CEL Power 8 Workshop User manual
Thanks for shopping with Improvements
!
Power 8 Workshop
8-in-1 Cordless Power Tool Set
Item # 410522
To order, call
1-800-642-2112
West Chester, OH 45069
If you have any questions regarding this product,
call 1-800-642-2112 and ask for our product
specialists (Mon.-Fri. 9:00-5:00 EST) or e-mail:
See many more products on the Internet!
www.ImprovementsCatalog.com
User Manual
Innovation from
C Enterprise Ltd
THANK YOU
Thank you for investing in a CEL power tool. The POWER workshop has
been engineered and made to demanding high quality standards, ease of
operations and Proper care of
your POWER workshop will give you years of trouble-free use.
Normal wear and tear, including accessory wear, is not covered under
guarantee. The product is guaranteed for domestic use against manufacturing
faults for a period of 12 months (for additional guarantee period please refer to
the store or agent from which you purchase the product or contact the nearest
authorized dealer). This product is not guaranteed for HIRE purpose.
If you have any questions, please contact us at:
It is possible to; download updated owner manuals, view demonstration video
and find information about new products at: www.POWER8workshop.com
Warning: User must read and understand the user manual before using this
product to reduce the risk of injury. Failure to follow all instructions may result in
electric shook, fire and/or serious personal injury. The tool must be used only for its
prescribed purpose. Any use other than those mentioned in this manual will be
considered a case of misuse. The manufacturer shall NOT be liable for any damage or
injury resulting from such cases of misuse.
8
8
safety have taken a major role in development.
Contents
Safety
1. Description of Symbols
2. Getting Started
2.1 General Safety Instructions
2.2 Tool Use and Care - Service
Power Management
3. POWERhandle
3.1 POWERhandle -
3.2 POWERhandle - Additional Safety Rules
3.3 POWERhandle - Operating Instructions
3.4 POWERhandle - Multi-Purpose Button (MPB)
3.5 POWERhandle - Maintenance
4. Charging
4.1 Charging - Specifications and Know Your Products
4.2 Charging - Additional Safety Rules
4.3 Charger Dock - Operating Instructions
4.4 Charger - Secondary Charging Point (SCP)
Handheld Power Tools
5. Drill/Driver
5.1 Drill/Driver - Specifications and Know Your Product
5.2 Drill/Driver - Additional Safety Rules
5.3 Drill/Driver - Operating Instructions
5.4 Drill/Driver - Maintenance
5.5 Drill/Driver - Notes
6. Circular Saw
6.1 Circular Saw - Specifications and Know Your Product
6.2 Circular Saw - Additional Safety Rules
6.3 Circular Saw - Operating Instructions
6.4 Circular Saw - Maintenance
Specifications and Know Your Products
3061583
Dectschland
Bauart
gepruft
Handheld Power Tools (continue)
7. Jigsaw
7.1 Jigsaw - Specifications and Know Your Product
7.2 Jigsaw - Additional Safety Rules
7.3 Jigsaw - Operating Instructions
7.4 Jigsaw - Maintenance
8. Halogen Light
8.1 Halogen Light - Specifications and Know Your Product
8.2 Halogen Light - Operating Instructions
8.3 Halogen Light - Maintenance
Bench top Functions
9. Case
9.1 Know Your Product
9.2 Post and Accessory Cases Storage and Release
10. Table Saw
10.1 Table Saw - Specifications and Know Your Product
10.2 Table Saw - Additional Safety Rules
10.3 Table Saw - Assembly
10.4 Table Saw - Operating Instructions
10.5 Table Saw - Maintenance
11. Drill Press
11.1 Drill Press - Specifications and Know Your Product
11.2 Drill Press - Additional Safety Rules
11.3 Drill Press - Assembly
11.4 Drill Press - Operating Instructions
11.5 Drill Press - Maintenance
Contents
Contents
Bench top Functions (continue)
12. Scroll Saw
12.1 Scroll Saw - Specifications and Know Your Product
12.2 Scroll Saw - Additional Safety Rules
12.3 Scroll Saw - Assembly
12.4 Scroll Saw - Operating Instructions
12.5 Scroll Saw - Maintenance
13. Table Light
13.1 Specifications and Know Your Product
13.2 Table Light Operating Instructions
Others
14. Spirit Level and Protractor
14.1 Post and Protractor Know Your Product
14.2 Post and Protractor Operating Instructions
15. Trouble Shooting
16. Additional Parts and Accessories
Handheld Power Tools (continue)
7. Jigsaw
7.1 Jigsaw - Specifications and Know Your Product
7.2 Jigsaw - Additional Safety Rules
7.3 Jigsaw - Operating Instructions
7.4 Jigsaw - Maintenance
8. Halogen Light
8.1 Halogen Light - Specifications and Know Your Product
8.2 Halogen Light - Operating Instructions
8.3 Halogen Light - Maintenance
Bench top Functions
9. Case
9.1 Know Your Product
