CCEA MIZAR Series User manual

1
ENGLISH
Installation Manual

ENGLISH
2
Index
1. Product description …………………….………………………………………… 3
2. Safety Warnings ……….…............................................................ 4
2.1 Proper use …………………………...…………………..………………….. 4
2.2 Product safety …..……………………………………………..……………. 4
2.3 Levels of risk ………………………………………………………………….. 6
3. Available Versions ……………………………………………………………..… 7
4. Installation Guide ………………………………………………….……..………. 7
4.1 Product sizes …………………………………………………………….………. 7
4.2 Fastening accessories ……………….……….………………………..……. 8
4.3 Installation…………………………………..……………………….…..………. 9
5. Power connection ….……..……………………………………………….……….. 11
5.1 24VDC power connection ………………..…………….……....….... 11
5.2 230V power connection ……………………………………………….. 11
5.3 Optional cable connections ………….…………………….………….. 12
6. Switch on- Switch off …………..……………………………………..………….. 12
7. Problem solving ……………..………………………………………….………….. 13
8. Light source replacement ……………………………………………..……….. 13
9. Product maintenance and cleaning ………………………………………… 13
10. Repairs …………………………………………………………………………………… 13
11. Warranty ……………………………………………………………………….……….. 14
12. Product Disposal …………………………………………………………..…………. 14
13. Technical information ………….…………………………………..……………… 15
14. Symbols ……………….………..……………………………………..………………... 15
15. Declaration of Compliance …….……………………………..…………………. 16
Table of contents

ENGLISH
3
1. Product Description
MIZAR is the Avant-Gard lamp for
Work, Assembly and Quality Control
Stations
•Anodized aluminum casing
•End caps in nylon (PA66)
•Front prismatic plexiglass
(PMMA)
•Mid Power LED light source
•50% energy savings and
constant flow beam for
60.000 hours
•24 Vdc or 110/230Vac via
cable 10 ft (3m)
•4 model sizes from 12W to
48 W
•Overhead mounting bracket
and wall mounting bracket
available
Product Description

ENGLISH
4
2. Safety Warnings
Each lighting device in the MIZAR
series was designed and
manufactured based on state-of-
the-art techniques.
It is made of well-selected, high-
quality materials. It is carefully
tested throughout the production
process, from the raw material
through to packaging, following a
detailed production schedule so as
to guarantee that the product is
safe and reliable
Material damages, as well as bodily
injuries, may nevertheless still
occur while using it.
➢This manual is part of the
equipment and must always be
kept with it.
➢Please make sure that ALL
instructions/information in this
manual is carefully read
through.
➢Strict compliance with the
instructions provided in this
manual and on the lighting
equipment is required for its
correct use
➢Installation and use of the
product is recommended only
provided it is in perfect conditions,
and the user is well-acquainted
with all safety instructions
➢CCEA, the manufacturer, waives
any responsibility in case of
product tampering or improper
use.
2.1 Proper use of the product
This lighting equipment is fit for being
installed inside machine tools, even in
a wet environment
2.2 Product safety
Electrical Risks
The improper and incorrect use of the
equipment may cause bodily injuries
and material damages.
➢All electrical connection
procedures must be carried out by
a licensed electrician.
➢Switch off the power supply
before any installation,
maintenance or reparation
procedures.
➢Please ensure that the power
supply rated tension and
frequency meets the
requirements shown on the
product label. Please respect
cable polarity.
➢Maintenance and reparations
must only be carried out by
qualified electricians.
Risk of explosion
The Risk of the explosion might occur
upon installing and using this product
for applications with a high risk of
Safety instructions

