Casio Casiotone 1000P User manual

OPERATION MANUAL
MANUAL DE OPERACION

i iw : .
Thank you very much for purchasing the Casiotone
1 000P, we hope it gives you many years of enjoyment.
The Casiotone 1000P is a valuable and exciting intro 
duction to the world of music, assembling myriad
sounds onto an electronic keyboard with under-arm
portability.
It is different from conventional synthesizers in that
it permits sounds to be created simply by combining
numbers using the sound programming function. There
is also an arpeggio programming function so you can
freely combine arpeggio patterns to support your
performance on the keyboard or accompany other
instruments in a group.
CasiotonelOOOP
ELECTRONIC MUSICAL INSTRUMENT
This booklet has been prepared to help you explore the
many
functions of the Casiotone 1000P and become
familiar with its varied abilities.
y:.; 1 ;.' ; •
CONTENTS
1 Unique features of the Casiotone 1 000P
]
2
In and around the Casiotone 1000P
2
3 Power Supply
5
4
Casiotone 1000P — Starting to Play
6
5
Sound Programming Function
9
6
Arpeggio Programming Function
15
7
Preset Arpeggio Function
2 e
8 Tuning (Transposing)
21
9 Troubleshooting Chart
23
10 Care of Your Unit
24
11
Specifications
25

Sound programming allows the
simple creation of 1000 sounds
and storage in 10 memories.
With the selective use of FEET, ENVELOPE and
MODULATION and the combination of numbers
shown on the digital display, as many as 1000
different sounds can be created. The ones you like
best, up to 1 0, can be stored in the memory.
A programmable arpeggio
function freely combines
arpeggio patterns and can also
be used as a sequencer.
Arpeggio patterns can be freely programmed to
match the music.
Since up to 127 steps, 9 note pitches and rests
can be stored, it is possible to use this function
for high class arpeggio or as a sequencer.
A digital frequency display and With a clear digital display of the frequency,
wide range digital pitch control tuning can be perfected visually as well as by
provides transposing function. sou ^- s J, nce tbe varia J ble / a A ng L g ° e 1 ! from 221 Hz
r to 662 Hz, with standard A=442 Hz, transposing
is also possible between minus 1 octave and plus
0.5 octave.
S 10 preset sounds and a 16-Step 10 beautiful preset sounds - the Piano, Jazz
up/down preset arpeggio give Organ, Vibraphone, etc. can be selected with one
big musical scope. touch - Also - since a . 16 - st ^P up/down arpeggio
° r pattern is preset, music with a professional back
ground can be enjoyed.
A* Various sound effects give full
play to musical expressions.
The Casiotone 1000P provides various sound ef 
fects such as Sustain — which produces a beautiful
lingering effect, Vibrato and Delayed Vibrato —
indispensable for delicate, emotional expressions,
and Heavy Vibrato — which creates a modern
musical ambience.
The keyboard split function
allows you to play the melody
and chord separately with
different sounds.
The 61 -key, 5-octave keyboard can be split into
3-octave upper keyboard and a 2-octave lower
keyboard
with one touch. Since different sounds
can be independently set for each section, you
can enjoy a wide variation of the performance
as if using a two-tiered organ keyboard.
Complete, yet compact
keyboard with 61 keys,
5 octaves and
8 -note polyphonic.
The note range accomodates all kinds of music
from classics to pops. And, with 8-note poly 
phonic, chord playing is truly realistic. All this,
in an instrument that is easily portable.
- 1 -

(Rear panel)
® i ® | ' ®
© © ©
(0 Power ON/OFF Switch
(?) TUNE Button
® TUNE/ARPEGGIO TEMPO Control
(4) TONE SET Button
( I> LOWER VOLUME Control Knob
(6) SPLIT Button
@ RECORD Button
(1) MEMORY Button
(9) UP/DOWN Button
© PROGRAM Button
(Q) Digital Display
©Sound Selection Buttons
©Sound Characteristic Data Chart
04) PROGRAM/PRESET Button
© FEET Button
© ©
© ENVELOPE Button
© MODULATION Button
© VIBRATO Button
© DELAYED VIBRATO Button
© HEAVY VIBRATO Button
© SUSTAIN Button
© Main Volume Control Knob
© Built-in Speaker
(Rear panel)
© Headphone jack (PHONES)
© Output Jack (LINE OUT)
© FOOT VOLUME jack
© SUSTAIN jack
© AC Power Socket

