Cartizan PAS-FD-SYNC2 User manual

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
1
User Manual
OEM RADIO:Camera Interface for FORD SYNC 2 system with 7" OEM monitor
Model name
PAS-FD-SYNC2
Released Date
2020-03-18
Manual Version
V1.3
Language
English

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
2
1. Car Compatibility
Car Models
Production Year
New Edge
-2016
kuga
-2016
Focus
-2016

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
3
Contents
1.Features................................................................................................................................................................4
2.Specifications.......................................................................................................................................................5
3.Packing Lists........................................................................................................................................................6
4.Wiring Diagram ....................................................................................................................................................7
5.DIP Switch Settings.............................................................................................................................................8
6.Operation Instructions ......................................................................................................................................11
7.Safety Considerations.......................................................................................................................................17

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
4
1. Features:
A. IPAS+ 2 Video in
B. Support Intelligent parking assist system(selected models)
C. Reverse camera auto trigger
D. 1 video in for rear camera, another for 360 view or DVR/front view(need factory radio botton to switch it)
Optional:
360 Panoramic,etc

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
5
2. Specifications
1. Interface I/O Spec:
Input: CVBS *2 (Rear View Camera, 360, Front View Camer), VGA *1 (Specific 360 Panoramic System)
Output: FPC
2. Power Spec:
Input Power: 9V-16V
Consumption: 6W
3. Package Content:
Interface Unit * 1
Main Power Cable * 1
FPC * 1

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
6
3. Packing Lists
Camera Interface Power Harness FPC

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
7
4. Wiring Diagram

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
8
5. DIP Switch Settings
ON (▼) OFF(▲)
Car Model
No.1
No.2
No.3
Kuga/Focus
OFF(▲)
OFF(▲)
OFF(▲)
New Edge
ON (▼)
OFF(▲)
OFF(▲)
PIN
ON (▼)
OFF(▲)
4
Turn off PDC
Turn on PDC
5
Turn off dynamic guideline
Turn on dynamic guideline
6
Turn on DVR
Turn off DVR
7
VGA 360

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
9
*Please note that DIP Switch 5 and 8 put ON (▼) for OEM rear view.
* Dip Switcher SettingsⅡ（Quick Setting）:
Mode selection
No.4
No.5
No.6
No.7
No.8
AV.360 (Canbus reverse
not working)
OFF(▲)
OFF(▲)
OFF(▲)
OFF(▲)
ON (▼)

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
10
6. Operation Instructions
6.1 Installation Process
* Please note that power off the car and take protection measures to avoid damaging in the installation.
1. Focus(SYNC2) central control map (Figure 1).
2. First remove the top frame on the screen of the original car with tools (Figure 2).
3. Remove the screws with a screwdriver and take out the screen and the radio of the original car (Figure 3).
1 2 3

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
11
4. Remove the four screws with a screwdriver at the back of the screen. Replace the rear cover of the screen with the one
provided in the set of Interface(Figure 4).
5. Same as step 4 to remove the four screws at the side of the display with a screwdriver (Figure 5), unscrew the three
screws on the original screen board (Figure 6).
Figure 4 Figure 5 Figure 6

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
12
6. Install the three screw holes of the interface with the original screen board to fix the original screen board.
7. Set the dip switcher before recover the radio. Transfer the power harness as below:

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
13
*Long press MENU button on the steering wheel for 2 seconds to enter the DVR/front view.

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
14
7. Safety Considerations
1. In order to protect driving safety and avoid breaking the traffic law, please do not watch the program or use this product
when you’re driving.
2. Please do not put the product in the damp environment or water, in order to avoid electric shock, damaged and fire
accident caused by short circuit.
3. The reversing surveillance function just be used in reversing assistance. Once happened reversing accident does not
concern us. And hint of fault message need to be confirmed by professional maintenance Center.
4. In order to safety and ensure the use of product, the installation please leave it to the professional. Do not unload by
yourself in order to avoid causing damaged or accident.
5. Start the engine before loading, check the interface whether have function displayed, key control whether correct, the
vehicle interface whether have scratch. Please give the feedback to customers if there has any questions.
6. Please note that put the disassemble automotive components in a good way on the installation process, avoid
scratching the instrument panel, the leftovers of connect cables need to handle and do not leave it in the car. The
connecting plug must be insulated in order to short circuit.

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
15
7. The cables should be connected in a good way, the vehicle installation space is small, so reduce space usage as far as
possible, and it will easy installation for monitor. There should be a good plan about connect cables, avoid affecting
the active component of connecting, such as control components of turning steering wheel, throttle and brake pedal.
There need to be fasten after connecting cables in case of drop.
8. Please do not plug or pull the connected cables in the state of power-on, in order to avoid damaging monitor or
accessory.

Total Solutions for Car Audio & Video Interface
Cartizan Technology | www.icartizan.com
16
w w w. i c a r t i z a n . c o m
Copyright © Cartizan. All rights reserved.
