CBS B822 Series Setup guide

CBS - Carsten Daus GmbH
Friedberger Str. 35
D - 63452 Hanau (Germany)
CAGE CODE: DL161
LIQUID SOAP DISPENSER
PART NUMBER
B822 SERIES
B823 SERIES
B825 SERIES
B828 SERIES
COMPONENT MAINTENANCE MANUAL
WITH
ILLUSTRATED PARTS LIST
Issue: D
Date: May 02/2022
25-40-01 May 02/2022

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
RECORD OF REVISIONS
REV. ISSUE INSERTED REASON FOR REVISION
NO. DATE
DATE BY
A OCT 01/2004 OCT 01/2004 CBS First Issue
B AUG 01/2005 AUG 01/2005 CBS Introduction of additional
soap containers.
C JUL 10/2009 JUL 10/2009 CBS Complete new revised CMM.
Re-introduction of key
(lockable) versions and
B825 Series
D May 02/2022 May 02/2022 CBS CMM revised and following
P/Ns were included:
B823-40-05-99
B823-40-10-99
ROR
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
RECORD OF TEMPORARY REVISIONS
TEMP
REV PAGE NUMBER ISSUE DATE BY DATE REMOVED BY
ROTR
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
SERVICE BULLETIN LIST
SERVICE BULLETIN NUMBER MODIFICATION INSERTION
DATE BY
SBL
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
LIST OF EFFECTIVE PAGES
SUBJECT PAGE DATE SUBJECT PAGE DATE
TITLEPAGE
DESCRIPTION AND
OPERATION
TITLE 1 MAY 02/2022
1 MAY 02/2022
RECORD OF REVISIONS
2 3 MAY 02/2022 MAY 02/2022
ROR 1 MAY 02/2022 4 MAY 02/2022
5 MAY 02/2022
RECORD OF TEMPORARY REVISIONS
6
7 MAY 02/2022
MAY 02/2022
ROTR 1 MAY 02/2022 8 MAY 02/2022
SERVICE BULLETIN LIST
TESTING AND FAULT
ISOLATION
SBL 1 MAY 02/2022
1001 MAY 02/2022
LIST OF EFFECTIVE PAGES
DISASSEMBLY
LEP 1 MAY 02/2022
LEP 2 MAY 02/2022 3001 MAY 02/2022
LEP 3 MAY 02/2022 3002 MAY 02/2022
CLEANING
TABLE OF CONTENTS
4001 MAY 02/2022
TOC 1 MAY 02/2022
TOC 2 MAY 02/2022 CHECK
TOC 3 MAY 02/2022
5001 MAY 02/2022
LIST OF TABLES
REPAIR
LOT 1 MAY 02/2022 6001 MAY 02/2022
LIST OF ILLUSTRATION ASSEMBLY
LOI 1 MAY 02/2022 7001 MAY 02/2022
7002 MAY 02/2022
INTRODUCTION
FITS AND CLEARANCES
INTRO 1 MAY 02/2022
INTRO 2 MAY 02/2022 8001 MAY 02/2022
INTRO 3 MAY 02/2022
INTRO 4 MAY 02/2022 LEP
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
SUBJECT PAGE DATE SUBJECT PAGE DATE
SPECIAL TOOLS, FIXTURES AND 10001A-3 MAY 02/2022
EQUIPMENT 10001B-0 MAY 02/2022
10001B-1 MAY 02/2022
9001 MAY 02/2022 10001B-2 MAY 02/2022
10001C-0 MAY 02/2022
ILLUSTRATED PARTS LIST 10001C-1 MAY 02/2022
10001C-2 MAY 02/2022
IPL-TP 10001 MAY 02/2022 10001C-3 MAY 02/2022
10001D-0 MAY 02/2022
INTRODUCTION 10001D-1 MAY 02/2022
10001D-2 MAY 02/2022
INTRO 10001 MAY 02/2022 10001E-0 MAY 02/2022
INTRO 10002 MAY 02/2022 10001E-1 MAY 02/2022
INTRO 10003 MAY 02/2022 10001E-2 MAY 02/2022
INTRO 10004 MAY 02/2022 10001E-3 MAY 02/2022
INTRO 10005 MAY 02/2022 10001F-0 MAY 02/2022
10001F-1 MAY 02/2022
NUMERICAL INDEX 10001F-2 MAY 02/2022
10001F-3 MAY 02/2022
NI 10001 MAY 02/2022 10001G-0 MAY 02/2022
NI 10002 MAY 02/2022 10001G-1 MAY 02/2022
NI 10003 MAY 02/2022 10001G-2 MAY 02/2022
NI 10004 MAY 02/2022 10001G-3 MAY 02/2022
NI 10005 MAY 02/2022 10001H-0 MAY 02/2022
NI 10006 MAY 02/2022 10001H-1 MAY 02/2022
NI 10007 MAY 02/2022 10001H-2 MAY 02/2022
NI 10008 MAY 02/2022 10001H-3 MAY 02/2022
NI 10009 MAY 02/2022 10001I-0 MAY 02/2022
NI 10010 MAY 02/2022 10001I-1 MAY 02/2022
NI 10011 MAY 02/2022 10001I-2 MAY 02/2022
NI 10012 MAY 02/2022 10001J-0 MAY 02/2022
NI 10013 MAY 02/2022 10001J-1 MAY 02/2022
NI 10014 MAY 02/2022 10001J-2 MAY 02/2022
NI 10015 MAY 02/2022 10001J-3 MAY 02/2022
10001K-0 MAY 02/2022
DETAILED PARTS LIST 10001K-1 MAY 02/2022
10001K-2 MAY 02/2022
DPL 10001 MAY 02/2022 10001K-3 MAY 02/2022
10001A-0 MAY 02/2022 10001L-0 MAY 02/2022
10001A-1 MAY 02/2022 10001L-1 MAY 02/2022
10001A-2 MAY 02/2022 10001L-2 MAY 02/2022
LEP
PAGE 2

