CCS SE-65-M Series User manual

- 1 -
High-resolution Telecentric Lens SE-65-M Series Operating Manual
Thank you for purchasing a High-resolution SE-65-M-series Telecentric Lens.
To properly use the product and take full advantage of its functionality, read this operating
manual before using the product. After reading this operating manual, store it in a safe and
readily accessible location.
*1 Calculations are based on a permissible circle of confusion diameter of 40 μm.
*2 These are calculated values.
*3 Theoretical resolution calculations are based on a wavelength of 550 nm.
*4 Reference values of the maximum image size are as follows:
2/3": 6.60 mm height, 8.80 mm width, 11.00 mm diagonal
2/3"L: 5.98 mm height, 11.26 mm width, 12.75 mm diagonal
• Do not disassemble or modify the product.
• Do not subject it to impact.
• Handle the lens with care during daily use. Make sure no dust, dirt, or ngerprints adhere to
the lens.
• Remove dust and dirt by blowing it off with air. Do not touch the lens with your hand.
• Use a soft, nely woven cloth to wipe away any marks, such as ngerprints.
• The lens barrel has a lens at the object-side end. Do not hold it too tight. For details of the
relevant part, refer to the dimension diagrams at the back of this instruction guide.
Application Precautions1
Specifications
2
Model
Coaxial SE-65VT05-M SE-65VT08-M SE-65VT10-M
Straight SE-65ST05-M SE-65ST08-M SE-65ST10-M
Lens type Object-space telecentric lens (xed magnication)
Optical magnication 0.5x ±5% 0.8x ±5% 1.0x ±5%
WD 65.1± 2 m m 65.4±2 mm 65.1± 2 m m
Depth of eld*1*2 2.87 mm 1.18 mm 0.79 mm
Optical resolution*2*3 12.0 μm 8.0 μm 6.7 μm
NA*2 0.028 0.042 0.05
Actual F number (Fe)*2 9.0 9.4 9.8
TV distortion*2 -0.001% +0.006% -0.023%
Weight
Coaxial 80 g 62 g 54 g
Straight 77 g 57 g 49 g
Camera mount C mount
Maximum image size*4 2/3"
Applicable wavelength 400 to 700 nm
Operating environment Temperature: 0 to 40°C, Humidity: 85%RH max. (with no condensation)
Storage environment Temperature: -20 to 60°C (with no condensation)

- 2 -
*1 Calculations are based on a permissible circle of confusion diameter of 40 μm.
*2 These are calculated values.
*3 Theoretical resolution calculations are based on a wavelength of 550 nm.
*4 Reference values of the maximum image size are as follows:
2/3": 6.60 mm height, 8.80 mm width, 11.00 mm diagonal
2/3"L: 5.98 mm height, 11.26 mm width, 12.75 mm diagonal
Specifications (Continued)
2
Model
Coaxial SE-65VT20-M SE- 6 5V T40 - M SE-65VT60-M
Straight SE-65ST20-M SE-65ST40-M SE-65ST60-M
Lens type Object-space telecentric lens (xed magnication)
Optical magnication 2.0x ±5% 4.0x ±5% 6.0x ±5%
WD 65.2±2 mm 65.3±2 mm 64±2 mm
Depth of eld*1*2 0.26 mm 0.08 mm 0.06 mm
Optical resolution*2*3 4.4 μm 2.9 μm 2.9 μm
NA*2 0.076 0.118 0.118
Actual F number (Fe)*2 12.9 16.9 25.5
TV distortion*2 +0.021% -0.003% -0.026%
Weight
Coaxial 55 g 85 g 100 g
Straight 49 g 83 g 98 g
Camera mount C mount
Maximum image size*4 2/3"L
Applicable wavelength 400 to 700 nm
Operating environment Temperature: 0 to 40°C, Humidity: 85%RH max. (with no condensation)
Storage environment Temperature: -20 to 60°C (with no condensation)

