CCV OPM-C60 User guide

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 1 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
Multifunctional terminal
OPP-C60s (Standard)
OPP-C60c (Compact)
OPP-C60m (7000)
OPM-C60
SCR-C, SCR-C NB, SCR-C NBS
COR-A10, COR-A12, COR-A20, COR-B20

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 2 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
Table of contents
1Purpose..........................................................................................................................5
2Scope.............................................................................................................................5
3Terms and Abbreviations................................................................................................5
4Responsibilties ...............................................................................................................5
5Characteristics................................................................................................................6
5.1 Safety Information....................................................................................................6
5.2 Important information for use...................................................................................7
5.2.1 Important integrator co-operation obligations .....................................................7
5.2.2 Cleaning OPP and OPM ....................................................................................8
5.2.3 Cleaning Card Reader........................................................................................8
5.2.4 Warranty............................................................................................................8
5.3 System description ..................................................................................................8
5.4 Payment methods....................................................................................................9
5.5 User Interface..........................................................................................................9
5.6 Certifications..........................................................................................................10
5.7 General technical information ................................................................................10
5.7.1 Interfaces for vending machines and ECR .......................................................10
5.7.2 Keyboard OPP-C60s/m....................................................................................10
5.7.3 Keyboard OPP-C60c........................................................................................11
5.7.4 Display.............................................................................................................11
5.7.5 Receipt Printer .................................................................................................11
5.7.6 IP/IK-Codes......................................................................................................11
5.7.7 OPP / OPM Status LED ...................................................................................12
5.7.8 Contacted reader SCR-C.................................................................................13
5.7.8.1 Certificates...............................................................................................13
5.7.8.2 Connection...............................................................................................13
5.7.8.3 LED status indicators at SCR-C................................................................14
5.7.9 Contacless reader COR...................................................................................15
5.7.9.1 General information about the COR .........................................................16
5.7.9.2 Viewing angle of the COR display ............................................................17
5.7.9.3 COR Interfaces.........................................................................................17
5.7.9.4 Security of COR-B20................................................................................19
5.7.104-eye Concept..................................................................................................20
5.7.11Merchant SAM Slot..........................................................................................20
5.7.12Communication................................................................................................20
5.7.13Interfaces.........................................................................................................21
5.7.14Protocols..........................................................................................................21
5.7.15Software...........................................................................................................21
5.8 Service ..................................................................................................................22
5.8.1 Integration in ECR and vending machine systems ...........................................22

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 3 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.8.2 Automatic startup.............................................................................................22
5.8.3 Software Update ..............................................................................................22
5.8.4 Maintenance and Repairs ................................................................................23
5.8.5 Maintenance-System........................................................................................23
5.8.6 Terminal Security State (TSS)..........................................................................23
5.9 Extensions.............................................................................................................25
5.10 Certification............................................................................................................25
6Technical Data .............................................................................................................26
6.1 Images and Dimensions ........................................................................................26
6.1.1 OPP-C60s (Standard)......................................................................................26
6.1.2 OPP-C60c (Compact) ......................................................................................27
6.1.3 OPP-C60m (7000) ...........................................................................................28
6.1.4 OPM-C60.........................................................................................................29
6.1.5 OPP-C60/OPM-C60 installation notes..............................................................30
6.1.6 SCR-C .............................................................................................................31
6.1.7 SCR-C NB (new bezel / new bezel with shutter)...............................................33
6.1.8 Dimensions of SCR-C front cut-out ..................................................................35
6.1.9 Dimensions of COR-A10 / COR-A20................................................................36
6.1.10Dimensions of COR-A12..................................................................................37
6.1.11Dimensions of COR-B20..................................................................................38
6.1.12COR mounting cut-out......................................................................................39
6.2 Interfaces...............................................................................................................40
6.2.1 POS (ZVT ERC interface) ................................................................................42
6.2.2 COM ................................................................................................................43
6.2.3 SCR.................................................................................................................43
6.2.4 MDB/COM2......................................................................................................43
6.2.5 LAN..................................................................................................................44
6.2.6 PWR (Power supply)........................................................................................44
6.2.7 USB-OTG.........................................................................................................45
6.2.8 USB-A..............................................................................................................46
6.2.9 GPRS Dongle (optional)...................................................................................46
6.3 Technical Data.......................................................................................................47
6.3.1 OPP-C60/OPM-C60.........................................................................................47
6.3.2 SCR-C .............................................................................................................50
6.3.3 COR.................................................................................................................51
6.4 ECR protocols........................................................................................................53
6.4.1 ZVT..................................................................................................................53
6.4.1.1 ZVT Spezification .....................................................................................53
6.4.1.2 Terminal startup with ZVT.........................................................................53
6.4.1.3 Cyclic poll of terminal status.....................................................................55
6.4.1.4 Reconciliation with closure .......................................................................55

