Casablanca C3443001 AT0209 User manual

1
Ve r m o n t ®
Safety and the proper operation of your Casablanca fan both require a thorough knowledge of the product and
proper installation; therefore, before attempting to install and operate your Casablanca fan, read this owner’s
manual completely and carefully. Retain this manual for future reference.
Caution: To avoid possible electrical shock, make certain that electricity is turned off at the circuit breaker or fuse
box before attempting any installation procedure.
Vermont ®Owner’s Manual
INTRODUCTION..........................................................................5
Before You Start.........................................................................5
Safe Use ..............................................................................5
MOUNTING RECOMMENDATIONS...........................................................6
General Guidelines ......................................................................6
Getting Started..........................................................................6
CEILING MEDALLION PREPARATION AND INSTALLATION .......................................7
Ceiling Medallion Bracket Installation ........................................................7
MOTOR INSTALLATION....................................................................8
Motor Housing Installation ................................................................10
BLADE PREPARATION AND INSTALLATION ..................................................12
LIGHT FIXTURE INSTALLATION ............................................................13
 .................................................16
Control Bracket Installation ...............................................................16
Remote Operation ......................................................................17
Changing Transmitter Frequency Setting ....................................................18
TROUBLESHOOTING TIPS................................................................19
CARE RECOMMENDATIONS ..............................................................20
PRODUCT SPECIFICATIONS ..............................................................21
PN C3443001 AT0209
READ AND SAVE THESE INSTRUCTIONS!
CONTENTS

2
RECORD MODEL AND SERIAL NUMBERS BEFORE INSTALLATION!
Please take a moment to locate the model number and serial number from your fan (see below) and record this information on
the Warranty page inside the front cover of your Owner’s Manual if it does not appear there already.ese numbers are found on
the motor identification plate affixed to the fan motor in the location shown below:
PLEASE INSPECT ALL PACKAGING PRIOR TO DISCARDING!
Your Casablanca fan was crafted with pride and care and inspected thoroughly prior to shipment. Before
you begin to assemble and install your Casablanca fan, remove all parts from the carton and check them
against the Parts Guide in this manual.
Make sure all parts are included in the box using
the Parts Guide on the following pages.
If there are missing or broken parts:
Call 1-888-227-2178 Monday through Friday,7 a.m.to 4 p.m.
PST.Your request will be handled immediately.Replacement
parts will be sent to you via Federal Express.
Proper Parts Handling
Do not remove lightbulbs from their packaging until you are
ready to install them.
Before discarding packaging materials,be certain that all parts
have been removed.
Use a clean, dry paintbrush to remove small Styrofoam pieces
that may remain after unpacking.
Do not brush Styrofoam into wiring cavities.
e blades in each pack are matched for equal weight to assure
smooth fan operation.If more than one fan is being installed,
do not mix blades from different cartons.
When cleaning,painting,or working near your fan,be cautious
of the fan and blades.
Always turn power to the ceiling fan OFF before replacing
lightbulbs or working on your fan.
Never insert anything into the path of the fan blades while
the fan is in operation.
Never install a fan over a pool or spa.
Never operate a fan that has been damaged in any way.
Install the fan according to the instructions in
this manual.
If the fan does not work:
Refer to the Troubleshooting Tips in this Owner’s Manual.
Call Technical Support at 1-888-227-2178.
Contact your local Authorized Service Center.
Our Web site at www.casablancafanco.com contains additional
information on Casablanca products, troubleshooting, and
Authorized Dealer or Service Centers. Please do not return
this product to the store.
Serial Number
Model Number
Vermont®
TYPE HANGER TYPE
DJ01 1151 MODEL #C34G624M
POMONA, CA
SERIAL No.: DJ06 2237
C34G624M
Motor Identification Plate

3
Parts Guide
Item # Description Picture (not to scale) Quantity
1. Motor Housing 1
2. Ceiling Mounting Bracket 1
3. Motor Assembly 1
4. Phillips Screwdriver 1
5. Screw Pack (A):
11/2" x 8-32" Roundhead screws and Washers 2 EA
6. Screw Pack (A):
11/2" Wood Screws and Washers 2 EA
7. Screw Pack (A):
3" Wood screws and Washers 2 EA
8. Screw Pack (A):
Wire Nuts (4), 4
9. Screw Pack (B):
Hole Plugs 4
10. Screw Pack (B):
Motor Housing Mounting Screws 2
11. Blades 5
12. Blade Irons 5
13. Blade Medallions 5
14. Screw Pack (C):
Blade Screws 21
15. Screw Pack (D):
Blade Iron Screws 11

