Cecomp F16AD User manual

Cecomp®Low-Voltage Powered Digital Pressure Gauges with Selectable Units F16AD, F16ADN
cecomp.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
© 02-12
Ranges and Resolution
See table below. Select range and default engineering units.
Consult factory for special engineering units.
Units may be changed to any listed under the same sensor range.
Resolution is fixed and limited to available display digits.
Accuracy
Includes linearity, hysteresis, repeatability
Standard: ±0.25% of full scale ±1 least significant digit
HA option: ±0.1% FS ±1 LSD, see table below for availability
Display
3 readings per second nominal display update rate
4 digit LCD, 0.5" H and 5 character 0.25" H alphanumeric
BL: Red LED backlight on when gauge is on
Power
8-24 VAC 50/60 Hz or 9-32 VDC
AD: Approximately 5 mA
ADBL: Approximately 80 mA
3 ft long, 2-conductor 22 AWG cable
All models are designed for continuous operation
Order optional WMPSK 115V/12 VDC wall mount power supply kit.
Controls and Functions
Front button turns gauge on or off, zeros gauge reference gauges,
and cycles through min/max functions
Internal buttons for engineering unit selection, auto shutoff time,
min/max setup, calibration. Pass code protected setup & calibration.
Min/Max Functions
Minimum and maximum readings stored 3 times per second
Front button cycles through min display, max display, clear
Configurable for min only, max only, min/max, or none
Configure to clear or retain min/max values at power off
±0.25% Test Gauge Accuracy
316 Stainless Steel Wetted Parts
Minimum, Maximum, Zero Functions
Selectable Units
Low Voltage Powered
BSOLUTE ROCESS NSTRUMENTS, Inc.
Division of
Calibration
Pass code protected calibration
Non-interactive zero, span, and linearity, ±10% of range
Weight
Gauge: 9 ounces (approximately)
Shipping: 1 pound (approximately)
Housing
F16AD: Extruded aluminum case, epoxy powder coated, ABS/
polycarbonate bezel (aluminum bezel optional), front and rear
gaskets, polycarbonate label
F16ADN: ABS/polycarbonate NEMA 4X case, rear gasket, polycar-
bonate label
Connection and Material
1/4" NPT male fitting, 316L stainless steel
All wetted parts are 316L stainless steel
Overpressure, Burst, Vacuum
Ranges using 3000 psig sensor: 5000 psig
Ranges using 5000 psig sensor: 7500 psig
All others: 2 X pressure range
3000 psi, 5000 psi, and 4 digit ranges 112.5% full scale out-of-
range display: 1– – – or I –.–.–.–
4 X sensor burst pressure rating, or 10,000 psi, whichever is less
Vacuum service: ±15 psig, 15 psig, 30 psia, 100 psig, 100 psia,
200 psig sensors.