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 4 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
6.4.1.5 Receipt printing ........................................................................................55
6.4.1.6 Off-states of Terminals.............................................................................56
6.4.1.7 Service-Menü...........................................................................................56
6.4.1.8 Time controlled actions of the terminal .....................................................56
6.4.1.9 Autorisation with existing Card data..........................................................56
6.4.1.10 Notes for privacy shield by PINPads.........................................................57
6.4.1.11 Notes of the printer stand .........................................................................57
6.4.1.12 Interpretation of interim state Information .................................................57
6.4.1.13 BMP 3C Formats......................................................................................57
6.4.1.14 Reconciliation with closure .......................................................................58
6.4.1.15 Supported fleet cards and station cards....................................................58
6.4.1.16 ZVT supported commands .......................................................................61
6.4.1.17 06 01 Authorization...................................................................................62
6.4.1.18 06 22 Pre-Authorisation / Reservation......................................................63
6.4.1.19 06 23 Partial-Reversal of a Pre-Authorisation/Booking of a Reservation...63
6.4.1.20 06 24 Book total .......................................................................................63
6.4.1.21 LED indicators at SCR-C..........................................................................64
6.4.2 O.P.I.................................................................................................................64
6.4.3 MDB.................................................................................................................65
7MTBF statistics.............................................................................................................65
8CE Declation of Conformity ..........................................................................................66
9EMV Certificates...........................................................................................................66
10 Changelog....................................................................................................................66

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 5 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
1 Purpose
This specification details the integration of the terminal OPP-C60 into vending machines.
2 Scope
Customer, Integrators, Net Provider, (CCV-EW, SA, PM)
3 Terms and Abbreviations
BMP Bitmap, pre-defined data field
COR Contactless Only Reader
DK Deutsche Kreditwirtschaft (formerly ZKA; http://www.die-deutsche-
kreditwirtschaft.de/)
OPM Outdoor Payment Module: This terminal is a multifunctional Terminal. It
has no display or keyboard within the machine.
OPP Outdoor PIN-Pad is a secure multifunctional terminal for installation in
machine for indoor and outdoor use.
COR-Bxx describes the contactless only reader combined with a chip reader
COR-Cxx describes the contactless only reader
OPP-C60s OPP-C60Standard with front cut-off 199*140mm (OPP-A40/B50)
OPP-C60c OPP-C60Compact with front cut-off 141*92mm
OPP-C60m OPP-C607000 with front cut-off 196*132mm
PM Product Management
SA Sales
SCR Secure-Card-Reader
TA Tankautomat (Auto fuel terminal)
TKS Terminal Configuration Server (Server responsible for software-updates)
TS3 Terminal Supervisor 3
WA Warenautomat (Vending Machine)
ZKA Zentraler Kreditausschuss (look at DK)
SAM Merchant Secure Access Module
RDT/DFÜ Remote Data Transmission
nWAKE negative Wakeup signal (bidirectionally (input and output): Each
connected MDB device can pull this line low to wakeup all other devices
on the bus
EMC Electromagnetic compatibility
4 Responsibilties
The Product Management group (PM) is accountable for the maintenance of this specification.