9.2 Post and Accessory Cases Storage and Release
10. Table Saw
10.1 Table Saw - Specifications and Know Your Product
10.2 Table Saw - Additional Safety Rules
10.3 Table Saw - Assembly
10.4 Table Saw - Operating Instructions
10.5 Table Saw - Maintenance
11. Drill Press
11.1 Drill Press - Specifications and Know Your Product
11.2 Drill Press - Additional Safety Rules
11.3 Drill Press - Assembly
11.4 Drill Press - Operating Instructions
11.5 Drill Press - Maintenance
Contents
Contents
Bench top Functions (continue)
12. Scroll Saw
12.1 Scroll Saw - Specifications and Know Your Product
12.2 Scroll Saw - Additional Safety Rules
12.3 Scroll Saw - Assembly
12.4 Scroll Saw - Operating Instructions
12.5 Scroll Saw - Maintenance
13. Table Light
13.1 Specifications and Know Your Product
13.2 Table Light Operating Instructions
Others
14. Spirit Level and Protractor
14.1 Post and Protractor Know Your Product
14.2 Post and Protractor Operating Instructions
15. Trouble Shooting
16. Additional Parts and Accessories
General Safety Instructions 2.1
Work area
a) Keep your work area clean and well lit.
Cluttered benches and dark areas invite
accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power
tools create sparks which may ignite the dust or
fumes.
c) Keep bystanders, children, and visitors
away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adaptor plugs with earthed (grounded)
power tools.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
c) Do not expose power tools to rain or wet
conditions.
d) Handle the cord carefully. Never use the
cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp
edges or moving parts.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the
risk of electric shook.
Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use tool when tired or under the
influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Dress properly. Do not wear loose clothing
or jewellery. Contain long hair. Keep your hair,
clothing and gloves away from moving parts.
Loose clothes, jewellery, or long hair can be
caught in moving parts.
c) Remove adjusting keys or wrenches before
turning the tool on. A wrench or a key that is left
attached to a rotating part of the tool may result
in personal injury.
d) Do not overreach. Keep proper footing and
balance at all times. Proper footing and balance
enables better control of the tool in unexpected
situations.
e) Use safety equipment. Always wear eye
protection. Dust mask, non-skid safety shoes,
hard hat, or hearing protection must be used for
appropriate conditions.
f) Avoid accidental starting. Ensure the switch
is in the off-position before plugging. Carrying
power tools with your finger on the switch or
plugging in power tools that have the switch on
invites accidents.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
that these are connected and properly used. Use
of these devices can reduce dust-related hazard.
The safety and International symbols and pictographs that appear on this product, in the
owner’s manual and rating plate, represent important information about the product or
instructions on its use.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Read the manual.
Warning.
Do not dispose of the batteries.
Return exhausted batteries to
your local collection or
recycling point.
Do not expose to water
Contains Nickel-cadmium
batteries. Battery must be
recycled or disposed of
properly
Always change the battery
pack between temperatures
0°C to 40°C (32°F to 104°F).
Do not burn.
Recycle unwanted materials
instead of disposing of them as
waste. All tools, hoses and
packaging should be sorted,
taken to the local recycling
center and disposed of in an
environmentally safe way.
Keep hands away from blade
and working area.
For indoor use only.
Keep your hands away from
blade or working area.
Double insulation.
MAX 40°C
Description of Symbols 1.0
General Safety Instructions 2.1
Work area
a) Keep your work area clean and well lit.
Cluttered benches and dark areas invite
accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power
tools create sparks which may ignite the dust or
fumes.
c) Keep bystanders, children, and visitors
away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adaptor plugs with earthed (grounded)
power tools.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
c) Do not expose power tools to rain or wet
conditions.
d) Handle the cord carefully. Never use the
cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp
edges or moving parts.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the
risk of electric shook.
Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use tool when tired or under the
influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Dress properly. Do not wear loose clothing
or jewellery. Contain long hair. Keep your hair,
clothing and gloves away from moving parts.
Loose clothes, jewellery, or long hair can be
caught in moving parts.
c) Remove adjusting keys or wrenches before
turning the tool on. A wrench or a key that is left
attached to a rotating part of the tool may result
in personal injury.
d) Do not overreach. Keep proper footing and
balance at all times. Proper footing and balance
enables better control of the tool in unexpected
situations.
e) Use safety equipment. Always wear eye
protection. Dust mask, non-skid safety shoes,
hard hat, or hearing protection must be used for
appropriate conditions.
f) Avoid accidental starting. Ensure the switch
is in the off-position before plugging. Carrying
power tools with your finger on the switch or
plugging in power tools that have the switch on
invites accidents.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
that these are connected and properly used. Use
of these devices can reduce dust-related hazard.
The safety and International symbols and pictographs that appear on this product, in the
owner’s manual and rating plate, represent important information about the product or
instructions on its use.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Read the manual.
Warning.
Do not dispose of the batteries.
Return exhausted batteries to
your local collection or
recycling point.
Do not expose to water
Contains Nickel-cadmium
batteries. Battery must be
recycled or disposed of
properly
Always change the battery
pack between temperatures
0°C to 40°C (32°F to 104°F).
Do not burn.
Recycle unwanted materials
instead of disposing of them as
waste. All tools, hoses and
packaging should be sorted,
taken to the local recycling
center and disposed of in an
environmentally safe way.
Keep hands away from blade
and working area.
For indoor use only.
Keep your hands away from
blade or working area.
Double insulation.
MAX 40°C
Description of Symbols 1.0
Tool Use and Care - Service 2.2
h) Only use accessories that are
only
recommended by the manufacturer for your
model. Accessories that may be suitable for
one tool, may become hazardous when used on
another tool.
Service
a) Tool service must be performed only by
qualified repair personnel. Service or
maintenance performed by unqualified
personnel could result in a risk of injury.
b) When servicing a tool, use identical
replacement parts. Follow instructions in the
Maintenance section of this manual. Use of
unauthorized parts or failure to follow
Maintenance instructions may create a risk of
electric shook or injury.
Tool use and care
a) Use clamps or other practical ways to
secure and support the workpiece to a stable
platform. Holding the work by hand or against
your body is unstable and may lead to loss of
control.
b) Do not force tool. Use the correct tool for
your application. The correct tool will do the job
better and safer at the rate for which it is
designed.
c) Do not use the tool if switch does not
turn it on or off. Any tool that cannot be
controlled with the switch is dangerous and must
be repaired.
d) Disconnect the plug from the power
source before making any adjustments,
changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tools accidentally.
e) Store idle tools out of reach of children
and other untrained persons. Tools are
dangerous in the hands of untrained users.
f) Maintain tools with care. Keep cutting
tools sharp and clean. Properly maintained
tools, with sharp cutting edges are less likely to
bind and are easier to control.
g) Check for misalignment or binding of
moving parts, breakage of parts, and any
other condition that may affect the tools
operation. If damaged, have the tool serviced
before using. Many accidents are caused by
poorly maintained tools.
3. POWERhandle
Tool Use and Care - Service 2.2
h) Only use accessories that are
only
recommended by the manufacturer for your
model. Accessories that may be suitable for
one tool, may become hazardous when used on
another tool.
Service
a) Tool service must be performed only by
qualified repair personnel. Service or
maintenance performed by unqualified
personnel could result in a risk of injury.
b) When servicing a tool, use identical
replacement parts. Follow instructions in the
Maintenance section of this manual. Use of
unauthorized parts or failure to follow
Maintenance instructions may create a risk of
electric shook or injury.
Tool use and care
a) Use clamps or other practical ways to
secure and support the workpiece to a stable
platform. Holding the work by hand or against
your body is unstable and may lead to loss of
control.
b) Do not force tool. Use the correct tool for
your application. The correct tool will do the job
better and safer at the rate for which it is
designed.
c) Do not use the tool if switch does not
turn it on or off. Any tool that cannot be
controlled with the switch is dangerous and must
be repaired.
d) Disconnect the plug from the power
source before making any adjustments,
changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tools accidentally.
e) Store idle tools out of reach of children
and other untrained persons. Tools are
dangerous in the hands of untrained users.
f) Maintain tools with care. Keep cutting
tools sharp and clean. Properly maintained
tools, with sharp cutting edges are less likely to
bind and are easier to control.
g) Check for misalignment or binding of
moving parts, breakage of parts, and any
other condition that may affect the tools
operation. If damaged, have the tool serviced
before using. Many accidents are caused by
poorly maintained tools.