Under-range display (non-vacuum sensors): –Err
Environmental
Storage temperature: –40 to 203°F (–40 to 95°C)
Operating temperature: –4 to 185°F (–20 to 85°C)
Compensated temperature: 32 to 158°F (0 to 70°C)
F16AD Quick Link
cecomp.com/ad
Made
in
USA
★★★★★★
★★★★★
★★★★★★
★★★★★
★★★★★★
★★★★★
★★★★★★
★★★★★
★★★★★★
How to Specify Type
F16AD range - options Standard housing
F16ADBL range - options Standard housing,
backlit display
F16ADN range - options NEMA 4X housing
F16ADNBL range - options NEMA 4X housing,
backlit display
Example: F16ADBL100PSIG-HA
Low voltage powered, backlit display, 0-100 psig, high
accuracy
Sensor Ranges and Engineering Units ‡ -HA option not available
3 psig ‡Res 15 psig vac ‡Res 30 psia ‡Res –15V100psig ‡Res 300 psig Res
3PSIG .001 100KPAVAC .1 2KGCMA .001 –15V100PSIG .1 300PSIG .1
6INHGG .001 0.1MPAVAC .0001 2ATMA .001 –30INHG/100PSIG .1 610INHGG .1
85INH2OG .1 1BARVAC .001 30 psig Res –30V200INHGG .1 4800ZING 1
50ZING .01 1KGCMVAC .01 30PSIG .01 –400V2770INH2OG 1700FTH2O .1
210GCMG .1 1ATMVAC .001 60INHGG .01 –240V1600ZING 12000KPAG 1
150MMHGG .1 15 psig Res 850INH2OG 1–760V5200MMHGG 12MPAG .001
150TORRG .1 15PSIG .01 480ZING .1 –760V5200TORRG 120BARG .01
200MBARG .1 30INHGG .01 2100GCMG 1–100V700KPAG 120KGCMG .01
200CMH2OG .1 400INH2OG .1 1600MMHGG 1–0.1V0.7MPAG .001 20ATMG .01
2000MMH2OG 1240ZING .1 1600TORRG 1–1V7BARG .01 500 psig Res
7FTH2O .001 1000GCMG 12000MBARG 1–1V7KGCMG .01 500PSIG .1
20KPAG .01 760MMHGG .1 2100CMH2OG 1–1V7ATMG .01 1020INHGG 1
5 psig Res 760TORRG .1 70FTH2O .01 100 psig Res 1150FTH2O 1
5PSIG .001 1000MBARG 1200KPAG .1 100PSIG .1 3500KPAG 1
10INHGG .01 1000CMH2OG 10.2MPAG .0001 200INHGG .1 3.5MPAG .001
140INH2OG .1 35FTH2O .01 2BARG .001 2770INH2OG 135BARG .01
80ZING .1 100KPAG .1 2KGCMG .001 1600ZING 135KGCMG .01
350GCMG .1 0.1MPAG .0001 2ATMG .001 7000GCMG 135ATMG .01
260MMHGG .1 1BARG 160 psig Res 5200MMHGG 11000 psig Res
260TORRG .1 1KGCMG 160PSIG .01 5200TORRG 11000PSIG 1
350MBARG .1 1ATMG 1120INHGG .1 7000MBARG 12040INHGG 1
350CMH2OG .1 ±15 psig ‡Res 1660INH2OG 17000CMH2OG 12300FTH2O 1
3500MMH2OG 1±15PSIG .01 960ZING 1230FTH2O .1 7000KPAG 1
12FTH2O .01 –30INHG/15PSIG .01 4200GCMG 1700KPAG .1 7MPAG .0001
35KPAG .01 ±30INHGG .01 3100MMHGG 10.7MPAG .0001 70BARG .01
15 psia ‡Res ±400INH2OG 13100TORRG 17BARG .001 70KGCMG .01
15PSIA .01 ±240ZING .1 4100MBARG 17KGCMG .001 70ATMG .01
30INHGA .01 ±1000GCMG 14200CMH2OG 17ATMG .001 2000 psig Res
400INH2OA .1 ±760MMHGG 1140FTH2O .1 –15V200 psig ‡Res 2000PSIG 1
240ZINA .1 ±760TORRG 1400KPAG .1 –15V200PSIG .1 4070INHGG 1
1000GCMA 1±1000MBAR 10.4MPAG .0001 –30INHG/200PSIG .1 4600FTH2O 1
760MMHGA .1 ±1000CMH2OG 14BARG .001 –30V400INHGG .1 14MPAG .01
760TORRA .1 ±100KPAG .1 4KGCMG .001 –400V5500INH2OG 1140BARG .1
1000MBARA 1±0.1MPAG .0001 4ATMG .001 –240V3200ZING 1140KGCMG .1
1000CMH2OA 1±1BARG .001 100 psia ‡Res –100V1400KPAG 1140ATMG .1
100KPAA .1 ±1KGCMG .001 100PSIA .1 –0.1V1.4MPAG .001 3000 psig Res
0.1MPAA .0001 ±1ATMG .001 200INHGA .1 –1V14BARG .01 3000PSIG 1
