Caterlite CD983 User manual

Model:
CD983
Air Fryer
Instruction manual
CD983_UK_A5_v1_20220111.indb 1CD983_UK_A5_v1_20220111.indb 1 2022/1/11 11:322022/1/11 11:32

2
UK
Safety Instructions
Please take a few moments to carefully read through this
manual. Correct maintenance and operation of this machine
will provide the best possible performance from your Caterlite
product.
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• The temperature of accessible surfaces may be high when the
appliance is operating. Only hold the collection tray/basket by
the handle only.
• As an oil-free fryer working on hot air, do not fill the collection
pan with oil or fat - fire hazard!
• Only use the original parts and accessories.
• DO NOT immerse the appliance in water.
• Do not clean with jet/pressure washers.
• Do not move or carry the appliance when hot.
• DO NOT obstruct or cover the appliance in any way when in use.
• This is an attended appliance and must be supervised when in
use.
• Always switch off the appliance, disconnect the power supply
and allow to cool when not in use, before cleaning or carrying
out maintenance.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
CD983_UK_A5_v1_20220111.indb 2CD983_UK_A5_v1_20220111.indb 2 2022/1/11 11:322022/1/11 11:32

3
UK
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children
unless they are older than 8 and supervised.
• Keep the appliance and its cord out of reach of child less than
8 years.
• This appliance is not intended to be operated by means of an
external timer or separate remote-control system.
• Caterlite recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
• Caterlite recommend that this product is connected to a circuit
protected by an appropriate RCD (Residual Current Device).
Pack Contents
The following is included:
• Air fryer • Instruction manual
Caterlite prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your Caterlite dealer immediately.
Before first time use
• Remove all packaging materials. Make sure that all protective plastic
film and coatings are thoroughly removed from all surfaces.
• Position the fryer on a flat, stable and heat-resistant surface. For
sufficient ventilation, allow a minimum of 10cm of space above the
oven, at the back and sides.
• Pull the collection tray out of the fryer. Then press down the release
button on the handle and lift upward to separate the basket from
the collection tray. Clean both parts thoroughly and dry well.
• Press down the release button and locate the basket into the
collection tray.
CD983_UK_A5_v1_20220111.indb 3CD983_UK_A5_v1_20220111.indb 3 2022/1/11 11:322022/1/11 11:32

4
UK
Operation
Temperature indicator
Control panel
Motor ON indicator
Heating element ON indicator
Time indicator
Function key Start/pause key
Decrease key
Basket handle
On/off key
Collection tray
Increase key
Power ON indicator
LED display
Air frying
1. Put the food to be fried in the basket, then push the collection tray into the unit.
• Caution: Never use the collection tray directly without the basket in place! Never overfill
the basket to prevent food from contacting the heating element overhead.
2. Connect the appliance to the mains power supply. The power ON indicator lights up RED.
3. Press the on/off key to switch on. The fryer beeps once and the default settings are shown on the
display.
4. Press the function button to toggle between the Temperature and Timer functions.
5. Press the Increase or Decrease key to select the suitable settings.
Function Range Increment Default
Temperature 80°C - 200°C 5°C 180°C
Timer 1min - 60min 1min 15min
6. Press the Start/Pause key to start. The timer begins to count down on the display.
7. For foodstuffs that require shaking halfway, just pull out the collection tray directly. All indicators on
the display will disappear. Afterwards, shake and re-locate the collection tray. The fryer will resume
working automatically and the frying time will be reset. For best frying result, it’s recommended to set
the remaining time.
8. When the set time elapses, the fryer beeps and “00:00” is shown. (Or you can manually stop the
frying process by pressing the “on/off” key.)
9. Pull out the collection tray and transfer the fried food into a suitable container.
Caution:
• When removing the collection tray, be careful of the hot steam arising!
• In case of dark smoke emission, unplug the appliance immediately. Wait to
let the smoke dissipate then remove the food.
CD983_UK_A5_v1_20220111.indb 4CD983_UK_A5_v1_20220111.indb 4 2022/1/11 11:322022/1/11 11:32