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
SUBJECT PAGE DATE SUBJECT PAGE DATE
10001L-3 MAY 02/2022
10001M-0 MAY 02/2022
10001M-1 MAY 02/2022
10001M-2 MAY 02/2022
10001M-3 MAY 02/2022
10002A-0 MAY 02/2022
10002A-1 MAY 02/2022
10002A-2 MAY 02/2022
10003A-0 MAY 02/2022
10003A-1 MAY 02/2022
10004A-0 MAY 02/2022
10004A-1 MAY 02/2022
SPECIAL PROCEDURES
11001 MAY 02/2022
REMOVAL
12001 MAY 02/2022
12002 MAY 02/2022
12003 MAY 02/2022
12004 MAY 02/2022
INSTALLATION
13001 MAY 02/2022
13002 MAY 02/2022
13003 MAY 02/2022
13004 MAY 02/2022
13005 MAY 02/2022
13006 MAY 02/2022
13007 MAY 02/2022
13008 MAY 02/2022
SERVICING
14001 MAY 02/2022
14002 MAY 02/2022
STORAGE
15001 MAY 02/2022
LEP
PAGE 3

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
TABLE OF CONTENTS
INTRODUCTION INTRO 1
1. GENERAL INTRO 1
2. MANUFACTURE INTRO 1
3. SPARES SUPPORT INTRO 1
4. LAYOUT OF MANUAL INTRO 2
5. MAINTENANCE POLICY INTRO 3
6. REVISION SERVICE INTRO 3
7. SHOP VERIFICATION INTRO 3
8. WARNING, CAUTION, NOTES INTRO 3
9. MEASUREMENT UNITS INTRO 3
10. LIST OF ABBREVIATIONS INTRO 4
DESCRIPTION AND OPERATION 1
1. GENERAL 1
2. DESCRIPTION 1
3. OPERATION 2
4. TECHNICAL DATA 2
TESTING AND FAULT ISOLATION 1001
1. GENERAL 1001
2. LIST OF POSSIBLE DEFECTS 1001
DISASSEMBLY 3001
1. GENERAL 3001
2. PROCEDURE 3001
TOC
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
CLEANING 4001
1. GENERAL 4001
2. PROCEDURE 4001
CHECK 5001
1. GENERAL 5001
REPAIR 6001
1. GENERAL 6001
ASSEMBLY 7001
1. GENERAL 7001
2. PROCEDURE 7001
FITS AND CLEARANCE 8001
1. GENERAL 8001
SPECIAL TOOLS, FIXTURES AND EQUIPMENT 9001
INTRODUCTION INTRO 10001
1. GENERAL INTRO 10001
2. MATERIAL ARRANGEMENT INTRO 10001
NUMERICAL INDEX NI 10001
NI 10015
DETAILED PARTS LIST DPL 10001
SPECIAL PROCEDURES 11001
1. NOT APPLICABLE 11001
REMOVAL 12001
A. PROCEDURE 12001
INSTALLATION 13001
A. LIST OF MATERIALS 13001
TOC
PAGE 2

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
B. GENERAL 13001
C. PROCEDURE 13002
SERVICING 14001
1. REFILLING 14001
STORAGE 15001
1. GENERAL 15001
TOC
PAGE 3