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 6 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5 Characteristics
5.1 Safety Information
•The system handbook should be studied before integrating the product into vending
machines, as this contains important information regarding installation.
•Damage resulting from not following the guidelines or from incorrect operation will
void the guarantee. No liability will be accepted for any consequential damage.
•No liability will be accepted for damage or injury resulting from incorrect operation or
from failure to observe the safety guidelines.
•Integration of the product may only be carried out of qualified by electrical specialists
(i.e. electrician), according to the relevant regulations (i.e. VDE, CE).
•If you have no specialist knowledge regarding the installation, do not carry this out
yourself. Installation should only be carried out by a qualified specialist.
•Never remove the power supply or the card-reader from terminal, whilst this is
performing a payment or other active functions (i.e. display indication „please wait...“).
Please contact your network provider if such a message appears for a longer period.
•Change the card-reader only if the power supply is disconnected.
•The terminal is certified for cashlesspayments in various countries, dependent on the
network provider / acquirer. Operation outside of Germany is to be agreed in
consultation with the relevant trade partner.
•Never try to open the terminal. Unauthorized opening leads to deletion of all secure
data, activating the fraud function and setting the terminal out of order. This also voids
the warranty.
•Never submerge the terminal in water, throw into fire or expose to high humidity. The
device should be cleaned with a soft damp cloth. Do not use chemical cleaners.
•Repairs may only be performed by authorized agents of CCV.
•Do not expose the device to temperatures outside the approved limits.
•Keep sufficient distance to mobile phones and wireless devices because these may
cause interference. This is not necessary for devices that are able to perform a
contactless transaction (e.g. mobile with NFC interface).
•Please obtain regular information about available and/or necessary updates or
product extensions (Hotline of your network operator).
•Following software updates, telephone installation changes, or other changes to the
terminal the complete payment operation including closing should be tested.
•Damage to or removal of the identification labels and seals on the equipment will void
your warranty.
•One mounting screw of the terminal must be connected with the grounding of the local
electrical system. The grounding must not be connected to a floating ground or a
phase (see chapter Installation Instructions.

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 7 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.2 Important information for use
5.2.1 Important integrator co-operation obligations
•The installation instructions as described in the system manual must be followed,
particularly in view of mechanical, electrical and operational guidelines (ESD-
electrical grounding).
•Check the integrity of the Terminal. Check if the Terminal shows damage and
manipulation and the seal is unbroken. If you detect damage, tampering or a broken
seal do not operate the Terminal. Contact the support at [e-mail].
•Important! Please ensure that the terminal is connected, configured and tested so as
to execute updates via remote maintenance server TKS. Please also ensure
possibility that updates can be initiated via the vending machine interface or the
network-provider. In installation lacking a network connection where remote
maintenance is not possible, it must be ensured that the integrator carries out on-site
updates using Terminal Supervisor 3 or USB and that additional costs will occur.
•It must be ensured that software tools (Terminal Supervisor 3, Updatempp, etc.) are
regularly updated. The current versions are available from the CCV download server.
(https://download.ccv-deutschland.de)
•CCV points out that regular operational and security relevant updates could be
required. Not carrying out these updates can lead to loss of approval and/or
malfunction. CCV notifies of necessary updates in an appropriate time of period via
release-notes. The provision of updates during the guarantee period isfree. CCV is not
liable for malfunctions or damage caused by lack of maintenance updates or
maintenance errors due to the customer.
•CCV supports you during the initial installation of the product into vending- or other
machine, and recommends a joint check of your vending-machine/terminal integration
on-site prior to piloting, so that typical problems can be eliminated in advance. Please
contact you reseller or CCV directly for details of this.
•Following expiry of the warranty period it is possible to purchase software-updates or
a part of a previously contracted software maintenance contract. Necessary updates
are documented in the release-notes. Software-updates are generally only available
for a fee. Further details are available in consultation with your sales partner.

