Casablanca Utopian 54035 User manual

English
Owner’s Guide and Installation Manual
Lifetime Limited Warranty
If purchased from our authorized dealer, this ceiling fan is warranted to the original purchaser by Casablanca Fan Company against defects in materials and workmanship for the following: Motor excluding Electronics�������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������Lifetime Component Parts, Electronic or Manual Control, Blades, Light Fixture, and Finish�����������������������������������������������������������������������������������������������������������One Year
Light bulbs ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������No Warranty During the warranty period, we repair (or, at our option, replace at no charge) a defective product� For details, contact Casablanca at 1-888-227-2178 or visit us on the Web at www�CasablancaFanCo�com� HOW TO OBTAIN SERVICE: Contact Casablanca for the name of the nearest Authorized Service Center or refer to the Authorized Service Centers list included with this Owner’s Manual� Do not return your fan without approval from Casablanca Fan Company� Should it become necessary to return your fan to an Authorized Service Center, make sure it is packaged properly to avoid in-transit damage, which is not covered by this warranty�
WHAT IS NOT COVERED:
Casablanca Fan Company requires the use of genuine Casablanca accessories with this fan�
Where a failure of this fan is caused by the use of accessories not supplied by Casablanca, this warranty is void�
This warranty does not apply if the product has been damaged by improper installation, neglect, accident, misuse, exposure to extremes of heat or humidity, or as a result of
service or modication by other than a Casablanca Authorized Service Center� In addition, this warranty does not cover minor variations in plated metal nishes due to the
imperfect nature of the plating and nishing process� Handblown glass may contain blisters, seeds, or thin lines� These characteristics are not defects, but substantiate that this
is hand blown and handcrafted glass� All costs of installing, removing, and reinstalling the product are the responsibility of the owner� Under-warranty motors requiring repair
must be shipped to the factory for replacement� Casablanca will pay for shipping charges incurred in sending the defective product from the customer to Casablanca Fan
Company as well as for return UPS shipment� No other expressed warranty is given� The repair or replacement of a product is the consumer’s exclusive remedy�
Any implied warranty of merchantability or tness is limited for consequential or incidental damages� IN-HOME SERVICE: Casablanca offers In-Home Service where available as follows: Within the rst 120 days, Casablanca will send a eld service representative to repair or replace the part or parts deemed to be defective from the factory� Most Service Center contracts cover up to a 30-mile radius from their place of business� Casablanca will not cover repairs caused by improper installation� After the 120-day period, the consumer will be charged for the service call and labor� Casablanca will pay for all defective parts through the duration of the parts warranty� NOTE: Service Centers are required to submit a Proof of Purchase with each warranty claim� The consumer must provide a copy of the Proof of Purchase at the time of service� If no in-home service is available, the consumer has the option of sending an in-warranty fan to Casablanca Fan Company in Memphis, TN, for repair� The fan must be packaged properly, shipped freight prepaid, and include a copy of the Proof of Purchase� The fan will be repaired and returned at no charge to the consumer, freight prepaid�
Utopian
Utopian Utopian
1.888.227.2178
IMPORTANT!
______________________________
Model Number
______________________________
Date Purchased
______________________________
Where Purchased
Read and Save These Instructions
The information below will make
communication MUCH easier
should you ever need to contact
customer service�
If parts are missing,
DO NOT RETURN THIS ITEM
TO THE STORE!
For assistance call 1-888-227-2178
www.CasablancaFanCo.com
Model 54035
©2012–2015 Casablanca Fan Co�

104
53 55
Pre-installed Parts
13 26
#Item# in Parts List
Spare Parts Bag
Hardware drawn to scale
For your convenience, you may receive extra fasteners�
131 140
Included Accessories
Optional Accessories
30
These parts are used only if adding a light kit to the fan�
72 5971 57
5
11
718
20
28
24
66
96
63
51
98
Parts List
MODEL # 54035
DRAWING # K0295-01
Weight ±2 lbs 21.4 lbs (9.7 kg)
FINISH Brushed Cocoa
Item# Item Name Qty. Part#
1Hanging System Kit 1 K0065-02
5Ceiling Bracket 1
7Canopy 1
11 Downrod Assembly 1
13 Setscrew 1
18 Canopy Screw 2
20 Wood Screw 3” 2
24 Flat Washer 2
26 Mounng Isolator 4
28 Wire Connector 4
30 Hanger Pipe 1
50 Hardware Kit 1 K0295-00-860
51 Blade Assembly Screw 16
53 Machine Screw 6-32 3
55 Switch Housing Assembly Screw 3
57 Switch Housing Cap Screw 2
59 Light Kit Adapter Screw 2
63 Blade Grommet 16
66 Switch Housing Assembly 1 K0058-02
71 Switch Housing Cap 1 K0188-01
72 Light Kit Adapter 1 K0182-03
79 Wire Harness (not shown) 1 K0165-02
96 Blade Iron Set 1 K0220-05
98 Blade Set 1 K0423-25-026
104 Blade Iron Armature Screw 11 K0064-02
131 Fan Pull Chain Pendant 1 K0185-04
140 Balancing Kit 1 K0118-01
PARTS GUIDE
Casablanca Fan Company • 7130 Goodlett Farms Parkway #400 • Memphis, TN 38016 • www.CasablancaFanCo.com • 98000-03-019 • 06-29-2015 • ©2015