4
Item # Description Picture (not to scale) Quantity
16. Light Kit 1
17. Socket Plate 1
18. Screw Pack (E):
Switch Housing Plate Screws 3
19. Screw Pack (E):
Socket Plate Screws 3
20. Halogen Lightbulb, 100W 1
21. Lightbulb Shield 1
22. Glass Shade 1
23 W-72 Control, Bracket, Battery, and Mounting Hardware 1

5
Ve r m o n t ®
Circuit Breaker
(Trip breaker for the
circuit you will be
working on)
Fuse Box
(Remove fuse for the
circuit you will be
working on)
18"
84"
70"
Safe USe
IntrodUctIon
Before YoU Start
from bottom
edge of blade

from wall
to end of
blade
from wall to
center of fan
Dimensions indicated are the minimum
allowable for proper installation.
•CAUTION:RISK OFELECTRICALSHOCK! Installationis to beinaccordancewiththe NationalElectricalCode,

electrician. To avoid overheating and possible damage to other equipment, do not install control to a receptacle,

 
ceiling fan installations. If it is not, a new box must be installed.
• This ceiling fan requires a grounded electrical supply of 120 VAC, 60 Hz and a minimum 15 amp circuit. The

Maximum light current is about .83 amps or 100 watts of lighting.
•Where wire nuts are employed, be sure all bare wires are within the connectors.
•WARNING: Do not bend the blade brackets when installing the brackets, balancing the blades, or cleaning the
fan. Do not insert foreign objects in between the rotating fan blades.
Unpacking
Before assembling and installing your ceiling fan, remove all parts from the shipping cartons and check them
against the parts listed in the Parts Guide. Before discarding packaging materials, be certain that all parts have
been removed.
For best performance and for your warranty to be valid,
useonlygenuineCasablancablades,lightxtures,andaccessories.
•Thebladesineachpackarematchedforequalweight
to assure smooth fan operation. If more than one fan
is being installed, be careful not to mix blades from
different cartons.
•Inspect the contents of your carton for possible
shipping or handling damage. If parts are missing or
damaged, call 1-888-227-2178.
•It is always a good idea to have an assistant to help
with the installation.
•When cleaning, painting, or working near your fan,
be very careful of the fan and blades.Always turn the
power OFF to the ceiling fan before working on it or
replacing lightbulbs.
•Never insert anything into the path of the fan blades
while the fan is in operation.
 
•Never operate a fan that has been damaged
in any way. For assistance in obtaining
service, call Casablanca Fan Company at
1-888-227-2178 or contact your local authorized
Casablanca dealer.

6
MOUNTING RECOMMENDATIONS
Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air
circulation, and fan size are all important factors to consider before installation.
Location
Ceilingfans havepracticalusesinalmosteveryroom inyourhome.Wesuggest
you follow these mounting recommendations as you decide where to install
your Casablanca fan.
 
              

 
 
for the blades.
 
of the bed.
 
avoid damage from pool cues.
      
clear the fan blades.
 
humidity combined with corrosive gases will destroy the

Fan Size
Variable fan speed capability permits the use of a full-size
52" fan even in smaller rooms. For very large rooms, two
fans may be needed.
GENERAL GUIDELINES
Using Existing Ceiling Fixture Outlet Box


it is not, a new box must be installed.
Installing a New Ceiling Fixture Outlet Box


GETTING STARTED
ceiling outlet
box
support
brace
standard
mounting
style
WARNING!
Toreducetheriskofre,electricalshock,or
personal injury, mount to outlet box marked
“Acceptable Fan Support of 22.7 kg (50
lbs.) or less” using the mounting hardware
provided with the outlet box.

7
Ve r m o n t ®
CEILING BRACKET BRACKET INSTALLATION
Step 1. Route the outlet box wires through the center
hole of the ceiling bracket.Attach the ceiling bracket to
theoutlet boxwith themounting hardwareincludedwith
the outlet box, ensuring that the outlet box wires are
not pinched by the washers or between the mounting
bracket and the ceiling.
Ceiling Mounting Bracket Motor Assembly
Phillips
Screwdriver
Screw Pack A:
Wire Nuts (4),
CEILING BRACKET PREPARATION AND INSTALLATION
Screw Pack A:
11/2" x 8-32"
Roundhead screws (2),
washers (2),
CEILING BRACKET HARDWARE (not to scale)
CAUTION:
To reduce the risk of personal injury, use
only the mounting hardware provided with
theapprovedoutletboxtoinstalltheceiling
bracket.
Screw Pack A:
3" Wood screws (2)
washers (2),
Screw Pack A:
11/2" Wood Screws (2),
washers (2),

