Carrier Infinity SYSTXCCITW01 User manual

SYSTXCCITW01 &
SYSTXCCITN01
InfinityrTouch Control
Installation Instructions
NOTE: Read the entire instruction manual before starting the installation.
US Patents: CarrierrU.S. Pat No. 7,243,004, CarrierrU.S. Pat No. 7,775,452,
pointSETtU.S. Pat No. 7,415,102

TABLE OF CONTENTS
PAGE
1.Safety Considerations 1.............................................
2.Introduction 1.....................................................
3.Quick Start 2......................................................
3.1. Set Time and Date 2............................................
3.2. Set Dealer Information 3........................................
4.Installation 4......................................................
4.1. Overview 4...................................................
4.2. Check Equipment 4............................................
4.3. Location 5....................................................
4.3.1. Wall Control 5...........................................
4.3.2. Remote Room Sensors 6...................................
4.3.2.1.Remote Room Sensor Averaging 6...........................
4.3.3. Smart Sensors (for zoning applications) 7......................
4.4. Wiring Considerations 7.........................................
4.4.1. Shielded Wire 10.........................................
4.4.2. Damper Control Module 11.................................
4.5. Mounting 11..................................................
4.5.1. Decorative Backplate 12...................................
4.6. Humidifier Connections 13......................................

TABLE OF CONTENTS (cont.)
PAGE
4.6.1. Bypass Humidifier 13......................................
4.6.2. Fan Powered Humidifiers 13................................
5.Commissioning 14.................................................
5.1. Searching for Indoor Unit 14.....................................
5.2. Searching for Outdoor Unit 15....................................
5.3. Indoor Evaporator Selection 16...................................
5.4. Electric Heater Selection 16......................................
5.4.1. Hydronic Heat Application 17...............................
5.5. Searching SAM Module (If Applicable) 18..........................
5.6. Searching for Zones (If Applicable) 18.............................
5.7. Filter Type Selection 19.........................................
5.8. Humidifier Installation 19........................................
5.9. Ultraviolet Lights Installation 19..................................
5.10.Equipment Summary 29........................................
5.11.Static Pressure Check 20........................................
5.12.Duct Assessment (zoning applications only) 20......................
6.Service Menu 22...................................................
6.1. Equipment Summary 22.........................................
6.2. Installation 23.................................................
6.3. Set up 24.....................................................

TABLE OF CONTENTS (cont.)
PAGE
6.3.1. Thermostat 25............................................
6.3.1.1.Auto Mode set up 25......................................
6.3.1.2.Heat/Cool Deadband 26...................................
6.3.1.3.Offsets 26..............................................
6.3.1.4.Reset factory defaults 26...................................
6.3.1.5.Scheduling Enable 26.....................................
6.3.1.6.Smart Recovery Enable 27.................................
6.3.1.7.Temperature Units Display 27...............................
6.3.2. Fan Coil 27..............................................
6.3.2.1.Airflow 28..............................................
6.3.2.2.Altitude 28.............................................
6.3.2.3.Fan Coil Dehumidification 29...............................
6.3.2.4.Fan Coil G--Terminal 29...................................
6.3.3. Furnace 30..............................................
6.3.3.1.Furnace Airflow 30.......................................
6.3.3.2.AC/HP Air Flow 31.......................................
6.3.3.3.Furnace Staging 32.......................................
6.3.3.4.Furnace Airflow Limits (modulating furnace only) 32............
6.3.3.5.Furnace Off Delay 32.....................................
6.3.3.6.Altitude 33.............................................

TABLE OF CONTENTS (cont.)
PAGE
6.3.3.7.Furnace Dehumidifier Drain 33.............................
6.3.3.8.Furnace G Terminal 33....................................
6.3.4. AC/Heat Pump 34........................................
6.3.4.1.Cooling Lockout 35......................................
6.3.4.2.Defrost Interval 35.......................................
6.3.4.3.Low Ambient Cooling 36..................................
6.3.4.4.Quiet Shift 36...........................................
6.3.4.5.AC/Heat Pump RPM Max 36...............................
6.3.4.6.Defrost Fan Delay 36.....................................
6.3.4.7.Brownout Disable 37.....................................
6.3.4.8.Energy Efficiency 37......................................
6.3.5. Heat Source Lockout 37....................................
6.3.6. Zoning (If Applicable) 38...................................
6.3.6.1.Zoning Disable 39........................................
6.3.6.2.Zone Offsets 39..........................................
6.3.6.3.Zone Airflow Limits 39....................................
6.3.6.4.Duct Assessment Time 40..................................

