CCTV WDR3600 User manual

USER'S MANUAL
WDR(Wide Dynamic Range)
COLOR DAY & NIGHT CAMERA

WDR is a Powerful and Ultra advanced Technology to Capture
Cleaner , Superior High Resolution pictures at the same time even
the Dark part when observing the objects under a strong back lig
h
Spotlight BLC function is especially effective to Read the number
plate of the vehicles in the street or parking lot at night time.
Especially users can adjust and select the special required area
to Observe the target object under the strong spots of lights exist.
Newly Developed 3D filtering method of DNR enhances Excellent
Efficient at night time. 3D Filtering of the video signal optimizing the
Signal to noise, allowing the much better visibility and it enhances
increasing powerfully SENS - UP to 256 times in low light condition.
WIDE DYNAMIC RANGE
NORMAL SPOTLIGHT BLC
3D FILTERING METHOD ADVANCED DNR TECHNOLOGY
DNR OFF DNR ON
SPOTLIGHT BLC FUNCTION
WDR OFF WDR ON
W D R
B L C
3D DNR

Precautions for use
☞Please read this manual enough before using this camera to obtain the skill
Of correct operation.
Cautions when using
☞Do not open the camera body and touch to prevent electric shock.
☞Do not insert other object into camera body to prevent hazards of fire and electric shock.
☞Do not touch with wet hands to prevent electric shock.
☞Do not pull out by taking power cord when plug out from the outlet.
☞Must pull out by taking plug socket.
☞If the camera has burning smells, please plug out and ask to shop where you bought
It or the nearest A/S center.
Cautions when Install
☞Plug on after installation of all device.
☞Do not install the camera face to strong light directly.
☞Do not install or use the camera in places where the humidity is high.
☞Do not install near the cooling device or heating device.
☞Do not install the camera where is high humidity or heavy dust.
☞Do not install the camera to the place where it has physical shocks.
☞Do not expose the camera to rain or moisture.
☞This products must have use DC adaptor for power.
2

3
Camera Parts & Function P1
Precautions P2
Content P3
Menu Setup P7
MENU SET UP P7
LENS SET UP P8
EXPOSURE P9
MOTION DET. P21
B L C P12
SPECIAL P18
WHITE BAL. P11
S S N R P14
IMAGE ADJ. P16
DAY & NIGHT P15
CAMERA TITLE P18
LANGUAGE P23
S Y N C P21
PRIVAC P2
DIS P2
COMM ADJ. P2
How to Install P24
Troubleshooting P25
EXIT P23
C O N T E N T
General Features P4
How To O
p
erate Camera Menu P5
Special Menu P6

◈WDR (Wide Dynamic Range)
- Camera has very strong compensation performance in WDR. It always shows obvious,
Clear and perfect light contrast picture in environment.
◈560TV Lines
- Unification of DNR Technology and Sony Super HAD CCD image sensor provides Clear & Superior
High resolution of 560 TV lines.
◈Day & Night
- Up to the lighting conditions, the video automatically switching to color mode in bright zone
And Monochrome mode in dark zone making to achieve safe and perfect 24 hours surveillance.
◈Illumination
- Ultra Advanced DNR technology enhanced incredibly minimum illumination of amazing 0.00006 Lux
With capture of good image under the extremely low light conditions.
◈Illumination
◈Disk Saving Effects
- Upmost and advanced DNR technology camera picture quality has a disk saving effects due to
Image sizes are smaller than standard CCTV camera image.
◈DNR DSP Chip
- DNR is superior DSP chipset enhanced various and powerful function of high resolution,
Day & Night, Removing camera noise and sense up, as well. It is the highest and
Advanced technology that is unified Up-most necessary functions by one DSP chipset
Enhanced powerful surveillance functions.
◈Additional Functions
OSD is available (Support Multi- Languages of 8 Country)
Privacy Masking Funtion(8 Zones)
Sens-up( X256)
Digital Zoom(X 10)
4
- DNR technology solved removing the trouble of ghost figures and displaying clearer, superior
High resolution even in extremely low light circumstance.
G E N E R A L F E A T U R E S

