CDA HN6411 Quick start guide

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : [e-mail] W : www.cda.eu www.cda.eu
IMPORTANT: PLEASE REFER TO PAGE 20 FOR
INFORMATION ON CONFIGURING THE POWER
CONSUMPTION MODE CORRECTLY.
THE HOB MUST BE CONFIGURED AT FIRST
SWITCH ON.
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : customer[email protected] W : www.cda.eu
HN6411
Induction Hob
Installation, Use and Maintenance

2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
2014/35/EU and Electromagnetic interference compatibility (EMC)

3
2014/30/EU. Parts intended to come into contact with food conform to
1935/2004/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
Please note:
•Induction hobs become hot and remain hot during and immediately
after use. Do not touch the hob until it has been allowed to cool.
•Keep children away from the appliance when in use.
•Never use the hob top for storage.
•Pan handles should never stand out beyond the edge of the
worktop. This will ensure children cannot reach them.
•Do not lean over the hob when it is in use.
•Follow the cleaning instructions carefully.
•Ensure the base of the saucepan is clean and dry before placing it
on the hob.
•Avoid hard shocks from cookware – the vitroceramic glass surface
is highly resistant but not unbreakable.

4
•Do not place hot lids flat on the hob top. A “suction” eect could
cause damage to the hob.
•Do not drag cookware across the hob top: in the long term, this
could cause damage to the hob.
•Do not store cleaning or flammable products in the unit below the
hob.
•Always use appropriate cookware.
•Do not cook unopened tins of food directly on the hob.
•Never put cooking foil or plastic materials on the ceramic surface
when the hob is hot. These materials could melt and cause
damage to the hob.
•This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use should be considered incorrect and
therefore dangerous.
FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:
The function of this hob conforms to current electromagnetic
interference standards and thus is in total compliance with legal
requirements (2004/108/CE directives).
To avoid interference between your hob and a pacemaker, your
pacemaker must be designed and programmed in compliance with
the regulations that apply to it. As such, CDA guarantee only that our
product is compliant.
With regard to the compliance of the pacemaker or any potential
incompatibility, you should obtain information from the manufacturer
or your attending physician.

5
Important
•Do not use the hob if the glass surface is cracked or damaged to
prevent the risk of electric shock. Disconnect it from the power
supply.
•Ensure that the power cables of connected electrical appliances
near the hob are not in contact with the cooking zones.
Important: Please refer to page 20 for information on configuring
the power consumption mode correctly. The hob must be
configured at first switch on.

6
Cooking on induction
The principle of induction cooking is based on magnetic eect.
When you put your cookware on an induction zone and switch it on,
the electronic boards in the hob produce induced currents in the base
of the cookware and instantly raise its temperature. This heat is then
transferred to the food inside the cookware.
The best cookware to use with induction cooking has thick flat bases,
as the heat will be better distributed so cooking more evenly.
Most cookware is compatible with induction cooking. There are three
ways to check the suitability of your cookware:
1. Use a magnet to see if the base of the pan is magnetic: if the
magnet sticks, then the cookware is compatible.
2.Place the pan on one of the cooking zones switched on to power
level 4: If the display remains on, then the cookware is
compatible. If the display flashes, the cookware cannot be used on
an induction hob.
3.Check the instructions or packaging of the pans for the symbols
indicating suitability for use with induction.

7
Control panel
The table below oers guidance as to what each power level is for.
Power level Type of cooking
0 Switched o
1/2 Melting (butter/chocolate) or keeping food warm
2/3 Keeping food hot or to heat small quantities of liquid
3/4 Heat larger quantities of liquid (sauces etc.)
4/5 Slow boiling, e.g spaghetti, soups, stews, potatoes
6/7 Gentle frying
7/8 Browning meats, frying fish, omelettes
9 Fast frying steaks
Fig.1
5
Control panel:
5. Power key
6. Timer keys
7. Safety key lock sensor
8. Zone power level keys
9. Zone displays
6 7 98
Zones:
1. Front left 1.5 kW (2.0kW boost) 210 mm
2. Back left 1.2 kW (1.6kW boost) 145 mm
3. Back right 1.5 kW (2.0kW boost) 210 mm
4. Front right 1.2 kW (1.6kW boost) 145 mm
2
1
3
4

8
Using your hob
To switch the hob on
To switch the power on, touch and hold the key for approximately
two seconds. The hob will beep and all four zone displays will show
zero.
Please note: If a power level is not set within ten seconds, the hob
will switch o automatically.
To set the power level
There are power keys for each individual zone which allow you to set
the power level by touching the “+” or “-” keys for the zone required.
To increase the power level from 1 (minimum) toward 9 (maximum),
touch the “+” key.
To go straight to power level 9, touch the “-” key when the zone
display shows “0”.
To turn the power o
To switch o a single zone, touch the “+” and “-” keys together for
the zone no longer required. This will set the power level to zero.
Alternatively, touch the “-” key until the zone display shows zero.
When all the zones are at zero, the hob will switch o automatically
after approximately ten seconds.
Alternatively, to switch o the hob immediately, touch and hold the
key for approximately two seconds.