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
LIST OF TABLES
TITLE TABLE PAGE
FAULT ISOLATION CHART TABLE 1001 1001
CLEANING MATERIALS TABLE 4001 4001
TORQUE VALUES TABLE 8001 8001
INSTALLATION MATERIALS TABLE 13001 13001
LOT
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
LIST OF ILLUSTRATION
TITLE FIGURE PAGE
DIMENSION SOAP CONTAINERS FIGURE 1 5
DIMENSION PISTON ASSY - B822-23-3 FIGURE 2 6
DIMENSION PISTON ASSY - B822-23-2 FIGURE 3 7
DIMENSION HOLDER - B822-118-1 FIGURE 4 8
LIQUID SOAP DISPENSER FIGURE 1A 10001A-0
LIQUID SOAP DISPENSER FIGURE 1B 10001B-0
LIQUID SOAP DISPENSER FIGURE 1C 10001C-0
LIQUID SOAP DISPENSER FIGURE 1D 10001D-0
LIQUID SOAP DISPENSER FIGURE 1E 10001E-0
LIQUID SOAP DISPENSER FIGURE 1F 10001F-0
LIQUID SOAP DISPENSER FIGURE 1G 10001G-0
LIQUID SOAP DISPENSER FIGURE 1H 10001H-0
LIQUID SOAP DISPENSER FIGURE 1I 10001I-0
LIQUID SOAP DISPENSER FIGURE 1J 10001J-0
LIQUID SOAP DISPENSER FIGURE 1K 10001K-0
LIQUID SOAP DISPENSER FIGURE 1L 10001L-0
LIQUID SOAP DISPENSER FIGURE 1M 10001M-0
PISTON ASSY FIGURE 2A 10002A-0
SHANK ASSY FIGURE 3A 10003A-0
WASTE BOX INSTALLATION KIT FIGURE 4A 10004A-0
REMOVAL OF B822 SERIES FIGURE 12001 12001
REMOVAL OF B823 SERIES FIGURE 12002 12002
REMOVAL OF B828 SERIES FIGURE 12003 12003
REMOVAL OF WASTE BOX KIT FIGURE 12004 12004
INSTALLATION OF B822 SERIES FIGURE 13001 13003
INSTALLATION OF B823 SERIES FIGURE 13002 13005
INSTALLATION OF B828 SERIES FIGURE 13003 13007
INSTALLATION OF WASTE BOX KIT FIGURE 13004 13008
REFILLING OF SOAP CONTAINER FIGURE 14001 14002
LOI
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
INTRODUCTION
1. GENERAL
This Component Maintenance Manual (CMM) contains maintenance
information and Illustrated Parts List (IPL) for the Soap Dispensers
installed in aircraft lavatories.
The information is prepared in accordance with Air Transport
requirements.
2. MANUFACTURER
The Soap Dispensers are manufactured by:
CAGE CODE: DL161
CBS - Carsten Daus GmbH
Friedberger Str. 35
D-63452 Hanau (Germany)
Telephone: [phone]
Telefax: [phone]
E-mail: [e-mail]
Internet: http://www.dauscbs.com
3. SPARES SUPPORT
The Soap Dispenser is supported by:
CAGE CODE: DL161
CBS - Carsten Daus GmbH
Friedberger Str. 35
D-63452 Hanau (Germany)
Telephone: [phone]
Telefax: [phone]
E-mail: [e-mail]
Internet: http://www.dauscbs.com
INTRO
PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
SATAIR A/S
Amager Landevej 147A
DK-2770 Kastrup (Denmark)
CAGE CODE: R1120
Phone: [phone]
Fax: [phone]
AOG Phone: [phone]
SITA: CPHSA7X
[email protected]
http://www.satair.com
LEKI AVIATION A/S
Amager Landevej 278
DK-2770 Kastrup (Denmark)
CAGE CODE: R3867
Phone: [phone]
Fax: [phone]
AOG Phone: [phone]
AOG Email: [email protected]om
[e-mail]
http://www.lekiaviation.com
4. LAYOUT OF MANUAL
This manual contains 16 chapters. The main chapters are general
description and operation followed by data for testing and fault
isolation, repair, disassembly and assembly of the Soap Dispenser. This
is followed by an Illustrated Parts List which gives detailed breakdown
information.
INTRO
PAGE 2