1BARA .001 30 psia ‡Res 2770INH2OA 1–1V14KGCMG .01 6100INHGG 1
1KGCMA .001 30PSIA .01 1600ZINA 1–1V 14ATMG .01 6900FTH2O 1
1ATMA .001 60INHGA .01 7000GCMA 1200 psig Res 20MPAG .01
15 psig vac ‡Res 850INH2OA 15200MMHGA 1200PSIG .1 200BARG .1
15PSIVAC .01 480ZINA .1 5200TORRA 1400INHGG .1 200KGCMG .1
30INHGVAC .01 2100GCMA 17000MBARA 15500INH2OG 1200ATMG .1
400INH2OVAC .1 1600MMHGA 17000CMH2OA 13200ZING 15000 psig Res
240ZINVAC .1 1600TORRA 1700KPAA .1 480FTH2O .1 5000PSIG 1
1000GCMVAC 12000MBARA 10.7MPAA .0001 1400KPAG 135MPAG .01
760MMHGVAC .1 2100CMH2OA 17BARA .001 1.4MPAG .001 350BARG .1
760TORRVAC .1 200KPAA .1 7KGCMA .001 14BARG .01 350KGCMG .1
1000MBARVAC 10.2MPAA .0001 7ATMA .001 14KGCMG .01 340ATMG .1
1000CMH2OVAC 12BARA .001 14ATMG .01
Options—add to end of model number
HA
High accuracy, ±0.1% FS ±1 LSD. Not available with 3
psi, bipolar, absolute, or vacuum sensors, and some 3.5
digit display ranges. See table at left for availability.
PM Panel mount, 4.1" x 4.1". Not avail. with NEMA models.
MC Metal front cover. Not available with NEMA models.
CC Moisture resistant circuit board conformal coating
TP Top gauge port. Not available with NEMA models.
Accessories—order separately
WMPSK Wall mount power supply kit, 115 VAC/12 VDC
RB Protective rubber boot. Not avail. with NEMA models.
CD Calibration data; 5 test points and date
NC NIST traceability documentation, 5 points and date
F16ADN
psi = PSI
inHg = INHG
oz/in2= ZIN
inH2O = INH2O
ftH2O = FTH2O
mmHg = MMHG
torr = TORR
mmH2O = MMH2O
kg/cm2= KGCM
g/cm2= GCM
kPa = KPA
MPa = MPA
mbar = MBAR
bar = BAR
cmH2O = CMH2O
atm = ATM
G = gauge reference pressure
VAC = gauge reference vacuum
A = absolute reference
If vacuum gauge requires a minus sign, please specify.
The range code indicates the gauge’s default range. Engineering
units may be changed to any of those listed under the same sensor
range. The listed ranges are rounded off.
Range—see table at left
MOD-TRONIC Instruments ·Brampton, ON · 905-457-6322 or 1-800-794-5883 ·[e-mail] · www.mod-tronic.com

cecomp.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
Instructions F16AD, F16ADN
BSOLUTE ROCESS NSTRUMENTS, Inc.
Division of
Read these instructions before using the gauge. Configuration
may be easier before installation. Contact the factory for assis-
tance.
These products do not contain user-serviceable parts. Contact
us for repairs, service, or refurbishment.
Gauges must be operated within specified ambient temperature
ranges.
Outdoor or wash down applications require a NEMA 4X gauge or
installation in a NEMA 4X housing.
Use a pressure or vacuum range appropriate for the application.
Use fittings appropriate for the pressure range of the gauge.
Due to the hardness of 316 stainless steel, it is recommended
that a thread sealant be used to ensure leak-free operation.
For contaminated media use an appropriate screen or filter to
keep debris out of gauge port.
Remove system pressures before removing or installing gauge.