8
MOTOR INSTALLATION
2 Black
Wires
2 White
Wires
3 Green
Wires
Motor
Hook
Motor
Hook
Ceiling
Bracket
Loops
Figure #1
Figure #2
Ceiling
Bracket
Loop
Step 2a.Attach one of the hooks on the outside of
the motor onto one of the loops hanging from the
ceiling bracket as shown in Figure #1.
Step 2b. Trimexcessmotorwirestosixinchesand
attach the fan wires to the ceiling bracket wiring
by placing the bare end of the wires side by side
and then securing with a wire nut. Test that the
connection is secure by pulling on the wire nut.
Connect in this order:
• GREEN leads from ceiling bracket and motor to
GROUND conductor of power source. Secure
with wire nut as shown in Figure #2.
        
in ceiling bracket to the WHITE NEUTRAL
conductor wire from the power source. Secure
with wire nut as shown in Figure #2.

bracket to the BLACK conductor wire from the
power source. Secure with wire nut as shown
in Figure #2.

9
Ve r m o n t ®
Figure #3
Step 2c. Lift up on the motor, attach the second
hook on the outside of the motor onto one of the
other loops hanging from the ceiling bracket as
shown in Figure #3.
Step 2d. After making the wire connections, the
wiresshouldbetuckedintotheoutletboxasshown
inFigure#4.Thewiresshouldbespreadapart,with
thethreegroundedconductorwiresbeingplacedon
one side of the outlet box and the power conductor
wires being placed onto the other side of the outlet
box separating the connections.
NOTE: If the color of your ceiling wires differs from
that described, consult an electrician.
Step 2e. Lift up on the motor again and place the
thirdmotorhooklocatedon theside.Hangthehook
onto the last hanger loop on the ceiling bracket as
shown in Figure #5.
Figure #4
Figure #5

10
Step 3a. Locate and loosen the two motor housing
mounting screws that are located on the side of the
ceiling mounting bracket as shown in Figure #1.
Step 3b. Install the motor housing by aligning the
two slots on the inside of the motor housing with the
heads of the two mounting screws that are mounted
oneachsideoftheceilingmountingbracketasshown
in Figure #2. Then rotate the motor housing counter
clockwise until the heads of the two screws on the
ceiling mounting bracket lock together, attaching the
motor cover to the ceiling plate as shown in Figure
#3.
NOTE: When aligning the screws, center the motor
housing so that there is an even amount of space all
around the motor.
Motor Housing
Screw Pack (B)
Motor Housing Mounting
Screws (2)
Screw Pack (B)
Hole Plugs (4)
MOTOR HOUSING INSTALLATION
CEILING BRACKET HARDWARE (not to scale)
Ceiling
Mounting
Bracket
Motor Cover
Mounting Screws
Mounting
Slots
Motor Cover
Mounting Screws
Figure #1
Figure #3
Figure #2

11
Ve r m o n t ®
Step 3c. Installthelast twoofthe four motorhousing
mountingscrewsholdingthemotorcovertotheceiling
mounting plate as shown in Figure 4. Tighten all four
screws until hand tight.
Step 3d. Insert the four hole plugs as shown in
Figure#5coveringtheheadsofthescrews.Theplugs
inserted should look like Figure #6.
Figure #4
Figure #5
Figure #6

12
BLADE PREPARATION AND INSTALLATION
Blade Irons (5) Blade Medallions (5)
Blades (5)
Screw Pack C
Blade Screws (21)
Screw Pack D
Blade Iron Screws (11)
Step 4a.
thebladebadgeontotheblade(PackC),thenattaching
the bladeholder using the four blade screws provided
asshown inFigure#1. Usingtheprovidedscrewdriver,
tighten securely by hand only. Repeat for each blade
assembly.
Step 4b. Attach each blade/bladeholder assembly to
the motor by threading two blade iron screws (Pack
D) through the matching holes in the blade iron and
the motor as shown in Figure #2. Using the Phillips
      
blade assemblies have been installed, tighten the
screws with the screwdriver as shown in Figure #3.
BLADE HARDWARE (not to scale)
Blade Screws
Blade Iron
Blade Badge
Motor
Blade Iron
and Blade
Figure #1
Figure #2
Figure #3