3. POWERhandle
Know Your Product
Voltage:
18V
Charger:
240 or 120V ~ 50 or 60Hz
Batteries: 15 x 1.2v Ni-Cd1.5Ah
Charging time: 1 Hour
Weight: 2.2 lbs (0.95 kg)
POWERhandle - Specifications and Know Your Product 3.1
1. Rails
2. Product release latch
3. Rear soft grip
4. Battery cooling vent
5. Electronic coupling
6. Mechanical coupling parts
7. MPB (Multi-Purpose-Button)
8. Power Trigger
9. Front soft grip
10. Loop handle socket
11. Battery cooling vent.
Specifications
POWERhandle - Know Your Product 3.1
1
2
3
4
5
8
9
10
11
6
7
Know Your Product
Voltage:
18V
Charger:
240 or 120V ~ 50 or 60Hz
Batteries: 15 x 1.2v Ni-Cd1.5Ah
Charging time: 1 Hour
Weight: 2.2 lbs (0.95 kg)
POWERhandle - Specifications and Know Your Product 3.1
1. Rails
2. Product release latch
3. Rear soft grip
4. Battery cooling vent
5. Electronic coupling
6. Mechanical coupling parts
7. MPB (Multi-Purpose-Button)
8. Power Trigger
9. Front soft grip
10. Loop handle socket
11. Battery cooling vent.
Specifications
POWERhandle - Know Your Product 3.1
1
2
3
4
5
8
9
10
11
6
7
Additional Safety Rules
Battery Packs
a) Ensure the switch is in the off position
before inserting the POWERhandle (battery).
Inserting the battery pack into power tools that
have the switch on invites accidents.
b) A battery operated tool with integral
batteries or a separate battery pack must be
recharged only with the specified charger for
the battery. A charger that may be suitable for
one type of battery may create a risk of fire when
used with another battery.
c) Use battery operated tool only with
specifically designated battery pack. Use of
any other batteries may create a risk of fire.
d) The battery pack for this tool has been
shipped in a low charge condition. You should
charge the battery pack fully before use.
e) Avoid conducting short charges. Make sure
that the battery is fully charged every time by
allowing the charger to complete its full charging
cycle.
f) Never allow the drill to come to a complete
standstill before recharging. The battery should
be placed on charge whenever it is noticeably
running down or the drill no longer performs a
task it previously performed.
g) To ensure the longest battery life and best
battery performance, always charge the battery
when the air temperature is between 18-24°C
(65-75°F). Do not charge or store the battery
pack below 4°C (40°F), or above 40°C (104°F).
This is important. Failure to observe this safety
rule could cause serious damage to the battery
pack.
h) Do not incinerate the battery pack even if it is
seriously damaged or can no longer hold a
charge. The battery pack can explode in a fire.
i) A small leakage of liquid from the battery
pack may occur under extreme usage or
temperature conditions. This does not
necessarily indicate a failure of the battery pack.
However, if the outer seal is broken and this
leakage comes into contact with your skin:
?Wash the affected area quickly with soap and
water
?Neutralise the liquid with a mild acid such as
lemon juice or vinegar
If the leakage gets into your eyes:
?Flush your eyes with clean water for a
minimum of 10 minutes and seek immediate
medical attention. Inform the medical staff
that the liquid is a 25-35% solution of
potassium hydroxide.5. Never attempt to
open the battery pack for any reason. If the
plastic housing of the battery pack breaks
open or cracks, immediately discontinue its
use and do not recharge it.
j) Do not store or carry a spare battery pack in
a pocket or toolbox or any other place where it
may come into contact with metal objects. The
battery pack may be short circuited causing
damage to the battery pack, burns or a fire.
I) If the battery of the POWERhandle (battery
pack) utilises nickel-cadmium cells, beware that
cadmium is considered to be a toxic material.
k) Use an environmentally safe disposal unit at
a municipal waste disposal centre to dispose of
a damaged or worn out battery, or return it to
your dealer.
POWERhandle - Additional Safety Rules 3.2
1. To fit the POWERhandle to a product, grip
one in each hand and align the rails. Push the
POWERhandle forward onto the product until it
‘clicks’ and will move no further. To ensure that it
is fully assembled, try to pull them apart; they
should be locked together.