TABLE OF CONTENTS (cont.)
PAGE
6.3.7. Accessories 40...........................................
6.3.7.1.Filter 41................................................
6.3.7.2.Humidifier 41...........................................
6.3.7.3.Ultraviolet Lights 42......................................
6.3.7.4.Ventilator 42............................................
6.3.8. Utility Curtailment 42......................................
6.3.9. Hydronic Airflow 43......................................
6.4. Check out 44.................................................
6.4.1. Electric Heat 44..........................................
6.4.2. Furnace 45..............................................
6.4.3. Hydronic 45.............................................
6.4.4. Air Conditioning 45.......................................
6.4.5. Heat Pump Heating 46.....................................
6.4.6. Heat Pump Cooling 47.....................................
6.4.7. Humidifier 47............................................
6.4.8. Ventilator 48.............................................
6.4.9. Zoning (If Applicable) 48...................................
6.4.9.1.Airflow Limits 48........................................
6.4.9.2.Damper/Sensor Check 48..................................

TABLE OF CONTENTS (cont.)
PAGE
6.4.9.3.Zone Duct Assessment 49..................................
6.4.9.4.Sensor Type 49..........................................
6.5. Service Information 49..........................................
6.5.1. Fan Coil Status 50........................................
6.5.2. Furnace Status 50.........................................
6.5.3. AC Status 51.............................................
6.5.4. Heat Pump Status 51......................................
6.5.5. Zoning Status 52..........................................
6.5.6. Last 10 System Faults 52...................................
6.5.7. Run/Fault History 53......................................
6.5.8. Model/Serial Numbers 54...................................
6.5.9. Service Phone Number 54..................................
6.5.10. Energy Tracking Watt Meter 54..............................
6.6. Refrigerant Charging 55.........................................
6.6.1. Charging 55.............................................
6.6.2. Pump down 56...........................................
6.6.3. Evacuation 57............................................
6.7. Dealer Logo 57................................................
7.Wireless Setup 58..................................................
8.Appendix A -- Wiring Diagrams 65....................................

1
1. Safety Considerations
Improper installation, adjustment, alteration, service, maintenance, or use can cause
explosion, fire, electrical shock, or other conditions which may cause death,
personal injury or property damage. Consult a qualified installer, service agency or
your distributor or branch for information or assistance. The qualified installer or
agency must use factory--authorized kits or accessories when modifying this
product. Refer to the individual instructions packaged with the kits or accessories
when installing.
Follow all safety codes. Wear safety glasses, protective clothing, and work gloves.
Have a fire extinguisher available. Read these instructions thoroughly and follow
all warnings and cautions included in literature and attached to the unit. Consult
local building codes and the current edition of the National Electrical Code (NEC)
NFPA 70. In Canada, refer to the current editions of the Canadian Electrical Code
CSA C22.1.
Recognize safety information. When you see this symbol on the unit and in
instructions or manuals, be alert to the potential for personal injury. Understand the
signal words DANGER,WARNING,andCAUTION. These words are used with
the safety--alert symbol. DANGER identifies the most serious hazards, which will
result in severe personal injury or death. WARNING signifies hazards, which could
result in personal injury or death. CAUTION is used to identify unsafe practices,
which may result in minor personal injury or product and property damage. NOTE
is used to highlight suggestions which will result in enhanced installation,
reliability, or operation.
2. Introduction
The InfinityrSystem consists of several intelligent communicating components
which includes the InfinityrTouch Control (or User Interface), variable speed
furnace or FE fan coil, and 2--stage AC or HP, which continually communicate with
each other via a four--wire connection called the ABCD bus. Commands, operating

2
conditions, and other data are passed continually between components over the
ABCD bus. The result is a new level of comfort, versatility, and simplicity.
All Infinityrfurnaces or fan coils are variable--speed and multi stage for maximum
flexibility, efficiency, and comfort. They support controlled ventilation,
humidification, dehumidification, and air quality control. Either an Infinityr
(communicating), or a standard single--stage 24VAC controlled outdoor unit may be
used.
When using conventional single--stage outdoor units, the Infinity furnace or fan coil
provides the 24 volt signals needed to control them. Also, the InfinityrNetwork
Interface Module (P/N SYSTXCCNIM01) allows connection of a Carrier HRV or
ERV without the need for separate wall control.
When using a Carrier HRV or ERV with a zoned system, the InfinityrZone board
allows connection of a Carrier HRV or ERV without the need for separate wall
control.
All system components are controlled through the wall mounted Infinity Touch
Control, which replaces the conventional thermostat and provides the homeowner
with a single wall control for all features of the system.
3. Quick Start
3.1. Set Time and Date
From the main screen, touch MENU, on the bottom of the control. The
TIME/DATE icon allows you to set the time and date for the InfinityrTouch
Control.
dTo set the HOUR, MINUTE, MONTH, DAY, or YEAR touch the feature
you wish to change.
dUse the Up (Y) and Down (B) buttons to make the appropriate changes.
dWhen you have completed all of the settings touch SAVE.

