Sealey YK15 User manual

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
2. INTRODUCTION & SPECIFICATIONS
FLOOR Models: YK15, YK15FM, YK30, YK30FM, YK50FM.
BENCH Models: YK10BM, YK15BLG, YK15BM.
1. SAFETY INSTRUCTIONS
2.1. GENERAL INFORMATION
The Sealey range of heavy duty floor and bench hydraulic presses are ideal for a variety of workshop applications and are particularly suited
to agricultural or industrial use. Jobs such as straightening, bending, folding, punching, removing bolts and bearings etc are some of tasks that
may be accomplished by your press. All models are fitted with pressure gauge and work-table V-blocks except where stated. The BM and FM
range of press units feature integrally mounted rams giving more vertical clearance between the table and ram head enabling larger items
to be fitted on the working table.
p p
p p
WARNING! All models are purpose designed to withstand greater loads than the hydraulic units can develop. For safety reasons, always
ensure the workpiece is secured on table and loads that flex will not suddenly give causing danger to operator or damage to component.
1.2 GENERAL SAFETY
3Familiarise yourself with this products application and limitations, as well as the specific potential hazards peculiar to the press.
3Maintain the press in good condition (use an authorised service agent).
3Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the warranty.
3Keep the press clean for best and safest performance.
3Locate the press in an adequate working area for its function, keep area clean and tidy and free from unrelated materials, and ensure
there is adequate lighting.
3Ensure the workpiece is correctly secured before operating the press.
pWARNING! Always wear approved eye or face protection when operating the press.
3Remove ill fitting clothing. Remove ties, watches, rings, and other loose jewellery, and contain long hair.
3Keep hands and body clear of the work table when operating the press.
3Maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.
3Keep children and unauthorised persons away from the working area.
7DO NOT operate the press if any parts are missing as this may cause failure or possible personal injury.
7DO NOT force the press to achieve a task it was not designed to perform.
7DO NOT adjust or tamper with the safety valve.
7DO NOT exceed the rated capacity of the press.
7DO NOT apply off centre loads.
7DO NOT allow the workpiece of the arbor plates to fall from the press working bench.
7DO NOT get the press wet or use in damp or wet locations or areas where there is condensation.
7DO NOT operate the press when you are tired, under the influence of alcohol, drugs or intoxicating medication.
3When not in use release pressure from the pump and clean the press. Stand or store the arbors in a safe location.
Unpack product and check contents against list below. Should there be any damaged or missing parts contact your supplier immediately.
Take care to ensure safety when removing main frame from packing as the unit is very heavy. Retain pressure gauge in carton until required,
and do not remove white tape from gauge mount or masking tape from the angle arm.
Contents:
3Frame 3legs x2 3worktable x1 3worktable pins x2 3v-blocks x2 3pump handle x1 3pressure gauge x1 (except model YK15BLG)
3gauge angle arm connector x1. 50Ton models incorporate winch handle.
3.1. Press Assembly
3.1.1. Identity and lay out parts. Handle the main frame with care and lay horizontally allowing the cross legs to be bolted on to the bottom
of the pre-assembled main frame. Note: care must be taken when handling the main frame to ensure stability. DO NOT allow to fall.
3. ASSEMBLY
INSTRUCTIONS FOR:
HYDRAULIC BENCH & FLOOR PRESS
2.2. SPECIFICATIONS
Model: YK15BLG YK10BM YK15BM YK15 YK15FM YK30 YK30FM YK50FM
Capacity 15T 10T 15T 15T 15T 30T 30T 50T
Ram Stroke 150mm 95mm 95mm 150mm 95mm 150mm 95mm 95mm
Extension screw 60mm 70mm 70mm 60mm 67mm 60mm 70mm 70mm
Ram to table 300mm 455mm 455mm 600mm 600mm 600mm 620mm 615mm
Min Ht-Ram to table 150mm 155mm 155mm 150mm 150mm 150mm 180mm 165mm
Table Aperture 112mm 140mm 140mm 112mm 140mm 133mm 143mm 170mm
Work table width 500mm 500mm 500mm 500mm 500mm 550mm 550mm 550mm
Overall Height 945mm 1035mm 945mm 1675mm 1650mm 1750mm 1750mm 1830mm
Gauge Included no yes yes yes yes yes yes yes
Weight 69kg 65kg 69kg 80kg 86kg 122kg 125kg 240kg
YK10BM, YK15, YK15BLG, YK15BM, YK15FM, YK30, YK30FM, YK50FM. - 0025 - 050897

Note: Maintenance and repair must only be carried out by qualified person. Contact your Sealey dealer for details.