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 8 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.2.2 Cleaning OPP and OPM
Clean the cabinet of the terminals with a slightly damp cloth or an antistatic cloth. Please do
not use chemical cleaners. Never usepetrol, thinner or othersolvents for cleaning the housing,
otherwise deformation and discoloration can occur on the housing.
5.2.3 Cleaning Card Reader for smartcards/ magnetic stripe
cards
Clean the smartcard/ magnetic stripe reader (for example SCR-C60) regularly with a cleaning
card to prevent read errors. The cleaning intervals depend on the frequency of use and on the
ambient conditions. Please do not use chemical cleaners. For cleaning the front of the card
reader please use a slightly damp cloth or antistatic cloth.
The following intervals should serve as a guideline:
- Indoor device: 1 * weekly
- Outdoor device: 1 * daily
5.2.4 Warranty
Caution: Do not try to repair or to open the terminals card reader. Opening the device will void
the warranty. The device will be no longer functional and must be replaced.
In case of damage, please contact your service provider.
5.3 System description
The multifunctional OPP-C60 and OPM-C60 are as an evolution of the OPP-B50 tailor-made
payment system for vending machines, tank machines, service machines and kiosk, where it
is used as a compact and fully functional terminal. A more compact design is available as the
OPP-C60 Compact, which requires a smaller installation footprint with the same functionality.
The multifunctional OPP-C60 consists of a separated card reader and a highly integrated PIN-
Pad as the main device of the Systems. Next to the built-in LAN port, diverse communications
can be realized via USB connections such as ISDN or GPRS. For this purpose the device does
not even to be removed.
Otherwise, no more additional components are required in the machine (besides the card
reader and receipt printer) the cost of integration in an automatic system is reduced to a
minimum.
The elegant OPP-C60 with is front in vertically brushed stainless steel, a high resolution
graphicalLCD display andone for the purpose optimally tuned keyboard isbased on a forward-
looking hardware platform, the highest quality standards sufficient and due to their design
offers a high level of security. It is vandal-resistant, weather resistant and can be used in an
extended temperature range. The OPP-C60 is beside the Indoor use ideal for Outdoor use.
The OPP-C60 Standard requires the same mounting cutout and the same mounting points as
the OPP-A40 und OPP-B50. Therefore, it can be used by integrators easily.
The terminals are conforming to the requirements of ZKA TA7.1 trader terminals. As a
pioneering hardware platform with extensive storage facilities it offers not only a variety of

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 9 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
uses, but can also be updated at any time by a Software-Download to add new software
features and functionality
The intelligent software update concept offers maximum reliability. To the very best service
concepts (exp. Terminal supervisor and terminal management system TKS) were adopted at
this point. Thus, it offers maximum investment security.
5.4 Payment methods
With the terminals following payment methods can be performed:
OPP-C60
•girocard, Maestro, V PAY,
•ELV (Lastschriftverfahren, Debit process)
•Online-Lastschriftverfahren (Online Debit process)
•Credit cards (e.g. Mastercard, VISA, American Express, Diners, JCB)
•Station- and Fleet Cards (optional)
•Various loyalty cards can be added with card profiles
•GeldKarte (optional)
•The processing of various contactless cards is possible in combination with the COR
contactless reader.
OPM-C60
•girocard, Maestro, V PAY
•Credit cards (e.g. Mastercard, VISA, American Express, Diners, JCB)
•Several customer chip cards; additional over card profiles
•GeldKarte (optional)
•The processing of various contactless cards is possible in combination with the COR
contactless reader
•In combination with the COR-B20 reader several contacted payment applications can
be used without PIN.
5.5 User Interface
The user of the OPP-C60 can get along easily with the terminals. The easy to use interface
and the textual information on the big graphic display will help with it. The OPM-C60 can be
comfortably administrated with the TS3 that can be downloaded for free.
The terminals can be used as unattended terminal (e.g. vending machine or petrol vending
machine) and as attended terminal preferably in rough environments (extended temperature
range, splash and vandalism).