Install or remove gauge using a wrench on the hex fitting only.
Do not attempt to turn gauge by forcing the housing.
Good design practice dictates that positive displacement liquid
pumps include protection devices to prevent sensor damage
from pressure spikes, acceleration head, and vacuum extremes.
 Avoid permanent sensor damage! Do not apply vacuum to non-
vacuum gauges or hydraulic vacuum to any gauges.
 Avoid permanent sensor damage! NEVER insert objects into
gauge port or blow out with compressed air.
Gauges are not for oxygen service. Accidental rupture of sensor
diaphragm may cause silicone oil inside sensor to react with
oxygen.
Bipolar ranges read positive pressure and vacuum in the same
units, and zero with the gauge port open.
1000 psi and higher sensor are a sealed reference type. They read
zero with the gauge port open are internally referenced to 14.7 psi.
Functionally similar to gauge reference sensors.
Absolute reference gauges read zero at full vacuum and atmo-
spheric pressure with the gauge port open. With an open gauge
port the readings will vary continuously due to the effects of
barometric pressure.
Range Codes
The range code is part of the gauge model number and indicates
the default range when the gauge is ordered.
Selectable Ranges
Engineering units may be changed to any of those listed in the same
sensor range as shown in the range table.
Conversion
Engineering units are calculated from the factory default unit to the
newly selected units. The ranges listed under the psi sensor range
are rounded off.
The AD series is powered by 8-24 VAC 50/60 Hz or 9-32 VDC.
The type and magnitude of the supply voltage have negligible
effects on the gauge calibration as long as it is within the voltage
ranges stated above. No polarity needs to be observed when con-
necting a power supply. An inexpensive unregulated low voltage AC
or DC power supply can be used.
After the gauge is installed, route the wires away from heat sources
and moving equipment and connect the low-voltage power source
to the gauge wires.
Ensure that the gauge supply voltage does not fall below 8 VACRMS
if AC power is used, or 9 VDC if DC power is used. Operation with
less than these values may cause erratic or erroneous readings.
When operating multiple gauges from the same power supply, refer
to the mA rating in the specifications to ensure adequate power.
Note that standard 24 VAC transformers with small loads often
operate at voltages well over the gauge's 24 VAC limit.
Power-Up
Press and hold the front button for approximately 1 second.
The display is tested, the default full-scale range is indicated, the
full-scale range in the selected units are indicated, the display is
tested again, then the actual pressure and units are displayed.
Power-Up With Zero
This applies to gauge reference models only. Absolute reference
gauges do not use the zero feature since they read atmospheric
pressure under normal conditions.
Be sure the gauge port is exposed to normal atmospheric pressure
and no pressure is applied. The zeroing function is only activated
at each power-up and the stored zero correction is erased when
the gauge is shut off.
Press and hold the front button. The display is tested and then oooo
is displayed. The gauge is now zeroed. Release the button and the
full-scale range in the selected units are indicated, the display is
tested again, then the actual pressure and units are displayed.
Attempting to zero the gauge with pressure greater than approxi-
mately 3% of full-scale pressure or vacuum applied will result in an
error condition, and the display will alternately indicate Err 0 and
the actual measured pressure. The gauge must be powered down
to reset the error condition.
Normal Operation
Following the start-up initialization, the display indicates the pres-
sure reading updated approximately 3 times per second. The gauge
may be left on continuously or shut off as desired.
If excessive vacuum is applied to a pressure-only gauge, the display
will indicate -Err until the vacuum is released.
Applying vacuum to a gauge designed for pressure may damage
the pressure sensor. If excessive pressure is applied (112.5% over
range), an out-of-range indication of 1 – – – or 1.–.–.– will be
displayed depending on model.
Display Backlighting (BL models only)
Display backlighting is on whenever the gauge is on.
The display backlighting will not be apparent under bright lighting
conditions.
Minimum and Maximum Readings
Gauges are normally configured with minimum and maximum
capture functions enabled. One or both can be disabled in the User
Configuration mode.
