Casio 5478 User manual

Operation Guide 5478
E-9
To do this: Enter this mode: See:
xView the current time in one of 48 cities
(31 time zones) around the globe
xSwap Home Time and World Time
World Time Mode E-40
Set an alarm time Alarm Mode E-44
E-8
Mode Reference Guide
The mode you should select depends on what you want to do.
To do this: Enter this mode: See:
xView the current date in the Home City
xConfigure Home City and daylight saving time (DST)
settings
xConfigure time and date settings
xOne-press stopwatch timing start
xChange the display illumination duration setting
xEnable/disable the button operation tone
Timekeeping Mode E-17
xUse the stopwatch to measure elapsed time
xUse Target Time Alarm Stopwatch Mode E-25
Use the countdown timer Countdown Timer Mode E-36
E-7
Illumination. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
To turn on illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
To change the illumination duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-49
Adjusting Hand Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-50
Button Operation Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-53
To turn the button operation tone on and off . . . . . . . . . . . . . . . . . . . . . . . . . E-53
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-55
Main Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-56
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-59
E-6
To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-39
Checking the Current Time in a Different Time Zone . . . . . . . . . . . . . . . . . . . E-40
To enter the World Time Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-41
To view the time in another time zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-41
To specify standard time or daylight saving time (DST) for a city. . . . . . . . . . . E-42
To swap your Home City and World Time City . . . . . . . . . . . . . . . . . . . . . . . . E-43
Using the Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-44
To enter the Alarm Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-44
To set an alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-45
To test the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-46
To turn an alarm and the Hourly Time Signal on and off . . . . . . . . . . . . . . . . . E-47
To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-47
E-5
Using the Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-25
To enter the Stopwatch Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-26
To perform an elapsed time operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-28
To pause at a split time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-28
To measure two finishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-28
To set a target time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-30
To use the target time alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-31
To stop the alert beeper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-35
To perform stopwatch timing without using the Target Time Alarm. . . . . . . . . E-35
Countdown Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-36
To enter the Countdown Timer Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-36
To configure the countdown timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-37
To perform a countdown timer operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-38
E-4
Contents
About This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2
Things to check before using the watch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3
Mode Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-8
Timekeeping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-17
Configuring Home City Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-18
To configure Home City settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-18
To change the Daylight Saving Time (summer time) setting . . . . . . . . . . . . . . E-20
Adjusting the Digital Time and Date Settings . . . . . . . . . . . . . . . . . . . . . . . . . E-21
To configure the digital time and date settings . . . . . . . . . . . . . . . . . . . . . . . . E-21
E-3
Things to check before using the watch
1. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under “To configure Home City settings” (page E-18) to configure
your Home City and daylight saving time settings.
Important!
xProper World Time Mode data depends on correct Home City, time, and date
settings in the Timekeeping Mode. Make sure you configure these settings
correctly.
2. Set the current time.
xSee “Adjusting the Digital Time and Date Settings” (page E-21).
The watch is now ready for use.
E-2
About This Manual
xDepending on the model of your watch, display text
appears either as dark figures on a light background, or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
xButton operations are indicated using the letters shown
in the illustration.
xNote that the product illustrations in this manual are
intended for reference only, and so the actual product
may appear somewhat different than depicted by an
illustration.
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
MA1606-EA © 2016 CASIO COMPUTER CO., LTD.

Operation Guide 5478
E-19
3. After the setting is the way you want, press Ato return to the Timekeeping
Mode.
Note
xYou can check the city code and name (English) of your Home City by pressing A.
xAfter you specify a city code, the watch will use UTC* offsets in the World Time
Mode to calculate the current time for other time zones based on the current time
in your Home City.
* Coordinated Universal Time, the world-wide scientific standard of timekeeping.
The reference point for UTC is Greenwich, England.
E-18
Configuring Home City Settings
There are two Home City settings: actually selecting the Home City, and selecting
either standard time or daylight saving time (DST).
To configure Home City settings
1. In the Timekeeping Mode, hold down Auntil the
flashing SET Hold indicator disappears from the
display and the currently selected city code flashes on
the display.
xThis indicates the Home City setting mode.
2. Use D(+) and B(–) to scroll through city codes until
the one you want is displayed.
xFor details about city codes, see the “City Code
Table” at the back of this manual.
xHolding down either button scrolls at high speed.