2. To release a POWERhandle from a product,
first pull the release slider down with your thumb
whilst gripping the handle. Grip the product head
with the other hand and pull the POWERhandle
backwards. The handle should easily slide off
the product.
All POWER8 components are connected and
disconnected in this way; it is also necessary to
slide the product release slider down to remove
the POWERhandle from the charger dock.
POWERhandle - Operating Instructions 3.3
1
2
2
1
2
Additional Safety Rules
Battery Packs
a) Ensure the switch is in the off position
before inserting the POWERhandle (battery).
Inserting the battery pack into power tools that
have the switch on invites accidents.
b) A battery operated tool with integral
batteries or a separate battery pack must be
recharged only with the specified charger for
the battery. A charger that may be suitable for
one type of battery may create a risk of fire when
used with another battery.
c) Use battery operated tool only with
specifically designated battery pack. Use of
any other batteries may create a risk of fire.
d) The battery pack for this tool has been
shipped in a low charge condition. You should
charge the battery pack fully before use.
e) Avoid conducting short charges. Make sure
that the battery is fully charged every time by
allowing the charger to complete its full charging
cycle.
f) Never allow the drill to come to a complete
standstill before recharging. The battery should
be placed on charge whenever it is noticeably
running down or the drill no longer performs a
task it previously performed.
g) To ensure the longest battery life and best
battery performance, always charge the battery
when the air temperature is between 18-24°C
(65-75°F). Do not charge or store the battery
pack below 4°C (40°F), or above 40°C (104°F).
This is important. Failure to observe this safety
rule could cause serious damage to the battery
pack.
h) Do not incinerate the battery pack even if it is
seriously damaged or can no longer hold a
charge. The battery pack can explode in a fire.
i) A small leakage of liquid from the battery
pack may occur under extreme usage or
temperature conditions. This does not
necessarily indicate a failure of the battery pack.
However, if the outer seal is broken and this
leakage comes into contact with your skin:
?Wash the affected area quickly with soap and
water
?Neutralise the liquid with a mild acid such as
lemon juice or vinegar
If the leakage gets into your eyes:
?Flush your eyes with clean water for a
minimum of 10 minutes and seek immediate
medical attention. Inform the medical staff
that the liquid is a 25-35% solution of
potassium hydroxide.5. Never attempt to
open the battery pack for any reason. If the
plastic housing of the battery pack breaks
open or cracks, immediately discontinue its
use and do not recharge it.
j) Do not store or carry a spare battery pack in
a pocket or toolbox or any other place where it
may come into contact with metal objects. The
battery pack may be short circuited causing
damage to the battery pack, burns or a fire.
I) If the battery of the POWERhandle (battery
pack) utilises nickel-cadmium cells, beware that
cadmium is considered to be a toxic material.
k) Use an environmentally safe disposal unit at
a municipal waste disposal centre to dispose of
a damaged or worn out battery, or return it to
your dealer.
POWERhandle - Additional Safety Rules 3.2
1. To fit the POWERhandle to a product, grip
one in each hand and align the rails. Push the
POWERhandle forward onto the product until it
‘clicks’ and will move no further. To ensure that it
is fully assembled, try to pull them apart; they
should be locked together.
2. To release a POWERhandle from a product,
first pull the release slider down with your thumb
whilst gripping the handle. Grip the product head
with the other hand and pull the POWERhandle
backwards. The handle should easily slide off
the product.
All POWER8 components are connected and
disconnected in this way; it is also necessary to
slide the product release slider down to remove
the POWERhandle from the charger dock.
POWERhandle - Operating Instructions 3.3
1
2
2
1
2
POWERhandle - Multi-Purpose Button (MBP) 3.4
The MPB (Multi-Purpose-Button) will adapt its
function to the requirements of the product
attached to the POWERhandle.
For example when the POWERhandle is
connected to;
The Drill/Driver:
direction control
The Halogen Light: .
on / off / flashes (press trigger)
The Jigsaw and Circular Saw:
safety button, pressed before the
trigger is released.
The MPB has 3 normal positions; fully left,
centred and fully right. It is not possible to move
the MPB when the trigger is pulled and when the
MPB is centred the trigger will be locked
forward.
The trigger will also perform differently when the
POWERhandle is attached to different products.