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 10 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.6 Certifications
•ZKA TA7.1 as attended and unattended payment terminal
•EMV Level 1 and Level 2
•PCI-PTS 3.0 (with the SCR-B PCI 3.x)
•DC-POS 2.5 (also with DC-POS 2.4)
5.7 General technical information
5.7.1 Interfaces for vending machines and ECR
The ECR connection can be established via the LAN, MDB (optional in preparation) or RS232
interface.
•RS232 interface: Maximum transmission speed up to 115.200 Baud and Hardware-
Handshake are possible.
•LAN: Ethernet 10Base-T und 100Base-T, full duplex.
•MDB (Multi-Drop-Bus): 9600 Baud interface format for vending machines.
The serial protocol ZVT-ECR interface will mostly be used. The advantage of ZVT-ECR
interface that it is supported by almost all automated systems.
Die O.P.I. Interface is can also be used for vending and ticketing machines.
The OPP-C60 is ready to be used with the MDB interface.
The terminals have the special advantage, that the connection to a machine (e.g. vending
machine) can be used with different interface transmission speeds (19.200, 38.400, 115.200
Baud).
5.7.2 Keyboard OPP-C60s/m
The PIN pad of the OPP-C60s / m is equipped with a vandal
proof, high quality stainless steel keyboard with 20 keys, 4 of soft
keys (F1 - F4). The keys are equipped with tactile and audible
feedback by sound and embossing according to the specification
“EBS100V3 –October 2004” of ECBS.

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 11 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.7.3 Keyboard OPP-C60c
The PIN-Pad of the OPP-C60c is equipped with a vandal proof,
high-quality stainless steel keyboard with 16 keys. The keys are
equipped with tactile and audible feedback by sound and
embossing according to the specification „EBS100V3 – October
2004“ of ECBS .
5.7.4 Display
320*240 pixels, full graphics display with adjustable, high contrast and wide viewing angle. No
slowdown of the display at low temperatures.
OPP-C60s/m: 3,5“ TFT Color display, Active Size 72,7*54,3mm
OPP-C60c: 2,7“ TFT Color display, Active Size 58,3*43,9mm
5.7.5 Receipt Printer
The receipt will be printed by the machines printer (e.g. vending machine). It is controlled via
the machine control system.
The machine (e.g. vending machine) is getting all information from the OPP-C60 / OPM-C60
that is needed to print the receipt either as a complete receipt or asa data message containing
all relevant data to generate the receipt.
5.7.6 IP/IK-Codes
In the table below there are the IP and IK Codes for the OPP, OPM and the card readers. The
IP-Codes are separated in the front side and Rear side of the device. The IK-Codes for the
display is different to the keyboard. There for there are two different IK-Codes mentioned in
the table. The first is for the keyboard and the second is for the display.
Product
Front side
Rear side
OPP-C60 S/M/C
IP 65 / IK 10 / IK 8
IP 21
OPM-C60
IP 21
IP 21
SCR-B
IP 32 / IK 10
IP 21
SCR-C
IP 32 / IK 10
IP 32
SCR-C NB, NBS
IP 34 / IK 10
IP 32
COR-A10, -A12, -A20
IP 65 / IK 7
IP 20
COR-B20
IP 32 / IK 7
IP 20

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 12 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.7.7 OPP / OPM Status LED
There are two status LEDs at the rear side of the OPP / OPM, “PWR” (Power) and “STA”
(Status), which has the following meanings.
Status
PWR
heating off
(green, PWR)
PWR
heating on
(orange, PWR)
STA (rot, controllable)
Boot process
permanently on
permanently on
permanently on
Terminal ready, waiting for
login
permanently on
permanently on
2x slowly blinking, 2x fast
blinking
Terminal ready, login
successful
permanently on
permanently on
off
SecureLink/4eye to reader
not active
permanently on
permanently on
1x slowly, 1x fast
Startup lock
permanently on
permanently on
1x slowly, 2x fast
Initialization lock /
Diagnosis lock
permanently on
permanently on
1x slowly, 3x fast
Fraud
permanently on
permanently on
fast blinking
Not identified / other error
permanently on
permanently on
slowly blinking