Minimum and maximum readings are continuously stored and
updated whenever the gauge is on. The stored readings can be
manually cleared if desired. The MAX and MIN memory is also
cleared whenever the gauge is off unless configured to save the
readings.
Press and hold the button for about 1 second until MAX is displayed
alternating with the units. The maximum reading will be continu-
ously updated. The gauge may be left in this mode.
After MAX is displayed, press and hold the button for about 1 sec-
ond until MIN is displayed alternating with the units. The minimum
reading will be continuously updated. The gauge may be left in this
mode. If excessive vacuum is applied to a pressure-only gauge
while in this mode, the display will indicate -Err until the MAX/MIN
readings are cleared.
After MIN is displayed, press and hold the button again for about 1
second until * * * * is displayed. The MAX and MIN memory is not
erased and the gauge returns to normal operation with the display
indicating the current reading.
Press and continue to hold the button until the display indicates clr
MX/MN (about 3 seconds total) and then release the button. Both
maximum and minimum values are cleared and the gauge returns
to the normal mode and displays the current pressure.
Shut-Down
To shut off the gauge manually at any time, press and hold the button
until the display indicates OFF (about 5 seconds) and then release.
Operation—continued
Types of Gauges
Installation Precautions
Dimensions
Operation
Cecomp maintains a constant effort to upgrade and improve its products.
Specifications are subject to change without notice. Consult factory for your
specific requirements.
Selectable Ranges
¼" NPT
2.88"
3.38" Standard
3.5" NEMA 4X
0.75"
2.0"
Cecomp Electronics / Made in USA
1.65"
NEMA 4X
3.0"
Standard
Turn at hex
fitting only
XXXXX
8
8
8
8
82
Low voltage
indicator
3 ft long 2
conductor 22
AWG cable with
stripped and
tinned wire
ends
Turn at hex
fitting only
Function Button Prompt (Release Button)
On Press for 1
second
Display test > default units > selected
units FUll scale > display test >
actual reading
Zero
(gauge ref.
only)
Press and
hold
Display test >
oooo > default units >
selected units FUll scale >
display test > actual reading
Hi reading Press/hold Max > max. reading & units
Lo reading Press/hold MIN > min. reading & units
Exit Hi/Lo Press/hold
 > actual reading
Clear Hi/Lo Press/hold Max > Clr mx/mn > actual reading
Clear, off Press/hold Max > Clr mx/mn > OFF
Power
MOD-TRONIC Instruments ·Brampton, ON · 905-457-6322 or 1-800-794-5883 ·[e-mail] · www.mod-tronic.com

Instructions F16AD, F16ADN
cecomp.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
BSOLUTE ROCESS NSTRUMENTS, Inc.
Division of
User configuration allows requires a pass code for access and
allows more features to be configured.
Remove the rear cover to gain access to the buttons located near
the lower right and left corners of the circuit board.
With the gauge off, press and hold the UP button. Then press the
front button. Release all buttons when the display indicates CFG
and the program version then the full-scale range is indicated and
the display is tested.
The display then indicates _ _ _ _ with the first underscore blink-
ing, and with CFGPC (configuration pass code) on the character
segments.
Note: The gauge will automatically revert to normal operation if
no buttons are operated for approximately 15 seconds. To cancel
and return to normal operation, press and release the front button
without entering any pass code characters.
Pass Code Entry
The factory default is 3510, but this may be changed by the user
under the Pass Code Configuration section.
1. Use the UP or DOWN buttons to set the left-most digit to 3.
2. Press and release the front button to move to the next position.
The 3 will remain, and the second position will be blinking.
3. Use the UP or DOWN buttons to select 5.
4. Press and release the front button to index to the next position.
35 will remain, and the third position will be blinking.
5. Use the UP or DOWN buttons to select 1.
6. Press and release the front button to index to the next position.
351 will remain, and the fourth position will be blinking.