ENGLISH
5
explosion. It might cause severe body
injuries.
➢Do not install and use this product
in hazardous environments (high
risk of explosion).
Installation and safety
➢Handle the lamp with care and
avoid having it drop or being hit
even it is still packed which might
cause body injuries, as well as
material damages.
➢Ensure the original mounting
accessories are used, as available
from the manufacturer.
➢Set up the mounting accessories
properly.
➢The equipment must be correctly
fastened using the proper screws
according to the application, place
and surface where the product is
being mounted.
➢Ensure that the fastenings are
regularly checked.
Danger of dazzling glare due to a
white light source
Avoid staring directly at the light
source, as it may cause a temporary
reduction of vision. Irritation, aches,
damages or accidents may as well
occur.
➢Avoid staring directly at the light
source.
➢The device must be adjusted so as
to avoid having the light flow
directed towards the eyes.
Danger caused by inappropriate
spare parts.
Using inappropriate spare parts may
cause bodily injuries and material
damages.
➢Do not use spare parts that have
not approved by the
manufacturer.
Damage caused by the presence of
laser beams
Use of the TRACKALPHA LED lighting
equipment is not allowed when a high
power laser –see: a laser cutting
system - is operating, since it may
damage the LED source.
Danger due to high temperatures
Installing and using the equipment in
all the environments where the
existing temperature remarkably
exceeds the foreseen operating
temperature will considerably reduce
LED lifetime while damaging as well
the built-in electronic components.
➢Do not use this Device in
environments where the operating
temperature of the device is
exceeded.
➢Operating temperature -4/+113°F
(-20/+45°C)
➢Avoid direct solar radiation.
Danger due to repairs
➢Having the product disassembled
or repaired without any
appropriate technical /electrical
knowledge may cause damages to
persons and objects.
Safety instructions

ENGLISH
6
➢Do not try to repair or
disassemble the equipment.
Please apply to qualified
technicians for any issues.
Any product tampering or
modifications not having been
approved by the manufacturer
will null and void the warranty.
2.3 Damage risk levels
Dangers that in case of non-
compliance immediately causes
serious injuries or even death.
Dangers that in case of non-
compliance could cause serious injury
or even death.
Dangers that in case of non-
compliance could cause injury.
Danger that can cause material
damage in case of non-observance.
HAZARD
ATTENTION
WARNING
NOTICE
Risk levels

ENGLISH
7
3. Available Versions
4. Guide to Installation
4.1 Product sizes and accessories
Please refer to the table hereunder listing all the lighting equipment, for you to
identify the version you need and its main features, for you to have the lighting
equipment correctly and efficiently installed and used.
Note: The product code is found on the brand name label stuck on the product’s
backside.
▪Find out the product code printed on the brand name label and see if you find it on
the table hereunder;
▪Compare the codes and see if you can identify the same model on the table
hereunder;
▪The code printed on the brand name label shows the device’s week and year
of production.
Note: Do not discard the product labeling which may be requested in case of a complaint.
Available Versions
MZ032xS01
Picture 01
MZ012xS01
MZ022xS01
MZ042xS01

ENGLISH
8
4.2 Mounting Accessories
Installation
Ceiling fixing with MZ.FX01
Wall fixing with MZ.FX02
Picture 02
Picture 03

ENGLISH
9
4.3 Installation
The lamp fall-down may cause
damage to persons and objects
➢When mounting the lamp ensure
that the original fastenings are
used, which you may purchase
from the supplier.
➢Make sure the mounting
accessories have correctly
installed
Switch off power supply before
proceeding to installation.
Correct installation using
MZ.FX01
The fastener kit consists of:
-No.2 pairs of chrome steel
brackets for lamp plaphone
fastening
-No.2 screws M5x10 with washers
for mating brackets
-No.2 M5x10 screws with rollsfor
fixingbrackets on the lamp
Hook the two pairs of fastening
brackets using the screw (Picture 04)
Then fasten the brackets to the four-
dice lamp (Picture 5,6).
Then attach the lamp to the dedicated
structure, using suitable M5 screws,
chosen by the installer (Picture 7)
ATTENZION
WARNING
Installation
Picture 04
Picture 05
Picture 06