City Code
E-17
Timekeeping
Use the Timekeeping Mode to set and view the current time and date.
Hour
Second
Day of week
Minute
Month-Day
Second
Hour : Minute
PM indicator
Dial hand
D
E-16
2. Holding down Bagain as you press Cwill cause the hands to return to their
normal positions (normal timekeeping).
Note
xWatch button functions are the same regardless of whether the hands are moved
out of the way or at their normal positions.
xChanging to another mode will cause the hands to move back to their normal
positions.
xThe hands also will move back to their normal positions automatically if no
operation is performed for about one hour.
Auto Return
xIf you do not perform any operation for about two or three minutes while
configuring settings (setting flashing on the digital display) in any mode, the watch
will exit the setting operation and return to normal display.
E-15
1. While holding down B, press C.
xThis will cause the hour and minute hands to move to a location where they do
not block your view of the digital display.
Example: When the current time is 8:23
Flashes while the hands are moved out of the way.
E-14
General Functions (All Modes)
The functions and operations described in this section can be used in all modes.
Moving the Hands Out of the Way for Better Viewing
You can use the procedure below to temporarily move the hour and minute hands
out of the way to better view what is on the display.
xThis operation can be performed in any mode. In the case of a setting mode
(setting flashing on the screen), the hands will move out of the way automatically,
even if you do not perform the below operation.
E-13
xThe dial hand indicates the mode (Timekeeping Mode: ).
When you enter the Timer Mode (TR) or Stopwatch Mode (ST), the dial hand first
indicates TR or ST, and then moves to the position shown below.
C
Alarm Mode Stopwatch ModeWorld Time Mode
C
C
E-12
Timekeeping Mode Countdown Timer Mode
C
C
E-11
xPress Cto cycle between the modes as shown below.
xTo return to the Timekeeping Mode from any other mode, hold down Cfor about
two seconds.
xIn any mode (except a setting mode), press Bto illuminate the display.
E-10
Selecting a Mode
xIn the Timekeeping Mode, press Eto enter the Stopwatch Mode.
xFor more information about using the Stopwatch Mode, see “To enter the
Stopwatch Mode” (page E-26).
Timekeeping Mode Stopwatch Mode
E
C

Operation Guide 5478
E-29
Note
xOnce started, elapsed time measurement continues until the elapsed time
measurement limit is reached, even if you change to a different mode.
Using the Target Time Alarm
You can set a target time in the range of one minute to 24 hours, in units of one
minute.
A beeper will sound for 10 seconds when the elapsed timing of the stopwatch
reaches the target time.
E-28
To perform an elapsed time operation
EE E E D
Start Stop (Resume) (Stop) Reset
To pause at a split time
ED D E D
Start Split
(SPL displayed)
Split release Stop Reset
To measure two finishes
ED E D D
Start Split
(SPL displayed)
First runner finishes.
Display time of first
runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Reset
E-27
Entering from Another Mode (including the Timekeeping Mode)
Press Cas many times as necessary to navigate to the Stopwatch Mode as shown
on page E-13.
xTo enter from the Timekeeping Mode using this method, press Cfour times.
xThis will display the stopwatch screen in the same status as it was the last time you
exited the Stopwatch Mode. However, if you exited with a split time displayed, the
split time operation will be released when you return.
E-26
To enter the Stopwatch Mode
You can enter the Stopwatch Mode using any one of the methods below.
Entering Directly from the Timekeeping Mode
If the stopwatch was reset to all zeros the last time you used it, a new elapsed time
operation will start as soon as you enter the Stopwatch Mode.
See page E-28 for information about measuring an elapsed time.
1. In the Timekeeping Mode, press E.
This will result in one of the following, depending on the status of the stopwatch the
last time you exited the Stopwatch Mode.
xIf reset (stopped at 0:00 00"00): Timing starts.
(One-press timing start from the Timekeeping Mode)
xIf an ongoing timing operation is paused: Timing remains paused.
xIf an ongoing timing operation is in progress*: Timing continues to be performed.
*An ongoing stopwatch timing operation continues even if you navigate to
another mode from the Stopwatch Mode.
2. Now you can perform the same operations as those shown on page E-28.
E-25
Using the Stopwatch
The stopwatch measures elapsed time, split times, and two finishes.
xThe measurement range of the stopwatch is 23 hours, 59minutes, 59.99 seconds.