- 3 -
Dimensions
3
Coaxial Lenses Straight Lenses
(Unit: mm)(Unit: mm)
SE-65ST05-M
SE-65VT05-M
SE-65VT08-M
SE-65VT10-M
SE-65ST08-M
SE-65ST10-M
Do not hold.
(Lens)
Hexagon socket set screws
C mount
Hexagon socket set screws
Adjustment for camera rotation axis
Do not hold.
(Lens)
Hexagon socket set screws
C mount
Hexagon socket set screws
Adjustment for camera rotation axis
Do not hold.
(Lens)
Hexagon socket set screws
C mount
Hexagon socket set screws
Adjustment for camera rotation axis
Ø29
Do not hold.
(Lens)
Hexagon socket set screws
Adjustment for camera rotation axis
17.526 88.4
4
7
7.5(22.4)2533.5
(WD 65.1)
(O/I=171.1)
C mount
120°
120°
Ø22
Ø32
3xM3x3
Ø29
Do not hold.
(Lens)
Hexagon socket set screws
Adjustment for camera rotation axis
17.526 88.6
4
7.52135.3
14
(24.8)
(WD 65.4)
(O/I=171.5)
C mount
120°
120°
Ø16
Ø25
3xM3x6
Ø29
Do not hold.
(Lens)
17.526
78.4
4
7.52129.3
12
(20.6)
(WD 65.1)
(O/I=161)
C mount
120°
120°
Ø16
Ø25
Hexagon socket set screws
Adjustment for camera rotation axis
3xM3x6
Ø29
Ø22
Ø32
721
Ø15.5
Ø14
Ø8
17.526
7
7.5(22.4)2533.5
88.4
47.5 4
(WD 65.1)
(O/I=171.1)
120°
120°
3xM3x3
2xM3x4
Ø29
Ø16
Ø25
7
23
Ø15.5
Ø8
Ø14
14
17.526
7.5(24.8)2135.3
88.6
45.8 4
(WD 65.4)
(O/I=171.5)
120°
120°
3xM3x6
2xM3x4
Ø29
Ø16
23
Ø25
7
Ø15.5
Ø8
Ø14
12
17.526
7.5(20.6)2129.3
39.8
78.4
4
(WD 65.1)
(O/I=161)
120°
120°
3xM3x6
2xM3x4

- 4 -
Dimensions (Continued)
3
(Unit: mm)(Unit: mm)
Coaxial Lenses Straight Lenses
SE-65VT20-M SE-65ST20-M
SE-65ST40-M
SE-65ST60-M
SE-65VT40-M
SE-65VT60-M
17.526
17.526
17.526
(O/I=160.9)
(O/I=184.5)
(O/I=216.7)
(WD 65.2)
(WD 65.3)
(WD 64)
78.2
101.6
135.2
7.5
7.5
7.5
21
27.7
27.7
41.9
41.9
12
12
21.4
4
4
4
(24.5)
(58.1)
Ø25
Ø25
Ø25
Ø16
Ø22
Ø22
Ø29
Ø29
Ø29
C mount
C mount
C mount
C mount
C mount
C mount
120°
120°
120°
120°
120°
120°
Hexagon socket set screws
Adjustment for camera rotation axis
Hexagon socket set screws
Adjustment for camera rotation axis
Hexagon socket set screws
Hexagon socket set screws
Adjustment for camera rotation axis
Hexagon socket set screws
Adjustment for camera rotation axis
3xM3x6
Hexagon socket set screws
Hexagon socket set screws
3xM3x3
Hexagon socket set screws
Adjustment for camera rotation axis
Hexagon socket set screws
Adjustment for camera rotation axis
3xM3x3
Do not hold.
(Lens)
Do not hold.
(Lens)
Do not hold.
(Lens)
Do not hold.
(Lens)
(28.3)
17.526
(O/I=160.9)
(WD 65.2) 78.2
7.5
4
21
21.4 (28.3)
Ø25
23
Ø16
7
Ø8
Ø14
Ø15.5
31.9
Ø29
120°
120°
3xM3x6
2xM3x4
17.526
(O/I=184.5)
(WD 65.3) 101.6
7.5
4
(24.5)
27.741.9
Ø25
Ø22
7
22.5
Ø8
Ø14
Ø15.5
12
31.4
Ø29
120°
120°
2xM3x4
3xM3x3
17.526
(O/I=216.7)
(WD 64) 135.2
7.5
4
(58.1)
27.7
41.9
Ø25
Ø22
7
22.5
Ø8
Ø14
Ø15.5
12
31.4
Ø29
120°
120°
2xM3x4
3xM3x3
Copyright© 2017 CCS Inc. All Rights Reserved.
Descriptions in this instruction guide are based on information available as of April 2017. KZ08966-T001-001