9
Booster
The hob is equipped with a booster function, allowing a higher power
level than the maximum for approximately ten minutes. To turn on the
booster function, touch the “+” key when the power level is already
set at 9. “P” will show in the display. To cancel the booster at any
time, touch the “-” key to return to power level 9.
Timer
The hob is equipped with a timer that allows a finish time to be set for
the end of cooking on any zone, between a minimum of one minute
and a maximum of 99 minutes. This timer can be used only one zone
at a time.
To set the timer
First switch on the hob.
Touch either the timer “+” or “-” keys. The timer display will show “00”
and the zone displays will flash “t”.
Set the power level for the zone requiring the timer by touching
the “+” or “-” key for the required zone. The timer indicator LED will
illuminate on the zone to confirm the timer is selected.
Set the required duration using the timer “+” or “-” keys within five
seconds. Touching the timer “-” key will go straight to the maximum
99 minutes. Touch and hold the timer “+” or “-” keys to scroll through
the duration quickly.
After approximately five seconds, the LED and the timer display will
stop flashing and the countdown will start. The timer display will show
the minutes remaining until the last minute, when it will show the
seconds remaining.

10
At the end of the timer, the selected zone will switch o and the
timer display and the zone timer LED will flash. The hob will beep for
approximately one minute. To switch o the beep and the flashing
displays, touch any key.
To cancel the timer
Touch the timer “+” and “-” keys together.
Please note: Cancelling the timer will not switch o the zone. You
should switch the zone o manually if required.
Please note: the power level can be adjusted during the
countdown using the “+” or “-” keys.
Safety key lock
The hob is equipped with a safety key lock to lock the controls. This
can be used when the hob is o or during cooking.
To switch on the safety key lock
Touch the key for approximately two seconds until the LED above
the safety key lock sensor illuminates and the hob beeps to confirm
the safety key lock is switched on.
To turn o the childlock
Touch the key for approximately two seconds until the LED above
the safety key lock sensor switches o and the hob beeps to confirm
the safety key lock is switched o.

11
Use of the safety key lock when the hob is o
The safety key lock LED is illuminated to show the childlock is on.
Use of the safety key lock when the hob is in use
The safety key lock LED is illuminated to confirm that the lock is
switched on and no adjustments can be made to any of the zones or
the timer. It is possible to switch o the hob using the key when
the lock is on for safety reasons.
Please note:
The safety key lock is switched on automatically when the hob is first
connected to the power. You must switch o the lock to be able to
configure and use the hob.
Residual heat indicators
The hob is equipped with residual heat indicators to warn when any
of the zones are still hot to the touch after cooking. An “H” will show
in the relevant zone display after cooking until the zone is at a safe
temperature to touch.
In the event of a power cut, the residual heat indictors will illuminate
after the power supply is restored. However, when there is no power
supply to the hob the residual heat indicators will not work, so extra
care must be taken.
Please note:
You should avoid touching the zones when the hob is in use, or when
an “H” is showing on the zone display.

12
Small object safety
Anything left on the control panel (e.g. cutlery or towels) will cause
the hob to switch o automatically and there will be a beep every ten
seconds until the obstruction is removed.
Temperature limiter
The hob is equipped with a temperature limiting sensor that will switch
o the zone and show “C” alternating with the power level in the zone
display until the hob temperature is within the limits preset.
Pan detection
The hob is equipped with a sensor that will advise when the pan is
removed from the zone, or is unsuitable for use on induction hobs.
The zone display will show “U” alternating with the power level until
a suitable pan is placed on the zone. The zone will switch o after
approximately one minute if no suitable pan is placed on the zone.