When the measurement range is exceeded, measurement stops (display becomes
0).
Seconds
Minutes
Minutes
Seconds
1/100 Second
Hours
E-24
Note
xResetting the seconds to 00 while the current count is in the range of 30 to
59causes the minutes to be increased by 1.
xThe watch’s built-in full automatic calendar makes allowances for different month
lengths and leap years. Once you set the date, there should be no reason to
change it except after you have the watch’s battery replaced.
xThe day of the week changes automatically when the date changes.
E-23
3. When the timekeeping setting you want to change is flashing, perform the
operation described below.
Screen To do this: Do this:
Toggle between 12-hour (12H) and 24-hour
(24H) timekeeping Press D.
Reset the seconds to 00 Press D.
Change the hour or minute
Use D(+) and B(–) to
change these settings.
xHolding down either button
scrolls at high speed.
Change the year
Change the month or day
4. Press Ato exit the setting mode.
E-22
2. Press Cto move the flashing in the sequence shown below to select the other
settings.
Home City
(page E-18)
CDST
(page E-20)
C
12/24-Hour Format
C
Seconds
C
CHour
C
Illumination Duration
(page E-48) Minute
CC
Button Operation Tone On/Off
(page E-53) C
Day
C
Month
C
Year
E-21
Adjusting the Digital Time and Date Settings
Use the procedure below to adjust the digital time and date settings.
To configure the digital time and date settings
1. In the Timekeeping Mode, hold down Auntil the
flashing SET Hold indicator disappears from the
display and the currently selected city code flashes on
the display.
E-20
To change the Daylight Saving Time (summer time) setting
1. In the Timekeeping Mode, hold down Auntil the
flashing SET Hold indicator disappears from the
display and the currently selected city code flashes on
the display.
2. Press Cto display the DST setting mode.
3. Press Dto toggle between Daylight Saving Time (ON)
and Standard Time (OFF).
xNote that you cannot switch between daylight saving
time and standard time while UTC is selected as your
Home City.
4. After the setting is the way you want, press Ato
return to the Timekeeping Mode.
xThe DST indicator appears to indicate that Daylight
Saving Time is turned on.
DST indicator

Operation Guide 5478
E-39
To stop the alarm
Press any button.
E-38
To perform a countdown timer operation
EE E E D
Start Stop (Resume) (Stop) Reset
Countdown in Progress
Dial hand: Moves from right to left.
E-37
To configure the countdown timer
xIf a countdown timer operation is in progress, press E
to pause it and then press Dto reset the target time to
its start time.
xIf a countdown timer operation is paused, press Dto
reset the timer to its start time.
1. Hold down Auntil the flashing SET Hold indicator
disappears from the display and the minutes digits
start to flash. Release Aafter the digits start to flash.
2. Use D(+) and B(–) to change the minutes setting.
xHolding down either button scrolls at high speed.
3. After all the settings are the way you want, press Ato
exit the setting screen.
E-36
Countdown Timer
The countdown timer can be set within a range of
one minute to 60minutes. An alarm sounds when the
countdown reaches zero.
To enter the Countdown Timer Mode
Use Cto select the Countdown Timer Mode as shown
on page E-12.
Minutes
Seconds
Seconds
1/10 second
E-35
Note
xTARGET flashes in the above operation even if the watch is in another mode.
To stop the alert beeper
Pressing any button while the alert beeper is sounding will stop it.
xPressing Dor Eoperates the elapsed time operation on page E-28.
To perform stopwatch timing without using the Target Time Alarm
Use step 7 under “To set a target time” to disable the target time alarm.
E-34
(3) Target time reached
xBeep for 10 seconds.
xScreen: Changes as shown in the figure.
xTARGET becomes unlit.
(4) After target time is expired
xScreen: Rightmost indicator that indicates minutes flashes (at slow speed).
xElapsed time is measured, with TARGET remaining unlit.
xResetting the elapsed stopwatch time automatically causes TARGET to re-
appear. You can re-use the same target time, if you want.
E-33
(2) From target time half until target time is reached
xScreen: As shown in the figure, all of the part that
indicates minutes flashes.
xTARGET flashes at high speed starting from one
minute before the target time.
E-32
xYou can get an idea of time elapsed until the target time from changes in the
display.