3
dIf you make a mistake you may touch CANCEL and begin again.
A12175
3.2. Set Dealer Information
From the main screen, touch MENU, on the bottom of the control. The SERVICE
icon allows you to upload your contact information into the Infinity Touch Control.
A12176
SFormat your contact information and logo (if applicable) using the PC/MAC
application, save it to a standard USB drive. See Section 6.7.
STouch the SERVICE icon for about 10 seconds, then touch DEALER LOGO
UPLOAD.
SPlace the USB drive into the USB port on the bottom of the Infinity Touch
Control and follow the on screen prompts.

4
SMore detailed information can be found on HVACPartners.com under the
Product tab> Thermostats & Controls> SYSTXCCITW01> Documents &
Downloads> Marketing/Miscellaneous> Infinity Touch Control Dealer Logo
Application -- Instructions.
4. Installation
4.1. Overview
This instruction covers installation of the InfinityrTouch Control and the Infinityr
Wireless Access Point only. Physical installation instructions for the indoor and
outdoor equipment, and accessories are provided with each unit.
Setup, commissioning, operation, and troubleshooting of the InfinityrSystem are
covered only in this installation instruction. It is the guide to connecting the system
components and commissioning the system once all physical components are
installed. Special screen prompts and start--up capabilities are provided in the
InfinityrSystem to simplify and automate the initial commissioning of the system.
SInstall the Infinity Touch Control according to this instruction.
SInstall indoor unit, outdoor unit, and accessories according to their instructions.
SWire complete system according to this instruction.
SSetup, commission, and operate system according to this instruction to assure a
smooth and trouble free start--up.
4.2. Check Equipment
Inspect equipment. File a claim with shipping company prior to installation if
shipment is damaged or incomplete.

5
4.3. Location
ELECTRICAL OPERATION HAZARD
Failure to follow this warning could result in personal injury
or death.
Disconnect power before routing control wiring.
!WARNING
All wiring must comply with national, local, and state codes.
4.3.1. Wall Control
The Infinity Touch Control is the command center for the Infinity System. It should
be located where it is easily accessible and visible to the adult homeowner or end
user. For accurate temperature measurement, the following guidelines should be
followed:
The Infinity Touch Control and Remote Room Sensors SHOULD be mounted:
SApproximately 5--ft (1.5 m) from the floor.
SClose to or in a frequently used room, preferably on an inside partitioning wall.
SOn a section of wall without pipes or ductwork.
The Infinity Touch Control and Remote Room Sensors SHOULD NOT be
mounted:
SClose to a window, on an outside wall, or next to a door leading to the outside.
SExposed to direct light or heat from a lamp, sun, fireplace, or other
temperature--radiating objects which could cause a false reading.

6
SClose to or in direct airflow from supply registers.
SIn areas with poor air circulation, such as behind a door or in an alcove.
4.3.2. Remote Room Sensors
A Remote Room Sensor can be used with the Infinity Touch Control to take the
place of the control’s internal temperature sensor. This allows the Infinity Touch
Control to be mounted in areas with less than optimal airflow (such as near an
exterior door, window or in a closet). The remote sensor can be wired to the
terminal block connectors labeled S1 and S2 at the control’s backplate, or the ZS1
and ZS1C connection at the Damper Control Module. In either case, the Infinity
Touch Control will automatically detect the Remote Room Sensor and ignore its
internal temperature sensor.
4.3.2.1. Remote Room Sensor Averaging
Typically, one remote sensor is used but, multiple sensors may be used and
averaged in some applications. Averaging requires a special series--parallel wiring
method with a specific number of sensors. See figure below. It is also important to
note the humidity sensor cannot be remotely located, so do not locate the Infinity
Control in an area where humidity sensing may not be accurate.

7
Sensor 1 Sensor 2
Sensor 3 Sensor 4
Damper Control
Module
ZS_
Damper Control
Module
ZS_C
A03233
4.3.3. Smart Sensors (for zoning applications)
Any zone may use a Smart Sensor. It provides a temperature display and buttons to
adjust the desired temperature in that zone only. It also displays outdoor
temperature and indoor humidity sensed at the control. Only one Smart Sensor may
be used per zone. They cannot be averaged like Remote Room Sensors. If a Smart
Sensor is used in a zone, a Remote Room Sensor may also be used in the same
zone. The Remote Room Sensor has priority over the Smart Sensor. The Smart
Sensor will display the Remote Room Sensor temperature.
NOTE: Smart Sensors must be addressed to identify which zone it will control. See
Smart Sensor Installation Instructions for details.
4.4. Wiring Considerations
Ordinary thermostat wire is recommended. Use 22 AWG or larger for normal
wiring applications. Continuous wire lengths over 100 ft. should use 20 AWG or
larger.