⑨EXIT
SHUTTER : A.FLK
⑤DNR ON ON(LIMIT : 0 ~ 32 Level Selectable) / OFF
RETURN
FREEZE : OFF
V-REV : OFF
H-REV : OFF
DZOOM : OFF
SHARPNESS : ON
⑦IMAGE
V-REV : ON / OFF
⑧SPECIAL Refer to the next page
①LENS DC ONLY
MANUAL(x 256 ~ 120K)
②EXPOSURE
SHUTTER : -
AGC : LOW
SENS_UP : OFF
ESC(BRIGHTNESS : Level Selectable)
AGC : OFF / LOW / HIGH
SENS_UP : OFF / AUTO(2~256 Level Selectable)
RETURN
SET UP MENU DEFAULT SET M E N U
Setup Menu
③WHITE BAL. ATW
INDOOR / OUTDOOR / AWC / ATW
MANUAL(RGAIN : Level Selectable,
BGAIN : Level Selectable)
COLOR / B/W / AUTO / EXTERNAL
DWELL TIME : 5 ~ 60SEC
④BACKLIGHT OFF
WDR : LOW / MIDDLE / HIGH
BLC : TOP / DOWN / LEFT / RIGHT
OFF
⑥DAY / NIGHT COLOR
DURATION TIME : SLOW / FAST
FREEZE : ON / OFF
H-REV : ON / OFF
DZOOM : ON / OFF (0 ~ 255 Level Selectable)
Save all the SETUP Menu and then exits
5
SHARPNESS : ON / OFF (1 ~ 31 Levlel Selectable)
S P E C I F I C A T I O N

SEPECIAL MENU
AREA MODE : OFF
YPOS : Level Selectable
FILL →SET
AREA MODE : TOP / DOWN / LEFT / RIGHT
①CAMERA TITLE OFF ON / OFF
OFF
TRANSP. : Level Selectable
RETURN
④PRIVACY
AREA SEL : AREA 1
6
DEFAULT SET M E N U
RETURN
MASK COLOR : GREEN / RED / BLUE
③MOTION DET
INT / LL
(PHASE : 0 ~ 259 Level Selectable, MODE : OFF / TRACE)
INT
SEL POS : L_TOP
XPOS : Level Selectable
②SYNC
SENSITIVITY : AREA 1
⑥COMM ADJ.
RET PKT : ENABLE
DISP CAM ID : OFF
OFF
CAM ID : 0
⑧RESET −Returns to the level which was set by manufacturer for shipme
n
BAUDRATE : 2400 / 4800 / 9600 / 1920 / 38400 / 57600
PARITY : 8-N-1
RET PKT : ENABLE
DISP CAM ID : OFF
BAUDRATE : 38400
PARITY : 8-N-1
⑦LANGUAGE ENGLISH
BLACK / WHITE / GRAY
⑤DIS OFF OFF / ON
CAM ID : ID Selectable
⑨RETURN −Return to the SETUP menu
S P E C I A L M E N U

Menu could be adjusted by the OSD button of the camera
1. Press the setup button.
Setup menu will be displayed on the monitor
Move the arrow indicator UP or Down to indicate onto desired feature by pressing the UP or Down butto
n
Select desired Change the adjustment
Feature By Left or Right
Button
Available value or Status will be displayed by pressing the Left or Right button. Please press the
4. After complete the adjustment, move the arrow indicator to “EXIT” and press the “SET” button to Exit.
Button until desired features appears.
2. Move and Select to function what you want to control by the button.
3. Menu Setting Up change by Left or Right Button
7
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WD
R
DNR ON
DAY / NIGHT AUTO
IMAGE AD
J
SPECIAL
EXIT
CAUTION
Moving available to submenu by moving arrow to desired feature
A
ccess are not available to submenu on the mode o
f
" -----".
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WD
R
DNR ON
DAY / NIGHT AUTO
IMAGE AD
J
SPECIAL
EXIT
M E N U S E T U P