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
5. MAINTENANCE POLICY
The Component Maintenance Manual provides procedures that will enable
an approved repairer, who is unfamiliar with the component, to restore
the Soap Dispenser to a serviceable condition. These procedures are
prepared for the shop mechanic who performs work.
6. REVISION SERVICE
This manual will be updated as required by revisions. Changes to
hardware given in service bulletins will be included in this manual
with revisions. Configuration changes will be shown in the text by the
service bulletin number, i.e. pre SB- and post SB-. Procedures of
illustrations not identified by pre SB- or post SB- refers to all
configurations.
7. SHOP VERIFICATION
The procedures within this manual have been shop verified by the
manufacturer. The sections Testing, Disassembly and Assembly and
Storage were verified by actually performing the functions described in
these sections.
8. WARNING, CAUTIONS, NOTES
These adjuncts to the text are expressed by the following headings:
WARNING: WARNINGS CALL ATTENTION TO THE USE OF MATERIALS, ROCESSES,
PROCEDURES, METHODS OR LIMITS WHICH MUST BE ADHERED
PRECISELY TO AVOID DEATH OR INJURY TO PERSONS.
CAUTION: CAUTIONS CALL ATTENTION TO METHODS AND PROCEDURES WHICH
MUST BE FOLLOWED TO AVOID DAMAGE TO EQUIPMENT.
NOTE: NOTES CALL ATTENTION TO METHODS WHICH MAKE THE JOB EASIER.
9. MEASUREMENT UNITS
All the units in this manual are metric with English equivalents shown
in brackets. Units of temperature are in degree Celsius, Fahrenheit
shown in brackets.
INTRO
PAGE 3

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
10. LIST OF ABBREVIATIONS
ASSY ASSEMBLY
C CELSIUS
cm CENTIMETER
CMM COMPONENT MAINTENANCE MANUAL
DES DESCRIPTION AND OPERATION
Det DETAILS
EFF EFFECTIVE
F FAHRENHEIT
FIG FIGURE
FWD FORWARD
in INCH
IPL ILLUSTRATED PARTS LIST
kg KILOGRAMM
lb POUND
LH LEFT HAND
max. MAXIMUM
mm MILIMETER
NHA NEXT HIGHER ASSY
NO. NUMBER
REF REFERENCE
RH RIGHT HAND
SB SERVICE BULLETIN
INTRO
PAGE 4

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
DESCRIPTION AND OPERATION
1. GENERAL
This section has description and operation information for the Liquid
Soap Dispenser.
WARNING: IN ORDER TO GUARANTEE MAXIMUM PERFORMANCE OF THE LIQUID
SOAP DISPENSER, LIQUID SOAP MUST HAVE A VISCOSITY < 30
MPA/S, NACL-SHARE < 1 % AND BE FREE OF ALCOHOL AND
AROMATIC COMPOUNDS. WE RECOMMEND TO USE ONLY THE ORIGINAL
APPROVED SOAP MANUFACTURED BY CBS - CARSTEN DAUS GMBH.
2. DESCRIPTION
NOTE: The piston assembly is interchangeable for all versions.
A. The Liquid Soap Dispenser, herein referred to as the unit, is
installed in aircraft lavatories. The unit is mounted on the
lavatory cabinet surface; the soap container is mounted in the
cabinet. At standard installation, the soap container is mounted
vertically below the dispenser.
NOTE: If soap container cannot be installed vertically below the
dispenser use a flexible tube of appropriate length to
connect the dispenser to the soap container.
B. The piston assy (1-10) and piston (2-10) are made of vanadium steel;
cover (2-60) and shank (3-10) are made of ABS-plastic. The cover is
chrome-plated.
C. The Liquid Soap Dispensers consist mainly of 3 or 4 parts:
- Piston Assy (faucet/pump) which is mounted on the counter top
- Shank Assy which is installed through a hole in the counter top
and supports the Piston Assy
- flexible hose that connects the soap container with the dispenser
(except B822 Series)
- Soap Container (250 ml, 500 ml or 1000 ml) and a wall mounted
holder (except B822 Series) for the soap container
Part numbers containing the letter “K”are lockable versions.
B822- Series = The soap container is mounted vertically below the
dispenser as standard. Available with 2.5”or 4.0”
piston spout length, 250 ml, 500 ml or 1000 ml soap
container, placard in English, English/German,
English/French, English/Spanish or English/Italian
(other languages upon request). PAGE 1