ENGLISH
10
➢Then connect the lamp to the
power supply.
Correct installation using MZ.FX02
The fastener kit consists of:
-No.2 pairs of chrome steel
brackets for lamp plaphone
fastening
-No.2 M5x10 screws with bracket
coupling washers
-No.2 M5x10 screws with bracket
fastening washers on the lamp
Hook the two pairs of fastening
brackets using the supplied screw
(Picture 08)
Then fasten the brackets to the four-
dice lamp (Picture 09)
Then attach the lamp to the dedicated
structure, using suitable M5 screws,
chosen by the installer (Picture 10)
➢Then connect the lamp to the
power supply.
Collegamento elettrico
Picture 07
Picture 10
Picture 08
Installation
Picture 09

ENGLISH
11
Damaging or destruction of the
appliance.
➢Periodically check the mounting
system and the tightening of the
screws
5. Plug-in
Material damage caused by liquid
infiltration causes damage to the
lamp.
NOTE: The fastening parts for this
lamp are available as accessories.
Please For further details, please visit
our website: www.ccealights.com
5.1 24VDC Power Connection
Any material damage caused by
wiring errors will damage the lamp.
➢Qualified personnel must carry
out the electrical connections.
➢Polarities of the conductors have
to be correctly matched.
Cable output on the back of the lamp
Conductor Connection
Black 1 24VDC
Black 2 0VDC
*On request the possibility of exiting side cable
opposite to the side of the switch
➢Stay within the input voltage
range for the lamp so you don’t
damage the LED driver:
22 ÷ 36VDC
NOTICE
NOTICE
Collegamento elettrico
Plug-in
NOTICE
NOTICE

ENGLISH
12
5.2 110/230VAC Power Connection
High tension, danger of death!
The connection must be made by a
specialized electrician.
Conductor Connection
Black 1 L –110/230VAC
Black 2 N –110/230VAC
Yellow/green GND –110/230VAC
Stay within the input voltage range for
the lamp so you don’t damage the LED
driver AC/DC.
5.3 Wiring Accessories
Cod. N12710001040202
CONN M12 4P (M) for ø 6-8mm cable
Current max. 4A –Conductors cross-
section max. 0,75mm2 –IP67
6. Switching On and Off
➢The lamp is equipped with an
independent on and off switch
system.
➢The switch stops in the power
phase conductor.
Plug-in
WARNING
NOTICE

ENGLISH
13
7. Problem solving
In case the lamp doesn’t turn on:
➢Check that the lamp is properly
wired to the supply voltage.
➢Check that polarity wiring has
been carried out correctly.
Please contact CCEA’S Technical support
service in case the lamp is defective
CCEA Technical Support Service
Phone: [phone]
[e-mail]
www.ccealights.com
8. Replacing the LED light
source
The outstanding lifetime of the LED
light source, over 60.000 hours, makes
it unnecessary to replace the PCB LED
if the lamp is properly installed and
used following the instructions in this
manual. Please contact CCEA’s
Technical Support service - or your
Reseller –in case the replacement of
the PCB LED is needed for any defects
not covered by the warranty.
9. Product Maintenance and
Cleaning
Switch off the power supply before
any installation, maintenance or
reparation procedures.
This product is maintenance-free.
➢Lamp cleaning to be carried out
only after it has been switched off
and surfaces have cooled down.
➢Carefully rinse the lamp surface
with a mild cleanser and then
wipe off using a soft cloth in order
to avoid scoring it.
Leakage of liquid will cause damage
to the lamp.
➢The lamp cannot be installed in
humid environments
10. Repairs
All material damages caused by
poorly executed repairs may damage
the lamp
➢All repairs must be carried out by
the manufacturer or by qualified
technicians.
➢Only use spare parts having been
approved by the manufacturer.
WARNING
NOTICE
NOTICE
Problem solving and Repair