7. Use the UP or DOWN buttons to select 0.
8. Press and release the front button to proceed with configuration
procedures.
If an incorrect pass code is entered, the gauge will return to the
start of the pass code entry sequence.
Factory/User Configuration
The upper display section will be blank, and the lower section will
display either USER_ or FCTRY.
If USER_ is selected, the user configuration can be modified as
described in the following steps.
To select USER_, press and release the DOWN button.
The lower display will indicate USER_.
Press and release the front button to continue.
If FCTRY is selected, the existing user configuration will be replaced
by the original factory configuration.
To select FCTRY, press and release the UP button.
The lower display will indicate FCTRY.
Press and release the front button to restore the factory configura-
tion and restart the gauge.
Max/Min Configuration
Use the UP and DOWN buttons to select from the following:
MX/MN Both highest and lowest values will be captured
MX/--- Only highest value will be captured
--/MN Only lowest value will be captured
--/-- Capture feature is disabled
Press and release the front button to move to the next parameter.
Max/Min Memory
The upper display section will indicate clr.
Use the UP and DOWN buttons to select from the following:
AUTO Automatically clear max. and min. values when the
gauge is powered off
MAN Manually clear max. and min. values
Press and release the front button to move to the next parameter.
Gauge Type Configuration
This will only appear with 15, 100, or 200 psig ranges that were
originally ordered as compound gauges.
Use the UP and DOWN buttons to select from the following:
-/+EU Vacuum is indicated as negative pressure in the
selected engineering units
CMPND Vacuum is negative INHG, pressure is PSIG. This setting
will disable engineering unit selection.
Press and release the front button to save the user configuration
and restart the gauge.
Replace the rear cover taking care not to pinch the power wires
between the cover and the case.
Advanced ConfigurationBasic Configuration
Engineering Unit Selection
Engineering unit selection is done via internal buttons to help pre-
vent accidental or unauthorized changes. The selected engineering
unit is stored in non-volatile memory and will be retained even with
the gauge off or batteries removed. The available engineering units
depend on the sensor range and display resolution.
Compound (inHg/PSIG) gauges must be changed to display single-
unit vacuum/pressure readings in the Advanced Configuration mode
before different engineering units can be selected.
The default engineering units are mathematically converted to the
newly selected engineering unit. When the gauge is powered up,
the originally configured range is displayed and then the conversion
with the selected engineering unit is displayed.
To change engineering units remove the rear cover to gain access
to the two internal buttons located near the lower right and left
corners of the circuit board.
With the gauge powered up, press and hold the UP button. Release
the button when the engineering units begin to flash.
Use the UP and DOWN buttons to scroll through the list of engineer-
ing units available for the pressure range of the sensor.
When the desired units are displayed, press and release the front
button to save the selection and return to normal operation.
Note: The gauge will automatically revert to normal operation if no
buttons are operated for approximately 15 seconds.
Replace the rear cover taking care not to pinch the power wires
between the cover and the case.
All gauges are factory calibrated using NIST traceable calibration
equipment. Calibration is not required before using the gauge.
Calibration intervals depend on your quality standards, but annual
re-calibration is customary.
Calibration equipment is not required to zero gauge reference
ranges. Absolute reference ranges may be zeroed with application
of full vacuum.
Span calibration should only be performed using appropriate cali-
bration procedures with calibration standards that are at least four
times more accurate than the gauge being calibrated.
The calibration system must be able to generate and measure pres-
sure/vacuum over the full range of the gauge. A vacuum pump able
to produce a vacuum of 100 microns (0.1 torr or 100 millitorr) or
lower is required for vacuum and absolute gauges.
Connect gauge to a 8-24 VAC 50/60 Hz or 9-32 VDC power supply.
Allow the gauge to equalize to normal room temperature for
approximately 20 minutes before calibration.