DC / VIDEO : DC Auto IRIS Lens
It’s function of control the picture brightness.
1. Move to arrow indicator to “LENS” by pressing of UP or Down button on the Set Up menu screen.
2. Select the desired lens type by pressing of Left or Right button.
3. Press the SETUP button to return previous menu.
8
LENS( Option )
CAUTION
Available to control the brightness when selected DC. Brightness control range will be
LENS
BRIGHTNESS 1--------1---------1 35
Press Set to
MANUAL:Manual Lens
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WDR
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
L E N S ( O P T I O N )

2. Select desired shutter mode by pressing of Left or Right Button.
9
It’s a function of selecting the Automatic shutter speed control or Manual shutter speed control.
1. On the Set Up menu screen, select " EXPOSURE" by using of UP or Down button.
●FLK : Select “FLK” mode when it has flickering by unmatched of electric lights and radio waves.
●ESC : Available automatic shutter speed control. Brightness could be automatically controlled when
Selected “ESC” mode.
●MANUAL : Shutter speed could be controlled by manually.
EXPOSURE
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WDR
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
EXPOSURE SETUP
SHUTTER
A G C HIGH
SENS - UP OFF
RETURN
E X P O S U R E

AGC(AUTO GAIN CONTROL):
The higher the gain level, the brighter the screen makes the highter noise.
OFF : Deactivates the AGC function
LOW : Allows automatic gain control from "0 ~ 30dB.
HIGH : Allows automatic gain control from "0 ~ 42dB.
SENS-UP :
When it is night and/or dark condition, the camera automatically detects the light level
and maintains a clear picture if this mode is activated.
OFF : Deactivates the SENS-UP function.
AUTO : Activates the SENS-UP function.
RETURN
Select this is to save the changes in the EXPOSURE menu and return to SETUP menu.
10
CAUTION
To produce better results with A.FLK, do not use it in conjunction with WDR
mode of the BACKLIGHT menu
When the SHUTTER is set to ESC after selecting the internal Syncronization type.
the picture may become unstable if the camera faces a bright fluorescent light.
So there is needed take care when choosing the installation position
ESC and MANUAL modes are only available together when the lens is set to
MANUAL.
When the SHUTTER is set to MANUAL or A.FLK mode, SENS-UP will be disabled.
LIMIT
AUTO X 2
Press SET to Return
CAUTION
If press the SET button in "AUTO" mode, the brightness could be adjusted by
increasing or decreasing the shutter speed. (X2 ~ X256)
Note that the higher zoom level, the brigher the screen, but the more likely it is that
an after - image will appear.
Although Noise, Spots and Whitish symptoms may occur in SENS-UP operation
when the zoom level is increased, this is normal operation.

* Select one of the following 5 modes for user's purpose.
●ATW : It is suitable in the color temperature ranges from 1,800˚K to 10,500˚K
INDOOR : Select this mode when the color temperature is between 4500°K and 8500°K
OUTDOOR : Select this mode when the color temperature is between 1800°K and 10500°K
●AWC →SET : To find the optimal setting for the current luminance environment in this mode, set the poin
t
set the point the camera towards a sheet of white paper and press the SET button.
If the environment changes, readjust it.
●MANUAL : Select this to fine-tune White Balance manually, Set White Balance first by using the
ATW or AWC, Select the Manual mode and press the SETUP button to increase or
Decrease the value of R-Gain(RED) and B-Gain(Blue) while watching the color of image.
2. Select desired mode by using of Left or Right button.
1. Move the arrow indicator to ‘WHITE BAL’ by pressing of SET button on the SETUP Menu screen.
Use the White Balance function when need to color control on the screen.
11
WHITE BALANCE
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WDR
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
CAUTION
Proper White Balance may not be worked under the following conditions. In that case,
Select the AWC mode
When the scene of object has most high color temperature.( Ex: Blue Sky, Sunset )
When install the camera in place of the changing illumination and / or faces directly to
Fluorecent lights.
When the scene of object is so dim
MANUAL
Press SET to Return
B L U E 50
R E D 50
W H I T E B A L A N CE