13
Ve r m o n t ®
LIGHT FIXTURE INSTALLATION
Light Kit Lightbulb Shield
Socket Plate
Glass Shade
Pack E
Switch Housing Plate
Screws (3)
Pack E
Socket Plate
Screws (3)
Halogen Lightbulb
LIGHT FIXTURE HARDWARE (not to scale)
Step5c. Insertthethirdscrewandtightenscrewswith
the provided screw driver attaching the light kit to the
switch housing plate as shown in Figure #3.
Step 5a. Locatethethreeswitchhousingplatescrews
in pack E. Screw in part way two of the three screws
in the switch housing plate as shown in Figure #1.
Switch Housing
Plate
Switch Housing
Plate Screws
Figure #1
Figure #2
Switch
Housing Plate
Switch Housing
Plate Screws
Light Kit
Light Kit
Wiring
Figure #3
Step 5b. Hold the light kit up to the motor. Feed the
wiresthroughthecenterholeandalignthetwoswitch
housing screws with the keyholes. Twist the switch
housing clockwise as shown in Figures # 2.

14
CAUTION:
Thehalogenbulbisverydelicate andshould
not be handled with bare hands. After
removing it from the box, grasp it gently by
the plastic covering or a soft cloth.
Step 5d. Remove the ceramic wire nuts from the
wires and set aside for use in the next two steps.

WHITE wire coming from the bottom of the motor.
Secure with a ceramic wire nut.

BLACK wire with white stripe coming from the
bottom of the motor. Secure with a ceramic wire
nut.
Step 5e.Carefully tuckin thewires sotheydonotget
pinched.Alignthethreeholesonthesocketplatewith
the screw holes on the switch housing. Insert three
socketplatescrews(PackE) andtightenuntil secure
using the screwdriver as shown in Figure #1.
Ceramic
Wire Nuts
Socket Plate
Socket Plate
Screws
Halogen
Lightbulb
Lightbulb
Shield
Lightbulb
Sockets
Halogen
Lightbulb
GLASS INSTALLATION
Figure #1
Figure #2
Figure #3
Install Halogen Bulb
Step 6a. Insert one end of the halogen bulb into the
socket. Push the end of the socket, then insert the
other side of the halogen bulb into the socket. as
shown in Figure #2.
Step 6b. Install the glass shield by pushing it into
place with the clips on the light socket as shown in
Figure #3.
NOTE: In compliance with US Federal Energy
Regulations, this ceiling fan contains a device that

Exceedingthatlimitorthemarkedlimitonthisproduct


15
Ve r m o n t ®
Step 7a. Position the indentations in the outer rim
of the glass shade so that they line up with the tabs

Step 7b. Carefully lift the glass shade up inside the

a clockwise direction until it is held tightly in place
by the three tabs as shown in Figure #1.
Figure #1
Figure #2

16
Screw
6-32 X 1"
(2)
Screw
6-32 X 3/8"
(2)
Wood
Screw
1" (2)
Drywall Anchor
6-32 (2)12v Battery
W-72
Control
W-72
Control Holder
VERSA•TOUCH2® COnTROl InSTAllATIOn
CONTROL BRACKET INSTALLATION
Standard Light Switch
Step A. Remove the two screws holding the switch
cover plate. Do not remove the cover plate.
Step B. Orient the control bracket as shown and line
up the two inner mounting holes with those on the
switch.
Step C. Insert and tighten the screws using the
provided screwdriver.
Inner
Mounting
holes
Control
Bracket
Standard
Toggle
Switch
Switch
Cover
Plate
Rocker Light Switch
Step A. Break off the two tabs by pushing outward.
Step B. Remove the two screws holding the switch
cover plate. Do not remove the cover plate.
Step C. Orient the control bracket as shown and line
up the two inner mounting holes with those on the
switch.
Step D. Insert and tighten the screws using the
provided screwdriver.
Outer
Mounting
Holes
Control
Bracket
Rocker
Light
Switch
Switch
Cover
Plate
Wall Installation
Step A. Locate a 2x4
wall stud in a convenient
location.
StepB.Orient thecontrol
bracket as shown over
the 2x4 stud.
StepC.Insertthe1"wood
screws in either the inner
or outer mounting holes
and tighten using the
provided screwdriver. Decor Ovalhead Screw
6-32 X 1"
Anchor
Panhead
Screw Drywall Anchor
NOTE: The wall anchors and 6-32 x 1" screws may
be used in situations where mounting to a stud is not
possible.Usetheinnermountingholes.Aftersecuring
the anchor, discard the anchor’s pointed screws and
use the 6-32 decor ovalhead screws supplied.
Wood
Screw 1"
VERSA•TOUCH2®HARDWARE (not to scale)
Step 8. Follow instructions for the type of transmitter control bracket you will be using.
SAFETY FIRST: To reduce the risk of electrical shock, this fan must be installed with an isolating
wall control/switch. CAUTION! Do not use with wall dimmer.
WARNING:Toreducetheriskofreorelectricshock,donotusethisfanwithanysolidstatespeed
control device. Use only the control provided with this fan.
®