(1) From start up to half of target time
xScreen: As shown in the figure, rightmost indicator that
indicates minutes flashes.
xTARGET starts to flash.
E-31
7. Press Dto toggle the target time alarm between on and off.
xTARGET is displayed while the target time alarm is on, and not displayed while
it is off.
8. After all the settings are the way you want, press Ato exit the setting screen.
To use the target time alarm
1. Reset the stopwatch to all zeros and then press E.
This will cause TARGET to flash on the display.
2. Now you can perform the same operations as those in the steps on page E-28.
(1) (2) (4)
(3)
Start Target time
E-30
To set a target time
1. Reset the stopwatch to all zeros.
2. Hold down Auntil the flashing SET Hold indicator
disappears from the display and the hour digit starts to
flash. Release Aafter the hour digit starts to flash.
3. Use D(+) and B(–) to change the hour setting.
xHolding down either button scrolls at high speed.
xFor a target time of 24 hours, set 00hours
00minutes.
4. Press Cto switch to the minutes setting.
5. Use D(+) and B(–) to change the minutes setting.
xHolding down either button scrolls at high speed.
6. Press Cto display the target time alarm on/off setting.
Hours
Target Time operation in
progress

Operation Guide 5478
E-49
To change the illumination duration
1. In the Timekeeping Mode, hold down Auntil the flashing SET Hold indicator
disappears from the display and the currently selected city code flashes on the
display.
2. Press Cten times to display the illumination duration setting screen.
xThe current illumination duration setting (1 or 3) will be flashing in the display.
xSee the sequence in step 2 of the procedure under “To configure the digital time
and date settings” (page E-21) for information about how to scroll through setting
screens.
3. Press Dto toggle the illumination duration between three seconds (3displayed)
and 1.5seconds (1displayed).
4. After all the settings are the way you want, press Ato exit the setting screen.
E-48
Illumination
The display of the watch is illuminated for easy reading in the dark.
To turn on illumination
Press Bin any mode to illuminate the display.
xYou can use the procedure below to select either 1.5 seconds or three seconds as
the illumination duration.
E-47
To turn an alarm and the Hourly Time Signal on and off
In the Alarm Mode, press Dto select an alarm or the
Hourly Time Signal.
xWhen the alarm you want or the Hourly Time Signal
is displayed, press Eto toggle it between on
(ON displayed) and off (OFF displayed).
xThe alarm on indicator (when any alarm is on), snooze
alarm indicator (when the snooze alarm is on), and the
Hourly Time Signal on indicator (when the Hourly Time
Signal is on) are shown on the display in all modes.
xSNZ and ALM will be displayed while the snooze
alarm is turned on.
To stop the alarm
Press any button.
Hourly time signal
on indicator
Snooze alarm on indicator
Alarm on indicator
E-46
3. Press Cto move the flashing between the hour and the minute digits.
xThe selected digits are those that are flashing.
4. Use D(+) and B(–) to change the hour and minute settings.
xHolding down either button scrolls at high speed.
xWhen setting the alarm time using the 12-hour format, take care to set the time
correctly as a.m. (no indicator) or p.m. (PM indicator).
5. Press Ato exit the setting mode.
To test the alarm
In the Alarm Mode, hold down Dto sound the alarm.
E-45
xIf you do not perform any operation for about two or three minutes in the Alarm
Mode, the watch will automatically return to the Timekeeping Mode.
To set an alarm time
1. In the Alarm Mode, use Dto display the alarm whose
settings you want to change.
AL1 AL3AL2
SNZSIG AL4
2. Hold down Auntil the flashing SET Hold indicator
disappears from the display and the alarm time hour
digits start to flash. Release Aafter the digits start
to flash.
xALM appears on the display, indicating that alarm
setting is enabled.
Alarm indicator
E-44
Using the Alarm
You can set five independent daily alarms. When a daily
alarm is turned on, an alarm tone will sound for about
10seconds each day when the time in the Timekeeping
Mode reaches the preset alarm time. One of the alarms
is a snooze alarm that repeats every five minutes, up to
seven times.
You can also turn on an Hourly Time Signal, which will
cause the watch to beep twice every hour on the hour.
To enter the Alarm Mode
Use Cto select the Alarm Mode as shown on page E-13.
xThe snooze alarm screen is indicated by SNZ, while the
other alarm screens are numbered AL1 through AL4.