■.....■ ....
Each time a button is pressed, it t urns the function on
and off. When on, a red indicator
lamp will light (except for the So und Selection Butte
ns). The UP/DOWN Button and
the PROGRAM Button indicators will blink in time
vith the arpeggio tempo which is
currently established.
® Power ON/OFF Switch
Turns the power on and off.
©TUNE Button
Press on when tuning or transposing.
©TUNE/ARPEGGIO TEMPO Control Knob
Adjusts arpeggio speed or note pitch. Turning the knob to the right increases the tempo
of the arpeggio or raises the pitch of the notes. Turning the knob to the left decreases the
tempo
of the arpeggio or lowers the pitch of the notes. If you continue to turn the knob
in one direction, it will eventually return to the lowest or highest setting as it employs an
endless system control.
©TONE SET Button
Press on to set the sound for the lower keyboard (lower two octaves) when the keyboard
is split.
©LOWER VOLUME Control Knob
Adjusts the volume of the lower keyboard (lower two octaves) when the keyboard is split.
As this is adjusted relative to the main volume, it will not function when the Main Volume
Control Knob is set to MIN.
©SPLIT Button
Press on to split the upper three octaves and the lower two octaves of the keyboard. In
this case, the lower two octaves will become one octave higher.
©RECORD Button
Press on the PROGRAM Button and this button at the same time when programming
arpeggio patterns.
©MEMORY Button
If this button is pressed on, while playing arpeggio, the sounds will continue to be produced
until the next chord is pressed even if the fingers are removed from the keyboard.
©UP/DOWN Button
Press on when you want to play arpeggio using the preset arpeggio pattern (16-step, up/
down pattern).
CO>PROGRAM Button
When programming an arpeggio pattern, press on the RECORD Button and this button
at the same time. Also, press on when playing arpeggio using the programmed arpeggio
pattern.
©Digital Display
Displays the preset sound number, programmed sound memory number, sound character 
istic numbers and note pitch (Hz).
©Sound Selection Buttons
Press to select preset sounds or programmed sounds. Also, these buttons are used when
programming sound characteristics or arpeggio patterns.
©Sound Characteristic Data Chart
Shows the various sound characteristics for sound programming. (10 elements each for
FEET, ENVELOPE and MODULATION).

©PROGRAM/PRESET Button
Each time this is pressed, it selects either the preset sounds or programmed sounds.
©FEET Button
Press on to designate the feet while programming a sound.
©ENVELOPE Button
Press on to designate the envelope while programming a sound.
©MODULATION Button
Press on to designate the modulation while programming a sound.
©VIBRATO Button
Press on to give warmth and strong expression to the sound. It allows full and effective
tonal reverberation.
©DELAYED VIBRATO Button
Press on to'get a delayed vibrato effect. It allows a certain delay of the vibrato after de 
pression of a key.
©HEAVY VIBRATO Button
Press on to give a heavy vibration to the sound. It creates a modern musical ambience.
©SUSTAIN Button
Press on to get a sustain effect. The sound lingers on even after the fingers are removed
from the keyboard.
©Main Volume Control Knob
Adjusts the volume of the entire instrument. Turning the knob to the right increases the
volume.
©Built-in Speaker
Delivers ideal sound for home parties, personal listening or musical lessons.
(Rear panel)
©Headphone Jack (PHONES)
If a headphone (optional) is connected, the speaker sound will be automatically cut off
and playing can be enjoyed privately.
©Output jack (LINE OUT)
If the instrument is connected to audio equipment or a keyboard amplifier, etc. and ex 
ternal speakers, playing can be enjoyed with a more powerful volume. The volume can be
adjusted by using the volume control on this instrument or a foot volume control pedal
(optional).
© FOOT VOLUME Jack
By
connecting a foot volume control pedal (optional) to this jack, free volume change
can be made by foot during play.
©SUSTAIN Jack
If a sustain pedal (optional) is connected, a lingering sustain effect can be obtained while
stepping on the pedal, even after keyboard playing has finished.
©AC Power Socket
Connect the AC power cord (standard accessory).
- 4 -

( Main Power Supply )
AC power socket
The Casiotone 1 000P uses domestic AC for a power
supply. Connect the provided AC power cord to the AC
power
socket on the Casiotone 1000P and plug it into
an AC outlet.
( Memory Protection Power Supply )
v-_ --------- — — ----------- ; — : -------------- — — — A C ou 1 1 e t
Any programmed sound and arpeggio will be protected
even when the main power supply (Power ON/OFF
Switch) is turned OFF. Three AA size manganese dry
batteries
(UM-3) are used as backup power for memory
protection. Battery life is approximately one year, during
which
time the memory contents will be retained.
When batteries become weak, a distorted sound, different
from the one you programmed, may be produced or an
erroneous display appears. It is advisable to replace the
batteries once a year to avoid the above conditions.
[Battery Replacement]
The battery compartment is located on the back panel
of the instrument. Slide open the lid and replace the
batteries making sure the © and 0 terminals are facing
correctly.
Note:
T 3
H
r 1
fOPEN A
i
T
a b r~
’ lit!
i
i
1
1
00 s
1
1
t
SI
m
i
;
j 1
---------- — —
Since the lifespan of UM-3 or SUM-3 batteries is approximately one year, replace all three
batteries
once a year. The original batteries are installed at the factory, so the first replacement
should be made within approximately 8 to 10 months. Also, when the instrument is to be
left unused for a long time, remove the batteries to avoid damage caused by leakage.
Removing the batteries clears the memory contents. So, when the power is switched
ON just after battery replacement, the sound or display may be confused. Press a
Sound Selection Button to return to a normal condition. However, the programmed
sound and arpeggio need to be re-programmed.
.... ■ " '