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 13 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.7.8 Contacted reader SCR-C
The SCR-C, SCR-C NB (new bezel) and SCR-C NBS (new bezel with shutter) is a hybrid card
reader for all common card types.
The integration into tank machines, vending machines as well as further machines in
connection with the outdoor-terminal OPP-B50 are the ideal fields of use. The SCR-C has
three LEDs for the communication with the user.
Following the technical data and interfaces of the SCR-C are described.
Notice
The SCR-C must be grounded by a grounding wire (min. diameter 2.5 mm²) at one of the four
mounting screws
In case of power disconnection or a software crash, the card can be pulled out of the reader
against resistance.
5.7.8.1 Certificates
The certificates for pollution control and waste prevention are also listed below.
•ZKA TA 7.1 and DC POS 2.5
•leant to the EVA-CVS specifications for unattended terminals
•PCI 2.1 in connection with the OPP-B50 and PCI 3.1 with the OPP-C60 (expertise by
T-Systems)
•EFT-POS C-TAP conform
•PCI+ conform (Dutch domestic)
•eft/pos 2000 conform
•MasterCard TQM Label
•EMVL1 Type Approval
•EMVL2 Type Approval
•CE-Approval
•RoHS compliant
•WEEE
5.7.8.2 Connection
Connection to OPP-C60 / OPM-C60 Connector: RJ45 8-poles, shielded
Pin
Signal
1
power in
2
GND
3
TxD (output)
4
RxD (input)
5
Not connected
6
Not connected
7
Wakeup
8
GND

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 14 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.7.8.3 LED status indicators at SCR-C
Function
Terminal
type
Condition
LED Indicators
Startup SCR-C
All
No
All LED off
Fraud
All
No
Red LED interval blinking, 100ms on,
900ms off
4eye activation
needed
All
Card locked
Yellow LED interval blinking, 100ms on,
900ms off
Sleep Mode
All
No
All LED off

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 15 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.7.9 Contacless reader COR
COR contactless readers can be used with the OPP-C60 and the OPM-C60. A certification is
available for the combination OPP-C60 + COR-A10/12/20 and OPM-C60 + COR-A10/12/20 /
COR-B20. The OPP-C60 must not be used with COR-B20! The OPM-C60 does not require
a 4-eye-activation.
COR-A10/12
COR-A20
COR B20
(contactless only)
(as A10 plus Display)
(as A20 plus chip reader)
A cable with an infused ferrite can be found in the scope of supply. The following figure is
showing the cable from OPP-C60 / OPM-C60 to the COR reader (the ferrite is infused in the
cable part to the COR).
a) Description
SN
Designation
Name & Type
Qty
1
Connector
U.S. PLUG 8P8C, Molded Pantone
orange 165, Gold Plated 3U
1
2
Cabel
PU Jacket, 28AWG PP*4C, Black
Shiny
1
3
Connector
U.S. PLUG 8P8C, Molded Pantone
Yellow 107, Gold Plated 3U
1

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 16 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
b) Wire List
P1
Color
PIN OUT DETAILS
P2
1
White
V_IN-OUT
1
2
Black
GND
2
3
Red
<= RS232
3
4
Green
=> RS232
4
7
Blue
Wake UP
7
8
Blue
GND_IN-OUT
8
Note: All cables have to pass electrical test.
5.7.9.1 General information about the COR
The COR provides the following IP protection classes.
- COR-A10, -A12, -A20
ofront panel IP65
oback panel IP20
- COR-B20
oback panel IP20
ofront panel IP32
▪3 = foreign object size > 2.5mm diameter cannot entry
▪2 = water drops with 15° angle have no effects of damage
Further information for COR-B20
Water can entry to the backside of the COR reader (inside the vending machine) over the card
slot. The contacting unit of the COR is opened at the bottom side to let foreign objects fall out
or to let invaded water flow out (this is needed to prevent a blockade of the contacting unit).
There should be mounted a drain sheet inside the vending machine under the COR-B20 to
shield the electronics under the COR-B20.
The openings at the backside of the COR housing for connector plugs or flexible connectors
are mounted above the contacting unit.So there is no possibility for water drops to entry in this
area to the COR electronics over the card slot.
Only spray water or hose water could entry over some corners. Depending on the location
where the COR is used we recommend to provide a protection board to prevent the device
from soiling or spray water.