Remove the rear cover to gain access to the UP and DOWN buttons
located near the lower right and left corners of the circuit board.
Continued on next page...
Calibration Preparation
MOD-TRONIC Instruments ·Brampton, ON · 905-457-6322 or 1-800-794-5883 ·[e-mail] · www.mod-tronic.com

cecomp.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
BSOLUTE ROCESS NSTRUMENTS, Inc.
Division of
Instructions F16AD, F16ADN
Entering Calibration Mode
With the gauge off, press and hold the DOWN button. Then press
the front button. Release all buttons when the display indicates CAL.
The display begins by indicating the full-scale positive pressure
rating of the gauge in the engineering units as configured by the
factory, and then shows all display.
Before the gauge enters the Calibration Mode, the display initially
indicates _ _ _ _ with the first underscore blinking, and with CALPC
(calibration pass code) on the lower display.
Note: The gauge will automatically revert to normal operation if
no buttons are operated for approximately 15 seconds. To cancel
and return to normal operation, press and release the front button
without entering any pass code characters.
Enter the User-Modifiable Pass Code
The factory default is 3510, but this is user changeable.
1. Use the UP or DOWN buttons to set the left-most digit to 3.
2. Press and release the front button to move to the next position.
The 3 will remain, and the second position will be blinking.
3. Use the UP or DOWN buttons to select 5.
4. Press and release the front button to index to the next position.
35 will remain, and the third position will be blinking.
5. Use the UP or DOWN buttons to select 1.
6. Press and release the front button to index to the next position.
351 will remain, and the fourth position will be blinking.
7. Use the UP or DOWN buttons to select 0.
8. Press and release the front button to proceed with configuration
procedures.
If an incorrect pass code is entered, the gauge will return to the
start of the pass code entry sequence.
Calibration Mode
The gauge enters and remains in the calibration mode until
restarted manually or power is removed. Features not related to
calibration are disabled and compound range models are set for the
same engineering units for pressure and for vacuum.
The calibration may be performed in any of the available engineer-
ing units as well as percent (PCT). For greatest accuracy, use the UP
and DOWN buttons to select engineering units for calibration with
highest resolution (highest number of display counts). Press and
release the front button when the appropriate engineering units are
displayed. Suggested units are listed below.
Sensor Suggested units for calibration
5 PSI 5.000 PSI
15 PSI 775.7 MMHG (TORR)
30 PSI 61.08 INHG
50 PSI 50.00 PSI
60 PSI 60.00 PSI
100 PSI 7.031 KG/CM2
200 PSI 407.2 INHG
300 PSI 610.8 INHG
500 PSI 500.0 PSI
1000 PSI 70.31 KG/CM2
2000 PSI 4072 INHG
3000 PSI 6108 INHG
5000 PSI 5000 PSI
Any 100.00 PCT (percent)
The display will then indicate the currently applied pressure in the
engineering units selected for calibration.
UP and DOWN Button Operation
Each time one of the calibration buttons is pressed and released
quickly, a small change is made to the digitized pressure signal. It
may take more than one of these small changes to result in a single
digit change on the display.
To make larger changes, press and hold the appropriate calibration
button. After about one second, the display will begin to change
continuously. Release the button to stop. Then make fine adjust-
ments by pressing and quickly releasing the calibration buttons as
previously described.
Gauge Reference Pressure Gauges
Apply zero pressure by venting the gauge port to atmosphere. The
character display will alternate between ZERO and CAL. Adjust for
a display indication of zero using the UP and the DOWN buttons.
Apply full-scale pressure. The character display will alternate
between +SPAN and CAL. Adjust for a display indication of full-
scale pressure using the UP and the DOWN buttons.
Apply 50% full-scale pressure. The character display will alternate
between +MID and CAL. Adjust for a display indication equal to
50% of full-scale pressure using the UP and the DOWN buttons.