13
Ecient Use of Your Hob
The hob is equipped with zones of dierent sizes, designed to
accommodate most shapes and sizes of pan. For best results,
only use pans with flat bottoms and choose an appropriate zone
depending on the size of the pan. The most ecient use of the hob is
shown below, where the pan and zone are correctly chosen.
Use pan lids where possible to minimize the energy usage of your
appliance.
It is very important that the pans used on the hob are made of a
suitable material and have the correct type of base. The base of the
pan must be clean before use to prevent any scratches on the hob
top.
Zone Size
160mm
180mm
210mm
Maximum Pan Size (cm)
18
22
24
Minimum Pan Size (cm)
10
12
18
Fig.2

14
Care and Maintenance
Always disconnect the appliance from the power supply before
undertaking any cleaning or maintenance.
Important:
•Steam cleaners must not be used when cleaning this appliance. •
You should use a non-abrasive cleaner to clean the hob top. Any
abrasive cleaner (including Cif) will scratch the surface and
could erase the control panel markings.
•Sugar and starch can cause permanent damage to the surface of the
hob. Wipe away any spillages immediatly.
If your hob is not working:
1. Check that the zone is switched on.
2. Check that the mains supply has not been switched o.
3. Check that the fuse in the spur has not blown.
4. Check the hob is configured correctly (see page 20).
Types of residues Clean with Cleaning advice
Light Cleaning sponge and soft
cloth
Wipe over the zone to be cleaned with a
sponge and hot water, and then wipe o with a
soft dry cloth.
Accumulated baked-on
stains/dirt, sugar spills or
melted plastics
Cleaning sponge or glass
scraper and soft cloth
Wipe over the zone to be cleaned with a
sponge and hot water, using a ceramic scraper
to remove any large marks or stains and then
wipe o with a soft dry cloth.
Rings and hard water
residues
White vinegar and soft
cloth
Pour a small amount of warm white vinegar
onto the stain, leave it to stand, and then wipe
o with a soft dry cloth.
Shiny metallic streaks
Cleaning agent for
vitroceramic glass
etc.) Slow boiling, e.g.
spaghetti, soups, stews,
potatoes
Use specialist vitroceramic glass cleaner
(preferably one with silicone for its protective
properties)

15
In the event of a fault with the hob, please advise CDA Customer Care
of any fault code shown on the display.
Contact CDA Customer Care
A : Customer Care Department, The CDA Group Ltd, Harby Road,
Langar, Nottinghamshire, NG13 9HY
T : 01949 862 012 F: 01949 862 003
E: customer[email protected] W: www.cda.eu
Troubleshooting
On first use
You observe that Possible Causes What should you do?
The display shows a series
of digits and symbols on first
connection
Working normally
Nothing, the hob will be ready
to use within approximately 10
seconds
Installation blows a fuse or
only one side of the hob works
The electrical connection of the
hob is incorrect
Check that it is set up properly
(see the Electrical Connection
section)
The hob produces an odour
during the first cooking sessions New appliance
Heat a saucepan full of water
on each cooking zone for 30
minutes
You observe that Possible Causes What should you do?
The hob does not work and the
lights on the control panel do not
switch on
The hob is not connected to
the power supply or the power
supply is faulty
Check the electrical circuit
breaker and fuses
The hob is not working and the
display shows a non-standard
graphic
The electronics are not
functioning correctly Call CDA Customer Care
The hob is not working and the
safety key lock LED is on The safety key lock is on Switch o the lock before trying to use the hob.
9 fast frying steaks
On switching on

16
IMPORTANT - PLEASE NOTE: In the event of any breakage, crack
or cracking – even minimal – of the vitroceramic glass, immediately
disconnect your appliance to prevent a risk of electric shock and
contact CDA Customer Care. Contact details can be found on page 15
of this manual.
In use
You observe that Possible Causes What should you do?
The hob has stopped operating.
The hob beeps at approximately
ten second intervals
There was an overflow or an
object is in contact with the
control panel
Clean the hob or remove the
object, and begin cooking again
C shows on the zone display The temperature limiter sensor
has been activated
Allow the zone time to cool
down.
U flashes on the zone display
The cookware used is not
suitable for induction or is less
than 12 cm in diameter (10 cm on
the 16 cm zone)
See page 6 for information on
cooking on induction
The saucepans make noise
during cooking or your hob
makes a clicking sound during
cooking
This is normal with some types of
cookware. This is caused by the
transfer of energy from the hob
to the cookware
Nothing. There is no risk,
neither to your hob nor to your
cookware
The fan continues to function for
a few minutes after the hob is
turned o
Cooling of the electronic
components.
Working normally
Nothing.
The hob keeps blowing the mains
fuse
This is most likely to be
caused by an incorrect power
configuration setting
Refer to the instructions on
configuring your hob (page 20)