8
NOTE: ABCD bus wiring only requires a four--wire connection; however, it is
good practice to run thermostat cable having more than four wires in the event of a
damaged or broken wire during installation.
Each communicating device in the InfinityrZone System has a four--pin connector
labeled ABCD. It is recommended that the following color code be used when
wiring each device:
A — Green = Data A
B — Yellow = Data B
C — White = 24VAC (Com)
D — Red = 24VAC (Hot)
ABCD
A03193
It is not mandatory that the above color code be used, but each ABCD connector in
the system MUST be wired consistently.
NOTE: Some outdoor units provide their own low--voltage power source and do
not require the “C” (24VAC common) and “D” (24VAC power) connections. See
the outdoor unit installation instructions for more information.

9
ELECTRICAL OPERATION HAZARD
Failure to follow this warning could result in personal injury
or death.
Before installing, modifying, or servicing system, the main
electrical disconnect switch must be in the OFF position. There
may be more than 1 disconnect switch. Lock out and tag
switch with a suitable warning label.
!WARNING
STurn off all power to equipment.
SIf an existing InfinityrControl or other control is being replaced:
dRemove existing control from wall.
dDisconnect wires from existing control.
dDiscard or recycle old control.
SNOTE: Mercury is a hazardous waste, if existing control contains any
mercury, it MUST be disposed of properly. The Infinity Touch Control
does not contain mercury.
SSelect Infinity Control mounting plastic (backplate and decorative backplate if
desired).
SRoute wires through large hole in mounting plastic. Level rear plastic against
wall (for aesthetic value only; Infinity Touch Control need not be level to
operate properly) and mark wall through two mounting holes.
SDrill two 3/16--in (4.8 mm) mounting holes in wall where marked.
SSecure mounting plastic to wall using two screws and anchors provided.

10
SAdjust length and routing of each wire to reach each wire entry on the
connector backplate. Strip 1/4--in (6.4 mm) of insulation from each wire.
SMatch and connect thermostat wires to proper terminals on control backplate.
dSee wiring diagrams in Appendix A.
SPush any excess wire into the wall. Seal hole in wall to prevent any air leaks.
Leaks can affect operation.
SAttach Infinity Control to the mounting plastic by lining up the plastic guides
on the back of the control with the opening on the mounting plastic and push
on.
SPerform installation of all other system equipment (i.e. dampers, humidifier,
ventilator, UV lights, etc.).
STurn on power to equipment.
4.4.1. Shielded Wire
If the thermostat wiring will be located near or in parallel with high voltage wiring,
radio, TV or Ethernet wiring, then four conductor, twisted--pair, shielded cable can
be used to reduce or eliminate potential interference. The shield wire should be
connected to the C terminal, or ground, at the indoor unit. The shield wire should
NOT be connected to any terminal at the user interface. Connecting the shield to
ground at both ends can cause current loops in the shield, reducing shield
effectiveness.
Connect one pair of the two--pair (minimum) cable to the A and B communication
terminals, and another pair to the C and D terminals at both ends of the cable. The
shield wire should ONLY be connected at the indoor equipment ground or C
terminal. Note that some outdoor units only require the A and B connections. See
the outdoor unit installation instructions for more information.

11
4.4.2. Damper Control Module (zoning systems only)
All wiring is run back to the Damper Control Module. Select a location near the
furnace or fan coil where wiring from the control, each Remote Room Sensor or
Smart Sensor, each damper actuator, and the equipment itself can come together
easily. The Damper Control Module is approved for indoor use only and should
never be installed with any of its components exposed to the elements. The Damper
Control Module (and zone dampers) may be installed in any area where the
temperature remains between --4_F to 158_F(--20_Cto70_C), and there is no
condensation. The cover must be installed to prevent damage from other sources.
Do not locate where it will be accessible to children. It may be mounted in either
vertical or horizontal position. Remember that wiring access is likely the most
important consideration.
PERSONAL INJURY HAZARD
Failure to follow this caution may result in personal injury.
To prevent possible damage to the Damper Control Module,
DO NOT mount on plenum, ductwork, or flush against
furnace or fan coil.
CAUTION
!
4.5. Mounting
First become familiar with all plastic assembly pieces shown on the following page.
The Infinity Touch Control will snap together with the backplate. A backplate is
supplied. Attach backplate using only a small hole in the wall allowing a four wire
connection to pass through. Mount the assembly to the backplate.

12
A12214
A12215
NOTE: Once Infinity Control is secured to wall with the backplate assembly
(snapped together), care must be taken not to bend or break the interlocking tabs
when removing.
4.5.1. Decorative Backplate
Sold separately, a thin decorative backplate is available to hide any marks/screw
holes left from the previous thermostat. This decorative backplate (or beauty ring)
is used by snapping it onto the back of the mounting plate before securing the plate
to the wall.
