Carvin Splash pak Programming manual

Sand Filter

Owner’s Manual

and Installation Guide

5/05

221666071552A

Congratulations! You have purchased one of the most user-friendly

pool filter systems available. Ideal for an above-ground pool or in-

ground vinyl liner pool, it will provide you with many years of pool

enjoyment. This step-by-step installation and maintenance guide will

provide the necessary information for you to install your new pool sys-

tem and easily maintain the equipment.

Before installation be sure to read all instructions and warnings care-

fully. Refer to product dataplate(s) for additional operation instruction

and specifications.

This filter operates under pressure. If

this unit is not assembled properly or

is operated with air in the circulation system, serious bodily injury

and/or property damage could occur.

Your filter is a pressure vessel and

should never be serviced while under

pressure. Always shut off pump to relieve the pressure in the filter

prior to servicing the unit.

To reduce risk of injury, do not permit

children to use this product unless they

are closely supervised at all times.

Locate the system at least five feet

(1.5M) from the pool to prevent it being

used as a means of access to the pool by young children. (See

ANSI/NSPI-8 1996 “Model Barrier Code For Residential Swimming

Pools, Spas and Hot Tubs”).

WARNING

INSPECTION

Examine the equipment when received. Notify your dealer or carrier

of any damage or missing parts. Verify that equipment is of size and

model specified.

INSTALLATION LOCATION

Locate unit on a solid foundation as close to pool/spa as possible, but

keep at a distance of at least five feet (1.5 M). (See previous warning).

Give consideration to draining - away from equipment ventilation and

access for future servicing and winterizing.

PUMP SELECTION

A full line of pool/spa pumps are available for installation with these

filters. For those installations where the equipment will be placed

above the water level, a self-priming pump should be selected. Ask

your dealer to determine the proper size and distance from pool or

spa and friction losses (restrictions) of associated equipment.

GENERAL PLUMBING

FOR SOLVENT WELD CONNECTIONS

Rigid or flexible PVC pipe can be used. Pipe ends should be clean

and free of any flash caused by the cutting operation. Be sure that the

proper adhesive is used on the type of pipe specified. Recommended

Adhesives - These are examples only and are not intended to restrict

brands:

PVC - PVC Joint PVC - ABS Joint

Uni-Weld Pool-Tite 2000 Uni-Weld Pool-Tite 2000

Suregard Flex 20 Suregard Weld-All No. 5

IPS Weld-On 705 IPS Weld-On 794

Note: A primer will assure that adhesive joints are superior. Suregard

P-3000 has a purple tracer to qualify in areas where codes specify a

primer must be used.

Caution: We recommend that you consider climatic conditions when

applying adhesives. Certain atmospheric situations, such as high mois-

ture content, make the adhesive action of certain glues less effective.

Check the manufacturer’s instructions.

FOR THREADED CONNECTIONS

Use only Teflon tape or equivalent on threaded plumbing connections.

Other pipe compounds may damage threads. We do not recommend

the use of silicone or petroleum based compounds. DO NOT OVER-

TIGHTEN. HAND-TIGHTEN PLUS 1/2 TURN IS SUFFICIENT.

SAND FILTER PREPARATION

DO NOT PLACE SAND IN FILTER TANK BEFORE IT IS POSI-

TIONED AS ITS WEIGHT WILL MAKE MOVING TANK MORE

DIFFICULT AND MAY CAUSE DAMAGE.

Remove bag of miscellaneous parts and proceed as follows:

1. Place standpipe cover on standpipe to prevent entrance of any sand.

Standpipe cover is either a plastic cap or waxed corrugated assembly

found in Misc. parts bag or separately in carton. Some filters may al-

ready have standpipe cover installed on standpipe and diverter removed

located in Misc. parts bag.

2. Fill tank approximately 1/2 full of water.

3. Add sand (not provided) following recommendation for size and

amount. Be sure that standpipe remains centered while pouring sand.

Be sure sand is level.

4. Remove cover from standpipe.

DIAL VALVE INSTALLATION

Carefully remove all sand particles from the mounting location. Position

the rubber O-ring on the dial valve body. Place valve on tank and rotate

until the valve inlet is approximately in line with the pump outlet open-

ing. Install the V-clamp. Install pressure gauge after wrapping threads

with teflon tape.

DIAL VALVE FUNCTIONS

FILTER - For normal filtering. This position also can be used for regular

vacuuming.

BACKWASHING - Clean your filter with this position. Note instructions

on Cleaning Filter.

DRAIN - This position allows you to pump water from the pool - the flow

from the pump is permitted to bypass filter and go directly to the waste.

Use this position to vacuum heavy concentration of debris.

