CARVIN 742-V1 User manual

SPEAKER CABLES
The PH50 is our standard cable when purchasing a complete sound system.
These cables feature 1/4” plugs and heavy 16 gauge copper wire. The PH50 is
adequate for lengths up to 50’ under normal use. You can DAISY-CHAIN up to one
additional speaker per cable by using the unused 1/4” OUTPUT” jack (right side)
on your speaker jack plate. Be sure to note the total impedance to the amp so it is
not lower than it’s recommended impedance. See Typical Loudspeaker Impedance
Configurations.
PRECAUTIONS
1) DO NOT EXCEED THE POWER RATING marked on the rear connect plate.
Excessive power will destroy drivers. 2) DISTORTION from power amps will destroy
drivers much faster than clean power. 3) WATER, MOISTURE, and DUST are
harmful to drivers causing failure which is not covered under warranty.
WARRANTY
CARVIN loudspeakers are covered by a ONE year limited warranty unless
otherwise stated. Warranty coverage is limited to original manufactures defects
only. WARRANTY DOES NOT COVER: 1) Opened or burned voice coils. 2) Torn
cones caused by improper packing or abuse. 3) Damage from rain, moisture, ETC.
When returning defective driver(s), remove them from the enclosure to reduce
shipping costs . DO NOT stuff paper into the driver(s). Return pre-paid by UPS.
Include your address and description of the problem. Your driver(s) will be returned
COD for the cost of shipping and reconditioning if not covered under warranty.
MODEL 742 SPEAKER SYSTEM SPECS:
Frequency Response: 65Hzto17kHz±3dB
Useable Low Frequency: 42Hz(-10dB)
Power Handling: 400wContinuousPower
Recommended Amp: 5to600watts
Sensitivity: 101dBSPL,1Watt@1meter
Coverage Angles: 90°Horizontal,45°Vertical
Imp: 8Ω
Horn Driver Protection: Yes
Inputs/Outputs: Two 1/4"
Woofer Enclosure Type: Closed Box
Enclosure Covering: BlackDuratuffII™
Dim/Wt: 20"Wx14"Dx26"H,46lbs.
Warranty: OneYear
Options: Cover: CVS742
742 FREQUENCY RESPONSE
CARVIN ENGINEERING DATA 742 SPEAKER SYSTEM INSTRUCTIONS
742
Congratulations on your selection of the 742 monitor speaker. The 742 is our top
of the line 15” monitor speaker designed to cut through on any stage. This monitor
will easily handle 400 watts and at the same time offer studio quality sound even
when pushed to extreme levels. Because of it’s controlled dispersion, feedback
problems are minimized.
RECEIVING INSPECTION
INSPECT YOUR SPEAKER FOR ANY DAMAGE which may have occurred during
shipping. If any damage is found, please notify the shipping company & CARVIN.
SAVE THE CARTON & ALL PACKING MATERIALS. In the event you have to re-ship
your unit, always use the original carton and packing material. This will provide the best
possible protection during shipment. CARVIN and the shipping company are not liable
for any damage caused by improper packing.
SAVE YOUR INVOICE. It will be required for warranty service if needed in the future.
SHIPMENT SHORTAGE. If you find items missing, they may have been shipped
separately. Please allow several days for the rest of your order to arrive before inquiring.
RECORD THE SERIAL NUMBER on the enclosed warranty card or below on this
manual for your records. Keep your portion of the card and return the portion with your
name and comments to us.
SUGGESTIONS FOR OPTIMAL PERFORMANCE
Raise the enclosure to the ear level of your audience for greater coverage. To
help control feedback, use a graphic equalizer. Keep the speakers in front of the
microphone. Never direct the microphone towards the speaker. For greater
coverage, add a second speaker system 20° to 30° off axis.
TYPICAL LOUDSPEAKER IMPEDANCE CONFIGURATIONS
Individual speaker or speaker cabinet wiring examples for total impedance.
For your records, you may wish to record the following information.
Serial No._____________________ Invoice Date_______________
SERIES CONNECTION
16ΩTOTAL IMPEDANCE
+
+
+
PARALLEL CONNECTION
4ΩTOTAL IMPEDANCE
+
++
8ΩTOTAL
IMPEDANCE SERIES/PARALLEL
CONNECTION
8ΩTOTAL IMPEDANCE
+
+ +
+
+
+
+
8Ω8Ω
8Ω
8Ω
8Ω
8Ω
8Ω
4Ω8Ω
8Ω
16Ω8Ω8Ω
REAR CONNECT PLATE
Two professional twist-lock SPEAKON™
connectors and two standard 1/4” phone
jacks are featured. Use these connectors
for connecting to the power amp and daisy
chaining to an additional speakers.