17
Fitting the Hob
Unpacking the hob:
Take care not to lose or mishandle any parts.
Fitting position of the hob:
This appliance must be installed a minimum of 50mm from any
back wall and a minimum of 180mm away from any adjacent vertical
surfaces, e.g. a tall cupboard end panel. This may be reduced to
100mm if the adjacent surface is resistant to fire (tiles or steel, for
example). These dimensions are shown in Fig. 5.
Ventilation requirements:
This appliance must be installed to allow air to flow freely to the air
intake, from the air outlet and in the base and run of units into which
it is installed (Fig 3). Failure to allow sucient ventilation could cause
damage to the hob and constitutes incorrect installation, which is not
covered by the warranty.
Notes:
•This could be a simple slot cut out of the plinth, or a dedicated
ventilation grille.
•The furniture top rail should not be fitted to the unit. This allows the
induction hob to exhaust air into the kitchen space.
•The recommended ventilation sizes are for guidance only.
If fitting a cooker hood above the hob:
If a cooker hood is to be installed above the hob, the height of
the hood above the hob must be at least 600mm (650mm is

18
recommended) (Fig. 4). If the instructions supplied with the hood
dictate that the hood must be installed at a height greater than
600mm, then that height is the minimum required.
Wall furniture requirements:
The minimum height of any cabinet immediately above the hob is
900mm. The minimum height of any adjacent units (including light
pelmets) is 400mm, unless they are manufactured from a material
resistant to fire (steel, for example).
Notes:
•Do not position this appliance above a refrigeration unit. The heat
generated may cause the refrigeration unit to fail.
•This appliance is designed to be installed into cabinet units capable
of withstanding temperatures of 65°C or greater above ambient
temperature.
•Never place perishable foods, soft items such as tea towels,
cleaning products or flammable items in the cupboard or drawer
below the appliance.
•If an oven is to be installed below the hob, the thermal safety system
on the hob will not allow the hob to be used at the same time as a
pyrolytic programme on the oven.
•The hob is equipped with an anti-overheating safety device that
can be activated if the hob is installed over an oven that is not
suciently ventilated. In the event that this occurs, the zone display
will show “C”. We recommend that you increase the ventilation of
the hob by creating an opening in the side of the cabinet (8cm x
5cm).

19
How to Install the Hob
Overall dimensions of the hob:
Width: 580 mm Depth: 510 mm
Worktop cut-out dimensions:
Width: 560 mm Depth: 490 mm
1. Make the required hole in the
worktop. Before doing this, you must
check the instructions supplied with
any cooker hood to ensure that you
will have the required clearance. The
cut-out (Fig. 5) shows a 60mm gap
from the wall to the cut-out edge.
The distance from the hob, when
fitted, to the back wall is 50mm.
If a splashback/worktop upstand is
to be fitted, take this into account
when cutting the hole. The minimum
distance that the hob should be
positioned away from the rear wall or
splashback is 50mm.
2.Fix the foam seal underneath the
appliance by following the outline of
the worktop upon which the hob will
rest. This ensures an airtight seal with
the worktop. Do not use silicone type
sealant.
Fig.3
Fig.4
400mm
600mm
600mm minimum
(650mm recommended)
Ho b
Top rail removed to allow air to exit.
Recommended 560mm x 6mm
Air intake into the run of units.
Recommended 560mm x 10mm
A ventilation slot may need to be cut
into the base if there is no ventilation
provided.
Recommended 560mm x 25mm
65mm
470mm
550mm
150mm150mm
60mm
490mm
560mm
190mm190mm
Fig.5

20
Power Configuration
This hob can be connected to a 13, 16, 25 or 32Amp supply and
configured to work on any of these power settings.
If the hob is connected to a 32Amp supply all four zones can be used
on the maximum setting with boost at the same time. If, however,
the hob is connected and configured to a 13Amp supply and all four
zones are selected at the same time the hob will limit the maximum
power consumed so that the 2.8kW power supply cannot be
exceeded.
To configure the hob at first switch on
1. Switch on the power supply.
2. All the displays will show “8” briefly then just the safety key lock
symbol will show.
3. Touch the key to switch o the lock.
4. Touch the “+” and “-” keys for the front left zone and the “+” and “-”
keys for the front right zone, all simultaneously.
5. Touch the front left zone “-” key to cycle through the options.
The displays will show:
6. Touch the “+” and “-” keys for the front left zone and the “+” and
“-” keys for the front right zone, all simultaneously, to confirm the
setting.
Front left zone display Timer display Front right zone
display
Power Settings
2 PO 8 2.8 kW
3 PO 5 3.5 kW
6 PO 0 6.0 kW
7 PO 2 7.2 kW