WHIRLPOOL - By bypassing the filter, this position creates more pres-

sure to obtain optimum performance from any hydro-therapy fittings.

No filtration occurs while the valve is in this position.

WINTERIZE - This is a neutral position which is used only when pump

is stopped. It allows air to leave - or enter the tank to help priming and

draining.

RINSE - (6 and 7 position dial valve only, not available on 4 position

dial valve.) For sitting filter bed after backwashing and for carrying

any remaining loose dirt to waste. The rinse prevents any return of re-

sidual dirt to the pool that occurs momentarily when changing directly

from BACKWASH TO FILTER.

TEST - (6 and 7 position dial valve only, not available on 4 position dial

valve). This position prevents any backflow of water from pool during

pump maintenance if filter is below water level.

FILTER START-UP

1. Set dial valve to DRAIN position.

2. Perform pump start-up.

3. After good flow has been established, continue pumping for one minute

or until wastewater is clear.

4. Stop the pump. Set dial valve to BACKWASH and restart pump.

5. Observe the waste water. When flow becomes clear (approximately

2 to 3 minutes). STOP pump.

6. If your dial valve does not have a RINSE cycle, proceed to STEP 7. If

your dial valve does have a RINSE cycle, set it to that position, restart

pump and allow it to run 20 seconds. STOP pump.

7. Set dial valve to FILTER and restart pump.

WATER CHEMISTRY

Proper and consistent use of chemicals is necessary to maintain clean,

sanitary water, prevent a spread of germ infection and control the growth

of algae which can spoil the appearance and enjoyment of your pools or

spa.

Chlorine is the most commonly used chemical to provide clean, sani-

tary water. Either dry or liquid chlorine can be used which should be

added daily as it is dissipated by dirt and germs as well as by the sun

and the wind.

It is also important that the correct level of acidity or alkalinity of the pool

water be maintained. This is the pH of your pool with pH 7.0 being neu-

tral. Readings above pH 7.0 are alkaline and readings below are acid. A

desirable range is 7.2 to 7.4. Consult your local pool/spa dealer for com-

plete information on the proper application and use of chemicals.

FILTER MAINTENANCE

Filter tank and contents should not require attention other then

backwashing provided water is kept in continuous chemical balance

without heavy dosages of corrosive chemicals.

CLEANING FILTER (Backwashing)

When the new filter is placed in service, note the reading on pressure

gauge. As dirt builds up in filter, the pressure reading will increase. When

it reads 6-8 PSI above the original reading, it is time to Backwash as

described below.

1. STOP pump.

2. Set dial valve to BACKWASH and start pump.

3. Observe the waste water. STOP pump when flow becomes clear

(approximately two to three minutes).

4. If your dial valve does not have a RINSE cycle proceed to step 5. If

your dial valve does have a RINSE cycle, set it to that position, restart

pump and allow to run 20 seconds. STOP pump.

5. Set dial to FILTER and start pump to resume filtering operation.

Do not use pool vacuum cleaner when filter is backwashing.

WINTERIZING

Consult your dealer for advice on wintering your equipment if freezing

temperatures occur in your locality. Their knowledge of your equipment

makes them the best qualified source of information. Follow their rec-

ommendations, and if these include draining the filter system, proceed

as follows:

1. BACKWASH for 3 to 5 minutes and the set dial valve to WINTERIZE

position.

2. Drain system by removing drain plugs and/or removing pipe caps

from the filter, pumps, and disinfecting equipment. Store plugs in a dry

place for safekeeping.

TROUBLE SHOOTING

Sand Level 1” to 2”

Below Basket

Filter Basket

Sand-fill Cover

Filter Backwash Rinse Whirlpool

Drain Test Winterize

SAND BACK TO POOL

• Sand too small: Recommend .40mm to .50 mm size, 20# silica. In-

spect.

• Flow rate too high. Adjust discharge valve to reduce flow.

• Sand bed calcified. Change sand.

• Cracked or loose laterals. Inspect or replace.

• Cracked manifold. Inspect or replace.

• Cracked or unseated standpipe in manifold. Inspect or replace.

• Too much sand; above basket on stand pipe. Inspect.

Disconnect power to motor

main circuit breaker to avoid

electrical shock.

WARNING

ALGAE OR DEBRIS BACK TO POOL

• Upper standpipe disengaged from bottom of valve. Lengthen upper

standpipe.

• Upper standpipe disengaged from top of basket on standpipe. In-

spect.

• Heavy dirt load.

• Heavy bather load.

• Algae. Shock and flock to remove from pool.

• Dial valve isn’t locked in position. Inspect.

EXCESSIVE PRESSURE IN FILTER

• Dirty filter. Backwash; recheck pressure.

• Backwash adapter in the “return” outlet on the dial valve. Inspect.