Gauge Reference Vacuum Gauges
Apply zero pressure by venting the gauge port to atmosphere. The
character display will alternate between ZERO and CAL. Adjust for
a display indication of zero using the UP and the DOWN buttons.
Apply full-scale vacuum. The character display will alternate
between +SPAN and CAL. Adjust for a display indication of full-
scale vacuum using the UP and the DOWN buttons.
Apply 50% full-scale vacuum. The character display will alternate
between +MID and CAL. Adjust for a display indication equal to
50% of full-scale vacuum using the UP and the DOWN buttons.
Absolute Reference Gauges
Apply full vacuum to the gauge. The character display will alternate
between ZERO and CAL. Press the UP and DOWN buttons to obtain
a display indication of zero.
Apply full-scale pressure. The character display will alternate
between +SPAN and CAL. Press the UP and DOWN buttons to obtain
a display indication equal to full-scale pressure.
Apply 50% of full-scale pressure. The lower display will alternate
between +MID and CAL. Press the UP and DOWN buttons to obtain
an indication equal to 50% of full-scale pressure.
Compound and Bipolar Gauges
In addition to the steps described above for pressure gauges, apply
full-scale vacuum. The character display will alternate between
-SPAN and CAL. Adjust for a display indication of actual applied
vacuum using the UP and the DOWN buttons.
For bipolar and –30.00inHg/+15.00psig compound range models
only, apply 50% full-scale vacuum. The character display will alter-
nate between -MID and CAL. Adjust for a display indication equal
to 50% of full-scale vacuum using the UP and the DOWN buttons.
Save Calibration
Once the adjustments are complete, press and hold the front button
until the display indicates - - - - then release the button to store
the calibration parameters in non-volatile memory and restart the
gauge.
Verify the pressure indications at 0%, 25%, 50%, 75% and 100%
of full scale.
Replace the rear cover taking care not to pinch the wires between
the cover and the case.
Remove the rear cover to access the buttons located near the lower
right and left corners of the circuit board.
View or change user configuration pass code
With the unit off, press and hold the UP button, then press the
front button.
Release all buttons when the display indicates CFG.
View or change user calibration pass code
With the unit off, press and hold the DOWN button, then press the
front button.
Release all buttons when the display indicates CAL.
Enter access code 1220
Before the unit enters the view or change pass code mode, the dis-
play initially indicates ' _ _ _ _ ' with the first underscore blinking,
and with CFGPC or CALPC on the character display.
Note: The gauge will automatically revert to normal operation if no
buttons are operated for approximately 15 seconds.
To cancel and return to normal operation, press and release the
POWER button without entering any pass code characters.
1. Use the UP and DOWN buttons to set the left-most digit to 1.
2. Press and release the front button to move to the next position.
The 1 will remain, and the second position will be blinking.
3. Use the UP and DOWN buttons to select 2.
4. Press and release the front button to index to the next position.
12 will remain, and the third position will be blinking.
5. Use the UP and DOWN buttons to select 2.
6. Press and release the front button to move to the next position.
1 2 2 will remain, and the fourth position will be blinking.
7. Use the UP and DOWN buttons to select 0.
8. Press and release the front button to proceed.
Note: If an incorrect access code was entered, the gauge will return
to the start of the access code entry sequence.
Once the access code has been entered correctly, the display will
indicate the existing user-defined pass code with CFGPC or CALPC
on the character segments.
1. Operate the UP or DOWN button to select the first character of
the new pass code.
2. When the correct first character is being displayed, press and
release the front button to proceed to the next pass code char-
acter.
3. Repeat above until the entire pass code is complete.
4. To exit, press and hold the front button. Release the button
when the display indicates ---- to restart the gauge.
5. Replace the rear cover taking care not to pinch the power wires
between the cover and the case.
User-Defined Pass Code ConfigurationCalibration Calibration—continued
MOD-TRONIC Instruments ·Brampton, ON · 905-457-6322 or 1-800-794-5883 ·[e-mail] · www.mod-tronic.com