Some products may require variable power,
others a simple on/off. For example: the drill
spindle speed is controlled by the amount the
trigger is pulled, but the Circular Saw only
requires on/off.
4. Charging Dock and
Secondary Charger (SCP)
POWERhandle - Multi-Purpose Button (MBP) 3.4
The MPB (Multi-Purpose-Button) will adapt its
function to the requirements of the product
attached to the POWERhandle.
For example when the POWERhandle is
connected to;
The Drill/Driver:
direction control
The Halogen Light: .
on / off / flashes (press trigger)
The Jigsaw and Circular Saw:
safety button, pressed before the
trigger is released.
The MPB has 3 normal positions; fully left,
centred and fully right. It is not possible to move
the MPB when the trigger is pulled and when the
MPB is centred the trigger will be locked
forward.
The trigger will also perform differently when the
POWERhandle is attached to different products.
Some products may require variable power,
others a simple on/off. For example: the drill
spindle speed is controlled by the amount the
trigger is pulled, but the Circular Saw only
requires on/off.
4. Charging Dock and
Secondary Charger (SCP)
Charging - Additional Safety Rules
Know Your Product
Input:
120 or 240V AC 50/60Hz 46W
Output:
18V DC 1.5A
Charging time: 1 Hour
Specifications
Charging - Specification and Know Your Product 4.1
1. Before using the charger (Handle Dock), read
all the instructions and cautionary markings on
the charger and battery pack (POWERhandle)
as well as the instructions on using the battery
pack.
2. This charger is designed for indoor use only.
Do not charge your batteries outdoors.
3. DANGER: Do not allow any liquid to come
into contact with the charger. There is a danger
of electric shook.
4. The charger is not intended for any use other
than charging the exact type of rechargeable
battery pack as supplied with the charger. Any
other use may result in the risk of fire, electric
shook or electrocution.
5. To reduce the risk of an electric shook, unplug
the charger from the power supply before
attempting to clean it.
6. Do not disassemble the charger. Take it to an
authorised service center when service or repair
is required. Incorrect re-assembly may result in
the risk of fire, electric shook or electrocution.
7. Do not pull on the lead of the charger to
disconnect it from the power source. Do not
carry the charger by the cable. Protect the cable
from sharp objects, heat and oil; have it replaced
if damaged.
4.2
Charging Dock - Operating Instructions 4.3
The POWERhandle has been shipped in a low
charge condition. You should charge the battery
fully before use.
WARNING. Do not throw used POWERhandles
into a fire or water; it could cause an explosion!
NOTE. It is necessary to slide down the product
release latch in order to remove the
POWERhandle from the charger dock, or from
the tools.
To charge the POWERhandle slide it into the
charger dock; the rails of the POWERhandle
should be aligned with the rails of the charger
dock. Slide the battery down until it “clicks” into
position. Connect the mains plug to a suitable
mains outlet.
LED’s on the top of the charger dock
will display the battery’s condition.
When the green LED is on, the case
is correctly connected to the mains
power. A green flashing LED means
fast charging. When the red LED is on,
the POWERhandle is fully charged
Full
Charging
fast ready
Secondary
Charger
Point(SCP)
Charger Dock
POWERhandle
LED Display
Charging - Additional Safety Rules
Know Your Product
Input:
120 or 240V AC 50/60Hz 46W
Output:
18V DC 1.5A
Charging time: 1 Hour
Specifications
Charging - Specification and Know Your Product 4.1
1. Before using the charger (Handle Dock), read
all the instructions and cautionary markings on
the charger and battery pack (POWERhandle)
as well as the instructions on using the battery
pack.
2. This charger is designed for indoor use only.
Do not charge your batteries outdoors.
3. DANGER: Do not allow any liquid to come
into contact with the charger. There is a danger
of electric shook.
4. The charger is not intended for any use other
than charging the exact type of rechargeable
battery pack as supplied with the charger. Any
other use may result in the risk of fire, electric
shook or electrocution.
5. To reduce the risk of an electric shook, unplug
the charger from the power supply before
attempting to clean it.
6. Do not disassemble the charger. Take it to an
authorised service center when service or repair
is required. Incorrect re-assembly may result in
the risk of fire, electric shook or electrocution.
7. Do not pull on the lead of the charger to
disconnect it from the power source. Do not
carry the charger by the cable. Protect the cable
from sharp objects, heat and oil; have it replaced
if damaged.
4.2
Charging Dock - Operating Instructions 4.3
The POWERhandle has been shipped in a low
charge condition. You should charge the battery
fully before use.