• Calcified sand bed. Inspect and change if necessary.

• Using Soft Swim; Baquacil. Use Baquacil’s cleaners.

FILTER LEAKS WATER

• Split in tank. Replace.

• Split in tank due to freeze damage. Replace.

• Drain plug missing or not tight. Inspect.

• O-ring between tank and valve damaged, twisted or not lubed. In-

spect.

DIAL VALVE LEAKS

• Valve set in intermediate position. Inspect.

• Diverter O-ring damaged. Replace diverter.

• O-ring between body and housing damaged. Inspect or replace.

• O-ring between valve and tank damaged, twisted, not lubed. In-

spect.

FILTER WILL NOT KEEP WATER CLEAN

• Dirty filter. Backwash or change sand; recheckpressure.

• Algae growth in pool. Shock and flock; then vacuum up waste.

• Water started out dirty. Continue to filter and clean as necessary.

• Improper sand media. Recommend .40mm to .50mm, 20# silicia.

Inspect.

• Heavy swimmer load.

• Not enough sand in filter. Inspect or fill to proper level.

• Calcified sand bed. Inspect and change sand if necessary.

• Dial valve in intermediate position. Inspect.

• Flow rate too low.

• Backwash adapter in the “pump” inlet on the dial valve. Inspect.

SAND COMING OUT OF BACKWASH IN BACK-

WASH MODE

• Valve missing backwash adapter. Check valve.

• Too much sand. Just changed and overfilled?

• Pump is over sized. GPM of pump vs. GPM capacity of filter. Check

this.

• May need smaller backwash adapter . . . extreme case. PSI is im-

portant.

NOTE: If these recommendations do not solve your particular

problem(s), please contact your local dealer for service.

SERVICE & REPAIR PARTS

Refer all service to your local dealer as his knowledge of your equip-

ment makes him the best qualified source of information. Order all

repair parts through your dealer. Give the following information when

ordering repair parts: Unit nameplate data and description of part.

MANUFACTURER’S WARRANTY

Cantar Pool Products warrants it’s pool equipment to be free of defects

in material and workmanship for a period of 12 months from the date

of purchase or 36 months from the date of manufacture, whichever

comes first.

This warranty extends only to the original retail purchaser and only

during the time in which the original retail purchaser occupies the site where

the product was originally installed.

THIS WARRANTY IS EFFECTIVE NOVEMBER 1, 2003. ANY IMPLIED

WARRANTIES WHICH THE PURCHASER MAY HAVE, INCLUDING

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

SHALL NOT EXTEND BEYOND THE APPLICABLE WARRANTY

PERIOD. Some states or provinces do not allow limitations on how

long an implied warranty lasts, so the above limitation may not apply

to you. IN NO EVENT SHALL CPP BE LIABLE FOR INCIDENTAL OR

CONSEQUENTIAL DAMAGES. Some states or provinces do not allow

the exclusion or limitation of incidental or consequential damages, so

the above may not apply to you.

This warranty applies to products used in swimming pool, spa, & aquaculture

applications only and does not apply to any product which has been

subjected to negligence, alteration, accident, abuse, misuse, improper

installation, abrasives, corrosion and/or electrolysis, improper voltage

supply, vandalism, civil disturbances, or acts of God (including but not

limited to freeze damage, lightening strikes, and other damage caused by

catastrophic events). The only warranties authorized by CPP are those set

forth herein. CPP does not authorize other persons to extend any warranties

with respect to its products, nor will CPP assume liability for any unauthorized

warranties made in connection with the sale of its products. The Company

will not be responsible for any statements that are made or published,

written or oral, which are misleading or inconsistent with the facts as

published in the literature or specifications furnished by the Company.

WARRANTY CLAIM PROCEDURE

Warranty claims shall be made by contacting the installing/selling, builder,

dealer, or retailer (point of purchase). All equipment must be inspected by

a local Company representative or at the factory before warranty is

authorized.All charges or expenses for freight to and from the factory,

removal and reinstallation of the products, or installation of a replacement

product are the responsibility of the purchaser unless otherwise expressly

authorized by Cantar Pool Products.

The Company, at its discretion, may repair or replace free of charge (F.O.B.

factory in Toronto, Ontario) any product that proves defective within the

warranty period, or it may issue credit in the amount of the invoice of the

defective equipment in lieu of repair or replacement. The Company

reserves the right to substitute new or improved equipment on any

replacements.

The provisions of this additional written warranty are in addition to and not

a modification of or subtraction from the statutory warranties and other

rights and remedies provided by any state or provincial law.