WDR : When there are both of bright & dark areas at the same time, this mode makes both areas distincti
v
OFF : WDR function will not operated.
BLC : Enables a user to directly select a desired area from a picture and to view the area clearly.
OFF
This camera provide intelligent light level control to overcome the severe Backlight condition.
W D R
1. Move the arrow indicator to ‘BACKLIGHT’ by pressing of UP or Down button on the SETUP Menu screen.
12
2. Select the desired mode by pressing of Left or Right button.
BACKLIGHT ( BLC )
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT OFF
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
B A C K L I G H T ( B LC )

3. Select a desired mode using the Left and Right buttons and press the SET button.
Select "WDR" to adjust the WDR LIMIT and LEVEL.
LIMIT : Adjust the WDR Sensitivity by selecting LOW, MIDDLE or HIGH.
LEVEL : Adjust the WDR Brightness by controlling the bar fro 0 ~ 100.
Select " BLC " to adjust the area to be enhanced and enhancement level.
13
WD
R
LIMIT
LIMIT MIDDLE
Press SET to Return
LEVEL 50
B L C SETUP
Press SET to Return
BOTTOM 82
T O P 27
L E F T 42
RIGHT 42
LEVEL MIDDLE
CAUTION
You cannot use the WDR mode when MANUAL or A.FLK mode in " SHUTTER "
menu is selected.
Since the following symptoms may occur according to the ambient illumination when
WDR is selected, set it to OFF.
Color or Screen changes unnatually.
Noise appears in the bright part of the screen.
Since the performance of the WDR function may be affected by the area of the bright
part of the screen, optimize the installation angle for the best WDR performance.
If you increase LIMIT, the screen display may be distorted.
For the performance of WDR function, using DC IRIS lens rather than manual lens is
recommended

2. Select a desired mode using the Left and Right buttons.
This function reduce the background noise in a low luminance environment.
1. When the SETUP menu screen is displyed, select " DNR " by using the UP and DOWN buttons
ON : Activates DNR, Noise is reduced.
OFF : Deactivates DNR, Noise is not reduced.
3. Set the DNR mode to " ON " and press the SET button to adjust noise reduction level.
14
SSNR
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WDR
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
D N
R
Press SET to Return
LEVEL 20
CAUTION
You cannot set the DNR to "ON" or "OFF" when the AGC mode of the EXPOSURE
menu is " OFF "
When the adjusting the noise reduction level of the DNR mode, REMEMBER that
the higher the level set, the more noise level will be reduced but that after image
may also occur.
D N R

2. Select a desired mode using the Left and Right buttons according to the picture displyed you want.
COLOR : The picture is always displyed in color.
B/W : The picture is always displyed in black and white
AUTO : The mode is automatically switches to " COLOR " in normal condition
But it switches to " B/W " mode when ambient illumination is low.
To Set the switching time or speed for AUTO mode, press the SET button.
DWELL TIME : Duration time could be selected by changing the DAY / NIGHT mode.
→5s, 7s, 10s, 20s, 30s, 40s, 50s, 60s.
DURATION : Brightness of the illumination could be selected by changing the DAY / NIGHT mode.
* The brightness of illumination is changeable by installed environment.
Fast 2.5 Lux 4 Lux
Color →B/W
15
The pictures could be displyed in color of black and white.
B/W →Color
1. Select " DAY/ NIGHT" using of UP or Down button on the SETUP the screen.
Slow 0.8 Lux 6 Lux
DAY / NIGHT
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WDR
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
AUTO SETUP
Press SET to Return
DWELL TIME 10 SEC
DURATION FAST
D A Y / N I G H T