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 17 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
Information for the contacting unit of the COR-B20
- The contacting unit for the chip card is produced for 10 years in a large quantity. It is
sophisticated very solid and is also used for outdoor applications.
- All materials of the contacting unit are water resistant (i.e. synthetics, high-grade steel,
gold-plated contacts for contactingthe chip and gold-plated contactsat the limit switch).
- There can only be problems with frozen contacts. If the card is put in more times the
ice on the contacts will detach. For preventing the contacts of freezing we recommend
to use a heating inside of the vending machine.
5.7.9.2 Viewing angle of the COR display
Respecting the tolerances of the hardware components and the mounting tolerances the
following max. viewing angle for the COR can be given.
-max. viewing angle from top / bottom about 17° to the display normal
-max. viewing angle from left / right about 50° to the display normal
5.7.9.3 COR Interfaces
a) RS-232 Host Interface
High speed RS232 (default 115.2 kbps, switchable to 230.4, 460.8 or 921.6 kbps);
RJ45; 8 pin shielded) without hardware handshake.
The RJ45 Connector is located at the bottom side of the COR and the maximum cable
length is 100cm.
Pin
Signal
1
Vin (power supply)
2
GND
3
TxD (output)
4
RxD (input)
5
Not connected
6
Not connected
7
nWAKE (input/output)
8
Power GND
b) USB host interface
•USB 2.0 compatible, 12 MBps, USB function (slave)
•connector type: 5-pin Mini-B-Connector
•Power supply via RJ45 connector (VBUS not used for supply)
•Automatic wakeup, if VBUS is present

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 18 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
c) Interface selection
•If VBUS is active (5V): USB interface is selected
•VBUS is inactive (0V): RS232 interface is selected
•Only one interface is active at a time
Note that only the following product combinations are allowed:
Comb.
Type of use
Master
Card Reader
Ctls Card Reader
PCI-PTS 3.x
SRED
1
Full featured
Chip&PIN solution
with acceptance of
magstripe, chip and
contactless
OPP-C60
SCR-B
SCR-C
COR-A10 or
COR-A20
Yes
2
No-PIN solution for
low-value payments
OPM
SCR-B
SCR-C
SCR-C NB
SCR-C NBS
COR-A10 or
COR-A20
Yes
3
No-PIN solution for
low-value payments
without SRED
certification with
acceptance of chip
contact and
contactless.
OPM
-
COR-B20
No

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 19 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.7.9.4 Security of COR-B20
The product combination #3 is foreseen special for the low-value payment market in segments
parking, vending, ticketing. From a security point of view, the product COR-B20 + OPM is
fulfilling the PCI-PTS 3.1 SRED requirements on contactless side as well, as on contactless
side the card holder data have to be secured from the point of digitalization.
On the contact chip card reader, the COR-B20 is using all securitymechanisms as well. In this
context the COR-B20 is an non-encapsulated reader. From the point of digitalization all
requirements of SRED are fulfilled.
The following picture is explaining this.
•Clear-text PIN requirements are not applicable as the reader never is combined with
a PED.
•The security for card holder data is similar to the NFC, where this data are transferred
in plain text as well.
COR-B20
HSM
Application
OPM
HSM
NFC
Interface
ICC
Interface
Secure Link
contacted
contactless

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 20 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
5.7.10 4-eye Concept
OPP and reader must be coupled to a PCI compliant operation after installation in the machine
with the terminals, so that disassembly of the devices leads to a temporary decommissioning.
The devices have to be coupled again after the replacement (or exchange of the two devices).
For this, both devices include built-in mounting buttons that signalize if it is mounted or not.
Note: Please perform a 4-eye-activation at the OPP before executing the automatic startup.
The OPM-C60 does not require a 4-eye-activation.
5.7.11 Merchant SAM Slot
The OPP-C60 can use up to 2 Merchant SAM. For further information about the operating
speed see chapter "Technical data").
Please change the merchant SAM in the following steps:
1. Execute reconciliation with closure to transfer all GeldKarte transactions to the host
system.
2. Disconnect the device from the supply voltage.
3. Change the merchant SAM.
4. Reconnect the terminal to the power supply.
5.7.12 Communication
For online payment processing and service processes, the terminals are connected over an
integrated LAN interface. It is possible to connect an external ISDN modem or GSM/GPRS
communication module with the USB port.
The terminals support the following types of communication to the service provider:
•X.25 B-channel
•X.25 D-channel (X.31)
•X.75
•LAN
•Other Protocols on request
