 (Pure Water) 11
10 1.062 1.077
20 1.114 1.168
30 1.177 1.271
40 1.248 1.393
50 1.316 1.543
Selection procedure (cont)