5.1. Lubricate all moving parts at regular intervals.
5.2. Always keep the press clean, dry, and protected from harsh conditions.
5.3. Should you need to replace oil ensure piston is fully retracted. An excess of oil will render press inoperative. Use only appropriate
Sealey hydraulic oil. DO NOT use brake fluid. Contact your local Sealey dealer for details. Purge the system to remove any air.
5.4. Check your model parts information for spares. Repair kits are also available.
5. MAINTENANCE
Declaration of Conformity We, the sole importer into the UK, declare that the productslisted below are in conformity with the following
EEC standards and directives.
The construction files for these productsare held by the Manufacturer
and may be inspected on request by contacting Jack Sealey Ltd
For Jack Sealey Ltd. Sole importer into the UK of Sealey Quality Machinery
Hydraulic Press Models
YK10BM, YK15, YK15BLG, YK15BM,
YK15FM, YK30, YK30FM, YK50FM.
Machine Directive (S.L. 1992/3073)
93/68/EEC CE Marking Directive
Signed by John Sealey Date 1st September 1998
4.1. INSTALLATION.
4.1.1. Securely attach the press to a flat, firm, level surface taking into account clearance for working pieces. Should you wish to mount
a bench press on a workbench or surface, ensure the bench is flat and level and is strong enough to support the press
and any workpiece during operation.
4.1.2. Purge hydraulic system.
Before operating the press, purge the hydraulic system in order to eliminate any air that may have built up during transit. Open the release
valve and pump the handle several times. Should the system malfunction at any time, repeating this process may resolve the problem.
s s
s s
s
DANGER! Models are purpose designed to withstand greater loads than the hydraulic units can develop. For safety reasons, always ensure
the workpiece is secured on table and loads that flex will not suddenly give causing danger to operator or damage to component. Also ensure
you have read and understood chapter 1 safety instructions.
4.2. OPERATING INSTRUCTIONS.
4.2.1. Using press adjustable table support pins place the press working table at the required operating height.
4.2.2. Check that the hydraulic unit is fully closed ready for operating.
4.2.3. Place workpiece onto the work table or the two arbors appropriately positioned. Position the head of the hydraulic unit on the centre
of the workpiece using appropriate extension. Note: care must be taken to ensure an arbor does not fall from the press worktable.
4.2.4. DO NOT exceed the stroke indicated on the label or the red mark on the piston.
4.2.5. DO NOT apply off centre loads.
4.2.6. When work is complete release the pressure and the piston and the ram head will retract automatically.
Note: Always keep the piston, extension screw and pump piston retracted after use.
4. INSTALLATION & OPERATING
3.1.2. Locate the pressure gauge inlet hole in the head of the press hydraulic system and remove the dust plug with a hex key, (this may
be very tightly secured). Note: There is no pressure gauge on the YK15BLG.3.1.3. Fitting pressure gauge.
a) For models with integral hydraulic system screw gauge angle arm (retain white tape around thread) into inlet hole, Find the outlet
hole by feeling through the tape and ensure the final tightening of the arm leaves the outlet facing upward. DO NOT over tighten.
Remove the masking tape carefully exposing the rubber seal which must lay flat in the bottom of the outlet hole.
b) Remove the pressure gauge from carton and screw into the angle arm securing with a spanner.
c) For models with a standard hydraulic system (YK15, YK30,) screw the pressure gauge directly into the system inlet hole
by holding the gauge to the front and turning the nut at the head of the connector.
3.1.3. For installation see chapter 4.
3.1.4. Once installed, screw the pump handle into the pump arm.
3.1.5. Insert the work table pins through holes in the main frame and carefully place the work table between the frame upright
lowering it onto the pins accordingly. pWARNING! Take care not to allow the working table to drop onto the pins and ensure your
hands and fingers are clear of the working table when lowered.
3.1.6. Place v-blocks on work table ready for use. Take care to ensure the v-blocks do not fall from the work table.
YK10BM, YK15, YK15BLG, YK15BM, YK15FM, YK30, YK30FM, YK50FM. - 0025 -050897
IMPORTANT: NO RESPONSIBILITY IS ACCEPTED FOR INCORRECT USE OF THE MACHINE.
Hydraulic products are only repaired by local service agents. We have service/repair agents in all parts of the UK.
DO NOT RETURN PRODUCT TO US. Please telephone us on 01284 757500 to obtain the address and phone number of your local agent.
If product is under guarantee please contact your dealer.
De-commissioning Product
Should the product become completely unserviceable and require disposal, draw off the oil into an approved container and dispose
of the product and the oil according to local regulations.
01284 757500 E-mail: [e-mail]
01284 703534
Sealey Group,
Bury St. Edmunds, Suffolk.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No responsibility is accepted for incorrect use of this product. WARRANTY: Guarantee is 12 months from purchase date. Proof of purchase
will be required for any claim. INFORMATION: Please call us for a copy of our latest catalogue