WARNING. Do not throw used POWERhandles
into a fire or water; it could cause an explosion!
NOTE. It is necessary to slide down the product
release latch in order to remove the
POWERhandle from the charger dock, or from
the tools.
To charge the POWERhandle slide it into the
charger dock; the rails of the POWERhandle
should be aligned with the rails of the charger
dock. Slide the battery down until it “clicks” into
position. Connect the mains plug to a suitable
mains outlet.
LED’s on the top of the charger dock
will display the battery’s condition.
When the green LED is on, the case
is correctly connected to the mains
power. A green flashing LED means
fast charging. When the red LED is on,
the POWERhandle is fully charged
Full
Charging
fast ready
Secondary
Charger
Point(SCP)
Charger Dock
POWERhandle
LED Display
Charging - Secondary Charger Point (SCP) 4.4
As well as the main charger dock the
POWER8works is fitted with a secondary
charger point(SCP). This allows a
POWERhandle to be charged while a second
POWERhandle is powering the
POWER8workshop benchtop functions.
When the secondary charger point is removed
from the charger dock, the dock will not charge a
POWERhandle. The secondary charger point
must be correctly replaced into the side of the
charger dock to start charging the
POWERhandle in the dock.
As soon as a POWERhandle is connected to the
SCP, and the mains plug is connected to a
suitable power source, it will start the charging
cycle.
To obtain the best life for the battery:
Never allow the battery to completely discharge;
it should be placed on charge whenever it is
noticeably running down, or the tool no longer
performs a task it previously performed.
Avoid conducting short charges. Make sure that
the battery is fully charged every time by
allowing the charger to complete its full charging
cycle.
Avoid allowing loose items like screws or nails
etc. to be stored with battery packs as this may
cause a fire or explosion.
Always unplug the charger when not in use and
store in a dry, secure place. Avoid charging or
storing your battery in temperatures below 0°C
(32°F), and above 40°C (104°F).
5. Drill/Driver
Charging - Secondary Charger Point (SCP) 4.4
As well as the main charger dock the
POWER8works is fitted with a secondary
charger point(SCP). This allows a
POWERhandle to be charged while a second
POWERhandle is powering the
POWER8workshop benchtop functions.
When the secondary charger point is removed
from the charger dock, the dock will not charge a
POWERhandle. The secondary charger point
must be correctly replaced into the side of the
charger dock to start charging the
POWERhandle in the dock.
As soon as a POWERhandle is connected to the
SCP, and the mains plug is connected to a
suitable power source, it will start the charging
cycle.
To obtain the best life for the battery:
Never allow the battery to completely discharge;
it should be placed on charge whenever it is
noticeably running down, or the tool no longer
performs a task it previously performed.
Avoid conducting short charges. Make sure that
the battery is fully charged every time by
allowing the charger to complete its full charging
cycle.
Avoid allowing loose items like screws or nails
etc. to be stored with battery packs as this may
cause a fire or explosion.
Always unplug the charger when not in use and
store in a dry, secure place. Avoid charging or
storing your battery in temperatures below 0°C
(32°F), and above 40°C (104°F).
5. Drill/Driver
67
2
8
1
9
3
11
5 4
9
10
11
Drill/Driver - Specifications and Know Your Product 5.1 Drill/Driver - Know Your Product 5.1
Know Your product
1. Variable power trigger/Stop
2. MPB(Direction selector/lock)
3. Soft grip
4. Motor cooling vents
5. Keyless chuck
6. 2 Speed gearbox selector
7. Torque/Hammer selector
8. Replaceable brush cover
9. Battery cooling vents
10. Handle release latch
11. Driver bit
Voltage: 18V
No load speed: 0-350, 0-1,250 RPM
Torque settings:
20 Positions
Max drilling capacity:
Steel 1/2” (13 mm)
Wood 1 1/10” (28 mm)
Concrete 1/2” (13 mm)
Hammer impact frequency:
0-5,600, 0-20,000 min -1
Single Sleeve
Drill chuck capacity:
Weight: (WS1-HD01) 4.3lbs (2.4 kg)
Specifications
½” (13 mm) keyless
Weight: (WS1-LD01) 4.7lbs (2.1 kg)
Double Sleeve
Drill chuck capacity: (10 mm) keyless
NOTE. Hammer Mode is not available on drill model WS1-LD01
Table of contents
Other CEL Power Tools manuals