17
Send Signal
LED
Fan Control
To start the fan. Press the selected speed button to run the fan at the desired
speed.
LOW=Low speed MED=Medium speed HIGH=High speed
To turn off the fan, press the FAN OFF button.
AirowDirection
          
any speed whether the fan is on or off. The fan returns to its set speed after
reversing.
Light Control
Turn the light on or off independently from the fan by pressing the LIGHT button.
Ifyoupressthe buttonformorethan0.7seconds,it becomesadimmer.Thelight

the LIGHT button, this sequence will reverse when the light reaches its brightest
or dimmest level. Release the button when the desired level is reached.
Memory Feature
The last light fuction and fan speed will resume when power is turned back on.
Auto Resume
Quick (pressing less than 0.7 seconds) on/off operation of the LIGHT button
maintains the desired brightness level set previously.
LOW
MED
HIGH
LIGHT
FAN
OFF
REVERSE
REMOTE OPERATION
®
Install Battery
Press battery into control aligned as shown.
Observe proper polarity. Replace the battery
door.
Remove Battery Door
Turn control on its front. Twist a coin or use your
A. Lift door away from
control B.
12V BATTERY
BATTERY INSTALLATION

18
If the fan is not functioning after installation:
Step 1. Check to make sure that batteries are installed
correctly in the control.
Step 2. Turn the power off to the fan (from the circuit
breaker) for at least 5 seconds.
Step 3. Turn the power back on (at the circuit breaker) and
push the HIGH, MED, and LOW buttons–in that order–
within 20 seconds.
Step 4. The fan should now function properly.
CHANGING TRANSMITTER FREQUENCY SETTING
You will only have to change the dip switch settings in the
remoteif youare usingmorethanonefaninthesamearea
and want to control them separately.
Step 1. At the circuit breaker or fuse box, turn the power
off for the fan you want to change.

and remove the batteries.
Step 3. Change the dip switch settings, assuring that they
      
fan.
Step 4. Re-install the batteries and the battery door on the con-
trol.
Step 5. At the circuit breaker or fuse box, turn the power
back on for the fan whose frequency you are changing.
Step 6. Within 20 seconds of restoring power, push the
HIGH, MED, and LOW buttons (in that order).
Circuit Breaker
or Fuse Box
Press in this order to set new
frequency:
1. HIGH 2. MED 3. LOW
Dip Switch
Set to “01001”
Dip Switch
Set to “10000”
Versa•Touch 2
Control
(back)
1
2
3
Note: You may want to label your controls to assure
you do not mix them up.
WARNING!
Do not turn the power off at the circuit
breaker, then back on, for the previously
installed Versa•Touch2 fan(s), as you may
inadvertently change the frequency settings
for it as well.


19
Ve r m o n t ®
Please refer to this troubleshooting guide before requesting service or contacting your dealer for assistance.
TROUBLESHOOTING TIPS
PROBLEM POSSIBLE REMEDIES
               
connections. Make sure the power is turned off during this inspection.
  
mounted in the switch housing.
  
  
         
that is not functioning. Check that the jumper switches match in both the receiver and the
transmitter.
  
            
balanced.
  
bracket is attached tightly to the ceiling outlet box and the downrod assembly is secured

  
tightened.
             
lightbulb(s).
  
the canopy and switch housing are not touching the metal parts and that they have not
fallen off the wire splices. Tighten as necessary.
                 
bladeholder screws.
  
  
  
  
  
  
  
  
  
  
  
  
  
  
In compliance with US Federal Energy Regulations, this
ceiling fan contains a device that restricts the light kit to a
maximum of 190 watts. Exceeding that limit or the marked

operation.

20
Fan Finishes
 
 
 

Blades
 
applied for added protection and beauty.
 
mild detergent and slightly dampened soft cloth. An antistatic agent may be used, but never use abrasive cleaning agents

No Need for Lubrication
 
for life.
 
Changing Lightbulbs
 
 
 Note: In compliance with US Federal Energy Regulations,
this ceiling fan contains a device that restricts the light kit to a maximum of 190 watts. Exceeding that limit or the
markedlimitonthisproductmayresultinarehazardorimproperoperation.
CARE RECOMMENDATIONS
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
1.This device may not cause harmful interference.
2.This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residental installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communication. However, there is no guarantee that the interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
 
 
 
 


For questions or to locate the nearest Casablanca Authorized Service Center call toll free: 1-888-227-2178
or visit us on the web at: www.casablancafanco.com