EXTERN : This mode allows you to apply a desired filter to external signals.
Down buttons to adjust " IMAGE ADJ."
2. Select the desired mode by pressing of UP or Down buttons.
16
1. When the SETUP menu screen is displyed, select "IMAGE ADJ." by using the UP and
IMAGE ADJ.
CAUTION
When using a Video Auto Iris Lens, if you set the lens level to low, it automatically
switching between Color and Black and White may not occured.
You cannot control the DAY / NIGHT menu when AGC in the EXPOSURE menu is
"OFF" . At this time, the exchange between DAY mode and NIGHT mode operates as
like selecting " COLOR" mode.
The camera may focus less well under infrared illumination than under normal
illumination
Since the camera may not focus as well under infrared illumination at night as it does
under normal illumination, install an Extra-Low dispersion Lens to obtain sharp pictures.
The OSD key does not working for 3 seconds when switching to COLOR or B/W to
ensure stable camera operation.
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WDR
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
IMAGE SETUP
1. FREEZE OFF
5. SHARPNESS ON
6. RETURN
2. V - REV OFF
3. H - REV OFF
4. D - ZOOM OFF
I M A G E A D J.

FREEZE : You can see still or moving pictures.
V - REV : You can flip the picture vertically on the screen.
H - REV : You can flip the picture horizontally on the screen.
D - ZOOM : You can use a digital zoom of x1 ~ x10.
SHARPNESS : As you increase this value, the picture outline becomes stronger
and clearer. Adjust this value appropriately depending on the
sharpness of the picture.
RETURN : Select this to save the settings for the IMAGE ADJ. menu and to return
to the SETUP menu.
17
CAUTION
When H - REV or V - REV is selected, any text in the picture also will be flipped
horizontally or vertically.
If you increase SHARPNESS level too high, the picture may become distorted or
noise may appear.
D - ZOOM
Press SET to Return
LEVEL 5
SHARPNESS
Press SET to Return
LEVEL 10

Down buttons to control the SPECIAL menu.
2. Select a desired mode using the UP and DOWN buttons.
1. When the SETUP menu screen is displayed, select " Special " by using the UP and
1. CAM TITLE : If inputted CAM TITLE, CAM TITLE will be displayed onto the screen.
1-1) Move the arrow indicator to ‘Camera ID’ by pressing of UP or Down button on the SETUP
Menu screen
1-2) Set “ON” by using of Left or Right button.
18
SPECIAL
CAUTION
When Cam Title is set to"OFF", The Camera ID will not displayed onto the monitor.
SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
BACKLIGHT WDR
DNR ON
DAY / NIGHT AUTO
IMAGE ADJ
SPECIAL
EXIT
SPECIAL
1.CAM TITLE OFF
2.SYNC INT
3.MOTION DET OFF
4.PRIVACY OFF
5.DIS OFF
6.COMM ADJ.
7.LANGUAGE
8.RESET
9.RETUR
N
S P E C I A L

1-3) Press the SETUP button
②Select the desired character in A, B~Y, Z, a, b~y, z, 0, 1~8, 9 by using of Up, Down, Left
1-4) ID could be entered up to 15 characters.
①Move the cursor to character enter location by using of Left or Right button.
And Right button.
③Set the desired character by pressing of SETUP button.
- The cursor will moved to next position after character select by pressing SETUP button.
19
④Repeat above steps until created the desired full name .
Camera ID
A B C D E F G H I J K L M N O P
Q R S T U V W X Y Z
a b c d e f g h I j k l m n o p q r
s t u v w x y z
1 2 3 4 5 6 7 8 9
CLR POS
Camera
A B C D E F G H I J K L M N O P
Q
R S T U V W X Y
Z
a b c d e f g h I j k l m n o p q r
s t u v w x y z
1 2 3 4 5 6 7 8 9
CLR POS
CAUTION
In Case of Wrong Camera ID Input…...
Move the cursor to "CLR" and press the SETUP button from right to left to erase
The characters. And repeat above steps to correct the characters again.