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
B822K Series = key version (lockable) of B822- Series.
B823- Series = Version with soap container mounted in a displaced
position and connected to the dispenser by a flexible
hose/tube of appropriate length. Available with 2.5”
or 4.0”piston spout length, 250 ml, 500 ml or 1000 ml
soap container, placard in different languages (see
above).
B823K Series = key version (lockable) of B823- Series.
B825- Series = Version with soap container mounted in a displaced
position and connected to the dispenser by a flexible
metal pipe of appropriate length. Available with 2.5”
or 4.0”piston spout length, 500 ml or 1000 ml soap
container, placard in different languages (see above).
-This is the previous version of the B828- Series and
only a few models are still in use.
B825K Series = key version (lockable) of B825- Series. - This is the
previous version of the B828K Series and only a few
models are still in use.
B828- Series = Version with soap container mounted in a displaced
position and connected to the dispenser by a flexible
metal pipe of appropriate length. Available with 2.5”
or 4.0”piston spout length, 500 ml or 1000 ml soap
container, placard in different languages (see above).
B828K Series = key version (lockable) of B828- Series.
3. OPERATION
A. The piston conveys approx. 0,76 ml (0.03 oz.) soap to the piston
outlet by each manual depression of the piston. Single-hand
operation of the unit is possible.
NOTE: Cleaning of the soap container must be carried out after
18 months (Ref. to chapter CLEANING).
4. TECHNICAL DATA
A. Filling capacity
The unit is available with a filling capacity of:
- approx. 0,25 l (8.45 oz.) for approx. 325 washings
- approx. 0,50 l (16.19 oz.) for approx. 650 washings
- approx. 1,00 l (33.81 oz.) for approx. 1300 washings
PAGE 2

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
B. Weight and Dimensions
(1) Weight Soap Dispenser complete:
B822-25-02-XX 0,249 kg (0.549 lb)
B822-25-05-XX 0,261 kg (0.575 lb)
B822-25-10-XX 0,306 kg (0.675 lb)
B822K25-02-XX 0,249 kg (0.549 lb)
B822K25-05-XX 0,261 kg (0.575 lb)
B822K25-10-XX 0,306 kg (0.675 lb)
B822-40-02-XX 0,259 kg (0.571 lb)
B822-40-05-XX 0,271 kg (0.597 lb)
B822-40-10-XX 0,316 kg (0.697 lb)
B822K40-02-XX 0,259 kg (0.571 lb)
B822K40-05-XX 0,271 kg (0.597 lb)
B822K40-10-XX 0,316 kg (0.697 lb)
B823-25-02-XX 0,604 kg (1.332 lb)
B823-25-05-XX 0,616 kg (1.358 lb)
B823-25-10-XX 0,661 kg (1.457 lb)
B823K25-02-XX 0,604 kg (1.332 lb)
B823K25-05-XX 0,616 kg (1.358 lb)
B823K25-10-XX 0,661 kg (1.457 lb)
B823-40-02-XX 0,614 kg (1.354 lb)
B823-40-05-XX 0,626 kg (1.380 lb)
B823-40-10-XX 0,671 kg (1.479 lb)
B823K40-02-XX 0,614 kg (1.354 lb)
B823K40-05-XX 0,626 kg (1.380 lb)
B823K40-10-XX 0,671 kg (1.479 lb)
B825-40-10-11 0,786 kg (1.733 lb)
B825K40-10 0,786 kg (1.733 lb)
B828-25-07-XX 0,766 kg (1.688 lb)
B828-25-17-XX 0,829 kg (1.827 lb)
B828-25-24-XX 0,776 kg (1.711 lb)
B828-25-25-XX 0,723 kg (1.593 lb)
PAGE 3

COMPONENT MAINTENANCE MANUAL
SOAP DISPENSERS
SEIFENSPENDER
B82X SERIES
No.: 25-40-01
Issue: D
Date: May 02/2022
25-40-01 May 02/2022
B828K25-07-XX 0,766 kg (1.688 lb)
B828K25-17-XX 0,829 kg (1.827 lb)
B828K25-24-XX 0,776 kg (1.711 lb)
B828K25-25-XX 0,723 kg (1.593 lb)
B828-40-07-XX 0,776 kg (1.710 lb)
B828-40-17-XX 0,839 kg (1.849 lb)
B828-40-24-XX 0,786 kg (1.733 lb)
B828-40-25-XX 0,733 kg (1.616 lb)
B828K40-07-XX 0,776 kg (1.710 lb)
B828K40-17-XX 0,839 kg (1.849 lb)
B828K40-24-XX 0,786 kg (1.733 lb)
B828K40-25-XX 0,733 kg (1.616 lb)
(2) Weight Soap Container:
B822-125 0,034 kg (0.075 lb)
B822-114 0,046 kg (0.101 lb)
B822-95 0,091 kg (0.200 lb)
B822-205 0,064 kg (0.140 lb)
B822-204 0,117 kg (0.257 lb)
B822-70 0,107 kg (0.235 lb)
B822-170 0,170 kg (0.374 lb)
(3) Dimensions
Refer to figure 1 to 4
PAGE 4