ENGLISH
14
11. Warranty
Terms of warranty
CCEA ensures that any control
procedures or repairs –to be carried
out exclusively at/by CCEA Technical
service dept. or by any CCEA’S official
dealer –are covered throughout the
entire product’s lifetime. In view of
the above, take care to preserve the
product label and case, to be
submitted if any repair operations are
needed.
All repair and spare parts costs will be
notified after the defects have been
examine.
The warranty does not cover:
• Any transport, packaging or
shipping costs;
• Any damages or deterioration
caused by:
- Installation and/or operation carried
out following different ways;
- Any unauthorized repairs or
attempts to repair the product;
-Equipment operation under
environmental conditions other
than those specified in the user
manual;
- Liquid leakages inside the lamp;
- Failure to follow the safety
precautions related to transport and
shipping the product back for repair
(please make sure to have it shipped
back in its original case).
Period of warranty
The warranty period covers 24
months, starting from the delivery
date. CCEA guarantees that the
products have no manufacturing
defects or malfunctioning.
12. Product disposal (EU
Regulation)
All the electrical and electronic
equipment (WEEE) have to be
managed with selective waste sorting
and cannot be disposed of as
municipal waste, as provided for in
Directive 2012/19/Ue.
In view of the above this equipment,
all its components, subsystems and
the consumables which are an integral
part of the product have to be
conveyed to the local collection
facilities for them to be disposed of in
accordance with the current
legislation.
Please apply to the council offices of
your place of residence in order to
know where the collection facilities
are located.
Warranty

ENGLISH
15
13. Technical data
NOTE: Please refer to the data printed
on the label or engraved on the lamp.
24VDC version
230V version
14. Simboli
CE conformity marking
Class III insulation
appliance
Class I insulation
appliance
IP40 degree of protection
Power supply 22-36VDC
Power 12-24-36-48W
(see lamp)
IEC classe III
Degree of protection IP40
LED driver Integrated
driver system
Light color 5000K
CRI 80
Operating
Temperature -20 + 45 °C
For other values see the table on page 7
Technical Data and Symbols
IP40
Power supply 100-120V
220-240V
50/50Hz
Power 12-24-36-48W
(see lamp)
IEC classe I
Degree of protection IP40
LED driver sistema IDS
integrato
Light color 5000K
CRI 80
Operating
Temperature -20 + 45 °C
For other values see the table on page 7
WARNING:
Cancer and Reproductive Harm
www.P65Warnings.ca.gov

ENGLISH
16
15. Declaration of Conformity
Attached MIZAR_user_manual_EN_23-08-21
C.C.E.A. SRL, via Piave, 2 - 36077 Altavilla Vicentina (VI), Italy –VAT and Tax number 02374040240
hereby declares that the light equipment named MIZAR –to which the present Declaration of
Conformity is related - was manufactured by CCEA SRL in accordance with the following Directives:
2014/35/UE on Low Voltage Equipment Safety and the Directive of Electromagnetic Compatibility
89/336/CEE (EMC) 2014/30/UE. The unit complies in particular with the following regulations:
llowing regulations:
•Directives:
•Harmonized Standards
CEI EN 60598-1 “Lighting equipment. Part 1: General instructions and tests”
CEI EN 60598-2-4 “Lighting equipment part 2: particular requirements – part 4 Portable
general-purpose luminaries”.
CEI EN 62031 “LED modules for general lighting. Safety specifications”.
CEI EN 62384 “DC or AC supplied electronic control gear for LED modules. Performance
requirements”.
This is a standard product manufactured following a detailed production schedule ensuring that
inspections and destructive tests were carried out, for a safe, functional and sustainable product to be
delivered.
C.C.E.A. SRL disclaims any responsibility resulting from tampering and/or wrong use of the device.
Date: ___________________________
Week of production: ______________
Product code: ___________________
Declaration of Comformity
C . C . E . A . s r l
Via Piave, 2
36077 Altavilla Vicentina (VI) - Italy
Tel. ++39 0444 572083
Fax. ++39 0444 572337
E-mail: [email protected]
www.ccealights.com
Machinery Directive 2006/42/EC
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