5
UK
Frying guide
As food differ in type, size, amount/weight, shape, etc., it’s hard to guarantee the best settings. See the
table below for reference only.
Food type Weight
(g)
Time
(Min.)
Temp
(°C)
Shake
halfway?
Remark
Potato & fries
Thin frozen fries 300-400 18-25 200 Yes
Thick frozen fries 300-400 20-25 200 Yes
Potato gratin 500 20-25 200 Yes
Meat & Poultry
Steak 100-500 10-20 180 No
Pork chops 100-500 10-20 180 No
Hamburger 100-500 10-20 180 No
Sausage roll 100-500 13-15 200 No
Drumsticks 100-500 25-30 180 No
Chicken breast 100-500 15-20 180 No
Snacks
Spring rolls 100-400 8-10 200 Yes
Frozen chicken nuggets 100-500 15-20 200 Yes
Frozen fish fingers 100-400 15-20 200 No
Frozen bread crumbed
cheese snacks
100-400 8-10 180 No
Stuffed vegetables 100-400 10 160 No
Baking
Cake 300 20-25 160 No Use additional baking
tin
Quiche 400 20-22 180 No
Muffins 300 15-18 200 No Use additional baking
tin or oven dish
Sweet snacks 400 20 160 No
• Normally bigger food pieces require longer time than smaller ones and vice versa.
• Shaking smaller ingredients halfway through the process optimizes the end result and can help
prevent unevenly fried ingredients.
• It is recommended to apply some oil to fresh potatoes for a crispy result. Only fry the ingredients
within a few minutes after applying the oil.
• Do not prepare extremely greasy ingredients such as sausages in the Air fryer.
• Snacks that can be prepared in an oven can also be prepared in the Air fryer.
• The optimal amount for preparing crispy fries is 500 grams.
• Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough also requires a
shorter preparation time than home-made dough.
• A baking tin or oven dish can be used in the frying basket when to bake a cake, quiche, or fragile
ingredients and filled ingredients.
• When to reheat with this unit, you can set the temperature to 150°C and time to 10 minutes.
CD983_UK_A5_v1_20220111.indb 5CD983_UK_A5_v1_20220111.indb 5 2022/1/11 11:322022/1/11 11:32

6
UK
Cleaning, Care & Maintenance
Always switch off the appliance, disconnect the power supply and allow to cool
before cleaning or performing maintenance.
Always keep the appliance clean!
• Clean the appliance after every use.
• Wipe the exterior/interior surfaces with a moist cloth. Then wipe dry with a dry cloth.
• Clean the heating element with a soft brush to remove any food residues.
Cleaning the collection tray and basket
• For a thorough cleaning, separate the basket from the collection tray first.
• Clean both parts with warm soapy water and a non-abrasive sponge. Do not use abrasive powder or
metal brush, as this may damage the non-stick coating.
• Tip: Both parts are dishwasher-safe.
• If dirt gets stuck to the basket or the bottom of the tray, fill the tray with hot water and some
detergent. Then put the basket in the tray and soak for approximately 10 minutes.
• Rinse and dry well.
Troubleshooting
A Caterlite dealer or qualified technician should carry out repairs if required.
Fault Probable Cause Solution
The unit is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Replace plug or lead
Fuse in the plug has blown Replace the plug fuse
Mains power supply fault Check mains power supply
Hard to insert the
Collection tray
Too much food in the basket Never fill the basket above the MAX mark
Fried food is not
done or cooked
evenly
Food pieces too big Cut food into smaller pieces
Frying temperature too low Set higher temperature
Frying time too short Set longer temperature
Certain types of food need to be
shaken halfway
Refer to the section “Frying guide” for the
food types to shake
Fried snacks not
crispy
Used snacks intended to be prepared
in a traditional deep fryer
Use oven snacks or lightly brush some oil
onto the snacks before frying
Fried Fresh fries are
not even or crisp
Not using the right potato type Use fresh potatoes and make sure they
stay firm during frying
Potato sticks not properly rinsed
before frying
Rinse the potato sticks well to remove the
starch
Crispiness of the fries largely
depends on the amount of oil and
water in the fries
Dry the potato sticks well before frying
Cut the potato into smaller sticks
Apply slightly more oil for a crisp result
CD983_UK_A5_v1_20220111.indb 6CD983_UK_A5_v1_20220111.indb 6 2022/1/11 11:322022/1/11 11:32