( Turn the pow er ON . )
When the Power ON/OFF Switch is turned ON, the digital
display
will illuminate to show the Casiotone I000P is operat 
ing. At this time, a number between 0 and 9 will be displayed.
This
is the number of the preset sound set prior to turning the
power
OFF.
OFF
ON
POWER
* If the memory number of the programmed sound was last
set prior to turning the power OFF, that memory number
will be displayed as the number of the preset sound.
f
J
Preset sound number
'
Switching the power OFF and then ON again turns off all of the buttons on the
Casiotone 1000P. This Operation Manual will explain the instrument from this initial
condition. Therefore, switch the power OFF and then ON again to prepare the instru 
ment before starting to play.
* The sound and arpeggio which have been preset or programmed are protected by
a separate power supply.
Let's produce some sounds. )
With the Casiotone 1000P in this initial condition, the preset
sound whose number is shown on the digital display is set in
the entire 5-octave keyboard. Set the Main Volume Control
Knob as illustrated on the right and play the keys. Adjust
the volume while pressing the keys.
VOLUME
( Now, selec t one of 1 0 prese t sound s. )
The Casiotone 1000P has 10 preset sounds such as
Jazz Organ, Piano, Vibraphone . . . and by pressing
the Sound Selection Buttons, any one can easily
be selected. The number of the selected preset
sound will appear on the digital display.
* The CPU ME sound can be used as a sound
effect as it contains various musical intervals.
JAZZ
ORGAN BASSOON
3 4
Preset sound name
Preset sound number
Sound Selection Buttons
(Preset sound display)
3
3
A single-digit number (0 — 9)
shows the preset sound number.
Each time the PROGRAM/PRESET Button is pressed, the two sets of information
shown below will change alternately on the display. When only one digit is displayed,
the preset sound can be selected by using the Sound Selection Buttons.
(Preset sound display)
(Sound programming display)
-
3
3
n _ 3
u
3
- 6 -

( E xperiment with s ome effects. )
There are four effect buttons as shown on the right. Each time
the buttons are pressed they turn on and off. When they are on,
the respective indicators will light up.
• VIBRATO
This is a normal vibrato effect.
VIBRATO
DELAYED HEAVY SUSTAIN
viohmiu V1BRATQ VIBRATO
• DELAYED VIBRATO
This is a delayed vibrato effect.
• HEAVY VIBRATO
This gives a heavy vibration to the sound.
• Only one vibrato effect may be selected at one time.
• SUSTAIN
A lingering sound remains even after the fingers are removed from the keyboard.
( How to split the keyboard, )
If the SPLIT Button is pressed, the 61 -key, 5-octave keyboard
will be split into a 3-octave upper keyboard and a 2-octave
lower keyboard, each one adopting 4-note polyphonic. At
this time, the lower keyboard note range will raise one octave
and become a note range suitable for accompaniment.
A
B
C D E
Lower keyboard (4-note polyphonic) Upper keyboard (4-note polyphonic)
* Since the note range of A and B is raised one octave, B
becomes in the same note range as C.
LOWER
TONE SET - SPLIT
Lower Keyboard Volume Adjustment
The volume of the lower keyboard (lower two octaves) can be
independently adjusted. This is done by using the LOWER
VOLUME Control Knob. Turning the knob to the right in 
creases the volume. However, if the Main Volume Control
Knob is set to MIN, even if the LOWER VOLUME Control
Knob is set to MAX, no sound will be produced.
Lower Keyboard Sound Selection
Different sounds can be independently set for the lower and
upper keyboards.
(1)
Press both the SPLIT Button and the TONE SET Button
on.
• 7 he SPL 11' and TONE SET indicators will light.
TONE SET
- SPLIT
7

wag;;
(2) Press the desired Sound Selection Button. ^
• The number of the selected preset sound will be displayed J
JAZZ
ORGAN
BASSOON
WAH
BRASS
PI.
on the digital display.
3
4
5
(3) Press the TONE SET Button off.
• The TONE SET indicator will go off.
* With the above operation, the desired sound pressed in
Step 2, above, is now set in the lower keyboard.
When the Sound Selection Button is pressed in Step 3 (TONE
SET Button: off, SPLIT Button: on), that sound can be
set only in the upper keyboard.
TONE SET - SPLIT
T:-
• The sound set in the lower keyboard will be deleted and the sound set in the upper
L •• ..till U o i . »■ /*. o «•■ /• •> I U « rot • a U a I a 11 / a »• /n \ i io tU a r a rui'inft cnroc
8
