CAS ScanMaster M1 Operator's manual

ScanMaster M1/M2
Static Parcel DWS System
Quick use manual

ScanMaster M1/M2
•Introduction of Main Components

Visual measurement module
Automatic bar code and
Dimensioning
Touch screen
Scale
Tempered glass countertop,
Ambient light prompt
Shock absorber caster

PAD
Wireless control of
ScanMaster M2
Scale
Multi-section roller table for
different sizes
Double visual measurement
module
Automatic bar code and
Dimensioning
32” screen

Quick Operations Wizard
•Open device
•Use equipment for measurement
•Shut down equipment
•Query historical data
•SOP

Boot button
（Equipment front）
Power switch
（Back of equipment）
Open device（M1）
Step1：Rotate the power switch on the back of the equipment, and the
switch knob shows red.
Step2：Click the boot button on the front of the device, and the blue button
shows that the device is on.

Boot button
（Left side of device ）
Power switch
（Left side of device）
Open device（M2）
Step1：Toggle the main power switch, the red light is on.
Step2：Rotate the power switch on the left side of the device, the switch knob lights up red.
Step3：Click the boot button on the left side of the device, and the button displays blue to
indicate that the device is turned on.
Main switch
（Left side of device）

Open the application
The first time the machine is turned off after a
period of time, please wait 5 minutes for the
machine to warm up.

User login
Step1: Enter username and password
（M2 is input on the PAD）
Step2: After logging in, you can view the user
information interface.

Bar code display
Measurement live display
Barcode label photo
Data communication record
Device module status
Item size and weight data
display
Live efficiency information
User information or
package identification
display

Help documentation, and remote technical support.
Light/dark theme replacement.
Simplified Chinese/Traditional Chinese/English Language Switching.
Real-time monitoring interface / nearly 20 acquisition data interface switching
Recent data list
Homepage button

Homepage button
The weight is forced to zero.
System settings button.

System shutdown
Step 1：Click System settings button.
Step 2：Click “shut down”tab.
Step 3：Click “Turn off”tab.Wait for the main swich to turn off.
after the display is completely turned off

Touch PAD(M2) Main button function introduction
Recollection
Print again
Shut down
Reboot
Statistical interface
Recent detailed record
collection
The weight is forced to zero.
Manually enter bar code and
measure
Return to the login screen

Precautions before measurement
1. There is nothing on the measuring table and nothing
around it touches the measuring table
2. Make sure your glass countertops are clean
3. The status prompt lights at the bottom of the
software are all green
When the no-load
weight is not zero,
you can click the
zero button
Equipment self-test
status display

Measurement method 1 (M1)
The green ambient light around the table
indicates that the measurement is over.
The barcode of the package is placed
face up on the measuring table
Quickly move your hands away from the
measuring table（Measurement delay is
optional）
The barcode position

Measurement method 2 (M1)
The green prompt light indicates that the
measurement is completed.
Step1: Hold the item in your hand
with the barcode facing up. Step2: After the barcode identification is successful,
the blue prompt light will be on, and then the goods
will be placed on the test table.
Step3: Take the package away when
the green ambient light is on.

Measurement method 1 (M2)
The green ambient light around the table
indicates that the measurement is over.
The barcode of the package is placed
face up on the measuring table
Quickly move your hands away from the
measuring table（Measurement delay is
optional）
The barcode position

Measurement method 2 (M2)
The green prompt light indicates that the
measurement is completed.
Step1: Hold the item in your hand
with the barcode facing up. Step2:After the barcode identification is successful, the blue prompt light will be on, and
then the goods will be placed on the test table.
Step3: Take the package away
when the green ambient light is on.

Data query and export
Step1: Click the gear shape icon in the bottom right corner
of the homepage
Step2:Select “History”
Step3: Enter the history list, perform range query and
export .
Step 1
Step 2
Step 3
Step 3
①②③
①Label photo
②Item photo
③Item measurement video