The Hourly Time Signal screen is indicated by SIG.
xWhen you enter the Alarm Mode, the data you were
viewing when you last exited the mode appears first.
Alarm ON/OFF indicator
Alarm number
Alarm time (Hour : Minute)
E-43
To swap your Home City and World Time City
In the World Time Mode, hold down Efor at least three seconds.
This will cause SWAP Hold to flash on the display, and then your Home City and
World Time City will be swapped.
Example: To swap the Home City (TYO) and World Time City (NYC)
E, at least
3 seconds
World Time City (NYC) time
TYO (Tokyo) time
New World Time City (TYO)
NYC (New York) time
E-42
To specify standard time or daylight saving time (DST) for a city
1. In the World Time Mode, press Dto display the city
code (time zone) whose Standard Time/Daylight Saving
Time setting you want to change.
2. Hold down Afor about two seconds.
xThis toggles the city code you selected in step1
between Daylight Saving Time (DST indicator
displayed) and standard time (DST indicator not
displayed).
xNote that you cannot switch between standard time/
daylight saving time (DST) while UTC is selected as
the World Time City.
xThe standard time/daylight saving time (DST) setting
affects only the currently displayed city. Other cities
are not affected.
DST indicator
E-41
To enter the World Time Mode
Use Cto select the World Time Mode as shown on page E-13.
To view the time in another time zone
In the World Time Mode, press Dto change the city code setting.
xHolding down Dscrolls at high speed.
xTo display the UTC city code (differential 0), press Band Dat the same time.
E-40
Checking the Current Time in a Different Time Zone
You can use the World Time Mode to view the current
time in one of 31 time zones (48 cities) around the
globe. The city that is currently selected in the World
Time Mode is called the “World Time City”.
xThe hour and minute hands indicate information for
the currently selected Home City.
xWhen you enter the World Time Mode, the currently
selected city code and city name (English) scroll once
across the digital display. After that, the city code
remains displayed.
xYou can view the name (English) of your Home City
by pressing A.
World Time City hour and
minute
City code of World Time City
Second
Indicates WT.

Operation Guide 5478
E-59
Specifications
Accuracy at normal temperature: ±15 seconds a month
Digital Timekeeping: Hour, minutes, seconds, p.m. (PM), month, day, day of the
week
Time format: 12-hour and 24-hour
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Home City code (can be assigned one of 48 city codes);
Standard Time/Daylight Saving Time (summer time)
Analog Timekeeping: Hour, minutes (hand moves every 20seconds)
Stopwatch:
Measuring unit: 1/100 second
Measuring capacity: 23:59' 59.99"
Measuring modes: Elapsed time, split time, two finishes, One-press timing start
from the Timekeeping Mode, Target Time Alert
E-58
Dial Hand
The dial hand indicates the information below in each mode.
Mode Dial Hand Indication
Timekeeping Mode name
Stopwatch Elapsed seconds
Countdown Timer Seconds count
World Time Mode name
Alarm Mode name
E-57
Graphic
The graphic flashes in each mode as described below.
Mode Flashing
Timekeeping Seconds of current time
Stopwatch Minutes of elapsed time measurement
Countdown Timer Minutes of countdown
World Time Seconds of current time
Synced with World Time seconds.
E-56
Main Indicators
Number Name See
1
1
Snooze alarm on indicator E-47
2
2
Alarm on indicator E-45
3
3
Hourly time signal on indicator E-47
4
4
PM indicator E-17
5
5
Hands shifted indicator E-14
6
6
DST indicator E-20, E-42
7
7
Target Time operation in
progress E-30
1 65432
7
E-55
Troubleshooting
Time Setting
■The current time setting is off by hours.
Your Home City setting may be wrong (page E-18). Check your Home City setting and
correct it, if necessary.
■The current time setting is off by one hour.
You may need to change your Home City’s standard time/daylight saving time
(DST) setting. Use the procedure under “Adjusting the Digital Time and Date
Settings” (page E-21) to change the standard time/daylight saving time (DST) setting.
World Time Mode
■The time for my World Time City is off in the World Time Mode.
This could be due to incorrect switching between standard time and daylight saving
time. See “To specify standard time or daylight saving time (DST) for a city” (page E-42)
for more information.
