CCTV CMF1171X User manual

PRECAUTIONS
D E S C R I P T I O N
PARTS INSTRUCTION
FEATURES
420 TV Line
Enhanced Effio-E Advanced Image Processing Technology; 700TVL High Resolution
700 TV Line
The series camera adopts SONY newest generation image processing technology-
Enhanced Effio-E. It has high horizontal resolution up to 700TVL as well as advanced
DNR, D-WDR, HS-BLC and other functions. Fashionable and professional appearance
design; IP66 waterproof. Powerful OSD menu(optional) includes Brightness, Contrast,
Saturation adjusting functions; Multi-area, White Balance, AGC , and other functions
ensure clear bright pictures. Besides, Mirror, Privacy and other aided functions make it
suitable for various special environments and realize simple and convenient round-clock
surveillance.
Thank you for your purchasing this product. Before attempting to connect or operate this
product, please read these instr uctions carefully and save this manual for future use.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL
Use special algorithm, reduce video and color noises, which increases its resolution
and cleanliness and creates clearer and sharper images.
2D-DNR
D-WDR
Advanced D-WDR technology greatly improves its image quality under variable
lighting conditions.
HS BLC
It can distinguish strong strong light spots, and cover them to improve the definition
of the entire image and thus ensures clearer and more effective surveillance.
700TVL horizontal resolution with 1/3" sony 960H CCD.
High Resolution
COLOR mode in daytime when there is enough light and B/W mode at night when
the illumination is low and IR turned on automatically.
Auto D/N Swithover Operating Mode
Up to 4 areas can be masked to protect personal privacy by concealing parts of the
image from view.
Privacy Mask(optional)
Powerful OSD menu allows for various function settings.
OSD Menu(optional)
1.
is DC12V.
2.
3.
4. Do not expose the camera to rain or moisture, or tr y to operate it in wet areas.
Do not place the camera in the following locations:
①Locations where temperature is lower than -10℃or higher than 50℃;
②Locations where humidity is higher than 95%;
③Locations where there are large amounts of water vapor and steam.
6.
7.
8.
Use the Appropriate Power Supply
The input power for the camera Be sure to connect it to the appropriate
power. Wrong connection may cause malfunction and/or damage to the video
camera.
Do not attempt to disassemble the camera.
To prevent electric shock, do not remove screws or covers. There are no user
serviceable parts inside. Ask a qualified ser vice person for servicing.
Handle the camera with care.
Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged
by improper handling or storage.
5. Do note use strong or abrasive detergents when cleaning the camera body.
Use a dr y cloth to clean the camera when dirty. In case the dirt is hard to remove. Use
a mild detergent and wipe gently.
Clean the CCD faceplate with care.
When cleaning the CCD panel, do not use strong or abrasive detergents. Use a piece
of lens tissue or cotton tipped applicator and ethanol.
Do not attempt to aim the camera at the sun
Do not attempt to aim the camera at the sun or other extremely bright objects that
causes mear to appear irrespective of whether the camera is operating or not. This can
damage the CCD (Charge Coupled Device).
Do not put the camera in a place with interference.
When this camera is installed near the equipment like wireless communication device
which emits strong electromagnetic field, some irregularity such as noise on monitor
screen may happen.
SPECIFICATIONS
Model No
Sensor
Video Format
Sync Mode
Resolution
S/N Ratio
Mini Illumination
AGC
White Bal
BLC
Mirror
Iris Control
Shutter Speed
Voltage
Current
Operating Temp
Storage Temp
Dimension
Weight
Mode
Range
1/3 High Sensitivity CCD" 960H
PAL/NTSC
INTERNAL
700TVL
0.01Lux
AUTO; MANUAL
ON; OFF; HLC
ON/OFF
Electronic Iris/Auto Iris Lens
1/60(1/50)-1/100000 Second
DC12V
>50dB (AGC OFF)
MANUAL;ATW; USER
(ATW) 2200~10000°K
-10℃~50℃
-20℃~50℃
Day/Night
AUTO; COLOR; B&W
Sensor
Privacy
ON/OFF(1-4 AREAS)
Adjustment
HIGH LUMINANCE; LOW LUMINANCE
Title
ON/OFF (15 Characters Max)
Menu Oper(optional) Power
2D-DNR
D-WDR
ON/OFF
ON/OFF
Lens
*Specifications subject to change without notice.
<200mA
Color High Resolution Waterproof Dome
Camera Operating Instruction
2.8-12mm
144mm（φ ）* 99mm(H)
850g
IP 66 Waterproof
Waterproof, Dust Prevention Design.
DIMENSIONS (Unit: mm)
1.
2.
3.
4.
5.
Affix the Installation instructions sticker on the wall;
Let base holes align the holes (sticker on the wall), and
use screws to secure the base on the wall;
If you want to adjust the lens, you need loosen the
Glass cover screw (four), then adjust the lens;
When you finished the lens adjustment, then install
the Ball cover component.
Installation complete.
1.
2.
3.
4. inner cover
5.OSD menu
6.
7.
8.
Installation instructions sticker
Glass cover screw (four)
Ball cover components
I
Lens
Base
Install screws hole (four)
4.5 125
99
54.5
（φ ）92
（φ ）144
± °
° ± °
Adjust Camera Direction
When camera is fixed on the ceiling,
you can adjust its three-dimensional
bracket to the angle you need: X: 175 ,
Y:0-70 , Z: 175 . Adjust the lens to the
focal length you need and adjust the focus
again to get clear pictures.
Z
X
Y±175°
0-70°
±175°
Notice: Camera front-end mark on mounting bracket should face to the monitoring area.
Camera Installation:
Corresponding
installation
4 Point-
Drilling Position 1
2
3
4
5
6
7
8

EN-U4-660-121122