39-2585-09-R

9408-5745-R

9408-5623-R

9408-5172-R

42-3882-07-R

42-3883-06-R

42-3884-05-R

42-3532-01-R

42-3511-06-R

85-5311-02-K

85-5312-03-K

85-8263-00-R

12-1121-08-R

22-3639-07-R

85-8139-02-R

9193-4182-R

47-0364-05-R

31-1650-04-R

31-1652-02-R

31-1653-01-R

Dial Valve 15 VK

Replacement filter tank SS160 w/#5

Replacement filter tank SS185 w/#5

Replacement filter tank SS240 w/#5

Snap-Fit SS160SF Standpipe w/laterals

Snap-Fit SS185SF Standpipe w/laterals

Snap-Fit SS240SF Standpipe w/laterals

Lateral Kit f/SS160-SS185 (incl. 8 lat. per kit) prior to 3/02

Lateral Kit f/SS240 (incl. 8 lat. per kit) prior to 3/02

Lateral Kit Snap-Fit f/SS160-SS185 (effective 3/02)

Lateral Kit Snap-Fit f/SS240 (effective 3/02)

Drain Cap w/13-1023-06-R Gasket.

Base filter tank support

9869 Sand-Fill Cover

Clamp V-Band

PG-60 Pressure Gauge 1/4" 0-60#

O-Ring 6-3/4 x 7-1/8 x 3/16 BN

Backwash Adapter f/SS160

Backwash Adapter f/SS185

Backwash Adapter f/SS240

FIG NO. PART NO. DESCRIPTION

16”, 18.5” & 24” SAND FILTER SYSTEM REPAIR PARTS

RKIT

39-2611-02-R

14-4263-08-R

14-4264-07-R

14-2563-09-R6

39-2632-07-R

39-2612-01-R

47-0236-01-R

47-0364-47-R

14-4266-05-R

16-1092-09-R

47-0212-09-R

16-1108-01-R

16-1093-08-R

13-1076-02-R

13-1074-04-R

39-2636-03-R

39-2613-00-R

14-4267-04-R

14-4268-03-R

13-1075-03-R

23-4823-00-R

47-0240-05-R

47-0229-00-R

39-2634-05-R

39-2617-06-R

FIG NO. PART NO. DESCRIPTION

PARTS FOR 1-1/2” (39-2585-09) & 2” (39-2586-03)

DIAL VALVES

Handle

Pin SS

Washer NYL.

Screw SS (6 each req’d) (6 per bag)

Cover (1-1/2” Dial Valve)

Cover (2” Dial Valve)

O-Ring Nitrile (1-1/2” Dial Valve)

O-Ring Nitrile (2” Dial Valve)

Washer

Spring SS

O-Ring Nitrile

Valve Diverter Noryl (1-1/2” Dial Valve)

Valve Diverter Noryl (2” Dial Valve)

Spider Gasket Kraton (1-1/2” Dial Valve)

Spider Gasket Kraton (2” Dial Valve)

Valve Body (1-1/2” Dial Valve)

Valve Body (2” Dial Valve)

Nut SS

1/4” Plug ABS

Gasket Nitrile

Sight Glass

O-Ring Nitrile (1-1/2” Dial Valve)

O-Ring Nitrile (2” Dial Valve)

REPAIR KITS

Handle/Cover Assembly (1-1/2” Dial Valve)

Handle/Cover Assembly (2” Dial Valve)

In Canada 325 Humber College Blvd. Toronto, ON, M9W 7C3 Phone: 800.836.1210 Fax: 416.798.2801

In USA 1515 S. Bowman Rd., Suite A Little Rock, AR 72211 Phone: 866.370.2664 Fax: 800.447.3181

CANTARCANTAR

CANTAR Pool Products Ltd.Pool Products Ltd.

Pool Products Ltd.Pool Products Ltd.

Pool Products Ltd.

Produits de Piscine Ltée.Produits de Piscine Ltée.

Produits de Piscine Ltée.

MAGNUM PUMP

Owner’s manual

POMPE MAGNUM

Manuel du propriétaire

MAGNUM PUMPEN

Bedienungsanleitung

POMPE MAGNUM

Manuale dell’utente

BOMBA MAGNUM

Manual del usuario

BOMBA MAGNUM

Manual do Proprietário

MAGNUM POMPEN

Gebruikers Handleiding

LE ACCE OIRE DE PI CINE COMPETITION INC.

12775, rue Brault, Mirabel, Québec, Canada J7J 0C4

Tél.: (450) 437-2420 Fax: (450) 437-4860

www.competition-pool.com

M10003C

Tél : 450-250-4500 : Fax : 450-250-4501

Sans Frais  Toll Free : 1-866-979-4501

http://www.carvinpool.com

Les Équipements de Piscines Carvin Inc. 

Carvin Pool Equipment Inc.