E-54
3. Press Dto toggle the setting between KEY (ON) and MUTE (OFF).
4. After all the settings are the way you want, press Ato exit the setting screen.
E-53
Button Operation Tone
You can turn the button operation tone on or off as
desired.
xEven if you turn off the button operation tone, the Target
Time Alert, alarms, the Hourly Time Signal, and other
beepers all operate normally.
To turn the button operation tone on and off
1. In the Timekeeping Mode, hold down Auntil the
flashing SET Hold indicator disappears from the
display and the currently selected city code flashes on
the left side of the upper display.
2. Press Cnine times to display the button operation
tone On/Off screen (page E-22).
The screen will show either KEY or MUTE.
E-52
3. Press C.
xThis enters the hour and minute hand adjustment
mode.
xPress Cagain* to enter the dial hand adjustment
mode.
*Nothing will happen if you press Cwhile the hands
are moving.
4. If the hour and minute hands are not at 12o’clock,
use D(+) and B(–) to adjust them until they are.
xHolding down either button scrolls at high speed.
5. Press Ato return to the Timekeeping Mode.
Check to make sure that the time indicated by the
hands matches the time on the digital display. If the
times don’t match, perform the correction procedure
above again.
Hour hand and minute hand
E-51
1. In the Timekeeping Mode, hold down Afor about
five seconds until 00 starts to flash. Release Aafter
00 flashes.
xThis indicates the dial hand adjustment mode.
2. If the dial hand is not at 0 o’clock, use D(+) and B
(–) to move it there.
Dial hand
E-50
Adjusting Hand Positions
The watch hands can go out of alignment with the time on the digital display if it
is exposed to strong magnetism or impact. If this happens, you should adjust the
hand positions.
Important!
xYou do not need to perform the operation below as long as the analog hands
indicate the same time as the digital display.

Operation Guide 5478
L-3
City
Code City UTC Offset/ GMT Differential
MOW Moscow +3
JED Jeddah
THR Tehran +3.5
DXB Dubai +4
KBL Kabul +4.5
KHI Karachi +5
DEL Delhi +5.5
KTM Kathmandu +5.75
DAC Dhaka +6
RGN Yangon +6.5
BKK Bangkok +7
SIN Singapore
+8
HKG Hong Kong
BJS Beijing
TPE Taipei
City
Code City UTC Offset/ GMT Differential
SEL Seoul +9
TYO Tokyo
ADL Adelaide +9.5
GUM Guam +10
SYD Sydney
NOU Noumea +11
WLG Wellington +12
x This table shows the city codes of this
watch (As of January 2016).
x The rules governing global times
(GMT differential and UTC offset) and
summer time are determined by each
individual country.
L-2
City Code Table
City
Code City UTC Offset/ GMT Differential
PPG Pago Pago –11
HNL Honolulu –10
ANC Anchorage –9
YVR Vancouver –8
LAX Los Angeles
YEA Edmonton –7
DEN Denver
MEX Mexico City –6
CHI Chicago
NYC New York –5
YHZ Halifax –4
YYT St. John’s –3.5
BUE Buenos Aires –3
RIO Rio De Janeiro
City
Code City UTC Offset/ GMT Differential
FEN Fernando de
Noronha –2
RAI Praia –1
UTC
0LIS Lisbon
LON London
MAD Madrid
+1
PAR Paris
ROM Rome
BER Berlin
STO Stockholm
ATH Athens
+2CAI Cairo
JRS Jerusalem
L-1
City Code Table
E-61
Power Supply: One lithium battery (Type: CR2016)
Approximate battery operating time: 3 years under the following conditions:
xStopwatch: 40 hours/month
xAlarm: 10 seconds/day
x1 illumination operation (1.5 seconds) per day
Frequent use of illumination runs down the battery.
Specifications are subject to change without notice.
E-60
Countdown Timer:
Measuring unit: 1/10 second
Countdown range: 60 minutes
Countdown start time setting range: 1 to 60 minutes (1-minute increments)
World Time: 48 cities (31 time zones)
Other: Daylight Saving Time/Standard Time; Home City/World Time City
switching
Alarms: 5 Daily alarms (with 1 snooze alarm); Hourly time signal
Illumination: LED (light-emitting diode); Selectable illumination duration
(approximately 1.5 seconds or 3 seconds)
Other: Button operation tone on/off; Moving the Hands to View the Digital Display