7
UK
Technical Specifications
Model Voltage Power Temp. range Basket
capacity
Dimensions
H x W x D mm
Weight
(kg)
CD983 220-240V~,
50-60Hz 1300W 80°C - 200°C 3 L 378 x 279 x 314 4.65
Electrical Wiring
This appliance is supplied with a 3 pin BS1363 plug and lead.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
Caterlite parts have undergone strict product testing in order to comply
with regulatory standards and specifications set by international,
independent, and federal authorities.
Caterlite products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of Caterlite.
Every effort is made to ensure all details are correct at the time of going to press, however, Caterlite reserves the right to
change specifications without notice.
CD983_UK_A5_v1_20220111.indb 7CD983_UK_A5_v1_20220111.indb 7 2022/1/11 11:322022/1/11 11:32

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
Air Fryer
CD983
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en)
• Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n)
• Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Low Voltage Directive (LVD) - 2014/35/EU
Electrical Equipment (Safety) Regulations 2016
EN 60335-1:2012 +A11:2014 +A13:2017
EN 60335-2-9:2003 +A1:2004 +A2:2006 +A12:2007 +A13:2010
EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive 2014/30/EU - recast of 2004/108/EC
Electromagnetic Compatibility Regulations 2016 (S.I. 2016/1091)
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Regulation (EC) 1275/2008 - Standby and off mode power consumption (2019)
EN 50564:2011
Restriction of Hazardous Substances Directive (RoHS) 2015/863 amending Annex II to
Directive 2011/65/EU
Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations 2012 (S.I. 2012/3032)
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Caterlite
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)
and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data •
Fecha • Data
3rd December 2021
Signature • Handtekening • Signature
• Unterschrift Firma • Firma •
Assinatura
Full Name • Volledige naam • Nom et
prénom • Vollständiger Name • Nome
completo • Nombre completo • Nome
por extenso
Ashley Hooper
Eoghan Donnellan
Position • Functie • Fonction • Position
• Qualifica • Posición • Função
Technical & Quality Manager
Commercial Manager/ Importer
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore •
Dirección del fabricante • Morada do
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point Business Park
New Mallow Road
Cork
Ireland
DocuSign Envelope ID: 4E3729DC-A72D-4D56-A6BE-3C3B13D51DD6
CD983_UK_A5_v1_20220111.indb 8CD983_UK_A5_v1_20220111.indb 8 2022/1/11 11:322022/1/11 11:32

UK
[phone]
Eire
NL 040 – 2628080
FR 01 60 34 28 80
BE-NL 0800-29129
BE-FR 0800-29229
DE 0800 – 1860806
IT N/A
ES 901-100 133
CD983_UK_A5_v1_20220111.indb 9CD983_UK_A5_v1_20220111.indb 9 2022/1/11 11:322022/1/11 11:32

CD983_UK_A5_v1_20220111.indb 10CD983_UK_A5_v1_20220111.indb 10 2022/1/11 11:322022/1/11 11:32

CD983_UK_A5_v1_20220111.indb 11CD983_UK_A5_v1_20220111.indb 11 2022/1/11 11:322022/1/11 11:32

CD983_UK_A5_v1_20220111
CD983_UK_A5_v1_20220111.indb 12CD983_UK_A5_v1_20220111.indb 12 2022/1/11 11:322022/1/11 11:32
